MODEL IDENTIFICATION

Note. For scheduled maintenance intervals and the related fluid capacities, fluid specifications and labor times for major service intervals, see SCHEDULED SERVICES article in this section. Warranty information and specifications for fluid capacities, lubrication specifications, wheel and tire size, and battery type are covered in this article.

VIN LOCATION

The Vehicle Identification Number (VIN) is located on the left side of the dash panel at the base of the windshield. The VIN chart explains the code characters.

VIN CODE ID EXPLANATION

Numbers preceding the explanations in the legend below refer to the sequence of characters as listed on VIN identification label. See VIN example below.

VIN Code ID Explanation. Scheme 1

Scheme 1: VIN Code ID Explanation

SEVERE & NORMAL SERVICE DEFINITIONS

Note. Use the Severe Service schedule if the vehicle to be serviced or operated under ANY (one or more) of these conditions

Service is recommended at mileage intervals based on vehicle operation. Service schedules are based on the following primary operating conditions

Severe Service

  1. Short Trips (4 Miles Or Less)
  2. Towing Or Heavily Loaded
  3. Severe Dust Conditions
  4. Hot Weather, Stop-And-Go Driving
  5. Extensive Idling Conditions (Taxi Or Delivery Type Service)
  6. Trips Less Than 10 Miles In Freezing Temperatures

Normal Service

  1. Driven More Than 10 Miles Daily
  2. No Severe Service Operating Conditions

Scheme 2

Scheme 2: SERVICE POINT LOCATIONS

Scheme 3

Scheme 3: INFORMATION LABEL LOCATIONS

Scheme 4

Scheme 4

SERVICE LABOR TIMES

Note. For 1990 and newer vehicles, labor times are provided, where available, within appropriate SERVICE INTERVAL table in SCHEDULED SERVICES article.

TIRE INFLATION

The tire specification decal is located on the rear of the driver's door.

WHEEL TIGHTENING

1983-90 - Tighten all wheel lug nuts to 80 ft. lbs. (108 N.m).

1991-92 - Tighten all wheel lug nuts to 100 ft. lbs. (140 N.m).

BATTERY SPECIFICATIONS

CAUTIONWhen battery is disconnected, vehicles equipped with computers may lose memory data. When battery power is restored, driveability problems may exist on some vehicles. These vehicles may require a relearn procedure. See COMPUTER RELEARN PROCEDURES article in the GENERAL INFORMATION section.

1983-86 - Models with VIN Codes F, G, H, and S use Group 75-60 batteries. Models with VIN Code 2 and optional models use Group 75A-60 batteries.

1987-88 - Models with VIN Codes S, E, and F use Group 75-60 batteries. Models with VIN Code 8 and Heavy Duty models use Group 75A-72 batteries.

1989 - Models with VIN Codes S, T, E, and F use Group 75-60 batteries. Models with VIN Code 8 use Group 75A-72 batteries. Heavy Duty models use 75A-50 batteries.

1990-92 - Models with VIN Codes E, F, P, S and T use Group 75-60 batteries. Models with VIN Code 8 and Heavy Duty models use Group 75A-72 batteries.

SUPPLEMENTAL RESTRAINT SYSTEM - AIR BAG (1990-92)

Note. See the AIR BAGS article in the ACCESSORIES/SAFETY EQUIPMENT Section.

Modifications or improper maintenance, including incorrect removal and installation of the Supplemental Restraint System (SRS), can adversely affect system performance. DO NOT cover, obstruct or change the steering wheel horn pad in any way, as such action could cause improper function of the system. Use only plain water when cleaning the horn pad. Solvents or cleaners could adversely affect the air bag cover and cause improper deployment of the system.

WARNINGTo avoid injury from accidental air bag deployment, read and carefully follow all warnings and service precautions. See appropriate AIR BAGS article in ACCESSORIES/SAFETY EQUIPMENT.

Modification to the air bag system component or wiring can adversely affect system performance and possibly cause injury.

CAUTIONThe Diagnostic Energy Reserve Module (DERM) can maintain enough voltage to cause a deployment of the inflator module for up to 10 minutes after the ignition switch is turned off and the battery is disconnected. Many of the service procedures requir e disconnection of the inflator module to avoid an accidental deployment.
CAUTIONDisconnect negative battery cable before servicing any air bag system, steering column or passenger side dash component. After any repair, turn ignition key to the ON position from passenger's side of vehicle in case of accidental air bag inflation

ANTI-LOCK BRAKE SYSTEM

The anti-lock brake system contains electronic equipment that can be susceptible to interference caused by improperly installed or high output radio transmitting equipment. Since this interference could cause the possible loss of the anti-lock braking capability, such equipment should be installed by qualified professionals.

On models equipped with anti-lock brake systems, ALWAYS observe the following cautions

  1. DO NOT attempt to bleed hydraulic system without first referring to the appropriate ANTI-LOCK BRAKE SYSTEM article in the BRAKES Section.
  2. DO NOT mix tire sizes. As long as tires remain close to the original diameter, increasing the width is acceptable. Rolling diameter must be identical for all 4 tires. Some manufacturers recommend tires of the same brand, style and type. Failure to follow this precaution may cause inaccurate wheel speed readings.
  3. Use ONLY recommended brake fluids. DO NOT use silicone brake fluids in an ABS-equipped vehicle.

BATTERY WARNING

WARNINGWhen battery is disconnected, vehicles equipped with computers may lose memory data. When battery power is restored, driveability problems may exist on some vehicles. These vehicles may require a relearn procedure. See COMPUTER RELEARN PROCEDURES article in GENERAL INFORMATION section.

REPLACING BLOWN FUSES

CAUTIONBefore replacing a blown fuse, remove ignition key, turn off all lights and accessories to avoid damaging the electrical system. Be sure to use fuse with the correct indicated amperage rating. The use of an incorrect amperage rating fuse may result in a dangerous electrical system overload.

BRAKE PAD WEAR INDICATOR

Indicator will cause a squealing or scraping noise, warning that brake pads need replacement.

CATALYTIC CONVERTER

CAUTIONContinued operation of vehicle with a severe malfunction could cause converter to overheat, resulting in possible damage to converter and vehicle.

COOLANT (PROPYLENE-GLYCOL FORMULATIONS)

CAUTIONTo avoid possible damage to vehicle use only ethylene-glycol based coolants with a mixture ratio from 44-68% anti-freeze. DO NOT use 100% anti-freeze as it will cause the formation of cooling system deposits. This results in coolant temperatures of over 300° F (149°C) which can melt plastics. 100% anti-freeze has a freeze point of only -8° F (-22°C).
CAUTIONPropylene-Glycol Mixtures has a smaller temperature range than Ethylene-Glycol. The temperature range (freeze-boil) of a 50/50 Anti-Freeze/Water Mix is as follows: Propylene-Glycol -26° F (-32°C) - 257° F (125°C) Ethylene-Glycol -35° F (-37°C) - 263° F (128°C)
CAUTIONPropylene-Glycol/Ethylene-Glycol Mixtures can cause the destabilization of various corrosion inhibitors. Also Propylene-Glycol/Ethylene-Glycol has a different specific gravity than Ethylene-Glycol coolant, which will result in inaccurate freeze point calculations.

ELECTROSTATIC DISCHARGE SENSITIVE (ESD) PARTS

WARNINGMany solid state electrical components can be damaged by static electricity (ESD). Some will display a warning label, but many will not. Discharge personal static electricity by touching a metal ground point on the vehicle prior to servicing any ESD sensitive component.

ENGINE OIL

CAUTIONNever use non-detergent or straight mineral oil.

FUEL SYSTEM SERVICE

WARNINGRelieve fuel system pressure prior to servicing any fuel system component (fuel injection models).

HALOGEN BULBS

WARNINGHalogen bulbs contain pressurized gas which may explode if overheated. DO NOT touch glass portion of bulb with bare hands. Eye protection should be worn when handling or working around halogen bulbs.

RADIATOR CAP

CAUTIONAlways disconnect the fan motor when working near the radiator fan. The fan is temperature controlled and could start at any time even when the ignition key is in the OFF position. DO NOT loosen or remove radiator cap when cooling system is hot.

RADIATOR FAN

WARNINGKeep hands away from radiator fan.

WARRANTY INFORMATION

CAUTIONDue to the different warranties offered in various regions and the variety of after-market extended warranties available, please refer to the warranty package that came with the vehicle to verify all warranty options.

BASIC NEW CAR LIMITED WARRANTY (1987-88)

Everything is covered for 12 months or 12,000 miles, whichever occurs first. Warranty covers cost of all parts and labor needed to repair or adjust any items (except tires) that have been proven defective in material, workmanship or factory preparation under normal vehicle use.

POWERTRAIN WARRANTY

Powertrain warranty takes effect upon the expiration of the 12-month/12,000-mile Basic New Car Limited Warranty and last for 6 years or 60,000 miles whichever occurs first. Covers all moving internal and external parts, including seals and water pump on engine and clutch cover and U-joints on transaxle. Items not covered include accessory drive belts, clutch discs and brake pads.

BUMPER TO BUMPER PLUS COVERAGE LIMITED WARRANTY (1989-92)

Everything covered for 3 years or 50,000 miles, whichever occurs first. Covered by this warranty are any repairs to vehicle which have proven defective during material and workmanship in normal use (tires excluded). Warranty repairs (parts and labor) will be made by the Dealer at no charge using new or remanufactured parts by the Dealer. This warranty is subject to a 100 deductible for each repair visit after the first year or 12,000 miles, whichever occurs first. Maintenance items are covered up to their first scheduled replacement interval only.

Note. 1992 vehicles are covered for 3 years or 36,000 miles with no deductible.

SUPPLEMENTAL INFLATABLE RESTRAINT COVERAGE

Begins at Warranty Start Date and lasts 3 years regardless of mileage.

CORROSION COVERAGE

Begins at Warranty Start Date and lasts 6 years or 100,000 miles, whichever occurs first. Covers any holes in body sheet metal caused by corrosion.

FEDERAL EMISSIONS DEFECT & PERFORMANCE WARRANTY (EXCEPT CALIFORNIA)

Defect Warranty ensures that vehicle meets applicable EPA regulations and that vehicle's emission control system is free from defects in materials and workmanship for a period of 5 years or 50,000 miles, whichever occurs first.

The Performance Warranty covers all costs of repairing or adjusting any components or parts as needed in order for the vehicle to pass a Federally required state or local emissions test.

Other emission control parts related to these components are covered by the Performance warranty, where applicable. If another part fails due to the failure of one of these components, both parts are covered. See customer's copy of warranty information for specific items covered.

EMISSION "PERFORMANCE" WARRANTY (CALIFORNIA)

If vehicle fails a Smog Check inspection, all necessary repairs and adjustments will be made by manufacturer to ensure that vehicle passes the inspection. Warranty begins at warranty start date and lasts for a period of 3 years or 50,000 miles, whichever occurs first.

EMISSION "DEFECT" WARRANTY (CALIFORNIA)

If any emission-related part on the vehicle is defective, the part will be repaired or replaced by manufacturer. Warranty begins at warranty start date and lasts for a period of 3 years or 50,000 miles, whichever occurs first.

Some emission-related parts are warranted for 7 years or 70,000 miles whichever occurs first, and will be repaired or replaced by manufacturer if found to be defective in material or workmanship. See customer's copy of warranty information for specific items covered.

Scheme 5

Scheme 5: FUSE PANEL IDENTIFICATION (1983-86 CAMARO)

Fuse & Circuit Breaker Identification

  1. 1 - 10 Amp - Electronic Control Module, Fuel Injectors (1985-86)
  2. 2 - 10 Amp - Fuel Pump, Engine Cooling Fan, Choke Heater (1986)
  3. 3 - 3 Amp - Crank Signal To ECM
  4. 4 - 20 Amp - Choke Heater (1983-85), Deck Lid (1986)
  5. 5 - 20 Amp - Turn Signal Lights, Back-Up Lights
  6. 6 - Blank (1983-84), 10 Amp - Fuel Injector
  7. 7 - 20 Amp - Tail & Parking Lights, License & Side Marker Lights
  8. 8 - 25 Amp - Heater & Air Conditioner
  9. 9 - 10 Amp - Gauges & Warning Lights, Seat Belt Audible Warning, Key Audible Warning, Cruise Control
  10. 10 - 10 Amp - Instrument Panel (1983-85), Fuel Injector (1985-86), Fuel Pump (1986)
  11. 11 - 20 Amp - Courtesy Light, Dome Light, Rear Compartment Light, Clock, Horn, Cigarette Lighter, Rear Hatch Release, Power Antenna
  12. 12 - 30 Amp (Circuit Breaker) - Power Window, Rear Window Washer/Wiper
  13. 13 - 5 Amp - Instrument Panel Lights
  14. 14 - 10 Amp - Radio
  15. 15 - 30 Amp (Circuit Breaker) - Power Seat, Door Locks, Rear Window Defogger
  16. 16 - 25 Amp - Windshield Wipers
  17. 17 - 20 Amp - Stoplight Switch, Hazard Warning Lights

Scheme 6

Scheme 6: FUSE PANEL IDENTIFICATION (1987-89 CAMARO)
  1. 1 - 10 Amp (Red) - Engine
  2. 2 - 20 Amp (Yellow) - Engine Cooling Fan
  3. 3 - 3 Amp (Violet) - Crank Signal to E.C.M.
  4. 4 - 20 Amp (Yellow) - Engine Cooling Fan (Engine Codes F & S)
  5. 5 - 20 Amp (Yellow) - Turn Signal Lights, Back-Up Lights
  6. 6 - 10 Amp (Red) - Fuel Injector
  7. 7 - 20 Amp (Yellow) - Taillights
  8. 8 - 25 Amp (White) - Heater & Air Conditioner
  9. 9 - 10 Amp (Red) - Gauges
  10. 10 - 10 Amp (Red) - Fuel Pump, Fuel Injector
  11. 11 - 20 Amp (Yellow) - Accessory
  12. 12 - 30 Amp (Circuit Breaker) - Power Window
  13. 13 - 5 Amp (Tan) - Instrument Lights
  14. 14 - 10 Amp (Red) - Radio
  15. 15 - 35 Amp (Circuit Breaker) - Power Door Locks, Rear Window Defogger
  16. 16 - 25 Amp (White) - Windshield Wiper
  17. 17 - 20 Amp (Yellow) - Stoplight Switch, Hazard Flasher

Scheme 7

Scheme 7: FUSE PANEL IDENTIFICATION (1983-89 FIREBIRD)
  1. 1 - 10 Amp (Red) - Computer Command Control
  2. 2 - 10 Amp (Red) - Fuel Pump, Oil Pressure Switch, Electric Cluster (1987-89)
  3. 3 - 3 Amp (Violet) - Crank Signal To ECM
  4. 4 - 20 Amp (Yellow) - Choke Heater (Engine Code H) (1983-87), Cooling Fan Relay (Engine Codes F & S)
  5. 5 - 20 Amp (Yellow) - Turn Signal Lights, Back-Up Lights
  6. 6 - Blank (1983-86), 20 Amp (Red) - MPFI Injectors (Engine Codes F & S)
  7. 7 - 20 Amp (Yellow) - Parking Lights, Side Marker Lights, Taillights
  8. 8 - 25 Amp (White) - Heater &/Or Air Conditioner
  9. 9 - 10 Amp (Red) - Audio Alarm System, Computer Command Control (1983-86), Vehicle Speed Sensor (1987-89), TCC Brake Switch, Cruise Control, A/C Relay, Gauges, Rear Window Defogger
  10. 10 - Blank (1983-86), 20 Amp (Yellow) - MPFI Injectors (Engine Codes F & S)
  11. 11 - 20 Amp (Yellow) - Glove Box Light, Cigarette Lighter, Hatchback Lid Release, Horn Relay, Interior Lights, Power Antenna, Power Door Locks, Radio/Digital Clock, Computer Command Control
  12. 12 - 5 Amp (Tan) - Instrument Panel Lights
  13. 13 - 10 Amp (Red) - Radio
  14. 14 - 25 Amp (White) - Windshield Wiper/Washer
  15. 15 - 35 Amp (Circuit Breaker) - Power Windows, Rear Wiper/Washer
  16. 16 - 35 Amp (Circuit Breaker) - Power Door Locks, Power Seats, Rear Window Defogger
  17. 17 - 20 Amp (Yellow) - Stoplight Switch, Hazard Flasher, Chime

Scheme 8

Scheme 8: FUSE PANEL IDENTIFICATION (1990-92 CAMARO & FIREBIRD)
  1. 1 - 10 Amp - Computer Command Control
  2. 2 - 10 Amp - Fuel Injector Feed No. 1
  3. 3 - 15 Amp - Hatch Pull-Down Motor
  4. 4 - 20 Amp - Cooling Fan Relay
  5. 5 - 20 Amp - Turn Signal & Back-Up Lights
  6. 6 - 10 Amp - MPFI Injectors No. 2
  7. 7 - 20 Amp - Parking Lights, Side Marker Lights, Taillights
  8. 8 - 25 Amp - Heater Or Air Conditioner
  9. 9 - 10 Amp - Audio Alarm System, Vehicle Speed Sensor, TCC Brake Switch, Gauges, Rear Window Defogger, Daytime Running Lights
  10. 10 - 10 Amp - Supplemental Inflatable Restraint
  11. 11 - 20 Amp - Glove Box Light, Cigarette Lighter, Hatchback Lid Release, Horn Relay, Interior Lights & Power Antenna, Power Door Locks, Radio/Digital Clock, Computer Command Control
  12. 12 - 5 Amp - Instrument Panel Lights
  13. 13 - 10 Amp - Radio
  14. 14 - 25 Amp - Windshield Wiper/Washer
  15. 15 - 35 Amp (1990), 30 Amp (1991-92) - Power Windows
  16. 16 - 35 Amp (1990), 30 Amp (1991-92) - Power Door Locks & Power Seats, Rear Window Defogger
  17. 17 - 20 Amp - Stoplight Switch, Hazard Flasher, Chime
  18. 18 - 10 Amp - VATS II Security Light
  19. 19 - 20 Amp - Radio
  20. 20 - 3 Amp - ECM Crank Circuit
  21. 21 - 10 Amp - Daytime Running Lights (Canada)
  22. 22 - 30 Amp (Circuit Breaker) - Fog Light
