POWER MIRROR SWITCH TEST
Remove power mirror switch. See POWER MIRROR SWITCH under REMOVAL & INSTALLATION. Disconnect power mirror switch connector. Using an ohmmeter, check continuity between appropriate mirror switch terminals. See POWER MIRROR SWITCH CONTINUITY TEST table. see scheme 3 Continuity should exist between indicated terminals. If continuity is not as specified, replace switch.
| Application | Terminals No. | ||
|---|---|---|---|
| Selector Switch In "L" Position | |||
| Horizontal/Vertical Switch | |||
| Up | 1 & 9; 6 & 10 | ||
| Down | 1 & 10; 6 & 9 | ||
| Left | 5 & 9; 6 & 10 | ||
| Right | 5 & 10; 6 & 9 | ||
| Selector Switch In "R" Position | |||
| Horizontal/Vertical Switch | |||
| Up | 6 & 10; 7 & 9 | ||
| Down | 6 & 9; 7 & 10 | ||
| Left | 6 & 10; 8 & 9 | ||
| Right | 6 & 9; 8 & 10 | ||
POWER MIRROR SWITCH CONTINUITY TEST
POWER MIRROR MOTOR TEST
Access power mirror motor harness connector. See POWER MIRROR ASSEMBLY under REMOVAL & INSTALLATION. Disconnect power mirror motor connector. Using 12-volt power source, connect positive and negative leads to indicated motor terminals. See POWER MIRROR MOTOR TEST table. (Scheme 3) If motor fails any test, replace power mirror assembly. See POWER MIRROR ASSEMBLY under REMOVAL & INSTALLATION.
| Apply 12 Volts To Terminal No. | Ground Terminal No. | Mirror Operation |
|---|---|---|
| 3 | 2 | Up |
| 2 | 3 | Down |
| 1 | 2 | Left |
| 2 | 1 | Right |
POWER MIRROR MOTOR TEST
