Object Detection System - Park Assist System: Removal & Installation Chevrolet Cruze I facelift

Collision/avoidance 2 illustrations ~194 words

Removal Procedure

  1. Remove the rear bumper fascia. Refer to «Rear Bumper Fascia Replacement»(ref-543806-S33900343182013042400000)
  2. Disconnect electrical from the rear object sensor.
  3. Lift the locking tabs on the housing and remove the rear object sensor.

Installation Procedure

  1. Insert the sensor into the housing.
  2. Connect the electrical connector to the rear object sensor.
  3. Install the rear bumper fascia. Refer to «Rear Bumper Fascia Replacement»(ref-543806-S33900343182013042400000) .

Rear Object Sensor Housing Replacement

  1. Remove the rear fascia. Refer to «Rear Bumper Fascia Replacement»(ref-543806-S33900343182013042400000) .
  2. Disconnect the sensor harness.
  3. Remove the sensor from the sensor housing. The sensor housing must be painted if replaced. If reinstalled, painting will not be necessary.
  4. Sand/grind sonic weld plastic residue from the fascia.
  5. Apply structural adhesive epoxy, Lord Fusor™ 127EZ or equivalent, to fascia at mating surface.
  6. Using the alignment tabs, install the sensor housing to the fascia.
  7. Allow adhesive to cure according to manufacturer's directions.
  8. Install the sensor to the sensor housing.
  9. Connect the electrical harness.
  10. Install the rear fascia. Refer to «Rear Bumper Fascia Replacement»(ref-543806-S33900343182013042400000) .

Scheme 4

Scheme 4: Rearview Camera Image Display Module Replacement
Scheme 4: Rearview Camera Image Display Module Replacement
CalloutComponent Name
Preliminary Procedure Remove the rearview camera image display module bracket. Refer to Rearview Camera Image Display Module Bracket Replacement .
1Rearview Camera Image Display Module Procedure Use a suitable tool to remove.

Rearview Camera Image Display Module Replacement

Scheme 5

Scheme 5: Rearview Camera Image Display Module Bracket Replacement
Scheme 5: Rearview Camera Image Display Module Bracket Replacement
CalloutComponent Name
Preliminary Procedure Remove the rear compartment lid applique. Refer to Rear Compartment Lid Applique Replacement .
1Rearview Camera Image Display Module Bracket Procedure Use a suitable tool to remove. Remove the rearview camera image display module. Refer to Rearview Camera Image Display Module Replacement .

Rearview Camera Image Display Module Bracket Replacement
