Specifications

ApplicationSpecification
MetricEnglish
Axle Flange Bolts, 10.5" Axle156 N.m115 lb ft
Bearing Cap Bolts, 8.6" Axle75 N.m55 lb ft
Bearing Cap Bolts, 9.5" Axle85 N.m63 lb ft
Bearing Cap Bolts, 9.75" Axle109 N.m80 lb ft
Bearing Cap Bolts, 10.5" Axle185 N.m136 lb ft
Brake Backing Plate Bolts, All Except 9.75" Axle140 N.m103 lb ft
Brake Hose Bracket Bolt22 N.m16 lb ft
Brake Pipe Bracket Bolt22 N.m16 lb ft
Brake Pipe Bracket Nut13 N.m115 lb in
Brake Pipe Junction Block Bolt22 N.m16 lb ft
Differential Bearing Adjuster Nut Lock Bolt, 9.5" Axle26 N.m19 lb ft
Differential Bearing Adjuster Nut Lock Bolt, 10.5" Axle27 N.m20 lb ft
Differential Housing Cover Bolts, All Except 9.75" Axle40 N.m30 lb ft
Drain Plug, All Except 9.75" Axle33 N.m24 lb ft
Drain Plug, 9.75" Axles27 N.m20 lb ft
Fill Plug, All Except 9.75" Axle33 N.m24 lb ft
Fill Plug, 9.75" Axle21 N.m15 lb ft
Jounce Bracket Bolt, 9.75" Axle12 N.m106 lb in
Pinion Bearing Cage Bolts, 10.5" Axle88 N.m65 lb ft
Pinion Shaft Lock Bolt, 8.6" Axle36 N.m27 lb ft
Pinion Shaft Lock Bolt, 9.5" Axle50 N.m37 lb ft
Pinion Yoke Nut, 9.75" Axle370 N.m273 lb ft
Propeller Shaft Retainer Bolts25 N.m18 lb ft
Ring Gear Bolts, 8.6" Axle120 N.m89 lb ft
Ring Gear Bolts, 9.5" Axle140 N.m103 lb ft
Ring Gear Bolts, 9.75" Axle178 N.m131 lb ft
Ring Gear Bolts, 10.5" Axle165 N.m122 lb ft
U-Bolt Nuts, 15 Series and 25 Series w/o 8.1 L Engine72 N.m53 lb ft
U-Bolt Nuts, 15 Series w/ RPO NYS and 25 Series w/ 8.1 L Engine150 N.m110 lb ft
Wheel Hub Nut, 10.5" Axle70 N.m52 lb ft

Fastener Tightening Specifications

Scheme 221

Scheme 221: Differential Adjustment Shims Specifications

Scheme 222

Scheme 222

Scheme 223

Scheme 223

Scheme 224

Scheme 224

Scheme 225

Scheme 225: Rear Axle Disassembled Views

Scheme 226

Scheme 226

Scheme 227

Scheme 227

Scheme 228

Scheme 228

Scheme 229

Scheme 229

Begin the system diagnosis by reviewing the system Description and Operation. Reviewing the Description and Operation information will help you determine the correct symptom diagnostic procedure when a malfunction exists. Reviewing the description and Operation information will also help you determine if the condition described by the customer is normal operation. Refer to SYMPTOMS - REAR DRIVE AXLE in order to identify the correct procedure for diagnosing the system and where the procedure is located.

Review the system and operation in order to familiarize yourself with the system functions. Refer to REAR DRIVE AXLE DESCRIPTION AND OPERATION

Visual/Physical Inspection

  1. Inspect the system for loose or missing fasteners.
  2. Inspect the system for leaking components.
  3. Inspect the system for obvious damage or conditions which may cause the symptom.

Symptom List

Refer to a system diagnostic procedure from the following list in order to diagnose the symptom

  1. «REAR DRIVE AXLE NOISES»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle)
  2. Noisy in Drive, See «Noisy in Drive Troubleshooting»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle)
  3. Noisy When Coasting, See «Noisy When Coasting Troubleshooting»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle)
  4. Intermittent Noise, See «Intermittent Noise Troubleshooting»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle)
  5. Constant Noise, See «Constant Noise Troubleshooting»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle)
  6. Noisy on Turns, See «Noisy on Turns Troubleshooting»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle)

Gear Noise

Gear noise or whine is audible from 32-89 km/h (20-55 mph) under 4 driving conditions

  1. Drive- Acceleration or heavy pull
  2. Road Load-Vehicle driving load or constant speed
  3. Float-Using enough throttle to keep the vehicle from driving the engine, the vehicle slows down gradually but the engine still pulls slightly
  4. Coast-Throttle is closed and the vehicle is in gear

Gear noise most frequently has periods where the noise is more prominent, usually between 48-64 km/h (30-40 mph) and 80-85 km/h (50-53 mph). Gear whine is corrected by either ring and pinion gear replacement or adjustment, depending on the mileage of the gearset.

Bearing Noise

Faulty bearings produce a rough growl or grating sound, rather than the whine typical of gear noise. Bearing noise/hum will pulsate at a constant vehicle speed. This indicates a bad pinion or a bad rear axle side bearing. This noise can be confused with rear wheel bearing noise. Inspect and replace the bearings and the affected components as required.

Rear Wheel Bearing Noise

A rough rear wheel bearing produces a noise which continues with the car coasting at low speed and the transmission in neutral. The noise may diminish some when the brakes are gently applied. The noise may also change when performing side-to-side maneuvers with the vehicle.

A rough/noisy rear wheel bearing can be heard by spinning the rear wheels by hand and listening at the hubs for the noise. Inspect and replace the bearings and the affected components as needed.

Knock at Low Speeds

A low speed knock can be caused by a differential case side gear bore that has worn oversize. Inspect the side gears and differential case and replace the components as necessary.

Backlash Clunk

Excessive backlash clunk under acceleration or deacceleration can be caused by any of the following

  1. Worn differential pinion shaft
  2. Worn differential pinion and/or side gear teeth
  3. Worn thrust washers
  4. Excessive clearance between the side gears and the axle shafts
  5. Excessive clearance between differential side gears and the bore in the case
  6. Excessive drive pinon and ring gear backlash

Inspect, adjust or replace the affected components as necessary.

Scheme 230

Scheme 230: Noisy in Drive Troubleshooting

Scheme 231

Scheme 231: Noisy When Coasting Troubleshooting

Scheme 232

Scheme 232: Intermittent Noise Troubleshooting

Scheme 233

Scheme 233: Constant Noise Troubleshooting

Scheme 234

Scheme 234: Noisy on Turns Troubleshooting

Tapered Roller Bearing Diagnosis

Consider the following factors when diagnosing bearing condition

  1. General condition of all parts during disassembly and inspection
  2. Classify the failure with the aid of the illustrations.
  3. Determine the cause.
  4. Make all repairs following recommended procedures.

Scheme 235

Scheme 235: Abrasive Roller Wear

Pattern on the races and the rollers caused by fine abrasives. Clean all of the parts and the housings. Check the seals and the bearings. Replace any leaky, rough, or noisy bearings.

Scheme 236

Scheme 236: Abrasive Step Wear

Pattern on the roller ends caused by fine abrasives. Clean all of the parts and the housings. Check the seals and the bearings. Replace any leaky, rough, or noisy bearings.

Scheme 237

Scheme 237: Galling

Metal smears on the roller ends due to overheating, lubricant failure, or lubricant overload. Replace the bearing. Check the seals. Check for proper lubrication.

Scheme 238

Scheme 238: Etching

Bearing surfaces appear gray or grayish black in color, with related etching away of material usually at roller spacing. Replace the bearings. Check the seals. Check for proper lubrication.

Scheme 239

Scheme 239: Bent Cage

A damaged cage due to improper handling or improper tool usage. Replace the bearing.

Scheme 240

Scheme 240: Cage Wear

Wear around the outside diameter of the cage and the roller pockets caused by abrasive material. Wear caused from inefficient lubrication. Clean the related parts and the housings. Check the seals. Replace the bearings.

Scheme 241

Scheme 241: Indentations

Surface depressions on the race and the rollers caused by hard particles of foreign matter. Clean all the parts and the housings. Check the seals. Replace rough or noisy bearings.

Scheme 242

Scheme 242: Frettage

Corrosion caused by small relative movement of parts with no lubrication. Replace the bearing. Clean the related parts. Check the seals. Check for proper lubrication.

Scheme 243

Scheme 243: Smears

Smearing of the metal due to slippage. Slippage can be caused by the following factors

  1. Poor fits
  2. Lubrication
  3. Overheating
  4. Overloads
  5. Handling damage

Replace the bearings. Clean the related parts. Check for proper fit and lubrication.

Scheme 244

Scheme 244: Stain Discoloration

Discoloration ranging from light brown to black. This discoloration is caused from incorrect lubrication or moisture. Reuse the bearing if you can remove the stains with light polishing. Reuse the bearing if there is no evidence of overheating. Check the seals and the related parts for damage.

Scheme 245

Scheme 245: Heat Discoloration

Heat discoloration ranges from faint yellow to dark blue. This discoloration results from overload or an incorrect lubricant. Excessive heat causes softening of the races or the rollers. In order to check for loss of temper on the races and the rollers, perform a file test. A file drawn over a tempered part will grab and cut the metal. A file drawn over a hard part will glide readily with no metal cutting. Replace the bearings if overheating damage is indicated. The tempered part will fail the file test. Check the seals and the other related parts.

Scheme 246

Scheme 246: Misalignment

Misaligned outer race due to a foreign object. Clean the related parts. Replace the bearing. Ensure the races are properly sealed.

Scheme 247

Scheme 247: Cracked Inner Race

Cracked race due to improper fit, cocking, or poor bearing seats. Replace the bearing. Correct bearing seats.

Scheme 248

Scheme 248: Fatigue Spalling

Flaked surface metal that results from fatigue. Replace the bearing. Clean all related parts.

Scheme 249

Scheme 249: Brinelling

Surface indentations in the race way caused by the rollers under impact loading or caused from vibration while the bearing is not rotating. Replace a rough or noisy bearing.

Straight Roller Bearing Diagnosis

Consider the following factors when diagnosing a bearing condition

  1. Note the general condition of all parts during disassembly and inspection.
  2. Classify the failure with the aid of the illustrations.
  3. Determine the cause.
  4. Make all repairs following recommended procedures.

Scheme 250

Scheme 250: Wear (Minor)

Light pattern on races and rollers can be caused by fine abrasives. Clean all of the parts including the housings. Check the seals. Replace the bearings if rough or noisy. Replace the shaft if damaged.

Scheme 251

Scheme 251: Wear (Major)

Heavy pattern on races and rollers can be caused by fine abrasives. Clean all of the parts including the housing. Check the seals. Replace the bearings if rough or noisy. Replace the shaft if damaged.

Scheme 252

Scheme 252: Brinelling

Surface indentations in the raceway can be caused by roll either under impact loading or vibration while the bearing is not rotating. Replace the bearing if rough or noisy. Replace the shaft if damaged.

Scheme 253

Scheme 253: Indentations

Surface depressions on race and rollers can be caused by hard particles of foreign material. Clean all of the parts, including the housing. Check the seals. Replace the bearings if rough or noisy. Replace the shaft if damaged.

Scheme 254

Scheme 254: Single Edge Pitting

Flaking of surface metal results from fatigue, usually at one edge of race and rollers. Replace the bearing. Clean all related parts. Replace the shaft if damaged.

Scheme 255

Scheme 255: Double Edge Pitting

Flaking of surface metal results from fatigue, usually at both edges of the race and rollers. Replace the bearing. Clean all related parts. Replace the shaft if damaged.

Scheme 256

Scheme 256: Misalignment

Outer misalignment due to a foreign object. Replace the bearing. Ensure races are properly seated. Replace the shaft if the bearing operating surface is damaged.

Scheme 257

Scheme 257: Frettage

Corrosion set up by a small relative movement of parts with no lubrication. Replace the bearing. Clean all the relative parts. Check the seals. Check for proper fit and lubrication. Replace the shaft if damaged.

Scheme 258

Scheme 258: Smears

Smearing of metal due to slippage. Slippage can be caused by poor fits, lack of lubrication, overheating, overloads or handling damage. Replace the bearing. Clean all the related parts. Check for proper fit and lubrication.

Rear Axle Lubricant Leak Diagnosis

Rear axle lubricant leaks can occur at the following locations

  1. Axle tube to differential carrier housing joint
  2. Axle shaft oil seal
  3. Axle housing porosity
  4. Differential housing cover gasket
  5. Drain plug
  6. Fill plug
  7. Pinion yoke oil seal
  8. Vent tube

Determining the Cause

While most rear axle leaks may be easy to find, determining the cause may not be. A thorough inspection of the area around the leak may assist in determining the cause of the leak.

Oil Seals

Lubricant leaks from a oil seal may be caused by any of the following

  1. An improperly installed seal
  2. A distorted seal
  3. A worn seal
  4. A worn shaft
  5. A brittle seal lip
  6. A hardened seal lip

To determine the actual cause of the leak, clean the area around the leak. Observe the area of the leak and determine the if the seal or another component is causing the leak. A worn seal surface will cause a leak at the sealing lip while a misaligned seal or a seal installed into a housing with an excessive bore will cause the seal to leak at the outside surface of the seal. Hardened or cracked seal lips usually indicate the axle is operating beyond the normal temperature limits for the axle, A seal whose sealing surface has been nicked or cut may indicate that the shaft has a rough, burred, or gouged surface and will need to be inspected before the seal can be replaced.

Gaskets

A leak at a gasket is usually caused by a poor fit of the components on each side of the gasket surface. Inspect each component for distortion and for nicks or gouges that may prohibit the gasket from sealing properly.

Rear Axle Housing

Rear axle housing lubricant leaks usually occur at the following locations

  1. Drain Plug
  2. Fill Plug

Drain and fill plug leaks are usually caused by a loose plug. These leaks can by repaired by either tightening the plug or by using an approved sealer on the threads on the plug.

Other leaks such as axle tube to differential carrier housing or porosity leaks require the replacement of the rear axle housing.

Scheme 259

Scheme 259: Lubricant Level Inspection - Rear Drive Axle (8.6 Inch Axle)
  1. Raise the vehicle. Refer to «LIFTING AND JACKING THE VEHICLE»(/chevrolet/avalanche/i-2001-2006/remont/hoistjack/#jacking-and-lifting-avalanche__lifting-and-jacking-the-vehicle) in General Information.
  2. Make sure the vehicle is level.
  3. Inspect the rear axle for leaks. Repair as necessary.
  4. Clean the area around the rear axle fill plug.
  5. Remove the rear axle fill plug.
  6. Fabricate a dipstick from a pipe cleaner or similar item. Form the pipe cleaner into an "L".
  7. Insert the pipe cleaner into the fill plug opening with the stem facing down.
  8. Remove the pipe cleaner and measure the distance from the bend in the pipe cleaner to the lubricant level. Specification The distance between the bend and the lubricant level should be 15-40 mm (0.6-1.6 in).
  9. If the measurement is greater than 40 mm (1.6 in), add lubricant until the level is between 15-40 mm (0.6-1.6 in) from the bottom edge of the fill plug hole. Use the proper fluid. NOTE: Refer to «FASTENER NOTICE»(/chevrolet/avalanche/i-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__fastener-notice) in Cautions and Notices.
  10. Install the rear axle fill plug. Tighten Tighten the rear axle fill plug to 33 N.m (24 lb ft).
  11. Lower the vehicle.

Scheme 260

Scheme 260: Lubricant Level Inspection - Rear Drive Axle (9.5, 10.5 Inch Axle)
  1. Raise the vehicle. Refer to «LIFTING AND JACKING THE VEHICLE»(/chevrolet/avalanche/i-2001-2006/remont/hoistjack/#jacking-and-lifting-avalanche__lifting-and-jacking-the-vehicle) in General Information.
  2. Make sure the vehicle is level.
  3. Inspect the rear axle for leaks. Repair as necessary.
  4. Clean the area around the rear axle fill plug.
  5. Remove the rear axle fill plug.
  6. Inspect the lubricant level. Specification The lubricant level should be between 0-10 mm (0-0.4 in) below the fill plug opening.
  7. If the level is low, add lubricant until the level is even with the bottom edge of the fill plug opening. Use the proper fluid. NOTE: Refer to «FASTENER NOTICE»(/chevrolet/avalanche/i-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__fastener-notice) in Cautions and Notices.
  8. Install the rear axle fill plug. Tighten Tighten the rear axle fill plug to 33 N.m (24 lb ft).
  9. Lower the vehicle.

Scheme 261

Scheme 261: Lubricant Level Inspection - Rear Drive Axle (9.75 Inch Axle)
  1. Raise the vehicle. Refer to «LIFTING AND JACKING THE VEHICLE»(/chevrolet/avalanche/i-2001-2006/remont/hoistjack/#jacking-and-lifting-avalanche__lifting-and-jacking-the-vehicle) in General Information.
  2. Ensure the vehicle is level.
  3. Inspect the rear axle for leaks. Repair as necessary.
  4. Clean the area around the rear axle fill plug.
  5. Remove the rear axle fill plug.
  6. Inspect the lubricant level. Specification The lubricant level should be between 0-6 mm (0-0.25 in) below the fill plug opening.
  7. If the level is low, add lubricant the until level is even with the bottom edge of the fill plug opening. Use the proper fluid. NOTE: Refer to «FASTENER NOTICE»(/chevrolet/avalanche/i-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__fastener-notice) in Cautions and Notices.
  8. Install the rear axle fill plug. Tighten Tighten the rear axle fill plug to 21 N.m (15 lb ft).
  9. Lower the vehicle.

Scheme 262

Scheme 262: Removal Procedure

Scheme 263

Scheme 263
  1. Raise the vehicle. Refer to «LIFTING AND JACKING THE VEHICLE»(/chevrolet/avalanche/i-2001-2006/remont/hoistjack/#jacking-and-lifting-avalanche__lifting-and-jacking-the-vehicle) in General Information.
  2. Remove the rear axle fill plug.
  3. Remove the rear axle housing cover bolts (1). Discard the rear axle housing cover bolts.
  4. Carefully remove the rear axle housing cover (2) and drain the lubricant into a suitable container.
  5. Remove any gasket material from the rear axle housing and/or the rear axle housing cover.
  6. Inspect the bottom of the rear axle housing for excessive metal particle accumulation. This accumulation is an indication of extreme wear.

Scheme 264

Scheme 264: Installation Procedure

Scheme 265

Scheme 265
  1. Install a new gasket and the rear axle housing cover (2). NOTE: Refer to «FASTENER NOTICE»(/chevrolet/avalanche/i-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__fastener-notice) in Cautions and Notices. Important: Do not reuse the rear axle housing cover bolts.
  2. Install the new rear axle housing cover bolts (1). Tighten Tighten the bolts to 40 N.m (30 lb ft).
  3. Fill the rear axle. Use the proper fluid.
  4. Install the rear axle fill plug. Tighten Tighten the rear axle fill plug to 33 N.m (24 lb ft).
  5. Lower the vehicle.

Scheme 266

Scheme 266: Removal Procedure

Scheme 267

Scheme 267
  1. Raise the vehicle. Refer to «LIFTING AND JACKING THE VEHICLE»(/chevrolet/avalanche/i-2001-2006/remont/hoistjack/#jacking-and-lifting-avalanche__lifting-and-jacking-the-vehicle) in General Information.
  2. Remove the rear axle fill plug.
  3. Remove the rear axle drain plug.
  4. Drain the lubricant into a suitable container.
  5. Inspect the drain plug for excessive metal particle accumulation. This accumulation is symptomatic of extreme wear.
  6. Clean the drain plug.

Installation Procedure

Note. Refer to FASTENER NOTICE in Cautions and Notices.

Scheme 268

Scheme 268: Installation Procedure

Scheme 269

Scheme 269
  1. Install the rear axle drain plug. Tighten Tighten the rear axle drain plug to 33 N.m (24 lb ft).
  2. Fill the rear axle. Use the proper fluid.
  3. Install the rear axle fill plug. Tighten Tighten the rear axle fill plug to 33 N.m (24 lb ft).
  4. Lower the vehicle.

Scheme 270

Scheme 270: Removal Procedure

Scheme 271

Scheme 271
  1. Raise the vehicle. Refer to «LIFTING AND JACKING THE VEHICLE»(/chevrolet/avalanche/i-2001-2006/remont/hoistjack/#jacking-and-lifting-avalanche__lifting-and-jacking-the-vehicle) in General Information.
  2. Remove the rear axle fill plug.
  3. Remove the rear axle drain plug.
  4. Drain the lubricant into a suitable container.
  5. Inspect the drain plug for excessive metal particle accumulation. This accumulation is symptomatic of extreme wear.
  6. Clean the drain plug.

Note. Refer to FASTENER NOTICE in Cautions and Notices.

Scheme 272

Scheme 272: Installation Procedure

Scheme 273

Scheme 273
  1. Install the rear axle drain plug. Tighten Tighten the rear axle drain plug to 27 N.m (20 lb ft).
  2. Fill the rear axle. Use the proper fluid.
  3. Install the rear axle fill plug. Tighten Tighten the rear axle fill plug to 21 N.m (15 lb ft).
  4. Lower the vehicle.

Removal Procedure

Important: Make note of the routing in order to aid in reassembly.

Scheme 274

Scheme 274: Removal Procedure

Scheme 275

Scheme 275

Scheme 276

Scheme 276
  1. Raise and support the vehicle.
  2. Remove the vent hose (1) from the top of the rear axle (2).
  3. Remove the vent hose (1) from the clip (2) on the frame.
  4. Remove the vent hose (1) from the clamp (2) on the filler hose.

Scheme 277

Scheme 277: Installation Procedure

Scheme 278

Scheme 278

Scheme 279

Scheme 279
  1. Install the vent hose (1) to the clamp (2) on the filler hose (3). Route the same way as when removed. Ensure that the hose is free of kinks and is routed clear of sharp objects. Ensure that the vent is not plugged.
  2. Install the vent hose (1) in the clip (2) on the frame.
  3. Install the vent hose (1) to the top of the rear axle (2).
  4. Remove the supports and lower the vehicle.

Scheme 280

Scheme 280: Removal Procedure
  1. Raise the vehicle. Refer to «LIFTING AND JACKING THE VEHICLE»(/chevrolet/avalanche/i-2001-2006/remont/hoistjack/#jacking-and-lifting-avalanche__lifting-and-jacking-the-vehicle) in General Information.
  2. Drain the rear axle. Refer to «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (8.6 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (9.5, 10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle)
  3. Remove the rear axle housing cover bolts (1). Discard the rear axle housing cover bolts.
  4. Remove the rear axle housing cover (2) from the axle housing. Catch the oil in a drain pan. Remove any gasket material from the rear axle housing and/or the rear axle housing cover.

Scheme 281

Scheme 281: Installation Procedure
  1. Install the rear axle housing cover (2) and a new gasket. NOTE: Refer to «FASTENER NOTICE»(/chevrolet/avalanche/i-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__fastener-notice) in Cautions and Notices. Important: Do not reuse the rear axle housing cover bolts.
  2. Install the new rear axle housing cover bolts (1). Tighten Tighten the rear axle housing cover bolts in a crosswise pattern to 40 N.m (30 lb ft).
  3. Fill the rear axle. Use the proper fluid.
  4. Lower the vehicle.

Scheme 282

Scheme 282: Removal Procedure

Scheme 283

Scheme 283

Scheme 284

Scheme 284

Scheme 285

Scheme 285

Scheme 286

Scheme 286
  1. Raise the vehicle. Refer to «LIFTING AND JACKING THE VEHICLE»(/chevrolet/avalanche/i-2001-2006/remont/hoistjack/#jacking-and-lifting-avalanche__lifting-and-jacking-the-vehicle) in General Information.
  2. Remove the tire and wheel assembly. Refer to TIRE AND WHEEL REMOVAL AND INSTALLATION in Tires and Wheels.
  3. Remove the brake caliper. Refer to «BRAKE CALIPER»(/chevrolet/avalanche/i-2001-2006/remont/mechanical-hydraulic/#disc-brakes__brake-caliper) in Disc Brakes.
  4. Remove the rear cover and the gasket. Refer to «REAR AXLE HOUSING COVER AND GASKET REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  5. Remove the pinion shaft locking bolt.
  6. On axles without a locking differential, remove the pinion shaft.
  7. On axles with a locking differential, remove the shaft part way. Rotate the case until the pinion shaft touches the housing.
  8. On axles with a locking differential, use a screwdriver, or a similar tool, in order to enter the differential case and rotate the lock (1) until the lock aligns with the thrust block (2).
  9. Push the flange of the axle shaft (1) toward the differential.
  10. Remove the C-lock (4) from the button end of the axle shaft (1). Important: When removing the axle shaft, do not rotate the shaft. Rotating the shaft will misalign the gears. Misaligning the gears will make the assembly difficult.
  11. Remove the axle shaft (1) from the housing (5).

Important: Carefully insert the axle shaft in order to not damage the seal.

Scheme 287

Scheme 287: Installation Procedure

Scheme 288

Scheme 288

Scheme 289

Scheme 289
  1. Install the axle shaft (1) into the rear axle housing (5).
  2. Slide the axle shaft (1) into place allowing the splines to engage the differential side gear.
  3. On axles without a locking differential, place the lock (4) on the button end of the axle shaft (1).
  4. On axles with a locking differential, keep the pinion shaft partially withdrawn.
  5. On axles with a locking differential, place the C-lock (1) on the axle shaft (3) so that the ends are flush with the thrust block (2).
  6. Pull the shaft flange outward in order to seat the lock in the differential gear.
  7. Align the hole in the pinion shaft with the bolt hole in the differential case. NOTE: Refer to «FASTENER NOTICE»(/chevrolet/avalanche/i-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__fastener-notice) in Cautions and Notices.
  8. Install the new pinion shaft locking bolt. Tighten Tighten the pinion shaft locking bolt to 34 N.m (25 lb ft).
  9. Install the rear cover and the gasket. Refer to «REAR AXLE HOUSING COVER AND GASKET REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  10. Install the brake caliper. Refer to «BRAKE CALIPER»(/chevrolet/avalanche/i-2001-2006/remont/mechanical-hydraulic/#disc-brakes__brake-caliper) in Disc Brakes.
  11. Install the tire and wheel assembly. Refer to TIRE AND WHEEL REMOVAL AND INSTALLATION in Tires and Wheels.
  12. Fill the rear axle. Use the proper fluid.
  13. Lower the vehicle.

Tools Required

  1. J 2619-01 Slide Hammer
  2. J 45859 Axle Remover

Scheme 290

Scheme 290: Removal Procedure

Scheme 291

Scheme 291

Scheme 292

Scheme 292

Scheme 293

Scheme 293
  1. Raise the vehicle. Refer to «LIFTING AND JACKING THE VEHICLE»(/chevrolet/avalanche/i-2001-2006/remont/hoistjack/#jacking-and-lifting-avalanche__lifting-and-jacking-the-vehicle) in General Information.
  2. Remove the tire and wheel assembly. Refer to TIRE AND WHEEL REMOVAL AND INSTALLATION in Tires and Wheels.
  3. Remove the brake caliper. Refer to «BRAKE CALIPER»(/chevrolet/avalanche/i-2001-2006/remont/mechanical-hydraulic/#disc-brakes__brake-caliper) in Disc Brakes.
  4. Remove the rear wheel speed sensor. Refer to WHEEL SPEED SENSOR REPLACEMENT - REAR in Anti-lock Brake System.
  5. Remove the rear cover and the gasket. Refer to «REAR AXLE HOUSING COVER AND GASKET REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  6. Remove the pinion shaft locking bolt.
  7. Remove the pinion shaft.
  8. Push the flange of the axle shaft (1) toward the differential. Important: It may be necessary to tap the axle shaft toward the differential with a soft faced mallet to obtain the clearance needed to remove the C-lock.
  9. Remove the C-lock (4) from the button end of the axle shaft (1). Important: When removing the axle shaft, do not rotate the shaft. Rotating the shaft will misalign the gears. Misaligning the gears will make the assembly difficult.
  10. Remove the axle shaft (1) from the housing (5) by pulling the axle shaft away from the differential.
  11. If the axle is difficult to remove, use the J 45859 (1) and the J 2619-01 (2) to remove the axle shaft from the housing.

Important: Carefully insert the axle shaft in order to not damage the seal.

Scheme 294

Scheme 294: Installation Procedure

Scheme 295

Scheme 295
  1. Install the axle shaft (1) into the rear axle housing (5).
  2. Slide the axle shaft (1) into place allowing the splines to engage the differential side gear. It may be necessary to tap the end of the axle shaft with a soft faced mallet as it is being installed to seat the wheel speed sensor ring on the axle.
  3. Place the lock (4) on the button end of the axle shaft (1).
  4. Pull the shaft flange outward in order to seat the lock in the differential gear.
  5. Align the hole in the pinion shaft with the bolt hole in the differential case. NOTE: Refer to «FASTENER NOTICE»(/chevrolet/avalanche/i-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__fastener-notice) in Cautions and Notices.
  6. Install the new pinion shaft locking bolt. Tighten Tighten the pinion shaft locking bolt to 36 N.m (27 lb ft).
  7. Install the rear cover and the gasket. Refer to «REAR AXLE HOUSING COVER AND GASKET REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  8. Install the rear wheel speed sensor. Refer to WHEEL SPEED SENSOR REPLACEMENT - REAR in Anti-lock Brake System.
  9. Install the brake caliper. Refer to «BRAKE CALIPER»(/chevrolet/avalanche/i-2001-2006/remont/mechanical-hydraulic/#disc-brakes__brake-caliper) in Disc Brakes.
  10. Install the tire and wheel assembly. Refer to TIRE AND WHEEL REMOVAL AND INSTALLATION in Tires and Wheels.
  11. Fill the rear axle. Refer to «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (8.6 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (9.5, 10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  12. Lower the vehicle.

Scheme 296

Scheme 296: Removal Procedure

Scheme 297

Scheme 297
  1. Release the park brake.
  2. Raise the vehicle. Refer to «LIFTING AND JACKING THE VEHICLE»(/chevrolet/avalanche/i-2001-2006/remont/hoistjack/#jacking-and-lifting-avalanche__lifting-and-jacking-the-vehicle) in General Information.
  3. Remove the tire and wheel assembly. Refer to TIRE AND WHEEL REMOVAL AND INSTALLATION in Tires and Wheels.
  4. Remove the rear steering gear assembly. Refer to «STEERING GEAR ACTUATOR AND COVER REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/electronic-steering/#rear-wheel-steering-system) in Rear Wheel Steering.
  5. Remove the steering knuckle assembly. Refer to «STEERING KNUCKLE REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/electronic-steering/#rear-wheel-steering-system) in Rear Wheel Steering.
  6. Remove the lock clip from the axle shaft end. The lock clip is spring loaded and fits securely in the axle shaft slot and may need to be push off the shaft end with a screw driver or related tool. Pushing the axle shaft inwards towards the gears my help in removal of the lock clip. Important: When removing the axle shaft do not rotate the shaft. Rotating the shaft will cause the gears to move. Misalignment of the gears will make the assembly difficult.
  7. Remove the axle shaft.

Scheme 298

Scheme 298: Installation Procedure

Scheme 299

Scheme 299
  1. Install the axle shaft.
  2. Install the spring loaded lock clip to the axle shaft end.
  3. Install the steering knuckle assembly. Refer to «STEERING KNUCKLE REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/electronic-steering/#rear-wheel-steering-system) in Rear Wheel Steering.
  4. Install the rear steering gear assembly. Refer to «STEERING GEAR ACTUATOR AND COVER REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/electronic-steering/#rear-wheel-steering-system) in Rear Wheel Steering.
  5. Install the tire and wheel assembly. Refer to TIRE AND WHEEL REMOVAL AND INSTALLATION in Tires and Wheels.
  6. Lower the vehicle.

Scheme 300

Scheme 300: Removal Procedure
  1. Raise the vehicle. Refer to «LIFTING AND JACKING THE VEHICLE»(/chevrolet/avalanche/i-2001-2006/remont/hoistjack/#jacking-and-lifting-avalanche__lifting-and-jacking-the-vehicle) in General Information.
  2. Remove the tire and wheel assembly. Refer to TIRE AND WHEEL REMOVAL AND INSTALLATION in Tires and Wheels.
  3. Remove the axle shaft. Refer to «REAR AXLE SHAFT REPLACEMENT (8.6 INCH AXLE W/O JL4, 9.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «REAR AXLE SHAFT REPLACEMENT (8.6 INCH AXLE W/JL4)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «REAR AXLE SHAFT REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  4. Remove the axle shaft seal.

Scheme 301

Scheme 301: Installation Procedure
  1. Install the axle shaft seal.
  2. Install the axle shaft. Refer to «REAR AXLE SHAFT REPLACEMENT (8.6 INCH AXLE W/O JL4, 9.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «REAR AXLE SHAFT REPLACEMENT (8.6 INCH AXLE W/JL4)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «REAR AXLE SHAFT REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  3. Install the tire and wheel assembly. Refer to TIRE AND WHEEL REMOVAL AND INSTALLATION in Tires and Wheels.
  4. Lower the vehicle.
  1. J 33049 Camshaft Bearing Service Set
  2. J 45177 Differential Seal Installer - Inner

Scheme 302

Scheme 302: Removal Procedure

Scheme 303

Scheme 303

Scheme 304

Scheme 304

Scheme 305

Scheme 305
  1. Raise the vehicle. Refer to «LIFTING AND JACKING THE VEHICLE»(/chevrolet/avalanche/i-2001-2006/remont/hoistjack/#jacking-and-lifting-avalanche__lifting-and-jacking-the-vehicle) in General Information.
  2. Remove the tire and wheel assembly. Refer to TIRE AND WHEEL REMOVAL AND INSTALLATION in Tires and Wheels.
  3. Remove the axle shafts. Refer to «REAR AXLE SHAFT REPLACEMENT (8.6 INCH AXLE W/O JL4, 9.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «REAR AXLE SHAFT REPLACEMENT (8.6 INCH AXLE W/JL4)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «REAR AXLE SHAFT REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  4. Remove the differential assembly. Refer to «DIFFERENTIAL REPLACEMENT (8.6 INCH, 9.5 INCH AXLES)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL REPLACEMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  5. Install the smallest expanding driver (3) and the small driving washer (1) onto the expander assembly (2).
  6. Align the separation lines between the expanding driver and the expander assembly.
  7. Assemble the expander assembly (2) onto the driver bar extension (1).
  8. Assemble the drive bar extension on to the driver bar.
  9. Insert the J 33049 into the axle tube and through the axle shaft seal.
  10. While holding the expander assembly nut, turn the driving bar clockwise until the expanding driver is snug against the axle shaft seal.
  11. Drive out the seal using the J 33049 and a hammer.

Scheme 306

Scheme 306: Installation Procedure

Scheme 307

Scheme 307
  1. Assemble the drive bar extension on to the drive bar of J 33049.
  2. Insert the J 33049 into the opposite side axle shaft tube.
  3. Install the J 45177 onto the J 33049.
  4. Insert the axle shaft seal into the axle tube.
  5. Install the J 45177 (1) and the J 33049 (2) over the axle shaft seal.
  6. Drive the axle shaft seal into the axle tube using the J 45177 , the J 33049 and a hammer.
  7. Install the differential assembly. Refer to «DIFFERENTIAL REPLACEMENT (8.6 INCH, 9.5 INCH AXLES)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL REPLACEMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  8. Install the axle shafts. Refer to «REAR AXLE SHAFT REPLACEMENT (8.6 INCH AXLE W/O JL4, 9.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «REAR AXLE SHAFT REPLACEMENT (8.6 INCH AXLE W/JL4)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «REAR AXLE SHAFT REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  9. Install the tire and wheel assembly. Refer to TIRE AND WHEEL REMOVAL AND INSTALLATION in Tires and Wheels.
  10. Lower the vehicle. Refer to «LIFTING AND JACKING THE VEHICLE»(/chevrolet/avalanche/i-2001-2006/remont/hoistjack/#jacking-and-lifting-avalanche__lifting-and-jacking-the-vehicle) in General Information.
  1. J 8092 Driver Handle
  2. J 21128 Axle Pinion Oil Seal Installer (8.6 inch Axle)
  3. J 23690 Bearing Installer (8.6 inch Axle)
  4. J 2619-01 Slide Hammer
  5. J 29709 Wheel Bearing Installer (9.5 inch Axle)
  6. J 29712 Wheel Bearing Remover (9.5 inch Axle)
  7. J 29713 Axle Seal Installer (9.5 inch Axle)
  8. J 44685 Rear Axle Seal and Bearing Remover (8.6 inch Axle)

Scheme 308

Scheme 308: Removal Procedure

Scheme 309

Scheme 309
  1. Raise the vehicle. Refer to «LIFTING AND JACKING THE VEHICLE»(/chevrolet/avalanche/i-2001-2006/remont/hoistjack/#jacking-and-lifting-avalanche__lifting-and-jacking-the-vehicle) in General Information.
  2. Remove the tire and wheel assembly. Refer to TIRE AND WHEEL REMOVAL AND INSTALLATION in Tires and Wheels.
  3. Remove the rear axle housing cover. Refer to «REAR AXLE HOUSING COVER AND GASKET REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  4. Remove the axle shaft. Refer to «REAR AXLE SHAFT REPLACEMENT (8.6 INCH AXLE W/O JL4, 9.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «REAR AXLE SHAFT REPLACEMENT (8.6 INCH AXLE W/JL4)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «REAR AXLE SHAFT REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  5. Remove the axle shaft seal and the bearing from the axle housing using the J 44685 (8.6 inch axle) (1) and the J2619-01 (2).
  6. Remove the axle shaft seal and the bearing from the axle housing using the J 29712 (9.5 inch axle).

Scheme 310

Scheme 310: Installation Procedure

Scheme 311

Scheme 311
  1. Install the axle shaft bearing using the J 23690 (8.6 inch axle) (1) or the J 29709 (9.5 inch axle) (1) and the J 8092 (2).
  2. Drive the axle shaft bearing into the axle housing until the tool bottoms against the tube.
  3. Install the axle shaft seal using the J 21128 (8.6 inch axle) or the J 29713 (9.5 inch axle).
  4. Drive the tool into the bore until the axle shaft seal bottoms flush with the tube.
  5. Install the axle shaft. Refer to «REAR AXLE SHAFT REPLACEMENT (8.6 INCH AXLE W/O JL4, 9.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «REAR AXLE SHAFT REPLACEMENT (8.6 INCH AXLE W/JL4)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «REAR AXLE SHAFT REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  6. Install the rear axle housing cover. Refer to «REAR AXLE HOUSING COVER AND GASKET REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  7. Install the tire and wheel assembly. Refer to TIRE AND WHEEL REMOVAL AND INSTALLATION in Tires and Wheels.
  8. Fill the rear axle. Refer to «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (8.6 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (9.5, 10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  9. Lower the vehicle.
  1. J 8092 Driver Handle
  2. J 21128 Axle Pinion Oil Seal Installer
  3. J 23690 Bearing Installer
  4. J 2619-01 Slide Hammer
  5. J 44685 Rear Axle Seal and Bearing Remover
  6. J 45857 Tone Wheel and/or Bearing Remover

Scheme 312

Scheme 312: Removal Procedure
  1. Raise the vehicle. Refer to «LIFTING AND JACKING THE VEHICLE»(/chevrolet/avalanche/i-2001-2006/remont/hoistjack/#jacking-and-lifting-avalanche__lifting-and-jacking-the-vehicle) in General Information.
  2. Remove the tire and wheel assembly. Refer to TIRE AND WHEEL REMOVAL AND INSTALLATION in Tires and Wheels.
  3. Remove the rear axle housing cover. Refer to «REAR AXLE HOUSING COVER AND GASKET REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  4. Remove the axle shaft. Refer to «REAR AXLE SHAFT REPLACEMENT (8.6 INCH AXLE W/O JL4, 9.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «REAR AXLE SHAFT REPLACEMENT (8.6 INCH AXLE W/JL4)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «REAR AXLE SHAFT REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  5. To remove the seal only, use a suitable seal remover.
  6. To remove the axle shaft seal and the bearing together from the axle housing, use the J 45857 (1) and the J2619-01 (2).

Scheme 313

Scheme 313: Installation Procedure

Scheme 314

Scheme 314
  1. Install the axle shaft bearing using the J 23690 (1) and the J 8092 (2).
  2. Drive the axle shaft bearing into the axle housing until the tool bottoms against the tube.
  3. Install the axle shaft seal using the J 21128.
  4. Drive the tool into the bore until the axle shaft seal bottoms flush with the tube.
  5. Install the axle shaft. Refer to «REAR AXLE SHAFT REPLACEMENT (8.6 INCH AXLE W/O JL4, 9.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «REAR AXLE SHAFT REPLACEMENT (8.6 INCH AXLE W/JL4)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «REAR AXLE SHAFT REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  6. Install the rear axle housing cover. Refer to «REAR AXLE HOUSING COVER AND GASKET REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  7. Install the tire and wheel assembly. Refer to TIRE AND WHEEL REMOVAL AND INSTALLATION in Tires and Wheels.
  8. Fill the rear axle. Refer to «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (8.6 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (9.5, 10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  9. Lower the vehicle.

Scheme 315

Scheme 315: Removal Procedure
  1. Raise the vehicle. Refer to «LIFTING AND JACKING THE VEHICLE»(/chevrolet/avalanche/i-2001-2006/remont/hoistjack/#jacking-and-lifting-avalanche__lifting-and-jacking-the-vehicle) in General Information.
  2. Remove the tire and wheel. Refer to TIRE AND WHEEL REMOVAL AND INSTALLATION in Tires and Wheels.
  3. Remove the flange bolts.
  4. Lightly tap the axle shaft with a soft-faced hammer in order to loosen the shaft.
  5. Grip the rib on the axle shaft flange with a locking pliers. Twist the axle shaft flange in order to start the axle shaft removal.
  6. Remove the axle shaft from the tube.
  7. Remove the gasket.
  8. Clean the axle shaft flange and the outside face of the hub assembly.

Scheme 316

Scheme 316: Installation Procedure
  1. Install the gasket onto the axle shaft.
  2. Install the gasket and the axle shaft into the axle tube. Ensure the shaft splines mesh into the differential side gear. Align the holes in the axle flange and the gasket with the holes in the hub. NOTE: Refer to «FASTENER NOTICE»(/chevrolet/avalanche/i-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__fastener-notice) in Cautions and Notices.
  3. Install the axle flange bolts. Tighten Tighten the rear axle flange bolts to 156 N.m (115 lb ft).
  4. Install the tire and wheel assembly. Refer to TIRE AND WHEEL REMOVAL AND INSTALLATION in Tires and Wheels.
  5. Inspect and add axle lubricant to the axle housing, if necessary. Refer to «LUBRICANT LEVEL INSPECTION - REAR DRIVE AXLE (8.6 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «LUBRICANT LEVEL INSPECTION - REAR DRIVE AXLE (9.5, 10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «LUBRICANT LEVEL INSPECTION - REAR DRIVE AXLE (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  6. Lower the vehicle.
  1. J 8092 Universal Driver Handle - 3/4 inch - 10
  2. J 2222-C Wheel Bearing Nut Wrench
  3. J 24426 Wheel Bearing Race Installer - Outer
  4. J 24427 Wheel Bearing Race Installer- Inner
  5. J 44419 Hub Outer Bearing Race Installer
  6. J 44420 Differential Bearing and Hub Seal Installer

Scheme 317

Scheme 317: Removal Procedure

Scheme 318

Scheme 318

Scheme 319

Scheme 319

Scheme 320

Scheme 320

Scheme 321

Scheme 321

Scheme 322

Scheme 322

Scheme 323

Scheme 323

Scheme 324

Scheme 324

Scheme 325

Scheme 325
  1. Raise the vehicle. Refer to «LIFTING AND JACKING THE VEHICLE»(/chevrolet/avalanche/i-2001-2006/remont/hoistjack/#jacking-and-lifting-avalanche__lifting-and-jacking-the-vehicle) in General Information.
  2. Remove the tire and wheel assembly. Refer to TIRE AND WHEEL REMOVAL AND INSTALLATION in Tires and Wheels.
  3. Remove the brake caliper. Refer to «BRAKE CALIPER»(/chevrolet/avalanche/i-2001-2006/remont/mechanical-hydraulic/#disc-brakes__brake-caliper) in Disc Brakes.
  4. Remove the axle shaft. Refer to «REAR AXLE SHAFT AND/OR GASKET REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  5. Remove the axle nut retaining ring.
  6. Remove the key.
  7. Remove the adjusting nut using the J 2222-C.
  8. Remove the adjusting nut.
  9. Remove the hub from the axle housing.
  10. Remove the rotor, if necessary. Refer to «REMOVAL (REAR -- ALL WITH 4-WHEEL STEERING)»(/chevrolet/avalanche/i-2001-2006/remont/mechanical-hydraulic/#disc-brakes__removal-rear-all-with-4-wheel) or «REMOVAL (REAR -- WITHOUT DUAL WHEELS & 4-WHEEL)»(/chevrolet/avalanche/i-2001-2006/remont/mechanical-hydraulic/#disc-brakes__removal-rear-without-dual-wheels) in Disc Brakes.
  11. Remove the oil seal from the wheel hub using a suitable seal removal tool.
  12. Remove the inner hub bearing.
  13. Remove the inner hub bearing cup using a brass drift and a hammer.
  14. Remove the retaining ring from the wheel hub.
  15. Remove the outer hub bearing and bearing cup using the J 24426 (2) and the J 8092 (1).

Scheme 326

Scheme 326: Installation Procedure

Scheme 327

Scheme 327

Scheme 328

Scheme 328

Scheme 329

Scheme 329

Scheme 330

Scheme 330

Scheme 331

Scheme 331

Scheme 332

Scheme 332

Scheme 333

Scheme 333

Scheme 334

Scheme 334

Scheme 335

Scheme 335
  1. Lubricate the following with a light coat of high melting point EP bearing lubricant: The outer wheel bearing The inner wheel bearing The outer wheel bearing cup The inner wheel bearing cup The axle housing
  2. Install the outer bearing into the wheel hub.
  3. Install the outer bearing cup into the wheel hub.
  4. Drive the bearing cup into the wheel hub using the J 44419 (2) and the J 8092 (1).
  5. Install the retaining ring into the groove. Make sure the retaining ring is fully and evenly seated in the groove.
  6. Install the inner bearing cup.
  7. Drive the inner bearing cup into the wheel hub using the J 24427 (2) and the J 8092 (1).
  8. Install the inner bearing. Important: Each time you replace the wheel hub bearings, install a new oil seal in order to prevent the wheel hub from leaking.
  9. Install the new oil seal using the J 44420 (2) and the J 8092 (1).
  10. Install the rotor, if necessary. Refer to «REMOVAL (REAR -- ALL WITH 4-WHEEL STEERING)»(/chevrolet/avalanche/i-2001-2006/remont/mechanical-hydraulic/#disc-brakes__removal-rear-all-with-4-wheel) or «REMOVAL (REAR -- WITHOUT DUAL WHEELS & 4-WHEEL)»(/chevrolet/avalanche/i-2001-2006/remont/mechanical-hydraulic/#disc-brakes__removal-rear-without-dual-wheels) in Disc Brakes.
  11. Apply a light coat of high melting point EP bearing lubricant to the axle housing spindle.
  12. Install the wheel hub to the axle housing.
  13. Install the adjusting nut to the hub using the J 2222-C.
  14. Adjust the wheel bearings. Refer to «WHEEL BEARING ADJUSTMENT»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  15. Install the axle shaft. Refer to «REAR AXLE SHAFT AND/OR GASKET REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  16. Install the brake caliper. Refer to «BRAKE CALIPER»(/chevrolet/avalanche/i-2001-2006/remont/mechanical-hydraulic/#disc-brakes__brake-caliper) in Disc Brakes.
  17. Install the tire and wheel assembly. Refer to TIRE AND WHEEL REMOVAL AND INSTALLATION in Tires and Wheels.
  18. Inspect and add axle lubricant to the axle housing, if necessary. Refer to «LUBRICANT LEVEL INSPECTION - REAR DRIVE AXLE (8.6 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «LUBRICANT LEVEL INSPECTION - REAR DRIVE AXLE (9.5, 10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «LUBRICANT LEVEL INSPECTION - REAR DRIVE AXLE (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  19. Lower the vehicle.
  1. J 8614-01 Flange/Pulley Holding Tool
  2. J 22388 Pinion Oil Seal Installer - Rear (8.6 inch, 9.5 inch axle)
  3. J 44414 Pinion Seal Installer (10.5 inch axle)

Important: Observe and mark the positions of all the driveline components, relative to the propeller shaft and the axles, prior to disassembly. These components include the propeller shafts, drive axles, pinion flanges, output shafts, etc. Reassemble all the components in the exact places in which you removed the parts. Follow any specifications, torque values, and any measurements made prior to disassembly.

Scheme 336

Scheme 336: Removal Procedure

Scheme 337

Scheme 337

Scheme 338

Scheme 338

Scheme 339

Scheme 339
  1. Raise the vehicle. Refer to «LIFTING AND JACKING THE VEHICLE»(/chevrolet/avalanche/i-2001-2006/remont/hoistjack/#jacking-and-lifting-avalanche__lifting-and-jacking-the-vehicle) in General Information.
  2. Remove the tire and wheel assemblies (8.6 inch, 9.5 inch axles). Refer to TIRE AND WHEEL REMOVAL AND INSTALLATION in Tires and Wheels.
  3. Remove the rear brake calipers (8.6 inch, 9.5 inch axles). Refer to «BRAKE CALIPER»(/chevrolet/avalanche/i-2001-2006/remont/mechanical-hydraulic/#disc-brakes__brake-caliper) in Disc Brakes.
  4. Remove the brake rotors (8.6 inch, 9.5 inch axles). Refer to «REMOVAL (REAR -- ALL WITH 4-WHEEL STEERING)»(/chevrolet/avalanche/i-2001-2006/remont/mechanical-hydraulic/#disc-brakes__removal-rear-all-with-4-wheel) or «REMOVAL (REAR -- WITHOUT DUAL WHEELS & 4-WHEEL)»(/chevrolet/avalanche/i-2001-2006/remont/mechanical-hydraulic/#disc-brakes__removal-rear-without-dual-wheels) in Disc Brakes.
  5. Remove the axle shafts (10.5 inch axle). Refer to «REAR AXLE SHAFT AND/OR GASKET REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  6. Reference mark the rear propeller shaft (3) to the rear axle pinion yoke (4).
  7. Disconnect the propeller shaft from the axle. Wrap the bearing caps with tape in order to prevent the loss of bearing rollers. Support the propeller shaft as necessary.
  8. Measure the amount of torque required to rotate the pinion. Use an inch-pound torque wrench. Record this measurement for reassembly. This will give the combined preload for the following components: The pinion bearings The pinion pilot bearing (10.5 inch axle) The pinion oil seal The differential case bearings The axle bearings (8.6 inch, 9.5 inch axles) The axle seals (8.6 inch, 9.5 inch axles)
  9. Draw 2 arrows pointing at each other, one on the pinion stem, the other on the pinion yoke.
  10. Record the number of exposed threads on the pinion stem for reference.
  11. Install the J 8614-01 as shown.
  12. Remove the pinion nut while holding the J 8614-01.
  13. Remove the washer.
  14. Install the J 8614-2 (2) and the J 8614-3 (3) into the J 8614-01 (1) as shown.
  15. Remove the pinion yoke by turning the J 8614-3 (3) clockwise while holding the J 8614-01 (1). Use a container in order to retrieve the lubricant.
  16. Remove the pinion oil seal. Use a suitable seal removal tool. Do not damage the housing.

Scheme 340

Scheme 340: Installation Procedure

Scheme 341

Scheme 341

Scheme 342

Scheme 342

Scheme 343

Scheme 343
  1. Install a new pinion oil seal using the J 22388 or the J 44414 .
  2. Apply sealant, GM P/N 12346004 (Canadian P/N 10953480) or equivalent, to the splines of the pinion yoke.
  3. Install the pinion yoke. Align the marks made during removal. NOTE: Refer to «PINION FLANGE/YOKE INSTALLATION NOTICE»(/chevrolet/avalanche/i-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__pinion-flangeyoke-installation-notice) in Cautions and Notices.
  4. Seat the pinion yoke onto the pinion shaft by tapping it with a soft-faced hammer until a few pinion shaft threads show through the yoke.
  5. Install the washer and a new pinion nut.
  6. Install the J 8614-01 onto the pinion yoke as shown. NOTE: Refer to «FASTENER NOTICE»(/chevrolet/avalanche/i-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__fastener-notice) in Cautions and Notices. Important: If the rotating torque is exceeded, the pinion will have to be removed and a new collapsible spacer installed.
  7. Tighten the pinion nut while holding the J 8614-01 . Tighten Tighten the nut until the pinion end play is just taken up. Rotate the pinion while tightening the nut to seat the bearings.
  8. Measure the rotating torque of the pinion. Compare this measurement with the rotating torque recorded during removal. Tighten Tighten the nut in small increments, as needed, until the rotating torque is 0.40-0.57 N.m (3- 5 lb in) greater than the rotating torque recorded during removal.
  9. Once the specified torque is obtained, rotate the pinion several times to ensure the bearings have seated. Recheck the rotating torque and adjust if necessary.
  10. Install the propeller shaft (3) to the pinion yoke (4). Align the reference marks made during removal.
  11. Install the propeller shaft yoke retaining clamps and the bolts. Tighten Tighten the propeller shaft yoke retaining clamp bolts to 25 N.m (18 lb ft).
  12. Install the axle shafts (10.5 inch axle). Refer to «REAR AXLE SHAFT AND/OR GASKET REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  13. Install the brake rotors (8.6 inch, 9.5 inch axles). Refer to «REMOVAL (REAR -- ALL WITH 4-WHEEL STEERING)»(/chevrolet/avalanche/i-2001-2006/remont/mechanical-hydraulic/#disc-brakes__removal-rear-all-with-4-wheel) or «REMOVAL (REAR -- WITHOUT DUAL WHEELS & 4-WHEEL)»(/chevrolet/avalanche/i-2001-2006/remont/mechanical-hydraulic/#disc-brakes__removal-rear-without-dual-wheels) in Disc Brakes.
  14. Install the brake calipers (8.6 inch, 9.5 inch axles). Refer to «BRAKE CALIPER»(/chevrolet/avalanche/i-2001-2006/remont/mechanical-hydraulic/#disc-brakes__brake-caliper) in Disc Brakes.
  15. Install the tire and the wheel. Refer to TIRE AND WHEEL REMOVAL AND INSTALLATION in Tires and Wheels.
  16. Inspect and add axle lubricant to the axle housing, if necessary. Refer to «LUBRICANT LEVEL INSPECTION - REAR DRIVE AXLE (8.6 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «LUBRICANT LEVEL INSPECTION - REAR DRIVE AXLE (9.5, 10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «LUBRICANT LEVEL INSPECTION - REAR DRIVE AXLE (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  17. Lower the vehicle.
  1. J 8614-01 Flange and Pulley Holding Tool
  2. J 45710 Pinion Bearing Oil Seal Installer

Important: Observe and mark the positions of all the driveline components, relative to the propeller shaft and the axles, prior to disassembly. These components include the propeller shafts, drive axles, pinion flanges, output shafts, etc. Reassemble all the components in the exact places in which you removed the parts. Follow any specifications, torque values, and any measurements made prior to disassembly.

Scheme 344

Scheme 344: Removal Procedure

Scheme 345

Scheme 345

Scheme 346

Scheme 346

Scheme 347

Scheme 347
  1. Raise the vehicle. Refer to «LIFTING AND JACKING THE VEHICLE»(/chevrolet/avalanche/i-2001-2006/remont/hoistjack/#jacking-and-lifting-avalanche__lifting-and-jacking-the-vehicle) in General Information.
  2. Disconnect the propeller shaft from the rear axle pinion yoke. Refer to PROPELLER SHAFT REPLACEMENT - REAR in Propeller Shaft.
  3. Place an alignment mark between the pinion and the pinion yoke.
  4. Install the J 8614-01 as shown.
  5. Remove the pinion nut while holding the J 8614-01.
  6. Remove the washer.
  7. Install the J 8614-2 (2) and the J 8614-3 (3) into the J 8614-01 (1) as shown.
  8. Remove the pinion yoke by turning the J 8614-3 (3) clockwise while holding the J 8614-01 (1). Use a container in order to retrieve the lubricant.
  9. Remove the pinion oil seal. Use a suitable seal removal tool. Do not damage the axle housing.

Scheme 348

Scheme 348: Installation Procedure

Scheme 349

Scheme 349

Scheme 350

Scheme 350

Scheme 351

Scheme 351

Scheme 352

Scheme 352
  1. Apply a light coat of axle lubricant, GM P/N 12378557 or equivalent meeting GM Specification 9986207, to the lip of the pinion seal.
  2. Install the new seal using the J 45710.
  3. Install the pinion yoke. NOTE: Refer to «PINION FLANGE/YOKE INSTALLATION NOTICE»(/chevrolet/avalanche/i-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__pinion-flangeyoke-installation-notice) in Cautions and Notices.
  4. Seat the pinion yoke onto the pinion shaft by tapping it with a soft-faced hammer until a few pinion shaft threads show through the yoke.
  5. Install the washer.
  6. Install the new pinion nut
  7. Install the J 8614-01 onto the pinion yoke as shown. NOTE: Refer to «FASTENER NOTICE»(/chevrolet/avalanche/i-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__fastener-notice) in Cautions and Notices.
  8. Tighten the pinion nut while holding the J 8614-01. Tighten Tighten the pinion nut to 370 N.m (273 lb ft).
  9. Install the propeller shaft to the rear axle pinion yoke. Refer to PROPELLER SHAFT REPLACEMENT - REAR in Propeller Shaft.
  10. Inspect and add axle lubricant to the axle housing, if necessary. Refer to «LUBRICANT LEVEL INSPECTION - REAR DRIVE AXLE (8.6 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «LUBRICANT LEVEL INSPECTION - REAR DRIVE AXLE (9.5, 10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «LUBRICANT LEVEL INSPECTION - REAR DRIVE AXLE (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  11. Lower the vehicle.
  1. J 44414 Pinion Seal Installer
  2. J 22912-01 Bearing Split-Plate Puller
  3. J 24433 Pinion Cone and Side Bearing Installer
  4. J 37624 Pinion Bearing Installer
  5. J 8092 Driver Handle
  6. J 8608 Rear Pinion Bearing Race Installer
  7. J 8614-01 Flange/Pulley Holding Tool

Scheme 353

Scheme 353

Important: Observe and mark the positions of all the driveline components, relative to the propeller shaft and the axles, prior to disassembly. These components include the propeller shafts, drive axles, pinion flanges, output shafts, etc. Reassemble all the components in the exact places in which you removed the parts. Follow any specifications, torque values, and any measurements made prior to disassembly.

Scheme 354

Scheme 354: Removal Procedure

Scheme 355

Scheme 355

Scheme 356

Scheme 356

Scheme 357

Scheme 357

Scheme 358

Scheme 358

Scheme 359

Scheme 359

Scheme 360

Scheme 360

Scheme 361

Scheme 361

Scheme 362

Scheme 362
  1. Raise the vehicle. Refer to «LIFTING AND JACKING THE VEHICLE»(/chevrolet/avalanche/i-2001-2006/remont/hoistjack/#jacking-and-lifting-avalanche__lifting-and-jacking-the-vehicle) in General Information.
  2. Drain the axle lubricant. Refer to «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (8.6 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (9.5, 10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  3. Remove the axle shafts. Refer to «REAR AXLE SHAFT AND/OR GASKET REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  4. Reference mark the rear propeller shaft (3) to the rear axle pinion yoke (4).
  5. Disconnect the propeller shaft from the axle. Wrap the bearing caps with tape in order to prevent the loss of bearing rollers. Support the propeller shaft as necessary.
  6. Measure the amount of torque required to rotate the pinion and the ring gear. Use an inch-pound torque wrench. Record this measurement for reassembly. This will give the combined preload for the following components: The pinion bearings The pinion pilot bearing The pinion oil seal The differential case bearings
  7. Place an alignment mark between the pinion and the pinion yoke.
  8. Remove the pinion gear bearing retainer bolts.
  9. Remove the pinion gear bearing retainer and the pinion.
  10. Remove the selective shim.
  11. Measure the amount of torque required to rotate the pinion. Use an inch-pound torque wrench. Record this measurement for reassembly.
  12. Install the J 8614-01 as shown.
  13. Remove the pinion nut while holding the J 8614-01.
  14. Remove the washer.
  15. Install the J 8614-2 (2) and the J 8614-3 (1) into the J 8614-01 (3) as shown.
  16. Remove the pinion yoke by turning the J 8614-3 (1) clockwise while holding the J 8614-01 (3).
  17. Remove the pinion oil seal. Use a suitable seal removal tool. Do not damage the housing.
  18. Remove the outer pinion bearing.
  19. Remove the pinion.
  20. Remove the collapsible spacer.
  21. Remove the inner pinion bearing from the pinion using the J 22912-01 and a hydraulic press.
  22. Remove the outer pinion bearing cup using a hammer and a brass drift in the slots provided. Move the drift back and forth between one side of the cup and the other in order to work the cups out of the retainer evenly.
  23. Remove the inner pinion bearing cup using a hammer and a brass drift in the slots provided. Move the drift back and forth between one side of the cup and the other in order to work the cups out of the retainer evenly.

Scheme 363

Scheme 363: Installation Procedure

Scheme 364

Scheme 364

Scheme 365

Scheme 365

Scheme 366

Scheme 366

Scheme 367

Scheme 367

Scheme 368

Scheme 368

Scheme 369

Scheme 369

Scheme 370

Scheme 370

Scheme 371

Scheme 371

Scheme 372

Scheme 372
  1. Install the inner pinion bearing cup into the pinion gear bearing retainer using the J 37624 (2) and the J 8092 (1).
  2. Install the outer pinion bearing cup into the pinion gear bearing retainer using the J 8608 (2) and the J 8092 (1).
  3. Install the inner pinion bearing using the J 24433. Press the bearing on until the cone seats on the pinion.
  4. Install a new collapsible spacer.
  5. Lubricate the pinion bearings with axle lubricant Use the proper fluid.
  6. Install the pinion into the pinion gear bearing retainer.
  7. Install the outer pinion bearing onto the pinion.
  8. Install a new pinion oil seal using the J 44414 .
  9. Apply sealant, GM P/N 12346004 (Canadian P/N 10953480) or equivalent, to the splines of the pinion yoke.
  10. Install the pinion yoke. Align the marks made during removal. NOTE: Refer to «PINION FLANGE/YOKE INSTALLATION NOTICE»(/chevrolet/avalanche/i-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__pinion-flangeyoke-installation-notice) in Cautions and Notices.
  11. Seat the pinion yoke onto the pinion shaft by tapping it with a soft-faced hammer until a few pinion shaft threads show through the yoke.
  12. Install the washer and a new pinion nut.
  13. Install the J 8614-01 onto the pinion yoke as shown. NOTE: Refer to «FASTENER NOTICE»(/chevrolet/avalanche/i-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__fastener-notice) in Cautions and Notices. Important: If the rotating torque is exceeded, the pinion will have to be removed and a new collapsible spacer installed.
  14. Tighten the pinion nut while holding the J 8614-01 . Tighten Tighten the nut until the pinion end play is just taken up. Rotate the pinion while tightening the nut to seat the bearings.
  15. Measure the rotating torque of the pinion Compare this measurement with the rotating torque recorded during removal. Tighten Tighten the nut in small increments, as needed, until the rotating torque is 0.40-0.57 N.m (3-5 lb in) greater than the rotating torque recorded during removal.
  16. Once the specified torque is obtained, rotate the pinion several times to ensure the bearings have seated. Recheck the rotating torque and adjust if necessary.
  17. Determine the selective shim thickness for the pinion gear bearing retainer. Refer to «PINION DEPTH ADJUSTMENT (8.6 INCH, 9.5 INCH AXLES)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «PINION DEPTH ADJUSTMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «PINION DEPTH ADJUSTMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle__pinion-depth-adjustment-105-inch-axle) .
  18. Apply sealant, GM P/N 1052942 (Canadian P/N 10953466) or equivalent, to the sealing surface of the pinion gear bearing retainer.
  19. Install the selective shim. Align the tab on the shim with the un-machined surface of the pinion gear bearing retainer.
  20. Apply sealant, GM P/N 1052942 (Canadian P/N 10953466) or equivalent, to the surface of the selective shim.
  21. Install the pinion gear bearing retainer.
  22. Install the pinion gear bearing retainer bolts. Tighten: Tighten the pinion gear bearing retainer bolts to 88 N.m (65 lb ft).
  23. Measure the rotating torque of the pinion and the ring gear. Compare this measurement with the rotating torque recorded during removal. Specification The rotating torque of the pinion and the ring gear should be between 3.9-6.2 N.m (30-55 lb in) for new bearings or 2.8-5.6 N.m (25-50 lb in) for used bearings.
  24. If the rotating torque of the pinion and the ring gear is not within specifications, adjust the preload of the pinion or the differential side bearings as necessary.
  25. Install the propeller shaft (3) to the pinion yoke (4). Align the reference marks made during removal.
  26. Install the propeller shaft yoke retaining clamps and the bolts. Tighten: Tighten the propeller shaft yoke retaining clamp bolts to 25 N.m (18 lb ft).
  27. Install the axle shafts. Refer to «REAR AXLE SHAFT AND/OR GASKET REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  28. Fill the axle with axle lubricant. Refer to «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (8.6 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (9.5, 10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  29. Lower the vehicle.

J 22536 Pinion Driver

Scheme 373

Scheme 373: Removal Procedure

Scheme 374

Scheme 374

Scheme 375

Scheme 375

Scheme 376

Scheme 376
  1. Raise the vehicle. Refer to «LIFTING AND JACKING THE VEHICLE»(/chevrolet/avalanche/i-2001-2006/remont/hoistjack/#jacking-and-lifting-avalanche__lifting-and-jacking-the-vehicle) in General Information.
  2. Remove the differential assembly. Refer to «DIFFERENTIAL REPLACEMENT (8.6 INCH, 9.5 INCH AXLES)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL REPLACEMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  3. Remove the pinion yoke and the oil seal. Refer to «DRIVE PINION FLANGE/YOKE AND/OR OIL SEAL REPLACEMENT (ALL EXCEPT 9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION FLANGE/YOKE AND/OR OIL SEAL REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  4. Install the J 22536 as shown. Ensure that the J 22536 is firmly seated on the pinion.
  5. Drive the pinion out using the J 22536 and a hammer. Strike the J 22536 slowly. Do not let the pinion fall out of the rear axle housing.
  6. Remove the collapsible spacer from the pinion. Discard the spacer.
  7. Remove the pinion bearings and the cups. Refer to «DRIVE PINION BEARINGS REPLACEMENT (8.6, 9.5 INCH AXLES)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION BEARINGS REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION BEARINGS REPLACEMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) . Important: The ring gear bolts have left-hand threads.
  8. Remove the ring gear bolts. Discard the bolts. NOTE: Refer to «RING GEAR REMOVAL NOTICE»(/chevrolet/avalanche/i-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__ring-gear-removal-notice) in Cautions and Notices.
  9. Remove the ring gear from the differential. Drive the gear off with a brass drift if necessary.

Important: The mating surface of the ring gear and the differential case must be clean and free of burrs before installing the ring gear.

Scheme 377

Scheme 377: Installation Procedure

Scheme 378

Scheme 378
  1. Install the ring gear to the differential case. Important: The ring gear bolts have left-hand threads.
  2. Install the new ring gear bolts. Hand start each bolt to ensure that the ring gear is properly installed to the differential case. NOTE: Refer to «FASTENER NOTICE»(/chevrolet/avalanche/i-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__fastener-notice) in Cautions and Notices.
  3. Tighten the ring gear bolts. Tighten the ring gear bolts alternately and in stages, gradually pulling the ring gear onto the differential case. Tighten: For the 8.6 inch axle, tighten the ring gear bolts in sequence to 120 N.m (89 lb ft). For the 9.5 inch axle, tighten the ring gear bolts in sequence to 140 N.m (103 lb ft).
  4. Install the pinion bearing cups. Refer to «DRIVE PINION BEARINGS REPLACEMENT (8.6, 9.5 INCH AXLES)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION BEARINGS REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION BEARINGS REPLACEMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  5. Determine the selective shim thickness for the pinion gear. Refer to «PINION DEPTH ADJUSTMENT (8.6 INCH, 9.5 INCH AXLES)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «PINION DEPTH ADJUSTMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «PINION DEPTH ADJUSTMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle__pinion-depth-adjustment-105-inch-axle) .
  6. Install the selective shim onto the pinion.
  7. Install the inner pinion bearing to the pinion. Refer to «DRIVE PINION BEARINGS REPLACEMENT (8.6, 9.5 INCH AXLES)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION BEARINGS REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION BEARINGS REPLACEMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  8. Install a new collapsible spacer.
  9. Lubricate the pinion bearings with axle lubricant.
  10. Install the outer pinion bearing into the axle housing.
  11. Install the new pinion oil seal. Refer to «DRIVE PINION FLANGE/YOKE AND/OR OIL SEAL REPLACEMENT (ALL EXCEPT 9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION FLANGE/YOKE AND/OR OIL SEAL REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  12. Install the pinion into the axle housing.
  13. Install the pinion yoke. Refer to «DRIVE PINION FLANGE/YOKE AND/OR OIL SEAL REPLACEMENT (ALL EXCEPT 9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION FLANGE/YOKE AND/OR OIL SEAL REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  14. Install the differential assembly. Refer to «DIFFERENTIAL REPLACEMENT (8.6 INCH, 9.5 INCH AXLES)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL REPLACEMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  15. Fill the axle with lubricant. Use the proper fluid. Refer to «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (8.6 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (9.5, 10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  16. Lower the vehicle.

J 22536 Pinion Driver

Scheme 379

Scheme 379: Removal Procedure

Scheme 380

Scheme 380

Scheme 381

Scheme 381

Scheme 382

Scheme 382
  1. Raise the vehicle. Refer to «LIFTING AND JACKING THE VEHICLE»(/chevrolet/avalanche/i-2001-2006/remont/hoistjack/#jacking-and-lifting-avalanche__lifting-and-jacking-the-vehicle) in General Information.
  2. Remove the differential assembly. Refer to «DIFFERENTIAL REPLACEMENT (8.6 INCH, 9.5 INCH AXLES)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL REPLACEMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  3. Remove the drive pinion yoke and the pinion oil seal. Refer to «DRIVE PINION FLANGE/YOKE AND/OR OIL SEAL REPLACEMENT (ALL EXCEPT 9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION FLANGE/YOKE AND/OR OIL SEAL REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  4. Remove the thrust washer
  5. Install the J 22536 as shown. Ensure that the J 22536 is firmly seated on the pinion.
  6. Drive the pinion out using the J 22536 and a hammer. Strike the J 22536 slowly. Do not let the pinion fall out of the rear axle housing.
  7. Remove the pinion preload shims from the drive pinion and set aside.
  8. Remove the inner pinion bearing and the pinion position shim. Refer to «DRIVE PINION BEARINGS REPLACEMENT (8.6, 9.5 INCH AXLES)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION BEARINGS REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION BEARINGS REPLACEMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) . Important: The ring gear bolts have right-hand threads.
  9. Remove the ring gear bolts. Discard the bolts. NOTE: Refer to «RING GEAR REMOVAL NOTICE»(/chevrolet/avalanche/i-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__ring-gear-removal-notice) in Cautions and Notices.
  10. Remove the ring gear from the differential case. Drive the gear off with a brass drift if necessary.

Scheme 383

Scheme 383: Installation Procedure

Scheme 384

Scheme 384
  1. Determine the pinion position shim thickness and the pinion preload shim thickness for the drive pinion gear. Refer to «PINION DEPTH ADJUSTMENT (8.6 INCH, 9.5 INCH AXLES)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «PINION DEPTH ADJUSTMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «PINION DEPTH ADJUSTMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle__pinion-depth-adjustment-105-inch-axle) . Important: The mating surface of the ring gear and the differential case must be clean and free of burrs before installing the ring gear.
  2. Install the ring gear to the differential case. Align the holes in the differential case to the bolts holes in the ring gear. Important: The ring gear bolts have right-hand threads.
  3. Install the new ring gear bolts. Hand start each bolt to ensure that the ring gear is properly installed to the differential case. NOTE: Refer to «FASTENER NOTICE»(/chevrolet/avalanche/i-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__fastener-notice) in Cautions and Notices.
  4. Tighten the new ring gear bolts. Tighten the ring gear bolts alternately and in stages, gradually pulling the ring gear onto the differential case. Tighten: Tighten the new ring gear bolts to 178 N.m (131 lb ft).
  5. Install the differential assembly. Refer to «DIFFERENTIAL REPLACEMENT (8.6 INCH, 9.5 INCH AXLES)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL REPLACEMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  6. Fill the axle with lubricant. Use the proper fluid. Refer to «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (8.6 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (9.5, 10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  7. Lower the vehicle.

Scheme 385

Scheme 385: Removal Procedure
  1. Raise the vehicle. Refer to «LIFTING AND JACKING THE VEHICLE»(/chevrolet/avalanche/i-2001-2006/remont/hoistjack/#jacking-and-lifting-avalanche__lifting-and-jacking-the-vehicle) in General Information.
  2. Remove the differential assembly. Refer to «DIFFERENTIAL REPLACEMENT (8.6 INCH, 9.5 INCH AXLES)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL REPLACEMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  3. Remove the pinion gear bearing retainer. Refer to «DRIVE PINION HOUSING AND/OR SEAL REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  4. Remove the pinion and the pinion bearings. Refer to «DRIVE PINION HOUSING AND/OR SEAL REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) . Important: The ring gear bolts have left-hand threads.
  5. Remove the ring gear bolts. Discard the bolts. NOTE: Refer to «RING GEAR REMOVAL NOTICE»(/chevrolet/avalanche/i-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__ring-gear-removal-notice) in Cautions and Notices.
  6. Remove the ring gear from the differential. Drive the gear off with a brass drift if necessary.

Scheme 386

Scheme 386: Installation Procedure

Scheme 387

Scheme 387
  1. If the differential case has become separated, assemble the differential case by aligning the two arrows inside the differential case as shown. Important: The mating surface of the ring gear and the differential case must be clean and free of burrs before installing the ring gear.
  2. Install the ring gear to the differential case. Important: The ring gear bolts have left-hand threads.
  3. Install the new ring gear bolts. Hand start each bolt to ensure that the ring gear is properly installed to the differential case. NOTE: Refer to «FASTENER NOTICE»(/chevrolet/avalanche/i-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__fastener-notice) in Cautions and Notices.
  4. Tighten the new ring gear bolts. Tighten the ring gear bolts alternately and in stages, gradually pulling the ring gear onto the differential case. Tighten: Tighten the ring gear bolts in sequence to 165 N.m (122 lb ft).
  5. Install the pinion and the pinion bearings. Refer to «DRIVE PINION HOUSING AND/OR SEAL REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  6. Install the pinion gear bearing retainer. Refer to «DRIVE PINION HOUSING AND/OR SEAL REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  7. Install the differential assembly. Refer to «DIFFERENTIAL REPLACEMENT (8.6 INCH, 9.5 INCH AXLES)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL REPLACEMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  8. Fill the axle with lubricant. Use the proper fluid. Refer to «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (8.6 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (9.5, 10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  9. Lower the vehicle.
  1. J 7818 Inner Bearing Race Installer
  2. J 8092 Universal Driver Handle - 3/4 in - 10
  3. J 8611-01 Rear Pinion Bearing Race Installer
  4. J 8614-01 Flange and Pulley Holding Tool
  5. J 22306 Rear Pinion Cup Bearing Installer
  6. J 22912-01 Split Plate Bearing Puller
  7. J 24433 Pinion Cone and Side Bearing Installer
  8. J 36614 Inner Pinion Bearing Installer
  9. J 45870 Pinion Bearing Cup Installer
  10. J 45871 Pinion Bearing Remover

Scheme 388

Scheme 388: Removal Procedure

Scheme 389

Scheme 389

Scheme 390

Scheme 390

Scheme 391

Scheme 391
  1. Raise the vehicle. Refer to «LIFTING AND JACKING THE VEHICLE»(/chevrolet/avalanche/i-2001-2006/remont/hoistjack/#jacking-and-lifting-avalanche__lifting-and-jacking-the-vehicle) in General Information.
  2. Remove the differential assembly. Refer to «DIFFERENTIAL REPLACEMENT (8.6 INCH, 9.5 INCH AXLES)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL REPLACEMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  3. Remove the drive pinion from the axle. Refer to «DRIVE PINION AND RING GEAR REPLACEMENT (8.6 INCH, 9.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION AND RING GEAR REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION AND RING GEAR REPLACEMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  4. For the 8.6 inch axle, install the J 45871 (1) around the pinion bearing and the J 22912-01 (2) in the inverted position around the J 45871 .
  5. Press the bearing off of the pinion using the J 45871 and the J 22912-01 .
  6. For the 9.5 inch and 11.5 inch axles, press the bearing off of the drive pinion using the J 22912-01 .
  7. Remove the shim.
  8. Remove the outer pinion bearing cup from the axle housing using a hammer and a brass drift in the slots provided. Move the drift back and forth between one side of the cup and the other in order to work the cups out of the housing evenly.
  9. Remove the inner pinion bearing cup from the axle housing using a hammer and a brass drift in the slots provided. Move the drift back and forth between one side of the cup and the other in order to work the cups out of the housing evenly.

Scheme 392

Scheme 392: Installation Procedure

Scheme 393

Scheme 393

Scheme 394

Scheme 394

Scheme 395

Scheme 395

Scheme 396

Scheme 396

Scheme 397

Scheme 397

Scheme 398

Scheme 398
  1. Install the outer pinion bearing cup using the J 8611-01 , 8.6 inch axle, or the J 7818 , 9.5 inch axle (1), and the J 8092 (2).
  2. Install the inner pinion bearing cup using the J 45870 , 8.6 inch axle, or the J 22306 , 9.5 inch axle (2), and the J 8092 (1).
  3. Determine the selective shim thickness for the drive pinion. Refer to «PINION DEPTH ADJUSTMENT (8.6 INCH, 9.5 INCH AXLES)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «PINION DEPTH ADJUSTMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «PINION DEPTH ADJUSTMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle__pinion-depth-adjustment-105-inch-axle) .
  4. Install the selective shim between the inner pinion bearing and the shoulder on the gear.
  5. Install the inner pinion bearing using the J 24433 or the J 36614 . Press the bearing on until the cone seats on the pinion shim.
  6. Install a new collapsible spacer.
  7. Lubricate the pinion bearings with axle lubricant. Use the proper fluid.
  8. Install the outer pinion bearing into the axle housing.
  9. Install a new pinion oil seal using the J 22388 .
  10. Install the pinion into the axle housing.
  11. Apply sealant, GM P/N 12346004 (Canadian P/N 10953480) or equivalent, to the splines of the pinion yoke.
  12. Install the Pinion yoke. Align the marks made during removal. NOTE: Refer to «PINION FLANGE/YOKE INSTALLATION NOTICE»(/chevrolet/avalanche/i-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__pinion-flangeyoke-installation-notice) in Cautions and Notices.
  13. Seat the pinion yoke onto the pinion shaft by tapping it with a soft-faced hammer until a few threads show through the yoke.
  14. Install the washer and a new pinion nut.
  15. Install the J 8614-01 onto the pinion yoke as shown. NOTE: Refer to «FASTENER NOTICE»(/chevrolet/avalanche/i-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__fastener-notice) in Cautions and Notices. Important: If the rotating torque is exceeded, the pinion will have to be removed and a new collapsible spacer installed.
  16. Tighten the pinion nut while holding the J 8614-01 . Tighten: Tighten the pinion nut until the pinion end play is just taken up. Rotate the pinion while tightening the nut to seat the bearings.
  17. Measure the rotating torque of the pinion using an inch-pound torque wrench. Specification The rotating torque of the pinion should be between 1.0-2.3 N.m (10-20 lb in) for used bearings, or 1.7-3.4 N.m (15-30 lb in) for new bearings.
  18. If the rotating torque measurement is below 1.0 N.m (10 lb in) for used bearings, or 1.7 N.m (15 lb in) for new bearings, continue to tighten the pinion nut. Tighten: Tighten the pinion nut, in small increments, as needed, until the torque required in order to rotate the pinion is between 1.0-2.3 N.m (10-20 lb in) for used bearings, or 1.7-3.4 N.m (15-30 lb in) for new bearings.
  19. Once the specified torque is obtained, rotate the pinion several times to ensure the bearings have seated. Recheck the rotating torque and adjust if necessary.
  20. Install the differential assembly. Refer to «DIFFERENTIAL REPLACEMENT (8.6 INCH, 9.5 INCH AXLES)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL REPLACEMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  21. Fill the axle with lubricant. Use the proper fluid. Refer to «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (8.6 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (9.5, 10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  22. Lower the vehicle.
  1. J 22536 Pinion Driver
  2. J 22912-01 Split-Plate Bearing Puller
  3. J 42176 Universal Driver Handle - Non-Threaded
  4. J 45703 Pinion Bearing Race Remover - Dana 248
  5. J 45704 Pinion Bearing Race Installer - Dana 248
  6. J 45705 Pinion Bearing Race Remover - Dana 248/267
  7. J 7818 Inner Bearing Race Installer
  8. J 8092 Universal Drive Handle - 3/4 in - 10

Scheme 399

Scheme 399: Removal Procedure

Scheme 400

Scheme 400

Scheme 401

Scheme 401

Scheme 402

Scheme 402
  1. Raise the vehicle. Refer to «LIFTING AND JACKING THE VEHICLE»(/chevrolet/avalanche/i-2001-2006/remont/hoistjack/#jacking-and-lifting-avalanche__lifting-and-jacking-the-vehicle) in General Information.
  2. Remove the differential assembly. Refer to «DIFFERENTIAL REPLACEMENT (8.6 INCH, 9.5 INCH AXLES)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL REPLACEMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  3. Remove the pinion yoke and the pinion oil seal. Refer to «DRIVE PINION FLANGE/YOKE AND/OR OIL SEAL REPLACEMENT (ALL EXCEPT 9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION FLANGE/YOKE AND/OR OIL SEAL REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  4. Remove the thrust washer.
  5. Install the J 22536 as shown. Ensure that the J 22536 is firmly seated on the pinion.
  6. Drive the pinion out using the J 22536 and a hammer. Strike the J 22536 slowly. Do not let the pinion fall out of the rear axle housing.
  7. Remove the pinion preload shims from the drive pinion and set aside.
  8. Remove the inner pinion bearing cup and the oil deflector using the J 45703 (2) and the J 42176 (1).
  9. Remove the outer pinion bearing cup using the J 45705 and the J 42176 .
  10. Remove the inner pinion bearing using the J 22912-01 and a hydraulic press.
  11. Remove the pinion position shim.

Scheme 403

Scheme 403: Installation Procedure

Scheme 404

Scheme 404

Scheme 405

Scheme 405
  1. Install the oil deflector into the inner pinion cup bore.
  2. Install the inner pinion bearing cup using the J 45704 (2) and the J 8092 (1).
  3. Install the outer pinion bearing cup using the J 7818 (2) and the J 8092 (1).
  4. Determine the pinion position shim thickness and the pinion preload shim thickness for the drive pinion. Refer to «PINION DEPTH ADJUSTMENT (8.6 INCH, 9.5 INCH AXLES)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «PINION DEPTH ADJUSTMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «PINION DEPTH ADJUSTMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle__pinion-depth-adjustment-105-inch-axle) .
  5. Install the differential assembly. Refer to «DIFFERENTIAL REPLACEMENT (8.6 INCH, 9.5 INCH AXLES)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL REPLACEMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  6. Fill the axle with lubricant. Use the proper fluid. Refer to «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (8.6 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (9.5, 10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  7. Lower the vehicle.
  1. J 22388 Pinion Oil Seal Installer - Rear
  2. J 22761 Differential Side Bearing Installer
  3. J 22912-01 Split Plate Bearing Puller
  4. J 24433 Pinion Cone and Side Bearing Installer
  5. J 37624 Pinon Bearing Installer
  6. J 8092 Universal Driver Handle - 3/4 in - 10
  7. J 8608 Rear Pinion Bearing Installer
  8. J 8614-01 Flange and Pulley Holding Tool

Scheme 406

Scheme 406: Removal Procedure

Scheme 407

Scheme 407

Scheme 408

Scheme 408

Scheme 409

Scheme 409

Scheme 410

Scheme 410

Scheme 411

Scheme 411
  1. Raise the vehicle. Refer to «LIFTING AND JACKING THE VEHICLE»(/chevrolet/avalanche/i-2001-2006/remont/hoistjack/#jacking-and-lifting-avalanche__lifting-and-jacking-the-vehicle) in General Information.
  2. Remove the differential assembly. Refer to «DIFFERENTIAL REPLACEMENT (8.6 INCH, 9.5 INCH AXLES)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL REPLACEMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  3. Remove the pinion gear bearing retainer. Refer to «DRIVE PINION HOUSING AND/OR SEAL REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  4. Remove the pinion yoke and the oil seal. Refer to «DRIVE PINION HOUSING AND/OR SEAL REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  5. Remove the outer pinion bearing
  6. Remove the pinion.
  7. Remove the collapsible spacer.
  8. Remove the inner pinion bearing from the pinion using the J 22912-01 and a hydraulic press.
  9. Remove the outer pinion bearing cup using a hammer and a brass drift in the slots provided. Move the drift back and forth between one side of the cup and the other in order to work the cups out of the retainer evenly.
  10. Remove the inner pinion bearing cup using a hammer and a brass drift in the slots provided. Move the drift back and forth between one side of the cup and the other in order to work the cups out of the retainer evenly.
  11. Remove the pinion gear pilot bearing using a brass drift and a hammer.

Scheme 412

Scheme 412: Installation Procedure

Scheme 413

Scheme 413

Scheme 414

Scheme 414

Scheme 415

Scheme 415

Scheme 416

Scheme 416

Scheme 417

Scheme 417
  1. Install the pinion gear pilot bearing using the J 22761 .
  2. Install the inner pinion bearing cup into the pinion gear bearing retainer using the J 37624 (2) and the J 8092 (1).
  3. Install the outer pinion bearing cup into the pinion gear bearing retainer using the J 8608 (2) and the J 8092 (1).
  4. Install the inner pinion bearing using the J 24433 .
  5. Press the bearing on until the cone seats on the pinion.
  6. Install a new collapsible spacer.
  7. Lubricate the pinion bearings with axle lubricant. Use the proper fluid.
  8. Install the outer pinion bearing into the pinion bearing retainer.
  9. Install a new pinion oil seal using the J 22388 .
  10. Install the pinion into the pinion gear bearing retainer.
  11. Apply sealant, GM P/N 12346004 (Canadian P/N 10953480) or equivalent, to the splines of the pinion yoke.
  12. Install the pinion yoke. Align the marks made during removal. NOTE: Refer to «PINION FLANGE/YOKE INSTALLATION NOTICE»(/chevrolet/avalanche/i-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__pinion-flangeyoke-installation-notice) in Cautions and Notices.
  13. Seat the pinion yoke onto the pinion shaft by tapping it with a soft-faced hammer until a few threads show through the yoke.
  14. Install the washer and a new pinion nut.
  15. Install the J 8614-01 onto the pinion yoke. NOTE: Refer to «FASTENER NOTICE»(/chevrolet/avalanche/i-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__fastener-notice) in Cautions and Notices. Important: If the rotating torque is exceeded, the pinion will have to be removed and a new collapsible spacer installed.
  16. Tighten the pinion nut while holding the J 8614-01 . Tighten: Tighten the pinion nut until the pinion end play is just taken up. Rotate the pinion while tightening the nut to seat the bearings.
  17. Remove the J 8614-01 . Important: Do not apply sealant to the pinion gear bearing retainer at this time.
  18. Install the original shim to the pinion bearing retainer. If the original shim is not available, install a 0.41 mm (0.016 in) shim to build pinion depth.
  19. Install the pinion gear bearing retainer to the axle housing.
  20. Install the pinion bearing retainer bolts. Tighten: Tighten the pinion gear retainer bolts to 88 N.m (65 lb ft).
  21. Measure the rotating torque of the pinion using an inch-pound torque wrench. Specification The rotating torque of the pinion should be between 1.0-2.3 N.m (10-20 lb in) for used bearings, or 1.7-3.4 N.m (15-30 lb in) for new bearings.
  22. If the rotating torque measurement is below 1.0 N.m (10 lb in) for used bearings, or 1.7 N.m (15 lb in) for new bearings, install the J 8614-01 and continue to tighten the pinion nut. Tighten: Tighten the pinion nut, in small increments, as needed, until the torque required in order to rotate the pinion is between 1.0-2.3 N.m (10-20 lb in) for used bearings, or 1.7-3.4 N.m (15-30 lb in) for new bearings.
  23. Once the specified torque is obtained, rotate the pinion several times to ensure the bearings have seated. Recheck the rotating torque and adjust if necessary.
  24. Install the differential assembly Refer to «DIFFERENTIAL REPLACEMENT (8.6 INCH, 9.5 INCH AXLES)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL REPLACEMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  25. Adjust the differential side bearing preload. Refer to «DIFFERENTIAL SIDE BEARING PRELOAD ADJUSTMENT (8.6 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL SIDE BEARING PRELOAD ADJUSTMENT (9.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL SIDE BEARING PRELOAD ADJUSTMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL SIDE BEARING PRELOAD ADJUSTMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  26. Determine the selective shim thickness for the drive pinion. Refer to «PINION DEPTH ADJUSTMENT (8.6 INCH, 9.5 INCH AXLES)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «PINION DEPTH ADJUSTMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «PINION DEPTH ADJUSTMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle__pinion-depth-adjustment-105-inch-axle) .
  27. Adjust the backlash. Refer to «BACKLASH ADJUSTMENT (ALL EXCEPT 9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «BACKLASH ADJUSTMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  28. Fill the axle with lubricant. Use the proper fluid. Refer to «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (8.6 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (9.5, 10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  29. Lower the vehicle.

J 24429 Side Bearing Backlash Spanner

Important: Group and mark the shims together as originally removed. If you remove or replace the ring and pinion gear set, perform the bearing preload, backlash, and gear tooth contact pattern check in order to ensure proper contact of the gears. If you reinstall or replace the differential carrier without replacing any other component (i.e. pinion and ring gear set, bearings, etc.) then you may reinstall the carrier with the original shims in their original locations. Always perform a gear tooth contact pattern check, even when you remove only the carrier.

Scheme 418

Scheme 418: Removal Procedure

Scheme 419

Scheme 419

Scheme 420

Scheme 420
  1. Raise the vehicle. Refer to «LIFTING AND JACKING THE VEHICLE»(/chevrolet/avalanche/i-2001-2006/remont/hoistjack/#jacking-and-lifting-avalanche__lifting-and-jacking-the-vehicle) in General Information.
  2. Remove the axle shafts. Refer to «REAR AXLE SHAFT REPLACEMENT (8.6 INCH AXLE W/O JL4, 9.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «REAR AXLE SHAFT REPLACEMENT (8.6 INCH AXLE W/JL4)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «REAR AXLE SHAFT REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  3. Remove the differential bearing adjuster nut lock (9.5 inch axle - right side).
  4. Remove the bearing caps and bolts. Mark the bearing caps left and right. CAUTION: To prevent personal injury and/or component damage, support the differential case when removing the case from the axle housing. If the case is not supported, the differential case could fall and cause personal injury or damage to the differential case. NOTE: When removing the differential case from the axle housing, do not damage the cover gasket surface. If the cover gasket surface is damaged, lubricant may leak from the axle and cause premature failure of the axle assembly.
  5. Remove the differential by prying the differential from the axle housing at the differential window (8.6 inch axle).
  6. Loosen the differential bearing adjuster nut using the J 24429 (9.5 inch axle).
  7. Remove the differential (9.5 inch axle).
  8. Remove the bearing cups, the shims, and the spacers as necessary. Mark the cups and shims left and right and in the proper order as necessary. Place the cups and the shims with the bearing caps.
  9. Remove the differential side bearings, if necessary. Refer to «DIFFERENTIAL SIDE BEARINGS REPLACEMENT (ALL EXCEPT 9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL SIDE BEARINGS REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  10. Remove the ring gear, if necessary. Refer to «DRIVE PINION AND RING GEAR REPLACEMENT (8.6 INCH, 9.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION AND RING GEAR REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION AND RING GEAR REPLACEMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .

Scheme 421

Scheme 421: Installation Procedure

Scheme 422

Scheme 422
  1. Install the ring gear, if necessary. Refer to «DRIVE PINION AND RING GEAR REPLACEMENT (8.6 INCH, 9.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION AND RING GEAR REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION AND RING GEAR REPLACEMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  2. Install the differential side bearings, if necessary. Refer to «DIFFERENTIAL SIDE BEARINGS REPLACEMENT (ALL EXCEPT 9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL SIDE BEARINGS REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  3. Lubricate the differential side bearings with axle lubricant. Use the proper fluid.
  4. Place the case, with the bearing cups installed, into the axle housing. Support the case in order to keep the case from falling out of the axle housing.
  5. Install the bearing caps and the bolts. Do not torque the bearing cap bolts at this time.
  6. Adjust the differential side bearing preload. Refer to «DIFFERENTIAL SIDE BEARING PRELOAD ADJUSTMENT (8.6 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL SIDE BEARING PRELOAD ADJUSTMENT (9.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL SIDE BEARING PRELOAD ADJUSTMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL SIDE BEARING PRELOAD ADJUSTMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  7. Adjust the backlash. Refer to «BACKLASH ADJUSTMENT (ALL EXCEPT 9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «BACKLASH ADJUSTMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  8. Perform a gear tooth contact pattern check. Refer to «GEAR TOOTH CONTACT PATTERN INSPECTION»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle__gear-tooth-contact-pattern-inspection) .
  9. Tighten the bearing cap bolts. Tighten: For the 8.6 inch axle, tighten the bearing cap bolts to 75 N.m (55 lb ft) For the 9.5 inch axle, tighten the bearing cap bolts to 85 N.m (63 lb ft)
  10. Install the axle shafts. Refer to «REAR AXLE SHAFT REPLACEMENT (8.6 INCH AXLE W/O JL4, 9.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «REAR AXLE SHAFT REPLACEMENT (8.6 INCH AXLE W/JL4)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «REAR AXLE SHAFT REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  11. Fill the axle with lubricant. Use the proper fluid. Refer to «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (8.6 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (9.5, 10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  12. Lower the vehicle.
  1. J 24385-01 Axle Housing Spreader
  2. J 25025 Guide Pins
  3. J 34178 Spreader Gage Adapter
  4. J 8001 Dial Indicator Set

Scheme 423

Scheme 423: Removal Procedure

Scheme 424

Scheme 424
  1. Raise the vehicle. Refer to «LIFTING AND JACKING THE VEHICLE»(/chevrolet/avalanche/i-2001-2006/remont/hoistjack/#jacking-and-lifting-avalanche__lifting-and-jacking-the-vehicle) in General Information.
  2. Remove the axle shafts. Refer to «REAR AXLE SHAFT REPLACEMENT (8.6 INCH AXLE W/O JL4, 9.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «REAR AXLE SHAFT REPLACEMENT (8.6 INCH AXLE W/JL4)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «REAR AXLE SHAFT REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  3. Loosen the bearing cap bolts.
  4. Do not remove the bearing cap bolts at this time.
  5. Install the J 24385-01 onto the axle housing as shown.
  6. Install the J 25025 (2), the J 8001-1 and the J 8001-2 (1), the J 34178 (3), and the J 8001-3 and the J 8001-4 (4) onto the axle housing as shown.
  7. Preload the dial of the J 8001-3 by pushing the J 8001-3 against the edge of the J 24385-01 until the needle of the J 8001-3 has moved approximately 3/4 of a turn clockwise.
  8. Rotate the indicator housing to align the indicator needle of the J 8001-3 and the dial indicator face to ZERO. NOTE: Do not spread the axle housing more than 0.38 mm (0.015 inch). Overspreading the housing may result in component damage.
  9. Spread the axle housing by turning the clevis screw of the J 24385-01 clockwise while observing the J 8001 . Spread the housing just enough to remove the differential assembly.
  10. Remove the J 25025-B , the J 8001-1 , the J 8001-2 , the J 34178 , the J 8001-3 and the J 8001-4 from the axle housing.
  11. Remove the bearing cap bolts. CAUTION: To avoid any vehicle damage, serious personal injury or death when major components are removed from the vehicle and the vehicle is supported by a hoist, support the vehicle with jack stands at the opposite end from which the components are being removed. Important: Corresponding letters are stamped on the bearing caps and axle housing. The bearing caps must be reassembled in the same position as removed.
  12. Remove the bearing caps.
  13. Remove the differential assembly.
  14. Remove the J 24385-01 .
  15. Remove the ring gear. Refer to «DRIVE PINION AND RING GEAR REPLACEMENT (8.6 INCH, 9.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION AND RING GEAR REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION AND RING GEAR REPLACEMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  16. Remove the differential side bearings, if necessary. Refer to «DIFFERENTIAL SIDE BEARINGS REPLACEMENT (ALL EXCEPT 9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL SIDE BEARINGS REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .

Scheme 425

Scheme 425: Installation Procedure
  1. Install the ring gear. Refer to «DRIVE PINION AND RING GEAR REPLACEMENT (8.6 INCH, 9.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION AND RING GEAR REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION AND RING GEAR REPLACEMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  2. Determine the total shim pack size for the differential assembly. Refer to «DETERMINING TOTAL SHIM PACK SIZE»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  3. Install the differential side bearings, if necessary. Refer to «DIFFERENTIAL SIDE BEARINGS REPLACEMENT (ALL EXCEPT 9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL SIDE BEARINGS REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  4. Install the J 24385-01 onto the axle housing.
  5. Install the J 25025-B (4), the J 8001-1 and the J 8001-2 (5, 1), the J 34178 (2), and the J 8001-3 and the J 8001-4 (3) onto the axle housing as shown.
  6. Preload the dial of the J 8001-3 by pushing the J 8001-3 against the edge of the J 24385-01 until the needle of the J 8001-3 has moved approximately 3/4 of a turn clockwise.
  7. Rotate the indicator housing to align the indicator needle of the J 8001-3 and the dial indicator face to ZERO. NOTE: Do not spread the axle housing more than 0.38 mm (0.015 inch). Overspreading the housing may result in component damage.
  8. Spread the axle housing by turning the clevis screw of the J 24385-01 clockwise while observing the J 8001 . Spread the housing just enough to install the differential assembly.
  9. Remove the J 25025-B , the J 8001-1 , the J 8001-2 , the J 34178 , the J 8001-3 and the J 8001-4 from the axle housing.
  10. Install the differential assembly.
  11. Remove the J 24385-01 . Important: Corresponding letters are stamped on the bearing caps and axle housing. The bearing caps must be reassembled in the same position as removed.
  12. Install the bearing caps. NOTE: Refer to «FASTENER NOTICE»(/chevrolet/avalanche/i-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__fastener-notice) in Cautions and Notices.
  13. Install the bearing cap bolts. Tighten: Tighten the bearing cap bolts to 108 N.m (80 lb ft).
  14. Install the axle shafts. Refer to «REAR AXLE SHAFT REPLACEMENT (8.6 INCH AXLE W/O JL4, 9.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «REAR AXLE SHAFT REPLACEMENT (8.6 INCH AXLE W/JL4)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «REAR AXLE SHAFT REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  15. Fill the axle with lubricant. Use the proper fluid. Refer to «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (8.6 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (9.5, 10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  16. Lower the vehicle.

J 24429 Side Bearing Backlash Spanner

Scheme 426

Scheme 426: Removal Procedure

Scheme 427

Scheme 427

Scheme 428

Scheme 428
  1. Raise the vehicle. Refer to «LIFTING AND JACKING THE VEHICLE»(/chevrolet/avalanche/i-2001-2006/remont/hoistjack/#jacking-and-lifting-avalanche__lifting-and-jacking-the-vehicle) in General Information.
  2. Remove the axle shafts. Refer to «REAR AXLE SHAFT AND/OR GASKET REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  3. Remove the rear axle housing cover. Refer to «REAR AXLE HOUSING COVER AND GASKET REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  4. Remove the differential bearing adjuster nut retainers.
  5. Remove the bearing caps and bolts. Mark the bearing caps left and right. CAUTION: Refer to «VEHICLE LIFTING CAUTION»(/chevrolet/avalanche/i-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__vehicle-lifting-caution) in Cautions and Notices. To prevent personal injury and/or component damage, support the differential case when removing the case from the axle housing. If the case is not supported, the differential case could fall and cause personal injury or damage to the differential case. NOTE: Refer to «DIFFERENTIAL HOUSING COVER & GASKET REMOVAL NOTICE»(/chevrolet/avalanche/i-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__differential-housing-cover-gasket-removal) in Cautions and Notices. When removing the differential case from the axle housing, do not damage the cover gasket surface. If the cover gasket surface is damaged, lubricant may leak from the axle and cause premature failure of the axle assembly.
  6. Loosen the adjusters using the J 24429 .
  7. Remove the differential.
  8. Remove the bearing cups. Mark the cups left and right. Place the cups with the bearing caps.
  9. Remove the differential side bearings, if necessary. Refer to «DIFFERENTIAL SIDE BEARINGS REPLACEMENT (ALL EXCEPT 9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL SIDE BEARINGS REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  10. Remove the ring gear, if necessary. Refer to «DRIVE PINION AND RING GEAR REPLACEMENT (8.6 INCH, 9.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION AND RING GEAR REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION AND RING GEAR REPLACEMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .

Scheme 429

Scheme 429: Installation Procedure

Scheme 430

Scheme 430

Scheme 431

Scheme 431
  1. Install the ring gear, if necessary. Refer to «DRIVE PINION AND RING GEAR REPLACEMENT (8.6 INCH, 9.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION AND RING GEAR REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION AND RING GEAR REPLACEMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  2. Install the differential side bearings, if necessary. Refer to «DIFFERENTIAL SIDE BEARINGS REPLACEMENT (ALL EXCEPT 9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL SIDE BEARINGS REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  3. Lubricate the differential side bearings with axle lubricant. Use the proper fluid.
  4. Place the case, with the bearing cups installed, into the axle housing. Support the case in order to keep the case from falling out of the axle housing.
  5. Install the bearing caps and the bolts. Do not torque the bearing cap bolts at this time.
  6. Turn the adjusters evenly on each side using the J 24429 until snug against the differential.
  7. Adjust the differential side bearing preload. Refer to «DIFFERENTIAL SIDE BEARING PRELOAD ADJUSTMENT (8.6 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL SIDE BEARING PRELOAD ADJUSTMENT (9.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL SIDE BEARING PRELOAD ADJUSTMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL SIDE BEARING PRELOAD ADJUSTMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  8. Adjust the backlash. Refer to «BACKLASH ADJUSTMENT (ALL EXCEPT 9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «BACKLASH ADJUSTMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  9. Perform a gear tooth contact pattern check. Refer to «GEAR TOOTH CONTACT PATTERN INSPECTION»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle__gear-tooth-contact-pattern-inspection) . NOTE: Refer to «FASTENER NOTICE»(/chevrolet/avalanche/i-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__fastener-notice) in Cautions and Notices.
  10. Tighten the bearing cap bolts. Tighten: Tighten the bearing cap bolts to 185 N.m (136 lb ft).
  11. Install the axle shafts. Refer to «REAR AXLE SHAFT AND/OR GASKET REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  12. Install the rear axle housing cover. Refer to «REAR AXLE HOUSING COVER AND GASKET REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  13. Fill the axle with lubricant. Use the proper fluid. Refer to
  14. Lower the vehicle.
  1. J 8092 Universal Driver Handle - 3/4 in - 10
  2. J 21784 Side Bearing Installer
  3. J 22888-D Side Bearing Remover Kit
  4. J 29710 Differential Side Bearing Installer
  5. J 36597 Side Bearing Puller Pilot - 9.25 inch

Scheme 432

Scheme 432: Removal Procedure
  1. Remove the differential assembly. Refer to «DIFFERENTIAL REPLACEMENT (8.6 INCH, 9.5 INCH AXLES)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL REPLACEMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  2. Remove the differential side bearings by performing the following steps: For the 8.6 inch and the 9.5 inch axles, install the differential assembly in a vise. For the 10.5 inch axle, place a block of wood on each side of the differential case before installing the differential case into the vise. Install the differential assembly into a vise. Install the J 22888-20A (2) and the J 8107-4 , 8.6 inch axle, or the J 36597 , 9.5 inch or 10.5 inch axles as shown. Remove the differential side bearings using the J 22888-20A .
  3. Remove the differential assembly from the vise.

Scheme 433

Scheme 433: Installation Procedure
  1. Install the differential side bearings by doing the following: In order to protect the differential case, install the J 8107-4 , 8.6 inch axle, or the J 36597 , 9.5 inch or 10.5 inch axles, in the case on the side opposite the bearing installation. Install the J 21784 , 8.6 inch axle, or the J 29710 , 9.5 inch or 10.5 inch axle (2), and the J 8092 (1) onto the differential case bearing as shown. Drive the bearing onto the case using the J 21784 or the J 29710 and the J 8092 .
  2. Install the differential assembly. Refer to «DIFFERENTIAL REPLACEMENT (8.6 INCH, 9.5 INCH AXLES)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL REPLACEMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  1. J 22888-D Side Bearing Remover Kit
  2. J 24430 Differential Side Bearing Installer
  3. J 36597 Side Bearing Puller Pilot - 9.25 inch
  4. J 45711 Differential Side Bearing Remover - Dana 248
  5. J 45900 Differential Side Bearing Installer - Dana Axles
  6. J 8092 Universal Driver Handle - 3/4 in - 10

Scheme 434

Scheme 434: Removal Procedure
  1. Raise the vehicle. Refer to «LIFTING AND JACKING THE VEHICLE»(/chevrolet/avalanche/i-2001-2006/remont/hoistjack/#jacking-and-lifting-avalanche__lifting-and-jacking-the-vehicle) in General Information.
  2. Remove the differential assembly. Refer to «DIFFERENTIAL REPLACEMENT (8.6 INCH, 9.5 INCH AXLES)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL REPLACEMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  3. Remove the differential side bearing by performing the following steps: Install the J 45711 (2) and the J 36597 (1) as shown. Remove the differential side bearing using the J 45711 and a hydraulic press. Important: Mark the inboard shims left or right.
  4. Remove the inboard shims.

Scheme 435

Scheme 435: Installation Procedure
  1. Determine the shim thickness and preload for the differential assembly. Refer to «DIFFERENTIAL SIDE BEARING PRELOAD ADJUSTMENT (8.6 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL SIDE BEARING PRELOAD ADJUSTMENT (9.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL SIDE BEARING PRELOAD ADJUSTMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL SIDE BEARING PRELOAD ADJUSTMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  2. Install the differential side bearing by doing the following: In order to protect the differential case, install the J 8107-3 in the case on the side opposite of the bearing installation. Install the inboard shims. Install the differential side bearing. Install the J 24430 or the J 45900 (2) and the J 8092 (1) over the differential side bearing. Drive the differential side bearing into position using the J 24430 or the J 45900 and the J 8092 . Install the differential assembly. Refer to «DIFFERENTIAL REPLACEMENT (8.6 INCH, 9.5 INCH AXLES)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL REPLACEMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  3. Fill the axle with lubricant. Use the proper fluid. Refer to «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (8.6 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (9.5, 10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  4. Lower the vehicle.

Scheme 436

Scheme 436: Removal Procedure
  1. Raise the vehicle. Refer to «LIFTING AND JACKING THE VEHICLE»(/chevrolet/avalanche/i-2001-2006/remont/hoistjack/#jacking-and-lifting-avalanche__lifting-and-jacking-the-vehicle) in General Information.
  2. Place jack or utility stands at the front end of the vehicle.
  3. Drain the axle lubricant from the rear axle. Refer to «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (8.6 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (9.5, 10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  4. Disconnect the propeller shaft. Refer to PROPELLER SHAFT REPLACEMENT - REAR in Propeller Shaft.
  5. Remove the tire and wheel assemblies. Refer to TIRE AND WHEEL REMOVAL AND INSTALLATION in Tires and Wheels.
  6. Disconnect the parking brake cable. Refer to «REMOVAL (LEFT REAR -- WITHOUT 4-WHEEL STEERING)»(/chevrolet/avalanche/i-2001-2006/remont/mechanical-hydraulic/#disc-brakes__removal-left-rear-without-4-wheel) or «REMOVAL (LEFT REAR -- WITH 4-WHEEL STEERING)»(/chevrolet/avalanche/i-2001-2006/remont/mechanical-hydraulic/#disc-brakes__removal-left-rear-with-4-wheel) and «REMOVAL (RIGHT REAR -- WITHOUT 4-WHEEL STEERING)»(/chevrolet/avalanche/i-2001-2006/remont/mechanical-hydraulic/#disc-brakes__removal-right-rear-without-4-wheel) or «REMOVAL (RIGHT REAR -- WITH 4-WHEEL STEERING)»(/chevrolet/avalanche/i-2001-2006/remont/mechanical-hydraulic/#disc-brakes__removal-right-rear-with-4-wheel) in Park Brake.
  7. Remove the brake line bracket bolts. Suspend the brake lines from the vehicle with heavy mechanics wire.
  8. Remove the brake calipers from the brake caliper mounting brackets. Do not disconnect the brake lines. Suspend the calipers from the vehicle with heavy mechanics wire. Refer to «BRAKE CALIPER»(/chevrolet/avalanche/i-2001-2006/remont/mechanical-hydraulic/#disc-brakes__brake-caliper) in Disc Brakes.
  9. Disconnect the shock absorbers from the axle brackets. Refer to SHOCK ABSORBER REPLACEMENT (15 SERIES) or SHOCK ABSORBER REPLACEMENT (25 SERIES) in Rear Suspension.
  10. Remove the vent hose from the rear axle vent fitting. Refer to «VENT HOSE REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  11. Remove the nuts and the washers from the U-bolts.
  12. Remove the U-bolts, the spring plates and the spacers form the axle assembly.
  13. Lower the axle assembly.

Scheme 437

Scheme 437: Installation Procedure
  1. Place the rear axle assembly under the vehicle.
  2. Align the rear axle assembly with the springs.
  3. Connect the spacers, the spring plates and the U-bolts to the rear axle.
  4. Raise the rear axle assembly into position. NOTE: Refer to «FASTENER NOTICE»(/chevrolet/avalanche/i-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__fastener-notice) in Cautions and Notices.
  5. Install the washers if equipped and the nuts to the U-bolts. Tighten: 15 series tighten the nuts in a criss-cross pattern to 72 N.m (53 lb ft). 25 series tighten the nuts in a criss-cross pattern to 150 N.m (110 lb ft).
  6. Install the vent hose to the rear axle vent fitting. Refer to «VENT HOSE REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  7. Connect the shock absorbers to the rear axle. Refer to SHOCK ABSORBER REPLACEMENT (15 SERIES) or SHOCK ABSORBER REPLACEMENT (25 SERIES) in Rear Suspension.
  8. Install the brake calipers. Refer to «BRAKE CALIPER»(/chevrolet/avalanche/i-2001-2006/remont/mechanical-hydraulic/#disc-brakes__brake-caliper) in Disc Brakes.
  9. Install the brake lines and the brake line bracket bolts to the axle.
  10. Connect the parking brake cable. Refer to «REMOVAL (LEFT REAR -- WITHOUT 4-WHEEL STEERING)»(/chevrolet/avalanche/i-2001-2006/remont/mechanical-hydraulic/#disc-brakes__removal-left-rear-without-4-wheel) or «REMOVAL (LEFT REAR -- WITH 4-WHEEL STEERING)»(/chevrolet/avalanche/i-2001-2006/remont/mechanical-hydraulic/#disc-brakes__removal-left-rear-with-4-wheel) and «REMOVAL (RIGHT REAR -- WITHOUT 4-WHEEL STEERING)»(/chevrolet/avalanche/i-2001-2006/remont/mechanical-hydraulic/#disc-brakes__removal-right-rear-without-4-wheel) or «REMOVAL (RIGHT REAR -- WITH 4-WHEEL STEERING)»(/chevrolet/avalanche/i-2001-2006/remont/mechanical-hydraulic/#disc-brakes__removal-right-rear-with-4-wheel) in Park Brake.
  11. Install the tire and wheel assemblies. Refer to TIRE AND WHEEL REMOVAL AND INSTALLATION in Tires and Wheels.
  12. Connect the propeller shaft. Refer to PROPELLER SHAFT REPLACEMENT - REAR in Propeller Shaft.
  13. Fill the axle with lubricant. Use the proper fluid.
  14. Remove the utility stands.
  15. Lower the vehicle.

Scheme 438

Scheme 438: Removal Procedure

Scheme 439

Scheme 439
  1. Raise and support the vehicle. Refer to «LIFTING AND JACKING THE VEHICLE»(/chevrolet/avalanche/i-2001-2006/remont/hoistjack/#jacking-and-lifting-avalanche__lifting-and-jacking-the-vehicle) in General Information.
  2. Place jack stands at the front end of the vehicle in order to support the weight difference when the rear axle is removed.
  3. Drain the axle lubricant from the rear axle. Refer to «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (8.6 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (9.5, 10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  4. Remove the propeller shaft. Refer to PROPELLER SHAFT REPLACEMENT - REAR in Propeller Shaft.
  5. Remove the tire and wheel assemblies. Refer to TIRE AND WHEEL REMOVAL AND INSTALLATION in Tires and Wheels.
  6. Disconnect the parking brake cables. Refer to «REMOVAL (LEFT REAR -- WITHOUT 4-WHEEL STEERING)»(/chevrolet/avalanche/i-2001-2006/remont/mechanical-hydraulic/#disc-brakes__removal-left-rear-without-4-wheel) or «REMOVAL (LEFT REAR -- WITH 4-WHEEL STEERING)»(/chevrolet/avalanche/i-2001-2006/remont/mechanical-hydraulic/#disc-brakes__removal-left-rear-with-4-wheel) and «REMOVAL (RIGHT REAR -- WITHOUT 4-WHEEL STEERING)»(/chevrolet/avalanche/i-2001-2006/remont/mechanical-hydraulic/#disc-brakes__removal-right-rear-without-4-wheel) or «REMOVAL (RIGHT REAR -- WITH 4-WHEEL STEERING)»(/chevrolet/avalanche/i-2001-2006/remont/mechanical-hydraulic/#disc-brakes__removal-right-rear-with-4-wheel) in Park Brake.
  7. Remove the left and right brake calipers from the brake caliper mounting brackets. Do not disconnect the hydraulic brake lines from the brake calipers. Refer to «BRAKE CALIPER»(/chevrolet/avalanche/i-2001-2006/remont/mechanical-hydraulic/#disc-brakes__brake-caliper) in Disc Brakes. Secure the left and the right brake calipers with mechanics wire to the leaf spring or the frame assembly.
  8. Remove the 2 flex hose bracket bolts (1).
  9. Remove the 2 brake pipe bracket bolts (2).
  10. Remove the jounce bracket bolt (3).
  11. Remove the brake pipe bracket nut (4). Secure the rear brake pipe assembly with mechanics wire to the under body and frame. Do not bend or kink the brake pipe assembly.
  12. Disconnect the shock absorbers from the axle brackets. Refer to SHOCK ABSORBER REPLACEMENT (15 SERIES) or SHOCK ABSORBER REPLACEMENT (25 SERIES) in Rear Suspension.
  13. Remove the vent hose from the rear axle vent fitting. Refer to «VENT HOSE REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  14. Support the rear axle assembly with a suitable jack. Remove the nuts and the washers if equipped from the U-bolts.
  15. Remove the U-bolts, the spring plates and the spacers from the axle assembly.
  16. Lower the axle assembly.

Scheme 440

Scheme 440: Installation Procedure

Scheme 441

Scheme 441
  1. Place the axle assembly onto the jack and place the rear axle assembly under the vehicle.
  2. Align the rear axle assembly with the springs. Using the jack slowly raise the rear axle assembly into position.
  3. Connect the spacers, the spring plates and the U-bolts to the rear axle. NOTE: Refer to «FASTENER NOTICE»(/chevrolet/avalanche/i-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__fastener-notice) in Cautions and Notices.
  4. Install the washers if equipped and the nuts to the U-bolts. Tighten: Tighten the nuts in a criss-cross pattern to 150 N.m (110 lb ft).
  5. Install the vent hose to the rear axle vent fitting. Refer to «VENT HOSE REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  6. Connect the shock absorbers to the rear axle. Refer to SHOCK ABSORBER REPLACEMENT (15 SERIES) or SHOCK ABSORBER REPLACEMENT (25 SERIES) in Rear Suspension.
  7. Remove the mechanics wire supporting the brake pipe assembly. Carefully position the brake pipe assembly onto the rear axle.
  8. Install the brake pipe bracket nut (4). Tighten: Tighten the nut to 13 N.m (115 lb in).
  9. Install the jounce bracket bolt (3). Tighten: Tighten the bolt to 12 N.m (106 lb in).
  10. Install the 2 brake pipe bracket bolts (2). Tighten: Tighten the bolts to 22 N.m (16 lb ft).
  11. Install the 2 flex hose bracket bolts (1). Tighten: Tighten the bolts to 12 N.m (106 lb in).
  12. Remove the mechanics wire securing the brake calipers and install the brake calipers to the brake caliper mounting brackets. Refer to «BRAKE CALIPER»(/chevrolet/avalanche/i-2001-2006/remont/mechanical-hydraulic/#disc-brakes__brake-caliper) in Disc Brakes.
  13. Connect the parking brake cable. Refer to «REMOVAL (LEFT REAR -- WITHOUT 4-WHEEL STEERING)»(/chevrolet/avalanche/i-2001-2006/remont/mechanical-hydraulic/#disc-brakes__removal-left-rear-without-4-wheel) or «REMOVAL (LEFT REAR -- WITH 4-WHEEL STEERING)»(/chevrolet/avalanche/i-2001-2006/remont/mechanical-hydraulic/#disc-brakes__removal-left-rear-with-4-wheel) and «REMOVAL (RIGHT REAR -- WITHOUT 4-WHEEL STEERING)»(/chevrolet/avalanche/i-2001-2006/remont/mechanical-hydraulic/#disc-brakes__removal-right-rear-without-4-wheel) or «REMOVAL (RIGHT REAR -- WITH 4-WHEEL STEERING)»(/chevrolet/avalanche/i-2001-2006/remont/mechanical-hydraulic/#disc-brakes__removal-right-rear-with-4-wheel) in Park Brake.
  14. Install the tire and wheel assemblies. Refer to TIRE AND WHEEL REMOVAL AND INSTALLATION in Tires and Wheels.
  15. Connect the propeller shaft. Refer to PROPELLER SHAFT REPLACEMENT - REAR in Propeller Shaft.
  16. Fill the axle with lubricant. Use the proper fluid.
  17. Remove the jack stands.
  18. Lower the vehicle.
  1. Raise the vehicle. Refer to «LIFTING AND JACKING THE VEHICLE»(/chevrolet/avalanche/i-2001-2006/remont/hoistjack/#jacking-and-lifting-avalanche__lifting-and-jacking-the-vehicle) in General Information.
  2. Remove the axle lubricant. Refer to «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (8.6 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (9.5, 10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  3. Remove the rear axle assembly. Refer to «REAR AXLE REPLACEMENT (8.6 INCH, 9.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «REAR AXLE REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  4. Remove the brake caliper brackets. Refer to «REMOVAL (REAR -- UTILITY WITHOUT 4-WHEEL STEERING)»(/chevrolet/avalanche/i-2001-2006/remont/mechanical-hydraulic/#disc-brakes__removal-rear-utility-without-4-wheel) or «REMOVAL (REAR -- UTILITY WITH 4-WHEEL STEERING)»(/chevrolet/avalanche/i-2001-2006/remont/mechanical-hydraulic/#disc-brakes__removal-rear-utility-with-4-wheel) in Disc Brakes.
  5. Remove the wheel hub. Refer to «REAR AXLE HUB, BEARING, CUP, AND/OR SEAL REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) (10.5 inch axles only).
  6. Remove the rear axle cover housing and gasket. Refer to «REAR AXLE HOUSING COVER AND GASKET REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  7. Remove the brake backing plates. Refer to «REMOVAL (1500 SERIES UTILITY WITHOUT 4-WHEEL STEERING)»(/chevrolet/avalanche/i-2001-2006/remont/mechanical-hydraulic/#disc-brakes__removal-1500-series-utility-without-4-wheel) or «REMOVAL (1500 SERIES PICKUP & UTILITY WITH 4-WHEEL STEERING)»(/chevrolet/avalanche/i-2001-2006/remont/mechanical-hydraulic/#disc-brakes__removal-1500-series-pickup-utility) .
  8. Remove the axle shafts. Refer to «REAR AXLE SHAFT REPLACEMENT (8.6 INCH AXLE W/O JL4, 9.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «REAR AXLE SHAFT REPLACEMENT (8.6 INCH AXLE W/JL4)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «REAR AXLE SHAFT REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) (8.6 inch, 9.5 inch axles) or «REAR AXLE SHAFT AND/OR GASKET REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) (10.5 inch axles).
  9. Remove the differential. Refer to «DRIVE PINION AND RING GEAR REPLACEMENT (8.6 INCH, 9.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION AND RING GEAR REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION AND RING GEAR REPLACEMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  10. Remove the drive pinion. Refer to «DRIVE PINION AND RING GEAR REPLACEMENT (8.6 INCH, 9.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION AND RING GEAR REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION AND RING GEAR REPLACEMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  11. Remove the drive pinion shaft yoke and the seal. Refer to «DRIVE PINION FLANGE/YOKE AND/OR OIL SEAL REPLACEMENT (ALL EXCEPT 9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION FLANGE/YOKE AND/OR OIL SEAL REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  1. Install the drive pinion. Refer to «DRIVE PINION AND RING GEAR REPLACEMENT (8.6 INCH, 9.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION AND RING GEAR REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION AND RING GEAR REPLACEMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  2. Install the differential case. Refer to «DRIVE PINION AND RING GEAR REPLACEMENT (8.6 INCH, 9.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION AND RING GEAR REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION AND RING GEAR REPLACEMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  3. Adjust the side bearing preload. Refer to «DIFFERENTIAL SIDE BEARING PRELOAD ADJUSTMENT (8.6 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL SIDE BEARING PRELOAD ADJUSTMENT (9.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL SIDE BEARING PRELOAD ADJUSTMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL SIDE BEARING PRELOAD ADJUSTMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  4. Adjust the backlash. Refer to «BACKLASH ADJUSTMENT (ALL EXCEPT 9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «BACKLASH ADJUSTMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  5. Perform a gear tooth contact pattern check. Refer to «GEAR TOOTH CONTACT PATTERN INSPECTION»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle__gear-tooth-contact-pattern-inspection) .
  6. Install the brake backing plates. Refer to «REMOVAL (1500 SERIES UTILITY WITHOUT 4-WHEEL STEERING)»(/chevrolet/avalanche/i-2001-2006/remont/mechanical-hydraulic/#disc-brakes__removal-1500-series-utility-without-4-wheel) or «REMOVAL (1500 SERIES PICKUP & UTILITY WITH 4-WHEEL STEERING)»(/chevrolet/avalanche/i-2001-2006/remont/mechanical-hydraulic/#disc-brakes__removal-1500-series-pickup-utility) .
  7. Install the axle shafts. Refer to «REAR AXLE SHAFT REPLACEMENT (8.6 INCH AXLE W/O JL4, 9.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «REAR AXLE SHAFT REPLACEMENT (8.6 INCH AXLE W/JL4)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «REAR AXLE SHAFT REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) (8.6 inch, 9.5 inch axles) or «REAR AXLE SHAFT AND/OR GASKET REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) (10.5 inch axles).
  8. Install the rear axle housing cover and gasket. Refer to «REAR AXLE HOUSING COVER AND GASKET REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  9. Install the brake caliper brackets. Refer to «REMOVAL (REAR -- UTILITY WITHOUT 4-WHEEL STEERING)»(/chevrolet/avalanche/i-2001-2006/remont/mechanical-hydraulic/#disc-brakes__removal-rear-utility-without-4-wheel) or «REMOVAL (REAR -- UTILITY WITH 4-WHEEL STEERING)»(/chevrolet/avalanche/i-2001-2006/remont/mechanical-hydraulic/#disc-brakes__removal-rear-utility-with-4-wheel) in Disc Brakes.
  10. Install the wheel hub. Refer to «REAR AXLE HUB, BEARING, CUP, AND/OR SEAL REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) (10.5 inch axles only).
  11. Install the rear axle. Refer to «REAR AXLE REPLACEMENT (8.6 INCH, 9.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «REAR AXLE REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  12. Fill the axle with lubricant. Refer to «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (8.6 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (9.5, 10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  13. Lower the vehicle.
  1. Raise the vehicle. Refer to «LIFTING AND JACKING THE VEHICLE»(/chevrolet/avalanche/i-2001-2006/remont/hoistjack/#jacking-and-lifting-avalanche__lifting-and-jacking-the-vehicle) in General Information.
  2. Remove the steering gear protection shield. Refer to «STEERING GEAR PROTECTION SHIELD REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/electronic-steering/#rear-wheel-steering-system) in Rear Wheel Steering.
  3. Remove the axle lubricant. Refer to «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (8.6 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (9.5, 10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  4. Remove the rear axle assembly. Refer to «REAR AXLE REPLACEMENT (8.6 INCH, 9.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «REAR AXLE REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  5. Remove the steering knuckles. Refer to «STEERING KNUCKLE REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/electronic-steering/#rear-wheel-steering-system) in Rear Wheel Steering.
  6. Remove the axle shafts. Refer to «REAR AXLE SHAFT REPLACEMENT (8.6 INCH AXLE W/O JL4, 9.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «REAR AXLE SHAFT REPLACEMENT (8.6 INCH AXLE W/JL4)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «REAR AXLE SHAFT REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  7. Remove the differential. Refer to «DRIVE PINION AND RING GEAR REPLACEMENT (8.6 INCH, 9.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION AND RING GEAR REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION AND RING GEAR REPLACEMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  8. Remove the drive pinion shaft yoke and the pinion oil seal. Refer to «DRIVE PINION FLANGE/YOKE AND/OR OIL SEAL REPLACEMENT (ALL EXCEPT 9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION FLANGE/YOKE AND/OR OIL SEAL REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  9. Remove the drive pinion and the outer pinion bearing. Refer to «DRIVE PINION AND RING GEAR REPLACEMENT (8.6 INCH, 9.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION AND RING GEAR REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION AND RING GEAR REPLACEMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  10. Remove the pinion bearing cups. Refer to «DRIVE PINION BEARINGS REPLACEMENT (8.6, 9.5 INCH AXLES)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION BEARINGS REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION BEARINGS REPLACEMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  1. Install the pinion bearing cups. Refer to «DRIVE PINION BEARINGS REPLACEMENT (8.6, 9.5 INCH AXLES)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION BEARINGS REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION BEARINGS REPLACEMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  2. Install the drive pinion outer pinion bearing and the pinion oil seal. Refer to «DRIVE PINION FLANGE/YOKE AND/OR OIL SEAL REPLACEMENT (ALL EXCEPT 9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION FLANGE/YOKE AND/OR OIL SEAL REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  3. Install the drive pinion. Refer to «DRIVE PINION AND RING GEAR REPLACEMENT (8.6 INCH, 9.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION AND RING GEAR REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION AND RING GEAR REPLACEMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  4. Install the pinion yoke. Refer to «DRIVE PINION FLANGE/YOKE AND/OR OIL SEAL REPLACEMENT (ALL EXCEPT 9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION FLANGE/YOKE AND/OR OIL SEAL REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  5. Install the differential case. Refer to «DRIVE PINION AND RING GEAR REPLACEMENT (8.6 INCH, 9.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION AND RING GEAR REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION AND RING GEAR REPLACEMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  6. Adjust the side bearing preload. Refer to «DIFFERENTIAL SIDE BEARING PRELOAD ADJUSTMENT (8.6 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL SIDE BEARING PRELOAD ADJUSTMENT (9.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL SIDE BEARING PRELOAD ADJUSTMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL SIDE BEARING PRELOAD ADJUSTMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  7. Adjust the backlash. Refer to «BACKLASH ADJUSTMENT (ALL EXCEPT 9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «BACKLASH ADJUSTMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  8. Perform a gear tooth contact pattern check. Refer to «GEAR TOOTH CONTACT PATTERN INSPECTION»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle__gear-tooth-contact-pattern-inspection) .
  9. Install the axle shafts. Refer to «REAR AXLE SHAFT REPLACEMENT (8.6 INCH AXLE W/O JL4, 9.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «REAR AXLE SHAFT REPLACEMENT (8.6 INCH AXLE W/JL4)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «REAR AXLE SHAFT REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  10. Install the steering knuckles. Refer to «STEERING KNUCKLE REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/electronic-steering/#rear-wheel-steering-system) in Rear Wheel Steering.
  11. Install the rear axle. Refer to «REAR AXLE REPLACEMENT (8.6 INCH, 9.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «REAR AXLE REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  12. Install the steering gear protection shield. Refer to «STEERING GEAR PROTECTION SHIELD REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/electronic-steering/#rear-wheel-steering-system) in Rear Wheel Steering.
  13. Fill the axle with lubricant. Refer to «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (8.6 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (9.5, 10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «LUBRICANT REPLACEMENT - REAR DRIVE AXLE (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  14. Lower the vehicle.

Scheme 442

Scheme 442: Disassembly Procedure

Scheme 443

Scheme 443

Scheme 444

Scheme 444
  1. Remove the differential side bearings. Refer to «DIFFERENTIAL SIDE BEARINGS REPLACEMENT (ALL EXCEPT 9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL SIDE BEARINGS REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) . Important: The ring gear bolts have left-hand threads.
  2. Remove the gear bolts. Discard the bolts. NOTE: Refer to «RING GEAR REMOVAL NOTICE»(/chevrolet/avalanche/i-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__ring-gear-removal-notice) in Cautions and Notices.
  3. Remove the ring gear from the differential case. Drive the ring gear off with a brass drift if necessary.
  4. Remove the differential pinion gears and the differential side gears by performing the following steps: Remove the pinion shaft lock bolt. Remove the pinion shaft. Roll the differential pinion gears out of the case with the pinion gear thrust washers. Remove the differential side gears and the side gear thrust washers. Mark the pinion gears top and bottom and the differential side gears left and right.

Scheme 445

Scheme 445: Assembly Procedure

Scheme 446

Scheme 446

Scheme 447

Scheme 447
  1. Lubricate the pinion and side gears using axle lubricant. Use the proper fluid.
  2. Install the differential side gear thrust washers to the differential side gears.
  3. Install the differential side gears and thrust washers into the differential case. If the same differential side gears and the thrust washers are being used, install the gears and the thrust washers to their original locations.
  4. Install the differential pinion gears and pinion gear thrust washers by performing the following steps: Position one pinion gear between the differential side gears. Position the second pinion gear between the differential side gears directly opposite the of the first gear. Rotate the differential side gears until the pinion gears is directly opposite the opening in the differential case. Install the thrust washers. Rotate the pinion gears toward the differential opening in order to permit the sliding in of the thrust washers.
  5. Install the pinion shaft. NOTE: Refer to «FASTENER NOTICE»(/chevrolet/avalanche/i-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__fastener-notice) in Cautions and Notices.
  6. Install a new pinion shaft lock bolt. Tighten: Tighten the new pinion shaft lock bolt to 36 N.m (27 lb ft). Important: The mating surface of the ring gear and the differential case must be clean and free of burrs before installing the ring gear.
  7. Install the ring gear to the differential case. Important: The ring gear bolts have left-hand threads.
  8. Install the new ring gear bolts. Hand start each bolt to ensure that the ring gear is properly installed to the differential case.
  9. Tighten the ring gear bolts. Tighten the bolts alternately and in stages, gradually pulling the ring gear onto the differential case. Tighten: Tighten the ring gear bolts in sequence to 120 N.m (89 lb ft).
  10. Install the differential side bearings. Refer to «DIFFERENTIAL SIDE BEARINGS REPLACEMENT (ALL EXCEPT 9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL SIDE BEARINGS REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  1. J 8092 Universal Driver Handle - 3/4 in - 10
  2. J 22888-D Side Bearing Puller Kit
  3. J 29710 Differential Side Bearing Installer
  4. J 36597 Side Bearing Puller Pilot - 9.25 inch

Scheme 448

Scheme 448: Disassembly Procedure

Scheme 449

Scheme 449

Scheme 450

Scheme 450

Scheme 451

Scheme 451
  1. Remove the differential side bearings by performing the following steps: Install the differential assembly into a vise. Install the J 36597 (1) and the J 22888-20A (2) as shown. Remove the differential side bearings using the J 22888-20A . Important: The ring gear bolts have left-hand threads.
  2. Remove the gear bolts. Discard the bolts. NOTE: Refer to «RING GEAR REMOVAL NOTICE»(/chevrolet/avalanche/i-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__ring-gear-removal-notice) in Cautions and Notices.
  3. Remove the ring gear from the differential case. Drive the ring gear off with a brass drift if necessary.
  4. Remove the differential pinion gears and the differential side gears by performing the following steps: Remove the pinion shaft lock bolt. Remove the pinion shaft. Drive the pinion gear thrust washer out from the differential case using a hammer and a brass drift. Roll the differential pinion gears out of the differential case. Remove the differential side gears and the side gear thrust washers. Mark the pinion gears top and bottom and the differential side gears left and right.

Scheme 452

Scheme 452: Assembly Procedure

Scheme 453

Scheme 453

Scheme 454

Scheme 454

Scheme 455

Scheme 455
  1. Lubricate the pinion and side gears using axle lubricant. Use the proper fluid.
  2. Install the differential side gear thrust washers to the differential side gears.
  3. Install the differential side gears and thrust washers into the differential case. If the same differential side gears and the thrust washers are being used, install the gears and the thrust washers to their original locations.
  4. Install the differential pinion gears by performing the following steps: Position one of the pinion gears between the differential side gears. Install the second pinion gear directly opposite of the first gear between the differential side gears. Rotate the differential side gears until the pinion gears are directly opposite the opening in the differential case. Install the pinion gear thrust washers using a hammer and a brass drift.
  5. Install the pinion shaft. NOTE: Refer to «FASTENER NOTICE»(/chevrolet/avalanche/i-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__fastener-notice) in Cautions and Notices.
  6. Install a new pinion shaft lock bolt. Tighten: Tighten the new pinion shaft lock bolt to 50 N.m (37 lb ft). Important: The mating surface of the ring gear and the differential case must be clean and free of burrs before installing the ring gear.
  7. Install the ring gear to the differential case. Important: The ring gear bolts have left-hand threads.
  8. Install the new ring gear bolts. Hand start each bolt to ensure that the ring gear is properly installed to the differential case.
  9. Tighten the ring gear bolts. Tighten the bolts alternately and in stages, gradually pulling the ring gear onto the differential case. Tighten: Tighten the ring gear bolts in sequence to 140 N.m (103 lb ft).
  10. Install the differential side bearings by performing the following steps: In order to protect the differential case, install the J 36597 in the case on the side opposite the bearing installation. Install the J 29710 (2) and the J 8092 (1) onto the differential case bearing as shown. Drive the bearing onto the case using the J 29710 and the J 8092 .
  1. J 8092 Universal Driver Handle - 3/4 in - 10
  2. J 22888-D Side Bearing Remover Kit
  3. J 29710 Differential Side Bearing Installer

Scheme 456

Scheme 456: Disassembly Procedure

Scheme 457

Scheme 457

Scheme 458

Scheme 458
  1. Remove the differential side bearings by performing the following steps: Place a block of wood on each side of the differential case before installing the differential case into the vise. Install the differential assembly into a vise. Install the J 8107-3 (1) and the J 22888-20A (2) onto the differential side bearing. Remove the differential side bearings using the J 22888-20A . Important: The ring gear bolts have left-hand threads.
  2. Remove the ring gear bolts. NOTE: Refer to «RING GEAR REMOVAL NOTICE»(/chevrolet/avalanche/i-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__ring-gear-removal-notice) in Cautions and Notices.
  3. Remove the ring gear from the differential case. Drive the ring gear off with a brass drift if necessary.
  4. Separate the differential case assembly. Important: If the differential pinion gears, the differential side and the thrust washers are to be reused, mark the components so they can be re-installed in their original location in the differential case.
  5. Remove the following from the differential case: The thrust washers The differential pinion gears The differential pinion spider
  6. Remove the differential side gears.

Scheme 459

Scheme 459: Assembly Procedure

Scheme 460

Scheme 460

Scheme 461

Scheme 461

Scheme 462

Scheme 462
  1. Lubricate the differential side gears and the differential pinion gears with axle lubricant. Use the proper fluid.
  2. Install the differential side gears into the differential case. If the original differential side gears are being used, install the gears in the original location.
  3. Assemble the differential pinion gears and the thrust washers to the differential spider as shown. If the original differential pinion gears, the thrust washers and the differential spider are being used, install the components in the original locations.
  4. Assemble the differential case halves. Align the arrow in the differential case as shown. Important: The mating surface of the ring gear and the differential case must be clean and free of burrs before installing the ring gear.
  5. Install the ring gear to the differential case. NOTE: Refer to «FASTENER NOTICE»(/chevrolet/avalanche/i-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__fastener-notice) in Cautions and Notices.
  6. Install the new ring gear bolts. Hand start each bolt to ensure that the ring gear is properly installed to the differential case.
  7. Tighten the ring gear bolts. Tighten the bolts alternately and in stages, gradually pulling the ring gear onto the differential case. Tighten: Tighten the ring gear bolts in sequence to 165 N.m (122 lb ft).
  8. Install the differential side bearings by performing the following steps: In order to protect the differential case, install the J 8107-3 in the case on the side opposite the bearing installation. Install the J 29710 and the J 8092 onto the differential case bearing. Drive the bearing onto the case using the J 29710 and the J 8092 .

Bearings Inspection

Carefully and thoroughly inspect all drive unit parts before assembly. Thorough inspection of the drive parts for wear or stress with subsequent replacement of worn parts eliminates costly drive component repair after assembly.

Important: The differential bearings and the bearing cups are matched sets. Replace both the bearing and the cup when either part requires replacement.

  1. Lubricate the bearings with axle lubricant. Inspect the bearings for smooth rotation.
  2. Inspect the bearing rollers for wear.
  3. Inspect the bearing cups for wear, cracks, brinelling, and scoring.

Differential Inspection

  1. Check the pinion gear shaft for unusual wear.
  2. Check the pinion and the side gear teeth for wear, cracks, scoring and spalling.
  3. Check the thrust washers for wear.
  4. Check the fit of the side gears in the differential case and on the axle shafts.
  5. Check the differential case for cracks and scoring and replace all of the worn parts as necessary.

Pinion and Ring Gear Inspection

Ring and pinion gears are matched sets. When replacement of one or the other is necessary, both the ring and pinion gear must be replaced.

  1. Check the pinion and ring gear teeth for cracking, chipping, scoring, or excessive wear.
  2. Check the pinion gear splines for wear.
  3. Check the pinion flange/yoke splines for wear.
  4. Check the fit of the pinion gear splines on the pinion flange/yoke.
  5. Check the sealing surface of the pinion flange/yoke for nicks, burrs or rough tool marks that could damage the seal and cause an oil leak.
  6. Check for worn or broken parts and replace as necessary.

Rear Axle Housing Inspection

Carefully and thoroughly inspect all drive unit parts before assembly. Thorough inspection of the drive parts for wear or stress with subsequent replacement of worn parts eliminates costly drive component repair after assembly.

  1. Inspect for nicks or burrs that could prevent the outer diameter of the pinion seal from sealing. Remove any burrs.
  2. Inspect the bearing cup bores for nicks or burrs. Remove any burrs that are found.
  3. Inspect the housing for cracks. Replace the housing if any cracks are found.
  4. Inspect the housing for foreign material such as metal chips, dirt, or rust.

Shims Inspection

Important

  1. Do not reinstall the original cast iron production shims, if removed. Once the cast iron shims are removed from the axle housing, they must be replaced with service shims and spacers.
  2. If service shims were previously installed, the shims can be reused.

Inspect the shims for cracks and chips. Replace the damaged shims.

  1. J 21777-85 Gage and Plate, 9.5 inch axle
  2. J 21777-86 Side Bearing Disc, 9.5 inch axle, 2 Required
  3. J 34925 Pinion Setting Gage and Components
  4. J 8001 Dial Indicator

Important: Make sure all of the tools, the differential side bearing bores, and the pinion bearing cups are clean before proceeding.

Scheme 463

Scheme 463

Scheme 464

Scheme 464

Scheme 465

Scheme 465

Scheme 466

Scheme 466
  1. Lubricate the pinion bearings with axle lubricant.
  2. Install the pinion bearings into the axle housing.
  3. Assemble the following components into the axle housing: For the 8.6 in axle, assemble the J 21777-35 (1), the J 21777-43 (2), the J 21777-42 (3), and the J 21777-29 (4) as shown. For the 9.5 in axle, assemble the J 21777-8 (1), the J 21777-43 (2), the J 21777-42 (3), and the J 21777-85 (4) as shown.
  4. While holding the J 21777-43 stationary, install an inch-pound torque wrench on the nut of the J 21777-43 and tighten the nut until a rotating torque of 1.7 N.m (15 lb in) is obtained. Rotate the assembly several times in both directions in order to seat the pinion bearings.
  5. Check the rotating torque of the assembly. If the torque is less than 1.7 N.m (15 lb in), tighten the nut on the J 21777-43 until a rotating torque of 1.7-2.3 N.m (15-20 lb in) is obtained.
  6. Assemble the following components into the differential carrier bore of the axle housing: For the 8.6 in axle, assemble the J 21777-45 (1, 2) to the J 21777-1 (3) as shown. For the 9.5 in axle, assemble the J 21777-86 (1, 2) to the J 21777-1 (3) as shown.
  7. Install the bearing caps. NOTE: Refer to «FASTENER NOTICE»(/chevrolet/avalanche/i-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__fastener-notice) in Cautions and Notices.
  8. Install the bearing cap bolts. Tighten: Tighten the bearing cap bolts to 75 N.m (55 lb ft).
  9. Rotate the J 21777-1 within the J 21777-45, 8.6 inch axle, or the J 21777-86 , 9.5 inch axle. The J 21777-1 must rotate back and forth freely within the discs. If the J 21777-1 does not rotate freely, disassemble the components, inspect for proper seating and/or mis-aligned components and re-assemble.
  10. Align the plunger of the J 21777-1 (1) to the 8.5 in gage block setting of the J 21777-29, 8.6 inch axle, or the J 21777-85 , 9.5 inch axle (2).
  11. Install the J 8001 to the J 21777-1 as follows: Loosely clamp the J 8001 onto the stem on the J 21777-1. Place the contact pad of the J 8001 onto the mounting post of the J 21777-1. With the contact pad of the J 8001 touching the mounting post of the J 21777-1, loosen the lock nut on the J 8001 and push down on the J 8001 until the needle the J 8001 has turned 3/4 of a turn clockwise. Tighten the clamp on the J 8001 finger tight.
  12. Move the plunger of the J 21777-1 back and forth until the needle of the J 8001 indicates the greatest deflection. The deflection is the point where the needle changes direction.
  13. At the greatest point of deflection, move the housing of the J 8001 until the needle indicates zero.
  14. Move the plunger of the J 21777-1 back and forth again to verify the zero setting. Adjust the housing of the J 8001 as necessary to set the needle to zero.
  15. Rotate the plunger of the J 21777-1 away from the J 21777-29, 8.6 inch axle, or the J 21777-85 , 9.5 inch axle, until it no longer touches the J 21777-29 or the J 21777-85 .
  16. The value indicated on the J 8001 is the thickness of the shim needed in order to set the depth of the pinion.
  17. Select the shim that indicates the proper thickness. Measure the shim with a micrometer in order to verify that the thickness is correct
  18. Remove the pinion depth setting tools.
  19. Remove the pinion bearings.
  20. Install the pinion shim between the pinion gear and the inner pinion bearing. Refer to «DRIVE PINION BEARINGS REPLACEMENT (8.6, 9.5 INCH AXLES)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION BEARINGS REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION BEARINGS REPLACEMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  1. J 22536 Pinion Driver
  2. J 24433 Pinion Cone and Side Bearing Installer
  3. J 34925 Pinion Setting Gage and Components
  4. J 45692 Pinion Shim Selector Kit - Dana Axles
  5. J 45710 Pinion Bearing Oil Seal Installer
  6. J 8001 Dial Indicator Set
  7. J 8614-01 Flange and Pulley Holding Tool

Important

Scheme 467

Scheme 467
  1. Make sure all of the tools, the differential side bearing bores, and the pinion bearing cups are clean before proceeding.
  2. The oil deflector must be installed behind the inner pinion bearing cup in order to obtain the correct pinion depth measurement

Scheme 468

Scheme 468

Scheme 469

Scheme 469

Scheme 470

Scheme 470

Scheme 471

Scheme 471

Scheme 472

Scheme 472

Scheme 473

Scheme 473

Scheme 474

Scheme 474

Scheme 475

Scheme 475

Scheme 476

Scheme 476

Scheme 477

Scheme 477

Scheme 478

Scheme 478

Scheme 479

Scheme 479

Scheme 480

Scheme 480
  1. Lubricate the pinion bearings with axle lubricant.
  2. Assemble the J 45692-5 (2) and the outer pinion bearing onto the J 21777-43 (1) as shown.
  3. Install the J 45692-5, the outer pinion bearing, and the J 21777-43 into the axle housing.
  4. Install the inner pinion bearing into the axle housing.
  5. Install the J 21777-35 into the inner pinion bearing as shown.
  6. Install the J 45692-1 into the axle housing as shown.
  7. While holding the J 21777-43 stationary, tighten the nut on the J 21777-43 just until the end play between the pinion bearings is removed.
  8. Rotate the assembly several times in both directions in order to seat the pinion bearings.
  9. Measure the rotating torque of the assembly using an inch-pound torque wrench. Specification The rotating torque of the assembly should be between 2.3-5.1 N.m (20-45 lb in).
  10. If the rotating torque of the assembly is less than 2.3 N.m (20 lb in), continue to tighten the nut of the J 21777-43 until a rotating torque of 2.3-5.1 N.m (20-45 lb in) is obtained.
  11. Assemble the J 45692-2 (1) and the J 21777-1 (2) as shown.
  12. Install the J 45692-2 (1) and the J 21777-1 (2) into the axle housing. Place the stem of the J 21777-1 onto the bottom step of the J 45692-1. NOTE: Refer to «FASTENER NOTICE»(/chevrolet/avalanche/i-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__fastener-notice) in Cautions and Notices. Important: Corresponding letters are stamped on the bearing caps and axle housing. The bearing caps must be reassembled in the same position as removed.
  13. Install the bearing caps and bearing cap bolts. Tighten: Tighten the bearing cap bolts to 75 N.m (55 lb ft).
  14. Rotate the J 21777-1 within the J 45692-2. The J 21777-1 must rotate back and forth freely with the discs. If the J 21777-1 does not rotate freely, disassemble the components, inspect for proper seating and/or mis-aligned components and re-assemble.
  15. Install the J 8001 to the J 21777-1 as follows: Loosely clamp the J 8001 onto the stem on the J 21777-1. Place the contact pad of the J 8001 onto the mounting post of the J 21777-1. With the contact pad of the J 8001 touching the mounting post of the J 21777-1, loosen the lock nut on the J 8001 and push down on the J 8001 until the needle the J 8001 has turned 3/4 of a turn clockwise. Tighten the clamp on the J 8001 finger tight.
  16. Move the plunger of the J 21777-1 (1) back and forth on the bottom step of the J 45692-1 (2) until the needle of the J 8001 indicates the greatest deflection. The deflection is the point where the needle changes direction.
  17. At the greatest point of deflection, move the indicator housing of the J 8001 until the needle indicates ZERO.
  18. Move the plunger of the J 21777-1 back and forth again to verify the ZERO setting. Adjust the housing of the J 8001 as necessary to set the needle to ZERO.
  19. Rotate the plunger of the J 21777-1 (1) away from the J 45692-1 (2). The value indicated is the amount of pinion shim thickness required for a nominal pinion setting.
  20. In order to adjust the pinion shim thickness for the drive pinion that is to be installed, do the following: Read the number on the button end of the pinion. If the number on the button end of the pinion is "0", no adjustment of the pinion preload shim pack is necessary. If the number is not "0", the number will also have a corresponding "+" or "-" in front of it. The "+" or "-" indicates the amount of pinion preload shim thickness that either needs to be added to or subtracted from the amount determined in step 19 in order to the drive pinion gear to be positioned properly within the axle housing. For example, if the number on the button end of the pinion is a "+3", this indicates that 0.0762 mm (0.003 in) of shim thickness will need to be subtracted from the value determined in step 19 in order to place the teeth of the pinion in the best running position with the teeth of the ring gear. Refer to the table. If the number on the button end of the pinion is a "-3", this indicates that 0.0762 mm (0.003 in) of shim thickness will need to be added to the value determined in step 19 in order to place the teeth of the pinion in the best running position with the teeth of the ring gear. Refer to the table.
  21. Remove the pinion depth setting tools.
  22. Remove the pinion bearings.
  23. Install the pinion position shim onto the drive pinion. Measure the thickness of the shim with a micrometer in order to verify the thickness.
  24. Install the inner pinion bearing onto the drive pinion using the J 24433 .
  25. Install the original pinion preload shims onto the drive pinion. If the original shims are not available, assemble 1.52 mm (0.060 in) of pinion preload shims to install. Measure each shim separately with a micrometer and add the thickness together to determine the total shim pack size.
  26. Install the drive pinion with the inner pinion bearing and the pinion preload shims into the axle housing.
  27. Install the outer pinion bearing.
  28. Install the thrust washer.
  29. Seat the pinion yoke onto the pinion shaft by tapping it with a soft-faced hammer until a few pinion shaft threads show through the yoke.
  30. Install the pinion yoke nut washer.
  31. Install the pinion yoke nut. Tighten: Tighten the pinion yoke nut to 252 N.m (186 lb ft).
  32. Measure the rotating torque of the drive pinion using an inch-pound torque wrench. Specification The rotating torque of the drive pinion should be between 2.3-5.1 N.m (20-45 lb in).
  33. If the rotating torque of the drive pinion is not within specifications, adjust the pinion preload shim thickness by doing the following: Install the J 8614-01 to the pinion yoke. Remove the pinion nut while holding the J 8614-01 . Remove the washer. Install the J 8614-2 (2) and the J 8614-3 (3) into the J 8614-01 (1) as shown. Remove the pinion yoke by turning the J 8614-3 (3) clockwise while holding the J 8614-01 (1). Remove the thrust washer. Install the J 22536 . Ensure that the J 22536 is firmly seated on the drive pinion. Drive the pinion out using the J 22536 and a hammer. Remove the outer pinion bearing. Remove the pinion preload shim(s). Adjust the amount of pinion preload shim thickness by doing the following: Important: Removing approximately 0.0254 mm (0.001 in) of shim thickness will increase the rotating torque by approximately 71-89 N.m (8-10 lb in). If the rotating torque is too low, remove the appropriate amount of shim thickness from the shim thickness pack using the guideline above. Measure each shim separately with a micrometer and add the thickness together to determine the total shim pack size. Important: Adding approximately 0.0254 mm (0.001 in) of shim thickness will decrease the rotating torque by approximately 71-89 N.m (8-10 lb in). If the rotating torque is too high, add the appropriate amount of shim thickness to the shim thickness pack using the guideline above. Measure each shim separately with a micrometer and add the thickness together to determine the total shim pack size.
  34. Install the new pinion preload shim pack onto the drive pinion.
  35. Install the drive pinion with the inner pinion bearing and the pinion preload shims into the axle housing.
  36. Install the outer pinion bearing.
  37. Install the thrust washer.
  38. Seat the pinion yoke onto the pinion shaft by tapping it with a soft-faced hammer until a few pinion shaft threads show through the yoke.
  39. Install the pinion yoke nut washer.
  40. Install the pinion yoke nut. Tighten: Tighten the pinion yoke nut to 252 N.m (186 lb ft).
  41. Measure the rotating torque of the drive pinion using an inch-pound torque wrench. Specification The rotating torque of the drive pinion should be between 2.3-5.1 N.m (20-45 lb in).
  42. If the rotating torque of the drive pinion is not within specification, adjust the pinion bearing preload shim pack as necessary following the steps above.
  43. If the rotating torque is within specifications, install the J 8614-01 to the pinion yoke.
  44. Remove the pinion nut while holding the J 8614-01 .
  45. Remove the washer.
  46. Install the J 8614-2 (2) and the J 8614-3 (3) into the J 8614-01 (1) as shown.
  47. Remove the pinion yoke by turning the J 8614-3 (3) clockwise while holding the J 8614-01 (1).
  48. Apply a light coat of axle lubricant, GM P/N 12378557 or equivalent meeting GM Specification 9986207, to lip of the pinion seal.
  49. Install the new pinion oil seal using the J 45710 .
  50. Seat the pinion yoke onto the pinion shaft by tapping it with a soft-faced hammer until a few pinion shaft threads show through the yoke.
  51. Install the pinion yoke nut washer.
  52. Install the new pinion yoke nut. Tighten: Tighten the pinion yoke nut to 370 N.m (272 lb ft).
  53. Measure the rotating torque of the drive pinion using an inch-pound torque wrench. Specification The rotating torque of the drive pinion should be between 2.3-5.1 N.m (20-45 lb in).

Pinion Depth Adjustment (10.5 Inch Axle)

  1. Install the differential, if necessary. Refer to «DIFFERENTIAL REPLACEMENT (8.6 INCH, 9.5 INCH AXLES)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL REPLACEMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) . Important: Measure and record the thickness of the pinion gear bearing retainer shim before any service procedures are performed to the pinion gear bearing retainer assembly.
  2. Install the original shim to the pinion bearing retainer. If the original shim is not available; Install a 0.41 mm (0.016 in) shim to build pinion depth. Important: Do not apply sealant to the pinion gear bearing retainer at this time.
  3. Install the pinion gear bearing retainer. NOTE: Refer to «FASTENER NOTICE»(/chevrolet/avalanche/i-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__fastener-notice) in Cautions and Notices.
  4. Install the pinion gear bearing retainer bolts. Tighten: Tighten the pinion gear bearing retainer bolts to 88 N.m (65 lb ft).
  5. Adjust the backlash. Refer to «BACKLASH ADJUSTMENT (ALL EXCEPT 9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «BACKLASH ADJUSTMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  6. Perform a gear tooth pattern check on the pinion and the ring gear. Refer to «GEAR TOOTH CONTACT PATTERN INSPECTION»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle__gear-tooth-contact-pattern-inspection) .
  7. If the gear tooth contact pattern indicates a high or a low flank contact pattern; adjust the pinion depth by doing the following: Remove the pinion gear bearing retainer bolts. Remove the pinion gear bearing retainer. Remove the shim. If the gear tooth contact pattern shows a high flank contact pattern: Install a shim one size larger. If the gear tooth contact pattern shows a low flank contact pattern: Install a shim one size smaller. Install the new shim to the pinion gear bearing retainer. Install pinion gear bearing retainer. Install pinion gear bearing retainer bolts. Tighten: Tighten the pinion gear bearing retainer bolts to 88 N.m (65 lb ft). Recheck the gear tooth contact pattern of the pinion and the ring gear. Refer to «GEAR TOOTH CONTACT PATTERN INSPECTION»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle__gear-tooth-contact-pattern-inspection) . If the gear tooth pattern is still incorrect; adjust the shim thickness as necessary; and recheck the gear tooth pattern of the pinion and the ring gear.
  8. Recheck the backlash between the pinion and the ring gear and adjust, if necessary. Refer to «BACKLASH ADJUSTMENT (ALL EXCEPT 9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «BACKLASH ADJUSTMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .

The pinion shims are available in the following sizes

Shim Sizes

  1. 0.15 mm (0.006 in)
  2. 0.18 mm (0.007 in)
  3. 0.20 mm (0.008 in)
  4. 0.23 mm (0.009 in)
  5. 0.25 mm (0.010 in)
  6. 0.28 mm (0.011 in)
  7. 0.30 mm (0.012 in)
  8. 0.33 mm (0.013 in)
  9. 0.36 mm (0.014 in)
  10. 0.38 mm (0.015 in)
  11. 0.41 mm (0.016 in)
  12. 0.43 mm (0.017 in)
  13. 0.46 mm (0.018 in)
  14. 0.48 mm (0.019 in)
  15. 0.51 mm (0.020 in)
  16. 0.53 mm (0.021 in)
  17. 0.56 mm (0.022 in)
  18. 0.58 mm (0.023 in)
  19. 0.61 mm (0.024 in)
  1. J 8092 Universal Drive Handle - 3/4 in - 10
  2. J 24430 Differential Side Bearing Installer
  3. J 36597 Side Bearing Puller Pilot - 9.25 in
  4. J 45900 Differential Side Bearing Installer - Dana Axles

Scheme 481

Scheme 481

Scheme 482

Scheme 482

Scheme 483

Scheme 483
  1. Remove the differential side bearing shims. Refer to «DRIVE PINION BEARINGS REPLACEMENT (8.6, 9.5 INCH AXLES)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION BEARINGS REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION BEARINGS REPLACEMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  2. Determine the pinion position shim and the pinion preload shims, if necessary. Refer to «PINION DEPTH ADJUSTMENT (8.6 INCH, 9.5 INCH AXLES)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «PINION DEPTH ADJUSTMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «PINION DEPTH ADJUSTMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle__pinion-depth-adjustment-105-inch-axle) .
  3. Install the differential side bearing without the side bearing shims by doing the following: In order to protect the differential case, install the J 36597 in the case on the side opposite of the bearing installation. Install the differential side bearing. Install the J 24430 or the J 45900 (2) and the J 8092 (1) over the differential side bearing. Drive the differential side bearing into position using the J 24430 or the J 45900 and the J 8092 .
  4. Install the differential assembly into the axle housing.
  5. Move the differential assembly to the left until the left differential side bearing is against the left side bearing bore. Important: Install the bearing caps into the same position from which each was removed.
  6. Install the left side bearing cap. NOTE: Refer to «FASTENER NOTICE»(/chevrolet/avalanche/i-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__fastener-notice) in Cautions and Notices.
  7. Install the left side bearing cap bolts. Tighten: Tighten the bearing cap bolts finger tight. Do not torque the bolts to specification at this time.
  8. While holding the differential assembly against the left side bearing bore, press the right side bearing cup against the right differential side bearing. Important: In order to accurately measure the differential side bearing shim thickness, the differential side bearing cup must be evenly seated against the differential side bearing.
  9. Using a feeler gauge, measure the distance between the right side bearing cup and the right side bearing bore. Use progressively larger feeler gauge sizes until a moderate drag is felt. Repeat this step several times while rotating the differential case in order to obtain a consistent reading. This measurement, measurement a, is the total shim pack thickness for the differential assembly without preload. CAUTION: To prevent personal injury and/or component damage, support the differential case when removing the case from the axle housing. If the case is not supported, the differential case could fall and cause personal injury or damage to the differential case.
  10. Remove the left side bearing cap bolts.
  11. Remove the left side bearing cap.
  12. Install the right side bearing cap.
  13. Install the right side bearing cap bolts. Tighten: Tighten the bearing cap bolts finger tight. Do not torque the bolts to specification at this time.
  14. While holding the differential assembly ring gear against the drive pinion, press the left side bearing cup against the left differential side bearing. Important: In order to accurately measure the differential side bearing shim thickness, the differential side bearing cup must be evenly seated against the differential side bearing.
  15. Using a feeler gauge, measure the distance between the left side bearing cup and the left side bearing bore. Use progressively larger feeler gauge sizes until a moderate drag is felt. Repeat this step several times while re-positioning the differential case in order to obtain a consistent reading. This measurement, measurement b, is the left side shim pack thickness for the differential assembly without preload.
  16. In order to determine the right side shim pack thickness, subtract the left side measurement, measurement b, from the total shim pack measurement, measurement a. This measurement is the thickness for the right side shim pack without preload or setting the initial backlash.
  17. Remove the right side bearing cap bolts.
  18. Remove the right side bearing cap.
  19. Remove the differential assembly.
  20. Determine the differential side bearing preload. Refer to «DIFFERENTIAL SIDE BEARING PRELOAD ADJUSTMENT (8.6 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL SIDE BEARING PRELOAD ADJUSTMENT (9.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL SIDE BEARING PRELOAD ADJUSTMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL SIDE BEARING PRELOAD ADJUSTMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  1. J 22779 Side Bearing Backlash Gage
  2. J 25588 Side Bearing Shim Installer
  3. J 25025 Guide Pins
  4. J 8001 Dial Indicator Set

Important

  1. The differential side bearing preload adjustment must be completed before the backlash adjustment can be started.
  2. In order to maintain the original backlash, adjust the differential case side bearing preload by changing the thickness of the left and the right side shim packs equally.
  3. Measure the service shims and the spacers one at a time. Add the measurements together in order to obtain the total thickness of the left or the right side shim pack.
  4. Do not use or reuse the original cast iron production shims. Use service shims and spacers instead.
  1. Install the drive pinion, if necessary. Refer to «DRIVE PINION AND RING GEAR REPLACEMENT (8.6 INCH, 9.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION AND RING GEAR REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION AND RING GEAR REPLACEMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  2. Measure the rotating torque of the drive pinion using an inch-pound torque wrench. Specification The rotating torque of the drive pinion should be 1.7-3.4 N.m (15-30 lb in) for new bearings or 1.1-2.3 N.m (10-20 lb in) for used bearings. Record the measurement. Important: Before installation of the differential assembly, ensure that the differential side bearing surfaces in the axle housing are clean and free of burrs. If the original differential side bearings are to be reused, the original differential side bearing cups must also be used.
  3. Install the differential assembly with the differential side bearings and differential side bearing cups into the axle housing.
  4. Insert one 4.318 mm (0.170 in) thick service spacer into the left side of the axle housing.
  5. Side the differential assembly towards the service spacer in order to hold the spacer in place.
  6. Install the J 22779 between the right side differential side bearing cup and the axle housing. Important: Over-tightening may spread the housing and result in incorrect shim selection.
  7. Tighten the knob on the J 22779 until there is moderate drag when the J 22779 is moved.
  8. Remove the J 22779 .
  9. Remove the service spacer.
  10. Using a micrometer, measure the thickness of the J 22779 in 3 locations.
  11. Calculate the average of the 3 measurements. Record the measurement.
  12. Using a micrometer, measure the thickness of the service spacer. Record the measurement.
  13. Add the thickness of the service spacer to the average thickness of the J 22779 . The resulting value is the total service shim thickness without preload for the axle.
  14. Insert one 1.016 mm (0.040 in) service shim between the right side differential side bearing cup and the axle housing.
  15. Insert one BENT 1.016 mm (0.040 in) service shim between the right side differential side bearing cup and the service shim.
  16. Install the J 22779 on the left side of the differential assembly.
  17. While rotating the ring gear back and forth, tighten the knob on the J 22779 until there is approximately 0.025-0.051 mm (0.001-0.002 in) of backlash between the ring gear and the drive pinion.
  18. Once the amount of backlash is obtained, remove the J 22779 .
  19. Remove the differential case with the differential side bearings and the differential side bearing cups.
  20. Remove the service shims.
  21. Using a micrometer, measure the thickness of the J 22779 in 3 locations.
  22. Calculate the average of the 3 measurements. This value is the left side service shim thickness without preload.
  23. Subtract the service shim thickness for the left side of the axle, calculated in step 22, from the total service shim thickness, calculated in step 13. This value is the service shim thickness for the right side of the axle without preload.
  24. In order to initially set the preload of the differential side bearings and the backlash to approximately 0.013-0.023 mm (0.005-0.009 in), take the value determined in step 23 and add 0.0203 mm (0.008 in) service shim thickness to this amount.
  25. Assemble the left side shim pack using one 4.318 mm (0.170 in) service spacer and the appropriate amount of selective service shims equaling the thickness determined in step 22. Measure the service spacer and the service shims separately. Add the measurements together in order to determine the total shim pack thickness.
  26. Assemble the right side shim pack using one 4.318 mm (0.170 in) service spacer and the appropriate amount of selective service shims equaling the thickness determined in step 24. Measure the service spacer and the service shims separately. Add the measurements together in order to determine the total shim pack thickness.
  27. Install the differential assembly with the differential side bearings and the differential side bearing cups.
  28. Install the left side service spacer between the axle housing and the differential assembly.
  29. Install the left side selective service shim or shims. The service shim or shims must be installed between the service spacer and the differential side bearing cup.
  30. Install the right side service spacer between the axle housing and the differential assembly.
  31. Install the right side selective service shim or shims using the J 25588 , if necessary. The service shim or shims must be installed between the service spacer and the differential side bearing cup. NOTE: Refer to «FASTENER NOTICE»(/chevrolet/avalanche/i-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__fastener-notice) in Cautions and Notices.
  32. Install the differential bearing caps and the bolts. Tighten: Tighten the differential bearing cap bolts to 75 N.m (55 lb ft).
  33. Measure the drive pinion and differential side bearing preload using an inch-pound torque wrench. Rotate the pinion several times to ensure the differential side bearings have seated. Specification The rotating torque of the drive pinion and differential side bearings should be 3.9-6.2 N.m (30-55 lb in) for new bearings or 2.8-5.1 N.m (25-45 lb in) for used bearings. Record the measurement.
  34. Calculate the differential side bearing preload by subtracting the drive pinion preload, measured in Step 2, from the drive pinion and differential case bearing preload, measured in Step 33. Multiply the value obtained by the axle ratio. Specification The differential side bearing preload should be 1.7-4.0 N.m (15-35 lb in).
  35. If the differential side bearing preload is not within specifications, add or subtract shim thickness equally from each shim pack as necessary in order to increase/decrease the side bearing preload.
  36. Once the differential side bearing preload is correct, measure the backlash and adjust, if necessary. Refer to «BACKLASH ADJUSTMENT (ALL EXCEPT 9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «BACKLASH ADJUSTMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  37. Once the differential side bearing preload and backlash is correct, perform a gear tooth contact pattern check in order to ensure proper alignment between the ring and pinion gears. Refer to «GEAR TOOTH CONTACT PATTERN INSPECTION»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle__gear-tooth-contact-pattern-inspection) .
  1. J 8001 Dial Indicator Set
  2. J 22779 Side Bearing Backlash Gage
  3. J 24429 Side Bearing Backlash Spanner
  4. J 25025 Guide Pins

Important

  1. Ensure that the side bearing surfaces in the axle housing are clean and free of burrs. If the original bearings are to be reused, the original bearing cups must also be used.
  2. The drive pinion bearing preload must be within specifications before the differential side bearing preload adjustment can be performed.
  3. The differential side bearings must be initially preloaded in order to determine the backlash of the gear set. After the backlash is set, the final bearing preload is set.

Scheme 484

Scheme 484
CAUTIONTo prevent personal injury and/or component damage, support the differential case when removing the case from the axle housing. If the case is not supported, the differential case could fall and cause personal injury or damage to the differential case.
  1. Remove the differential assembly, if necessary.
  2. Measure the rotating torque of the drive pinion bearing using an inch-pound torque wrench. Specification The rotating torque of the drive pinion should be 1.7-3.4 N.m (15-30 lb in) for new bearings or 1.1-2.3 N.m (10-20 lb in) for used bearings.
  3. If the rotating torque of the drive pinion is less than 1.7 N.m (15 lb in) for new bearings or 1.1 N.m (10 lb in) for used bearings, tighten the pinion in small increments until the specified rotating torque is obtained.
  4. If the rotating torque of the drive pinion is greater than 3.4 N.m (30 lb in) for new bearings or 2.3 N.m (20 lb in) for used bearings, remove the drive pinion and replace the collapsible spacer and re-install the drive pinion. Refer to «DRIVE PINION BEARINGS REPLACEMENT (8.6, 9.5 INCH AXLES)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION BEARINGS REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION BEARINGS REPLACEMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  5. Install the differential assembly, if necessary.
  6. Support the differential assembly in order to prevent the differential assembly from falling out of the axle housing. Important: Do not force the ring gear into contact with the drive pinion.
  7. Slide the differential case assembly towards the right side axle housing until the ring gear contacts the drive pinion. This is the ZERO backlash point. If the ZERO backlash cannot be obtained, turn the differential bearing adjuster nut into the axle housing using the J 24429 until the ring gear fully contacts the drive pinion to obtain the ZERO backlash.
  8. While holding the ring gear against the pinion, turn the differential bearing adjuster nut out from the axle housing using the J 24429 until it contacts the differential side bearing.
  9. Turn the adjuster nut out from the axle housing an additional 2 slots using the J 24429 in order to obtain the initial backlash adjustment.
  10. Install the adjuster nut lock and the adjuster nut lock bolt.
  11. Remove the left side differential bearing cap bolts.
  12. Remove the left side differential bearing cap.
  13. Install the J 22779 into the left side axle housing between the differential bearing bore and the differential bearing cup. Important: Over-tightening may spread the axle housing and result in incorrect shim selection.
  14. Tighten the knob of the J 22779 until there is moderate drag when the J 22779 is moved.
  15. Remove the J 22779 .
  16. Measure the J 22779 in 3 locations.
  17. Calculate the average of the 3 measurements. The resulting value is the shim thickness required in order to set the initial backlash of the differential assembly.
  18. Select a service shim of approximately the same thickness to install into the axle housing. Verify the thickness of the service shim using a micrometer.
  19. Install the service shim into the axle housing between the differential bearing bore and the differential bearing cup.
  20. Install the left side differential bearing cap.
  21. Install the left side differential bearing cap bolts. Tighten the differential bearing cap bolts finger-tight. Do not torque the bolts at this time.
  22. Remove the differential bearing adjuster nut lock bolt.
  23. Remove the differential bearing adjuster nut lock.
  24. Firmly tighten the differential bearing adjuster nut using the J 24429 in order to force the differential case assembly into solid contact with the service shim.
  25. Rotate the pinion several times in order to seat the bearings.
  26. Loosen the differential bearing adjuster nut using the J 24429 until the nut is free from the differential side bearing.
  27. Tighten the differential bearing adjuster nut using the J 24429 until the differential bearing adjuster nut contacts the bearing.
  28. Once the right differential bearing adjuster contacts the differential bearing, tighten the differential bearing adjuster nut using the J 24429 the following additional amounts: Tighten: For new bearings, tighten the differential bearing adjuster nut an additional 3 slots. For used bearings, tighten the differential bearing adjuster nut an additional 2 slots.
  29. Install the right differential bearing adjuster nut lock.
  30. Install the right differential bearing adjuster nut lock bolt. Do not torque the bolt at this time. NOTE: Refer to «FASTENER NOTICE»(/chevrolet/avalanche/i-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__fastener-notice) in Cautions and Notices.
  31. Tighten the bearing cap bolts. Tighten: Tighten the bearing cap bolts to 85 N.m (63 lb ft).
  32. Tighten the differential bearing adjuster nut lock bolt. Tighten: Tighten the differential bearing adjuster nut lock bolt to 26 N.m(19 lb ft).
  33. Measure the drive pinion and differential case side bearing preload using an inch-pound torque wrench. Rotate the pinion several times to ensure the bearings have seated. Specification The rotating torque of the drive pinion and differential case bearings should be 3.9-6.2 N.m (30-55 lb in) for new bearings or 2.8-5.1 N.m (25-45 lb in) for used bearings. Record the measurement.
  34. Calculate the differential side bearing preload by subtracting the drive pinion preload, measured in Step 2, from the drive pinion and differential case bearing preload, measured in Step 35. Multiply the value obtained by the axle ratio. Specification The differential case side bearing preload should be 1.7-4.0 N.m (15-35 lb in).
  35. If the differential case side bearing preload is not within specifications, increase or decrease the shim thickness as necessary in order to increase/decrease the side bearing preload.
  36. Once the differential side bearing preload is correct, measure the drive pinion to differential assembly backlash and adjust, if necessary. Refer to «BACKLASH ADJUSTMENT (ALL EXCEPT 9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «BACKLASH ADJUSTMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .

Differential side bearing shims are available in the following sizes

  1. 5.59 mm (0.220 in)
  2. 5.64 mm (0.222 in)
  3. 5.69 mm (0.224 in)
  4. 5.74 mm (0.226 in)
  5. 5.79 mm (0.228 in)
  6. 5.84 mm (0.230 in)
  7. 5.89 mm (0.232 in)
  8. 5.94 mm (0.234 in)
  9. 5.99 mm (0.236 in)
  10. 6.05 mm (0.238 in)
  11. 6.10 mm (0.240 in)
  12. 6.15 mm (0.242 in)
  13. 6.20 mm (0.244 in)
  14. 6.25 mm (0.246 in)
  15. 6.30 mm (0.248 in)
  16. 6.35 mm (0.250 in)
  17. 6.40 mm (0.252 in)
  18. 6.45 mm (0.254 in)
  19. 6.50 mm (0.256 in)
  20. 6.55 mm (0.258 in)
  1. J 24430 Differential Side Bearing Installer
  2. J 36597 Side Bearing Puller Pilot - 9.25 inch
  3. J 45711 Differential Side Bearing Remover - Dana 248
  4. J 45900 Differential Side Bearing Installer - Dana Axles
  5. J 8092 Universal Driver Handle - 3/4 in - 10

Scheme 485

Scheme 485: Measurement and Adjustment Procedure

Scheme 486

Scheme 486

Scheme 487

Scheme 487

Scheme 488

Scheme 488

Scheme 489

Scheme 489
  1. Remove the differential side bearing shims. Refer to «DRIVE PINION BEARINGS REPLACEMENT (8.6, 9.5 INCH AXLES)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION BEARINGS REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DRIVE PINION BEARINGS REPLACEMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  2. Determine the pinion position shim and the pinion preload shims, if necessary. Refer to «PINION DEPTH ADJUSTMENT (8.6 INCH, 9.5 INCH AXLES)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «PINION DEPTH ADJUSTMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «PINION DEPTH ADJUSTMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle__pinion-depth-adjustment-105-inch-axle) .
  3. Install the differential side bearing without the side bearing shims by doing the following: In order to protect the differential case, install the J 36597 in the case on the side opposite of the bearing installation. Install the differential side bearing. Install the J 24430 or the J 45900 (2) and the J 8092 (1) over the differential side bearing. Drive the differential side bearing into position using the J 24430 or the J 45900 and the J 8092 .
  4. Install the differential assembly into the axle housing.
  5. Move the differential assembly to the left until the left differential side bearing is against the left side bearing bore. Important: Install the bearing caps into the same position from which each was removed.
  6. Install the left side bearing cap. NOTE: Refer to «FASTENER NOTICE»(/chevrolet/avalanche/i-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__fastener-notice) in Cautions and Notices.
  7. Install the left side bearing cap bolts. Tighten: Tighten the bearing cap bolts finger tight. Do not torque the bolts to specification at this time.
  8. While holding the differential assembly against the left side bearing bore, press the right side bearing cup against the right differential side bearing. Important: In order to accurately measure the differential side bearing shim thickness, the differential side bearing cup must be evenly seated against the differential side bearing.
  9. Using a feeler gauge, measure the distance between the right side bearing cup and the right side bearing bore. Use progressively larger feeler gauge sizes until a moderate drag is felt. Repeat this step several times while rotating the differential case in order to obtain a consistent reading. This measurement, measurement a, is the total shim pack thickness for the differential assembly without preload. CAUTION: To prevent personal injury and/or component damage, support the differential case when removing the case from the axle housing. If the case is not supported, the differential case could fall and cause personal injury or damage to the differential case.
  10. Remove the left side bearing cap bolts.
  11. Remove the left side bearing cap.
  12. Install the right side bearing cap.
  13. Install the right side bearing cap bolts. Tighten: Tighten the bearing cap bolts finger tight. Do not torque the bolts to specification at this time.
  14. While holding the differential assembly ring gear against the drive pinion, press the left side bearing cup against the left differential side bearing. Important: In order to accurately measure the differential side bearing shim thickness, the differential side bearing cup must be evenly seated against the differential side bearing.
  15. Using a feeler gauge, measure the distance between the left side bearing cup and the left side bearing bore. Use progressively larger feeler gauge sizes until a moderate drag is felt. Repeat this step several times while re-positioning the differential case in order to obtain a consistent reading. This measurement, measurement b, is the left side shim thickness for the differential assembly without preload.
  16. In order to determine the right side shim thickness, subtract the left side measurement, measurement b, from the total shim measurement, measurement a. This measurement is the thickness for the right side shim thickness without preload or setting the initial backlash.
  17. Remove the right side bearing cap bolts.
  18. Remove the right side bearing cap.
  19. Remove the differential assembly.
  20. Remove the differential side bearings by performing the following steps: Install the J 45711 (2) and the J 36597 (1) as shown. Remove the differential side bearings using the J 45711 and a hydraulic press.
  21. Add 0.25 mm (0.010 in) of shim thickness to the right side shim thickness measurement determined in step 16. This additional amount will set the differential side bearing preload and the initial backlash. Important: The number of shims required in order to equal the correct thickness may consist of one or more shims.
  22. Install the right side shim thickness onto the differential case. Measure the shims one at a time. Add the measurements together in order to obtain the total thickness of the right side shim pack.
  23. Install the right differential side bearing with the side bearing shim thickness by doing the following: In order to protect the differential case, install the J 8107-3 in the case on the side opposite of the bearing installation. Place the differential side shim thickness on top of the differential case. Place the differential side bearing on top of the differential case. Install the J 24430 or the J 45900 (2) and the J 8092 (1) over the differential side bearing. Drive the differential side bearing into position using the J 24430 or the J 45900 and the J 8092 . Important: The number of shims required in order to equal the correct thickness may consist of one or more shims.
  24. Install the left side bearing shim thickness and differential side bearing using the steps above.
  25. Install the differential assembly into the axle housing. Refer to «DIFFERENTIAL REPLACEMENT (8.6 INCH, 9.5 INCH AXLES)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL REPLACEMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  26. Adjust the backlash. Refer to «BACKLASH ADJUSTMENT (ALL EXCEPT 9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «BACKLASH ADJUSTMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .

The differential side bearing shims are available in the following sizes

  1. 0.25 mm (0.010 in)
  2. 0.28 mm (0.011 in)
  3. 0.30 mm (0.012 in)
  4. 0.33 mm (0.013 in)
  5. 0.36 mm (0.014 in)
  6. 0.38 mm (0.015 in)
  7. 0.41 mm (0.016 in)
  8. 0.43 mm (0.017 in)
  9. 0.46 mm (0.018 in)
  10. 0.48 mm (0.019 in)
  11. 0.51 mm (0.020 in)
  12. 1.02 mm (0.040 in)

J 24429 Side Bearing Backlash Spanner

Important: The rotating torque of the drive pinion must be within specifications before the pinion gear bearing retain or the differential case assembly can be installed.

  1. Install the pinion gear bearing retainer assembly. Refer to «DRIVE PINION HOUSING AND/OR SEAL REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) . Important: The differential side bearing preload is adjusted by the 2 adjusting nuts in the bearing bore. The bore and the bearing cap provide the mating threads for the bearing nut. The differential must be initially prelubricated in order to determine the backlash of the gear set. After the backlash is set, the final bearing preload is set.
  2. Install the differential side bearings, if necessary. Refer to «DIFFERENTIAL SIDE BEARINGS REPLACEMENT (ALL EXCEPT 9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL SIDE BEARINGS REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  3. Install the differential side bearing adjuster nuts. Important: Before installation of the differential case assembly, ensure that the side bearing surfaces in the carrier are clean and free of burrs. If the original bearings are to be reused, the original bearing cups must also be used. If the differential case assembly cannot be installed, turn the differential side bearing adjuster nuts into the axle housing until the differential case assembly until the proper clearance can be obtained.
  4. Install the differential case assembly.
  5. Install the differential bearing caps.
  6. Install the differential bearing cap bolts. Important: In the following service procedure, DO NOT torque the bearing cap bolts, only finger tighten them.
  7. Install the bearing cap bolts. Important: DO NOT FORCE the ring gear into contact with the drive pinion.
  8. Slide the differential case assembly towards the right side axle housing until the ring gear contact the pinion (this is the zero backlash point). Important: If the zero backlash cannot be obtained, turn the right side differential bearing adjuster nut in towards the axle housing until the ring gear fully contacts the pinion to obtain the zero backlash.
  9. Check for zero backlash.
  10. While holding the ring gear against the pinion, turn the left differential bearing adjuster nut out from the axle housing using the J 24429 until it contacts the differential side bearing.
  11. Turn the right differential bearing adjuster nut out from the axle housing using the J 24429 until it contacts the differential side bearing.
  12. Back off the left adjusting nut approximately 2 slots using the J 24429 in order to obtain the initial backlash adjustment. Important: In the following service procedure, DO NOT torque the adjuster nut lock bolt.
  13. Install the left adjuster nut lock and the adjuster nut lock bolt.
  14. Using the J 24429 , tighten the right differential bearing adjuster nut until the differential case is in contact with the left differential adjuster nut.
  15. Rotate the pinion several times in order to seat the bearings.
  16. Loosen the right differential bearing adjuster nut using the J 24429 until the nut is free from the differential side bearing.
  17. Tighten the right differential bearing adjuster nut using the J 24429 until the differential bearing adjuster nut contacts the bearing.
  18. Once the right differential bearing adjuster contacts the differential bearing, tighten the differential bearing adjuster nut using the J 24429 the following additional amounts: Tighten: For used bearings, tighten the differential bearing adjuster nut an additional 2 slots. For new bearings, tighten the differential bearing adjuster nut an additional 3 slots.
  19. Install the right differential bearing adjuster nut lock. Important: In the following service procedures, DO NOT torque the bolt at this time
  20. Install the right differential bearing adjuster nut lock bolt. NOTE: Refer to «FASTENER NOTICE»(/chevrolet/avalanche/i-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__fastener-notice) in Cautions and Notices.
  21. Tighten the bearing cap bolts. Tighten: Tighten the bearing cap bolts to 185 N.m (136 lb ft).
  22. Tighten differential bearing adjuster nut lock bolts. Tighten: Tighten the differential bearing adjuster nut lock bolts to 27 N.m (20 lb ft).
  23. Measure the ring gear to pinion backlash and adjust, if necessary. Refer to «BACKLASH ADJUSTMENT (ALL EXCEPT 9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «BACKLASH ADJUSTMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .

Preliminary Inspection

Important: Ensure the brakes are fully released and do not drag.

Pull or push the tire at the top back and forth in order to test the wheel bearing play.

  1. Use a pry bar under the tire as an alternative.
  2. If the wheel bearing adjustment is correct, the movement will be barely noticeable.
  3. If the movement is excessive, adjust the bearings.

J 2222-C Wheel Bearing Nut Wrench

Scheme 490

Scheme 490: Tools Required

Scheme 491

Scheme 491

Scheme 492

Scheme 492

Scheme 493

Scheme 493

Scheme 494

Scheme 494
  1. Raise the vehicle. Refer to «LIFTING AND JACKING THE VEHICLE»(/chevrolet/avalanche/i-2001-2006/remont/hoistjack/#jacking-and-lifting-avalanche__lifting-and-jacking-the-vehicle) in General Information.
  2. Remove the axle shaft. Refer to «REAR AXLE SHAFT AND/OR GASKET REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  3. Remove the hub adjuster nut retaining ring.
  4. Remove the adjuster nut lock key. NOTE: Refer to «FASTENER NOTICE»(/chevrolet/avalanche/i-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__fastener-notice) in Cautions and Notices.
  5. Tighten the wheel bearing adjusting nut using the J 2222-C. Rotate the hub in the opposite direction to the way the adjuster nut is turning.
  6. Ensure the inner bearing and the seal seats against the spindle shoulder. Tighten: Tighten the adjusting nut to 70 N.m (52 lb ft).
  7. Turn the adjusting nut counterclockwise until the nut is loose using the J 2222-C .
  8. Turn the adjusting nut clockwise until the nut contacts the bearing cone. Torque on the nut must be zero to finger tight.
  9. Insert the adjusting nut lock key into the keyway using one of the following procedures: If the adjusting nut slot is in alignment with the keyway in the axle spindle, insert the adjusting nut lock key into the keyway in the axle spindle. Important: Do not turn the adjusting nut more than one slot counterclockwise in order to align the adjusting nut slot with the keyway in the axle spindle. If the adjusting nut slot is not aligned with the keyway in the axle spindle, turn the adjusting nut counterclockwise until the adjusting nut slot is in alignment with the keyway in the axle spindle and insert the adjusting nut lock key.
  10. Install the retaining ring.
  11. Install the axle shaft. Refer to «REAR AXLE SHAFT AND/OR GASKET REPLACEMENT»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  12. Inspect the lubricant level and add, if necessary. Refer to «LUBRICANT LEVEL INSPECTION - REAR DRIVE AXLE (8.6 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «LUBRICANT LEVEL INSPECTION - REAR DRIVE AXLE (9.5, 10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «LUBRICANT LEVEL INSPECTION - REAR DRIVE AXLE (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  13. Lower the vehicle.
  1. J 8001 Dial Indicator Set
  2. J 25025 Guide Pins
  3. J 25588 Side Bearing Shim Installer

Scheme 495

Scheme 495

Scheme 496

Scheme 496
  1. Install the J 25025-1 and the J 8001 to the axle housing as shown.
  2. Place the indicator stem of the J 8001-3 at the heel end of a gear tooth.
  3. Set the J 8001-3 so that the stem is aligned with the gear rotation and perpendicular to the tooth angle.
  4. Preload the dial of the J 8001-3 .
  5. Align the needle and the dial face of the J 8001-3 to ZERO.
  6. While holding the drive pinion stationary, move the ring gear back and forth. Measure and record the backlash.
  7. Repeat the measuring procedure at eight points around the ring gear. Specification The difference between the backlash at all of the measuring points should not vary by more than 0.05 mm (0.002 in).
  8. If the difference between the backlash at all of the measuring points varies by more than 0.05 mm (0.002 in), inspect for the following conditions: Burrs A distorted case flange Uneven bolting
  9. If the difference between all the measuring points is within specifications, the backlash at the minimum lash point measured should be: Specification The backlash between the ring gear and the drive pinion should be between 0.08-0.25 mm (0.003-0.010 in) with a preferred backlash of 0.13-0.18 mm (0.005-0.007 in). Important: Do not use the original cast iron production shims to adjust the backlash. Use service shims and spacers instead. Adjust the thickness of the shim pack on each side of the differential in equal amounts. This will maintain the correct axle side bearing preload. Moving 0.05 mm (0.002 in) of shim thickness from one side of the differential to the other will change the backlash adjustment approximately 0.03 mm (0.001 in).
  10. If the backlash is too small, increase the backlash using the following procedure: Remove the bearing cap bolts and the bearing caps. Mark the bearing caps left or right. Remove the differential case assembly with the bearing cups and the shims. Mark the bearing cups and the shims left or right. Measure the thickness of left side shim pack. Measure the production shim or the shim and service spacer in 3 locations. Measure each shim separately. Calculate the average of the 3 measurements for each shim. Add the average of each of the shim measurements together. Record the measurement. This is the thickness for the left side shim pack. Assemble a new left side shim pack by decreasing the appropriate amount of thickness from the original left side shim pack. If the original shim is cast iron production shim, assemble the shim pack using a service spacer and service shims. For example, to increase the backlash by 0.05 mm (0.002 in), remove 0.10 mm (0.004 in) of thickness from the left side shim pack. Measure the thickness of right side shim pack. Measure the shim or the shim and service spacer in 3 locations. Measure each shim separately. Calculate the average of the 3 measurements for each shim. Add the average of each of the shim measurements together. Record the measurement. This is the thickness for the right side shim pack. Assemble a new right side shim pack by increasing the appropriate amount of thickness to the original right side shim pack. If the original shim is cast iron production shim, assemble the shim pack using a service spacer and service shims. For example, to increase the backlash by 0.05 mm (0.002 in), add 0.10 mm (0.004 in) of thickness to the right side shim pack.
  11. If the backlash is too large, decrease the backlash using the following procedure: Remove the bearing cap bolts and the bearing caps. Mark the bearing caps left or right. Remove the differential case assembly with the bearing cups and the shims. Mark the bearing cups and the shims left or right. Measure the thickness of left side shim pack. Measure the production shim or the shim and service spacer in 3 locations. Measure each shim separately. Calculate the average of the 3 measurements for each shim. Add the average of each of the shim measurements together. Record the measurement. This is the thickness for the left side shim pack. Assemble a new left side shim pack by increasing the appropriate amount of thickness to the original left side shim pack. If the original shim is cast iron production shim, assemble the shim pack using a service spacer and service shims. For example, to increase the backlash by 0.05 mm (0.002 in), add 0.10 mm (0.004 in) of thickness to the left side shim pack. Measure the thickness of right side shim pack. Measure the shim or the shim and service spacer in 3 locations. Measure each shim separately. Calculate the average of the 3 measurements for each shim. Add the average of each of the shim measurements together. Record the measurement. This is the thickness for the right side shim pack. Assemble a new right side shim pack by decreasing the appropriate amount of thickness to the original right side shim pack. If the original shim is cast iron production shim, assemble the shim pack using a service spacer and service shims. For example, to decrease the backlash by 0.05 mm (0.002 in), remove 0.10 mm (0.004 in) of thickness to the right side shim pack.
  12. Install the differential case assembly with the bearing cups.
  13. Install the left side service spacer between the axle housing and the differential case.
  14. Install the right side service spacer between the axle housing and the differential case.
  15. Install the left side service shim or shims using the J 25588 , if necessary. The service shim or shims must be installed between the service spacer and the differential bearing cup.
  16. Install the right side service shim or shims using the J 25588 , if necessary. The service shim or shims must be installed between the service spacer and the differential bearing cup. NOTE: Refer to «FASTENER NOTICE»(/chevrolet/avalanche/i-2001-2006/remont/oem-general-information/#gm-vehicles-cautions-notices__fastener-notice) in Cautions and Notices.
  17. Install the bearing caps and bolts. Tighten: Tighten the bolts to 75 N.m (55 lb ft).
  18. Recheck the backlash and adjust, if necessary.
  19. Once backlash is correct, perform a gear tooth contact pattern check in order to ensure proper alignment between the ring and pinion gears. Refer to «GEAR TOOTH CONTACT PATTERN INSPECTION»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle__gear-tooth-contact-pattern-inspection) .
  1. J 25025 Guide Pins
  2. J 8001 Dial Indicator

Scheme 497

Scheme 497
  1. Determine the differential side bearing preload and initial backlash. Refer to «DIFFERENTIAL SIDE BEARING PRELOAD ADJUSTMENT (8.6 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL SIDE BEARING PRELOAD ADJUSTMENT (9.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL SIDE BEARING PRELOAD ADJUSTMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL SIDE BEARING PRELOAD ADJUSTMENT (10.5 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  2. Install the J 25025 (1) and the J 8001 (2, 3) to the axle housing as shown.
  3. Place the indicator stem of the J 8001 at the heel end of a gear tooth.
  4. Set the J 8001 so that the stem is aligned with the gear rotation and perpendicular to the tooth angle.
  5. While holding the pinion stationary, move the ring gear back and forth. Measure and record the backlash.
  6. Repeat the measuring procedure at eight points around the ring gear. Specification The difference between the backlash at all of the measuring points should not vary by more than 0.05 mm (0.002 in).
  7. If the difference between the backlash at all of the measuring points varies by more than 0.05 mm (0.002 in), inspect for the following conditions: Burrs A distorted case flange Uneven bolting
  8. If the difference between all the measuring points is within specifications, the backlash at the minimum lash point measured should be: Specification The backlash between the ring gear and the drive pinion should be between 0.08-0.25 mm (0.003-0.010 in) with a preferred backlash of 0.13-0.20 mm (0.005-0.008 in). Important: Adjust the thickness of the shim pack on each side of the differential in equal amounts. This will maintain the correct axle side bearing preload.
  9. If the backlash is not within specifications, adjust the backlash by doing the following: Remove the differential side bearings. Refer to «DIFFERENTIAL SIDE BEARINGS REPLACEMENT (ALL EXCEPT 9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL SIDE BEARINGS REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) . If the backlash is too small, increase the backlash using the following procedure: Important: Moving 0.05 mm (0.002 in) of shim thickness from one side of the differential to the other will change the backlash adjustment by 0.03 mm (0.001 in). Remove the appropriate amount of thickness from the left side shim pack. For example, to increase the backlash by 0.10 mm (0.004 in), subtract 0.20 mm (0.008 in) of thickness from the left side shim pack. Add the 0.20 mm (0.008 in) of shim thickness to the right side shim pack. If the backlash is too large, decrease the backlash using the following procedure: Important: Moving 0.05 mm (0.002 in) of shim thickness from one side of the differential to the other will change the backlash adjustment by 0.03 mm (0.001 in). Remove the appropriate amount of thickness from the right side shim pack. For example, to decrease the backlash by 0.10 mm (0.004 in), subtract 0.20 mm (0.008 in) of thickness from the right side shim pack. Add the 0.20 mm (0.008 in) of shim thickness to the left side shim pack.
  10. Install the left and right shim packs onto the differential case.
  11. Install the differential side bearings. Refer to «DIFFERENTIAL SIDE BEARINGS REPLACEMENT (ALL EXCEPT 9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) or «DIFFERENTIAL SIDE BEARINGS REPLACEMENT (9.75 INCH AXLE)»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle) .
  12. Recheck the backlash and adjust as necessary.
  13. Once backlash is correct, perform a gear tooth contact pattern check in order to ensure proper alignment between the ring and pinion gears. Refer to «GEAR TOOTH CONTACT PATTERN INSPECTION»(/chevrolet/avalanche/i-2001-2006/remont/differentials-drive-axles/#rear-drive-axle__gear-tooth-contact-pattern-inspection) .

Gear Tooth Contact Pattern Inspection

The gear contact pattern check is not a substitute for adjusting the pinion depth and backlash. Use this method in order to verify the correct running position of the ring gear and the drive pinion. Gear sets which are not positioned properly may be noisy and/or have a short life span. A pattern check ensures that when best contact has been obtained between the ring gear and the drive pinion, the system will produce low noise and have a long life.

Drive Pinion and Ring Gear Identification

Production drive pinion and ring gears are manufactured by using a 2-cut or a 5-cut method. The 2-cut drive pinions and ring gears can be identified by having a groove cut into the outside edge of the ring gear and a ring on the stem of the drive pinion. The gear tooth contact patterns that are produced from each style of gear set differ slightly. A 2-cut gear will produce a pattern that is bias from the toe to the heel of the tooth (drive side), while a 5-cut gear set will produce a square pattern from the toe to the heel of the tooth (drive side). When diagnosing the gear tooth contact pattern, regardless of what type of gear set it is, a correct pattern will be centered within the area of the tooth, from toe to heel and from top to bottom.

Gear Tooth Nomenclature

The side of the ring gear tooth which curves outward, or is convex, is the drive side (4). The concave side is the coast side (3). The end of the tooth nearest the center of the ring gear is the toe end (2). The end of the tooth farthest away from the center is the heel end (1).

Scheme 498

Scheme 498: Gear Tooth Nomenclature

Adjustments Affecting Tooth Contact

The following 2 adjustments affect the tooth contact pattern

  1. Backlash adjustment
  2. Pinion depth adjustment

The effects of bearing preloads are not readily apparent on hand-loaded tooth contact pattern tests. However, bearing preloads should be within specifications before proceeding with backlash and pinion depth adjustments.

Backlash Adjustment

The backlash can be adjusted by either varying the thickness of the side bearing shims from side to side or by moving the adjuster sleeve(s) in or out, or both. By adjusting the shim thickness or moving the adjuster sleeve(s), the case and ring gear assembly will move closer to or further away from the pinion. In most cases, adjusting the backlash will correct an abnormal contact pattern. This adjustment will also be used to set the side bearing preload.

  1. If the thickness of the right shim is increased or the adjuster sleeve is moved in (if applicable), along with an equal decrease in the thickness of the left shim or the adjuster sleeve is moved out (if applicable), the backlash will increase.
  2. If the thickness of the left shim is increased or the adjuster sleeve is moved in (if applicable), along with an equal decrease in the thickness of the right shim or the adjuster sleeve is moved out (if applicable), the backlash will decrease.

Pinion Depth Adjustment

Adjust the position of the pinion by increasing or decreasing the distance between the pinion head and the centerline of the ring gear. Decreasing the distance moves the pinion closer to the centerline of the ring gear. Increasing the distance moves the pinion farther away from the centerline of the ring gear.

Scheme 499

Scheme 499: Testing Procedure
  1. Wipe clean the differential case, the ring gear and the axle housing of lubricant. Carefully clean each tooth of the ring gear.
  2. Use a medium stiff brush in order to sparingly apply gear marking compound, GM P/N 1052351 (Canadian P/N 10953497) or equivalent, to all of the ring gear teeth.
  3. Torque the bearing caps bolts to specification. Important: Performing a test without loading the gears will not produce a satisfactory pattern.
  4. Apply the park brake until a torque load of 14 N.m (10 lb ft) is required in order to turn the pinion. Important: Avoid turning the ring gear excessively.
  5. Using a wrench, turn the drive pinion flange/yoke so that the ring gear rotates 3 full revolutions.
  6. Turn the drive pinion flange/yoke in the opposite direction so that the ring gear rotates 3 full revolutions in the opposite direction.
  7. Observe the pattern on the ring gear teeth. Compare the pattern with the following illustrations.

Condition

The backlash and pinion depth is correct.

Correction

None required.

Service Hints

Loose bearings on the drive pinion or in the differential case may cause patterns that vary. If the contact pattern varies, inspect the following preload settings

  1. Total assembly
  2. Differential case
  3. Pinion

If these settings are correct, inspect for damage or incorrectly assembled parts.

Scheme 500

Scheme 500

The backlash is incorrect. The ring gear is too far away from the pinion.

Decrease the backlash. Move the ring gear closer to the pinion by adjusting the side bearing shim thickness or the adjuster sleeve(s). Refer to BACKLASH ADJUSTMENT (ALL EXCEPT 9.75 INCH AXLE) or BACKLASH ADJUSTMENT (9.75 INCH AXLE) .

Scheme 501

Scheme 501: Correction

The backlash is incorrect. The ring gear is too close to the drive pinion.

Increase the backlash. Move the ring gear away from the pinion by adjusting the side bearing shim thickness or the adjuster sleeve(s). Refer to BACKLASH ADJUSTMENT (ALL EXCEPT 9.75 INCH AXLE) or BACKLASH ADJUSTMENT (9.75 INCH AXLE) .

Scheme 502

Scheme 502: Correction

The backlash is incorrect. The ring gear is too far away from the pinion.

Decrease the backlash. Move the ring gear closer to the pinion by adjusting the side bearing shim thickness or the adjuster sleeve(s). Refer to BACKLASH ADJUSTMENT (ALL EXCEPT 9.75 INCH AXLE) or BACKLASH ADJUSTMENT (9.75 INCH AXLE) .

Scheme 503

Scheme 503: Correction

The backlash is incorrect. The ring gear is too close to the drive pinion.

Increase the backlash. Move the ring gear away from the pinion by adjusting the side bearing shim thickness or the adjuster sleeve(s). Refer to BACKLASH ADJUSTMENT (ALL EXCEPT 9.75 INCH AXLE) or BACKLASH ADJUSTMENT (9.75 INCH AXLE) .

Scheme 504

Scheme 504: Correction

The pinion depth is incorrect. The pinion gear is too far away from the ring gear.

Increase the pinion depth. Move the pinion gear closer to the ring gear by increasing the pinion shim thickness. Refer to PINION DEPTH ADJUSTMENT (8.6 INCH, 9.5 INCH AXLES) or PINION DEPTH ADJUSTMENT (9.75 INCH AXLE) or PINION DEPTH ADJUSTMENT (10.5 INCH AXLE) .

Scheme 505

Scheme 505: Correction

The pinion depth is incorrect. The pinion gear is too close to the ring gear.

Decrease the pinion depth. Move the pinion gear away from the ring gear by decreasing the pinion shim thickness. Refer to PINION DEPTH ADJUSTMENT (8.6 INCH, 9.5 INCH AXLES) or PINION DEPTH ADJUSTMENT (9.75 INCH AXLE) or PINION DEPTH ADJUSTMENT (10.5 INCH AXLE) .

Scheme 506

Scheme 506: Correction

Rear Axles for this vehicle consist of the following components

  1. Differential Axle Housing
  2. Differential Carrier
  3. Right and left Axle tubes
  4. Right and left axle shafts

The 800 series utility vehicles use either the 8.60, 9.50 or the 10.50 inch axles. The type of the axle can be identified by the stamping on the right side axle tube. They may also be identified by the ring gear size. The ring gear sizes include the 8.60, 9.50 and 10.50 inch axles. The locking differential information for these rear axles can be located in the locking differential section. A open differential has a set of 4 gears. 2 are side gears and 2 are pinion gears. Each side gear is splined to an axle shaft so each axle shaft; so each axle shaft turns when its side gear rotates. The pinion gears are mounted on a differential pinion shaft, and the gears are free to rotate on this shaft. The pinion shaft is fitted into a bore in the differential case and is at right angles to the axle shafts. Power is transmitted through the differential as follows: The drive pinion rotates the ring gear which is bolted to the differential case assembly. The differential pinion, as it rotates with the case, forces the pinion gears against the side gears. When both wheels have equal traction, the pinion gears do not rotate on the pinion shaft because the input force on the pinion gear is equally divided between the 2 side gears. Therefore the pinion gears revolve with the pinion shaft; but do not rotate around the shaft itself. The side gears; being splined to the axle shafts, and in mesh with the pinion gears rotate the axle shafts. When the vehicle turns a corner the inner wheel turns slower than the outer wheel which slows the rear axles' side gear (as the shaft is splined to the side gear). The rear axle pinion gears will roll around the slower moving rear axle side gear; driving the rear axle side gear wheel faster.

Scheme 507

Scheme 507: Special Tools and Equipment

Scheme 508

Scheme 508

Scheme 509

Scheme 509

Scheme 510

Scheme 510

Scheme 511

Scheme 511

Scheme 512

Scheme 512

Scheme 513

Scheme 513

Scheme 514

Scheme 514

Scheme 515

Scheme 515

Scheme 516

Scheme 516

Scheme 517

Scheme 517

Scheme 518

Scheme 518

See also:
LIFTING AND JACKING THE VEHICLE
FASTENER NOTICE
BRAKE CALIPER
STEERING GEAR ACTUATOR AND COVER REPLACEMENT
REMOVAL (REAR -- ALL WITH 4-WHEEL STEERING)
REMOVAL (REAR -- WITHOUT DUAL WHEELS & 4-WHEEL)
PINION FLANGE/YOKE INSTALLATION NOTICE
RING GEAR REMOVAL NOTICE
VEHICLE LIFTING CAUTION
DIFFERENTIAL HOUSING COVER & GASKET REMOVAL NOTICE
REMOVAL (LEFT REAR -- WITHOUT 4-WHEEL STEERING)
REMOVAL (LEFT REAR -- WITH 4-WHEEL STEERING)
REMOVAL (RIGHT REAR -- WITHOUT 4-WHEEL STEERING)
REMOVAL (RIGHT REAR -- WITH 4-WHEEL STEERING)
REMOVAL (REAR -- UTILITY WITHOUT 4-WHEEL STEERING)
REMOVAL (REAR -- UTILITY WITH 4-WHEEL STEERING)
REMOVAL (1500 SERIES UTILITY WITHOUT 4-WHEEL STEERING)
REMOVAL (1500 SERIES PICKUP & UTILITY WITH 4-WHEEL STEERING)
SYMPTOMS - REAR DRIVE AXLE
PINION DEPTH ADJUSTMENT (10.5 INCH AXLE)
GEAR TOOTH CONTACT PATTERN INSPECTION
