Secondary/Configurable Control Schematic Icons
Secondary/Configurable Control Schematic Icons Icon Icon Definition CAUTION: When performing service on or near the SIR components or the SIR wiring, the SIR system must be disabled. Refer to SIR DISABLING AND ENABLING . Failure to observe the correct procedure could cause deployment of the SIR components, personal injury, or unnecessary SIR system repairs
Scheme 1
Scheme 2
Scheme 3
| Callout | Component Name |
|---|---|
| 1 | Steering Wheel Controls - Left |
| 2 | Steering Wheel Controls - Right |
| 3 | Horn Switch |
Scheme 4
| Callout | Component Name |
|---|---|
| 1 | Steering Wheel |
| 2 | Steering Wheel Controls - Right |
| 3 | Steering Wheel Controls - Left |
| 4 | Horn Switch |
Scheme 5
| Callout | Component Name |
|---|---|
| 1 | Inflatable Restraint Steering Wheel Module Coil C3 |
| 2 | Rear Shroud |
Scheme 6
| Connector Part Information OEM: 50-57-9407 Service: See Catalog Description: 7-Way F (BK) |
|---|
| Terminal Part Information Terminal/Tray: See Terminal Repair Kit Core/Insulation Crimp: See Terminal Repair Kit Release Tool/Test Probe: See Terminal Repair Kit |
Steering Wheel Controls - Left (3-Spoke) Connector Parts Information
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| 1-2 | Not Used | ||
| 3 | GY | 8 | Instrument Panel Lamp Supply Voltage |
| 4 | PK | 339 | Ignition 1 Voltage |
| 5 | GY | 1884 | Cruise Control Switch Signal |
| 6 | L-GN | 696 | Cruise Control Cancel Signal |
| 7 | BK/WH | 651 | Ground |
Steering Wheel Controls - Left (3-Spoke) Connector Terminal Identification
Scheme 7
| Connector Part Information OEM: 30700-1100 Service: See Catalog Description: 10-Way F HDAC64 DR Series (GY) |
|---|
| Terminal Part Information Terminal/Tray: See Terminal Repair Kit Core/Insulation Crimp: See Terminal Repair Kit Release Tool/Test Probe: See Terminal Repair Kit |
Steering Wheel Controls - Left (4-Spoke) Connector Parts Information
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| 1 | PK | 339 | Ignition 1 Voltage |
| 2 | Not Used | ||
| 3 | GY | 1884 | Cruise Control Switch Signal |
| 4 | Not Used | ||
| 5 | L-GN | 696 | Cruise Control Cancel Signal |
| 6 | GY | 8 | Instrument Panel Lamp Supply Voltage |
| 7 | Not Used | ||
| 8 | BK/WH | 651 | Ground |
| 9-10 | Not Used |
Steering Wheel Controls - Left (4-Spoke) Connector Terminal Identification
Scheme 8
| Connector Part Information OEM: 50-57-9404 Service: See Catalog Description: 4-Way F Molex (BK) |
|---|
| Terminal Part Information Terminal/Tray: See Terminal Repair Kit Core/Insulation Crimp: See Terminal Repair Kit Release Tool/Test Probe: See Terminal Repair Kit |
Steering Wheel Controls - Right (3-Spoke) Connector Parts Information
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| 1 | BK/WH | 651 | Ground |
| 2 | WH/BK | 644 | 10-Volt Reference |
| 3 | GY | 8 | Instrument Panel Lamp Supply Voltage |
| 4 | D-BU | 1796 | Steering Wheel Controls Signal |
Steering Wheel Controls - Right (3-Spoke) Connector Terminal Identification
Scheme 9
| Connector Part Information OEM: 31068-1010 Service: See Catalog Description: 4-Way F HDAC64 SR Housing (BK) |
|---|
| Terminal Part Information Terminal/Tray: See Terminal Repair Kit Core/Insulation Crimp: See Terminal Repair Kit Release Tool/Test Probe: See Terminal Repair Kit |
Steering Wheel Controls - Right (4-Spoke w/UK3) Connector Parts Information
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| 1 | BK/WH | 651 | Ground |
| 2 | GY | 8 | Instrument Panel Lamp Supply Voltage |
| 3 | WH/BK | 644 | 10-Volt Reference |
| 4 | D-BU | 1796 | Steering Wheel Controls Signal |
Steering Wheel Controls - Right (4-Spoke w/UK3) Connector Terminal Identification
Circuit/System Description
The radio supplies 10 volts to the steering wheel control momentary contact switches, and monitors the return signal. Each switch is associated to a set resistance value, when pressed a specific voltage drop occurs through a series of resistors unique to the switch selected. The radio will perform the desired function, or send a serial data message to its another component.
The radio supplies 10 volts to the steering wheel control momentary contact switches, and monitors the return signal. Each switch is associated to a set resistance value, when pressed a specific voltage drop occurs through a series of resistors unique to the switch selected. The radio will perform the desired function, or send a serial data message to its another component.
The radio supplies 10 volts to the audio steering wheel control multiple momentary contact switches, and monitors the return signal. Each switch is associated to a set resistance value, when pressed a specific voltage drop occurs through a series of resistors unique to that switch. The radio will perform the desired function, or send a serial data message to another component.
The radio supplies 10 volts to the audio steering wheel control multiple momentary contact switches, and monitors the return signal. Each switch is associated to a set resistance value, when pressed a specific voltage drop occurs through a series of resistors unique to that switch. The radio will perform the desired function, or send a serial data message to another component.
Steering Wheel Controls Description and Operation
The audio steering wheel control switches duplicate the function of the primary controls of the associated component, through a network of multiple momentary contact switches and a series of resistors. The radio supplies voltage to the switches and monitors the return signal for a specific voltage drop to occur unique to the one pressed. The radio then identifies the switch selected to activate the feature, otherwise sends a serial data message that is received by the component controlled, activating the feature.
This information is intended to diagnosis the circuits between the radio and the audio steering wheel control switches. If the primary control for the device is inoperative, refer to the appropriate procedure for the component the steering wheel control switch is functioning.
