Scheme 180
Scheme 181
Scheme 182
Scheme 183
Scheme 184
Scheme 185
| Callout | Component Name |
|---|---|
| 1 | Cigar Lighter |
| 2 | Instrument Panel |
| 3 | Auxiliary Power Outlet - Front |
Callouts For (Scheme 185)
Scheme 186
| Callout | Component Name |
|---|---|
| 1 | Auxiliary Power Outlet - Front Connector |
| 2 | S333 |
| 3 | S307 |
| 4 | S303 |
| 5 | Rear Seat Audio (RSA) Controller Connector |
| 6 | Auxiliary Power Outlet - Console Connector |
| 7 | Audio Amplifier Connector C2 (UQ7) |
| 8 | Audio Amplifier Connector C1 (UQ7) |
| 9 | Cigar Lighter |
| 10 | C306 |
| 11 | Noise Compensation Microphone (UQ7 w/Y91) |
| 12 | Speaker - Subwoofer Connector |
| 13 | Speaker - Subwoofer (UQ7) |
Callouts For (Scheme 186)
Scheme 187
| Callout | Component Name |
|---|---|
| 1 | Auxiliary Power Outlet Switch (HP2) |
Callouts For (Scheme 187)
Scheme 188
| Callout | Component Name |
|---|---|
| 1 | Auxiliary Power Outlet 120-Volt AC - Interior (HP2) |
| 2 | Energy Storage Box (ESB) |
Callouts For (Scheme 188)
Scheme 189
| Callout | Component Name |
|---|---|
| 1 | Auxiliary Power Outlet 120-Volt AC - Exterior (HP2) |
Callouts For (Scheme 189)
Circuit/System Description
The auxiliary power outlet (APO) switch controls the operation of the hybrid control module (HCM) APO state manager. The APO state manager commands one of 3 states from the starter generator control module (SGCM), (APO Off, APO Normal, APO Continuous). The APO switch is a momentary button, its output signal an input to an HCM analogue channel. Five volts are supplied to the switch, the returned voltage is measured relative to HCM signal ground to determine the switch state. A resistor network in the switch circuitry ensures that shorted high and low states can be diagnosed successfully. There are 2 valid voltage ranges of the return signal, one representing switch open, the other representing switch closed. If the voltage is lower than a threshold, a short low is indicated. Similarly, if the voltage is greater than the short high threshold, a short 'high' is indicated.
The SGCM uses the interlock circuit to monitor the plugs and connectors for hybrid system function. The interlock indicates the state of the connectors in the 120 voltage circuits. In the SGCM, the primary side of the transformer is connected to a low frequency oscillator circuit. When the loop is complete, the shorted secondary reduces the oscillator voltage, and a comparator senses this as a good and complete interlock loop. If the loop is open, the oscillator amplitude increases and the comparator senses this as a problem. Short Circuits, Overloads and Ground Fault Detection (GFD)
