Check tire pressure. Riding height specifications are on door pillar or in glove box. Place front seats in rearmost position. Cargo compartment must be empty. Fuel tank should be full. To normalize riding height, bounce vehicle up and down. Measure riding height at locations shown. (Scheme 1)to 4.
Astro & Safari Riding Height Measuring Points. Scheme 1
Scheme 1: Astro & Safari Riding Height Measuring Points
"C", "K", "G", & "P" Series Riding Height Measuring Points. Scheme 2
Scheme 2: "C", "K", "G", & "P" Series Riding Height Measuring Points
"S" Series Riding Height Measuring Points. Scheme 3
Scheme 3: "S" Series Riding Height Measuring Points
Scheme 4
SPECIFICATIONS
| Application | Front "A" | Rear "B" |
|---|
| Astro/Safari (1) | 29-30" | 30-31" |
| C10/20 & C30 Series | 2 1/2-5 3/4" | N/A |
| G10/20/30 Series | 1 1/2-4 1/2" | N/A |
| K10/20/30 Series | N/A | N/A |
| P20/30 Series | 2-4 3/4" | N/A |
| S/T-10/15 Series (2) |
| 2WD | 2 5/8-3" | 6 1/2-7" |
| 4WD | 4 5/8-5" | 6 1/2-7" |
| (1) With approximately 1000 Lbs. of cargo or 4-5 passengers. (2) Adjust by turning torsion bar adjustment bolt. |
| (1) | With approximately 1000 Lbs. of cargo or 4-5 passengers. |
| (2) | Adjust by turning torsion bar adjustment bolt. |
