HVAC System - Automatic: Adjustments Chevrolet Captiva I facelift

Automatic HVAC System 2 illustrations

Calibration Procedure

Use the following steps to perform the calibration update

  1. Install a scan tool.
  2. Turn ON the ignition, with the engine OFF.
  3. Select HVAC Control Module.
  4. Select Special Functions.
  5. Select recalibrate All Motors.
  6. Select ON, wait 60 seconds.

Scheme 37

Scheme 37: Heater and Air Conditioning Control Replacement
Scheme 37: Heater and Air Conditioning Control Replacement
CalloutComponent Name
1Front Floor Console Accessory Trim Plate. Refer to Front Floor Console Accessory Trim Plate Replacement (Lower) , Front Floor Console Accessory Trim Plate Replacement (Upper) .
2HVAC Control Assembly Screw (Qty: 4) CAUTION: Refer to Fastener Caution . Tighten 1.5 N.m (13 lb in)
3HVAC Control Assembly Procedure Reprogram the HVAC control module. Refer to Control Module References .
CAUTION
Refer to Fastener Caution .

Heater and Air Conditioning Control Replacement

Scheme 38

Scheme 38: Air Inlet Valve Actuator Replacement
Scheme 38: Air Inlet Valve Actuator Replacement
CalloutComponent Name
Preliminary Procedure Remove the instrument panel assembly. Refer to Instrument Panel Assembly Replacement .
1Recirculation Actuator Screw (Qty: 3) CAUTION: Refer to Fastener Caution . Tighten 1.5 N.m (13 lb in)
2Recirculation Actuator Procedure Remove the electrical connector. Calibrate the recirculation actuator. Refer to Actuator Recalibration .
CAUTION
Refer to Fastener Caution .

Air Inlet Valve Actuator Replacement
