Tools Required Chevrolet Avalanche I

Tools Required

J 42059 Cigarette Lighter Socket Remover

Scheme 130

Scheme 131

Scheme 132

1. Remove the power supply fuse.
2. Lift up the front cover of the socket.
3. Insert the J 42059 into the socket sleeve. Tilt the tool so that the tool fits into the slots on the sides of the socket sleeve.
4. Hold the plastic ring in place. Pull the socket gently out of the assembly in order to remove the outlet.
5. Remove the electrical connector from the socket.

Scheme 133

1. Connect the electrical connector to the socket.
2. Insert the plastic ring into the opening and snap the plastic ring into place.
3. Insert the socket through the plastic ring gently by hand until the socket ring is sealed.
4. Install the power supply fuse.

Scheme 134

Scheme 135

1. Remove the instrument panel (I/P) cluster trim bezel. Refer to «BEZEL REPLACEMENT - INSTRUMENT PANEL (I/P) CLUSTER»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .
2. Remove the center console, if equipped. Refer to «CONSOLE REPLACEMENT (WITH CONSOLE MOUNTING BRACKET)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) or «CONSOLE REPLACEMENT (W/O CONSOLE MOUNTING BRACKET)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .
3. Open the I/P compartment door.
4. Remove the bolts retaining the lower trim panel to the I/P assembly.
5. Disconnect all of the electrical connectors (1, 2, 3).
6. Remove the lower trim panel from the I/P assembly.

Scheme 136

Scheme 137

1. Connect all of the electrical connectors (1, 2, 3). NOTE: Refer to «FASTENER NOTICE»(/chevrolet/avalanche/i-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__fastener-notice) in Cautions and Notices.
2. Install the bolts connecting the lower trim panel to the I/P assembly. Tighten Tighten the bolts to 2 N.m (18 lb in).
3. Install the center console, if equipped. Refer to «CONSOLE REPLACEMENT (WITH CONSOLE MOUNTING BRACKET)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) or «CONSOLE REPLACEMENT (W/O CONSOLE MOUNTING BRACKET)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .
4. Install the I/P cluster trim bezel. Refer to «INSTRUMENT PANEL CLUSTER (IPC) REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .

Scheme 138

1. Remove the I/P trim panel. Refer to «TRIM PANEL REPLACEMENT - INSTRUMENT PANEL (I/P) UPPER»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .
2. Remove the center console, if equipped. Refer to «CONSOLE REPLACEMENT (WITH CONSOLE MOUNTING BRACKET)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) or «CONSOLE REPLACEMENT (W/O CONSOLE MOUNTING BRACKET)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .
3. Disconnect the negative battery cable. Refer to BATTERY NEGATIVE CABLE DISCONNECT/CONNECT PROCEDURE .
4. Remove the driver side knee bolster. Refer to «KNEE BOLSTER REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .
5. Remove the lower I/P trim panel. Refer to «INSTRUMENT PANEL (I/P) TRIM PANEL REPLACEMENT - LOWER»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .
6. Remove the passenger side air bag module. Refer to «REMOVAL & INSTALLATION (PASSENGER-SIDE)»(/chevrolet/avalanche/i-2001-2006/remont/airbag/#supplemental-inflatable-restraint-system__removal-installation-passenger-side) in SIR.
7. Remove the radio. Refer to RADIO REPLACEMENT in Entertainment.
8. Remove the HVAC control. Refer to HVAC CONTROL MODULE REPLACEMENT in HVAC Systems-Automatic or HVAC CONTROL MODULE REPLACEMENT in HVAC Systems-Manual.
9. Remove the accessory switch housing. Refer to «ACCESSORY SWITCH REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .
10. Remove the left air louver housing. Refer to DEFLECTOR REPLACEMENT - INSTRUMENT PANEL AIR - LEFT in Heating, Ventilation and Air Conditioning.
11. Remove the steering column. Refer to STEERING COLUMN REPLACEMENT in Steering Wheel and Column.
12. Remove the communication interface module, if equipped. Refer to COMMUNICATION INTERFACE MODULE REPLACEMENT in Cellular Communication.
13. Remove the remote control door lock receiver module, if equipped. Refer to REMOTE CONTROL DOOR LOCK RECEIVER REPLACEMENT in Keyless Entry.
14. Remove the data link connector from the I/P. Refer to DATA LINK CONNECTOR REPLACEMENT in Data Link Communications.
15. Remove the park brake release lever from the I/P. Refer to «PARK BRAKE RELEASE HANDLE ASSEMBLY»(/chevrolet/avalanche/i-2001-2006/remont/mechanical-hydraulic/#disc-brakes) in Park Brake.
16. Remove the I/P cluster. Refer to «INSTRUMENT PANEL CLUSTER (IPC) REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .
17. Remove both front window air ducts from the I/P assembly.
18. Remove the harness from the I/P. Refer to INSTRUMENT PANEL ELECTRICAL CENTER OR JUNCTION BLOCK REPLACEMENT - LEFT and INSTRUMENT PANEL ELECTRICAL CENTER OR JUNCTION BLOCK REPLACEMENT - RIGHT .
19. Remove the I/P assembly retaining bolts (3) and nuts (4).
20. Remove all harness hold down retainers from the I/P assembly.
21. Remove the I/P assembly from the vehicle.

Scheme 139

1. Install the I/P assembly to the vehicle.
2. Install the harness hold down retainers to the I/P assembly.
3. Install the I/P assembly retaining bolts (3) and nuts (4). Ensure the wire harness is routed to all of the openings.
4. Install the harness to the I/P. Refer to INSTRUMENT PANEL ELECTRICAL CENTER OR JUNCTION BLOCK REPLACEMENT - LEFT and INSTRUMENT PANEL ELECTRICAL CENTER OR JUNCTION BLOCK REPLACEMENT - RIGHT .
5. Install both front window air duct to the I/P assembly.
6. Install the I/P cluster assembly. Refer to «INSTRUMENT PANEL CLUSTER (IPC) REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .
7. Install the park brake release lever to the I/P. Refer to «PARK BRAKE RELEASE HANDLE ASSEMBLY»(/chevrolet/avalanche/i-2001-2006/remont/mechanical-hydraulic/#disc-brakes) in Park Brake.
8. Install the data link connector to the I/P. Refer to DATA LINK CONNECTOR REPLACEMENT in Data Link Communications.
9. Install the remote control door lock receiver module, if equipped. Refer to REMOTE CONTROL DOOR LOCK RECEIVER REPLACEMENT in Keyless Entry.
10. Install the CIM, if equipped. Refer to COMMUNICATION INTERFACE MODULE REPLACEMENT in Cellular Communication.
11. Install the steering column. Refer to STEERING COLUMN REPLACEMENT in Steering Wheel and Column.
12. Install the left air louver housing. Refer to DEFLECTOR REPLACEMENT - INSTRUMENT PANEL AIR - LEFT in Heating, Ventilation and Air Conditioning.
13. Install the accessory switch housing. Refer to «ACCESSORY SWITCH REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .
14. Install the HVAC control. Refer to HVAC CONTROL MODULE REPLACEMENT in HVAC Systems-Automatic or HVAC CONTROL MODULE REPLACEMENT in HVAC Systems-Manual.
15. Install the radio. Refer to RADIO REPLACEMENT in Entertainment.
16. Install the passenger side airbag module. Refer to «REMOVAL & INSTALLATION (PASSENGER-SIDE)»(/chevrolet/avalanche/i-2001-2006/remont/airbag/#supplemental-inflatable-restraint-system__removal-installation-passenger-side) in SIR.
17. Install the lower trim panel. Refer to «INSTRUMENT PANEL (I/P) TRIM PANEL REPLACEMENT - LOWER»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .
18. Install the driver side knee bolster. Refer to «KNEE BOLSTER REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .
19. Connect the negative battery cable. Refer to BATTERY NEGATIVE CABLE DISCONNECT/CONNECT PROCEDURE .
20. Install the center console, if equipped. Refer to «CONSOLE REPLACEMENT (WITH CONSOLE MOUNTING BRACKET)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) or «CONSOLE REPLACEMENT (W/O CONSOLE MOUNTING BRACKET)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .
21. Install the I/P trim panel. Refer to «TRIM PANEL REPLACEMENT - INSTRUMENT PANEL (I/P) UPPER»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .

Scheme 140

Scheme 141

Scheme 142

Scheme 143

Scheme 144

Scheme 145

Scheme 146

Scheme 147

1. Remove the I/P trim panel. Refer to «TRIM PANEL REPLACEMENT - INSTRUMENT PANEL (I/P) UPPER»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .
2. Remove the center console, if equipped. Refer to «CONSOLE REPLACEMENT (WITH CONSOLE MOUNTING BRACKET)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) or «CONSOLE REPLACEMENT (W/O CONSOLE MOUNTING BRACKET)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .
3. Disconnect the negative battery cable. Refer to BATTERY NEGATIVE CABLE DISCONNECT/CONNECT PROCEDURE .
4. Remove the lower I/P trim panel. Refer to «INSTRUMENT PANEL (I/P) TRIM PANEL REPLACEMENT - LOWER»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .
5. Remove the passenger side air bag module. Refer to «REMOVAL & INSTALLATION (PASSENGER-SIDE)»(/chevrolet/avalanche/i-2001-2006/remont/airbag/#supplemental-inflatable-restraint-system__removal-installation-passenger-side) in SIR.
6. Remove the radio. Refer to RADIO REPLACEMENT in Entertainment.
7. Remove the HVAC control. Refer to HVAC CONTROL MODULE REPLACEMENT in HVAC Systems-Automatic or HVAC CONTROL MODULE REPLACEMENT in HVAC Systems-Manual.
8. Remove the accessory switch housing. Refer to «ACCESSORY SWITCH REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .
9. Remove the left air louver housing. Refer to DEFLECTOR REPLACEMENT - INSTRUMENT PANEL AIR - LEFT in Heating, Ventilation and Air Conditioning.
10. Remove the steering column. Refer to STEERING COLUMN REPLACEMENT in Steering Wheel and Column.
11. Remove the CIM, if equipped. Refer to COMMUNICATION INTERFACE MODULE REPLACEMENT in Cellular Communication.
12. Remove the remote control door lock receiver module, if equipped. Refer to REMOTE CONTROL DOOR LOCK RECEIVER REPLACEMENT in Keyless Entry.
13. Remove the data link connector from the I/P. Refer to DATA LINK CONNECTOR REPLACEMENT in Data Link Communications.
14. Remove the park brake release lever from the I/P. Refer to «PARK BRAKE RELEASE HANDLE ASSEMBLY»(/chevrolet/avalanche/i-2001-2006/remont/mechanical-hydraulic/#disc-brakes) in Park Brake.
15. Remove the I/P cluster. Refer to «INSTRUMENT PANEL CLUSTER (IPC) REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .
16. Remove both front window air duct from the I/P assembly.
17. Remove the harness from the I/P. Refer to INSTRUMENT PANEL ELECTRICAL CENTER OR JUNCTION BLOCK REPLACEMENT - LEFT and INSTRUMENT PANEL ELECTRICAL CENTER OR JUNCTION BLOCK REPLACEMENT - RIGHT .
18. Remove the I/P assembly retaining nuts (4) and bolts (3).
19. Remove all harness hold down retainers from the I/P assembly.
20. Remove the I/P assembly from the vehicle.
21. Remove the I/P upper brackets.
22. Disconnect all the electrical connectors from the wiring harness junction block. Refer to BODY WIRING HARNESS JUNCTION BLOCK REPLACEMENT in Wiring Systems.
23. Remove the transfer case control module from the bracket, if equipped. Refer to TRANSFER CASE SHIFT CONTROL MODULE REPLACEMENT in Transfer Case NV6 246 - NP8.
24. Remove the antenna cable from the cross car duct.
25. Remove the cross car duct. Refer to AIR DISTRIBUTOR DUCT REPLACEMENT in Heating, Ventilation and Air Conditioning.
26. Remove the amplifier, if equipped. Refer to AMPLIFIER REPLACEMENT in Entertainment.
27. Separate the I/P harness from the carrier. Do not remove the I/P harness from the vehicle.
28. If replacing the HVAC module, remove the right side of the carrier from the vehicle to gain access to the module.
29. Remove the I/P center support bracket bezel (1). Important: Remove all of the parts of the I/P carrier assembly from the vehicle as a unit.
30. Remove the I/P center support bracket bolt.
31. Remove the I/P carrier retaining bolts. The left side is shown, the right side is similar.
32. Remove the I/P carrier top bolts (1).
33. Remove the I/P carrier (1) from the vehicle.

Scheme 148

Scheme 149

Scheme 150

Scheme 151

Scheme 152

Scheme 153

Scheme 154

Scheme 155

1. Position the I/P carrier (1) in the vehicle. NOTE: Refer to «FASTENER NOTICE»(/chevrolet/avalanche/i-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__fastener-notice) in Cautions and Notices.
2. Install the I/P carrier top bolts (1). Tighten Tighten the bolts to 50 N.m (37 lb ft).
3. Install the I/P carrier retaining bolts. The left side is shown, the right is similar. Tighten Tighten the bolts to 50 N.m (37 lb ft).
4. Install the I/P center support bracket bolt. Tighten Tighten the bolt to 25 N.m (18 lb ft).
5. Install the I/P center support bracket bezel (1).
6. Install the right side of the carrier to the vehicle, if the HVAC module was removed.
7. Install the retaining bolts. Tighten Tighten the bolts to 50 N.m (37 lb ft).
8. Attach the I/P harness to the carrier.
9. Install the amplifier, if equipped. Refer to AMPLIFIER REPLACEMENT in Entertainment.
10. Install the cross car duct. Refer to AIR DISTRIBUTOR DUCT REPLACEMENT in Heating, Ventilation and Air Conditioning.
11. Install the antenna cable to the cross car duct.
12. Install the transfer case control module to the bracket, if equipped. Refer to TRANSFER CASE SHIFT CONTROL MODULE REPLACEMENT in Transfer Case NV6 246 - NP8.
13. Connect all of the electrical connectors to the wiring harness junction block. Refer to BODY WIRING HARNESS JUNCTION BLOCK REPLACEMENT in Wiring Systems.
14. Install the I/P upper brackets. Tighten Tighten the retaining bolts to 2 N.m (18 lb in).
15. Install the I/P assembly to the vehicle.
16. Install the I/P assembly retaining bolts (3) and nuts (4). Ensure the wire harness is routed to all of the openings. Tighten Tighten the retaining bolts and nuts to 9 N.m (80 lb in).
17. Install the harness hold down retainers to the I/P assembly.
18. Install the harness to the I/P. Refer to INSTRUMENT PANEL ELECTRICAL CENTER OR JUNCTION BLOCK REPLACEMENT - LEFT and INSTRUMENT PANEL ELECTRICAL CENTER OR JUNCTION BLOCK REPLACEMENT - RIGHT .
19. Install both front window air duct to the I/P assembly.
20. Install the I/P cluster assembly. Refer to «INSTRUMENT PANEL CLUSTER (IPC) REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .
21. Install the park brake release lever to the I/P. Refer to «PARK BRAKE RELEASE HANDLE ASSEMBLY»(/chevrolet/avalanche/i-2001-2006/remont/mechanical-hydraulic/#disc-brakes) in Park Brake.
22. Install the data link connector to the I/P. Refer to DATA LINK CONNECTOR REPLACEMENT in Data Link Communications.
23. Install the remote control door lock receiver module, if equipped. Refer to REMOTE CONTROL DOOR LOCK RECEIVER REPLACEMENT in Keyless Entry.
24. Install the CIM, if equipped. Refer to COMMUNICATION INTERFACE MODULE REPLACEMENT in Cellular Communication.
25. Install the steering column. Refer to STEERING COLUMN REPLACEMENT in Steering Wheel and Column.
26. Install the left air louver housing. Refer to DEFLECTOR REPLACEMENT - INSTRUMENT PANEL AIR - LEFT in Heating, Ventilation and Air Conditioning.
27. Install the accessory switch housing. Refer to «ACCESSORY SWITCH REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .
28. Install the HVAC control. Refer to HVAC CONTROL MODULE REPLACEMENT in HVAC Systems-Automatic or HVAC CONTROL MODULE REPLACEMENT in HVAC Systems-Manual.
29. Install the radio. Refer to RADIO REPLACEMENT in Entertainment.
30. Install the passenger side airbag module. Refer to «REMOVAL & INSTALLATION (PASSENGER-SIDE)»(/chevrolet/avalanche/i-2001-2006/remont/airbag/#supplemental-inflatable-restraint-system__removal-installation-passenger-side) in SIR.
31. Install the lower trim panel. Refer to «INSTRUMENT PANEL (I/P) TRIM PANEL REPLACEMENT - LOWER»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .
32. Install the driver side knee bolster. Refer to «KNEE BOLSTER REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .
33. Connect the negative battery cable. Refer to BATTERY NEGATIVE CABLE DISCONNECT/CONNECT PROCEDURE .
34. Install the center console, if equipped. Refer to «CONSOLE REPLACEMENT (WITH CONSOLE MOUNTING BRACKET)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) or «CONSOLE REPLACEMENT (W/O CONSOLE MOUNTING BRACKET)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .
35. Install the I/P trim panel. Refer to «TRIM PANEL REPLACEMENT - INSTRUMENT PANEL (I/P) UPPER»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .

Scheme 156

1. Open the console lid and remove the four retaining screws.
2. Remove the console door from the console.

Scheme 157

1. Install the console door to the console. NOTE: Refer to «FASTENER NOTICE»(/chevrolet/avalanche/i-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__fastener-notice) in Cautions and Notices.
2. Install the four retaining screws. Tighten Tighten the four retaining screws to 1.6 N.m (14 lb in).
3. Close the lid and ensure the lid is properly aligned.

Scheme 158

1. Remove the console compartment door. Refer to «DOOR REPLACEMENT - CONSOLE COMPARTMENT»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .
2. Remove the bin retaining screws.
3. Remove the 4 lower bolts.
4. Remove the storage bin from the console.

Scheme 159

1. Install the storage bin in the console. NOTE: Refer to «FASTENER NOTICE»(/chevrolet/avalanche/i-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__fastener-notice) in Cautions and Notices.
2. Install the bin retaining screws. Tighten Tighten the retaining screws to 1.6 N.m (14 lb in).
3. Install the 4 lower bolts Tighten Tighten the 4 bolts to 3.5 N.m (31 lb in).
4. Install the console compartment door. Refer to «DOOR REPLACEMENT - CONSOLE COMPARTMENT»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .

Scheme 160

1. Remove the console upper bezel. Refer to «BEZEL REPLACEMENT - FLOOR CONSOLE (NON-LUXURY UPPER)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) or «BEZEL REPLACEMENT - FLOOR CONSOLE (LUXURY UPPER)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) or «BEZEL REPLACEMENT - FLOOR CONSOLE (NON-LUX LOWER)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .
2. From the back of the bezel remove the retaining screws.
3. Remove the clock from the bezel.

Scheme 161

1. Install the clock to the bezel. NOTE: Refer to «FASTENER NOTICE»(/chevrolet/avalanche/i-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__fastener-notice) in Cautions and Notices.
2. Install the retaining screws. Tighten Tighten the retaining screws to 2 N.m (17 lb in).
3. Install the bezel to the console. Refer to «BEZEL REPLACEMENT - FLOOR CONSOLE (NON-LUXURY UPPER)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) or «BEZEL REPLACEMENT - FLOOR CONSOLE (LUXURY UPPER)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) or «BEZEL REPLACEMENT - FLOOR CONSOLE (NON-LUX LOWER)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .

Scheme 162

1. Remove both front seats. Refer to SEAT REPLACEMENT - FRONT BUCKET in Seats.
2. If equipped with a Bose® amplifier, remove the radio amp fuse located under the hood electrical center. Refer to Electrical Center Identification Views in Wiring Systems.
3. Remove the upper console bezel. Refer to «BEZEL REPLACEMENT - FLOOR CONSOLE (NON-LUXURY UPPER)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) or «BEZEL REPLACEMENT - FLOOR CONSOLE (LUXURY UPPER)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) or «BEZEL REPLACEMENT - FLOOR CONSOLE (NON-LUX LOWER)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .
4. Remove the cupholder. Refer to «CUPHOLDER REPLACEMENT (NON-LUXURY)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) or «CUPHOLDER REPLACEMENT (LUXURY)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) or «CUPHOLDER REPLACEMENT (REAR)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .
5. Remove the screws (1) retaining the console to the I/P.
6. Disconnect the wire connectors.
7. Remove the console assembly from the vehicle.
8. Remove the rear seat audio control from the console, if equipped. Refer to AUDIO CONTROL REPLACEMENT - REAR SEAT in Entertainment.

Scheme 163

1. Install the rear seat audio control to the console, if equipped. Refer to AUDIO CONTROL REPLACEMENT - REAR SEAT in Entertainment.
2. Install the console in the vehicle.
3. Connect the wire connectors.
4. Move the console forward in order to install the retaining screws. NOTE: Refer to «FASTENER NOTICE»(/chevrolet/avalanche/i-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__fastener-notice) in Cautions and Notices.
5. Install the 2 screws (1). Tighten Tighten the screws to 4 N.m (35 lb in).
6. Install the cupholder to the console. Refer to «CUPHOLDER REPLACEMENT (NON-LUXURY)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) or «CUPHOLDER REPLACEMENT (LUXURY)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) or «CUPHOLDER REPLACEMENT (REAR)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .
7. Install the upper console bezel. Refer to «BEZEL REPLACEMENT - FLOOR CONSOLE (NON-LUXURY UPPER)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) or «BEZEL REPLACEMENT - FLOOR CONSOLE (LUXURY UPPER)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) or «BEZEL REPLACEMENT - FLOOR CONSOLE (NON-LUX LOWER)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .
8. Install the radio amp fuse, if removed. Refer to Electrical Center Identification Views in Wiring Systems.
9. Install both front seats. Refer to SEAT REPLACEMENT - FRONT BUCKET in Seats.

Scheme 164

Scheme 165

Scheme 166

Scheme 167

1. If equipped with a Bose® amplifier, remove the radio amp fuse located under the hood electrical center. Refer to Electrical Center Identification Views in Wiring Systems.
2. Remove the floor console bezel. Refer to «BEZEL REPLACEMENT - FLOOR CONSOLE (NON-LUXURY UPPER)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) or «BEZEL REPLACEMENT - FLOOR CONSOLE (LUXURY UPPER)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) or «BEZEL REPLACEMENT - FLOOR CONSOLE (NON-LUX LOWER)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .
3. Remove the cupholder. Refer to «CUPHOLDER REPLACEMENT (NON-LUXURY)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) or «CUPHOLDER REPLACEMENT (LUXURY)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) or «CUPHOLDER REPLACEMENT (REAR)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .
4. Remove the bolts (1) retaining the console to the I/P.
5. Remove the console storage bin. Refer to «CONSOLE STORAGE BIN REPLACEMENT (EXPECT PRO)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .
6. Remove the center console end panel. Refer to «CENTER CONSOLE END PANEL REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .
7. Remove the 4 screws retaining the upper console bracket to the lower console bracket. The front 2 screws (1) are shown in the graphic.
8. Move both front seats to the fully forward.
9. Reposition the inboard seat track trim (1) in order to gain access to the rear console side panel screw (2).
10. Remove both rear console side panel screws.
11. Move both front seats to the fully rearward.
12. Remove both front console side panel screws (1).
13. Disconnect the floor console electrical connector.
14. Remove the console assembly from the vehicle.

Scheme 168

Scheme 169

Scheme 170

Scheme 171

1. Install the floor console.
2. Connect the floor console electrical connector. NOTE: Refer to «FASTENER NOTICE»(/chevrolet/avalanche/i-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__fastener-notice) in Cautions and Notices.
3. Install the screws (1) that retain the upper console bracket to the lower console bracket. Tighten Tighten the retaining screws to 2 N.m (18 lb in).
4. Install the bolts (1) retaining the console to the I/P. Tighten Tighten the bolts to 4 N.m (35 lb in).
5. Install both front console side panel screws (1). Tighten Tighten the screws to 2 N.m (18 lb in).
6. Move both front seats to the fully forward.
7. Install both rear console side panel screws (2). Tighten Tighten the retaining screws to 2 N.m (18 lb in).
8. Reposition the inboard seat track trim (1).
9. Connect the floor console electrical connector.
10. Install the center console end panel. Refer to «CENTER CONSOLE END PANEL REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .
11. Install the console storage bin. Refer to «CONSOLE STORAGE BIN REPLACEMENT (EXPECT PRO)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .
12. Install the cupholder to the console. Refer to «CUPHOLDER REPLACEMENT (NON-LUXURY)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) or «CUPHOLDER REPLACEMENT (LUXURY)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) or «CUPHOLDER REPLACEMENT (REAR)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .
13. Install the upper console bezel. Refer to «BEZEL REPLACEMENT - FLOOR CONSOLE (NON-LUXURY UPPER)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) or «BEZEL REPLACEMENT - FLOOR CONSOLE (LUXURY UPPER)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) or «BEZEL REPLACEMENT - FLOOR CONSOLE (NON-LUX LOWER)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .
14. Install the radio amp fuse. Refer to Electrical Center Identification Views in Wiring Systems.

Scheme 172

Scheme 173

1. Remove the I/P cluster bezel. Refer to «BEZEL REPLACEMENT - INSTRUMENT PANEL (I/P) CLUSTER»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .
2. Insert a flat bladed tool between the Bezel assembly and the console.
3. Pry the bezel from the console outwards partially in order to gain access to the connectors.
4. Disconnect the electrical connectors (1) and (2).
5. Remove the bezel from the console.

Scheme 174

Scheme 175

1. Place the bezel to the console.
2. Connect the electrical connectors (1) and (2).
3. Install the bezel to the console pushing on the corners till the retainers click in place.
4. Install the I/P cluster bezel. Refer to «BEZEL REPLACEMENT - INSTRUMENT PANEL (I/P) CLUSTER»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .

Scheme 176

1. Remove the I/P cluster bezel. Refer to «BEZEL REPLACEMENT - INSTRUMENT PANEL (I/P) CLUSTER»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .
2. Insert a flat bladed tool between the Bezel assembly and the console.
3. Pry the bezel from the console outwards partially in order to gain access to the connectors.
4. Disconnect the electrical connectors (1).
5. Remove the bezel from the console.

Scheme 177

1. Place the bezel to the console.
2. Connect the electrical connectors.
3. Install the bezel to the console by pushing on the corners until the retainers (1) click in place.
4. Install the I/P cluster bezel. Refer to «BEZEL REPLACEMENT - INSTRUMENT PANEL (I/P) CLUSTER»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .

Scheme 178

Scheme 179

Scheme 180

1. Remove the cluster bezel. Refer to «BEZEL REPLACEMENT - INSTRUMENT PANEL (I/P) CLUSTER»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .
2. Remove the upper bezel by inserting a flat bladed tool between the console and bezel.
3. Disconnect the electrical connectors (1, 2).
4. Remove the storage bin. Refer to «CONSOLE STORAGE BIN REPLACEMENT (EXPECT PRO)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .
5. Insert a flat bladed tool between the console and bezel in order to pry it out.
6. Remove the bezel from the console.

Scheme 181

Scheme 182

Scheme 183

1. Install the bezel to the console till it clicks in place.
2. Install the storage bin. Refer to «CONSOLE STORAGE BIN REPLACEMENT (EXPECT PRO)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .
3. Connect the electrical connectors (1, 2) to the upper bezel.
4. Install the upper bezel till it clicks in place.
5. Install the cluster bezel. Refer to «BEZEL REPLACEMENT - INSTRUMENT PANEL (I/P) CLUSTER»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .

Scheme 184

1. Remove both front seats. Refer to SEAT REPLACEMENT - FRONT BUCKET in Seats.
2. Remove the upper console bezel. Refer to «BEZEL REPLACEMENT - FLOOR CONSOLE (NON-LUXURY UPPER)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) or «BEZEL REPLACEMENT - FLOOR CONSOLE (LUXURY UPPER)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) or «BEZEL REPLACEMENT - FLOOR CONSOLE (NON-LUX LOWER)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .
3. Remove the cupholder. Refer to «CUPHOLDER REPLACEMENT (NON-LUXURY)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) or «CUPHOLDER REPLACEMENT (LUXURY)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) or «CUPHOLDER REPLACEMENT (REAR)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .
4. Remove the screws (1) retaining the console to the I/P.
5. Move the console assembly rearwards in order to disconnect the wire connectors.
6. Remove the console assembly from the vehicle.
7. Remove the console bin. Refer to «CONSOLE STORAGE BIN REPLACEMENT (EXPECT PRO)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .
8. Remove the amplifier and bracket from the console bracket.
9. Remove the vehicle sensor from the bracket. Refer to YAW RATE SENSOR/LATERAL ACCELEROMETER REPLACEMENT in Antilock Brake System.
10. Remove the fasteners retaining the console to the bracket.

Scheme 185

1. Install the console to the bracket. NOTE: Refer to «FASTENER NOTICE»(/chevrolet/avalanche/i-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__fastener-notice) in Cautions and Notices.
2. Install the fasteners retaining the console to the bracket. Tighten Tighten the fasteners to 2 N.m (17 lb in).
3. Install the vehicle sensor to the bracket. Refer to YAW RATE SENSOR/LATERAL ACCELEROMETER REPLACEMENT Antilock Brake System.
4. Install the amplifier and bracket to the console bracket. Refer to AMPLIFIER REPLACEMENT in Entertainment.
5. Install the console bin. Refer to «CONSOLE STORAGE BIN REPLACEMENT (EXPECT PRO)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .
6. Install the rear seat audio control to the console, if equipped. Refer to AUDIO CONTROL REPLACEMENT - REAR SEAT in Entertainment.
7. Install the console in the vehicle.
8. Connect the wire connectors.
9. Move the console forward in order to install the retaining screws.
10. Install the 2 screws (1). Tighten Tighten the screws to 4 N.m (35 lb in).
11. Install the cupholder to the console. Refer to «CUPHOLDER REPLACEMENT (NON-LUXURY)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) or «CUPHOLDER REPLACEMENT (LUXURY)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) or «CUPHOLDER REPLACEMENT (REAR)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .
12. Install the upper console bezel. Refer to «BEZEL REPLACEMENT - FLOOR CONSOLE (NON-LUXURY UPPER)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) or «BEZEL REPLACEMENT - FLOOR CONSOLE (LUXURY UPPER)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) or «BEZEL REPLACEMENT - FLOOR CONSOLE (NON-LUX LOWER)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .
13. Install both front seats. Refer to SEAT REPLACEMENT - FRONT BUCKET in Seats.

Scheme 186

Scheme 187

1. Remove the storage bin. Refer to «CONSOLE STORAGE BIN REPLACEMENT (EXPECT PRO)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .
2. Remove the rear cupholder from the end panel. Refer to «CUPHOLDER REPLACEMENT (NON-LUXURY)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) or «CUPHOLDER REPLACEMENT (LUXURY)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) or «CUPHOLDER REPLACEMENT (REAR)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .
3. Remove the 2 retaining screws.
4. Remove the top 2 retaining screws.
5. Move the end panel rearwards to gain access to the electrical connectors.
6. Remove the end panel from the console.
7. Remove the rear seat heater switch, if equipped. Refer to HEATED SEAT SWITCH REPLACEMENT - REAR in Seats.
8. Remove the rear seat audio controls, if equipped. Refer to AUDIO CONTROL REPLACEMENT - REAR SEAT in Entertainment.
9. Remove the power outlets from the end panel, if equipped. Refer to «ACCESSORY POWER RECEPTACLE REPLACEMENT - 12 VOLT»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .

Scheme 188

Scheme 189

1. Install the power outlets to the end panel, if equipped. Refer to «ACCESSORY POWER RECEPTACLE REPLACEMENT - 12 VOLT»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .
2. Install the rear seat audio control, if equipped. Refer to AUDIO CONTROL REPLACEMENT - REAR SEAT in Entertainment.
3. Install the rear seat heater switch, if equipped. Refer to «HEATED SEAT SWITCH REPLACEMENT - REAR»(/chevrolet/avalanche/i-2001-2006/remont/seats/#seat-system) in Seats.
4. Connect all electrical connectors.
5. Install the end panel to the console. NOTE: Refer to «FASTENER NOTICE»(/chevrolet/avalanche/i-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__fastener-notice) in Cautions and Notices.
6. Install the 2 top retaining screws. Tighten Tighten the screws to 1.6 N.m (14 lb in).
7. Install the 2 retaining screws. Tighten Tighten the screws to 1.6 N.m (14 lb in).
8. Install the rear cupholder to the end panel. Refer to «CUPHOLDER REPLACEMENT (NON-LUXURY)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) or «CUPHOLDER REPLACEMENT (LUXURY)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) or «CUPHOLDER REPLACEMENT (REAR)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .
9. Install the storage bin. Refer to «CONSOLE STORAGE BIN REPLACEMENT (EXPECT PRO)»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .

Scheme 190

1. Remove the I/P carrier. Refer to «INSTRUMENT PANEL (I/P) CARRIER REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .
2. Remove the driver's side hinge pillar trim panel. Refer to TRIM PANEL REPLACEMENT - HINGE PILLAR in Interior Trim.
3. Remove the driver's side seat, if equipped with power. Refer to SEAT REPLACEMENT - FRONT BUCKET .
4. Disconnect the electrical harness from the underhood electrical center. Refer to UNDERHOOD ELECTRICAL CENTER OR JUNCTION BLOCK REPLACEMENT .
5. Disconnect the wire harness from the hood, if equipped with underhood camp.
6. Remove the harness grommet from the cowl.
7. Remove the I/P harness from the vehicle.

Scheme 191

1. Install the I/P harness to the vehicle.
2. Install the harness grommet to the cowl.
3. Connect the wire harness to the hood, if equipped with underhood camp.
4. Connect the electrical harness from the underhood electrical center. Refer to UNDERHOOD ELECTRICAL CENTER OR JUNCTION BLOCK REPLACEMENT .
5. Install the driver's side seat, if equipped with power. Refer to SEAT REPLACEMENT - FRONT BUCKET
6. Install the driver's side hinge pillar trim panel. Refer to TRIM PANEL REPLACEMENT - HINGE PILLAR .
7. Install the I/P carrier. Refer to «INSTRUMENT PANEL (I/P) CARRIER REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .
