Object Detection System - Park Assist System: Other Chevrolet Cruze I facelift

Collision/avoidance 1 illustration ~3095 words

Reference Information

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Object Detection Description and Operation (with Side Blind Spot Alert (UFT)) , Object Detection Description and Operation (with Parking Assist (UD7)) , Object Detection Description and Operation (with Rearview Camera (UCV))

Electrical Information Reference

  1. «Circuit Testing»(ref-543822-S09065750572013042400000)
  2. «Connector Repairs»(ref-543822-S34024840292013042400000)
  3. «Testing for Intermittent Conditions and Poor Connections»(ref-543822-S12370792452013042400000)
  4. «Wiring Repairs»(ref-543822-S31020379062013042400000)

Scan Tool Reference

Control Module References for scan tool information

Circuit/System Verification

  1. Ignition ON.
  2. Verify that B094B 45 or B094C 45 is not set. If DTC is set Program the appropriate B218 Side Object Sensor Module. Verify the DTC does not set. If the DTC sets, replace the appropriate B218 Side Object Sensor Module. If the DTC does not set All OK. If DTC is not set
  3. Verify that B094B 00, B094C 00, B094B 08, B094C 08, B094B 54 or B094C 54 is not set. If DTC is set Replace the appropriate B218 Side Object Sensor Module. If the DTC is not set
  4. Verify that B094B 58 or B094C 58 is not set. If DTC is set Verify the area in front of the sensor is clean, unobstructed, and damage-free. If not clean, unobstructed, and damage-free, clean or repair as necessary. If clean, unobstructed, and damage-free, replace the appropriate B218 Side Object Sensor Module. If DTC is not set
  5. All OK.

Repair Instructions

Perform the Diagnostic Repair Verification after completing the repair.

Control Module References for side object sensor module replacement, programming and setup

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Object Detection Description and Operation (with Side Blind Spot Alert (UFT)) , Object Detection Description and Operation (with Parking Assist (UD7)) , Object Detection Description and Operation (with Rearview Camera (UCV))

Electrical Information Reference

  1. «Circuit Testing»(ref-543822-S09065750572013042400000)
  2. «Connector Repairs»(ref-543822-S34024840292013042400000)
  3. «Testing for Intermittent Conditions and Poor Connections»(ref-543822-S12370792452013042400000)
  4. «Wiring Repairs»(ref-543822-S31020379062013042400000)

Scan Tool Reference

Control Module References for scan tool information

  1. Ignition ON.
  2. Verify the scan tool can communicate with the right side object sensor. If the scan tool can not communicate with the right side object sensor Refer to Circuit/System Testing below - Right Side Object Sensor Malfunction. If the scan tool can communicate with the right side object sensor
  3. Verify the scan tool can communicate with the left side object sensor. If the scan tool can not communicate with the left side object sensor Refer to Circuit/System Testing below - Left Side Object Sensor Malfunction. If the scan tool can communicate with the left side object sensor
  4. Ignition OFF, ignition ON.
  5. Verify that both side blind zone alert system indicators located in the outside rearview mirrors briefly turn ON and then turn OFF during the system self test when ignition is initially turned ON. If both side blind zone alert indicators do not briefly turn ON and OFF The system may have been disabled, refer to Diagnostic Aids. If system has not been disabled refer to Circuit/System Testing below - Side Object Indicator Malfunction. If only one indicator does not briefly illuminate during the self test Refer to Circuit/System Testing below- Side Object Indicator Malfunction. If both side blind zone alert indicators briefly turn ON and OFF
  6. All OK.

Perform the Diagnostic Repair Verification after completing the repair.

  1. «Outside Rearview Mirror Glass Replacement»(ref-543830-S09765249992013042400000)
  2. «Control Module References»(ref-543823-S31978628992013042400000) for Side Object Sensor Module replacement, programming and setup.

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Object Detection Description and Operation (with Side Blind Spot Alert (UFT)) , Object Detection Description and Operation (with Parking Assist (UD7)) , Object Detection Description and Operation (with Rearview Camera (UCV))

Electrical Information Reference

  1. «Circuit Testing»(ref-543822-S09065750572013042400000)
  2. «Connector Repairs»(ref-543822-S34024840292013042400000)
  3. «Testing for Intermittent Conditions and Poor Connections»(ref-543822-S12370792452013042400000)
  4. «Wiring Repairs»(ref-543822-S31020379062013042400000)

Scan Tool Reference

Control Module References for scan tool information

  1. Ignition ON.
  2. Verify that DTC B1405 is not set. If the DTC is set Refer to «DTC B1405»(ref-543855-S14708258132013042400000) If the DTC is not set
  3. Verify that DTC B0958 01, B0959 01, B0960 01 or B0961 01 is not set. If the DTC is set Check the appropriate sensor for contamination with mud. If no contamination is diagnosed, refer to Circuit/System Testing below. If the DTC is not set
  4. Verify that DTC B0958 21, B0959 21, B0960 21 or B0961 21 is not set. If the DTC is set Check the appropriate sensor for contamination with mud, ice or snow. If no contamination is diagnosed, replace the sensor. If the DTC is not set
  5. Verify that DTC B0958 3A, B0959 3A, B0960 3A or B0961 3A is not set. If the DTC is set Replace the appropriate sensor with a sensor of correct sensor type. If the DTC is not set
  6. Ignition ON, transmission in REVERSE, verify the scan tool Parking Assist System Status parameter displays Enabled. If the Parking Assist System displays Disabled Refer to Circuit/System Testing below. If the Parking Assist System displays Enabled
  7. All OK.

Perform the Diagnostic Repair Verification after completing the repair

  1. «Rear Parking Assist Alarm Sensor Replacement»(ref-543855-S12079296222013042400000)
  2. «Control Module References»(ref-543823-S31978628992013042400000) for rear parking assist control module replacement, programming and setup.

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Object Detection Description and Operation (with Side Blind Spot Alert (UFT)) , Object Detection Description and Operation (with Parking Assist (UD7)) , Object Detection Description and Operation (with Rearview Camera (UCV))

Electrical Information Reference

  1. «Circuit Testing»(ref-543822-S09065750572013042400000)
  2. «Connector Repairs»(ref-543822-S34024840292013042400000)
  3. «Testing for Intermittent Conditions and Poor Connections»(ref-543822-S12370792452013042400000)
  4. «Wiring Repairs»(ref-543822-S31020379062013042400000)

Scan Tool Reference

Control Module References for scan tool information

  1. Ignition ON.
  2. Verify that DTC B0967 02 is not set. If the DTC is set Refer to Parking Assist Switch Malfunction below. If the DTC is not set
  3. Verify that B0968 01 or B0968 06 is not set. If the DTC is set Refer to Parking Assist Switch Indicator Malfunction below. If the DTC is not set
  4. Activate and deactivate the parking assist switch and verify the scan tool Park Assist Switch parameter changes between Active and Inactive. If the Parking Assist Switch parameter does not change between Active and Inactive Refer to Circuit/System Testing below. If the Parking Assist Switch parameter changes between Active and Inactive
  5. All OK.

Perform the Diagnostic Repair Verification after completing the repair

  1. «Rear Object Alarm Control Module Replacement»(ref-543855-S26636690162013042400000)
  2. «Control Module References»(ref-543823-S31978628992013042400000) for parking assist control module replacement, programming and setup.

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Object Detection Description and Operation (with Side Blind Spot Alert (UFT)) , Object Detection Description and Operation (with Parking Assist (UD7)) , Object Detection Description and Operation (with Rearview Camera (UCV))

Electrical Information Reference

  1. «Circuit Testing»(ref-543822-S09065750572013042400000)
  2. «Connector Repairs»(ref-543822-S34024840292013042400000)
  3. «Testing for Intermittent Conditions and Poor Connections»(ref-543822-S12370792452013042400000)
  4. «Wiring Repairs»(ref-543822-S31020379062013042400000)

Scan Tool Reference

Control Module References for scan tool information

  1. Ignition ON.
  2. Verify the DTC B1015 is not. If the DTC B1015 is set Program the control module the DTC originally set in. Verify the DTC does not set. If the DTC is sets, replace the control module the DTC set in. If the DTC does not set All OK If the DTC B1015 is not set
  3. All OK

Perform the Diagnostic Repair Verification after completing the repair

Control Module References for the rear parking assist control module, vehicle direction camera control module replacement, programming and setup.

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Object Detection Description and Operation (with Side Blind Spot Alert (UFT)) , Object Detection Description and Operation (with Parking Assist (UD7)) , Object Detection Description and Operation (with Rearview Camera (UCV))

Electrical Information Reference

  1. «Circuit Testing»(ref-543822-S09065750572013042400000)
  2. «Connector Repairs»(ref-543822-S34024840292013042400000)
  3. «Testing for Intermittent Conditions and Poor Connections»(ref-543822-S12370792452013042400000)
  4. «Wiring Repairs»(ref-543822-S31020379062013042400000)

Scan Tool Reference

Control Module References for scan tool information

Ignition ON, transmission in REVERSE, observe the scan tool Park Assist Sensor Reference Voltage parameter. The reading should be between 7.2-9.2 V.

Perform the Diagnostic Repair Verification after completing the repair.

  1. «Rear Object Alarm Control Module Replacement»(ref-543855-S26636690162013042400000)
  2. «Control Module References»(ref-543823-S31978628992013042400000) for parking assist control module replacement, programming and setup

Symptoms - Object Detection

Note. The following steps must be completed before using the symptom tables

  1. Perform the «Diagnostic System Check - Vehicle»(ref-543818-S13847936952013042400000) before using the Symptom Tables in order to verify that all of the following are true: before using the Symptom Tables in order to verify that all of the following are true: There are no DTCs set. The control modules can communicate via the serial data link.
  2. Review the system operation in order to familiarize yourself with the system functions. Refer to «Object Detection Description and Operation (with Side Blind Spot Alert (UFT))»(ref-543855-S41671292012013042400000) , «Object Detection Description and Operation (with Parking Assist (UD7))»(ref-543855-S18743447862013042400000) , «Object Detection Description and Operation (with Rearview Camera (UCV))»(ref-543855-S35233630052013042400000) .

Intermittent

Faulty electrical connections or wiring may be the cause of intermittent conditions. Refer to Testing for Intermittent Conditions and Poor Connections .

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Object Detection Description and Operation (with Side Blind Spot Alert (UFT)) , Object Detection Description and Operation (with Parking Assist (UD7)) , Object Detection Description and Operation (with Rearview Camera (UCV))

Electrical Information Reference

  1. «Circuit Testing»(ref-543822-S09065750572013042400000)
  2. «Connector Repairs»(ref-543822-S34024840292013042400000)
  3. «Testing for Intermittent Conditions and Poor Connections»(ref-543822-S12370792452013042400000)
  4. «Wiring Repairs»(ref-543822-S31020379062013042400000)

Scan Tool Reference

Control Module References for scan tool information

  1. Ignition ON.
  2. Verify the park assist system is enabled through the parking assist switch. If the park assist system is manually disabled, enable the system. Refer to the vehicle owners manual for instructions on enabling the system. If the park assist system does not manually change
  3. Verify the scan tool Park Assist Switch parameter while pressing and releasing the parking assist switch. The parameter should change between Active and Inactive. If the parameter does not change between Active and Inactive Refer to Parking Assist Switch Circuit Malfunction. If the parameter changes between Active and Inactive
  4. Command the Park Assist Switch LED output control On and Off with the scan tool. The parking assist switch indicator should turn On and Off when changing between the commanded states. If the indicator does not turn ON and OFF Refer to Parking Assist Switch Indicator Circuit Malfunction below. If the indicator does turn ON and OFF
  5. Transmission in reverse, verify the Engine Control Module (ECM) scan tool Reverse Position Switch parameter is Active. If the parameter is not Active Refer to «Backup Lamps Malfunction (Manual Transmission)»(ref-543807-S20239741532013042400000) , «Backup Lamps Malfunction (Automatic Transmission)»(ref-543807-S23998131652013042400000) . If the parameter is Active
  6. Transmission in REVERSE, verify the scan tool Park Assist System Status parameter displays Enable. If the parameter is not Enabled Refer to Diagnostic Aids to determine the cause of the inhibit. If the parameter is Enabled
  7. All OK.

Perform the Diagnostic Repair Verification after completing the repair.

  1. «Rear Object Alarm Control Module Replacement»(ref-543855-S26636690162013042400000)
  2. «Control Module References»(ref-543823-S31978628992013042400000) for Parking Assist Control Module replacement, programming and setup

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Object Detection Description and Operation (with Side Blind Spot Alert (UFT)) , Object Detection Description and Operation (with Parking Assist (UD7)) , Object Detection Description and Operation (with Rearview Camera (UCV))

Electrical Information Reference

  1. «Circuit Testing»(ref-543822-S09065750572013042400000)
  2. «Connector Repairs»(ref-543822-S34024840292013042400000)
  3. «Testing for Intermittent Conditions and Poor Connections»(ref-543822-S12370792452013042400000)
  4. «Wiring Repairs»(ref-543822-S31020379062013042400000)

Scan Tool Reference

Control Module References for scan tool information

  1. Ignition ON.
  2. Verify that DTC B2545 is not set. If the DTC is set Refer to «DTC B2545»(ref-543807-S41854155512013042400000) . If the DTC is not set
  3. Verify the rearview camera there is no debris on the lens and that the bezel or bezel seal is not damaged. If debris are found on the lens Clean the lens. If the lens, bezel, or bezel seal are damaged, replace as necessary. If no debris on the lens
  4. Ignition ON, transmission in REVERSE.
  5. Verify the backup lamps are On. If the backup lamps are not ON Refer to «Backup Lamps Malfunction (Manual Transmission)»(ref-543807-S20239741532013042400000) , «Backup Lamps Malfunction (Automatic Transmission)»(ref-543807-S23998131652013042400000) . If the backup lamps are ON
  6. Engine running, transmission in REVERSE.
  7. Verify a clear rear vision image is displayed on the radio. If a clear image is not displayed Refer to Circuit/System Testing below. If a clear image is displayed
  8. All OK.

Perform the Diagnostic Repair Verification after completing the repair.

  1. «Rearview Camera Image Display Module Replacement»(ref-543855-S37252243052013042400000)
  2. «Control Module References»(ref-543823-S31978628992013042400000) for body control module or radio replacement, programming and setup

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Object Detection Description and Operation (with Side Blind Spot Alert (UFT)) , Object Detection Description and Operation (with Parking Assist (UD7)) , Object Detection Description and Operation (with Rearview Camera (UCV))

Electrical Information Reference

  1. «Circuit Testing»(ref-543822-S09065750572013042400000)
  2. «Connector Repairs»(ref-543822-S34024840292013042400000)
  3. «Testing for Intermittent Conditions and Poor Connections»(ref-543822-S12370792452013042400000)
  4. «Wiring Repairs»(ref-543822-S31020379062013042400000)

Scan Tool Reference

Control Module References for scan tool information

  1. Ignition ON.
  2. Verify the scan tool can communicate with the right side object sensor. If the scan tool can not communicate with the right side object sensor Refer to Circuit/System Testing below - Right Side Object Sensor Malfunction. If the scan tool can communicate with the right side object sensor
  3. Verify the scan tool can communicate with the left side object sensor. If the scan tool can not communicate with the left side object sensor Refer to Circuit/System Testing below - Left Side Object Sensor Malfunction. If the scan tool can communicate with the left side object sensor
  4. Ignition OFF, ignition ON.
  5. Verify that both side blind zone alert system indicators located in the outside rearview mirrors briefly turn ON and then turn OFF during the system self test when ignition is initially turned ON. If both side blind zone alert indicators do not briefly turn ON and OFF The system may have been disabled, refer to Diagnostic Aids. If system has not been disabled refer to Circuit/System Testing below - Side Object Indicator Malfunction. If only one indicator does not briefly illuminate during the self test Refer to Circuit/System Testing below - Side Object Indicator Malfunction. If both side blind zone alert indicators briefly turn ON and OFF
  6. All OK.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

  1. «Outside Rearview Mirror Glass Replacement»(ref-543830-S09765249992013042400000)
  2. «Control Module References»(ref-543823-S31978628992013042400000) for Side Object Sensor Module replacement, programming and setup.

Scheme 6

Scheme 6: Rear Object Alarm Control Module Replacement
Scheme 6: Rear Object Alarm Control Module Replacement
CalloutComponent Name
Preliminary Procedures Remove the rear compartment side trim. Refer to Rear Compartment Side Trim Replacement - Left Side .
1Rear Object Alarm Module Clip (Qty: 3)
2Rear Object Alarm Module

Rear Object Alarm Control Module Replacement

Side Blind Zone Alert System Components

The side blind zone alert system is made up of the following components

  1. Left side object sensor module (also used for rear cross traffic alert)
  2. Right side object sensor module (also used for rear cross traffic alert)
  3. Driver outside rearview mirror
  4. Passenger outside rearview mirror

Side Object Sensor Modules

The side object sensor modules are located on each side of the vehicle behind the rear fascia and are not directly visible from outside the vehicle. The sensors use radar to determine the presence of objects nearby. When an object is detected in the side blind zone, the side object sensor module supplies voltage to illuminate the visual indicator on the appropriate side rear view mirror. Each sensor is supplied B+ and ground. The right sensor receives an additional ground. Both sensors communicate independently on the serial data line. The serial data enters the left sensor in a pass-thru configuration, that connects to the right sensor. The scan tool is able to individually communicate with each sensor.

Outside Rearview Mirrors

The outside rearview mirrors contain an icon that is backlit with high intensity, amber-colored LED's located on the mirror surface. The display brightness adapts to day/night conditions. The side blind zone alert indicator icon in the left or right outside rearview mirror is illuminated if the left or right side object sensor module detects a vehicle in the side blind zone to inform the driver that there is a vehicle driving in the blind spot zone.

Side Blind Zone Alert Driver Information Center Messages

SIDE BLIND ZONE ALERT OFF

This message indicates that the system has been disabled through the driver information center. Refer to the vehicle owners manual for instructions on how to set personalization options on the driver information center.

SERVICE SIDE DETECTION SYSTEM

This message indicates that the system requires service. When the message is displayed, the indicators will remain illuminated at all times, notifying the driver that the side blind zone system should not be relied upon when changing lanes. Since the sensors are also used for rear cross traffic alert, this feature will also be inoperative.

SIDE DETECTION SYSTEM UNAVAILABLE

This message indicates that the system has been temporarily disabled because the sensor is blocked or can otherwise not accurately detect vehicles or objects. Such instances may be mud, dirt, snow, ice, or slush build-up on the rear fascia, heavy rainfall, excessive road spray, fascia damage or stickers.

The rear cross traffic alert system will read the GPS latitude and longitude on the serial data bus and calculate if the vehicle is within a Radio Astronomy zone. These zones are located in Europe and Japan and require the sensors to be turned off. The "Side Detection System Unavailable" message will be displayed to the driver when this occurs.

Parking Assist System Driver Information Center Messages

SERVICE PARK ASSIST

The driver information center displays SERVICE PARK ASSIST when the parking assist control module detects a malfunction in the rear parking assist system and the system is disabled. The driver information center also displays SERVICE PARK ASSIST when a loss of communication occurs with the parking assist control module.

PARK ASSIST OFF

The PARK ASSIST OFF message is displayed in the driver information center when the parking assist system is disabled due to conditions that disable or inhibit the system. The parking assist control module requests the driver information center display PARK ASSIST OFF when it detects that one of the following conditions

  1. The rear parking assist system is manually disabled by the vehicle operator through the audio system personalization menu.
  2. The park brake is applied or not fully released.
  3. An object is attached to the rear of the vehicle, such as a trailer, bicycle rack, trailer hitch receiver, or tow bar. Also, an object extending beyond a lowered endgate will disable the system.
  4. The parking assist sensors are covered by snow, mud, dirt or ice.
  5. The vehicle bumper is damaged.
  6. Excessive paint thickness on a replacement parking assist sensor.
  7. The parking assist sensors are disrupted by vibrations, like those caused by a large nearby vehicle or from heavy equipment such as a jackhammer.

More articles — Object Detection System - Park Assist System
