Symptoms - Secondary and Configurable Customer Controls

IMPORTANTPerform the Diagnostic System Check - Vehicle before using the Symptom Tables in order to verify that all of the following conditions are true: There are no DTCs set. The control modules can communicate via the serial data link. Review the system operation in order to familiarize yourself with the system functions. Refer to Steering Wheel Controls Description and Operation .

Intermittent

Faulty electrical connections or wiring may be the cause of intermittent conditions. Refer to Testing for Intermittent Conditions and Poor Connections .

Schematic Reference

Steering Wheel Secondary/Configurable Control Schematics

Connector End View Reference

  1. «Entertainment/Communication Connector End Views»(ref-269121-S17408256212007102900000)
  2. «Secondary/Configurable Control Connector End Views»(ref-269170-S25083367102007102900000)

Electrical Information Reference

  1. «Circuit Testing»(ref-269145-S07499872622007102900000)
  2. «Connector Repairs»(ref-269145-S03006904552007102900000)
  3. «Testing for Intermittent Conditions and Poor Connections»(ref-269145-S26826198002007102900000)
  4. «Wiring Repairs»(ref-269145-S33888156582007102900000)

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

  1. «Steering Wheel Control Switch Assembly Replacement (Non SS)»(ref-269170-S16150456442007102900000) or «Steering Wheel Control Switch Assembly Replacement (SS)»(ref-269170-S07043839902007102900000)
  2. «Control Module References»(ref-269146-S40400118222007102900000) for radio replacement, setup, and programming

Schematic Reference

Steering Wheel Secondary/Configurable Control Schematics

Connector End View Reference

  1. «Entertainment/Communication Connector End Views»(ref-269121-S17408256212007102900000)
  2. «Secondary/Configurable Control Connector End Views»(ref-269170-S25083367102007102900000)

Electrical Information Reference

  1. «Circuit Testing»(ref-269145-S07499872622007102900000)
  2. «Connector Repairs»(ref-269145-S03006904552007102900000)
  3. «Testing for Intermittent Conditions and Poor Connections»(ref-269145-S26826198002007102900000)
  4. «Wiring Repairs»(ref-269145-S33888156582007102900000)

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

  1. «Steering Wheel Control Switch Assembly Replacement (Non SS)»(ref-269170-S16150456442007102900000) or «Steering Wheel Control Switch Assembly Replacement (SS)»(ref-269170-S07043839902007102900000)
  2. «Control Module References»(ref-269146-S40400118222007102900000) for radio replacement, setup, and programming

Scheme 10

Scheme 10: Steering Wheel Control Switch Assembly Replacement (Non SS)
CalloutComponent Name
CAUTION: Refer to SIR Caution . Preliminary Procedure: Remove the inflatable restraint steering wheel module. Refer to Inflatable Restraint Steering Wheel Module Replacement (Non-SS) or Inflatable Restraint Steering Wheel Module Replacement (SS) .
1Steering Wheel Control Switch Assembly Screw (Qty: 6) NOTE: Refer to Fastener Notice . Tip: DO NOT over tighten the steering wheel control switch screws or damage to the switch(s) or steering wheel covers may occur. Tighten: 2 N.m (18 lb in)
2Steering Wheel Control Switch Assembly (Qty: 2) Tip: Disconnect the electrical connector. Make sure the steering wheel control switch(s) are properly seated to the steering wheel shroud during installation.
CAUTION
Refer to SIR Caution .
NOTE
Refer to Fastener Notice .

Steering Wheel Control Switch Assembly Replacement (Non SS)

Scheme 11

Scheme 11: Steering Wheel Control Switch Assembly Replacement (SS)
CalloutComponent Name
CAUTION: Refer to SIR Caution . Preliminary Procedure: Remove the inflatable restraint steering wheel module. Refer to Inflatable Restraint Steering Wheel Module Replacement (Non-SS) or Inflatable Restraint Steering Wheel Module Replacement (SS) .
1Steering Wheel Trim Cover Bolt (Qty: 2) NOTE: Refer to Fastener Notice . Tighten: 2 N.m (18 lb in)
2Steering Wheel Trim Cover (Qty: 2)
3Steering Wheel Control Switch Assembly (Qty: 2) Tip: Disconnect the electrical connectors. Make sure the steering wheel control switches are properly seated to the steering wheel trim cover during installation.
CAUTION
Refer to SIR Caution .
NOTE
Refer to Fastener Notice .

Steering Wheel Control Switch Assembly Replacement (SS)

Personalization

The following options can be accessed in order by pressing the MENU button anytime while the vehicle is in ON. Press this button to scroll through each option. All of the personalization options may not be available on your vehicle. Only the options available will be displayed on your driver information center (DIC).

  1. Oil Life Monitor Reset
  2. Units Selection (English/Metric)
  3. Remote Start Capability
  4. Horn Chirp During Remote Keyless Entry Locking
  5. Horn Chirp During Remote Keyless Entry Unlocking
  6. Exterior Light Flash During Remote Keyless Entry Locking or Unlocking
  7. Delayed Locking
  8. Automatic Vehicle Unlocking: Specific Doors
  9. Automatic Vehicle Unlocking: When Key is Off or When Shift To Park
  10. Exterior Perimeter Lighting During Remote Keyless Entry Unlock
  11. Security System Passive or Remote Keyless Entry Arming
  12. Select Language: (English, French, Spanish or German)

When the desired option is reached, use the ENTER button to toggle between the modes of that option. To make a selection, press the MENU button again.

If no selection is made within 10 seconds, the display will revert back to the previous information displayed.

The MENU mode is exited when the INFO button is pressed, a 10 second time period has elapsed, the ignition is turned to OFF, or the end of the MENU list is reached.

The following display messages may appear on your vehicles audio display by pressing the MENU button

Radio Preset with Remote Keyless Entry

The vehicle may be equipped with a radio personalization feature. This feature allows you to store radio preset stations to the remote keyless entry transmitter used to unlock the doors. Two drivers can store different preset stations and the radio will recall the stored radio settings associated with a particular transmitter. When UNLOCK is pressed on the remote, the preset stations that the driver stored will be recalled. Refer to Radio/Audio System Description and Operation for more information about the radio.
