Scheme 54
| Callout | Component Name |
|---|---|
| 3 | Transmission Case Assembly |
| 53 | Control Valve Body Cover |
| 54 | Control Valve Body Cover Gasket |
| 56 | Control Valve Body Cover Bolt M 8 X 1.25 X 25 |
| 57 | Control Valve Body Cover TORX® Head Bolt M 8 X 1.25 X 21 |
| 58 | Control Valve Body Cover to Case Stud M 8 X 1.25 X 24 |
| 59 | Control Valve Body Cover to Case Cover Seal |
| 200 | Oil Pump Assembly - Model Dependent |
| 200 | Oil Pump Assembly - Model Dependent |
| 225 | Wiring Harness Assembly (IMS) |
| 226 | Wiring Harness Clip |
| 230 | Pump Cover to Case Cover Bolt M 6 X 1.0 X 95.0 |
| 231 | Pump Body to Case Bolt M6 X 1.0 X 87.5 |
| 300 | Control Valve Body Assembly - Model Dependent |
| 300 | Control Valve Body Assembly - Model Dependent |
| 368 | Spacer Plate and Gaskets/Control Valve Body Bolt |
| 368 | Spacer Plate and Gaskets/Control Valve Body Bolt |
| 372 | 1/4 Ball Check Valve |
| 372 | 5/16 Ball Check Valve |
| 373 | Ball Check Valve |
| 373 | Ball Check Valve |
| 374 | Control Valve Body Bolt M 6 X 1.0 X 65.0 |
| 375 | Control Valve Body to Case Bolt M 6 X 1.0 X 60.0 |
| 375 | Control Valve Body to Case Bolt M 6 X 1.0 X 60.0 |
| 376 | Control Valve Body to Case Bolt M 6 X 1.0 X 30.0 |
| 377 | Control Valve Body to Case Cover Bolt M 6 X 1.0 X 45.0 |
| 378 | Control Valve Body to Case Cover Bolt M 6 X 1.0 X 55.0 |
| 380 | Control Valve Body to Case Bolt M 8 X 1.25 X 90.0 |
| 381 | Control Valve Body to Case Bolt M 6 X 1 X 20.0 |
| 382 | TCC Solenoid Valve Screen/Seal Assembly |
| 382 | TCC Solenoid Valve Screen/Seal Assembly |
| 384 | Control Valve Body to Case Bolt M 6 X 1.0 X 85.0 |
| 390 | Temperature Sensor Clip |
| 391 | Transmission Fluid Temperature Sensor |
| 391 | Transmission Fluid Temperature Sensor |
| 395 | Transmission Fluid Pressure (TFP) Manual Valve Position Switch Assembly |
| 396 | Control Valve Body Spacer Plate and Gasket Assembly |
Scheme 55
| Callout | Component Name |
|---|---|
| 1 | Torque Converter Assembly |
| 2 | Torque Converter Bushing |
| 3 | Transmission Case |
| 4 | Right Axle Oil Seal Assembly |
| 5 | Case Extension Bolt M 10 X 1.5 X 35.0 |
| 6 | Case Extension Assembly |
| 7a | Front Differential Carrier Bushing |
| 7b | Output Shaft Bearing Assembly |
| 8 | Case Extension Seal |
| 9 | Vehicle Speed Sensor Bolt M 8 X 1.25 X 12.0 |
| 10 | Vehicle Speed Sensor Assembly |
| 11 | Vehicle Speed Sensor O-Ring Seal |
| 12 | FWD Servo Cover Bolt M 6 X 1.0 X 20.0 |
| 13 | Forward Band Servo Cover |
| 14 | Forward Band Servo Cover Seal |
| 15 | Forward Band Servo Pin Retaining Ring |
| 16 | Forward Band Servo Piston |
| 18 | Forward Band Servo Piston Oil Seal Ring |
| 19 | Forward Band Servo Piston Cushion Outer Spring |
| 20 | Forward Servo Cushion Spring Retainer |
| 21 | Forward Band Servo Piston Apply Pin |
| 22 | Forward Band Servo Piston Return Spring |
| 23 | Transmission Oil Pan Bolt M 6 X 1.0 X 17.0 |
| 24 | Transmission Oil Pan |
| 25 | Transmission Oil Pan Gasket |
| 26 | Transmission Oil Pan Magnets Qty: 2 |
| 27 | Oil Dam |
| 37 | Transmission Vent Assembly |
| 38 | Oil Pressure Test Hole Plug 1/8 - 27 NPTF |
| 39 | Reverse Band Servo Cover Retaining Ring |
| 40 | Reverse Band Servo Cover |
| 41 | Reverse Band Servo Cover O-Ring Seal |
| 42 | Reverse Band Servo Pin Retaining Ring |
| 43 | Reverse Band Servo Piston Oil Seal Ring |
| 44 | Reverse Band Servo Piston |
| 45 | Reverse Band Servo Piston Cushion Spring |
| 46 | Reverse Band Servo Piston Cushion Spring Retainer |
| 47 | Reverse Band Servo Piston Cushion Spring Inner |
| 48 | Reverse Band Servo Piston Apply Pin |
| 49 | Reverse Band Servo Piston Return Spring |
| 60 | Clip, Oil Cooler Quick Connect |
| 61 | Transmission Oil Cooler Pipe Fitting 9/16-18 UNF |
| 62 | Transmission Oil Cooler Pipe Fitting 9/16-18 UNF |
| 65 | Forward Band Servo Piston Cushion Inner Spring |
| 66 | Oil Cooler Pipe Fitting O-Ring Seal |
| 100 | Transmission Oil Filter Assembly |
| 101 | Transmission Oil Filter Seal Assembly |
| 227 | Oil Pump Drive Shaft Assembly |
| 228 | Oil Pump Drive Shaft Seal |
| 372 | Case Cover Ball Check Valve |
| 400 | Complete Case Cover Assembly |
Scheme 56
| Callout | Component Name |
|---|---|
| 3 | Transmission Case |
| 400 | Complete Case Cover Assembly |
| 432 | 4th Clutch Shaft Thrust Washer |
| 433 | Case Cover Bolt/Screw TORX® Special M6 X 1.0 X 32.0 |
| 434 | Case Cover Bolt/Screw M6 X 1.0 X 40.0 |
| 435 | Case Cover Bolt/Screw M8 X 1.25 X 50.0 |
| 436 | Case Cover Bolt/Screw M6 X 1.0 X 30.0 |
| 501 | 4th Clutch Fiber Plate Assembly |
| 502 | 4th Clutch Steel Plate |
| 504 | 4th Clutch Shaft Assembly |
| 505 | 4th Clutch Shaft Thrust Washer |
| 506 | Driven Sprocket |
| 507 | Drive Link Assembly |
| 508 | Driven Sprocket Thrust Washer |
| 509 | Drive Shaft Retaining Ring |
| 510a | Standard Output Shaft |
| 510b | Heavy Duty Output Shaft |
| 513 | Turbine Shaft Oil Seal Ring |
| 514 | Drive Sprocket Thrust Washer |
| 515 | Drive Sprocket Retaining Ring |
| 516 | Drive Sprocket |
| 517 | Drive Sprocket Thrust Washer |
| 518 | Turbine Shaft |
| 519 | Turbine Shaft Oil Seal Ring |
| 520 | Turbine Shaft O-Ring Seal |
| 521 | Drive Sprocket Support Bearing Assembly |
| 522 | Drive Sprocket Support |
| 523 | Drive Sprocket Support Bushing |
| 524 | Drive Sprocket Support Bolt/Screw M8 X 1.25 X 24.0 |
| 525 | Torque Converter Oil Seal Assembly |
| 526 | Case Cover Pin |
| 527 | Speed Sensor Reluctor Wheel Assembly |
| 528 | 4th Clutch Apply Plate |
Scheme 57
| Callout | Component Name |
|---|---|
| 3 | Transmission Case Assembly |
| 103 | 2-1 Manual Band Servo Cover Bolt/Screw M8 X 1.25 X 25.0 (3) |
| 104 | 2-1 Manual Band Servo Cover |
| 105 | 2-1 Manual Band Servo Cover Seal |
| 106 | 2-1 Manual Band Servo Piston Pin Retaining Ring |
| 107 | 2-1 Manual Band Servo Piston Seal |
| 108 | 2-1 Manual Band Servo Piston |
| 109 | 2-1 Manual Band Servo Piston Cushion Spring |
| 110 | 2-1 Manual Band Servo Piston Spring Retainer |
| 111 | 2-1 Manual Band Servo Piston Pin |
| 112 | 2-1 Manual Band Servo Piston Spring |
| 113 | 2-1 Manual Band Servo Piston Cylinder O-Ring Seal |
| 114 | 2-1 Manual Band Servo Piston Cylinder |
| 115 | 2-1 Manual Band Servo Exhaust Screen Assembly |
| 117a | Forward Band Anchor Pin |
| 117b | Reverse Band Anchor Pin |
| 120 | Thermo Element Plate Pin |
| 121 | Thermo Element |
| 122 | Thermo Element Plate |
| 123 | Thermo Element Plate Center Pin |
| 124 | Forward Band Servo Oil Pipe |
| 125 | 2-1 Manual Band Servo Oil Pipe |
| 129 | Lube Oil Pipe Retainer |
| 130 | Lube Oil Pipe and Washer Assembly |
| 131 | Accumulator Cover Bolt/Screw M6 X 1.0 X 28.0 (11) |
| 132 | Accumulator Cover |
| 134 | Accumulator Cover Spacer Plate Assembly |
| 135a | 1-2 Accumulator Piston Pin |
| 135b | 2-3 Accumulator Piston Pin |
| 136a | 1-2 Accumulator Piston |
| 136b | 2-3 Accumulator Piston |
| 137a | 1-2 Accumulator Piston Oil Seal Ring |
| 137b | 2-3 Accumulator Piston Oil Seal Ring |
| 138 | 2-3 Accumulator Piston Outer Spring |
| 139 | 1-2 Accumulator Piston Cushion Spring |
| 140 | 1-2 and 2-3 Accumulator Housing |
| 142 | 1-2 Accumulator Piston Outer Spring |
| 143 | 2-3 Accumulator Piston Cushion Spring |
Scheme 58
| Callout | Component Name |
|---|---|
| 201 | Pump Cover |
| 209 | Oil Pump Vane Ring |
| 209 | Oil Pump Vane Ring |
| 210 | Oil Pump Selective Rotor |
| 211 | Oil Pump Selective Vane |
| 212 | Oil Pump Slide Oil Seal Ring |
| 213 | Oil Pump Slide O-Ring Seal |
| 214 | Oil Pump Selective Slide |
| 215 | Oil Pump Slide Pivot Pin |
| 220 | Oil Pump Slide Seal |
| 221 | Oil Pump Slide Seal Support |
| 227 | Oil Pump Body |
| 228 | Oil Pump Body Alignment Pin |
| 229 | Oil Pump Base |
| 230 | Oil Pump Prime Spring |
Scheme 59
| Callout | Component Name |
|---|---|
| 301 | Control Valve Body Machined |
| 302 | Line Boost Valve and Bushing Retainer |
| 303 | Line Boost Valve Bore Plug |
| 304 | Line Boost Valve |
| 305 | TCC PWM Solenoid Valve O-Ring Seal |
| 306 | TCC PWM Solenoid Valve O-Ring Seal |
| 307 | Pressure Control Solenoid Valve O-Ring Seal |
| 309 | Reverse Boost Valve Bushing |
| 310 | Reverse Boost Valve |
| 311 | Pressure Regulator Valve Spring Outer |
| 312 | Pressure Regulator Valve Inner Spring |
| 313 | Pressure Regulator Valve |
| 314d | 1-2, 3-4 Shift Solenoid Valve Retainer |
| 314e | Pressure Control Solenoid Valve Retainer |
| 314f | TCC PWM Solenoid Valve Retainer |
| 314g | TCC Regulator Apply Valve Bore Plug Retainer |
| 315 | 1-2, 3-4 Shift Solenoid Valve Assembly |
| 316a | 1-2, 3-4 Shift Solenoid Valve O-Ring Seal |
| 316b | Pressure Control Solenoid Valve O-Ring Seal |
| 317 | 1-2 Shift Valve Spring |
| 318 | 1-2 Shift Valve |
| 320 | Torque Signal Regulator Valve Spring |
| 321 | Torque Signal Regulator Valve |
| 322 | Pressure Control Solenoid Valve Assembly |
| 323 | Line Pressure Relief Valve Spring |
| 324 | Line Pressure Relief Valve |
| 325 | Line Pressure Relief Valve Spring Retainer |
| 326 | TCC Regulator Apply Valve Spring |
| 327 | TCC Regulator Apply Valve - Some Models have touch activated Power |
| 327 | TCC Regulator Apply Valve - Some Models have touch activated Power |
| 328 | TCC Regulator Apply Valve Bore Plug O-Ring Seal |
| 329 | TCC Regulator Apply Valve Bore Plug |
| 334 | TCC PWM Solenoid Valve Assembly |
| 335 | TCC Control Valve |
| 336 | TCC Control Valve Spring |
Scheme 60
| Callout | Component Name |
|---|---|
| 301 | Machined Control Valve Body |
| 314a | 1-2 Accumulator Valve Retainer |
| 314b | 4-3 Manual Downshift Valve Retainer |
| 314c | 2-3 Shift Solenoid Valve Retainer |
| 315b | 2-3 Shift Solenoid Valve Assembly |
| 316 | O-Ring Seal |
| 339 | 1-2 Accumulator Valve Bore Plug |
| 340 | 3-4 Accumulator Valve Spring |
| 341 | 3-4 Accumulator Valve |
| 341 | 3-4 Accumulator Valve - Some Models |
| 342 | 2-3 Accumulator Valve Bore Plug Retainer |
| 343 | 2-3 Accumulator Valve Bore Plug |
| 344 | 2-3 Accumulator Valve |
| 345 | 2-3 Accumulator Valve Bushing |
| 346 | 2-3 Accumulator Valve Spring |
| 350 | 1-2 Accumulator Valve |
| 351 | 1-2 Accumulator Valve Spring |
| 353 | 3-2 Manual Downshift Valve Retainer |
| 354 | 3-2 Manual Downshift Valve Bore Plug |
| 355 | 3-2 Manual Downshift Valve Spring |
| 356 | 3-2 Manual Downshift Valve |
| 357 | 2-3 Shift Valve |
| 359 | 4-3 Manual Downshift Valve Bore Plug |
| 360 | 4-3 Manual Downshift Valve |
| 361 | 4-3 Manual Downshift Valve Spring |
| 362 | 3-4 Shift Valve |
| 385 | 2-3 Accumulator Valve Bushing Assembly Retainer |
Scheme 61
| Callout | Component Name |
|---|---|
| 401 | Case Cover |
| 402 | Manual Valve Link |
| 403 | Manual Valve Link Spring |
| 404 | Manual Valve |
| 405 | Low Blow Off Ball Valve Bore Plug |
| 406 | Low Blow Off Ball Valve Spring |
| 407 | Cooler Ball Valve Spring |
| 409 | Left Side Axle Oil Seal Assembly |
| 410 | Control Valve Body Alignment Sleeve |
| 411 | Bore Plug |
| 411 | Bore Plug |
| 412 | Orificed Cup Plug |
| 414 | Actuator Feed Limit Valve |
| 415 | Actuator Feed Limit Valve Spring |
| 416 | Actuator Feed Limit Valve Spring Retainer |
| 417 | Ball Valve Bore Plug |
| 418 | TCC Blow Off Ball Valve Spring |
| 420a | Low Blow Off Ball Valve |
| 420b | TCC Blow Off Ball Valve |
| 420c | Cooler Ball Valve |
| 421 | 3-4 Accumulator Piston Cylinder |
| 422 | 3-4 Accumulator Piston Cylinder O-Ring Seal |
| 423 | 3-4 Accumulator Piston Outer Spring |
| 424 | 3-4 Accumulator Piston Inner Spring |
| 426 | 3-4 Accumulator Piston Pin |
| 427 | 3-4 Accumulator Piston Oil Seal Ring |
| 428 | 3-4 Accumulator Piston |
| 429 | Case Cover Lower Gasket |
| 430 | Case Cover Upper Gasket |
| 431 | Front Wheel Drive Shaft Bearing Assembly |
| 432 | Fourth Clutch Shaft Thrust Washer |
| 440 | Input Speed Sensor Assembly |
| 441 | Input Speed Sensor Clip |
| 442 | Low Regulator Valve Spring 3-4 Accumulator Valve - Some models have touch activated power |
| 443 | Low Regulator Valve 3-4 Accumulator Valve - Some models have touch activated power |
| 444 | Low Regulator Valve Bore Plug 3-4 Accumulator Valve - Some models have touch activated power |
| 514 | Drive Sprocket/Case Cover Thrust Washer |
| 526 | Case Cover Dowel Pin |
| 526 | Case Cover Dowel Pin |
Scheme 62
| Callout | Component Name |
|---|---|
| 601 | 4th Clutch Spring Retaining Ring |
| 602 | 4th Clutch Piston Return Spring Assembly |
| 603 | 4th Clutch Piston Assembly |
| 604 | 4th Clutch Piston Seal Outer |
| 605 | 4th Clutch Piston Seal Inner |
| 606 | Drawn Cup Bearing Assembly |
| 607 | Orificed Cup Plug |
| 608 | Drive Link Lube Scoop |
| 609 | Driven Sprocket Support Assembly |
| 610 | Cup Plug |
| 611 | Thrust Washer Driven Sprocket Support 2nd Clutch Drum |
| 613 | Oil Seal Ring |
| 614 | Driven Sprocket Support Bushing |
| 615 | Reverse Band Assembly |
| 616 | 75.5 OD X 8.0 Bushing |
| 617 | 2nd Clutch Housing |
| 618 | Check Valve Retainer and Ball Assembly 2nd Clutch |
| 619 | 70.0 OD X 11.0 Bushing |
| 620 | 2nd Clutch Piston w/Molded Seal |
| 621 | 2nd Clutch Apply Ring and Release Spring Assembly |
| 622 | Retaining Ring |
| 623 | 2nd Clutch Plate Waved |
| 624 | 2nd Clutch Plate Assembly Fiber |
| 625 | 2nd Clutch Reaction Plate Steel |
| 626 | Backing Support Ring Plate Steel |
| 627 | 2nd Clutch Retaining Ring Outer |
| 628 | Oil Seal Ring Input Shaft |
| 629 | Thrust Bearing Support Sprocket/Thrust Washer |
| 630 | Selective Thrust Washer Bearing/Input Clutch Hub |
| 631 | Input Shaft Bushing |
| 632 | Input Housing Sleeve and Shaft Assembly |
| 633 | Check Valve Retainer and Ball Assembly |
| 634 | Input Clutch Piston Seal Inner |
| 635 | Input Clutch Piston Seal Outer |
| 636 | Input Clutch Piston |
| 637 | Input Clutch Spring and Retainer Assembly |
| 638 | O-Ring Seal |
| 639 | 3rd Clutch Piston Housing |
| 640 | Retaining Ring 3rd Clutch Piston Housing/Input Shaft |
| 640 | Retaining Ring 3rd Clutch Piston Housing/Input Shaft |
| 641 | 3rd Clutch Piston Seal Inner |
| 642 | 3rd Clutch Piston and Seal Assembly |
| 643 | 3rd Clutch Spring Retainer and Guide Assembly |
| 644 | Thrust Bearing Assembly |
| 645 | 3rd Clutch Plate Waved |
| 646 | 3rd Clutch Plate Assembly OD Spline |
| 647 | 3rd Clutch Plate Assembly ID Spline |
| 648 | 3rd Clutch Backing Plate |
| 649 | 3rd Clutch Backing Plate Retaining Ring |
| 654 | Input Clutch Apply Plate |
| 655 | Input Clutch Plate Waved |
| 657 | Input Clutch Plate Steel |
| 657 | Input Clutch Plate Steel |
| 658 | Input Clutch Backing Plate Steel |
| 659 | Input Clutch Backing Plate Retaining Ring |
| 716 | 2nd Clutch Apply Reaction Plate Tapered |
| 723 | 4th Clutch Shaft to Input Housing Bearing |
| 724 | 3rd Clutch Piston Housing Ball Check Valve Assembly |
| 725 | Input Clutch Plate Assembly Fiber - Pawl Clutch |
Scheme 63
| Callout | Component Name |
|---|---|
| 668 | Input Sun Gear |
| 669 | Reverse Reaction Drum |
| 671 | Input Sun Gear Thrust Bearing Assembly |
| 672 | Input Complete Carrier Assembly |
| 673 | Input Carrier/Reaction Carrier Lube Dam |
| 674 | Input/Reaction Carrier Thrust Bearing Assembly |
| 675 | Reaction Complete Carrier Assembly |
| 676 | Reaction Carrier/Sun Gear Thrust Bearing Assembly |
| 677 | Left Hand Reaction Sun Gear Bushing |
| 678 | Reaction Sun/Drum Gear Assembly |
| 679 | Right Hand Reaction Sun Gear Bushing |
| 680 | 2/1 Manual Band Assembly |
| 683 | 1/2 Support Roller Clutch Assembly |
| 685 | Thrust Bearing Assembly |
| 686 | 1/2 Support Bushing |
| 687 | 1/2 Support and Drum |
| 688 | Forward Band Assembly |
| 689 | Final Drive Sun Gear Shaft |
| 690 | Final Drive Internal Gear Bushing |
| 690 | Final Drive Internal Gear Bushing |
| 691 | Bearing 1/2 Support/Internal Gear |
| 692 | Retaining Ring Final Drive Internal Gear |
| 693 | Final Drive Internal Gear |
| 694 | Park Pawl Assembly |
| 695 | Thrust Bearing Assembly Internal Gear/Parking Gear |
| 696 | Parking Gear |
| 697 | Final Drive Sun Gear |
| 698 | Carrier/Sun Gear Thrust Bearing Assembly |
| 699 | Spiral Pinion Gear Pin Retaining Ring |
| 700 | Differential/Final Drive Carrier Assembly |
| 701 | Differential Pinion Shaft |
| 702 | Differential Pinion Shaft Retaining Pin |
| 703 | Thrust Washer Differential Pinion |
| 703 | Thrust Washer Differential Pinion |
| 704 | Differential Pinon Gear |
| 704 | Differential Pinon Gear |
| 705 | Differential Side Gear MN7 has unique left/right gears |
| 705 | Differential Side Gear MN7 has unique left/right gears |
| 706 | Bronze Thrust Washer Differential Side Gear |
| 706 | Bronze Thrust Washer Differential Side Gear |
| 708 | Pinion Thrust Washer Steel |
| 708 | Pinion Thrust Washer Steel |
| 709 | Roller Needle Bearing |
| 710 | Pinion Needle Bearing Spacer |
| 711 | Final Drive Planetary Pinion Gear |
| 712 | Planetary Pinion Gear Pin |
| 713 | Vehicle Speed Sensor Reluctor Wheel |
| 714 | Differential Carrier/Case Washer Thrust |
| 715 | Thrust Bearing Assembly |
| 727 | 3rd Clutch Pawl Assembly |
| 728 | Input Clutch Pawl Assembly |
Scheme 64
| Callout | Component Name |
|---|---|
| 800 | Park Pawl Actuator Assembly |
| 801 | Manual Shift Shaft Pin |
| 804 | Manual Shift Detent Assembly |
| 805 | Manual Shift Detent Bolt/Screw |
| 806 | Manual Shift Shaft Seal Assembly |
| 808 | Park Pawl Actuator Guide Pin |
| 809 | Park Pawl Actuator Guide |
| 810 | Park Pawl Actuator Guide O-Ring Seal |
| 811 | Lever Assembly-Manual Shaft Detent with Internal Mode Switch (IMS) |
Scheme 65
| Callout | Component Name |
|---|---|
| 1 | Oil Pump Assembly |
| 2 | Case Cover Assembly |
| 3 | Control Valve Body Assembly |
| 4 | Drive Sprocket |
| 5 | Torque Converter Assembly |
| 6 | Reverse Band Assembly |
| 7 | Third Clutch Pawl Assembly |
| 8 | Input Clutch Pawl Assembly |
| 9 | Input Carrier Assembly |
| 10 | 2-1 Manual Band Assembly |
| 11 | Reaction Carrier Assembly |
| 12 | 1/2 Support Roller Clutch Assembly |
| 13 | Vehicle Speed Sensor Assembly |
| 14 | Final Drive/Differential Carrier Assembly |
| 15 | Forward Band Assembly |
| 16 | 2-1 Manual Band Servo Assembly |
| 17 | Input Clutch Assembly |
| 18 | Third Clutch Assembly |
| 19 | Second Clutch Assembly |
| 20 | Oil Filter Assembly |
| 21 | Driven Sprocket Support Assembly |
| 22 | Driven Sprocket |
| 23 | Drive Link Assembly |
| 24 | Fourth Clutch Assembly |
| 25 | Output Shaft |
Scheme 66
| Callout | Component Name |
|---|---|
| 56 | Side Cover Bolt/Screw M8 X 1.25 X 25.0 (9) |
| 57 | Side Cover Bolt/Screw M8 X 1.25 X 21.0 (4) |
| 58 | Side Cover Bolt/Screw M8 X 1.25 X 24.0 (4) |
Scheme 67
| Callout | Component Name |
|---|---|
| 230 | Pump Body to Case Bolt M6 X 1.0 X 95.0 (2) |
| 230 | Pump Body to Case Bolt M6 X 1.0 X 95.0 (2) |
| 231 | Pump Cover to Case Cover Bolt M6 X 1.0 X 87.5 (9) |
| 231 | Pump Cover to Case Cover Bolt M6 X 1.0 X 87.5 (9) |
| 231 | Pump Cover to Case Cover Bolt M6 X 1.0 X 87.5 (9) |
| 231 | Pump Cover to Case Cover Bolt M6 X 1.0 X 87.5 (9) |
Scheme 68
| Callout | Component Name |
|---|---|
| 374 | Control Valve Body Bolt/Screw M6 X 1.0 X 65.0 (3) |
| 375 | Control Valve Body Bolt/Screw M6 X 1.0 X 60.0 (2) |
| 376 | Control Valve Body Bolt/Screw M6 X 1.0 X 30.0 (1) |
| 377 | Control Valve Body Bolt/Screw M6 X 1.0 X 45.0 (2) |
| 378 | Control Valve Body Bolt/Screw M6 X 1.0 X 55.0 (3) |
| 379 | Control Valve Body Bolt/Screw M6 X 1.0 X 87.5 (1) |
| 380 | Control Valve Body Bolt/Screw M8 X 1.0 X 90.0 (1) |
| 381 | Control Valve Body Bolt/Screw M6 X 1.0 X 20.0 (1) |
| 384 | Control Valve Body Bolt/Screw M6 X 1.0 X 85.0 (1) |
Scheme 69
| Callout | Component Name |
|---|---|
| 433 | Case Cover Bolt/Screw TORX® Plus Special M6 X 1.0 X 32.0 (1) |
| 434 | Case Cover Bolt/Screw M6 X 1.0 X 40.0 (3) |
| 435 | Case Cover Bolt/Screw M8 X 1.25 X 50.0 (3) |
| 436 | Case Cover Bolt/Screw M6 X 1.0 X 30.0 (3) |
| 805 | Case Cover Bolt/Screw M6 X 1.0 X 16.0 (1) |
Scheme 70
| Callout | Component Name |
|---|---|
| 23 | Transmission Oil Pan Bolt M6 X 1.0 X 17.0 (20) |
| 103 | 2-1 Manual Band Servo Cover Bolt/Screw M8 X 1.25 X 25.0 (3) |
| 131 | Accumulator Cover Bolt/Screw M6 X 1.0 X 28.0 (11) |
Scheme 71
| Callout | Component Name |
|---|---|
| 432 | Fourth Clutch Shaft Thrust Washer |
| 505 | Fourth Clutch Shaft Thrust Washer |
| 508 | Driven Sprocket Thrust Washer |
| 514 | Drive Sprocket Thrust Washer |
| 517 | Drive Sprocket Thrust Washer |
| 611 | Second Clutch Housing Thrust Washer |
| 630 | Input Clutch Housing Thrust Washer Selective |
| 703 | Differential Pinion Thrust Washer |
| 706 | Differential Side Gear Thrust Washer Bronze |
| 708 | Planetary Pinion Gear Thrust Washer Steel |
| 714 | Differential Carrier/Case Thrust Washer |
Scheme 72
| Callout | Component Name |
|---|---|
| 2 | Torque Converter Bushing |
| 7a | Front Differential Carrier Bushing M15 and MN3 Models Only |
| 523 | Turbine Shaft Bushing |
| 614 | Second Clutch Housing Bushing |
| 616 | Second Clutch Housing Front Bushing |
| 619 | Second Clutch Housing Rear Bushing |
| 631 | Input Shaft Bushing |
| 677 | Reaction Sun Gear Bushing Left Side |
| 679 | Reaction Sun Gear Bushing Right Side |
| 686 | 1-2 Support Drum Bushing |
| 690 | Front Differential Carrier Internal Gear Bushing |
Scheme 73
| Callout | Component Name |
|---|---|
| 7b | Output Shaft Bearing Assembly MN7 Models Only |
| 208 | Oil Pump Drive Shaft Bearing |
| 431 | Front Wheel Drive Shaft Bearing |
| 521 | Drive Sprocket Bearing Assembly |
| 606 | Driven Sprocket Bearing Assembly |
| 629 | Input Clutch Housing Thrust Bearing Assembly |
| 644 | Input Shaft Thrust Bearing Assembly |
| 671 | Input Sun Gear Thrust Bearing Assembly |
| 674 | Reaction Carrier Thrust Bearing Assembly |
| 676 | Reaction Sun Gear Thrust Bearing Assembly |
| 685 | 1-2 Drum Support Thrust Bearing |
| 691 | Final Drive Gear Internal Thrust Bearing |
| 695 | Front Differential Carrier Internal Gear Thrust Bearing |
| 698 | Front Differential Carrier Sun Gear Thrust Bearing |
| 709 | Front Differential Carrier Planetary Pinion Bearing |
| 715 | Front Differential Carrier Thrust Bearing |
| 723 | Input Clutch Housing Thrust Bearing |
Scheme 74
| Callout | Component Name |
|---|---|
| 4 | Front Wheel Drive Shaft Oil Seal Assembly Right Side |
| 18 | Forward Band Servo Piston Oil Seal Ring |
| 43 | Reverse Band Servo Piston Oil Seal Ring |
| 101 | Automatic Transmission Oil Filter Seal |
| 107 | Manual 2-1 Band Servo Piston Seal |
| 409 | Front Wheel Drive Shaft Oil Seal Assembly Left Side |
| 525 | Torque Converter Oil Seal Assembly |
| 604 | Fourth Clutch Piston Seal Outer |
| 605 | Fourth Clutch Piston Seal Inner |
| 620 | Second Clutch Piston and Seal Assembly |
| 620 | Second Clutch Piston and Seal Assembly |
| 634 | Input Clutch Piston Seal Inner |
| 635 | Input Clutch Piston Seal Outer |
| 641 | Third Clutch Piston Seal Inner |
| 642 | Third Clutch Piston and Seal Assembly |
| 642 | Third Clutch Piston and Seal Assembly |
| 806 | Manual Shift Shaft Seal |
Scheme 75
| Callout | Component Name |
|---|---|
| 8 | Automatic Transmission Case Extension Seal |
| 11 | Vehicle Speed Sensor O-Ring Seal |
| 14 | Forward Band Servo Cover Seal |
| 41 | Reverse Band Servo Cover O-Ring Seal |
| 105 | Manual 2-1 Band Servo Cover Seal |
| 113 | Manual 2-1 Band Servo Piston Cylinder O-Ring Seal |
| 137a | 1-2 Accumulator Piston Oil Seal Ring |
| 137b | 2-3 Accumulator Piston Oil Seal Ring |
| 212 | Automatic Transmission Oil Pump Slide Oil Seal Ring |
| 213 | Automatic Transmission Oil Pump Slide O-Ring Seal |
| 220 | Automatic Transmission Oil Pump Slide Seal |
| 221 | Automatic Transmission Oil Pump Slide Seal Support |
| 228 | Automatic Transmission Oil Pump Drive Shaft Seal |
| 422 | 3-4 Accumulator Piston Cylinder O-Ring Seal |
| 427 | 3-4 Accumulator Piston Oil Seal |
| 513 | Turbine Shaft Oil Seal Ring |
| 519 | Turbine Shaft Oil Seal Ring |
| 520 | Turbine Shaft O-Ring Seal |
| 612 | Second Clutch Housing Oil Seal Ring Four Lobe Seal |
| 613 | Second Clutch Housing Oil Seal Ring |
| 628 | Input Clutch Housing Oil Seal Ring |
| 638 | Third Clutch Housing O-Ring Seal |
| 810 | Park Pawl Actuator Guide O-Ring Seal |
Scheme 76
| Callout | Component Name |
|---|---|
| 25 | Oil Pan Gasket |
| 54 | Case Side Cover Gasket |
| 59 | Case Side Cover Inner Gasket |
| 396 | Control Valve Body Spacer Plate and Gasket Assembly |
| 429 | Case Cover Lower Gasket |
| 430 | Case Cover Upper Gasket |
Scheme 77
| Callout | Component Name |
|---|---|
| 1 | TCC Apply-Release |
| 2 | 2nd-2nd Clutch |
| 3 | Input Clutch-PRN |
| 4 | 3rd Clutch-Lo/1st |
| 5 | Reverse-Reverse Servo Large |
| 6 | D4-Servo Apply |
| 7 | Lo-Lo/1st |
| 8 | D2-Manual 2-1 Servo Feed |
| 9 | 3rd-3rd Clutch |
| 10 | Line-Lo/1st Gear |
