Accessory Power Socket Chevrolet Corvette C6

Body Electrical 3 illustrations

Scheme 22

Scheme 22: Cigar Lighter/Power Outlet Schematics
Scheme 22: Cigar Lighter/Power Outlet Schematics

Scheme 23

Scheme 23: Cigar Lighter Housing Replacement
Scheme 23: Cigar Lighter Housing Replacement
CalloutComponent Name
1Housing, Cigar Lighter Tip: Use J 42059 Cigar Lighter Socket Remover to remove the cigar lighter. Remove the Cigar lighter Fuse. Place one side of the "T" portion of the J 42059 into a tab window. Insert the opposite side of the "T" into the opposing tab window. Pull the housing and retainer straight out of the ashtray assembly. Disconnect the electrical connection.
2Retainer, Cigar Lighter

Scheme 24

Scheme 24: Floor Console Accessory Power Receptacle Replacement
Scheme 24: Floor Console Accessory Power Receptacle Replacement
CalloutComponent Name
1Receptacle, Accessory Power Outlet Tip: Use J 42059 Cigar lighter Socket Remover to remove the power outlet. Place one side of the "T" portion of the J 42059 into a tab window. Insert the opposite side of the "T" into the opposing tab window. Pull the receptacle and retainer straight out of the instrument panel (I/P) accessory trim panel. Disconnect the electrical connection.
2Retainer, Accessory Power Outlet
