SERVICE VALVE LOCATIONS
For service valve locations, see SERVICE VALVE LOCATIONS (CARS) or SERVICE VALVE LOCATIONS (TRUCKS & VANS) table.
| Vehicle | High | Low |
|---|
| Chrysler Corp. |
| Avenger & Sebring Coupe | (1) | (2) |
| 300M, Concorde, Intrepid & LHS |
| 2.7L | (3) | (4) |
| 3.2L & 3.5L | (5) | (6) |
| Breeze, Cirrus & Stratus | (7) | (4) |
| Neon | (7) | (4) |
| Sebring Convertible | (7) | (4) |
| Ford Motor Co. |
| Continental | (9) | (10) |
| Contour, Cougar & Mystique |
| 2.0L Engine | (7) | (11) |
| 2.5L Engine | (7) | (12) |
| Crown Victoria, Grand Marquis & Town Car | (7) | (13) |
| Escort & Tracer | (14) | (10) |
| Mustang | (7) | (12) |
| Sable & Taurus | (8) | (11) |
| General Motors |
| "C" Body | (3) | (15) |
| "E" & "K" Bodies | (3) | (15) |
| "F" Body | (9) | (4) |
| "G" Body | (3) | (15) |
| "H" Body | (7) | (12) |
| "J" Body | (7) | (12) |
| "M" Body | (9) | (4) |
| "N" Body | (9) | (4) |
| "S" Body | (9) | (4) |
| "V" Body | (9) | (4) |
| "W" Body | (9) | (4) |
| "Y" Body | (3) | (12) |
| "Z" Body | (7) | (15) |
| (1) On high-side liquid line, between receiver-drier and evaporator. (2) On low-side hose between evaporator and compressor. (3) On high-side liquid line. (4) On low-side suction line. (5) On top of compressor manifold. (6) On compressor manifold, closest to compressor clutch. (7) On high-side line, between compressor and condenser. (8) On extension of high-side line, between condenser and evaporator. (9) On high-side line (or extension), near condenser. (10) On low-side line (or extension), near accumulator. (11) On low-side line, between evaporator and accumulator/receiver-drier. (12) On low-side line, between acumulator/receiver-dryer and compressor. (13) On acumulator/receiver-drier. (14) On high-side line, near condenser. (15) On low-side line, between orifice tube and evaporator. |
| (1) | On high-side liquid line, between receiver-drier and evaporator. |
| (2) | On low-side hose between evaporator and compressor. |
| (3) | On high-side liquid line. |
| (4) | On low-side suction line. |
| (5) | On top of compressor manifold. |
| (6) | On compressor manifold, closest to compressor clutch. |
| (7) | On high-side line, between compressor and condenser. |
| (8) | On extension of high-side line, between condenser and evaporator. |
| (9) | On high-side line (or extension), near condenser. |
| (10) | On low-side line (or extension), near accumulator. |
| (11) | On low-side line, between evaporator and accumulator/receiver-drier. |
| (12) | On low-side line, between acumulator/receiver-dryer and compressor. |
| (13) | On acumulator/receiver-drier. |
| (14) | On high-side line, near condenser. |
| (15) | On low-side line, between orifice tube and evaporator. |
SERVICE VALVE LOCATIONS (CARS)
| Vehicle | High | Low |
|---|
| Chrysler Corp. |
| Caravan, Town & Country, & Voyager | (1) | (2) |
| Dakota | (3) | (4) |
| Durango | (3) | (4) |
| Ram Pickup | (3) | (5) |
| Ram Van/Wagon | (6) | (7) |
| Ford Motor Co. |
| "E" Series | (4) | (8) |
| Explorer, Mountaineer & Ranger | (6) | (9) |
| F150, F250LD, Expedition & Navigator | (6) | (9) |
| F250HD, F350 & Super Duty | (6) | (5) |
| Villager | (10) | (5) |
| Windstar | (11) | (9) |
| General Motors |
| "C" & "K" Series | (4) | (9) |
| "G" Series | (12) | (9) |
| "J" Series | (9) | (13) |
| "L" & "M" Series | (12) | (5) |
| "P" Series | (14) | (15) |
| "S" & "T" Series | (16) | (9) |
| "U" Series | (1) | (5) |
| Jeep |
| Cherokee | (6) | (17) |
| Grand Cherokee | (18) | (14) |
| Wrangler | (4) | (14) |
| (1) On high-side line, near right frame rail. (Scheme 7) (2) On low-side line, near compressor. (Scheme 7) (3) On high-side line, between condenser and evaporator, near front of engine compartment. (4) On compressor manifold. (5) On low-side line, near accumulator. (6) On high-side line, between compressor and condenser, near front of engine compartment. (7) On low-side line extension, near receiver-drier, at front of engine compartment. (8) On low-side line from accumulator, near windshield washer reservoir. (9) On accumulator/receiver-drier. (10) On high-side line extension from compressor. (11) On high-side line, between compressor and condenser, near accumulator. (Scheme 8) (12) On high-side line between evaporator and condenser, near evaporator. (13) On low-side (suction) line, near compressor. (14) On high-side inlet line, at evaporator. (15) On low-side outlet line, at evaporator. (16) On high-side line. (17) On low-side (suction) line, between accumulator outlet and compressor. (18) On high-side (liquid) line, near evaporator inlet, at rear of engine compartment. |
| (1) | On high-side line, near right frame rail. (Scheme 7) |
| (3) | On high-side line, between condenser and evaporator, near front of engine compartment. |
| (4) | On compressor manifold. |
| (5) | On low-side line, near accumulator. |
| (6) | On high-side line, between compressor and condenser, near front of engine compartment. |
| (7) | On low-side line extension, near receiver-drier, at front of engine compartment. |
| (8) | On low-side line from accumulator, near windshield washer reservoir. |
| (9) | On accumulator/receiver-drier. |
| (10) | On high-side line extension from compressor. |
| (11) | On high-side line, between compressor and condenser, near accumulator. (Scheme 8) |
| (12) | On high-side line between evaporator and condenser, near evaporator. |
| (13) | On low-side (suction) line, near compressor. |
| (14) | On high-side inlet line, at evaporator. |
| (15) | On low-side outlet line, at evaporator. |
| (17) | On low-side (suction) line, between accumulator outlet and compressor. |
| (18) | On high-side (liquid) line, near evaporator inlet, at rear of engine compartment. |
SERVICE VALVE LOCATIONS (TRUCKS & VANS)
Scheme 7
Scheme 8
