Scheme 10
| Callout | Component Name |
|---|---|
| 1 | Upper Intake Manifold |
| 2 | Upper Intake Manifold Stud |
| 3 | Upper Intake Manifold Bolt |
| 4 | Upper Intake Manifold Bolt |
| 5 | Manifold Absolute Pressure Sensor Bracket |
| 6 | Manifold Absolute Pressure Sensor |
| 7 | Manifold Absolute Pressure Sensor Seal |
| 8 | Evaporative Emission Canister Purge Solenoid Valve Bolt |
| 9 | Evaporative Emission Canister Purge Solenoid Valve |
| 10 | Evaporative Emission Canister Purge Solenoid Valve Seal |
| 11 | Throttle Body Stud |
| 12 | Throttle Body Seal |
| 13 | Throttle Body |
| 14 | Throttle Body Bolt |
| 15 | Throttle Body Nut |
| 16 | Positive Crankcase Ventilation Tube |
| 17 | Oil Filler Cap |
| 18 | Oil Filler Cap Seal |
| 19 | Oil Filler Tube |
| 20 | Oil Filler Tube Seal |
| 21 | Valve Rocker Arm Cover |
| 22 | Valve Rocker Arm Cover Gasket |
| 23 | Positive Crankcase Ventilation Tube |
| 24 | Engine Coolant Filler Cap |
| 25 | Engine Coolant Filler Tube Adapter Seal |
| 26 | Engine Coolant Filler Tube Adapter Seal |
| 27 | Engine Coolant Filler Tube Adapter |
| 28 | Engine Coolant Filler Tube Adapter Bolt |
| 29 | Engine Coolant Filler Tube Adapter Seal |
| 30 | Engine Coolant Crossover Pipe Gasket |
| 31 | Engine Coolant Crossover Pipe Gasket |
| 32 | Engine Coolant Crossover Pipe |
| 33 | Water Outlet Stud |
| 34 | Belt Idler Pulley |
| 35 | Belt Idler Pulley Bolt |
| 36 | Belt Idler Pulley |
| 37 | Belt Idler Pulley Bolt |
| 38 | Engine Lift Front Bracket Bolt |
| 39 | Belt Idler Pulley Bolt |
| 40 | Belt Idler Pulley |
| 41 | Engine Lift Front Bracket Bolt |
| 42 | Engine Lift Front Bracket |
| 43 | Water Outlet Bolt |
| 44 | Ignition Coil Stud |
| 45 | Ignition Coil |
| 46 | Ignition Coil Nut |
| 47 | Ignition Coil Bolt |
| 48 | Intake Manifold Tuning Valve Bolt |
| 49 | Intake Manifold Tuning Valve |
| 50 | Upper Intake Manifold Gasket |
| 51 | Intake Manifold Tuning Valve Seal |
Scheme 11
| Callout | Component Name |
|---|---|
| 1 | Spark Plug Wire Harness |
| 2 | Sequential Multiport Fuel Injection Fuel Rail |
| 3 | Fuel Schrader Valve |
| 4 | Fuel Pressure Service Valve Cap Seal |
| 5 | Fuel Pressure Service Valve Cap |
| 6 | Fuel Injection Fuel Rail Bolt |
| 7 | Fuel Injector Wiring Harness Connector Bracket |
| 8 | Fuel Injector Wiring Harness Connector Bracket Bolt |
| 9 | Fuel Injector Wiring Harness |
| 10 | Valve Push Rod |
| 11 | Valve Push Rod |
| 12 | Valve Rocker Arm |
| 13 | Valve Rocker Arm Bolt |
| 14 | Exhaust Crossover Pipe Stud |
| 15 | Exhaust Crossover Pipe Nut |
| 16 | Exhaust Crossover Pipe Heat Shield |
| 17 | Exhaust Crossover Pipe Heat Shield Bolt |
| 18 | Exhaust Crossover Pipe |
| 19 | Valve Stem Key |
| 19 | Valve Stem Key |
| 20 | Valve Spring Cap |
| 20 | Valve Spring Cap |
| 21 | Valve Spring |
| 21 | Valve Spring |
| 22 | Valve Spring Damper |
| 22 | Valve Spring Damper |
| 23 | Valve Stem Oil Seal - Intake |
| 24 | Valve Stem Oil Seal - Exhaust |
| 25 | Valve Guide |
| 26 | Valve Guide |
| 27 | Cylinder Head Bolt |
| 28 | Engine Coolant Temperature Sensor |
| 29 | Engine Mount Strut and Engine Lift Bracket |
| 30 | Engine Mount Strut and Engine Lift Bracket Bolt |
| 31 | Spark Plug |
| 32 | Exhaust Valve Seat |
| 33 | Exhaust Valve |
| 34 | Exhaust Manifold Heat Shield |
| 35 | Exhaust Manifold Bolt |
| 36 | Exhaust Manifold |
| 37 | Exhaust Manifold Gasket |
| 38 | Engine Mount Strut Bracket Bolt |
| 39 | Engine Mount Strut Bracket Bolt |
| 40 | Engine Mount Strut Bracket |
| 41 | Cylinder Head Location Pin |
| 42 | Cylinder Head Gasket |
| 43 | Intake Valve |
| 44 | Intake Valve Seat |
| 45 | Cylinder Head |
| 46 | Fuel Injector Seal |
| 47 | Fuel Injector Retainer |
| 48 | Fuel Injector Seal |
| 49 | Sequential Multiport Fuel Injector |
| 50 | Lower Intake Manifold Location Pin |
| 51 | Lower Intake Manifold Bolt |
| 52 | Lower Intake Manifold Bolt |
| 53 | Lower Intake Manifold |
| 54 | Lower Intake Manifold Gasket |
| 55 | Lower Intake Manifold Seal |
| 56 | Cylinder Head Gasket |
| 57 | Cylinder Head Core Hole Plug |
| 58 | Cylinder Head |
| 59 | Valve Rocker Arm Cover |
| 60 | Valve Rocker Arm Cover Bolt Grommet |
| 61 | Valve Rocker Arm Cover Bolt |
| 62 | Exhaust Manifold Gasket |
| 63 | Exhaust Manifold |
| 64 | Exhaust Manifold Heat Shield Bolt |
| 65 | Exhaust Manifold Heat Shield |
| 66 | Oxygen Sensor |
| 67 | Spark Plug Wire Support |
| 68 | Spark Plug Wire Harness |
Scheme 12
| Callout | Component Name |
|---|---|
| 1 | Engine Block Coolant Hole Plug |
| 2 | Engine Block Heater |
| 3 | Engine Block Oil Gallery Plug |
| 4 | Camshaft Sensor Seal |
| 5 | Camshaft Position Sensor |
| 6 | Camshaft Position Sensor Bolt |
| 7 | Valve Lifter |
| 8 | Valve Lifter Guide |
| 9 | Valve Lifter Guide Bolt |
| 10 | Engine Block |
| 11 | Oil Pump Drive Seal |
| 12 | Oil Pump Drive |
| 13 | Oil Pump Drive Clamp Bolt |
| 14 | Piston Pin Retainer |
| 15 | Piston Pin |
| 16 | Piston Compression Upper Ring |
| 17 | Piston Compression Lower Ring |
| 18 | Piston Oil Ring Rail |
| 19 | Piston |
| 20 | Connecting Rod |
| 21 | Connecting Rod Bearing |
| 22 | Connecting Rod Bearing Cap |
| 23 | Connecting Rod Bolt |
| 24 | Camshaft Rear Bearing Hole Plug |
| 25 | Engine Block Oil Gallery Plug |
| 26 | Crankshaft Rear Oil Seal |
| 27 | Transmission Locating Pin |
| 28 | Knock Sensor |
| 29 | Knock Sensor Bolt |
| 30 | Engine Oil Cooler Fitting |
| 31 | Engine Oil Cooler Hose Clamp |
| 32 | Engine Oil Cooler Inlet Hose |
| 33 | Engine Oil Cooler Hose Clamp |
| 34 | Engine Oil Cooler Gasket |
| 35 | Engine Oil Cooler |
| 36 | Engine Oil Cooler Connector |
| 37 | Heater Inlet and Outlet Pipe Nut |
| 38 | Heater Inlet and Outlet Pipe |
| 39 | Heater Outlet Hose Clamp |
| 40 | Heater Outlet Front Hose |
| 41 | Heater Outlet Front Hose |
| 42 | Heater Outlet Hose Clamp |
| 43 | Heater Inlet Pipe Adapter Seal |
| 44 | Heater Inlet Pipe Bolt |
| 45 | Heater Inlet and Outlet Pipe |
| 46 | Heater Inlet Pipe Bolt |
| 47 | Engine Oil Cooler Hose Clamp |
| 48 | Engine Oil Cooler Outlet Hose |
| 49 | Engine Oil Cooler Hose Clamp |
| 50 | Oil Filter Adapter Stud |
| 51 | Engine Oil Pressure Indicator Switch |
| 52 | Engine Block Coolant Hole Plug |
| 53 | Oil Filter Bypass Valve |
| 54 | Oil Filter Adapter Gasket |
| 55 | Oil Filter Adapter |
| 56 | Oil Filter Fitting |
| 57 | Oil Filter Gasket |
| 58 | Oil Filter |
| 59 | Oil Filter Adapter Bolt |
| 60 | Air Conditioning Compressor Bracket Bolt |
| 61 | Air Conditioning Compressor Bracket |
| 62 | Piston Oil Nozzle Bolt |
| 63 | Piston Oil Nozzle |
| 64 | Engine Front Cover Gasket |
| 65 | Engine Front Cover Location Pin |
| 66 | Water Outlet Bolt |
| 67 | Water Outlet Stud |
| 68 | Water Outlet |
| 69 | Engine Coolant Thermostat Seal |
| 70 | Engine Coolant Thermostat |
| 71 | Thermostat Bypass Hose |
| 72 | Thermostat Bypass Pipe Clamp |
| 73 | Thermostat Bypass Hose |
| 74 | Thermostat Bypass Hose |
| 75 | Thermostat Bypass Pipe Clamp |
| 76 | Engine Front Cover |
| 77 | Engine Front Cover Bolt |
| 78 | Engine Front Cover Bolt |
| 79 | Water Pump |
| 80 | Water Pump Gasket |
| 81 | Water Pump Bolt |
| 82 | Water Pump Pulley |
| 83 | Water Pump Pulley Bolt |
| 84 | Crankshaft Front Oil Seal |
| 85 | Crankshaft Balancer |
| 86 | Crankshaft Balancer Bolt |
| 87 | Drive Belt Tensioner Bolt |
| 88 | Drive Belt Tensioner |
| 89 | Camshaft Position Actuator Magnet Bolt |
| 90 | Camshaft Position Actuator Magnet |
| 91 | Camshaft Position Actuator Magnet Gasket |
| 92 | Crankshaft Sprocket |
| 93 | Timing Chain Dampener Bolt |
| 94 | Timing Chain Dampener |
| 95 | Crankshaft Position Sensor Stud |
| 96 | Crankshaft Position Sensor |
| 97 | Crankshaft Position Sensor Seal |
| 98 | Engine Block Oil Gallery Plug |
| 99 | Camshaft Bearing |
| 100 | Camshaft Bearing |
| 101 | Camshaft Bearing |
| 102 | Camshaft |
| 103 | Camshaft Position Actuator Solenoid Valve Filter |
| 104 | Camshaft Thrust Plate |
| 105 | Camshaft Thrust Plate Bolt |
| 106 | Timing Chain |
| 107 | Camshaft Position Actuator |
| 108 | Camshaft Position Actuator Bolt |
Scheme 13
| Callout | Component Name |
|---|---|
| 1 | Crankshaft Balancer Key |
| 2 | Crankshaft Upper No. 1 Bearing |
| 3 | Crankshaft Upper No. 2 Bearing |
| 4 | Crankshaft Upper No. 3 Bearing |
| 5 | Crankshaft Upper No. 4 Bearing |
| 6 | Crankshaft |
| 7 | Oil Level Indicator Tube |
| 8 | Oil Level Indicator Tube Bolt |
| 9 | Oil Level Indicator |
| 10 | Oil Level Indicator Seal |
| 11 | Flywheel |
| 12 | Flywheel Bolt |
| 13 | Clutch Pressure Plate Bolt |
| 14 | Clutch Pressure Plate |
| 15 | Flywheel |
| 16 | Oil Pump Cover Bolt |
| 17 | Oil Pressure Relief Valve Spring Seat Pin |
| 18 | Oil Pressure Relief Valve Bore Plug |
| 19 | Oil Pump Driven Gear |
| 20 | Oil Pump Driven Gear Shaft |
| 21 | Oil Pump Housing |
| 22 | Oil Pump Drive Shaft |
| 23 | Oil Pump Drive Gear |
| 24 | Oil Pump Screen |
| 25 | Oil Pump Bolt |
| 26 | Oil Pressure Relief Valve Bore Plug |
| 27 | Oil Pressure Relief Valve |
| 28 | Oil Pressure Relief Valve Spring |
| 29 | Oil Pump Cover |
| 30 | Oil Pump |
| 31 | Oil Pump Drive Shaft |
| 32 | Oil Pan Bolt |
| 33 | Oil Pan Support Bracket |
| 34 | Oil Pan Support Bracket Bolt |
| 35 | Engine Oil Level Indicator Switch Bolt |
| 36 | Engine Oil Level Indicator Switch Clip |
| 37 | Engine Oil Level Indicator Switch |
| 38 | Engine Oil Level Indicator Switch Seal |
| 39 | Oil Pan Bolt |
| 40 | Oil Pan Drain Plug Seal |
| 41 | Oil Pan Drain Plug |
| 42 | Oil Pan Support Bracket |
| 43 | Oil Pan Support Bracket Bolt |
| 44 | Oil Pan |
| 45 | Oil Pan Gasket |
| 46 | Crankshaft Oil Deflector Nut |
| 47 | Crankshaft Oil Deflector |
| 48 | Crankshaft Bearing Cap Stud |
| 49 | Crankshaft No. 1 Bearing Cap |
| 50 | Crankshaft Lower No. 1 Bearing |
| 51 | Crankshaft Lower No. 2 Bearing |
| 52 | Crankshaft Lower No. 3 Bearing |
| 53 | Crankshaft Lower No. 4 Bearing |
| 54 | Crankshaft Bearing Cap |
| 55 | Crankshaft No. 4 Bearing Cap |
| 56 | Oil Pump Location Pin |
| 57 | Crankshaft Bearing Cap Bolt |
| 58 | Clutch Pilot Bearing |
Scheme 14
The Vehicle Identification Number - VIN derivative (1) for 3900 LZ9 is stamped or laser etched on the front and left side of the engine block. The Vehicle Identification Number - VIN derivative is nine digits long and can be used to determine if a vehicle contains the original engine.
- The first digit identifies the division.
- The second digit identifies the model year.
- The third digit identifies the assembly plant.
- The fourth through ninth digits are the last six digits of the Vehicle Identification Number - VIN.
