Engine Mechanical - 3.6l - Component Locator Chevrolet Malibu VII

Mechanical 19 illustrations ~283 words

Scheme 116

Scheme 116: Disassembled Views
CalloutComponent Name
1Right Camshaft Cover Assembly
2Ignition Coil Bolt
3Ignition Coil
4Spark Plug
5Intake Manifold Assembly
6Left Camshaft Cover Assembly
7Crankshaft Position Sensor Heat Shield
8Crankshaft Position Sensor Heat Shield Bolt - Small
9Crankshaft Position Sensor Heat Shield Bolt - Large
10Engine Assembly
11Engine Flywheel Bolt
12Engine Flywheel
13Left Exhaust Manifold Gasket
14Left Exhaust Manifold Heat Shield
15Exhaust Manifold Heat Shield Bolt
16Left Exhaust Manifold
17Cylinder Head Exhaust Manifold Bolt
18Oil Pan Assembly
19Engine Front Cover Assembly
20Crankshaft Balancer
21Crankshaft Balancer Bolt
22Right Exhaust Manifold
23Right Exhaust Manifold Heat Shield
24Right Exhaust Manifold Gasket

Scheme 117

Scheme 117
CalloutComponent Name
4Engine Short Block Assembly
7Left Cylinder Head Assembly
8Right Cylinder Head Assembly
13Oil Pump Assembly
16Oil Filter Adapter Assembly
19Timing Drive Assembly
295Engine Coolant Air Bleed Pipe
296Engine Coolant Air Bleed Hose
297Engine Coolant Air Bleed Hose Clamp
298Engine Coolant Air Bleed Pipe Stud
299Engine Coolant Air Bleed Pipe Bolt
302Left Cylinder Head Gasket
303Right Cylinder Head Gasket
365Engine Cooling Thermostat
366Engine Cooling Thermostat Gasket
367Engine Cooling Thermostat Housing
368Engine Cooling Thermostat Housing Bolt
369Engine Cooling Thermostat Bolt - Short
377Water Outlet Seal
378Water Outlet O-ring
379Water Outlet Bolt
380Water Outlet
430Oil Level Indicator
431Oil Level Indicator Tube
432Oil Level Indicator Tube O-ring
433Oil Level Indicator Tube Bolt
434Oil Level Indicator Handle O-ring
720Crankshaft Position Sensor
721Crankshaft Position Sensor O-ring
722Crankshaft Position Sensor Bolt
723Knock Sensor
723Knock Sensor
724Knock Sensor Bolt
724Knock Sensor Bolt

Scheme 118

Scheme 118
CalloutComponent Name
250Left Camshaft Cover
251Left Camshaft Cover Gasket
252Right Camshaft Cover
253Right Camshaft Cover Gasket
254Camshaft Cover Spark Plug Port Seal
254Camshaft Cover Spark Plug Port Seal
255Camshaft Cover Bolt
255Camshaft Cover Bolt
256Camshaft Cover Bolt Insulator
256Camshaft Cover Bolt Insulator
257Ignition Coil Bolt Thread Insert
258Oil Fill Cap
259Oil Fill O-ring
260Left Camshaft Cover PCV Fitting
261Right Camshaft Cover PCV Fitting Orifice
262Oil Fill Tube
263Left Camshaft Cover PCV Fitting O-ring
265Left Camshaft Housing Cover Insulator
266Right Camshaft Housing Cover Insulator
704Ignition Coil
704Ignition Coil
705Ignition Coil Bolt
705Ignition Coil Bolt
719Spark Plug
719Spark Plug

Scheme 119

Scheme 119
CalloutComponent Name
1Primary Timing Chain Tensioner Bolt
2Left Secondary Timing Chain Shoe Bolt
3Right Secondary Timing Chain Tensioner
4Right Secondary Timing Chain Tensioner Gasket
5Right Secondary Timing Chain Shoe
6Secondary Timing Chain
7Camshaft Position Actuator Bolt
8Exhaust Camshaft Position Actuator
9Camshaft Position Actuator Thrust Washer
10Intake Camshaft Position Actuator
11Right Secondary Timing Chain Guide
12Left Camshaft Intermediate Drive Shaft Sprocket
13Camshaft Intermediate Drive Shaft Sprocket Bolt
14Left Secondary Timing Chain Shoe
15Left Secondary Timing Chain Tensioner Gasket
16Left Secondary Timing Chain Tensioner
17Left Secondary Timing Chain Guide
18Lower Primary Timing Chain Guide
19Lower Primary Timing Chain Guide Bolt
20Crankshaft Sprocket
21Primary Timing Chain
22Right Camshaft Intermediate Drive Shaft Sprocket
23Upper Primary Timing Chain Guide
24Primary Timing Chain Tensioner Gasket
25Primary Timing Chain Tensioner

Scheme 120

Scheme 120
CalloutComponent Name
283Dirty PCV Hose
285PCV Hose O-ring Outer/Larger
286PCV Hose O-ring Inner/Smaller
503Upper Intake Manifold
504Lower Intake Manifold
509Upper Intake Manifold Bolt - Long
510Upper Intake Manifold Bolt - Short
519Lower Intake Manifold to Upper Intake Manifold Dowel Pin
521Upper Intake Manifold Gasket
522Lower Intake Manifold Gasket
523Lower Intake Manifold Bolt
532Fuel Rail Bolt
561Fuel Injector
562Fuel Injector Retainer
563Fuel Injector Upper Seal
564Fuel Injector Lower Seal
565Fuel Pressure Service Valve Cap
566Fuel Pressure Service Valve
571Fuel Rail Bracket
572Fuel Rail Bracket Bolt
572Fuel Rail Bracket Bolt
594Fuel Injector Sight Shield Cover Ball Stud
700Fuel Injector Wiring Harness
701Throttle Body
702Throttle Body Bolt
703Throttle Body Gasket
740MAP Sensor
741MAP Sensor O-ring
743MAP Sensor Bolt
744EVAP Purge Solenoid
746EVAP Purge Solenoid Bolt
750EVAP Purge Solenoid Tube - Intake Manifold to EVAP Solenoid
752EVAP Purge Solenoid Bracket
755Intake Manifold Tuning Valve
756Intake Manifold Tuning Valve O-ring
757Intake Manifold Tuning Valve Bolt
765Fuel Injector Wiring Harness Bracket
766Fuel Injector Wiring Harness Bracket Bolt

Scheme 121

Scheme 121
CalloutComponent Name
532Fuel Rail Bolt
560Fuel Rail
561Fuel Injector
562Fuel Injector Retainer
563Fuel Injector Upper Seal
564Fuel Injector Lower Seal
565Fuel Pressure Service Valve Cap
566Fuel Pressure Service Valve
571Fuel Rail Bracket
572Fuel Rail Bracket Bolt
572Fuel Rail Bracket Bolt
700Fuel Injector Wiring Harness
765Fuel Injector Wiring Harness Bracket
766Fuel Injector Wiring Harness Bracket Bolt

Scheme 122

Scheme 122
CalloutComponent Name
300Left Cylinder Head
301Right Cylinder Head
302Left Cylinder Head Gasket
303Right Cylinder Head Gasket
310Cylinder Head Bolt
311Cylinder Head Front Bolt
313Cylinder Head Coolant Hole Threaded Plug
318Spark Plug Sleeve
319Cylinder Head Oil Gallery Expansion Plug - 14 mm
319Cylinder Head Oil Gallery Expansion Plug - 14 mm
320Exhaust Valve
321Intake Valve
322Valve Rocker Arm Assembly
323Hydraulic Valve Lash Adjuster Assembly
324Valve Stem Oil Seal
325Valve Spring
326Valve Spring Cap
327Valve Stem Key
328Cylinder Head Camshaft Front Thrust Bearing Cap
328Cylinder Head Camshaft Front Thrust Bearing Cap
329Camshaft Oil Seal Ring
330Left Exhaust Camshaft
331Left Intake Camshaft
332Right Intake Camshaft
333Right Exhaust Camshaft
336Cylinder Head Camshaft Cap - Intermediate
337Cylinder Head Camshaft Cap Bolt
339Cylinder Head Oil Gallery Check Valve
711Engine Coolant Temperature Sensor

Scheme 123

Scheme 123
CalloutComponent Name
1Water Pump Pulley Bolt
2Water Pump Pulley
3Water Pump Assembly
4Water Pump Pulley Gasket
5Camshaft Position Actuator Solenoid Valve Seal
6Camshaft Position Sensor Bolt
7Camshaft Position Sensor
8Camshaft Position Sensor O-ring Seal
9Camshaft Position Actuator Solenoid Valve Bolt
10Camshaft Position Actuator Solenoid Valve
11Engine Front Cover Gasket
12Engine Front Cover Locating Pin
13Engine Front Cover
14Engine Front Cover Bolt
15Engine Front Cover Seal
16Crankshaft Balancer
17Crankshaft Balancer Bolt
18Engine Front Cover Bolt
19Water Pump Bolt

Scheme 124

Scheme 124
CalloutComponent Name
151Lower Primary Timing Chain Guide
154Lower Primary Timing Chain Guide Bolt
463Oil Pump Housing
464Oil Pump Cover
465Oil Pump Driven Gear
466Oil Pump Drive Gear
468Oil Pump Cover Bolt
470Oil Pressure Relief Valve Bore Plug
471Oil Pressure Relief Valve Spring
472Oil Pressure Relief Valve
474Oil Pressure Relief Valve Bore Plug Retainer Clip
475Oil Pump Bolt

Scheme 125

Scheme 125
CalloutComponent Name
1Crankshaft
2Crankshaft Key
3Crankshaft Lower Bearing
4Crankshaft Bearing Cap
5Crankshaft Bearing Cap Outboard Bolt
6Crankshaft Bearing Cap Inboard Bolt
7Crankshaft Bearing Thrust Cap
8Piston Oil Nozzle Bolt
9Piston Oil Nozzle
10Oil Pan Locating Pin
11Crankshaft Bearing Cap Side Bolt - Long
12Engine Block Oil Gallery Threaded Plug - 14 mm
13Crankshaft Rear Oil Seal Housing Assembly
14Crankshaft Rear Oil Seal Housing Assembly Bolt
15Transaxle Locating Pin
16Piston and Connecting Rod Assembly
17Engine Block Coolant Drain Threaded Plug - 14 mm
18Engine Block Core Coolant Expansion Plug - 34.3 mm
19Cylinder Head Locating Pin
20Engine Block
21Engine Block Oil Gallery Expansion Plug - 14
22Engine Front Cover Stud
23Engine Block Oil Gallery Threaded Plug - 20 mm
24Engine Block Oil Gallery Expansion Plug - 10 mm
25Crankshaft Bearing Cap Side Bolt - Short
26Crankshaft Upper Thrust Bearing #3
27Crankshaft Upper Bearing

Scheme 126

Scheme 126
CalloutComponent Name
200Connecting Rod
201Connecting Rod Bolt
202Connecting Rod Bushing
203Connecting Rod Bearing
210Piston
211Piston Pin
212Piston Pin Retainer
212Piston Pin Retainer
213Piston Upper Compression Ring
214Piston Lower Compression Ring
215Piston Oil Control Rail Ring
216Piston Oil Control Ring Spacer

Scheme 127

Scheme 127
CalloutComponent Name
400Oil Pan
405Oil Pump Suction Pipe
406Oil Pump Suction Pipe Gasket
407Oil Pump Suction Pipe Bolt
407Oil Pump Suction Pipe Bolt
410Oil Pan Baffle Scraper
411Oil Pan Baffle Scraper Bolt
412Oil Pan Drain Plug
413Oil Pan Drain Plug O-ring
420Oil Pan Bolt
422Oil Pan Bolt - Long

Scheme 128

Scheme 128
CalloutComponent Name
440Oil Filter Adapter
441Oil Filter Adapter Gasket
442Oil Filter Adapter Bolt
443Oil Filter Adapter Bolt - Long
445Oil Filter Fitting
449Oil Filter
728Engine Oil Pressure Sensor
729Engine Oil Pressure Sensor O-ring

Vehicle Identification Number

The Vehicle Identification Number (VIN) Derivative is located in two places on the engine and is a nine digit number stamped or laser etched onto the block at the vehicle assembly plant. If reading the identification number the following information can be obtained

  1. The first digit identifies the vehicle division.
  2. The second digit is the model year.
  3. The third digit identifies the assembly plant.
  4. The fourth through ninth digits are the last six digits of the Vehicle Identification Number (VIN).

Scheme 129

Scheme 129

The engine block is marked with the VIN on a pad area on the left rear side (1).

Scheme 130

Scheme 130

The engine block is marked with the VIN on a pad area on the center lower right side (1).

Engine Traceability Label

The engine traceability label is located in two places on the engine and consists of the broadcast code, bar code and sequence number.

Scheme 131

Scheme 131: Engine Traceability Label

One engine traceability label (1) is located on the left rear side of the engine block.

Scheme 132

Scheme 132

Another engine traceability label (1) is located on the rear of the left cylinder head.

Engine Verification Label

The engine verification label is located in two places on the engine and consists of the broadcast code and bar code.

Scheme 133

Scheme 133: Engine Verification Label

One engine verification label (1) is located on the left side of the engine front cover below the exhaust camshaft position sensor.

Scheme 134

Scheme 134

Another engine verification label (1) is located on the rear of the right cylinder head.
