Engine Mechanical - 4.8l, 5.3l & 6.0l - Introduction Chevrolet Cab & Chassis Silverado 3500

Fastener Tightening Specifications

Fastener Tightening Specifications

Engine Mechanical Specifications (LR4 VIN V)

Engine Mechanical Specifications (LR4 VIN V)

Engine Mechanical Specifications (LM7 VIN T)

Engine Mechanical Specifications (LM7 VIN T)

Engine Mechanical Specifications (L33 VIN B)

Engine Mechanical Specifications (L33 VIN B)

Engine Mechanical Specifications (L59 VIN Z)

Engine Mechanical Specifications (L59 VIN Z)

Engine Mechanical Specifications (LQ4 VIN U)

Engine Mechanical Specifications (LQ4 VIN U)

Engine Mechanical Specifications (LQ9 VIN N)

Engine Mechanical Specifications (LQ9 VIN N)

Sealers, Adhesives, and Lubricants

Sealers, Adhesives, and Lubricants

Scheme 36

Engine Block - Front View

Scheme 37

Engine Block - Rear View

Scheme 38

Engine Block - Left Side View

Scheme 39

Engine Block - Right Side View

Scheme 40

Engine Block - Bottom View

Scheme 41

Engine Block - Top View

Scheme 42

Cylinder Head - Top View

Scheme 43

Cylinder Head - End View

Scheme 44

Cylinder Head - Exhaust Manifold Deck View

Scheme 45

Cylinder Head - Intake Manifold Deck View

Scheme 46

Scheme 47

Scheme 48

Scheme 49

Scheme 50

Scheme 51

Scheme 52

Scheme 53

The vehicle identification number (VIN) is located on the left side rear of the engine block (1) and is typically a nine digit number stamped or laser-etched onto the engine at the vehicle assembly plant.

1. The first digit identifies the division.
2. The second digit identifies the model year.
3. The third digit identifies the assembly plant.
4. The fourth through ninth digits are the last six digits of the VIN.

Diagnostic Starting Point - Engine Mechanical

Begin the system diagnosis by reviewing the Disassembled Views , Engine Component Description , Lubrication Description , New Product Information . Reviewing the description and operation information will help you determine the correct symptom diagnostic procedure when a malfunction exists. Reviewing the description and operation information will also help you determine if the condition described by the customer is normal operation. Refer to Symptoms - Engine Mechanical in order to identify the correct procedure for diagnosing the system and where the procedure is located.

Strategy Based Diagnostics

1. Perform the «Diagnostic System Check - Vehicle»(ref-197324-S38390546772005101100000) in Vehicle DTC Information before using the symptom tables, if applicable.
2. Review the system operations in order to familiarize yourself with the system functions. Refer to «Disassembled Views»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-introduction) , «Engine Component Description»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-introduction) , «Lubrication Description»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-introduction) , «New Product Information»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-introduction__new-product-information) , and .

All diagnosis on a vehicle should follow a logical process. Strategy based diagnostics is a uniform approach for repairing all systems. The diagnostic flow may always be used in order to resolve a system condition. The diagnostic flow is the place to start when repairs are necessary. For a detailed explanation, refer to Strategy Based Diagnosis in General Information.

Visual/Physical Inspection

1. Inspect for aftermarket devices which could affect the operation of the Engine. Refer to «Checking Aftermarket Accessories»(ref-197325-S26768357732005101100000) in Wiring Systems.
2. Inspect the easily accessible or visible system components for obvious damage or conditions which could cause the symptom.
3. Check for the correct oil level, proper oil viscosity, and correct filter application.
4. Verify the exact operating conditions under which the concern exists. Note factors such as engine RPM, ambient temperature, engine temperature, amount of engine warm-up time, and other specifics.
5. Compare the engine sounds, if applicable, to a known good engine and make sure you are not trying to correct a normal condition.

Intermittent

Test the vehicle under the same conditions that the customer reported in order to verify the system is operating properly.

Symptom List

Refer to a symptom diagnostic procedure from the following list in order to diagnose the symptom

1. «Base Engine Misfire without Internal Engine Noises»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-introduction__base-engine-misfire-without-internal-engine)
2. «Base Engine Misfire with Abnormal Internal Lower Engine Noises»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-introduction__base-engine-misfire-with-abnormal-internal)
3. «Base Engine Misfire with Abnormal Valve Train Noise»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-introduction__base-engine-misfire-with-abnormal-valve)
4. «Base Engine Misfire with Coolant Consumption»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-introduction__base-engine-misfire-with-coolant-consumption)
5. «Base Engine Misfire with Excessive Oil Consumption»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-introduction__base-engine-misfire-with-excessive-oil)
6. «Engine Noise on Start-Up, but Only Lasting a Few Seconds»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-introduction__engine-noise-on-start-up-but-only)
7. «Upper Engine Noise, Regardless of Engine Speed»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-introduction__upper-engine-noise-regardless-of-engine)
8. «Lower Engine Noise, Regardless of Engine Speed»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-introduction__lower-engine-noise-regardless-of-engine)
9. «Engine Noise Under Load»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-introduction__engine-noise-under-load)
10. «Engine Will Not Crank - Crankshaft Will Not Rotate»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-introduction__engine-will-not-crank-crankshaft)
11. «Coolant in Combustion Chamber»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-introduction__coolant-in-combustion-chamber)
12. «Coolant in Engine Oil»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-introduction__coolant-in-engine-oil)
13. «Engine Compression Test»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-introduction__engine-compression-test)
14. «Cylinder Leakage Test»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-introduction)
15. «Oil Consumption Diagnosis»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-introduction__oil-consumption-diagnosis)
16. «Oil Pressure Diagnosis and Testing»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-introduction__oil-pressure-diagnosis-and-testing)
17. «Crankcase Ventilation System Inspection/Diagnosis»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-introduction__crankcase-ventilation-system-inspectiondiagnosis)
18. «Drive Belt Chirping Diagnosis»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-introduction)
19. «Drive Belt Squeal Diagnosis»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-introduction)
20. «Drive Belt Whine Diagnosis»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-introduction)
21. «Drive Belt Rumbling Diagnosis»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-introduction)
22. «Drive Belt Vibration Diagnosis»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-introduction)
23. «Drive Belt Falls Off Diagnosis»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-introduction)
24. «Drive Belt Excessive Wear Diagnosis»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-introduction)
25. «Drive Belt Tensioner Diagnosis»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-introduction)

Base Engine Misfire without Internal Engine Noises

Base Engine Misfire without Internal Engine Noises

Base Engine Misfire with Abnormal Internal Lower Engine Noises

Base Engine Misfire with Abnormal Internal Lower Engine Noises

Base Engine Misfire with Abnormal Valve Train Noise

Base Engine Misfire with Abnormal Valve Train Noise

Base Engine Misfire with Coolant Consumption

Base Engine Misfire with Coolant Consumption

Base Engine Misfire with Excessive Oil Consumption

Base Engine Misfire with Excessive Oil Consumption

Engine Noise on Start-Up, but Only Lasting a Few Seconds

Engine Noise on Start-Up, but Only Lasting a Few Seconds

Upper Engine Noise, Regardless of Engine Speed

Upper Engine Noise, Regardless of Engine Speed

Lower Engine Noise, Regardless of Engine Speed

Lower Engine Noise, Regardless of Engine Speed

Engine Noise Under Load

Engine Noise Under Load

Engine Will Not Crank - Crankshaft Will Not Rotate

Engine Will Not Crank - Crankshaft Will Not Rotate

Coolant in Combustion Chamber

Coolant in Combustion Chamber

Coolant in Engine Oil

Coolant in Engine Oil

Engine Compression Test

1. Charge the battery if the battery is not fully charged.
2. Disable the ignition system.
3. Disable the fuel injection system.
4. Remove all the spark plugs.
5. Turn the ignition to the ON position.
6. Depress the accelerator pedal to position the throttle plate wide open.
7. Start with the compression gage at zero and crank the engine through four compression strokes, four puffs.
8. Check the compression for each cylinder. Record the readings.
9. If a cylinder has low compression, inject approximately 15 ml (1 tablespoon) of engine oil into the combustion chamber through the spark plug hole. Check the compression again and record the reading.
10. The minimum compression in any one cylinder should not be less than 70 percent of the highest cylinder. No cylinder should read less than 690 kPa (100 psi). For example, if the highest pressure in any one cylinder is 1 035 kPa (150 psi), the lowest allowable pressure for any other cylinder would be 725 kPa (105 psi). (1 035 x 70% = 725) (150 x 70% = 105). Normal - Compression builds up quickly and evenly to the specified compression for each cylinder. Piston Rings Leaking - Compression is low on the first stroke. Compression builds up with the following strokes, but does not reach normal. Compression improves considerably when you add oil. Valves Leaking - Compression is low on the first stroke. Compression usually does not build up on the following strokes. Compression does not improve much when you add oil. If two adjacent cylinders have lower than normal compression, and injecting oil into the cylinders does not increase the compression, the cause may be a head gasket leaking between the cylinders.

Tools Required

J 35667-A Cylinder Head Leakdown Tester or equivalent

1. Disconnect the battery ground negative cable.
2. Remove the spark plugs. Refer to «Spark Plug Replacement»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/testing-diagnostics/#engine-controls-48l-53l-60l-introduction) in Engine Controls - 4.8L, 5.3L, and 6.0L.
3. Rotate the crankshaft to place the piston in the cylinder being tested at top dead center (TDC) of the compression stroke.
4. Install the J 35667-A or equivalent.
5. Apply shop air pressure to the J 35667-A and adjust according to the manufacturers instructions.
6. Record the cylinder leakage value. Cylinder leakage that exceeds 25 percent is considered excessive and may require component service. In excessive leakage situations, inspect for the following conditions: Air leakage noise at the throttle body or air inlet hose that may indicate a worn or burnt intake valve or a broken valve spring. Air leakage noise at the exhaust system tailpipe that may indicate a worn or burnt exhaust valve or a broken valve spring. Air leakage noise from the crankcase, oil level indicator tube, or oil fill tube that may indicate worn piston rings, a damaged piston, a worn or scored cylinder bore, a damaged engine block or a damaged cylinder head. Air bubbles in the cooling system may indicate a damaged cylinder head or a damaged cylinder head gasket.
7. Perform the leakage test on the remaining cylinders and record the values.

Oil Consumption Diagnosis

Oil Consumption Diagnosis

Oil Pressure Diagnosis and Testing

Tools Required

1. J 21867 Pressure Gage. See «Special Tools»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-introduction__special-tools) .
2. J 42907 Oil Pressure Testing Tool. See «Special Tools»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-introduction__special-tools) .

1. With the vehicle on a level surface, run the vehicle for a few minutes. Allow adequate drain down time, 2-3 minutes, and measure the oil level.
2. If required, add the recommended grade engine oil and fill the crankcase until the oil level measures full on the oil level indicator.
3. Run the engine briefly, 10-15 seconds, and verify low or no oil pressure on the vehicle gage or light.
4. Listen for a noisy valve train or a knocking noise.
5. Inspect for the following conditions: Oil diluted by water or glycol antifreeze Foamy oil
6. Remove the oil filter and install the J 42907 . See «Special Tools»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-introduction__special-tools) .
7. Install J 21867 or equivalent to the . See «Special Tools»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-introduction__special-tools) . J 42907 . See «Special Tools»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-introduction__special-tools) .
8. Run the engine and measure the engine oil pressure.
9. Compare the readings to «Engine Mechanical Specifications (LR4 VIN V)»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-introduction__engine-mechanical-specifications-lr4-vin-v) or «Engine Mechanical Specifications (LM7 VIN T)»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-introduction__engine-mechanical-specifications-lm7-vin-t) or «Engine Mechanical Specifications (L33 VIN B)»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-introduction__engine-mechanical-specifications-l33-vin-b) or «Engine Mechanical Specifications (L59 VIN Z)»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-introduction__engine-mechanical-specifications-l59-vin-z) or «Engine Mechanical Specifications (LQ4 VIN U)»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-introduction__engine-mechanical-specifications-lq4-vin-u) or «Engine Mechanical Specifications (LQ9 VIN N)»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-introduction__engine-mechanical-specifications-lq9-vin-n) .
10. If the engine oil pressure is below specifications, inspect the engine for one or more of the following conditions: Oil pump worn or dirty Refer to «Oil Pump Cleaning and Inspection»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-repair-instructions-2-of-3__oil-pump-cleaning-and-inspection) . Oil pump-to-engine block bolts loose Refer to «Oil Pump, Pump Screen and Deflector Installation»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-repair-instructions-3-of-3__oil-pump-pump-screen-and-deflector) . Oil pump screen loose, plugged, or damaged Oil pump screen O-ring seal missing or damaged Malfunctioning oil pump pressure relief valve Excessive bearing clearance Cracked, porous, or restricted oil galleries Oil gallery plugs missing or incorrectly installed Refer to «Engine Block Plug Installation»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-repair-instructions-3-of-3) . Broken valve lifters Repair as necessary.
11. If the oil pressure reading on the J 21867 or equivalent is within specifications, inspect for the following conditions:. See «Special Tools»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-introduction__special-tools) . Plugged or incorrect oil filter and/or malfunctioning oil bypass valve Malfunctioning oil pressure gage or sensor Repair as necessary.

Oil Leak Diagnosis

Oil Leak Diagnosis

Crankcase Ventilation System Inspection/Diagnosis

Crankcase Ventilation System Inspection/Diagnosis

Diagnostic Aids

The chirping noise may be intermittent due to moisture on the drive belt(s) or the accessory drive pulley(s). In order to duplicate the customer's concern, it may be necessary to spray a small amount of water onto the drive belt(s). If spraying water onto the drive belt(s) duplicates the symptom, cleaning the accessory drive pulley(s) may be the most probable solution.

A loose or improper installation of a body or suspension component, or other item(s) on the vehicle may also cause the chirping noise.

Test Description

The number(s) below refer to the step(s) in the diagnostic table.

1. 2: The chirping noise may not be engine related. This step is to verify that the engine is making the noise. If the engine is not making the noise do not proceed any further in this table.
2. 3: The noise may be an internal engine noise. Remove the drive belt(s) and operate the engine for a few seconds, this will verify if the chirping noise is related to the drive belt(s) or not. With the drive belt(s) removed the water pump will not operate and the engine may overheat. Also diagnostic trouble codes (DTCs) may set when the engine is operated with the drive belt(s) removed.
3. 4: Inspect the drive belt(s) for signs of pilling. Pilling is the small balls, pills, or strings in the drive belt grooves caused by the accumulation of rubber dust.
4. 6: Misalignment of the accessory drive pulley(s) may be caused from improper mounting or incorrect installation of an accessory drive component, or the pulley may be bent inward or outward from a previous repair. Test for a misaligned accessory drive pulley using a straight edge in the pulley grooves across two or three pulleys. If a misaligned pulley is found, refer to that accessory drive component for the proper removal and installation procedure for that pulley.
5. 10: Inspection of the fasteners can eliminate the possibility that a incorrect bolt, nut, spacer, or washer was installed.
6. 12: Inspection of the accessory drive pulley(s) should include inspecting for bends, dents, or other damage to the pulley(s) that would prevent the drive belt(s) from seating properly in the pulley grooves or on the smooth surface of the pulley when the back side of the drive belt is used to drive the pulley.
7. 14: Replacing the drive belt(s) when it is not damaged or there is not excessive pilling will only be a temporary repair.

Drive Belt Chirping Diagnosis

A loose or improper installation of a body, or suspension component, or other item(s) on the vehicle may cause the squeal noise.

If the squeal is intermittent, verify that it is not the accessory drive component(s) by varying their load(s), making sure they are operating to their maximum capacity. An overcharged air conditioning (A/C) system, a power steering system restriction or the incorrect fluid, or a failing generator are suggested items to inspect.

The number(s) below refer to the step(s) in the diagnostic table.

1. 2: The squeal may not be engine related. This step is to verify that the engine is making the noise. If the engine is not making the noise do not proceed further in this table
2. 3: The squeal may be an internal engine noise. Remove the drive belt(s) and operate the engine for a few seconds, this will verify if the squealing noise is related to the drive belt(s) or an accessory drive component. With the drive belt(s) removed the water pump will not operate and the engine may overheat. Also diagnostic trouble codes (DTCs) may set when the engine is operated with the drive belt(s) removed.
3. 4: This test is to verify that an accessory drive component(s) does not have a seized bearing. With the belt(s) removed, test the bearings in the accessory drive component(s) for smooth operation. Also test the accessory drive component(s) with the engine operating by varying the load on the accessory drive component(s) to verify that the component(s) is operating properly.
4. 5: This test is to verify that the drive belt(s) tensioner(s) are not operating properly. If the drive belt tensioner(s) are not operating properly, proper belt tension may not be achieved to keep the drive belt(s) from slipping which could cause a squealing noise.
5. 6: This test is to verify that the drive belt(s) is not too long, which would prevent the drive belt tensioner(s) from operating properly. Also if the incorrect length drive belt(s) was installed, it may not be routed correctly and may be turning an accessory drive component in the incorrect direction.
6. 7: Misalignment of the accessory drive pulley(s) may be caused from improper mounting or incorrect installation of a accessory drive component, or the pulley may be bent inward or outward from a previous repair. Test for a misaligned pulley using a straight edge in the pulley grooves across two or three pulleys. If a misaligned pulley is found, refer to that accessory drive component for the proper removal and installation procedure for that pulley.
7. 8: Inspect the accessory drive pulley(s) to verify that they are the correct diameter or width. Using a known good vehicle, compare the accessory drive pulleys.

Drive Belt Squeal Diagnosis

The drive belt(s) will not cause the whine.

If the whine is intermittent, verify that it is not the accessory drive component(s) by varying their loads, making sure they are operating to their maximum capacity. An overcharged air conditioning (A/C) system, a power steering system restriction or the incorrect fluid, or a failing generator are suggested items to inspect.

The number(s) below refer to the step(s) in the diagnostic table.

1. 3: This test is to verify that the whine is being caused by the accessory drive component(s). Remove the drive belt(s) and operate the engine for a few seconds, this will verify if the whining noise is related to the accessory drive component. With the drive belt(s) removed the water pump will not operate and the engine may overheat. Also diagnostic trouble codes (DTCs) may set when the engine is operated with the drive belt(s) removed.
2. 4: This inspection should include checking the drive belt tensioner and the drive belt idler pulley bearings. The drive belt(s) may have to be installed and the accessory drive components operated separately by varying their loads. Refer to the suspected accessory drive component for the proper removal and installation procedure.

Drive Belt Whine Diagnosis

Vibration from the engine operating may cause a body component or another part of the vehicle to make rumbling noise.

The drive belt(s) may have a condition that can not be seen or felt. Sometimes replacing the drive belt(s) may be the only repair for the symptom.

If after replacing the drive belt(s) and completing the diagnostic table, the rumbling is only heard with the drive belt(s) installed, there might be an accessory drive component failure. Varying the load on the accessory drive component(s) may aid in identifying which component is causing the rumbling noise.

The number(s) below refer to the step(s) in the diagnostic table.

1. 2: This test is to verify that the symptom is present during diagnosing. Other vehicle components may cause a similar symptom.
2. 3: This test is to verify that the drive belt(s) is causing the rumbling. Rumbling may be confused with an internal engine noise due to the similarity in the description. Remove only one drive belt at a time if the vehicle has multiple drive belts. Operate the engine for a few seconds, this will verify if the rumbling noise is related to the drive belt(s) or not. With the drive belt(s) removed the water pump will not operate and the engine may overheat. Also diagnostic trouble codes (DTCs) may set when the engine is operated with the drive belt(s) removed.
3. 4: Inspect the drive belt(s) to ensure that the drive belt(s) is not the cause of the noise. Small cracks across the ribs of the drive belt(s) will not cause the noise. Belt separation is identified by the plys of the belt separating, this may be seen at the edge of the belt or felt as a lump in the belt.
4. 5: Small amounts of pilling is a normal condition and acceptable. When the pilling is severe the drive belt(s) does not have a smooth surface for proper operation.

Drive Belt Rumbling Diagnosis

The accessory drive components may have an affect on engine vibration. An overcharged air conditioning (A/C) system, a power steering system restriction, or the incorrect fluid, or an extra load placed on the generator are suggested items to inspect. To help identify an intermittent or an improper condition, vary the loads on the accessory drive components.

The number(s) below refer to the step(s) in the diagnostic table.

1. 2: This test is to verify that the vibration is present during diagnosing. Other vehicle components may cause a similar symptom such as the exhaust system, or the drivetrain.
2. 3: This test is to verify that the drive belt(s) or accessory drive components may be causing the vibration. Remove the drive belt(s) and operate the engine for a few seconds, this will verify if the vibration is related to the drive belt(s) or not. With the drive belt(s) removed the water pump will not operate and the engine may overheat. Also diagnostic trouble codes (DTCs) may set when the engine is operated with the drive belt(s) removed.
3. 4: The drive belt(s) may cause a vibration. While the drive belt(s) is removed this is the best time to inspect the condition of the drive belt(s).
4. 6: Inspection of the fasteners can eliminate the possibility that a incorrect bolt, nut, spacer, or washer was installed.
5. 8: This step should only be performed if the fan is driven by the drive belt. Inspect the engine cooling fan for bent, twisted, loose, or cracked blades. Inspect the fan clutch for smooth operation. Inspect for a bent fan shaft or bent mounting flange.
6. 9: Inspect the water pump drive shaft for being bent. Also inspect the water pump bearings for smooth operation and excessive play. Compare the water pump with a known, good water pump.
7. 10: Accessory drive component brackets that are bent, cracked, or loose may put an extra strain on that accessory drive component causing it to vibrate.

Drive Belt Vibration Diagnosis

If the drive belt(s) repeatedly falls off the accessory drive pulley(s), this may be caused by a pulley misalignment.

An extra load that is quickly applied or released by an accessory drive component may also cause the drive belt(s) to fall off. Verify that the accessory drive component(s) are operating properly.

If the drive belt(s) is the incorrect length, the drive belt tensioner may not maintain the proper tension on the drive belt(s).

The number(s) below refer to the step(s) in the diagnostic table.

1. 2: This inspection is to verify the condition of the drive belt(s). Damage may have occurred to the drive belt(s) when the drive belt(s) fell off the pulley. Inspect the drive belt(s) for cuts, tears, sections of ribs missing, or damaged belt plys.
2. 4: Misalignment of the accessory drive pulley(s) may be caused from improper mounting or incorrect installation of a accessory drive component, or the pulley may be bent inward or outward from a previous repair. Test for a misaligned pulley using a straight edge in the pulley grooves across two or three pulleys. If a misaligned pulley is found, refer to that accessory drive component for the proper removal and installation procedure of that pulley.
3. 5: Inspection of the accessory drive pulley(s) should include inspecting for bends, dents, or other damage that would prevent the drive belt from seating properly in the pulley grooves or on the smooth surface of a pulley when the back side of the drive belt(s) is used to drive the pulley.
4. 6: Accessory drive component brackets that are bent or cracked will also cause the drive belt(s) to fall off.
5. 7: Inspection of the fasteners can eliminate the possibility that a incorrect bolt, nut, spacer, or washer was installed. Missing, loose, or incorrect fasteners may cause pulley misalignment from the accessory drive bracket(s) moving under load. Over tightening the fasteners may cause misalignment of the accessory component bracket(s).

Drive Belt Falls Off Diagnosis

Excessive wear on a drive belt(s) is usually caused by incorrect installation or the incorrect drive belt(s) for the application.

Minor misalignment of the accessory drive pulley(s) will not cause excessive wear, but will probably cause the drive belt(s) to make a noise or fall off.

Excessive misalignment of the accessory drive pulley(s) will cause excessive wear and may also make the drive belt(s) fall off.

The number(s) below refer to the step(s) in the diagnostic table.

1. 2: This inspection is to verify that the drive belt(s) is correctly installed on all of the accessory drive pulleys. Wear on the drive belt(s) may be caused by mis-positioning the drive belt(s) by one or more grooves on a pulley(s).
2. 3: The installation of a drive belt(s) that is too wide or too narrow will cause wear on the drive belt(s). The drive belt(s) ribs should match all of the grooves on the pulleys.
3. 4: This inspection is to verify that the drive belt(s) is not contacting any part of the engine or body while the engine is operating. There should be sufficient clearance when the accessory drive components load varies. The drive belt(s) should not come in contact with an engine or a body component when snapping the throttle.

Drive Belt Excessive Wear Diagnosis

Scheme 54

1. Remove the drive belt. Refer to «Drive Belt Replacement - Accessory (4.8L, 5.3L, and 6.0L Engines)»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-repair-instructions-1-of-3) or «Drive Belt Replacement - Accessory (5.3L Engine w/RPO HP2)»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-repair-instructions-1-of-3) or «Drive Belt Replacement - Air Conditioning»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-repair-instructions-1-of-3) .
2. Move the drive belt tensioner through its full travel. The movement should feel smooth. There should be no binding. The tensioner should return freely.
3. If any binding is observed, replace the drive belt tensioner. Refer to «Drive Belt Tensioner Replacement - Accessory»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-repair-instructions-1-of-3) or «Drive Belt Tensioner Replacement - Air Conditioning»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-repair-instructions-1-of-3) .
4. Install the drive belt. Refer to of «Drive Belt Replacement - Accessory (4.8L, 5.3L, and 6.0L Engines)»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-repair-instructions-1-of-3) or «Drive Belt Replacement - Accessory (5.3L Engine w/RPO HP2)»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-repair-instructions-1-of-3) or «Drive Belt Replacement - Air Conditioning»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-repair-instructions-1-of-3) .

Crankcase Ventilation System Description

A closed crankcase ventilation system is used in order to provide a more complete scavenging of the crankcase vapors. Fresh air from the throttle body is supplied to the crankcase, mixed with blow-by gases, and then passed through a crankcase ventilation valve into the intake manifold.

The primary control is through the crankcase ventilation valve which meters the flow at a rate depending on manifold vacuum. To maintain idle quality, the crankcase ventilation valve restricts the flow when intake manifold vacuum is high. If abnormal operating conditions arise, the system is designed to allow excessive amounts of blow-by gases to back flow through the crankcase vent tube into the engine air inlet to be consumed by normal combustion.

Filtered fresh air is routed from up-stream of the throttle blade to the front of the right rocker arm cover via a formed rubber hose. To reduce the potential of oil pullover into the throttle bore area due to back flow of the ventilation system, the fitting in the right rocker arm cover is shielded from the rocker arms. From there fresh air and gases are routed through the crankcase and up to the opposite rocker arm cover where the positive crankcase ventilation (PCV) valve is located. Gases are then routed through a hose to the intake manifold.

Drive Belt System Description

The drive belt system consists of the following components

1. The drive belt
2. The drive belt tensioner
3. The drive belt idler pulley
4. The crankshaft balancer pulley
5. The accessory drive component mounting brackets
6. The accessory drive components The power steering pump, if belt driven The generator The A/C compressor, if equipped The engine cooling fan, if belt driven The water pump, if belt driven The vacuum pump, if equipped The air compressor, if equipped

The drive belt system may use 1 belt or 2 belts. The drive belt is thin so that it can bend backwards and has several ribs to match the grooves in the pulleys. There also may be a V-belt style belt used to drive certain accessory drive components. The drive belts are made of different types of rubbers - chloroprene or EPDM - and have different layers or plys containing either fiber cloth or cords for reinforcement.

Both sides of the drive belt may be used to drive the different accessory drive components. When the back side of the drive belt is used to drive a pulley, the pulley is smooth.

The drive belt is pulled by the crankshaft balancer pulley across the accessory drive component pulleys. The spring loaded drive belt tensioner keeps constant tension on the drive belt to prevent the drive belt from slipping. The drive belt tensioner arm will move when loads are applied to the drive belt by the accessory drive components and the crankshaft.

The drive belt system may have an idler pulley, which is used to add wrap to the adjacent pulleys. Some systems use an idler pulley in place of an accessory drive component when the vehicle is not equipped with the accessory.

Scheme 55

The 4.8, 5.3, and 6.0 liter V8 engines are identified as RPO LR4 VIN V (4.8L), RPO LM7 VIN T (5.3L), RPO L33 VIN B (5.3L), RPO L59 VIN Z (5.3L), RPO LQ4 VIN U (6.0L), and RPO LQ9 VIN N (6.0L).

Camshaft and Drive System

A billet steel 1 piece camshaft is supported by 5 bearings pressed into the engine block. The camshaft has a machined camshaft position (CMP) reluctor ring incorporated between the fourth and fifth bearing journals. The camshaft timing sprocket is mounted to the front of the camshaft and is driven by the crankshaft sprocket through the camshaft timing chain. The splined crankshaft sprocket is positioned to the crankshaft by a key and keyway. The crankshaft sprocket splines drive the oil pump driven gear. A retaining plate mounted to the front of the engine block maintains camshaft location.

Crankshaft

The crankshaft is cast nodular iron. The crankshaft is supported by 5 crankshaft bearings. The bearings are retained by crankshaft bearing caps which are machined with the engine block for proper alignment and clearance. The crankshaft journals are undercut and rolled. The center main journal is the thrust journal. A crankshaft position (CKP) reluctor ring is press fit mounted at the rear of the crankshaft. The reluctor ring is not serviceable separately. All crankshafts will have a short rear flange, at the crankshaft rear oil seal area. Certain 4.8L manual transmissions and 6.0L applications require a spacer between the rear of the crankshaft and the flywheel for proper flywheel positioning. Longer flywheel bolts are required in applications using the spacer.

Cylinder Heads

The cylinder heads are cast aluminum and have pressed in place powdered metal valve guides and valve seats. Passages for the engine coolant air bleed system are at the front of each cylinder head. The valve rocker arm covers are retained to the cylinder head by 4 center mounted rocker arm cover bolts.

Engine Block

The engine block is a cam-in-block deep skirt 90 degree V configuration with 5 crankshaft bearing caps. For most applications, the engine block is cast iron. RPO L33 applications have an aluminum engine block. The 5 crankshaft bearing caps each have 4 vertical M10 and 2 horizontal M8 mounting bolts. The camshaft is supported by 5 camshaft bearings pressed into the block.

Exhaust Manifolds

The exhaust manifolds are a 1 piece cast iron design. The exhaust manifolds direct exhaust gasses from the combustion chambers to the exhaust system. Each manifold also has an externally mounted heat shield that is retained by bolts.

Intake Manifold

The intake manifold is a 1 piece composite design that incorporates brass threaded inserts for mounting the fuel rail, throttle body, evaporative emission (EVAP) canister purge solenoid valve, wire harness stud, engine sight shield and sight shield bracket. Each side of the intake manifold is sealed to the cylinder head by a nonreusable silicone sealing gasket and nylon carrier assembly. The electronically actuated throttle body bolts to the front of the intake manifold. The throttle body is sealed by a 1 piece push in place silicone gasket. The fuel rail assembly with 8 separate fuel injectors is retained to the intake by 4 bolts. The injectors are seated into their individual manifold bores with O-ring seals to provide sealing. A fuel rail stop bracket is retained to the rear of the left cylinder head by a mounting bolt. The manifold absolute pressure (MAP) sensor is installed and retained to the top rear of the intake manifold and sealed by an O-ring seal. The EVAP solenoid valve is mounted to the top front of the intake manifold and retained by 1 bolt. There are no coolant passages within the intake manifold.

Oil Pan

The structural oil pan is cast aluminum. Incorporated into the design are the oil filter mounting boss, drain plug opening, oil level sensor mounting bore, and oil pan baffle. The oil pan cover and oil level sensor mount to the sides of the oil pan. The alignment of the structural oil pan to the rear of the engine block and transmission bell housing is critical.

Piston and Connecting Rod Assembly

The pistons are cast aluminum. The pistons use 2 compression rings and 1 oil control ring assembly. The piston is a low friction, lightweight design with a flat or recessed top and barrel shaped skirt. The piston pins are chromium steel and are a full-floating design. The connecting rods are powdered metal. The connecting rods are fractured at the connecting rod journal and then machined for the proper clearance. All applications use a piston with a graphite coated skirt.

Valve Rocker Arm Cover Assemblies

The valve rocker arm covers are cast aluminum and use a pre-molded silicon gasket for sealing. Mounted to each rocker cover are the coil and bracket assemblies. Incorporated into the left cover is the positive crankcase ventilation (PCV) system dirty air passage. Incorporated into the right cover is the oil fill tube and engine fresh air passage.

Valve Train

Motion is transmitted from the camshaft through the hydraulic roller valve lifters and tubular pushrods to the roller type rocker arms. The nylon valve lifter guides position and retain the valve lifters. The valve rocker arms for each bank of cylinders are mounted on pedestals, pivot supports. Each rocker arm is retained on the pivot support and cylinder head by a bolt. Valve lash is net build.

New Product Information

The purpose of New Product Information is to highlight or indicate important product changes from the previous model year.

Changes may include one or more of the following items

1. Torque values and/or fastener tightening strategies
2. Changed engine specifications
3. New sealants and/or adhesives
4. Disassembly and assembly procedure revisions
5. Engine mechanical diagnostic procedure revisions
6. New special tools required
7. A component comparison from the previous year

Torque Values and/or Fastener Tightening Strategies

1. All fasteners and threaded holes on the 4.8, 5.3, and 6.0 liter engines utilize metric threads.
2. All M11 cylinder head bolts are the same length and have a common torque/angle tightening strategy.

Changed Engine Specifications

Piston pin specifications have been revised.

Disassembly and Assembly Procedure Revisions

1. For certain applications, a spacer plate has been added between the flywheel and rear of the crankshaft. It is necessary to remove the spacer plate prior to removal and installation of the crankshaft rear oil seal and clutch pilot bearing.
2. Applications with RPO HP2 do not have a flywheel. The crankshaft balancer MUST be removed before the engine assembly is removed from the vehicle and installed after the engine is installed.
3. All applications use a full-floating piston pin design.

Engine Mechanical Diagnostic Procedure Revisions

All diagnosis on a vehicle should follow a logical process. Strategy based diagnostics is a uniform approach for repairing all systems. The diagnostic flow may always be used in order to resolve a system problem. The diagnostic flow is the place to start when repairs are necessary. For a detailed explanation, refer to Strategy Based Diagnosis in General Information or Diagnostic Starting Point - Engine Mechanical .

New Special Tools Required

1. J 41479-2A has been developed to install the rear oil seal on RPO HP2 equipped vehicles. See «Special Tools»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-introduction__special-tools) .
2. J 45849 has been developed to remove the pilot bushing on RPO HP2 equipped vehicles when the crankshaft is replaced. See «Special Tools»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-introduction__special-tools) .
3. J 45949 has been developed to install the pilot bushing on RPO HP2 equipped vehicles when the crankshaft has been replaced. See «Special Tools»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-introduction__special-tools) .
4. J 46093 has been developed to hold the crank stationary on RPO HP2 equipped vehicles to allow for the on-vehicle removal and installation of the crankshaft balancer. See «Special Tools»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-introduction__special-tools) .
5. Refer to «Special Tools»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-introduction__special-tools) .

A Component Comparison from the Previous Year

1. All M11 cylinder head bolts are the same length.
2. All applications use full-floating design piston pins.
3. 5.3 liter RPO L33 applications have an aluminum engine block.

Scheme 56

Engine lubrication is supplied by a gerotor type oil pump assembly. The pump is mounted on the front of the engine block and driven directly by the crankshaft sprocket. The pump gears rotate and draw oil from the oil pan sump through a pick-up screen and pipe. The oil is pressurized as it passes through the pump and is sent through the engine block oil galleries. Contained within the oil pump assembly is a pressure relief valve that maintains oil pressure within a specified range. Pressurized oil is directed through the lower gallery to the full flow oil filter where harmful contaminants are removed. A bypass valve is incorporated into the oil pan, at the oil filter boss, which will permit oil flow in the event the filter becomes restricted. At the rear of the block, oil is then directed to the upper main oil galleries which are drilled just above the camshaft assembly. From there oil is then directed to the crankshaft and camshaft bearings. Oil that has entered the upper main oil galleries also pressurizes the valve lifter assemblies and is then pumped through the pushrods to lubricate the valve rocker arms and valve stems. Oil returning to the pan is directed by the crankshaft oil deflector. Oil pressure and crankcase level are each monitored by individual sensors.

An external oil cooler is available on certain applications, all 6.0L. Oil is directed from the oil pump, through the lower main oil gallery to the full flow oil filter. Oil is then directed through the oil pan outlet oil gallery, located in the left rear of the oil pan, and to the external oil cooler via a hose assembly. Oil flows through the oil cooler and returns to the engine at the oil pan inlet oil gallery, located in the left rear of the oil pan. Oil is then directed to the upper main oil galleries and the remainder of the engine assembly.

Cleanliness and Care

1. Throughout this section, it should be understood that proper cleaning and protection of machined surfaces and friction areas is part of the repair procedure. This is considered standard shop practice even if not specifically stated.
2. When any internal engine parts are serviced, care and cleanliness is important.
3. When components are removed for service, they should be marked, organized or retained in a specific order for assembly. Refer to «Separating Parts»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-introduction__separating-parts) .
4. At the time of installation, components should be installed in the same location and with the same mating surface as when removed.
5. An automobile engine is a combination of many machined, honed, polished and lapped surfaces with tolerances that are measured in millimeters or thousandths of an inch. These surfaces should be covered or protected to avoid component damage.
6. A liberal coating of clean engine oil should be applied to friction areas during assembly.
7. Proper lubrication will protect and lubricate friction surfaces during initial operation.

Separating Parts

Separate, mark, or organize the following components

1. Piston and the piston pin
2. Piston to the specific cylinder bore
3. Piston rings to the piston
4. Connecting rod to the crankshaft journal
5. Connecting rod to the bearing cap A paint stick or etching/engraving type tool are recommended. Stamping the connecting rod or cap near the bearing bore may affect component geometry.
6. Crankshaft main and connecting rod bearings
7. Camshaft and valve lifters
8. Valve lifters, lifter guides, pushrods and rocker arm assemblies
9. Valve to the valve guide
10. Valve spring and shim to the cylinder head location
11. Engine block main bearing cap location and direction
12. Oil pump drive and driven gears

J 28410 Gasket Remover

Gasket Use and Applying Sealants

1. Do not use any gasket again unless specified.
2. Gaskets that can be used again will be identified in the service procedure.
3. Do not apply sealant to any gasket or sealing surface unless called out in the service information.

Separating Components

1. Use a rubber mallet to separate components.
2. Bump the part sideways to loosen the components.
3. Bumping should be done at bends or reinforced areas to prevent distortion of parts.

Cleaning Gasket Surfaces

1. Remove all gasket and sealing material from the part using the J 28410 or equivalent.
2. Care must be used to avoid gouging or scraping the sealing surfaces.
3. Do not use any other method or technique to remove sealant or gasket material from a part.
4. Do not use abrasive pads, sand paper, or power tools to clean the gasket surfaces. These methods of cleaning can cause damage to the component sealing surfaces. Abrasive pads also produce a fine grit that the oil filter cannot remove from the oil. This grit is abrasive and has been known to cause internal engine damage.

Assembling Components

1. When assembling components, use only the sealant specified or equivalent in the service procedure.
2. Sealing surfaces should be clean and free of debris or oil.
3. Specific components such as crankshaft oil seals or valve stem oil seals may require lubrication during assembly.
4. Components requiring lubrication will be identified in the service procedure.
5. When applying sealant to a component, apply the amount specified in the service procedure.
6. Tighten bolts to specifications. Do not overtighten.

Pipe Joint Compound

1. Pipe joint compound is a pliable sealer that does not completely harden. This type sealer is used where two non-rigid parts, such as the oil pan and the engine block, are assembled together.
2. Do not use pipe joint compound in areas where extreme temperatures are expected. These areas include: exhaust manifold, head gasket, or other surfaces where gasket eliminator is specified.
3. Follow all safety recommendations and directions that are on the container. To remove the sealant or the gasket material, refer to «Replacing Engine Gaskets»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-introduction) .
4. Apply the pipe joint compound to a clean surface. Use a bead size or quantity as specified in the procedure. Run the bead to the inside of any bolt holes.
5. Apply a continuous bead of pipe joint compound to one sealing surface. Sealing surfaces to be resealed must be clean and dry.
6. Tighten the bolts to specifications. Do not overtighten.

RTV Sealer

1. RTV sealant hardens when exposed to air. This type sealer is used where two non-rigid parts, such as the intake manifold and the engine block, are assembled together.
2. Do not use RTV sealant in areas where extreme temperatures are expected. These areas include: exhaust manifold, head gasket, or other surfaces where a gasket eliminator is specified.
3. Follow all safety recommendations and directions that are on the container. To remove the sealant or the gasket material, refer to «Replacing Engine Gaskets»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-introduction) .
4. Apply RTV to a clean surface. Use a bead size as specified in the procedure. Run the bead to the inside of any bolt holes.
5. Assemble components while RTV is still wet, within 3 minutes. Do not wait for RTV to skin over.
6. Tighten bolts to specifications. Do not overtighten.

Anaerobic Sealer

1. Anaerobic gasket eliminator hardens in the absence of air. This type sealer is used where two rigid parts, such as castings, are assembled together. When two rigid parts are disassembled and no sealer or gasket is readily noticeable, the parts were probably assembled using a gasket eliminator.
2. Follow all safety recommendations and directions that are on the container. To remove the sealant or the gasket material, refer to «Replacing Engine Gaskets»(/chevrolet/cab-chassis-silverado-3500/2004-2007/remont/mechanical/#engine-mechanical-48l-53l-60l-introduction) .
3. Apply a continuous bead of gasket eliminator to one flange. Surfaces to be sealed must be clean and dry.
4. Spread the sealer evenly with your finger to get a uniform coating on the sealing surface.
5. Tighten bolts to specifications. Do not overtighten.
6. After properly tightening the fasteners, remove the excess sealer from the outside of the joint.

Tools and Equipment

Special tools are listed and illustrated throughout this section with a complete listing at the end of the section. These tools, or their equivalents, are specially designed to quickly and safely accomplish the operations for which they are intended. The use of these special tools will also minimize possible damage to engine components. Some precision measuring tools are required for inspection of certain critical components. Torque wrenches and a torque angle meter are necessary for the proper tightening of various fasteners.

To properly service the engine assembly, the following items should be readily available

1. Approved eye protection and safety gloves
2. A clean, well lit, work area
3. A suitable parts cleaning tank
4. A compressed air supply
5. Trays or storage containers to keep parts and fasteners organized
6. An adequate set of hand tools
7. Approved engine repair stand
8. An approved engine lifting device that will adequately support the weight of the components

Special Tools

Special Tools Illustration Tool Number/Description J 3049-A Valve Lifter Remover J 5824-01 Clutch Alignment Tool J 6125-1B Slide Hammer J 7872 Magnetic Base Dial Indicator Set J 8001 Dial Indicator Set J 8037 Piston Ring Compressor J 8062 Valve Spring Compressor - Head Off J 8087 Cylinder Bore Gage J 8089 Carbon Removal Brush J 8433-1 Puller Bar J 8520 Cam Lobe Lift Indicator J 9666 Valve Spring Tester J 21366 Converter Holding Strap J 21867 Pressure Gage J 22794 Spark Plug Port Adapter J 24270 Cylinder Bore Ridge Reamer J 28410 Gasket Remover J 28428-E High Intensity Black Light Kit J 33049 Camshaft Bearing Service Set J 35667-A Cylinder Head Leakdown Tester J 37378-1 Valve Guide Reamer J 38606 Valve Spring Compressor J 41476 Front and Rear Cover Alignment Tool J 41478 Crankshaft Front Oil Seal Installer J 41479 Crankshaft Rear Oil Seal Installer J 41479-2A Crankshaft Rear Oil Seal Installation Guide J 41480 Front and Rear Cover Alignment J 41556 Connecting Rod Guide J 41558 Crankshaft Sprocket Remover J 41665 Crankshaft Balancer and Sprocket Installer J 41712 Oil Pressure Switch Socket J 41798 Engine Lift Bracket J 41816 Crankshaft Balancer Remover J 41816-2 Crankshaft End Protector J 41818 Crankshaft Bearing Cap Remover J 42371 Hydraulic Clutch Line Separator J 42385-100 Head/Main Bolt Thread Repair Kit J 42385-200 Common Thread Repair Kit J 42385-300 Fixtures and Hardware Kit J 42386-A Flywheel Holding Tool J 42907 Oil Pressure Tester J 43276 Clutch Pilot Bearing Remover J 43690 Rod Bearing Clearance Checking Tool J 43690-100 Rod Bearing Checking Tool - Adapter Kit J 45059 Angle Meter J 45299 Engine Preluber J 45849 Bearing Remover J 45949 Pilot Bearing and Flywheel Locator Installer J 46093 Rotor and Flexplate Holding Tool

Scheme 57

Scheme 58

Scheme 59

Scheme 60

Scheme 61

Scheme 62

Scheme 63

Scheme 64

Scheme 65

Scheme 66

Scheme 67

Scheme 68

Scheme 69

Scheme 70

Scheme 71

Scheme 72

Scheme 73

Scheme 74

Scheme 75

Scheme 76

Scheme 77

Scheme 78

Scheme 79

Scheme 80

Scheme 81

Scheme 82

Scheme 83

Scheme 84

Scheme 85

Scheme 86

Scheme 87

See also:
• Drive Belt Replacement - Accessory (4.8L, 5.3L, and 6.0L Engines)
• Crankshaft Balancer Replacement (4.8L, 5.3L, and 6.0L Engines)
• Crankshaft Balancer Replacement (5.3L Engine w/RPO HP2)
• Spark Plug Inspection
• Detonation/Spark Knock
• Piston, Connecting Rod, and Bearing Installation
• Cylinder Head Cleaning and Inspection
• Cylinder Head Replacement - Left
• Cylinder Head Replacement - Right
• Spark Plug Replacement
• Oil Pump Cleaning and Inspection
• Oil Pump, Pump Screen and Deflector Installation
• Engine Block Plug Installation
• Disassembled Views
• New Product Information
• Base Engine Misfire without Internal Engine Noises
• Base Engine Misfire with Abnormal Internal Lower Engine Noises
• Base Engine Misfire with Abnormal Valve Train Noise
• Base Engine Misfire with Coolant Consumption
• Base Engine Misfire with Excessive Oil Consumption
• Engine Noise on Start-Up, but Only Lasting a Few Seconds
• Upper Engine Noise, Regardless of Engine Speed
• Lower Engine Noise, Regardless of Engine Speed
• Engine Noise Under Load
• Engine Will Not Crank - Crankshaft Will Not Rotate
• Coolant in Combustion Chamber
• Coolant in Engine Oil
• Engine Compression Test
• Oil Consumption Diagnosis
• Oil Pressure Diagnosis and Testing
• Crankcase Ventilation System Inspection/Diagnosis
• Special Tools
• Engine Mechanical Specifications (LR4 VIN V)
• Engine Mechanical Specifications (LM7 VIN T)
• Engine Mechanical Specifications (L33 VIN B)
• Engine Mechanical Specifications (L59 VIN Z)
• Engine Mechanical Specifications (LQ4 VIN U)
• Engine Mechanical Specifications (LQ9 VIN N)
• Fastener Tightening Specifications
• Diagnostic Starting Point - Engine Mechanical
• Separating Parts
