Contents Wiring diagrams Section: Collision/avoidance All sections

Object Detection System: Other Chevrolet Malibu VIII facelift

Collision/avoidance 2 illustrations ~2783 words

Reference Information

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Object Detection Description and Operation (Lane Departure Warning, UFL) , Object Detection Description and Operation (Rear Vision Camera, UVC) , Object Detection Description and Operation (Park Assist, UD7) , Object Detection Description and Operation (Foward Collision Alert, UEU)

Electrical Information Reference

  1. «Circuit Testing»(ref-609142-S10104287192014041500000)
  2. «Connector Repairs»(ref-609142-S09769844092014041500000)
  3. «Testing for Intermittent Conditions and Poor Connections»(ref-609142-S01252147272014041500000)
  4. «Wiring Repairs»(ref-609142-S33200196142014041500000)

Scan Tool Reference

Control Module References for scan tool information

Circuit/System Verification

  1. Ignition ON.
  2. Verify that DTC B1405 is not set. If the DTC is set Refer to «DTC B1405»(ref-609181-S06284846272014041500000) If the DTC is not set
  3. Verify that DTC B0958 01, B0959 01, B0960 01, B0961 01, B0958 21, B0959 21, B0960 21 or B0961 21 is not set. If the DTC is set Check the B78 Rear Object Sensor for contamination with snow, mud, dirt, slush, or ice. If contaminated, clean sensor. If there is no contamination Refer to Circuit/System Testing (below). If the DTC is not set
  4. Verify that DTC B0958 3A, B0959 3A, B0960 3A or B0961 3A is not set. If the DTC is set Replace the B78 Rear Object Sensor with the correct sensor type.
  5. Ignition ON, transmission in REVERSE.
  6. Verify the scan tool Parking Assist System Status parameter displays Enabled. If the Parking Assist System displays Disabled Refer to Circuit/System Testing (below). If the Parking Assist System displays Enabled
  7. All OK.

Repair Instructions

Perform the Diagnostic Repair Verification after completing the repair

  1. «Rear Object Alarm Replacement»(ref-609181-S40699357662014041500000)
  2. «Control Module References»(ref-609132-S00827563312014041500000) for rear parking assist control module replacement, programming and setup.

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Object Detection Description and Operation (Lane Departure Warning, UFL) , Object Detection Description and Operation (Rear Vision Camera, UVC) , Object Detection Description and Operation (Park Assist, UD7) , Object Detection Description and Operation (Foward Collision Alert, UEU)

Electrical Information Reference

  1. «Circuit Testing»(ref-609142-S10104287192014041500000)
  2. «Connector Repairs»(ref-609142-S09769844092014041500000)
  3. «Testing for Intermittent Conditions and Poor Connections»(ref-609142-S01252147272014041500000)
  4. «Wiring Repairs»(ref-609142-S33200196142014041500000)

Scan Tool Reference

Control Module References for scan tool information

  1. Ignition ON.
  2. Verify that DTC B0967 02 is not set. If the DTC is set Refer to Circuit/System Testing (below). If the DTC is not set
  3. Verify that B0968 01 or B0968 06 is not set. If the DTC is set Refer to Circuit/System Testing (below). If the DTC is not set
  4. Verify the scan tool Park Assist Switch parameter changes between Active and Inactive. If the Parking Assist Switch parameter does not change between Active and Inactive Refer to Circuit/System Testing (below). If the Parking Assist Switch parameter changes between Active and Inactive
  5. Verify the Parking Assist Switch Indicator turns ON and OFF when commanding with scan tool. If the indicator does not illuminate Refer to «Parking Assist System Malfunction»(ref-609181-S26802637252014041500000) If the indicator change between ON and OFF
  6. All OK.

Perform the Diagnostic Repair Verification after completing the repair

  1. «Vehicle Stability Control System Switch Replacement»(ref-609159-S19350694472014041500000)
  2. «Control Module References»(ref-609132-S00827563312014041500000) for parking assist control module replacement, programming and setup.

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Object Detection Description and Operation (Lane Departure Warning, UFL) , Object Detection Description and Operation (Rear Vision Camera, UVC) , Object Detection Description and Operation (Park Assist, UD7) , Object Detection Description and Operation (Foward Collision Alert, UEU)

Electrical Information Reference

  1. «Circuit Testing»(ref-609142-S10104287192014041500000)
  2. «Connector Repairs»(ref-609142-S09769844092014041500000)
  3. «Testing for Intermittent Conditions and Poor Connections»(ref-609142-S01252147272014041500000)
  4. «Wiring Repairs»(ref-609142-S33200196142014041500000)

Scan Tool Reference

Control Module References for scan tool information

  1. Ignition ON.
  2. Verify the DTC B356A is not set. If the DTC is set Refer to «DTC B356A»(ref-609181-S20279114352014041500000) If the DTC is not set
  3. Verify the scan tool Vehicle Direction Camera Indicator Status parameter changes between ON and OFF when pressing and releasing the lane departure warning switch. If the parameter does not change between ON and OFF Refer to Circuit/System Testing (below). If the parameter changes between ON and OFF
  4. All OK.

Perform the Diagnostic Repair Verification after completing the repair

  1. «Vehicle Stability Control System Switch Replacement»(ref-609159-S19350694472014041500000)
  2. «Control Module References»(ref-609132-S00827563312014041500000) for front view camera module replacement, programming and setup.

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Object Detection Description and Operation (Lane Departure Warning, UFL) , Object Detection Description and Operation (Rear Vision Camera, UVC) , Object Detection Description and Operation (Park Assist, UD7) , Object Detection Description and Operation (Foward Collision Alert, UEU)

Electrical Information Reference

  1. «Circuit Testing»(ref-609142-S10104287192014041500000)
  2. «Connector Repairs»(ref-609142-S09769844092014041500000)
  3. «Testing for Intermittent Conditions and Poor Connections»(ref-609142-S01252147272014041500000)
  4. «Wiring Repairs»(ref-609142-S33200196142014041500000)

Scan Tool Reference

Control Module References for scan tool information

  1. Ignition ON.
  2. Verify no other DTC is set except for DTC B1011. If any other DTCs are set Diagnose those first. Refer to «Diagnostic Trouble Code (DTC) List - Vehicle»(ref-609122-S17202613242014041500000) . If no other DTCs are set
  3. Refer to Diagnostic Aids and Frontview Camera Disable History for what caused B1011 to set. Diagnose the system that set the malfunction.

Perform the Diagnostic Repair Verification after completing the repair.

Control Module References for frontview camera module programming and setup

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Object Detection Description and Operation (Lane Departure Warning, UFL) , Object Detection Description and Operation (Rear Vision Camera, UVC) , Object Detection Description and Operation (Park Assist, UD7) , Object Detection Description and Operation (Foward Collision Alert, UEU)

Electrical Information Reference

  1. «Circuit Testing»(ref-609142-S10104287192014041500000)
  2. «Connector Repairs»(ref-609142-S09769844092014041500000)
  3. «Testing for Intermittent Conditions and Poor Connections»(ref-609142-S01252147272014041500000)
  4. «Wiring Repairs»(ref-609142-S33200196142014041500000)

Scan Tool Reference

Control Module References for scan tool information

  1. Ignition ON.
  2. Verify DTC B1015 is not. If DTC B1015 is set Program the control module the DTC originally set in. Verify the DTC does not set. If the DTC is sets, replace the control module the DTC set in. If the DTC does not set All OK If DTC B1015 is not set
  3. All OK

Perform the Diagnostic Repair Verification after completing the repair.

Control Module References for the parking assist control module or frontview camera control module replacement, programming and setup.

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Object Detection Description and Operation (Lane Departure Warning, UFL) , Object Detection Description and Operation (Rear Vision Camera, UVC) , Object Detection Description and Operation (Park Assist, UD7) , Object Detection Description and Operation (Foward Collision Alert, UEU)

Electrical Information Reference

  1. «Circuit Testing»(ref-609142-S10104287192014041500000)
  2. «Connector Repairs»(ref-609142-S09769844092014041500000)
  3. «Testing for Intermittent Conditions and Poor Connections»(ref-609142-S01252147272014041500000)
  4. «Wiring Repairs»(ref-609142-S33200196142014041500000)

Scan Tool Reference

Control Module References for scan tool information

  1. Ignition ON.
  2. Verify the scan tool Calculated Transmission Range parameter is Reverse. If not Reverse Refer to «DTC B2545»(ref-609145-S42394916402014041500000) If Reverse
  3. Verify the scan tool Park Assist Sensors Reference Voltage is between 7.2-9.2 V. If not between 7.2-9.2 V Refer to Circuit/System Testing (below). If is between 7.2-9.2 V
  4. All OK.

Perform the Diagnostic Repair Verification after completing the repair.

Control Module References for parking assist control module replacement, programming and setup.

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Object Detection Description and Operation (Lane Departure Warning, UFL) , Object Detection Description and Operation (Rear Vision Camera, UVC) , Object Detection Description and Operation (Park Assist, UD7) , Object Detection Description and Operation (Foward Collision Alert, UEU)

Electrical Information Reference

  1. «Circuit Testing»(ref-609142-S10104287192014041500000)
  2. «Connector Repairs»(ref-609142-S09769844092014041500000)
  3. «Testing for Intermittent Conditions and Poor Connections»(ref-609142-S01252147272014041500000)
  4. «Wiring Repairs»(ref-609142-S33200196142014041500000)

Scan Tool Reference

Control Module References for scan tool information

  1. Ignition ON.
  2. Verify the scan tool Vehicle Direction Warning Switch Status parameter changes between On and Off while cycling the lane departure warning switch. If the parameter does not change Refer to Circuit/System Testing (below). If the parameter changes
  3. All OK.

Perform the Diagnostic Repair Verification after completing the repair.

  1. «Vehicle Stability Control System Switch Replacement»(ref-609159-S19350694472014041500000)
  2. «Control Module References»(ref-609132-S00827563312014041500000) for frontview camera module replacement, programming and setup.

Symptoms - Object Detection

Note. The following steps must be completed before using the symptom tables

  1. Perform the «Diagnostic System Check - Vehicle»(ref-609122-S25539464382014041500000) before using the Symptom List in order to verify that all of the following are true: There are no DTCs set. The control modules can communicate via the serial data link. NOTE: The rear vision camera does not communicate on the serial data bus.
  2. Review the system operation in order to familiarize yourself with the system functions. Refer to «Object Detection Description and Operation (Lane Departure Warning, UFL)»(ref-609181-S16596995072014041500000) , «Object Detection Description and Operation (Rear Vision Camera, UVC)»(ref-609181-S04552664332014041500000) , «Object Detection Description and Operation (Park Assist, UD7)»(ref-609181-S15386070342014041500000) , «Object Detection Description and Operation (Foward Collision Alert, UEU)»(ref-609181-S11553546972014041500000) .

Intermittent

Faulty electrical connections or wiring may be the cause of intermittent conditions. Refer to Testing for Intermittent Conditions and Poor Connections .

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Object Detection Description and Operation (Lane Departure Warning, UFL) , Object Detection Description and Operation (Rear Vision Camera, UVC) , Object Detection Description and Operation (Park Assist, UD7) , Object Detection Description and Operation (Foward Collision Alert, UEU)

Electrical Information Reference

  1. «Circuit Testing»(ref-609142-S10104287192014041500000)
  2. «Connector Repairs»(ref-609142-S09769844092014041500000)
  3. «Testing for Intermittent Conditions and Poor Connections»(ref-609142-S01252147272014041500000)
  4. «Wiring Repairs»(ref-609142-S33200196142014041500000)

Scan Tool Reference

Control Module References for scan tool information

Note. Refer to Diagnostic Aids before performing Circuit/System Verification.

  1. Ignition ON.
  2. Verify the scan tool Forward Collision Alert Function Status parameter is not Malfunction. If the parameter is Malfunction Refer to «Circuit/System Testing - Frontview Camera Module Malfunction»(ref-609181-S28107233152014041500000) If parameter is not Malfunction
  3. Verify the forward collision alert indicators illuminate momentarily when turning ignition OFF and then ON. If the indicators do not illuminate Refer to «Circuit/System Testing - Forward Collision Alert Indicator Malfunction»(ref-609181-S28107233152014041500000) If the indicators illuminate
  4. Verify the driver information center forward collision alert distance indicator toggles between far, medium, near and off. If the setting does not change Refer to «Circuit/System Testing - Forward Collision Alert Switch Malfunction»(ref-609181-S28107233152014041500000) . If the setting changes
  5. Verify the area of the K109 Frontview Camera Module is not contaminated. If contaminated Clean the windshield If not contaminated
  6. All OK.

Perform the Diagnostic Repair Verification after completing the repair.

  1. «Cruise Control Switch Replacement»(ref-609167-S01301573292014041500000) - Steering Wheel Controls Switch - Left replacement.
  2. «Forward Collision Alert Display Replacement»(ref-609181-S17422025972014041500000)
  3. «Control Module References»(ref-609132-S00827563312014041500000) for Frontview Camera Module replacement, programming and setup

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Object Detection Description and Operation (Lane Departure Warning, UFL) , Object Detection Description and Operation (Rear Vision Camera, UVC) , Object Detection Description and Operation (Park Assist, UD7) , Object Detection Description and Operation (Foward Collision Alert, UEU)

Electrical Information Reference

  1. «Circuit Testing»(ref-609142-S10104287192014041500000)
  2. «Connector Repairs»(ref-609142-S09769844092014041500000)
  3. «Testing for Intermittent Conditions and Poor Connections»(ref-609142-S01252147272014041500000)
  4. «Wiring Repairs»(ref-609142-S33200196142014041500000)

Scan Tool Reference

Control Module References for scan tool information.

  1. Ignition ON.
  2. Verify the park assist system is enabled through the parking assist switch. If the park assist system is manually disabled, enable the system. Refer to the vehicle owners manual for instructions on enabling the system. If the park assist system is enabled
  3. Verify the scan tool Park Assist Switch parameter changes between Active and Inactive when cycling the park assist switch. If the parameter does not change between Active and Inactive Refer to «Parking Assist Switch Circuit Malfunction»(ref-609181-S34351805872014041500000) . If the parameter changes between Active and Inactive
  4. Verify the park assist switch indicator turns ON and OFF when commanding the scan tool Park Assist Switch LED On and Off. If the indicator does not turn ON and OFF Refer to «Parking Assist Switch Indicator Circuit Malfunction»(ref-609181-S34351805872014041500000) . If the indicator does turn ON and OFF
  5. Transmission in REVERSE.
  6. Verify the scan tool Park Assist System Status parameter is Enable. If the parameter is not Enabled Refer to «Diagnostic Aids»(ref-609181-S34298113002014041500000) to determine the cause of the inhibit. If the parameter is Enabled
  7. All OK.

Perform the Diagnostic Repair Verification after completing the repair.

  1. «Vehicle Stability Control System Switch Replacement»(ref-609159-S19350694472014041500000)
  2. «Control Module References»(ref-609132-S00827563312014041500000) for parking assist control module replacement, programming and setup.

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Object Detection Description and Operation (Lane Departure Warning, UFL) , Object Detection Description and Operation (Rear Vision Camera, UVC) , Object Detection Description and Operation (Park Assist, UD7) , Object Detection Description and Operation (Foward Collision Alert, UEU)

Electrical Information Reference

  1. «Circuit Testing»(ref-609142-S10104287192014041500000)
  2. «Connector Repairs»(ref-609142-S09769844092014041500000)
  3. «Testing for Intermittent Conditions and Poor Connections»(ref-609142-S01252147272014041500000)
  4. «Wiring Repairs»(ref-609142-S33200196142014041500000)
  1. Ignition ON.
  2. Verify that DTC B2545 is not set. If the DTC is set Refer to «DTC B2545»(ref-609145-S42394916402014041500000) . If the DTC is not set
  3. Verify there is no debris on the rearview camera lens and that the bezel and bezel seal are not damaged. If debris are found on the lens Clean the lens. If the lens, bezel, or bezel seal are damaged, replace as necessary. If no debris on the lens
  4. Engine running, transmission in REVERSE.
  5. Verify the backup lamps are On. If the backup lamps are not ON Refer to «Backup Lamps Malfunction»(ref-609145-S23892907582014041500000) . If the backup lamps are ON
  6. Engine running, transmission in REVERSE.
  7. Verify a clear rear vision image is displayed on the radio. If a clear image is not displayed Refer to Circuit/System Testing (below). If a clear image is displayed
  8. All OK.

Perform the Diagnostic Repair Verification after completing the repair.

Rearview Camera Image Display Module Replacement

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Object Detection Description and Operation (Lane Departure Warning, UFL) , Object Detection Description and Operation (Rear Vision Camera, UVC) , Object Detection Description and Operation (Park Assist, UD7) , Object Detection Description and Operation (Foward Collision Alert, UEU)

Electrical Information Reference

  1. «Circuit Testing»(ref-609142-S10104287192014041500000)
  2. «Connector Repairs»(ref-609142-S09769844092014041500000)
  3. «Testing for Intermittent Conditions and Poor Connections»(ref-609142-S01252147272014041500000)
  4. «Wiring Repairs»(ref-609142-S33200196142014041500000)

Scan Tool Reference

Control Module References for scan tool information

  1. Ignition ON.
  2. Verify that DTC B356A is not set. If the DTC is set Refer to «DTC B356A»(ref-609181-S20279114352014041500000) . If the DTC is not set
  3. Verify that DTC B0987 is not set. If the DTC is set Refer to «DTC B0987»(ref-609181-S37164527302014041500000) . If the DTC is not set
  4. Verify the scan tool Frontview Camera System Status parameter is Normal. If the parameter is Undefined or Malfunction Refer to Circuit/System Testing (below). If the parameter is Normal
  5. Verify the scan tool Lane Departure Warning Switch Status parameter changes between On and Off when pressing the lane departure warning switch. If the parameter does not change between On and Off Refer to «Lane Departure Warning Switch Circuit Malfunction»(ref-609181-S21696030032014041500000) in Circuit/System Testing. If the parameter changes between On and Off
  6. All OK.

Perform the Diagnostic Repair Verification after completing the repair.

Control Module References for Frontview Camera Module replacement, programming and setup

Scheme 7

Scheme 7: Forward Collision Alert Display Replacement
Scheme 7: Forward Collision Alert Display Replacement
CalloutComponent Name
Preliminary Procedure Remove the instrument panel assembly. Refer to Instrument Panel Assembly Replacement .
1Forward Collision Alert Display (Qty: 2) CAUTION: Refer to Fastener Caution .
2Forward Collision Alert Display Procedure Disconnect the electrical connector.
CAUTION
Refer to Fastener Caution .

Forward Collision Alert Display Replacement

Scheme 8

Scheme 8: Rear Object Alarm Replacement
Scheme 8: Rear Object Alarm Replacement
CalloutComponent Name
Preliminary Procedure Remove the left side rear compartment side trim panel. Refer to Rear Compartment Side Trim Panel Replacement (without HP6) , Rear Compartment Side Trim Panel Replacement (HP6, Left Side) , Rear Compartment Side Trim Panel Replacement (HP6, Right Side) .
1Rear Object Alarm Module Assembly Procedure Release the locking retainer from the rear object alarm module bracket. Disconnect the electrical connectors. For programming and set up, refer to Control Module References .

Rear Object Alarm Replacement

Lane Departure Warning System Driver Information Center Messages

The front view camera module can command the driver information center to display the various messages to alert the driver of a system concern or status information. For detailed information about the possible messages please refer to the user's manual.

Parking Assist System Driver Information Center Messages

SERVICE PARK ASSIST

The driver information center displays SERVICE PARK ASSIST when the parking assist control module detects a malfunction in the parking assist system and the system is disabled. The driver information center also displays SERVICE PARK ASSIST when a loss of communication occurs with the parking assist control module.

PARK ASSIST OFF

The PARK ASSIST OFF message is displayed in the driver information center when the parking assist system is disabled due to conditions that disable or inhibit the system. The parking assist control module requests the driver information center display PARK ASSIST OFF when it detects that one of the following conditions

  1. The parking assist system is manually disabled using the parking assist switch.
  2. An object is attached to the rear of the vehicle, such as a trailer, bicycle rack, trailer hitch receiver, or tow bar. Also, an object extending beyond a lowered tailgate will disable the system.
  3. The parking assist sensors are covered by snow, mud, dirt, slush, or ice.
  4. The vehicle bumper is damaged.
  5. Excessive paint thickness on a replacement parking assist sensor.
  6. The parking assist sensors are disrupted by vibrations, like those caused by a large nearby vehicle or from heavy equipment such as a jackhammer.

Forward Collision Alert System Driver Information Center Messages

The front view camera module can command the driver information center to display the various messages to alert the driver of a system concern or status information. For detailed information about the possible messages please refer to the user's manual.

More articles — Object Detection System
