Engine Mechanical - 6.2l, or 7.0l (2 of 8) Chevrolet Corvette C6

Mechanical 14 illustrations ~11853 words

Scheme 1

Scheme 1: Supercharger Belt Replacement
Scheme 1: Supercharger Belt Replacement
CalloutComponent Name
Preliminary Procedure: Remove the air intake duct, if necessary. Refer to Air Cleaner Assembly Replacement (6.2L) or Air Cleaner Assembly Replacement (7.0L) or Air Cleaner Assembly Replacement (LS9) .
1Supercharger Belt Tensioner Procedure Use a 3/8 inch breaker bar to rotate the supercharger belt tensioner. Remove the supercharger belt from the pulleys and tensioner.
2Supercharger Belt Procedure Clean and inspect the supercharger belt surfaces of all the pulleys. Inspect the supercharger belt for correct alignment.

Removal Procedure

  1. Remove the air intake duct, if necessary. Refer to «Air Cleaner Assembly Replacement (6.2L)»(/chevrolet/corvette/c6-2004-2014/remont/testing-diagnostics/#engine-controls-and-fuel-62l-or-70l-introduction) or «Air Cleaner Assembly Replacement (7.0L)»(/chevrolet/corvette/c6-2004-2014/remont/testing-diagnostics/#engine-controls-and-fuel-62l-or-70l-introduction) or «Air Cleaner Assembly Replacement (LS9)»(/chevrolet/corvette/c6-2004-2014/remont/testing-diagnostics/#engine-controls-and-fuel-62l-or-70l-introduction) .
  2. Install the appropriate tool to the drive belt tensioner bolt.
  3. Using the appropriate tool, rotate the drive belt tensioner clockwise to relieve the tension on the accessory drive belt.
  4. Remove the accessory drive belt from the pulleys and tensioner.
  5. Slowly release tension on the drive belt tensioner.
  6. Remove the breaker bar and socket from the drive belt tensioner bolt.
  7. Clean and inspect the drive belt surfaces of all the pulleys.

Installation Procedure

  1. Route the accessory drive belt around all the pulleys except the water pump pulley and tensioner.
  2. Install the appropriate tool to the drive belt tensioner.
  3. Using the appropriate tool, rotate the drive belt tensioner clockwise to relieve tension on the drive belt tensioner.
  4. Install the accessory drive belt under the water pump pulley.
  5. Install the accessory drive belt onto the drive belt tensioner.
  6. Slowly release the tension.
  7. Remove the tool from the drive belt tensioner.
  8. Install the air intake duct, if necessary. Refer to «Air Cleaner Assembly Replacement (6.2L)»(/chevrolet/corvette/c6-2004-2014/remont/testing-diagnostics/#engine-controls-and-fuel-62l-or-70l-introduction) or «Air Cleaner Assembly Replacement (7.0L)»(/chevrolet/corvette/c6-2004-2014/remont/testing-diagnostics/#engine-controls-and-fuel-62l-or-70l-introduction) or «Air Cleaner Assembly Replacement (LS9)»(/chevrolet/corvette/c6-2004-2014/remont/testing-diagnostics/#engine-controls-and-fuel-62l-or-70l-introduction) .
  9. Inspect the accessory drive belt for correct alignment.

Scheme 2

Scheme 2: Drive Belt Replacement - Accessory (LS9)
Scheme 2: Drive Belt Replacement - Accessory (LS9)
CalloutComponent Name
Preliminary Procedure: Remove the air intake duct, if necessary. Refer to Air Cleaner Assembly Replacement (6.2L) or Air Cleaner Assembly Replacement (7.0L) or Air Cleaner Assembly Replacement (LS9) .
1Drive Belt Procedure Use a 3/8 inch breaker bar to rotate the drive belt tensioner. Remove the drive belt from the pulleys and tensioner.
2Drive Belt Procedure Clean and inspect the drive belt surfaces of all the pulleys. Inspect the accessory drive belt for correct alignment.
  1. Remove the accessory drive belt. Refer to «Drive Belt Replacement - Accessory (w/o LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) or «Drive Belt Replacement - Accessory (LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) .
  2. Raise the vehicle. Refer to «Lifting and Jacking the Vehicle»(/chevrolet/corvette/c6-2004-2014/remont/hoistjack/#general-information__lifting-and-jacking-the-vehicle) .
  3. Using the appropriate tool, rotate the air conditioning (A/C) belt tensioner clockwise in order to relieve tension on the belt.
  4. Remove the A/C belt from the pulleys.
  5. Slowly release the tension on the A/C belt tensioner.
  6. Remove the wrench and or socket from the A/C belt tensioner.
  7. Clean and inspect the belt surfaces of all the pulleys.
  1. Install the A/C belt around the crankshaft balancer.
  2. Using the appropriate wrench or socket, rotate the A/C belt tensioner clockwise in order to relieve tension on the belt.
  3. Rotate the A/C belt tensioner clockwise in order to relieve tension on the belt.
  4. Install the A/C belt over the idler pulley.
  5. Install the A/C belt around the A/C compressor pulley.
  6. Slowly release the tension on the A/C belt tensioner.
  7. Remove the appropriate tool from the A/C belt tensioner.
  8. Inspect the A/C belt for proper installation and alignment.
  9. Lower the vehicle.
  10. Install the accessory drive belt. Refer to «Drive Belt Replacement - Accessory (w/o LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) or «Drive Belt Replacement - Accessory (LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) .

Scheme 3

Scheme 3: Drive Belt Idler Pulley Replacement (LS9)
Scheme 3: Drive Belt Idler Pulley Replacement (LS9)
CalloutComponent Name
Preliminary Procedure: Remove the accessory drive belt. Refer to Drive Belt Replacement - Accessory (w/o LS9) or Drive Belt Replacement - Accessory (LS9) .
1Drive Belt Idler Pulley Fastener CAUTION: Refer to Fastener Caution . Tighten: 50 N.m (37 lb ft)
2Drive Belt Idler Pulley Procedure: Transfer components as necessary.
CAUTION
Refer to Fastener Caution .
  1. Remove the accessory drive belt. Refer to «Drive Belt Replacement - Accessory (w/o LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) or «Drive Belt Replacement - Accessory (LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) .
  2. Loosen the drive belt idler pulley mounting bolt.
  3. Remove the drive belt idler pulley.
  1. Position the drive belt idler pulley on generator mounting bracket.
  2. Hand tighten the drive belt idler pulley mounting bolt.
  3. Tighten the drive belt idler pulley bolt. Tighten: Tighten the drive belt idler pulley bolt to 50 N.m (37 lb ft).
  4. Install the accessory drive belt. Refer to «Drive Belt Replacement - Accessory (w/o LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) or «Drive Belt Replacement - Accessory (LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) .
  1. Remove the accessory drive belt. Refer to «Drive Belt Replacement - Accessory (w/o LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) or «Drive Belt Replacement - Accessory (LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) .
  2. Remove the accessory drive belt tensioner bolts.
  3. Remove the accessory drive belt tensioner.
  1. Install the accessory drive belt tensioner.
  2. Install the accessory drive belt tensioner bolts. Tighten: Tighten the accessory drive belt tensioner bolts to 50 N.m (37 lb ft) starting with the lower bolt first.
  3. Install the accessory drive belt. Refer to «Drive Belt Replacement - Accessory (w/o LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) or «Drive Belt Replacement - Accessory (LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) .
  1. Remove the air conditioning (A/C) drive belt. Refer to «Air Conditioning Compressor Belt Replacement (w/o LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) .
  2. Raise and suitably support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/chevrolet/corvette/c6-2004-2014/remont/hoistjack/#general-information__lifting-and-jacking-the-vehicle) .
  3. Loosen the A/C drive belt tensioner bolt.
  4. Remove the A/C drive belt tensioner.
  1. Install the A/C drive belt tensioner.
  2. Tighten the A/C drive belt tensioner bolt. Tighten: Tighten the A/C drive belt tensioner bolt to 50 N.m (37 lb ft).
  3. Lower the vehicle.
  4. Install the A/C drive belt. Refer to «Air Conditioning Compressor Belt Replacement (w/o LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) .

Engine Mount Inspection

CAUTIONBroken or deteriorated mounts can cause misalignment and destruction of certain drive train components. When a single mount breaks, the remaining mounts are subjected to abnormally high stresses.
CAUTIONWhen raising or supporting the engine for any reason, do not use a jack under the oil pan, any sheet metal, or the crankshaft pulley. Due to the small clearance between the oil pan and the oil pump screen, jacking against the oil pan may cause the pan to be bent against the pump screen. This will result in a damaged oil pickup unit.
  1. Measure the engine movement at the engine mount in order to check for damage to the rubber portions of the mount. Apply the park brake. Start the engine. Firmly apply and hold the primary brakes. Have an assistant stand to the side of the vehicle in order to observe for engine movement. Slightly load the engine shifting from drive to reverse a few times. If the engine moves more than 24 mm (0.945 in) from the at rest position, in either direction, check for loose engine mount or engine mount bracket attachments.
  2. If the engine mount and engine mount bracket bolt torque is at specifications, check the condition of the engine mount.
  3. Replace the engine mount if any of the following conditions exist: Heat check cracks cover the rubber cushion surface. The rubber cushion is separated from the metal plate of the mount. There is a split through the rubber cushion.
  1. Remove the front suspension crossmember. Refer to «Front Suspension Crossmember Replacement (With Z06 or ZR1)»(/chevrolet/corvette/c6-2004-2014/remont/frames-subframes-crossmembers/#frame-and-underbody) or «Front Suspension Crossmember Replacement (Without Z06)»(/chevrolet/corvette/c6-2004-2014/remont/frames-subframes-crossmembers/#frame-and-underbody) .
  2. Remove the engine mount-to-engine mount bracket nut.
  3. Remove the engine mount.
  4. Remove the engine mount heat shield from the engine mount, if necessary.
  1. Install the engine mount heat shield to the engine mount, if necessary.
  2. Install the engine mount.
  3. Install the engine mount-to-engine mount bracket nut. Except LS9/ZR1, tighten the nut to 65 N.m (48 lb ft). For LS9/ZR1, tighten the nut to 100 N.m (74 lb ft).
  4. Install the front suspension crossmember. Refer to «Front Suspension Crossmember Replacement (With Z06 or ZR1)»(/chevrolet/corvette/c6-2004-2014/remont/frames-subframes-crossmembers/#frame-and-underbody) or «Front Suspension Crossmember Replacement (Without Z06)»(/chevrolet/corvette/c6-2004-2014/remont/frames-subframes-crossmembers/#frame-and-underbody) .
  1. Remove the left engine mount. Refer to «Engine Mount Replacement - Left Side»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) .
  2. Remove the engine mount bracket bolts.
  3. Remove the engine mount bracket.
  1. Install the engine mount bracket.
  2. Install the engine mount bracket bolts and tighten to 100 N.m (74 lb ft).
  3. Install the left engine mount. Refer to «Engine Mount Replacement - Left Side»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) .
  1. Remove the front suspension crossmember. Refer to «Front Suspension Crossmember Replacement (With Z06 or ZR1)»(/chevrolet/corvette/c6-2004-2014/remont/frames-subframes-crossmembers/#frame-and-underbody) or «Front Suspension Crossmember Replacement (Without Z06)»(/chevrolet/corvette/c6-2004-2014/remont/frames-subframes-crossmembers/#frame-and-underbody) .
  2. Remove the engine mount-to-engine mount bracket nut.
  3. Remove the engine mount (left side shown, right side similar).
  4. Remove the engine mount heat shield from the engine mount, if necessary.
  1. Install the engine mount heat shield to the engine mount, if necessary.
  2. Install the engine mount (left side shown, right side similar).
  3. Install the engine mount-to-engine mount bracket nut. Except LS9/ZR1, tighten the nut to 65 N.m (48 lb ft). For LS9/ZR1, tighten the nut to 100 N.m (74 lb ft).
  4. Install the front suspension crossmember. Refer to «Front Suspension Crossmember Replacement (With Z06 or ZR1)»(/chevrolet/corvette/c6-2004-2014/remont/frames-subframes-crossmembers/#frame-and-underbody) or «Front Suspension Crossmember Replacement (Without Z06)»(/chevrolet/corvette/c6-2004-2014/remont/frames-subframes-crossmembers/#frame-and-underbody) .
  1. Remove the right engine mount. Refer to «Engine Mount Replacement - Right Side»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) .
  2. Remove the engine mount bracket bolts.
  3. Remove the engine mount bracket.
  1. Install the engine mount bracket.
  2. Install the engine mount bracket bolts and tighten to 100 N.m (74 lb ft).
  3. Install the right engine mount. Refer to «Engine Mount Replacement - Right Side»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) .

Scheme 4

Scheme 4: Upper Intake Manifold Sight Shield Replacement (LS9)
Scheme 4: Upper Intake Manifold Sight Shield Replacement (LS9)
CalloutComponent Name
1Upper Intake Manifold Sight Shield Tip: Pull up on the shield to remove.
  1. Remove the oil filler cap (1), if needed.
  2. Remove the right engine sight shield (2), if needed.
  3. Remove the left engine sight shield (3), if needed.
  1. Install the left engine sight shield (3), if needed.
  2. Install the right engine sight shield (2), if needed.
  3. Install the oil filler cap (1), if needed.

Scheme 5

Scheme 5: Engine Oil Temperature Gage Sensor Replacement
Scheme 5: Engine Oil Temperature Gage Sensor Replacement
CalloutComponent Name
Preliminary Procedure Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle . Remove the RF tire and wheel assembly. Refer to Tire and Wheel Removal and Installation . Remove the RH front wheelhouse rear liner. Refer to Front Wheelhouse Liner Replacement (Front Liner) or Front Wheelhouse Liner Replacement (Rear Liner) .
1Oil Temperature Sensor Electrical Connector
2Oil Temperature Sensor CAUTION: Refer to Fastener Caution . Tighten: 20 N.m (15 lb ft)
CAUTION
Refer to Fastener Caution .

Scheme 6

Scheme 6: Oil Tank Replacement (LS9)
Scheme 6: Oil Tank Replacement (LS9)
CalloutComponent Name
Preliminary Procedures Remove the oil tank inlet hose. Refer to Oil Tank Inlet Hose Replacement . Remove the oil tank outlet hose. Refer to Oil Tank Outlet Hose Replacement . Remove the positive crankcase ventilation hose/pipe/tube. Refer to Positive Crankcase Ventilation Hose/Pipe/Tube Replacement (LS3) or Positive Crankcase Ventilation Hose/Pipe/Tube Replacement (LS7) or Positive Crankcase Ventilation Hose/Pipe/Tube Replacement (LS9) . Remove the wiring harness bracket. Refer to Wiring Harness Bracket Replacement (LS9) .
1Oil Tank Fastener (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten: 36 N.m (27 lb ft)
2Oil Tank Procedure Transfer components as necessary. Ensure full oil level after installation.
CAUTION
Refer to Fastener Caution .
  1. Remove the hood stop bracket to oil tank bolt.
  2. Disconnect the positive crankcase ventilation (PCV) fresh air tube from the front port on the oil tank.
  3. Disconnect the PCV dirty air tube from the rear port on the oil tank.
  4. Remove the 2 oil tank middle bracket nuts.
  5. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/chevrolet/corvette/c6-2004-2014/remont/hoistjack/#general-information__lifting-and-jacking-the-vehicle) .
  6. Drain the engine oil. Refer to «Engine Oil and Oil Filter Replacement (6.2L )»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-3-of-8) or «Engine Oil and Oil Filter Replacement (6.2L LS9 and 7.0L LS7)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-3-of-8) .
  7. Remove the right front tire and wheel assembly. Refer to «Tire and Wheel Removal and Installation»(/chevrolet/corvette/c6-2004-2014/remont/wheel-tire-system/#tires-and-wheels) .
  8. Remove the right front wheelhouse rear liner. Refer to «Front Wheelhouse Liner Replacement (Front Liner)»(/chevrolet/corvette/c6-2004-2014/remont/frames-subframes-crossmembers/#frame-and-underbody) or «Front Wheelhouse Liner Replacement (Rear Liner)»(/chevrolet/corvette/c6-2004-2014/remont/frames-subframes-crossmembers/#frame-and-underbody) .
  9. Disconnect the oil temperature sensor electrical connector.
  10. Remove the inlet hose to oil tank bolt (3) and disconnect the hose (2) from the oil tank. Discard the oil seal (1).
  11. Remove the outlet hose to oil tank bolt (3) and disconnect the hose (2) from the oil tank. Discard the oil seal (1).
  12. Remove the oil tank to frame bolts.
  13. Remove the oil tank from the bottom of the vehicle.
  1. Position the oil tank in place from the bottom of the vehicle.
  2. Install the oil tank lower bracket bolts to frame bolts. Tighten: Tighten the oil tank lower bracket to frame bolts to 36 N.m (27 lb ft).
  3. Using g a new oil seal (1) install the oil tank outlet hose (2) and bolt (3) to the oil tank. Tighten: Tighten the outlet hose to oil tank bolt to 22 N.m (16 lb ft).
  4. Using a new oil seal (1) install the oil tank inlet hose (2) and bolt (3) to the oil tank. Tighten: Tighten the inlet hose to oil tank bolt to 22 N.m (16 lb ft).
  5. Connect the oil temperature sensor electrical connector.
  6. Install the right front wheelhouse liner. Refer to «Front Wheelhouse Liner Replacement (Front Liner)»(/chevrolet/corvette/c6-2004-2014/remont/frames-subframes-crossmembers/#frame-and-underbody) or «Front Wheelhouse Liner Replacement (Rear Liner)»(/chevrolet/corvette/c6-2004-2014/remont/frames-subframes-crossmembers/#frame-and-underbody) .
  7. Install the right front tire and wheel assembly. Refer to «Tire and Wheel Removal and Installation»(/chevrolet/corvette/c6-2004-2014/remont/wheel-tire-system/#tires-and-wheels) .
  8. Lower the vehicle.
  9. Install the 2 oil tank middle bracket nuts. Tighten: Tighten the oil tank middle bracket nuts to 10 N.m (89 lb in).
  10. Connect the PCV dirty air tube to the rear port on the oil tank.
  11. Connect the PCV fresh air tube to the front port on the oil tank.
  12. Install the hood stop bracket to oil tank bolt. Tighten: Tighten the hood stop bracket to oil tank bolt to 10 N.m (89 lb in).
  13. Change the engine oil. Refer to «Engine Oil and Oil Filter Replacement (6.2L )»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-3-of-8) or «Engine Oil and Oil Filter Replacement (6.2L LS9 and 7.0L LS7)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-3-of-8) .

Scheme 7

Scheme 7: Wiring Harness Bracket Replacement (LS9)
Scheme 7: Wiring Harness Bracket Replacement (LS9)
CalloutComponent Name
1Wiring Harness Bracket Fastener (Qty: 3) CAUTION: Refer to Fastener Caution . Tighten: 8 N.m (71 lb in)
2Wiring Harness Bracket Procedure Disconnect any electrical connectors. Transfer components as necessary.
CAUTION
Refer to Fastener Caution .
  1. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/chevrolet/corvette/c6-2004-2014/remont/hoistjack/#general-information__lifting-and-jacking-the-vehicle) .
  2. Drain the engine oil. Refer to «Engine Oil and Oil Filter Replacement (6.2L )»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-3-of-8) or «Engine Oil and Oil Filter Replacement (6.2L LS9 and 7.0L LS7)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-3-of-8) .
  3. Remove the right front wheelhouse rear liner. Refer to «Front Wheelhouse Liner Replacement (Front Liner)»(/chevrolet/corvette/c6-2004-2014/remont/frames-subframes-crossmembers/#frame-and-underbody) or «Front Wheelhouse Liner Replacement (Rear Liner)»(/chevrolet/corvette/c6-2004-2014/remont/frames-subframes-crossmembers/#frame-and-underbody) .
  4. Remove the oil inlet/outlet hose bracket bolt.
  5. Remove the inlet hose to oil tank bolt (3) and disconnect the hose (2) from the oil tank. Discard the oil seal (1).
  6. Remove the inlet hose to oil pan bolt (3) and disconnect the hose (2) from the oil pan. Discard the oil seal (1).
  7. Remove the oil inlet hose.
  1. Position the oil inlet hose.
  2. Install the oil inlet/outlet hose bracket bolt. Tighten: Tighten the oil inlet/outlet hose bracket bolt to 22 N.m (16 lb ft).
  3. Using a new oil seal (1) install the oil inlet hose (2) and bolt (3) to the oil pan. Tighten: Tighten the inlet hose to oil pan bolt to 22 N.m (16 lb ft).
  4. Using a new oil seal (1) install the oil inlet hose (2) and bolt (3) to the oil tank. Tighten: Tighten the inlet hose to oil tank bolt to 22 N.m (16 lb ft).
  5. Install the right front wheelhouse rear liner. Refer to «Front Wheelhouse Liner Replacement (Front Liner)»(/chevrolet/corvette/c6-2004-2014/remont/frames-subframes-crossmembers/#frame-and-underbody) or «Front Wheelhouse Liner Replacement (Rear Liner)»(/chevrolet/corvette/c6-2004-2014/remont/frames-subframes-crossmembers/#frame-and-underbody) .
  6. Lower the vehicle.
  7. Change the engine oil. Refer to «Engine Oil and Oil Filter Replacement (6.2L )»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-3-of-8) or «Engine Oil and Oil Filter Replacement (6.2L LS9 and 7.0L LS7)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-3-of-8) .
  1. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/chevrolet/corvette/c6-2004-2014/remont/hoistjack/#general-information__lifting-and-jacking-the-vehicle) .
  2. Drain the engine oil. Refer to «Engine Oil and Oil Filter Replacement (6.2L )»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-3-of-8) or «Engine Oil and Oil Filter Replacement (6.2L LS9 and 7.0L LS7)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-3-of-8) .
  3. Remove the right front wheelhouse rear liner. Refer to «Front Wheelhouse Liner Replacement (Front Liner)»(/chevrolet/corvette/c6-2004-2014/remont/frames-subframes-crossmembers/#frame-and-underbody) or «Front Wheelhouse Liner Replacement (Rear Liner)»(/chevrolet/corvette/c6-2004-2014/remont/frames-subframes-crossmembers/#frame-and-underbody) .
  4. Remove the oil inlet/outlet hose bracket bolt.
  5. Remove the outlet hose to oil tank bolt (3) and disconnect the hose (2) from the oil tank. Discard the oil seal (1).
  6. Remove the outlet hose to oil pan bolt (2) and disconnect the hose (3) from the oil pan. Discard the oil seal (1).
  7. Remove the oil outlet hose.
  1. Position the oil outlet hose.
  2. Install the oil inlet/outlet hose bracket bolt. Tighten: Tighten the oil inlet/outlet hose bracket bolt to 22 N.m (16 lb ft).
  3. Using a new oil seal (1) install the oil outlet hose (3) and bolt (2) to the oil pan. Tighten: Tighten the outlet hose to oil pan bolt to 22 N.m (16 lb ft).
  4. Using a new oil seal (1) install the oil outlet hose (2) and bolt (3) to the oil pan. Tighten: Tighten the outlet hose to oil tank bolt to 22 N.m (16 lb ft).
  5. Install the right front wheelhouse rear liner. Refer to «Front Wheelhouse Liner Replacement (Front Liner)»(/chevrolet/corvette/c6-2004-2014/remont/frames-subframes-crossmembers/#frame-and-underbody) or «Front Wheelhouse Liner Replacement (Rear Liner)»(/chevrolet/corvette/c6-2004-2014/remont/frames-subframes-crossmembers/#frame-and-underbody) .
  6. Lower the vehicle.
  7. Change the engine oil. Refer to «Engine Oil and Oil Filter Replacement (6.2L )»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-3-of-8) or «Engine Oil and Oil Filter Replacement (6.2L LS9 and 7.0L LS7)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-3-of-8) .

Scheme 8

Scheme 8: Positive Crankcase Ventilation Hose/Pipe/Tube Replacement (LS3)
Scheme 8: Positive Crankcase Ventilation Hose/Pipe/Tube Replacement (LS3)
CalloutComponent Name
Preliminary Procedure: Remove the intake manifold sight shields. Refer to Upper Intake Manifold Sight Shield Replacement (LS9) or Upper Intake Manifold Sight Shield Replacement (w/o LS9) .
1Positive Crankcase Ventilation (PCV) Tube

Scheme 9

Scheme 9: Positive Crankcase Ventilation Hose/Pipe/Tube Replacement (LS7)
Scheme 9: Positive Crankcase Ventilation Hose/Pipe/Tube Replacement (LS7)
CalloutComponent Name
Preliminary Procedure: Remove the intake manifold sight shields. Refer to Upper Intake Manifold Sight Shield Replacement (LS9) or Upper Intake Manifold Sight Shield Replacement (w/o LS9) .
1Positive Crankcase Ventilation (PCV) Tube-Air Intake to Oil Tank
2PCV Tube-Rocker Covers to Oil Tank

Scheme 10

Scheme 10: Positive Crankcase Ventilation Hose/Pipe/Tube Replacement (LS9)
Scheme 10: Positive Crankcase Ventilation Hose/Pipe/Tube Replacement (LS9)
CalloutComponent Name
Preliminary Procedure: Remove the upper intake manifold sight shield. Refer to Upper Intake Manifold Sight Shield Replacement (LS9) or Upper Intake Manifold Sight Shield Replacement (w/o LS9) .
1Positive Crankcase Ventilation Hose/Pipe/Tube Procedure Disconnect the electrical connectors, as needed. Transfer components as necessary.

Scheme 11

Scheme 11: Charge Air Cooler Cover Replacement (LS9)
Scheme 11: Charge Air Cooler Cover Replacement (LS9)
CalloutComponent Name
Preliminary Procedures Remove the upper intake manifold sight shield. Refer to Upper Intake Manifold Sight Shield Replacement (LS9) or Upper Intake Manifold Sight Shield Replacement (w/o LS9) . Remove the positive crankcase ventilation hose/pipe/tube. Refer to Positive Crankcase Ventilation Hose/Pipe/Tube Replacement (LS3) or Positive Crankcase Ventilation Hose/Pipe/Tube Replacement (LS7) or Positive Crankcase Ventilation Hose/Pipe/Tube Replacement (LS9) . Remove the charge air cooler coolant hose-pump to cooler Charge Air Cooler Coolant Hose Replacement - Pump to Cooler . Remove the charge air cooler coolant house-cooler to radiator Charge Air Cooler Coolant Hose Replacement - Cooler to Radiator .
1Charge Air Cooler Cover Fastener (Qty: 16) CAUTION: Refer to Component Fastener Tightening Caution . Procedure: To access the rear charge air cooler cover bolt you must loosen the front suspension crossmember fastener 3/4 of the way. Refer to Front Suspension Crossmember Replacement (With Z06 or ZR1) or Front Suspension Crossmember Replacement (Without Z06) . Tighten: 10 N.m (89 lb in)
2Charge Air Cooler Cover Procedure Disconnect any electrical connectors. Transfer components as necessary.

Special Tools

  1. J 37088-A: Fuel Line Disconnect Tool Set
  2. EN 48898: Supercharger Lift Fixture
  3. For equivalent regional tools, refer to «Special Tools (6.2L LS3)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) or «Special Tools (6.2L LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls9) or «Special Tools (7.0L)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-70l)
  1. Open and remove the hood.
  2. Disconnect the negative battery cable.
  3. Raise the vehicle. Refer to «Lifting and Jacking the Vehicle»(/chevrolet/corvette/c6-2004-2014/remont/hoistjack/#general-information__lifting-and-jacking-the-vehicle) .
  4. Drain the engine cooling system.
  5. Drain the intercooler cooling system at the left front of the vehicle.
  6. Lower the vehicle.
  7. Remove the engine sight shield.
  8. Disconnect the mass airflow (MAF) sensor electrical connector located at the air inlet duct.
  9. Disconnect the positive crankcase ventilation (PCV) fresh air tube from the air inlet duct.
  10. Remove the air inlet duct.
  11. Disconnect the throttle actuator electrical connectors from the throttle body.
  12. Remove the supercharger and accessory drive belts.
  13. Disconnect the intercooler cooling system hoses. The two large coolant hoses at the front of the intercooler are retained by quick connects.
  14. Disconnect the generator electrical connector and battery positive cable.
  15. Remove the generator.
  16. Remove the supercharger belt tensioner (1) and bolts.
  17. Disconnect the purge solenoid electrical connector at the left front of the supercharger.
  18. Remove the purge tube from the purge solenoid.
  19. Disconnect the electrical connector from the supercharger actuator solenoid at the left front of the supercharger.
  20. Disconnect the active exhaust vacuum hose from the front of the supercharger assembly. The small exhaust vacuum hose routes from the left side of the engine compartment to the front of the supercharger.
  21. Disconnect the brake booster vacuum hose from the front of the supercharger assembly. The large brake booster vacuum hose routes from the left side of the engine compartment to the front of the supercharger.
  22. Disconnect the coolant temperature sensor electrical connector.
  23. Remove the coolant temperature sensor from the cylinder head.
  24. Disconnect the fuel injector and ignition coil harness connector.
  25. Disconnect the air outlet pressure sensor harness connector from the sensor and separate the harness from the fuel rail bracket and reposition at the left side of the intercooler. Do not remove the sensor from the intercooler.
  26. Disconnect the barometric sensor electrical connector on the right side of the intercooler. Do not remove the sensor from the intercooler.
  27. Disconnect the inlet air temperature sensor electrical connector from the sensor on the right side of the intercooler. Do not remove the sensor from the intercooler.
  28. Disconnect the fuel injector and ignition coil harness connector.
  29. Disconnect the engine wiring harness from the right side of the fuel rail bracket and reposition.
  30. Disconnect and remove the PCV fresh air hose assembly from the right and left valve covers and dry sump oil tank.
  31. Disconnect the ignition coil electrical connectors from the ignition coils.
  32. Remove the rear hood seal from the cowl.
  33. Raise the vehicle and remove the sway bar bushing-to-cradle brackets and bolts, left and right side.
  34. Loosen the cradle bolts and lower the engine assembly and cradle assembly approximately 1 inch.
  35. Lower the vehicle.
  36. Remove the intercooler cover and bolts.
  37. Place the supercharger rotor cover over the exposed areas of the rotors to avoid entry of dirt and debris.
  38. Remove the PCV dirty air hose from the supercharger.
  39. Bleed the fuel system pressure to 0 psi at the service test port.
  40. Disconnect the fuel system to fuel feed-to-rail hose using the J 37088-A: disconnect tool.
  41. Remove the supercharger bolts.
  42. Remove the supercharger assembly.
  43. Drill out the gasket rivets (1) using a drill bit with an outside diameter no larger than 3.2 mm (0.125 in). Remove the gasket (2).
  44. Install the NEW gaskets (1).
  45. Install NEW gasket rivets (2).
  1. Cover the inlet area of the supercharger (1) to prevent dirt or debris contamination onto the rotors.
  2. Install the EN 48898: fixture to the supercharger.
  3. Tighten the EN 48898: fixture bolts and nuts until snug.
  4. Using the lifting device, install the supercharger onto the engine. Align the dowel pin at the right front of the supercharger to the cylinder head.
  5. Apply a 5 mm (0.2 in) band of threadlocker GM P/N 12345382 (Canadian P/N 10953489) or equivalent to the threads of the bolts.
  6. Install the supercharger bolts (1).
  7. Tighten the bolts.
  8. Tighten the bolts a first pass in sequence to 5 N.m (44 lb ft).
  9. Tighten the bolts a final pass in sequence to 10 N.m (89 lb ft).
  10. Install the fuel rail with injectors as required. Refer to «Fuel Rail and Injectors Installation (6.2L LS3)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-7-of-8__fuel-rail-and-injectors-installation-62l) or «Fuel Rail and Injectors Installation (6.2L LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-7-of-8__fuel-rail-and-injectors-installation-62l) or «Fuel Rail and Injectors Installation (7.0L)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-7-of-8__fuel-rail-and-injectors-installation-70l) .
  11. Install the supercharger cover seal (3).
  12. Install the supercharger cover bolts (1) and the supercharger cover (2).
  13. Tighten the bolts.
  14. Tighten the bolts a first pass in sequence to 5 N.m (44 lb ft).
  15. Tighten the bolts a final pass in sequence to 10 N.m (89 lb ft).

Scheme 12

Scheme 12: Charge Air Cooler Replacement
Scheme 12: Charge Air Cooler Replacement
CalloutComponent Name
Preliminary Procedure: Remove the charge air cooler cover. Refer to Charge Air Cooler Cover Replacement (LS9) .
1Charge Air Cooler Fastener (Qty: 4) CAUTION: Refer to Component Fastener Tightening Caution . Tighten: 10 N.m (89 lb in)
2Charge Air Cooler Procedure: Transfer components as necessary.
  1. Remove the engine sight covers (2, 3). Refer to «Upper Intake Manifold Sight Shield Replacement (LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) or «Upper Intake Manifold Sight Shield Replacement (w/o LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) .
  2. Disconnect the electrical connector (1) for the fuel injectors.
  3. Disconnect the electrical connectors (3) from the throttle body.
  4. Disconnect the fuel feed for the fuel injectors.
  5. Remove the vacuum hose from the brake booster.
  6. Disconnect the electrical connector from the manifold absolute pressure (MAP) sensor.
  7. Remove the MAP sensor (714).
  8. Remove the grommet (715) from the sensor, as required.
  9. Remove the evaporative emission (EVAP) clip (740), bolt (742), bracket (741), valve (730), and tubes (729, 735).
  10. Remove the intake manifold bolts (512) and fuel rail stop bracket (712).
  11. Remove the intake manifold (500).
  12. Remove the intake manifold gaskets (514).
  13. Discard the intake manifold gaskets.
  1. Install NEW intake manifold-to-cylinder head gaskets (514).
  2. Install the intake manifold (500).
  3. Apply a 5 mm (0.20 in) band of threadlocker to the threads of the intake manifold bolts (512). Refer to «Adhesives, Fluids, Lubricants, and Sealers (6.2L LS3)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__adhesives-fluids-lubricants-and-sealers-62l) or «Adhesives, Fluids, Lubricants, and Sealers (6.2L LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__adhesives-fluids-lubricants-and-sealers-62l) or «Adhesives, Fluids, Lubricants, and Sealers (7.0L)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__adhesives-fluids-lubricants-and-sealers-70l) for the correct part number.
  4. Install the fuel rail stop bracket (712).
  5. Install the intake manifold bolts (512).
  6. Tighten the intake manifold bolts to the sequence below: Tighten: First Pass: Tighten the intake manifold bolts in sequence to 5 N.m (44 lb in). Final Pass: Tighten the intake manifold bolts in sequence to 10 N.m (89 lb in).
  7. Lubricate the MAP sensor grommet (715) with clean engine oil.
  8. Install the MAP sensor (714) and grommet (715).
  9. Install the EVAP valve (730), bracket (741), and bolt (742). Tighten: Tighten the bolt to 50 N.m (37 lb ft).
  10. Install the EVAP tubes (729, 735).
  11. Install the fuel rail. Refer to «Fuel Rail and Injectors Installation (6.2L LS3)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-7-of-8__fuel-rail-and-injectors-installation-62l) or «Fuel Rail and Injectors Installation (6.2L LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-7-of-8__fuel-rail-and-injectors-installation-62l) or «Fuel Rail and Injectors Installation (7.0L)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-7-of-8__fuel-rail-and-injectors-installation-70l) .
  12. Reconnect the electrical connector for the MAP sensor.
  13. Install the vacuum hose for the brake booster.
  14. Reconnect the electrical connectors (3) throttle body.
  15. Reconnect the electrical connector (1) for the fuel injectors.
  16. Refill the cooling system. Refer to «Cooling System Draining and Filling (Static Fill)»(/chevrolet/corvette/c6-2004-2014/remont/cooling-system-mechanical/#engine-cooling-system) or «Cooling System Draining and Filling (GE 47716)»(/chevrolet/corvette/c6-2004-2014/remont/cooling-system-mechanical/#engine-cooling-system) .
  17. Install the engine sight covers (2, 3). Refer to «Upper Intake Manifold Sight Shield Replacement (LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) or «Upper Intake Manifold Sight Shield Replacement (w/o LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) .
  1. Remove the intake manifold. Refer to «Intake Manifold Replacement»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) .
  2. Remove the oil pressure switch. Refer to «Engine Oil Pressure Sensor and/or Switch Replacement (without ls9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-3-of-8) or «Engine Oil Pressure Sensor and/or Switch Replacement (LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-3-of-8) .
  3. Remove the engine valley retaining bolts (1).
  4. Remove the engine valley cover (2).
  5. Remove the engine valley gasket (3).
  6. Remove the O-rings (4) from the engine valley cover (2).
  1. Install the O-rings (4) to the engine valley cover (2).
  2. Install the engine valley gasket (3).
  3. Install the engine valley cover (2).
  4. Install the retaining bolts (1).
  5. Tighten the engine valley retaining bolts. Tighten: Tighten the engine valley cover bolts to 25 N.m (18 lb ft).
  6. Install the intake manifold. Refer to «Intake Manifold Replacement»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) .
  7. Install the oil pressure switch. Refer to «Engine Oil Pressure Sensor and/or Switch Replacement (without ls9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-3-of-8) or «Engine Oil Pressure Sensor and/or Switch Replacement (LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-3-of-8) .
  1. Remove the left engine sight cover. Refer to «Upper Intake Manifold Sight Shield Replacement (LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) or «Upper Intake Manifold Sight Shield Replacement (w/o LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) .
  2. Disconnect the generator electrical connector (1).
  3. Remove the engine wiring harness generator lead nut (3) and lead.
  4. Remove the ignition coil assembly.
  5. Loosen the valve rocker arm cover bolts.
  6. Remove the valve rocker cover.
  7. Remove the gasket (1) from the rocker cover. Discard the OLD gasket.

Note. All gasket surfaces should be free of oil and other foreign material during assembly. DO NOT reuse the valve rocker arm cover gasket. The valve rocker arm cover bolt grommets may be reused. If the positive crankcase ventilation (PCV) valve grommet has been removed from the rocker arm, install a NEW grommet during assembly.

  1. Install a NEW rocker cover gasket (1) into the valve rocker cover lip.
  2. Install the valve rocker arm cover.
  3. Tighten the valve rocker cover bolts. Tighten: Tighten the valve rocker arm cover bolts to 12 N.m (106 lb in).
  4. Install the ignition coil assembly.
  5. Connect the generator electrical connector (1).
  6. Install the engine wiring harness generator lead and nut (3). Tighten: Tighten the engine wiring harness generator lead nut to 13 N.m (115 lb in).
  7. Install the left engine sight cover. Refer to «Upper Intake Manifold Sight Shield Replacement (LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) or «Upper Intake Manifold Sight Shield Replacement (w/o LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) .

Scheme 13

Scheme 13: Valve Rocker Arm Cover Replacement - Left Side (LSA/LS9)
Scheme 13: Valve Rocker Arm Cover Replacement - Left Side (LSA/LS9)
CalloutComponent Name
Preliminary Procedure Remove the crankcase ventilation hoses/pipes. Refer to Positive Crankcase Ventilation Hose/Pipe/Tube Replacement (LS3) or Positive Crankcase Ventilation Hose/Pipe/Tube Replacement (LS7) or Positive Crankcase Ventilation Hose/Pipe/Tube Replacement (LS9) . Remove the ignition coil. Refer to Ignition Coil Replacement .
1Valve Rocker Arm Cover Fastener (Qty: 4) CAUTION: Refer to Component Fastener Tightening Caution . Tighten: 12 N.m (106 lb in)
2Valve Rocker Arm Cover Procedure Disconnect any electrical connectors. Transfer components as necessary.
  1. Remove the engine sight cover. Refer to «Upper Intake Manifold Sight Shield Replacement (LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) or «Upper Intake Manifold Sight Shield Replacement (w/o LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) .
  2. Remove the crankcase ventilation hoses/pipes. Refer to «Positive Crankcase Ventilation Hose/Pipe/Tube Replacement (LS3)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) or «Positive Crankcase Ventilation Hose/Pipe/Tube Replacement (LS7)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) or «Positive Crankcase Ventilation Hose/Pipe/Tube Replacement (LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) .
  3. Remove the ignition coil assembly.
  4. Loosen the valve rocker arm cover bolts.
  5. Remove the valve rocker arm cover.
  6. Remove the gasket (1) from the rocker cover. Discard the OLD gasket.

Note. All gasket surfaces should be free of oil and other foreign material during assembly. DO NOT reuse the valve rocker arm cover gasket. The valve rocker arm cover bolt grommets may be reused.

  1. Install a NEW gasket (1) into the valve rocker cover lip.
  2. Install the valve rocker arm cover onto the cylinder head.
  3. Tighten the rocker arm cover bolts. Tighten: Tighten the valve rocker arm cover bolts to 12 N.m (106 lb in).
  4. Install the oil fill tube into the rocker arm cover.
  5. Install the ignition coil assembly.
  6. Install the crankcase ventilation hoses/pipes. Refer to «Positive Crankcase Ventilation Hose/Pipe/Tube Replacement (LS3)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) or «Positive Crankcase Ventilation Hose/Pipe/Tube Replacement (LS7)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) or «Positive Crankcase Ventilation Hose/Pipe/Tube Replacement (LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) .
  7. Install the engine sight cover. Refer to «Upper Intake Manifold Sight Shield Replacement (LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) or «Upper Intake Manifold Sight Shield Replacement (w/o LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) .

Scheme 14

Scheme 14: Valve Rocker Arm Cover Replacement - Right Side (LSA/LS9)
Scheme 14: Valve Rocker Arm Cover Replacement - Right Side (LSA/LS9)
CalloutComponent Name
Preliminary Procedure Remove the crankcase ventilation hoses/pipes. Refer to Positive Crankcase Ventilation Hose/Pipe/Tube Replacement (LS3) or Positive Crankcase Ventilation Hose/Pipe/Tube Replacement (LS7) or Positive Crankcase Ventilation Hose/Pipe/Tube Replacement (LS9) . Remove the ignition coil. Refer to Ignition Coil Replacement .
1Valve Rocker Arm Cover Fastener (Qty: 4) CAUTION: Refer to Component Fastener Tightening Caution . Tighten: 12 N.m (106 lb in)
2Valve Rocker Arm Cover Procedure Disconnect any electrical connectors. Transfer components as necessary.
  1. Remove the valve rocker arm covers. Refer to «Valve Rocker Arm Cover Replacement - Left Side (without LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) or «Valve Rocker Arm Cover Replacement - Left Side (LSA/LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) or «Valve Rocker Arm Cover Replacement - Right Side (Without ls9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) or «Valve Rocker Arm Cover Replacement - Right Side (LSA/LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) .
  2. Remove the valve rocker arm bolts.
  3. Remove the valve rocker arms.
  4. Remove the valve rocker arm pivot support.
  5. Remove the pushrods.
  6. Clean and inspect the valve rocker arms and pushrods. Refer to «Valve Rocker Arm and Push Rod Cleaning and Inspection (6.2L LS3)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-5-of-8__valve-rocker-arm-and-push-rod) or «Valve Rocker Arm and Push Rod Cleaning and Inspection (6.2L LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-5-of-8__valve-rocker-arm-and-push-rod) or «Valve Rocker Arm and Push Rod Cleaning and Inspection (7.0L)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-5-of-8__valve-rocker-arm-and-push-rod) .
  1. Lubricate the valve rocker arms and pushrods with clean engine oil.
  2. Lubricate the flange of the valve rocker arm bolts with clean engine oil.
  3. Install the valve rocker arm pivot support.
  4. Install the pushrods.
  5. Install the rocker arms and bolts.
  6. Rotate the crankshaft until number one piston is at top dead center of compression stroke. In this position, cylinder number one rocker arms will be off lobe lift, and the crankshaft sprocket key will be at the 1:30 position. The camshaft and crankshaft sprocket alignment marks will be in the 12 o'clock positions. If viewing from the rear of the engine, the additional crankshaft pilot hole, non-threaded, will be in the 10:30 position. The engine firing order is 1, 8, 7, 2, 6, 5, 4, 3. Cylinders 1, 3, 5 and 7 are left bank. Cylinders 2, 4, 6, and 8 are right bank.
  7. With the engine in the number one firing position, tighten the following valve rocker arm bolts: Tighten: Tighten exhaust valve rocker arm bolts 1, 2, 7, and 8 to 30 N.m (22 lb ft). Tighten intake valve rocker arm bolts 1, 3, 4, and 5 to 30 N.m (22 lb ft).
  8. Rotate the crankshaft 360 degrees.
  9. Tighten the following valve rocker arm bolts: Tighten: Tighten exhaust valve rocker arm bolts 3, 4, 5, and 6 to 30 N.m (22 lb ft). Tighten intake valve rocker arm bolts 2, 6, 7, and 8 to 30 N.m (22 lb ft).
  10. Install the valve rocker arm covers. Refer to «Valve Rocker Arm Cover Replacement - Left Side (without LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) or «Valve Rocker Arm Cover Replacement - Left Side (LSA/LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) or «Valve Rocker Arm Cover Replacement - Right Side (Without ls9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) or «Valve Rocker Arm Cover Replacement - Right Side (LSA/LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) .
  1. J 22794 Spark Plug Port Adapter. See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) .
  2. J 38606 Valve Spring Compressor (Head-on)
  1. Remove the valve rocker arms. Refer to «Valve Rocker Arm and Push Rod Replacement»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) .
  2. Remove the spark plug. Refer to «Spark Plug Replacement»(/chevrolet/corvette/c6-2004-2014/remont/testing-diagnostics/#engine-controls-and-fuel-62l-or-70l-introduction) .
  3. Install the J 22794 into the spark plug hole. See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) .
  4. Attach an air hose to J 22794 . See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) .
  5. Tap the end of the valve stem with a plastic face hammer in order to loosen any varnish on the valve stem keys.
  6. Use the J 38606 in order to compress the valve spring.
  7. Remove the valve stem keys (1).
  8. Carefully release the valve spring tension.
  9. Remove the J 38606 .
  10. Remove the valve spring cap (2).
  11. Remove the valve spring (3).
  12. Remove the valve stem oil seal and shim (4).
  1. Clean the cylinder head valve spring seat and/or shim area.
  2. Install the valve stem oil seal and shim (2).
  3. Install the valve stem oil seal onto the guide. Lubricate the valve guide and valve stem oil seal with clean engine oil. Install the valve stem oil seal onto the valve stem. Push the seal down until the seal contacts the valve guide.
  4. Install the valve spring to the J 38606 .
  5. Compress the valve spring using the J 38606 .
  6. Install the valve spring to the cylinder head.
  7. Install the valve spring cap (2).
  8. Install the valve stem keys (1). Use grease to hold the keys (2) in place and remove J 38606 . Make sure the keys (2) seat properly in the groove of the valve stem. Carefully release the valve spring pressure, making sure the valve keys stay in place. Remove the J 38606 . Tap the end to the valve stem with a plastic faced hammer to seat the keys, if necessary.
  9. Disconnect and remove the air supply from the J 22794 . See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) .
  10. Remove the J 22794 from the spark plug hole. See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) .
  11. Measure the valve spring installed height using a ruler. Measure from the base of the valve spring to the top of the valve spring. If the installed height exceeds 46.25 mm (1.82 in), install a valve spring shim of approximately 0.5 mm (0.02 in) thick. Do not shim the valve spring to obtain less than the specified height. Do not assemble the components without a spring shim on the cylinder head.
  12. Remove the air hose from the J 22794 . See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) .
  13. Install the spark plug. Refer to «Spark Plug Replacement»(/chevrolet/corvette/c6-2004-2014/remont/testing-diagnostics/#engine-controls-and-fuel-62l-or-70l-introduction) .
  14. Install the valve rocker arms. Refer to «Valve Rocker Arm and Push Rod Replacement»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) .
  1. Remove the oil level indicator.
  2. Remove the oil level indicator tube bolt.
  3. Remove the oil level indicator tube.
  4. Remove the O-ring from the oil level indicator tube, if required.
  1. Lubricate the O-ring seal with clean engine oil.
  2. Install the oil level indicator tube into position.
  3. Raise and suitably support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/chevrolet/corvette/c6-2004-2014/remont/hoistjack/#general-information__lifting-and-jacking-the-vehicle) .
  4. Insert the oil level indicator tube into the engine block until the collar is flush with the block.
  5. Lower the vehicle. CAUTION: Refer to «Fastener Caution»(/chevrolet/corvette/c6-2004-2014/remont/oem-general-information/#dangers-warnings-and-cautions__fastener-caution) .
  6. Install the oil level indicator tube bolt. Tighten: Tighten the oil level indicator tube bolt to 25 N.m (18 lb ft).
  7. Install the oil level indicator.
  8. Check the oil level and add if necessary.
  1. J 45059 Angle Meter. See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) .
  2. J 42385-100 Head/Main Bolt Thread Repair Kit. See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) .
  1. Remove the valve rocker arms and pushrods. Refer to «Valve Rocker Arm and Push Rod Replacement»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) .
  2. Remove the engine coolant air bleed pipe and covers. Refer to «Engine Coolant Air Bleed Pipe Replacement»(/chevrolet/corvette/c6-2004-2014/remont/cooling-system-mechanical/#engine-cooling-system) .
  3. Remove the generator bracket. Refer to «Generator Bracket Replacement»(/chevrolet/corvette/c6-2004-2014/remont/charging-system/#battery-charging-system-starting-system) .
  4. Remove the exhaust manifold. Refer to «Exhaust Manifold Replacement - Left Side (With LS7 or LS9)»(/chevrolet/corvette/c6-2004-2014/remont/exhaust/#engine-exhaust-system) or «Exhaust Manifold Replacement - Left Side (LS3)»(/chevrolet/corvette/c6-2004-2014/remont/exhaust/#engine-exhaust-system) .
  5. Remove the intake manifold. Refer to «Intake Manifold Replacement»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) .
  6. Remove the engine wiring harness ground bolt from the rear of the left cylinder head.
  7. Reposition the engine wire harness ground strap away from the cylinder head.
  8. Remove the cylinder head bolts.
  9. Remove the cylinder head.
  10. Remove the cylinder head gasket (217).
  11. Discard the gasket.
  12. Discard all M8 and M11 cylinder head bolts.
  13. Clean and inspect the cylinder head. Refer to «Cylinder Head Cleaning and Inspection (6.2L LS3)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-5-of-8) or «Cylinder Head Cleaning and Inspection (6.2L LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-5-of-8) or «Cylinder Head Cleaning and Inspection (7.0L)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-5-of-8) .
  1. Clean the engine block cylinder head bolt holes, if required. Thread repair tool J 42385-107 may be used to clean the threads of old threadlocking material.
  2. Spray cleaner into the hole. Refer to «Adhesives, Fluids, Lubricants, and Sealers (6.2L LS3)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__adhesives-fluids-lubricants-and-sealers-62l) or «Adhesives, Fluids, Lubricants, and Sealers (6.2L LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__adhesives-fluids-lubricants-and-sealers-62l) or «Adhesives, Fluids, Lubricants, and Sealers (7.0L)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__adhesives-fluids-lubricants-and-sealers-70l) for the correct part number.
  3. Clean the cylinder head bolt holes with compressed air.
  4. Install the cylinder head locating pins (230).
  5. Inspect the locating pins for proper installation.
  6. Inspect the displacement markings on the gasket for proper usage.
  7. Install the NEW cylinder head gasket (217) onto the locating pins.
  8. Install the cylinder head (218) onto the locating pins and the gasket.
  9. Install the NEW cylinder head bolts (200, 221).
  10. Tighten the cylinder head bolts. Tighten the M11 cylinder head bolts (1-10) a first pass in sequence to 30 N.m (22 lb ft). Tighten the M11 cylinder head bolts (1-10) a second pass in sequence to 90 degrees using the J 45059 . See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) . Tighten the M11 cylinder head bolts (1-10) a final pass in sequence to 70 degrees using the J 45059 . See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) . Tighten the M8 cylinder head bolts (11-15) to 30 N.m (22 lb ft). Begin with the center bolt (11) and alternating side-to-side, work outward tightening all of the bolts.
  11. Install the intake manifold. Refer to «Intake Manifold Replacement»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) .
  12. Position the engine wire harness ground strap against the cylinder head.
  13. Install the engine wiring harness ground bolt to the rear of the left cylinder head. Tighten the bolt to 32 N.m (24 lb ft).
  14. Install the exhaust manifold. Refer to «Exhaust Manifold Replacement - Left Side (With LS7 or LS9)»(/chevrolet/corvette/c6-2004-2014/remont/exhaust/#engine-exhaust-system) or «Exhaust Manifold Replacement - Left Side (LS3)»(/chevrolet/corvette/c6-2004-2014/remont/exhaust/#engine-exhaust-system) .
  15. Install the generator bracket. Refer to «Generator Bracket Replacement»(/chevrolet/corvette/c6-2004-2014/remont/charging-system/#battery-charging-system-starting-system) .
  16. Install the engine coolant air bleed pipe. Refer to «Engine Coolant Air Bleed Pipe Replacement»(/chevrolet/corvette/c6-2004-2014/remont/cooling-system-mechanical/#engine-cooling-system) .
  17. Install the valve rocker arms and pushrods. Refer to «Valve Rocker Arm and Push Rod Replacement»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) .
  1. J-37088-A: Fuel Line Disconnect Tool Set
  2. J-45059: Angle Meter For equivalent regional tools, refer to «Special Tools (6.2L LS3)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) or «Special Tools (6.2L LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls9) or «Special Tools (7.0L)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-70l)
  1. Open the hood and remove.
  2. Disconnect the battery negative cable. Refer to «Battery Negative Cable Disconnection and Connection (LS7 or LS9)»(/chevrolet/corvette/c6-2004-2014/remont/charging-system/#battery-charging-system-starting-system) or «Battery Negative Cable Disconnection and Connection (LS3)»(/chevrolet/corvette/c6-2004-2014/remont/charging-system/#battery-charging-system-starting-system) .
  3. Raise the vehicle and drain the engine cooling system.
  4. Drain the intercooler cooling system, at left front of the vehicle.
  5. Lower the vehicle.
  6. Remove the sight shield.
  7. Disconnect the mass air flow (MAF) sensor electrical connector, at the air inlet duct.
  8. Disconnect the positive crankcase ventilation (PCV) fresh air tube from the air inlet duct.
  9. Remove the air inlet duct.
  10. Disconnect the throttle actuator electrical connectors from the throttle body. Do not remove the throttle body.
  11. Remove the supercharger and accessory drive belts.
  12. Disconnect the intercooler cooling system hoses, two large coolant hoses at the front of the intercooler retained by quick connects.
  13. Disconnect the generator electrical connector and battery positive cable.
  14. Remove the generator.
  15. Disconnect the purge solenoid electrical connector, at left front of the supercharger.
  16. Remove the purge tube from the purge solenoid.
  17. Disconnect the electrical connector from the supercharger actuator solenoid, at left front of the supercharger. Do not remove the solenoid.
  18. Disconnect the active exhaust vacuum hose from the front of the supercharger assembly, the small hose that routes from the left side of the engine compartment to the front of the supercharger.
  19. Disconnect the brake booster vacuum hose from the front of the supercharger assembly, the large hose that routes from the left side of the engine compartment to the front of the supercharger.
  20. Disconnect the coolant temperature sensor electrical connector.
  21. Remove the coolant temperature sensor from the cylinder head.
  22. Disconnect the fuel injector and ignition coil harness connector.
  23. Disconnect the air outlet pressure sensor harness connector from the sensor and separate the harness from the fuel rail bracket and reposition, left side of intercooler. Do not remove the sensor from the intercooler.
  24. Disconnect the barometric sensor electrical connector, right side of intercooler. Do not remove the sensor from the intercooler.
  25. Disconnect the inlet air temperature sensor electrical connector from the sensor, right side of intercooler. Do not remove the sensor from the intercooler.
  26. Disconnect the fuel injector and ignition coil harness connector, multi-pin connector at the right rear of the engine.
  27. Disconnect the engine wiring harness from the fuel rail bracket, right side, and reposition.
  28. Disconnect and remove the PCV fresh air hose assembly from the right and left valve covers and dry sump oil tank.
  29. Disconnect the ignition coil electrical connectors from the ignition coil.
  30. Remove the rear hood seal from the cowl.
  31. Raise the vehicle and remove sway bar bushing-to-cradle brackets and bolts, left and right sides.
  32. Loosen the engine cradle bolts and lower the engine assembly and cradle assembly approximately 1 inch.
  33. Lower the vehicle.
  34. Remove the intercooler cover and bolts.
  35. Place the supercharger rotor cover over the exposed areas of the rotors to avoid entry of dirt or debris.
  36. Remove the PCV dirty air hose from the supercharger.
  37. Bleed the fuel system to 0 psi at service test port.
  38. Disconnect the fuel system to fuel feed-to-rail hose using the J-37088-A: disconnect tool.
  39. Remove the supercharger bolts.
  40. Remove the supercharger assembly.
  41. Remove the power steering pump bracket bolts, reposition the pump and bracket assembly forward away from the cylinder head. Remove the pump and bracket as an assembly. Do not separate the pump from the pulley and bracket assembly.
  42. Disconnect the spark plug wires from the spark plugs.
  43. Remove the rear ignition coil from the rocker cover.
  44. Remove the rocker cover.
  45. Loosen the valve rocker arm bolts and lift the rocker arms, pedestal, and bolts assembly from the left cylinder head. Discard the rocker arms and bolts, retain the pedestal.
  46. Remove and discard the pushrods.
  47. Remove the spark plugs.
  48. Raise the vehicle.
  49. Remove the exhaust manifold to cylinder head bolts. Reposition the exhaust manifold away from the cylinder head. Discard the bolts.
  50. Remove and discard the exhaust manifold to cylinder head gasket.
  51. Remove and discard the cylinder head bolts. DO NOT use an impact to remove the head bolts.
  52. Remove and discard the cylinder head gasket.
  1. Clean the engine block cylinder head bolt holes, if required.
  2. Spray cleaner GM P/N 12346139 (Canadian P/N 10953463), GM P/N 12377981 (Canadian P/N 10953463), or equivalent, into the hole.
  3. Clean the cylinder head bolt holes with compressed air.
  4. Install the cylinder head locating pins (230).
  5. Inspect the locating pins for proper installation.
  6. Inspect the displacement markings on the gasket for proper usage.
  7. Install the NEW cylinder head gasket (217) onto the locating pins. Install the gasket with the "FRONT" markings at front of engine.
  8. Install the cylinder head (218) onto the locating pins and the gasket.
  9. Lubricate the threads of the bolts with clean engine oil.
  10. Install the NEW cylinder head bolts (220, 221).
  11. Tighten the cylinder head bolts. Tighten the M12 cylinder head bolts (1-10) a first pass in sequence to 20 N.m (15 lb ft). Tighten the M12 cylinder head bolts (1-10) a second pass in sequence to 80 N.m (60 lb ft). Tighten the M12 cylinder head bolts (1-10) a third pass in sequence to 90 degrees using the J-45059: meter. Tighten the M12 cylinder head bolts (1-10) a final pass in sequence to 45 degrees using the J-45059: meter. Tighten the M8 cylinder head bolts (11-15) to 30 N.m (22 lb ft). Begin with the center bolt (11) and alternating side-to-side, work outward tightening all of the bolts.
  1. J 45059 Angle Meter. See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) .
  2. J 42385-100 Head/Main Bolt Thread Repair Kit. See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) .
  1. Remove the valve rocker arms and pushrods. Refer to «Valve Rocker Arm and Push Rod Replacement»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) .
  2. Remove the engine coolant air bleed pipe and covers. Refer to «Engine Coolant Air Bleed Pipe Replacement»(/chevrolet/corvette/c6-2004-2014/remont/cooling-system-mechanical/#engine-cooling-system) .
  3. Remove the exhaust manifold. Refer to «Exhaust Manifold Replacement - Right Side (LS7 or LS9)»(/chevrolet/corvette/c6-2004-2014/remont/exhaust/#engine-exhaust-system) or «Exhaust Manifold Replacement - Right Side (LS3)»(/chevrolet/corvette/c6-2004-2014/remont/exhaust/#engine-exhaust-system) .
  4. Remove the oil level indicator tube bolt.
  5. Reposition the oil level indicator tube, if necessary.
  6. Remove the intake manifold. Refer to «Intake Manifold Replacement»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) .
  7. Remove the wiring harness from the clip at the rear of the cylinder head.
  8. Remove the cylinder head bolts.
  9. Remove the cylinder head.
  10. Remove the cylinder head gasket (217).
  11. Discard the gasket.
  12. Discard the cylinder head bolts.
  13. Clean and inspect the cylinder head. Refer to «Cylinder Head Cleaning and Inspection (6.2L LS3)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-5-of-8) or «Cylinder Head Cleaning and Inspection (6.2L LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-5-of-8) or «Cylinder Head Cleaning and Inspection (7.0L)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-5-of-8) .
WARNINGWear safety glasses in order to avoid eye damage.
CAUTIONClean all dirt, debris, and coolant from the engine block cylinder head bolt holes. Failure to remove all foreign material may result in damaged threads, improperly tightened fasteners or damage to components.
  1. Clean the engine block cylinder head bolt holes, if required. Thread repair tool J 42385-107 may be used to clean the threads of old threadlocking material.
  2. Spray cleaner into the hole. Refer to «Adhesives, Fluids, Lubricants, and Sealers (6.2L LS3)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__adhesives-fluids-lubricants-and-sealers-62l) or «Adhesives, Fluids, Lubricants, and Sealers (6.2L LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__adhesives-fluids-lubricants-and-sealers-62l) or «Adhesives, Fluids, Lubricants, and Sealers (7.0L)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__adhesives-fluids-lubricants-and-sealers-70l) for the correct part number.
  3. Clean the cylinder head bolt holes with compressed air.
  4. Install the cylinder head locating pins (230).
  5. Inspect the locating pins for proper installation.
  6. Inspect the displacement markings on the gasket for proper usage.
  7. Install the NEW cylinder head gasket (217) onto the locating pins.
  8. Install the cylinder head (218) onto the locating pins and the gasket.
  9. Install the NEW cylinder head bolts (220, 221).
  10. Tighten the cylinder head bolts. Tighten the M11 cylinder head bolts (1-10) a first pass in sequence to 30 N.m (22 lb ft). Tighten the M11 cylinder head bolts (1-10) a second pass in sequence to 90 degrees using the J 45059 . See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) . Tighten the M11 cylinder head bolts (1-10) a final pass in sequence to 70 degrees using the J 45059 . See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) . Tighten the M8 cylinder head bolts (11-15) to 30 N.m (22 lb ft). Begin with the center bolt (11) and alternating side-to-side, work outward tightening all of the bolts.
  11. Install the wiring harness to the clip at the rear of the cylinder head.
  12. Install the intake manifold. Refer to «Intake Manifold Replacement»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) .
  13. Position the oil level indicator tube into place.
  14. Install the oil level indicator tube bolt and tighten to 25 N.m (18 lb ft).
  15. Install the exhaust manifold. Refer to «Exhaust Manifold Replacement - Right Side (LS7 or LS9)»(/chevrolet/corvette/c6-2004-2014/remont/exhaust/#engine-exhaust-system) or «Exhaust Manifold Replacement - Right Side (LS3)»(/chevrolet/corvette/c6-2004-2014/remont/exhaust/#engine-exhaust-system) .
  16. Install the engine coolant air bleed pipe. Refer to «Engine Coolant Air Bleed Pipe Replacement»(/chevrolet/corvette/c6-2004-2014/remont/cooling-system-mechanical/#engine-cooling-system) .
  17. Install the valve rocker arms and pushrods. Refer to «Valve Rocker Arm and Push Rod Replacement»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) .
  1. J 37088-A Fuel Line Disconnect Tool Set
  2. J 45059 Angle Meter. See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) .
  3. For equivalent regional tools, refer to «Special Tools (6.2L LS3)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) or «Special Tools (6.2L LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls9) or «Special Tools (7.0L)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-70l)
  1. Open and remove the hood.
  2. Disconnect the negative battery cable.
  3. Raise the vehicle. Refer to «Lifting and Jacking the Vehicle»(/chevrolet/corvette/c6-2004-2014/remont/hoistjack/#general-information__lifting-and-jacking-the-vehicle) .
  4. Drain the engine cooling system at the right front of the vehicle.
  5. Drain the intercooler cooling system at the left front of the vehicle.
  6. Lower the vehicle.
  7. Remove the engine sight shield.
  8. Disconnect the mass airflow (MAF) sensor electrical connector located at the air inlet duct.
  9. Disconnect the positive crankcase ventilation (PCV) fresh air tube from the air inlet duct.
  10. Remove the air inlet duct.
  11. Disconnect the throttle actuator electrical connectors from the throttle body.
  12. Remove the supercharger and accessory drive belts.
  13. Disconnect the intercooler cooling system hoses. The two large coolant hoses at the front of the intercooler are retained by quick connects.
  14. Disconnect the generator electrical connector and battery positive cable.
  15. Remove the generator.
  16. Remove the supercharger belt tensioner (1) and bolts.
  17. Disconnect the purge solenoid electrical connector at the left front of the supercharger.
  18. Remove the purge tube from the purge solenoid.
  19. Disconnect the electrical connector from the supercharger actuator solenoid.
  20. Disconnect the active exhaust vacuum hose from the front of the supercharger assembly.
  21. Disconnect the fuel injector and ignition coil harness connector.
  22. Disconnect the air outlet pressure sensor harness connector from the sensor and separate the harness from the fuel rail bracket and reposition at the left side of the intercooler. Do not remove the sensor from the intercooler.
  23. Disconnect the inlet air temperature sensor electrical connector from the sensor at the right side of the intercooler. Do not remove the sensor from the intercooler.
  24. Disconnect the fuel injector and ignition coil harness connector.
  25. Disconnect and remove the PCV fresh air hose assembly from the right and left valve covers and dry sump oil tank.
  26. Disconnect the ignition coil electrical connectors from the ignition coils.
  27. Remove the rear hood seal from the cowl.
  28. Raise the vehicle and remove the sway bar bushing-to-cradle brackets and bolts, left and right side.
  29. Loosen the cradle bolts and lower the engine assembly and cradle assembly approximately 1 inch.
  30. Lower the vehicle.
  31. Remove the intercooler cover and bolts.
  32. Place the supercharger rotor cover over the exposed areas of the rotors to avoid entry of dirt and debris.
  33. Remove the PCV dirty air hose from the supercharger.
  34. Disconnect the fuel system to fuel feed-to-rail hose using the J 37088-A disconnect tool.
  35. Remove the supercharger bolts.
  36. Remove the supercharger assembly.
  37. Disconnect the spark plug wires from the spark plugs.
  38. Remove the rear ignition coil from the rocker cover.
  39. Remove the rocker cover.
  40. Loosen the valve rocker arm bolts and lift the rocker arms, pedestal and bolt assembly from the right cylinder head. Discard the rocker arms and bolts and retain the pedestal.
  41. Remove and discard the pushrods.
  42. Remove the spark plugs.
  43. Raise the vehicle.
  44. Loosen the exhaust takedown pipe-to intermediate pipe joints to allow the exhaust manifold to move away from the cylinder heads.
  45. Lower the vehicle.
  46. Remove the exhaust manifold-to-cylinder head bolts. Reposition the exhaust manifold away from the right cylinder head. Discard the bolts.
  47. Remove and discard the exhaust manifold-to-cylinder head gasket.
  48. Remove the engine wire harness retaining bolt.
  49. Remove the coolant air bleed pipes and bolts and reposition the coolant tubes toward the front of engine.
  50. Remove the coolant plug from the right cylinder head.
  51. Lift the cylinder head assembly with the generator bracket from the right side of the engine and remove the generator bracket.
  52. Remove and discard the cylinder head gasket.
  1. Clean the engine block cylinder head bolt holes, if required.
  2. Spray cleaner GM P/N 12346139 (Canadian P/N 10953463), GM P/N 12377981 (Canadian P/N 10953463), or equivalent, into the hole.
  3. Clean the cylinder head bolt holes with compressed air.
  4. Install the cylinder head locating pins (230).
  5. Inspect the locating pins for proper installation.
  6. Inspect the displacement markings on the gasket for proper usage.
  7. Install the NEW cylinder head gasket (217) onto the locating pins. Install the gasket with the "FRONT" markings at front of engine.
  8. Install the cylinder head (218) onto the locating pins and the gasket.
  9. Lubricate the threads of the bolts with clean engine oil.
  10. Install the NEW cylinder head bolts (220, 221).
  11. Tighten the cylinder head bolts: Tighten the M12 cylinder head bolts (1-10) a first pass in sequence to 20 N.m (15 lb ft). Tighten the M12 cylinder head bolts (1-10) a second pass in sequence to 80 N.m (60 lb ft). Tighten the M12 cylinder head bolts (1-10) a third pass in sequence to 90 degrees using the J 45059: meter. Tighten the M12 cylinder head bolts (1-10) a final pass in sequence to 45 degrees using the J 45059: meter. Tighten the M8 cylinder head bolts (11-15) to 30 N.m (22 lb ft). Begin with the center bolt (11) and alternating side-to-side, work outward tightening all of the bolts.

J 3049-A Valve Lifter Remover. See Special Tools .

  1. Remove the cylinder head. Refer to «Cylinder Head Replacement - Left Side (6.2L, LS3, 7.0L, LS7)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) or «Cylinder Head Replacement - Left Side (LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) or «Cylinder Head Replacement - Right Side (6.2L, LS3, 7.0L, LS7)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) or «Cylinder Head Replacement - Right Side (LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) .
  2. Remove the guide bolts (211).
  3. Remove the guides (210) with lifters. Note the installed position of the guides. The notched area of the guide is to align with the locating tab on the block.
  4. Remove the valve lifters (209) from the guide (210).
  5. Organize or mark the components so they can be installed in the same location from which they were removed. Refer to «Separating Parts»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__separating-parts) .
  1. Lubricate the valve lifters (209) and engine block valve lifter bores with clean engine oil.
  2. Insert the valve lifters into the lifter guides (210). Align the flat area on the top of the lifter with the flat area in the lifter guide bore. Push the lifter completely into the guide bore.
  3. Install the valve lifters and guide assembly (210) to the engine block.
  4. Install the valve lifter guide bolts (211). Tighten: Tighten the valve lifter guide bolts to 10 N.m (89 lb in).
  5. Install the cylinder head. Refer to «Cylinder Head Replacement - Left Side (6.2L, LS3, 7.0L, LS7)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) or «Cylinder Head Replacement - Left Side (LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) or «Cylinder Head Replacement - Right Side (6.2L, LS3, 7.0L, LS7)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) or «Cylinder Head Replacement - Right Side (LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) .
  1. J 41816 Crankshaft Balancer Remover
  2. J 41816-2 Crankshaft End Protector. See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) .
  3. J 42386-A Flywheel Holding Tool. See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) .
  4. J 41665 Crankshaft Balancer and Sprocket Installer. See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) .
  1. Remove the air conditioning (A/C) drive belt. Refer to «Air Conditioning Compressor Belt Replacement (w/o LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) .
  2. Remove the power steering gear. Refer to «Steering Gear Replacement»(/chevrolet/corvette/c6-2004-2014/remont/manual-power-steering/#power-steering-system) .
  3. Remove the starter motor. Refer to «Starter Replacement»(/chevrolet/corvette/c6-2004-2014/remont/charging-system/#battery-charging-system-starting-system) .
  4. Remove the right transmission cover and bolt.
  5. Install the J 42386-A and bolts. See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) . Use one M10 - 1.5 x 120 mm and one M10 - 1.5 x 45 mm bolt for proper tool operation. Tighten: Tighten the J 42386-A bolts to 50 N.m (37 lb ft).
  6. Remove the crankshaft balancer bolt (139). Do not discard the crankshaft balancer bolt. The balancer bolt will be used during the balancer installation procedure.
  7. Mark or scribe the crankshaft balancer and the end of the crankshaft.
  8. Use the J 41816 (1) and the J 41816-2 (2) in order to remove the crankshaft balancer. See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) .
  9. Remove the crankshaft balancer (138).
  10. Note the position of the crankshaft balance weights, if applicable. Refer to «Engine Balancing»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__engine-balancing) and «Crankshaft Balancer Cleaning and Inspection»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-4-of-8__crankshaft-balancer-cleaning-and-inspection) .
  1. Install the J 42386-A and bolts. See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) . Use one M10 - 1.5 x 120 mm and one M10 - 1.5 x 45 mm bolt for proper tool operation. Tighten: Tighten the J 42386-A bolts to 50 N.m (37 lb ft).
  2. Using the old balancer as a reference, mark or scribe the new balancer in the same location, if applicable.
  3. Install balance weights into the new balancer, if applicable. Refer to «Engine Balancing»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__engine-balancing) and «Crankshaft Balancer Cleaning and Inspection»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-4-of-8__crankshaft-balancer-cleaning-and-inspection) .
  4. Position the balancer (138) onto the end of the crankshaft.
  5. Use the J 41665 in order to install the balancer. See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) . Assemble the threaded rod, nut, washer and installer. Insert the smaller end of the installer into the front of the balancer. Use a wrench and hold the hex end of the threaded rod. Use a second wrench and rotate the installation tool nut clockwise until the balancer is started onto the crankshaft. Remove the tool and reverse the installation tool. Position the larger end of the installer against the front of the balancer. Use a wrench and hold the hex end of the threaded rod. Use a second wrench and rotate the installation tool nut clockwise until the balancer is installed onto the crankshaft. Remove the balancer installation tool.
  6. Install the used crankshaft balancer bolt (139). Tighten: Tighten the crankshaft balancer bolt to 330 N.m (240 lb ft).
  7. Remove the used crankshaft balancer bolt.
  8. Measure for a correctly installed balancer. If the balancer is not installed to the proper dimensions, install the J 41665 and repeat the installation procedure. See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) .
  9. Install the NEW crankshaft balancer bolt (139). Tighten: Tighten the crankshaft balancer bolt a first pass to 50 N.m (37 lb ft). Tighten the crankshaft balancer bolt a second pass to 140 degrees using the J 45059 . See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) .
  10. Remove the J 42386-A . See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) .
  11. Install the starter motor. Refer to «Starter Replacement»(/chevrolet/corvette/c6-2004-2014/remont/charging-system/#battery-charging-system-starting-system) .
  12. Install the power steering gear. Refer to «Steering Gear Replacement»(/chevrolet/corvette/c6-2004-2014/remont/manual-power-steering/#power-steering-system) .
  13. Install the A/C drive belt. Refer to «Air Conditioning Compressor Belt Replacement (w/o LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) .
  14. Perform the crankshaft position (CKP) system variation learn procedure. Refer to «Crankshaft Position System Variation Learn»(/chevrolet/corvette/c6-2004-2014/remont/testing-diagnostics/#engine-controls-and-fuel-62l-or-70l-introduction__crankshaft-position-system-variation-learn) .
  1. EN-47812 Installer Bolt. See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) .
  2. J 41665 Crankshaft Balancer and Sprocket Installer. See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) .
  3. J 41816 Crankshaft Balancer Remover
  4. J 41816-2 Crankshaft End Protector. See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) .
  5. J 42386-A Flywheel Holding Tool. See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) .
  1. Remove the air conditioning (A/C) drive belt. Refer to «Air Conditioning Compressor Belt Replacement (w/o LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) .
  2. Remove the power steering gear. Refer to «Steering Gear Replacement»(/chevrolet/corvette/c6-2004-2014/remont/manual-power-steering/#power-steering-system) .
  3. Remove the starter motor. Refer to «Starter Replacement»(/chevrolet/corvette/c6-2004-2014/remont/charging-system/#battery-charging-system-starting-system) .
  4. Remove the right transmission cover and bolt.
  5. Install the J 42386-A and bolts. See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) . Use one M10 - 1.5 x 120 mm and one M10 - 1.5 x 45 mm bolt for proper tool operation. Tighten: Tighten the J 42386-A bolts to 50 N.m (37 lb ft).
  6. Remove the crankshaft balancer bolt (139). Do not discard the crankshaft balancer bolt. The balancer bolt will be used during the balancer installation procedure.
  7. Mark or scribe the crankshaft balancer and the end of the crankshaft.
  8. Use the J 41816 (1) and the J 41816-2 (2) in order to remove the crankshaft balancer. See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) .
  9. Remove the crankshaft balancer (138).
  10. Remove the crankshaft balancer washer.
  11. Note the position of the crankshaft balance weights, if applicable. Refer to «Engine Balancing»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__engine-balancing) and «Crankshaft Balancer Cleaning and Inspection»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-4-of-8__crankshaft-balancer-cleaning-and-inspection) .
  1. Install the J 42386-A and bolts. See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) . Use one M10 - 1.5 x 120 mm and one M10 - 1.5 x 45 mm bolt for proper tool operation. Tighten: Tighten the J 42386-A bolts to 50 N.m (37 lb ft).
  2. Using the old balancer as a reference, mark or scribe the new balancer in the same location, if applicable.
  3. Install balance weights into the new balancer, if applicable. Refer to «Engine Balancing»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__engine-balancing) and «Crankshaft Balancer Cleaning and Inspection»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-4-of-8__crankshaft-balancer-cleaning-and-inspection) .
  4. Install the crankshaft balancer washer (1) onto the crankshaft balancer.
  5. Position the balancer (138) onto the end of the crankshaft.
  6. Use the J 41665 (2) and the EN-47812 (1) in order to install the balancer. See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) . Assemble the EN-47812 (1), nut, washer and the J 41665 (2). See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) . Insert the smaller end of the J 41665 (2) into the front of the balancer. See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) . Use a wrench and hold the hex end of the EN-47812 (1). See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) . Use a second wrench and rotate the installation tool nut clockwise until the balancer is started onto the crankshaft. Remove the J 41665 (2) and reverse the installation tool. See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) . Position the larger end of the J 41665 (2) against the front of the balancer. See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) . Use a wrench and hold the end of the EN-47812 (1). See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) . Use a second wrench and rotate the installation tool nut clockwise until the balancer is installed onto the crankshaft. Remove the balancer installation tool.
  7. Install the used crankshaft balancer bolt (139). Tighten: Tighten the crankshaft balancer bolt to 330 N.m (240 lb ft).
  8. Remove the used crankshaft balancer bolt.
  9. Measure for a correctly installed balancer. If the balancer is not installed to the proper dimensions, install the EN-47812 and the J 41665 and repeat the installation procedure. See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) .
  10. Install the NEW crankshaft balancer bolt (139). Tighten: Tighten the crankshaft balancer bolt a first pass to 50 N.m (37 lb ft). Tighten the crankshaft balancer bolt a second pass to 230 degrees using the J 45059 . See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) .
  11. Remove the J 42386-A . See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) .
  12. Install the starter motor. Refer to «Starter Replacement»(/chevrolet/corvette/c6-2004-2014/remont/charging-system/#battery-charging-system-starting-system) .
  13. Install the power steering gear. Refer to «Steering Gear Replacement»(/chevrolet/corvette/c6-2004-2014/remont/manual-power-steering/#power-steering-system) .
  14. Install the A/C drive belt. Refer to «Air Conditioning Compressor Belt Replacement (w/o LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) .
  15. Perform the crankshaft position (CKP) system variation learn procedure. Refer to «Crankshaft Position System Variation Learn»(/chevrolet/corvette/c6-2004-2014/remont/testing-diagnostics/#engine-controls-and-fuel-62l-or-70l-introduction__crankshaft-position-system-variation-learn) .
  1. J 41816 Crankshaft Balancer Remover
  2. J 41816-2 Crankshaft End Protector. See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) .
  3. J 42386-A Flywheel Holding Tool. See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) .
  4. J 41665 Crankshaft Balancer and Sprocket Installer. See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) .
  5. J 45059 Angle Meter. See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) .
  6. EN-47812 Installer Bolt. See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) .
  1. Remove the air conditioning (A/C) drive belt. Refer to «Air Conditioning Compressor Belt Replacement (w/o LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) .
  2. Remove the power steering gear. Refer to «Steering Gear Replacement»(/chevrolet/corvette/c6-2004-2014/remont/manual-power-steering/#power-steering-system) .
  3. Remove the starter motor. Refer to «Starter Replacement»(/chevrolet/corvette/c6-2004-2014/remont/charging-system/#battery-charging-system-starting-system) .
  4. Remove the right transmission cover and bolt.
  5. Install the J 42386-A and bolts. See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) . Use one M10 - 1.5 x 120 mm and one M10 - 1.5 x 45 mm bolt for proper tool operation. Tighten the J 42386-A bolts to 50 N.m (37 lb ft).
  6. Remove the crankshaft balancer bolt (139). Do not discard the crankshaft balancer bolt. The balancer bolt will be used during the balancer installation procedure.
  7. Use the J 41816 (1) and the J 41816-2 (2) in order to remove the crankshaft balancer. See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) .
  8. Remove the crankshaft balancer (138).
  9. Note the position of the crankshaft balance weights, if applicable. Refer to «Engine Balancing»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__engine-balancing) and «Crankshaft Balancer Cleaning and Inspection»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-4-of-8__crankshaft-balancer-cleaning-and-inspection) .
  1. Install the J 42386-A and bolts. See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) . Use one M10 - 1.5 x 120 mm and one M10 - 1.5 x 45 mm bolt for proper tool operation. Tighten the J 42386-A bolts to 50 N.m (37 lb ft).
  2. Using the old balancer as a reference, mark or scribe the new balancer in the same location, if applicable. Refer to «Crankshaft Balancer Cleaning and Inspection»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-4-of-8__crankshaft-balancer-cleaning-and-inspection)
  3. Install balance weights into the new balancer, if applicable.
  4. Install the crankshaft balancer washer (1) onto the crankshaft balancer.
  5. Position the balancer (138) onto the end of the crankshaft.
  6. Use the J 41665 (2) and the EN-47812 (1) in order to install the balancer. See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) . Assemble the EN-47812 (1), nut, washer and the J 41665 . See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) .
  7. Insert the smaller end of the J 41665 (2) into the front of the balancer. See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) . Use a wrench and hold the hex end of the EN-47812 (1). See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) . Use a second wrench and rotate the installation tool nut clockwise until the balancer is started onto the crankshaft. Remove the J 41665 (2) and reverse the installation tool. See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) .
  8. Position the larger end of the J 41665 (2) against the front of the balancer. See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) . Use a wrench and hold the hex end of the EN-47812 (1). See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) . Use a second wrench and rotate the installation tool nut clockwise until the balancer is installed onto the crankshaft. Remove the balancer installation tools.
  9. Install the NEW crankshaft balancer bolt (139). Tighten the crankshaft balancer bolt a first pass to 150 N.m (110 lb ft). Loosen the crankshaft balancer bolt a second pass to 360 degrees. Tighten the crankshaft balancer bolt a third pass to 50 N.m (37 lb ft). Tighten the crankshaft balancer bolt a final pass to 230 degrees) using the J 45059 . See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) .
  10. Remove the J 42386-A . See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) .
  11. Install the starter motor. Refer to «Starter Replacement»(/chevrolet/corvette/c6-2004-2014/remont/charging-system/#battery-charging-system-starting-system) .
  12. Install the power steering gear. Refer to «Steering Gear Replacement»(/chevrolet/corvette/c6-2004-2014/remont/manual-power-steering/#power-steering-system) .
  13. Install the A/C drive belt. Refer to «Air Conditioning Compressor Belt Replacement (w/o LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) .
  14. Perform the crankshaft position (CKP) system variation learn procedure. Refer to «Crankshaft Position System Variation Learn»(/chevrolet/corvette/c6-2004-2014/remont/testing-diagnostics/#engine-controls-and-fuel-62l-or-70l-introduction__crankshaft-position-system-variation-learn) .

J 41478 Crankshaft Front Oil Seal Installer. See Special Tools .

  1. Remove the crankshaft balancer. Refer to «Crankshaft Balancer Replacement (6.2L)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) or «Crankshaft Balancer Replacement (7.0L)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) or «Crankshaft Balancer Replacement (LS9/LSA)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) .
  2. Gently pry the crankshaft oil seal (1) from the front cover.
IMPORTANTDo not lubricate the oil seal sealing surface. Do not reuse the crankshaft oil seal.
  1. Lubricate the outer edge of the oil seal (1) with clean engine oil.
  2. Lubricate the front cover oil seal bore with clean engine oil.
  3. Install the crankshaft front oil seal onto the J 41478 guide. See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) .
  4. Install the J 41478 threaded rod (with nut, washer, guide, and oil seal) into the end of the crankshaft. See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) .
  5. Use the J 41478 in order to install the oil seal into the cover bore. See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) . Use a wrench and hold the hex on the installer tool. Use a second wrench and rotate the installer nut clockwise until the seal bottoms in the cover bore. Remove the tool. Inspect the oil seal for proper installation. The oil seal should be installed evenly and completely into the front cover bore.
  6. Install the crankshaft balancer. Refer to «Crankshaft Balancer Replacement (6.2L)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) or «Crankshaft Balancer Replacement (7.0L)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) or «Crankshaft Balancer Replacement (LS9/LSA)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) .

EN-48853 Front Cover Alignment Tool. See Special Tools .

  1. Remove the accessory drive belt. Refer to «Drive Belt Replacement - Accessory (w/o LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) or «Drive Belt Replacement - Accessory (LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) .
  2. Remove the crankshaft balancer. Refer to «Crankshaft Balancer Replacement (6.2L)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) or «Crankshaft Balancer Replacement (7.0L)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) or «Crankshaft Balancer Replacement (LS9/LSA)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) .
  3. Remove the 2 front oil pan to front cover M8 bolts.
  4. Remove the water pump. Refer to «Water Pump Replacement»(/chevrolet/corvette/c6-2004-2014/remont/cooling-system-mechanical/#engine-cooling-system) .
  5. Disconnect the camshaft position (CMP) sensor electrical connector.
  6. Remove the front cover bolts (1).
  7. Remove the front cover (2) and gasket (3).
  8. Discard the front cover gasket.
  9. Clean and inspect the engine front cover. Refer to «Engine Front Cover Cleaning and Inspection (6.2L LS3)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-5-of-8__engine-front-cover-cleaning-and-inspection) or «Engine Front Cover Cleaning and Inspection (6.2L LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-5-of-8__engine-front-cover-cleaning-and-inspection) or «Engine Front Cover Cleaning and Inspection (7.0L)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-5-of-8__engine-front-cover-cleaning-and-inspection) .
  10. Remove the oil seal (140).
  11. Remove the bolt (705), camshaft position (CMP) sensor (703).
  12. Remove the O-ring (704) from the sensor, as required.
  1. Apply a 5 mm (0.2 in) bead of sealant 20 mm (0.8 in) long to the engine block. Apply the sealant to the T joint location where the oil pan meets the front of the engine block. Refer to «Adhesives, Fluids, Lubricants, and Sealers (6.2L LS3)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__adhesives-fluids-lubricants-and-sealers-62l) or «Adhesives, Fluids, Lubricants, and Sealers (6.2L LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__adhesives-fluids-lubricants-and-sealers-62l) or «Adhesives, Fluids, Lubricants, and Sealers (7.0L)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__adhesives-fluids-lubricants-and-sealers-70l) for the correct part number.
  2. Install a NEW crankshaft front oil seal. Refer to «Crankshaft Front Oil Seal Replacement»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) .
  3. Install the front cover gasket (3), front cover (2), and bolts (1).
  4. Tighten the cover bolts finger tight. Do not overtighten. Tighten the tool-to-engine block bolts to 25 N.m (18 lb ft).
  5. Install the EN-48853 onto the crankshaft. See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) .
  6. Tighten the crankshaft balancer bolt by hand until snug. Do not overtighten.
  7. Install the front cover.
  8. Remove the tool.
  9. Inspect the CMP sensor O-ring seal (704) for cuts or damage. If the seal is not cut or damaged, it may be used again.
  10. Lubricate the O-ring seal with clean engine oil.
  11. Install the O-ring seal onto the sensor (703).
  12. Install the sensor to the cover.
  13. Install the CMP sensor and bolt (705) and tighten to 12 N.m (106 lb in).
  14. Install the new crankshaft front oil seal. Refer to «Crankshaft Front Oil Seal Replacement»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) .
  15. Connect the CMP sensor electrical connector.
  16. Install the water pump. Refer to «Water Pump Replacement»(/chevrolet/corvette/c6-2004-2014/remont/cooling-system-mechanical/#engine-cooling-system) .
  17. Install the crankshaft balancer. Refer to «Crankshaft Balancer Replacement (6.2L)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) or «Crankshaft Balancer Replacement (7.0L)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) or «Crankshaft Balancer Replacement (LS9/LSA)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) .
  18. Install the accessory drive belt. Refer to «Drive Belt Replacement - Accessory (w/o LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) or «Drive Belt Replacement - Accessory (LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) .
  1. J 41480 Front/Rear Cover Alignment - Oil Pan Surface. See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) .
  2. J 41476 Front and Rear Cover Alignment (Crankshaft Oil Seal Area). See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) .
  1. Remove the crankshaft balancer. Refer to «Crankshaft Balancer Replacement (6.2L)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) or «Crankshaft Balancer Replacement (7.0L)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) or «Crankshaft Balancer Replacement (LS9/LSA)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) .
  2. Remove the water pump. Refer to «Water Pump Replacement»(/chevrolet/corvette/c6-2004-2014/remont/cooling-system-mechanical/#engine-cooling-system) .
  3. Remove the front cover bolts (501).
  4. Remove the front cover (502) and gasket (503).
  5. Discard the front cover gasket.
  6. Clean and inspect the engine front cover. Refer to «Engine Front Cover Cleaning and Inspection (6.2L LS3)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-5-of-8__engine-front-cover-cleaning-and-inspection) or «Engine Front Cover Cleaning and Inspection (6.2L LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-5-of-8__engine-front-cover-cleaning-and-inspection) or «Engine Front Cover Cleaning and Inspection (7.0L)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-5-of-8__engine-front-cover-cleaning-and-inspection) .
  7. Remove the oil seal (140).
  8. Remove the bolts (705, 738), camshaft position sensor (703), and wire harness (737).
  9. Remove the O-ring (704) from the sensor as required.
  1. Apply a 5 mm (0.2 in) bead of sealant 20 mm (0.8 in) long to the engine block. Refer to «Adhesives, Fluids, Lubricants, and Sealers (6.2L LS3)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__adhesives-fluids-lubricants-and-sealers-62l) or «Adhesives, Fluids, Lubricants, and Sealers (6.2L LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__adhesives-fluids-lubricants-and-sealers-62l) or «Adhesives, Fluids, Lubricants, and Sealers (7.0L)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__adhesives-fluids-lubricants-and-sealers-70l) for the correct part number. Apply the sealant directly onto the tabs of the front cover gasket that protrude into the oil pan surface.
  2. Install the front cover gasket (503), front cover (502), and bolts (501).
  3. Tighten the cover bolts finger tight. Do not overtighten.
  4. Install the J 41480 . See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) . Tighten: Tighten the tool-to-engine block bolts to 25 N.m (18 lb ft).
  5. Install the J 41476 . See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) .
  6. Install the crankshaft balancer bolt. Tighten: Tighten the crankshaft balancer bolt by hand until snug. Do not overtighten. Tighten the J 41480 . See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) . Tighten the engine front cover bolts to 25 N.m (18 lb ft).
  7. Remove the tools.
  8. Measure the oil pan surface flatness, front cover-to-engine block. Place a straight edge across the engine block and front cover oil pan sealing surfaces. Avoid contact with the portion of the gasket that protrudes into the oil pan surface. Insert a feeler gage between the front cover and the straight edge tool. The cover must be flush with the oil pan surface, or no greater than 0.5 mm (0.02 in) (a) below flush.
  9. If the front cover-to-engine block oil pan surface alignment is not within specifications, repeat the cover alignment procedure.
  10. If the correct front cover-to-engine block alignment cannot be obtained, replace the front cover.
  11. Inspect the camshaft position sensor O-ring seal (704) for cuts or damage. If the seal is not cut or damaged, it may be used again.
  12. Lubricate the O-ring seal with clean engine oil.
  13. Install the O-ring seal onto the sensor (703).
  14. Install the sensor to the cover.
  15. Install the camshaft position sensor wire harness (737) and bolts (705, 738). Tighten: Tighten the bolts to 12 N.m (106 lb in).
  16. Install the water pump. Refer to «Water Pump Replacement»(/chevrolet/corvette/c6-2004-2014/remont/cooling-system-mechanical/#engine-cooling-system) .
  17. Install the crankshaft balancer. Refer to «Crankshaft Balancer Replacement (6.2L)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) or «Crankshaft Balancer Replacement (7.0L)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) or «Crankshaft Balancer Replacement (LS9/LSA)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) .

J 41479 Crankshaft Rear Oil Seal Installer. See Special Tools .

  1. Remove the engine flywheel. Refer to «Engine Flywheel Replacement (LS9 and LSA)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-3-of-8) or «Engine Flywheel Replacement (Except LS9 and LSA)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-3-of-8) .
  2. Gently pry the crankshaft rear oil seal (1) from the rear cover.
  1. Inspect the seal and identify the part number markings for proper orientation.
  2. Lubricate the outside diameter (OD) of the oil seal (1) with clean engine oil. DO NOT allow oil or other lubricants to contact the seal surface.
  3. Lubricate the rear cover oil seal bore with clean engine oil. DO NOT allow oil or other lubricants to contact the crankshaft surface.
  4. Install the J 41479 cone (2) and bolts onto the rear of the crankshaft. See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) .
  5. Tighten the bolts until snug. Do not overtighten.
  6. Install the rear oil seal onto the tapered cone (2) and push the seal to the rear cover bore.
  7. Thread the J 41479 threaded rod into the tapered cone until the tool (1) contacts the oil seal. See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) .
  8. Align the oil seal onto the tool (1).
  9. Rotate the handle of the tool (1) clockwise until the seal enters the rear cover and bottoms into the cover bore.
  10. Remove the J 41479 . See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) .
  11. Install the engine flywheel. Refer to «Engine Flywheel Replacement (LS9 and LSA)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-3-of-8) or «Engine Flywheel Replacement (Except LS9 and LSA)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-3-of-8) .
  1. J 41476 Front and Rear Cover Alignment Tool. See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) .
  2. J 41479-2A Crankshaft Rear Oil Seal Installation Guide
  1. Remove the engine flywheel. Refer to «Engine Flywheel Replacement (LS9 and LSA)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-3-of-8) or «Engine Flywheel Replacement (Except LS9 and LSA)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-3-of-8) .
  2. Remove the oil pan-to-rear oil seal housing bolts (1).
  3. Remove the rear oil seal housing bolts (1).
  4. Remove the rear oil seal housing (2) and gasket (3). Discard the gasket.
  5. Remove and discard the rear oil seal (4).
  1. Apply a 5 mm (0.2 in) bead of sealant, 20 mm (0.8 in) to the 2 joints (a) at the rear of the block/pan. Refer to «Adhesives, Fluids, Lubricants, and Sealers (6.2L LS3)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__adhesives-fluids-lubricants-and-sealers-62l) or «Adhesives, Fluids, Lubricants, and Sealers (6.2L LS9)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__adhesives-fluids-lubricants-and-sealers-62l) or «Adhesives, Fluids, Lubricants, and Sealers (7.0L)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__adhesives-fluids-lubricants-and-sealers-70l) .
  2. Inspect the rear oil gallery plug for proper installation.

Installation Procedure - Cover with Seal

  1. Install the J 41479-2A cone and bolts onto the rear of the crankshaft.
  2. Install the NEW rear housing gasket (1), rear housing with seal (2), rear housing-to-engine bolts (3) and oil pan-to-rear housing bolts (4).
  3. Tighten the rear housing-to-engine bolts (3) until snug. Do not overtighten. Tighten: Tighten the oil pan-to-rear housing bolts (4) to 12 N.m (106 lb in).
  4. Tighten the rear housing-to-engine bolts (3). Tighten: Tighten the bolts to 30 N.m (22 lb ft).
  5. Remove the J 41479-2A .
  6. Install the engine flywheel. Refer to «Engine Flywheel Replacement (LS9 and LSA)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-3-of-8) or «Engine Flywheel Replacement (Except LS9 and LSA)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-3-of-8) .

Installation Procedure - Cover without Seal

  1. Position a NEW rear oil seal housing gasket (3) and the housing (2) to the engine.
  2. Install the rear oil seal housing bolts (1) until snug. Do not overtighten.
  3. Rotate the crankshaft until 2 opposing flywheel bolts holes are parallel to the oil pan surface.
  4. Install the J 41476 and bolts onto the rear of the crankshaft. See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) .
  5. Tighten the J 41476 bolts until snug. See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) . Do not overtighten.
  6. Install the oil pan-to-rear oil seal housing bolts (1). Tighten: Tighten the oil pan-to-rear cover bolts to 12 N.m (106 lb in). Tighten the rear oil seal housing-to-engine bolts to 30 N.m (22 lb ft).
  7. Remove the J 41476 . See «Special Tools»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-1-of-8__special-tools-62l-ls3) .
  8. Install a NEW crankshaft rear oil seal. Refer to «Crankshaft Rear Oil Seal Replacement»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-2-of-8) .
  9. Install the engine flywheel. Refer to «Engine Flywheel Replacement (LS9 and LSA)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-3-of-8) or «Engine Flywheel Replacement (Except LS9 and LSA)»(/chevrolet/corvette/c6-2004-2014/remont/mechanical/#engine-mechanical-62l-or-70l-3-of-8) .
  1. Remove the oil filter.
  2. Remove the oil filter adapter (1).
  1. Install the oil filter adapter (1). Tighten: Tighten the oil filter adapter to 55 N.m (40 lb ft).
  2. Install the oil filter. Tighten: Tighten the oil filter to 30 N.m (22 lb ft).

See also:
• Air Cleaner Assembly Replacement (6.2L)
• Lifting and Jacking the Vehicle
• Fastener Caution
• Front Suspension Crossmember Replacement (With Z06 or ZR1)
• Tire and Wheel Removal and Installation
• Engine Oil and Oil Filter Replacement (6.2L )
• Charge Air Cooler Coolant Hose Replacement - Pump to Cooler
• Component Fastener Tightening Caution
• Special Tools (6.2L LS3)
• Special Tools (6.2L LS9)
• Special Tools (7.0L)
• Fuel Rail and Injectors Installation (6.2L LS3)
• Fuel Rail and Injectors Installation (7.0L)
• Adhesives, Fluids, Lubricants, and Sealers (6.2L LS3)
• Adhesives, Fluids, Lubricants, and Sealers (7.0L)
• Valve Rocker Arm and Push Rod Cleaning and Inspection (6.2L LS3)
• Generator Bracket Replacement
• Exhaust Manifold Replacement - Left Side (With LS7 or LS9)
• Cylinder Head Cleaning and Inspection (6.2L LS3)
• Safety Glasses Warning
• Separating Parts
• Steering Gear Replacement
• Engine Balancing
• Crankshaft Balancer Cleaning and Inspection
• Crankshaft Position System Variation Learn
• Engine Front Cover Cleaning and Inspection (6.2L LS3)
• Drive Belt Replacement - Accessory (w/o LS9)

More articles — Engine
