HVAC System - Automatic: Specifications Chevrolet Aveo I facelift

Automatic HVAC System 9 illustrations

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Control Assembly Retaining Screws2N.m18 lb in

Scheme 1

Scheme 1: HVAC Schematics

Scheme 2

Scheme 2

Scheme 3

Scheme 3

Scheme 4

Scheme 4

Scheme 5

Scheme 5

Scheme 6

Scheme 6: HVAC Component Views
CalloutComponent Name
1Recirculation Actuator
2Blower Motor Resistor
3Blower Motor
4HVAC Control and Blower Switch

Scheme 7

Scheme 7
CalloutComponent Name
1A/C Compressor Clutch
2A/C Refrigerent Pressure Sensor

Scheme 8

Scheme 8
CalloutComponent Name
1Shaft Nut
2Compressor Shaft
3Shaft and Guide Pin Assembly Cylinder
4Rear Head O-Ring
5Suction Reed
6Valve Plate
7Rear Head Gasket
8Retaining Ring
9Control Valve O-Ring
10Compressor Control Valve
11Rear Head Compressor
12Adaptor Compressor
13Pressure Relief Valve O-Ring
14Pressure Relief Valve
15Adaptor Bolt
16Through-Bolt
17Clutch Hub Key
18Clutch and Hub Keyway
19Through-Gasket
20Oil Drain Plug
21Bearing
22Compressor Housing-to-Cylinder O-Ring
23Race
24Thrust Washer
25Compressor Housing
26Shaft Seal O-Ring
27Shaft Lip Seal
28Seal Retaining Ring
29Clutch Coil
30Rotor Pulley
31Pulley Bearing
32Pulley Bearing-to-Head Retaining Ring
33Drive Plate Clutch

Scheme 9

Scheme 9
CalloutComponent Name
1Shaft Bolt
2Shaft Bolt Washer
3Clutch and Drive Assembly
4Air Gap Shim
5Retaining Ring
6Pulley and Bearing Assembly
7Retaining Ring
8Coil and Housing Assembly
9Through Bolt
10Retaining Ring
11Lip Seal Assembly
12Front Head
13Front Head Gasket
14Discharge Reed Retainer
15Discharge Reed
16Front Valve Plate
17Suction Reed
18Parallel Locating Pin
19Front Compressor Cylinder
20Swash Plate and Shaft Assembly
21Piston Shoe
22Piston Assembly
23Thrust Bearing
24Thrust Bearing
25Cylinder O-Ring
26Bushing
27Roll Locating Pin
28Rear Compressor Cylinder
29Main Shaft Bearing
30Rear Valve Plate
31Rear Head Gasket
32Rear Head
