Fastener Tightening Specifications (1.4L LUV)
| Application | Specification | |
|---|---|---|
| Metric | English | |
| Air Conditioning Compressor And Condenser Hose Bolt | 9 N.m | 80 lb in |
| Air Conditioning Compressor And Condenser Hose Nut | 19 N.m | 14 lb ft |
| Air Conditioning Evaporator Hose Nut | 19 N.m | 14 lb ft |
| Engine Coolant Thermostat Housing Bolt | 8 N.m | 71 lb in |
| Engine Oil Cooler Bolt | 20 N.m | 15 lb ft |
| Engine Oil Cooler Inlet Pipe Bolt | 10 N.m | 89 lb in |
| Engine Oil Cooler Outlet Pipe Bolt | 10 N.m | 89 lb in |
| Ground Cable Nut - Coolant Fan Wiring Harness | 10 N.m | 89 lb in |
| Oil Pressure Indicator Switch | 20 N.m | 15 lb ft |
| Radiator Lower Bracket Bolt | 22 N.m | 16 lb ft |
| Radiator Upper Bracket Bolt | 22 N.m | 16 lb ft |
| Turbocharger Coolant Return Pipe Bolt | 10 N.m | 89 lb in |
| Water Outlet Bolt | 8 N.m | 71 lb in |
| Water Pump Bolt | 8 N.m | 71 lb in |
| Water Pump Pulley Bolt | 22 N.m | 16 lb ft |
Fastener Tightening Specifications (1.4L LUV)
Fastener Tightening Specifications (1.8L LUW and LWE)
| Application | Specification | |
|---|---|---|
| Metric | English | |
| Engine Coolant Fan Motor Bolt | 4 N.m | 36 lb in |
| Engine Coolant Fan Resistor Bolt | 4 N.m | 36 lb in |
| Engine Coolant Thermostat Bolt | 8 N.m | 71 lb in |
| Engine Coolant Thermostat Bypass Pipe Bolt | 8 N.m | 71 lb in |
| Engine Coolant Thermostat Housing Bolt | 8 N.m | 71 lb in |
| Engine Coolant Thermostat Housing Retainer Nut | 9 N.m | 80 lb in |
| Engine Oil Cooler Bolt | 8 N.m | 71 lb in |
| Engine Oil Cooler Housing Bolt | 25 N.m | 19 lb ft |
| Engine Oil Cooler Pipe Bolt | 8 N.m | 71 lb in |
| Hood Hold Open Rod Retainer Bracket Bolt | 22 N.m | 17 lb ft |
| Radiator Bracket Bolt | 25 N.m | 18 lb ft |
| Radiator Support Bracket Bolt | 22 N.m | 17 lb ft |
| Water Pump Housing Bolt | 8 N.m | 71 lb in |
| Water Pump Pulley Bolt | 20 N.m (1) | 15 lb ft (1) |
| (1) Recut threads before re-use and insert bolts with screw locking compound. The installation time, including torque inspection, is a maximum of 10 minutes. | ||
Fastener Tightening Specifications (1.8L LUW and LWE)
| Application | Specification | |
|---|---|---|
| Metric | English | |
| Cooling System | ||
| Water Pump Design | Rotary Pump | |
| Cooling Filling Quantity | 6.2 L | 6.6 quart |
| Thermostat (Grid Controlled) | ||
| Thermostat Opening 0V | 103°C | 217°F |
| Thermostat Opening 12V | 80°C | 176°F |
Engine Cooling System Specifications (1.4L LUV)
| Application | Specification | |
|---|---|---|
| Metric | English | |
| Cooling System | ||
| Water Pump Design | Rotary Pump | |
| Flow (engine outlet 6000 min -1 , Thermostat fully open) | 165 l/min | 43.588 US gal |
| Coolant filling quantity | 5.9L | 5.917 quart |
| Thermostat | ||
| Thermostat Opening- Electrical | 90°C | 194°F |
| Thermostat Opening- Thermic | 105°C | 221°F |
Engine Cooling System Specifications (1.8L LUW and LWE)
