Engine Mechanical - 2.4l - Component Locator Chevrolet Malibu VII

Mechanical 6 illustrations ~108 words

Scheme 75

Scheme 75: Disassembled Views
Scheme 75: Disassembled Views
CalloutComponent Name
201Exhaust Valve
202Intake Valve
203Timing Chain Guide Bolt Access Hole
204Cylinder Head
205Cylinder Head Gallery Plug
206Hydraulic Lash Adjuster
207Roller Finger Follower
208Cylinder Head Bolt
209Small Cylinder Head Bolt
210Valve Stem Seal
211Valve Spring
212Valve Spring Retainer
213Valve Keys
214Hydraulic Lash Adjuster
215Roller Finger Follower
216Lntake Camshaft
219Camshaft Cap
220Exhaust Camshaft
221Camshaft Cap
222Camshaft Cap Bolt
300Coolant Air Bleed Fitting
413Engine Oil Fill Cap
507Fuel Injector Rotator Cup
508Fuel Injector O-ring
509Fuel Injector
510Fuel Injector O-ring
511Fuel Injector Clip
512Fuel Rail
513Camshaft Cover Gasket
514Camshaft Cover
515Camshaft Cover Bolt
707Front Lift Bracket Bolt
708Front Lift Bracket
709Rear Lift Bracket
710Rear Lift Bracket Bolt
713Fuel Injector Wiring Harness
717Spark Plug
718Camshaft Position Actuator Solenoid Valve - Exhaust
719Camshaft Position Actuator Solenoid Valve - Intake
720Camshaft Position Actuator Solenoid Valve Bolt
721Ignition Coil
724Ignition Coil Bolt
725Camshaft Position Sensor
726Camshaft Position Sensor Bolt
727Camshaft Position Sensor
728Camshaft Position Sensor Bolt

Scheme 76

Scheme 76
Scheme 76
CalloutComponent Name
408Oil Indicator Tube O-ring
409Oil Indicator Tube
410Oil Indicator Tube Bolt
411Oil Indicator O-ring
412Oil Indicator
500Intake Manifold Gasket
501Intake Manifold Bolt
502Intake Manifold
503Throttle Body Seal
504Throttle Body
506Throttle Body Bolt
711Map Sensor

Scheme 77

Scheme 77
Scheme 77
CalloutComponent Name
1Exhaust Manifold Heat Shield Bolt
2Exhaust Manifold Heat Shield
3Exhaust Manifold Heat Shield Bolt
4Secondary Air Injection Assembly Nut
5Secondary Air Injection Assembly
6Secondary Air Injection Check Stud
7Secondary Air Injection Bolt
8Secondary Air Injection Pipe Assembly
9Secondary Air Injection Stud
10Secondary Air Injection Check Valve Gasket
11Secondary Air Injection Bolt
12Exhaust Manifold Gasket
13Exhaust Manifold Stud
14Exhaust Manifold
15Exhaust Manifold Nut
16Oxygen Sensor
17Exhaust Manifold Brace Bolt
18Exhaust Manifold Brace
19Exhaust Manifold Brace Bolt

Scheme 78

Scheme 78
Scheme 78
CalloutComponent Name
1Water Pump to Engine Block Seal
2Water Pump
3Water Transfer Pipe O-ring Seals
4Water Transfer Pipe
5Coolant Temperature Sensor
6Thermostat Housing to Block Gasket
7Thermostat Housing
8Thermostat
9Thermostat Gasket
10Thermostat Housing Cap Bolt
11Thermostat Housing Cap
12Water Pipe Support Bracket
13Water Pipe Support Bracket Bolt
14Water Pipe Support Bracket Bolt Stud
15Cylinder Head Gasket
16Piston Ring Assembly
17Piston Assembly
18Connecting Rod
19Connecting Rod Cap Bolt
20Connecting Rod Bearing
21Oil Filter Cap
22Oil Filter Cap O-ring
23Cylinder Head Alignment Pin
24Oil Filter
25Engine Block Gallery Plug
26Engine Block to Transaxle Alignment Pin
27Crankshaft Position Sensor
28Crankshaft Position Sensor Bolt
29Oil Pressure Switch
30Knock Sensor
31Crankshaft Bearing - Upper
32Crankshaft Rear Seal
33Flywheel - Automatic Transmission
34Manual Transaxle Flywheel
35Manual Transaxle Flywheel Bolt
36Automatic Transaxle Flywheel to Crankshaft Bolt
37Crankshaft
38Crankshaft Bearing - Lower
39Lower Crankcase
40Engine Oil Pan Alignment Pins
41Lower Crankcase Perimeter Bolt
42Engine Oil Pan
43Air Pump Assembly
44Air Pump Assembly Bolt
45Air Pump Assembly Bolt
46Engine Oil Pan Long Bolt
47Engine Oil Pan Bolt
48Engine Oil Pan Drain Plug
49Lower Crankcase Main Bearing Bolt
50Crankshaft Thrust Bearing - Lower
51Crankshaft Thrust Bearing - Upper
52Piston Oil Nozzle Assembly
53Engine Block
54Cylinder Bore Sleeve

Scheme 79

Scheme 79
Scheme 79
CalloutComponent Name
123Balance Shaft Rear Bearing
124Exhaust Balance Shaft
125Intake Balance Shaft
126Exhaust Balance Shaft Bearing Carrier
127Intake Balance Shaft Bearing Carrier
128Exhaust Balance Shaft Drive Sprocket
129Intake Balance Shaft Drive Sprocket
130Balance Shaft Drive Sprocket Bolts
223Upper Timing Chain Guide Bolt
224Upper Timing Chain Guide
225Exhaust Camshaft Position Actuator
226Intake Camshaft Position Actuator
227Camshaft Position Actuator Bolt
228Timing Chain Oil Nozzle
229Timing Chain Oil Nozzle Bolt
230Timing Chain Drive Sprocket
231Fixed Timing Chain Guide
232Fixed Timing Chain Guide Bolt
233Timing Chain
234Timing Chain Tensioner Washer
235Timing Chain Tensioner Body
236Timing Chain Tensioner O-ring Seal
237Timing Chain Tensioner Plunger
238Adjustable Timing Chain Guide
239Adjustable Timing Chain Guide Bolt
240Balance Shaft Drive Sprocket
241Balance Shaft Drive Chain Guide
242Balance Shaft Drive Chain Guide Bolt
243Balance Shaft Drive Chain Guide
244Balance Shaft Drive Chain Guide Bolt
245Balance Shaft Drive Chain
246Balance Shaft Drive Chain Tensioner Assembly
247Balance Shaft Drive Chain Tensioner Assembly Bolt
248Adjustable Balance Shaft Drive Chain Guide
249Adjustable Balance Shaft Drive Chain Guide Bolt
314Water Pump Drive Sprocket
315Water Pump Drive Sprocket Bolt
316Water Pump Bolt
317Engine Front Cover Access Plate Gasket
318Engine Front Cover Access Plate
319Engine Front Cover Access Plate Bolt
414Engine Front Cover Alignment Pins
415Engine Front Cover Gasket
416Oil Pump Cover Bolt
417Oil Pump Cover
418Oil Pump Outer Gerotor
419Oil Pump Inner Gerotor
420Engine Front Cover
421Engine Front Cover Bolt
422Oil Pressure Relief Valve Spring
423Oil Pressure Relief Valve Plunger
424Oil Pressure Relief Valve O-ring Seal
425Oil Pressure Relief Valve Plug
426Crankshaft Front Seal
427Crankshaft Damper
428Crankshaft Damper Bolt
429Friction Washer (Some Models)
704Belt Tensioner (Some Models)
705Belt Tensioner Bolt (Some Models)
722Belt Tensioner Bracket (Some Models)
723Belt Tensioner Bracket Bolts (Some Models)

Scheme 80

Scheme 80: Engine Identification
Scheme 80: Engine Identification

Identification can be made through the use of the Broadcast Code label on the engine front cover (1) and the use of the partial VIN etched in one of two places - the primary location is on the starter motor flange (3). The secondary location is the oil filter bowl (2).

  1. Barcode (1)
  2. Sequence Number (2)
  3. Day (3)
  4. Month (4)
  5. Year (5)
  6. Engine Assembly Plant (6)
  7. Broadcast Code (7)
  8. Part Designation (8)
  9. Engine Assembly Number (9)
  10. Broadcast Code (10)

The partial VIN identifies the specific vehicle by sequence number.
