HVAC Systems - Automatic: Removal & Installation Chevrolet Silverado 1500

Installation Procedure

1. Connect the electrical connectors to the HVAC control module.
2. Install the HVAC control module into the instrument panel, ensuring that the HVAC control module retaining tabs lock into place.
3. Install the screws from the HVAC control module. Tighten: Tighten the screws to 1.9 N.m (17 lb in).
4. Install the instrument panel accessory trim plate. Refer to «Bezel Replacement - Instrument Panel (I/P) Cluster»(ref-238186-S39159874752006072400000) in Instrument Panel, Gages and Console.
5. Start the vehicle and let run for one minute.

Scheme 95

Scheme 96

1. If equipped, remove the sound insulator panel. Refer to «Insulator Replacement - Instrument Panel (I/P)»(ref-238186-S25054897752006072400000) in Instrument Panel, Gages and Console.
2. Disconnect the electrical connector at the blower motor.
3. Disconnect the electrical connector (4) from the blower motor control processor (2).
4. Remove the blower motor control processor retaining screws (3) from the HVAC module (1).
5. Remove the blower motor control processor (2) from the HVAC module (1).

1. Install the blower motor control processor (2) to the HVAC module (1).
2. Install the blower motor control processor retaining screws. Tighten: Tighten the screws to 1.6 N.m (14 lb in).
3. Connect the electrical connector (4) to the blower motor control processor (2).
4. Connect the electrical connector at the blower motor.
5. If equipped, install the sound insulator panel. Refer to «Insulator Replacement - Instrument Panel (I/P)»(ref-238186-S25054897752006072400000) in Instrument Panel, Gages and Console.

Scheme 97

Scheme 98

1. Remove the air distribution duct. Refer to «Air Distributor Duct Replacement»(ref-238212-S23018334452006072400000) in Heating, Ventilation and Air Conditioning.
2. Disconnect the electrical connection from the recirculation actuator (1).
3. Remove the recirculation actuator retaining screws.
4. Remove the recirculation actuator.

1. Install the recirculation actuator.
2. Install the recirculation actuator retaining screws. Tighten: Tighten the screws to 1.6 N.m (14 lb in).
3. Connect the electrical connector to the recirculation actuator (1).
4. Install the air distribution duct. Refer to «Air Distributor Duct Replacement»(ref-238212-S23018334452006072400000) in Heating, Ventilation and Air Conditioning.

Scheme 99

Scheme 100

1. Remove the floor air outlet duct extension (1) from the floor duct (2).
2. Remove the center console. Refer to «Console Replacement (w/Console Mounting Bracket)»(ref-238186-S13709555522006072400000) or «Console Replacement (w/o Console Mounting Bracket)»(ref-238186-S17950090572006072400000) in Instrument Panel, Gages and Console.
3. Remove the screws from the center console duct.
4. Remove the center console duct.
5. Disconnect the electrical connection from the mode actuator (10).
6. Remove the mode actuator mounting screws from the HVAC module.
7. Remove the mode actuator as an assembly with the actuator cam.

1. Install the mode actuator as an assembly with the actuator cam. Line up the heater/defroster valve lever with the mode actuator cam slot. Line up the A/C valve lever with the mode actuator cam.
2. Install the mode actuator mounting screws to the HVAC module. Tighten: Tighten the screws to 1.6 N.m (14 lb in).
3. Connect the electrical connection at the mode actuator (10).
4. Install the center console duct.
5. Install the screws to the center console duct. Tighten: Tighten the screws to 1.6 N.m (14 lb in).
6. Install the center console. Refer to «Console Replacement (w/Console Mounting Bracket)»(ref-238186-S13709555522006072400000) or «Console Replacement (w/o Console Mounting Bracket)»(ref-238186-S17950090572006072400000) in Instrument Panel, Gages and Console.
7. Install the floor air outlet duct extension (1) to the floor air duct (2).

Removal Procedure

1. Remove the floor air outlet duct extension (1) from the floor duct (2).
2. Remove the body control module. Refer to «Body Control Module Replacement»(ref-238179-S13881127862006072400000) in Computer/Integrating Systems.
3. Disconnect the electrical connection at the mode actuator (10).
4. Remove the mode actuator mounting screws from the HVAC module.
5. Remove the mode actuator as an assembly with the actuator cam.

1. Install the mode actuator as an assembly with the actuator cam. Line up the heater/defroster lever with the mode actuator cam slot. Line up the A/C lever with the mode actuator cam.
2. Install the mode actuator mounting screws to the HVAC module. Tighten: Tighten the screws to 1.6 N.m (14 lb in).
3. Connect the electrical connection at the mode actuator (10).
4. Install the body control module. Refer to «Body Control Module Replacement»(ref-238179-S13881127862006072400000) in Computer/Integrating Systems.
5. Install the floor air outlet duct extension (1) to the floor air duct (2).

Scheme 101

1. Remove the I/P carrier. Refer to «Instrument Panel (I/P) Carrier Replacement»(ref-238186-S06717036552006072400000) in Instrument Panel, Gages and Console.
2. Disconnect the electrical connector (4) from the right air temperature actuator (3).
3. Remove the screws from the right air temperature actuator (3).
4. Remove the right air temperature actuator (3) from the HVAC module assembly (2).

1. Install the right air temperature actuator (3) to the HVAC module assembly (2).
2. Install the screws to the right air temperature actuator (3). Tighten: Tighten the screws to 2 N.m (18 lb in).
3. Connect the electrical connector to the right air temperature actuator.
4. Install the I/P carrier. Refer to «Instrument Panel (I/P) Carrier Replacement»(ref-238186-S06717036552006072400000) in Instrument Panel, Gages, and Console.
5. Reprogram the air temperature actuator. Refer to «Re-Calibrating Actuators»(ref-238240-S05049699792006072400000) .

Scheme 102

1. Remove the center console, if equipped. Refer to «Console Replacement (w/Console Mounting Bracket)»(ref-238186-S13709555522006072400000) or «Console Replacement (w/o Console Mounting Bracket)»(ref-238186-S17950090572006072400000) .
2. Remove the instrument panel (I/P) insulator panel. Refer to «Insulator Replacement - Instrument Panel (I/P)»(ref-238186-S25054897752006072400000) in Instrument Panel, Gages and Console.
3. Disconnect the electrical connector (1) from the left air temperature actuator (2).
4. Remove the screws from the left air temperature actuator (2).
5. Remove the left air temperature actuator (2) from the HVAC module assembly (3).

1. Install the left air temperature actuator (2) to the HVAC module assembly (3).
2. Install the screws to the left air temperature actuator (2). Tighten: Tighten the screws to 2 N.m (18 lb ft).
3. Install the electrical connector (1) to the left air temperature actuator (2).
4. Install the I/P insulator panel. Refer to «Insulator Replacement - Instrument Panel (I/P)»(ref-238186-S25054897752006072400000) in Instrument Panel, Gages and Console.
5. Install the center console, if equipped. Refer to «Console Replacement (w/Console Mounting Bracket)»(ref-238186-S13709555522006072400000) or «Console Replacement (w/o Console Mounting Bracket)»(ref-238186-S17950090572006072400000) .
6. Reprogram the left air temperature actuator. Refer to «Re-Calibrating Actuators»(ref-238240-S05049699792006072400000) .

Scheme 103

1. Remove the I/P upper trim panel. Refer to «Trim Panel Replacement - Instrument Panel (I/P) Upper»(ref-238186-S31882198492006072400000) in Instrument Panel, Gages, and Console.
2. Disconnect the electrical connector (1) from the upper right air temperature sensor (2).
3. Remove the upper right air temperature sensor (1) from the air distributor duct (3).

1. Install the upper right air temperature sensor (1) to the air distributor duct (3).
2. Connect the electrical connector (1) from the upper right air temperature sensor (2).
3. Install the I/P upper trim panel. Refer to «Trim Panel Replacement - Instrument Panel (I/P) Upper»(ref-238186-S31882198492006072400000) in Instrument Panel, Gages, and Console.

Scheme 104

1. Remove the upper left air temperature sensor (2) from the air distributor duct (1).
2. Disconnect the electrical connector (3) from the upper left air temperature sensor (2).

1. Install the upper left air temperature sensor (2) to the air distributor duct (1).
2. Connect the electrical connector (3) to the upper left air temperature sensor (2).

Scheme 105

1. Disconnect the electrical connector from the lower left air temperature sensor (1).
2. Remove the lower left air temperature sensor (1) from the HVAC module (2).

1. Install the lower left air temperature sensor (1) to the HVAC module (2).
2. Connect the electrical connector to the lower left air temperature sensor (1).

1. Remove the I/P lower closeout panel. Refer to «Insulator Replacement - Instrument Panel (I/P)»(ref-238186-S25054897752006072400000) in Instrument Panel, Gages, and Console.
2. Remove the right floor duct. Refer to «Air Outlet Duct Replacement - Floor, RH»(ref-238212-S03924205912006072400000) in Heating, Ventilation and Air Conditioning.
3. Remove the center console. Refer to «Console Replacement (w/Console Mounting Bracket)»(ref-238186-S13709555522006072400000) or «Console Replacement (w/o Console Mounting Bracket)»(ref-238186-S17950090572006072400000) in Instrument Panel, Gages, and Console.
4. Disconnect the electrical connector from the lower right air temperature sensor (1).
5. Remove the lower right air temperature sensor (1).

1. Install the lower right air temperature sensor (1).
2. Connect the electrical connector to the lower right air temperature sensor (1).
3. Install the center console. Refer to «Console Replacement (w/Console Mounting Bracket)»(ref-238186-S13709555522006072400000) or «Console Replacement (w/o Console Mounting Bracket)»(ref-238186-S17950090572006072400000) in Instrument Panel, Gages, and Console.
4. Install the right floor duct. Refer to «Air Outlet Duct Replacement - Floor, RH»(ref-238212-S03924205912006072400000) in Heating, Ventilation and Air Conditioning.
5. Install the I/P lower closeout panel. Refer to «Insulator Replacement - Instrument Panel (I/P)»(ref-238186-S25054897752006072400000) in Instrument Panel, Gages, and Console.

Scheme 106

1. Remove the Park/Turn Signal. Refer to «Park/Turn Signal Lamp Replacement (Old Style)»(ref-238182-S00390597082006072400000) in Lighting Systems.
2. Disconnect the electrical connector from the ambient air temperature sensor (3).
3. Remove the ambient air temperature sensor (3).

1. Install the ambient air temperature sensor (3).
2. Connect the electrical connector to the ambient air temperature sensor (3).
3. Install the Park/Turn Signal. Refer to «Park/Turn Signal Lamp Replacement (Old Style)»(ref-238182-S00390597082006072400000) in Lighting Systems.

Scheme 107

Scheme 108

1. Remove the left windshield garnish molding. Refer to «Garnish Molding Replacement - Windshield Pillar»(ref-238187-S01633474582006072400000) in Interior Trim.
2. Remove the left center pillar assist handle. Refer to «Assist Handle Replacement - Rear»(ref-238187-S08867996532006072400000) in Interior Trim.
3. Remove the left center pillar garnish molding. Refer to «Garnish Molding Replacement - Center Pillar»(ref-238187-S12227952342006072400000) in Interior Trim.
4. Remove the left sunshade. Refer to «Sunshade Replacement»(ref-238187-S02599658682006072400000) in Interior Trim.
5. Gently pull down the headliner.
6. Disconnect the electrical connector from the inside air temperature sensor.
7. Partially remove the inside air temperature sensor from the headliner.
8. Remove the sensor grille from the inside air temperature sensor.
9. Remove the inside air temperature sensor from the headliner.

1. Install the new sensor grille to the headliner.
2. Install the inside air temperature sensor to the headliner and sensor grille.
3. Connect the electrical connector to the inside air temperature sensor.
4. Install the left sunshade. Refer to «Garnish Molding Replacement - Center Pillar»(ref-238187-S12227952342006072400000) in Interior Trim.
5. Install the left center pillar garnish molding. Refer to «Garnish Molding Replacement - Center Pillar»(ref-238187-S12227952342006072400000) in Interior Trim.
6. Install the left center assist handle. Refer to «Assist Handle Replacement - Rear»(ref-238187-S08867996532006072400000) in Interior Trim.
7. Install the left windshield garnish molding. Refer to «Garnish Molding Replacement - Windshield Pillar»(ref-238187-S01633474582006072400000) in Interior Trim.

Scheme 109

1. Remove the instrument panel (I/P) upper trim panel. Refer to «Trim Panel Replacement - Instrument Panel (I/P) Upper»(ref-238186-S31882198492006072400000) in Instrument Panel, Gages and Console.
2. Remove the sun load sensor (2) from the upper trim panel.
3. Disconnect the electrical connector.

1. Connect the electrical connector.
2. Install the sun load sensor (2) to the upper trim panel.
3. Install the I/P upper trim panel. Refer to «Trim Panel Replacement - Instrument Panel (I/P) Upper»(ref-238186-S31882198492006072400000) in Instrument Panel, Gages and Console.
