Accessory Power Socket Chevrolet Malibu VI

Scheme 116

Scheme 117

Scheme 118

Scheme 119

Power Outlet Connector End Views

Power Outlet Connector End Views - Auxiliary Power Outlet - Console (NW7, NW9) Connector Part Information 12176836 3-Way F Metri-Pack 280 Series (GY) Pin Wire Color Circuit No. Function A RD/WH 40 Battery Positive Voltage B - - Not Used C BK 1150 Ground

Power Outlet Connector End Views - Auxiliary Power Outlet - Front (w/o NW7, NW9) Connector Part Information 12176836 3-Way F Metri-Pack 280 Series (GY) Pin Wire Color Circuit No. Function A RD/WH 40 Battery Positive Voltage B - - Not Used C BK 1150 Ground

Power Outlet Connector End Views - Auxiliary Power Outlet - Rear (Extended Sedan) Connector Part Information 12176836 3-Way F Metri-Pack 280 Series (GY) Pin Wire Color Circuit No. Function A RD/WH 240 Battery Positive Voltage B - - Not Used C BK 1150 Ground

Power Outlet Connector End Views - Cigar Lighter Connector Part Information 12176836 3-Way F Metri-Pack 280 Series (GY) Pin Wire Color Circuit No. Function A RD/WH 40 Battery Positive Voltage B - - Not Used C BK 1150 Ground

Tools Required

J 42059 Cigar Lighter Socket Remover. See Special Tools and Equipment .

Scheme 120

Scheme 121

1. Remove the auxiliary power outlet fuse from the fuse block.
2. Remove the receptacle: Look into the receptacle. There are two 3 mm (0.11 in) tab windows 12 mm (0.47 in) from the front of the receptacle. The J 42059 pushes the plastic latches from these tab windows and the receptacle can be pulled straight out. See «Special Tools and Equipment»(/chevrolet/malibu/vi-2003-2006/remont/body-electrical/#accessory-power-socket) . Place one side of the "T" portion of the J 42059 into the tab window. See «Special Tools and Equipment»(/chevrolet/malibu/vi-2003-2006/remont/body-electrical/#accessory-power-socket) . The J 42059 will not fit straight into the receptacle. Angle the J 42059 slightly for insertion into the receptacle. See «Special Tools and Equipment»(/chevrolet/malibu/vi-2003-2006/remont/body-electrical/#accessory-power-socket) . Insert the other side of the "T" into the opposite tab window. You must move the J 42059 handle toward horizontal to engage the other tab window. Use the J 42059 to pull the receptacle straight out.
3. If J 42059 tool fails to release the lighter socket from the retainer, perform the following alternate method:. See «Special Tools and Equipment»(/chevrolet/malibu/vi-2003-2006/remont/body-electrical/#accessory-power-socket) . Insert a small grinding tool with a cutoff wheel into the socket. Remove the plastic latches in the 3 mm (0.11 in) square windows. Use the J 42059 as directed above to remove the socket.

Scheme 122

1. Route the connector through the retainer. Align the accessory power receptacle retainer to the slot in the opening.
2. Install the retainer by pressing into place fully seated.
3. Connect the electrical connector to the receptacle.
4. Align the tabs on the receptacle to the slots in the retainer. Install the accessory power receptacle by pressing into place until fully seated.
5. Install the accessory power receptacle fuse.

Special Tools

Identifying Special Tools Illustration Tool Number/ Description J 42059 Cigar Lighter Socket Remover
