Door System, Mirror System & Window System Cadillac XLR I

Fastener Tightening Specifications

Fastener Tightening Specifications

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Scheme 21

Scheme 22

Power Door Systems Connector End Views

Door Handle Switch - Driver Exterior

Scheme 23

Power Door Systems Connector End Views

Door Handle Switch - Driver Interior

Door Handle Switch - Passenger Exterior

Power Door Systems Connector End Views

Door Handle Switch - Passenger Exterior

Door Handle Switch - Passenger Interior

Power Door Systems Connector End Views

Door Handle Switch - Passenger Interior

Scheme 24

Power Door Systems Connector End Views

Door Latch - Driver

Door Latch - Front Passenger

Power Door Systems Connector End Views

Door Latch - Front Passenger

Scheme 25

Power Door Systems Connector End Views

Door Lock Indicator - Driver

Door Lock Indicator - Passenger

Power Door Systems Connector End Views

Door Lock Indicator - Passenger

Scheme 26

Power Door Systems Connector End Views

Door Lock Switch - Driver

Door Lock Switch - Front Passenger

Power Door Systems Connector End Views

Door Lock Switch - Front Passenger

Scheme 27

Power Door Systems Connector End Views

Driver Door Module (DDM)

Scheme 28

Power Door Systems Connector End Views

Driver Door Switch Assembly (DDSA)

Front Passenger Door Module (FPDM)

Power Door Systems Connector End Views

Front Passenger Door Module (FPDM)

Scheme 29

Power Door Systems Connector End Views

Outside Rearview Mirror - Driver C1

Outside Rearview Mirror - Driver C2

Power Door Systems Connector End Views

Outside Rearview Mirror - Driver C2

Outside Rearview Mirror - Passenger C1

Power Door Systems Connector End Views

Outside Rearview Mirror - Passenger C1

Outside Rearview Mirror - Passenger C2

Power Door Systems Connector End Views

Outside Rearview Mirror - Passenger C2

Scheme 30

Power Door Systems Connector End Views

Window Switch - Front Passenger

Diagnostic Code Index

DIAGNOSTIC CODE INDEX

Diagnostic Starting Point - Doors

Begin the system diagnosis with the Diagnostic System Check - Vehicle in Vehicle DTC Information. The Diagnostic System Check - Vehicle will provide the following information

1. The identification of the control modules which command the system
2. The ability of the control modules to communicate through the serial data circuit
3. The identification of any stored diagnostic trouble codes (DTCs) and their status

The use of the Diagnostic System Check - Vehicle will identify the correct procedure for diagnosing the system and where the procedure is located.

Scan Tool Output Controls

Scan Tool Output Controls

Scan Tool Data List

Body Control Module

Driver Door Module

Driver Door Switch

Passenger Door Module

Circuit Description

The driver door module (DDM) and passenger door module (PDM) are responsible for checking the critical temperature of their respective window motors at least once every 50 milliseconds. When the DDM or PDM detects a critical temperature in the window motor, a DTC will be set. For more detailed information concerning power window operation refer to Power Windows Description and Operation .

DTC Descriptor

This diagnostic procedure supports the following DTC

DTC B1011 System Disabled Information Stored

Conditions for Running the DTC

Battery voltage must be between 9-16 volts.

Conditions for Setting the DTC

The DDM or PDM detects window motor temperature above the normal operating range.

Action Taken When the DTC Sets

1. Window indexing down is still functional.
2. Normal functional requests are possible until the window is completely closed.

Conditions for Clearing the DTC

1. The condition responsible for setting the DTC no longer exists.
2. You issue a scan tool CLEAR DTCs command.

Diagnostic Aids

The following conditions may cause an intermittent malfunction

1. An intermittent sticking or binding condition on a window causing excessive current draw resulting in a critical temperature fault
2. An internally shorted window motor
3. Thoroughly inspect the wiring and connectors. An incomplete inspection of the wiring and connectors may result in misdiagnosis causing part replacement with the reappearance of the malfunction. If an intermittent malfunction exists, refer to «Testing for Intermittent Conditions and Poor Connections»(/cadillac/xlr/i-2003-2009/remont/body-electrical/#how-to-diagnosis-repair-the-wiring-systems-testing__testing-for-intermittent-conditions-and-poor) in Wiring Systems.

DTC B1011

The driver door module (DDM) and passenger door module (PDM) check for proper system voltage of 9-16 volts at least once every 20 milliseconds. When the DDM or PDM detects that system voltage is either below 9 volts or above 16 volts, a DTC is set and DTC updates are disabled.

This diagnostic procedure supports the following DTC

DTC B1420 Device Voltage

Battery voltage must be between 9-16 volts.

The DDM or PDM detects system voltage is below 9 volts or above 16 volts.

DTC updates are disabled.

1. The condition responsible for setting the DTC no longer exists.
2. You issue a scan tool CLEAR DTCs command.

1. DTC B1420 may set during vehicle startup if the vehicle system voltage falls bellow 9 volts.
2. The Starting/Charging system may be the cause of an intermittent malfunction.
3. Thoroughly inspect the wiring and connectors. An incomplete inspection of the wiring and connectors may result in misdiagnosis causing part replacement with the reappearance of the malfunction. If an intermittent malfunction exists, refer to «Testing for Intermittent Conditions and Poor Connections»(/cadillac/xlr/i-2003-2009/remont/body-electrical/#how-to-diagnosis-repair-the-wiring-systems-testing__testing-for-intermittent-conditions-and-poor) in Wiring Systems.

DTC B1420

The left front interior door handle, left front exterior door handle, right front interior door handle and right front exterior door handle switch signal circuits provide inputs to the driver door module (DDM) or passenger door module (PDM) when an interior or exterior door handle switch is activated. These inputs allow the door module to detect a door open request. The door modules provide voltage to the door handle switches. If the door module detects that a ground is applied for greater than 180 seconds, a DTC is set and the door module will ignore the door handle switch input.

DTC Descriptors

This diagnostic procedure supports the following DTCs

1. DTC B1474 Right Front/Passenger Exterior Door Handle Switch Circuit
2. DTC B2981 Right Front Door Handle Switch Circuit
3. DTC B3848 Interior Door Handle Switch Circuit
4. DTC B3849 Left Front/Driver Exterior Door Handle Switch Circuit

Battery voltage must be between 9-16 volts.

1. The DDM or PDM detects a short to ground on an interior or exterior door handle switch signal circuit.
2. The condition must be present for more than 180 seconds.

The DDM or PDM will ignore the door handle switch input.

1. The condition responsible for setting the DTC no longer exists.
2. You issue a scan tool CLEAR DTCs command.

The following conditions may cause an intermittent malfunction

1. There is an intermittent short to ground in a door handle switch signal circuit.
2. An interior or exterior door handle switch is shorted to ground internally.
3. A interior or exterior door handle switch was activated for longer than 180 seconds.
4. Thoroughly inspect the wiring and connectors. An incomplete inspection of the wiring and connectors may result in misdiagnosis causing part replacement with the reappearance of the malfunction. If an intermittent malfunction exists, refer to «Testing for Intermittent Conditions and Poor Connections»(/cadillac/xlr/i-2003-2009/remont/body-electrical/#how-to-diagnosis-repair-the-wiring-systems-testing__testing-for-intermittent-conditions-and-poor) in Wiring Systems.

DTC B1474, B2981, B3848, or B3849 (DDM/PDM)

The left front interior door handle, left front exterior door handle, right front interior door handle and right front exterior door handle switch signal circuits provide inputs to the remote control door lock receiver (RCDLR) when an interior or exterior door handle switch is activated. These inputs allow the RCDLR to detect a door open request. The RCDLR provides voltage to the door handle switches. If the RCDLR detects that a ground is applied for greater than 180 seconds, a DTC is set and the RCDLR will ignore the door handle switch input.

This diagnostic procedure supports the following DTCs

1. DTC B1474 Right Front/Passenger Exterior Door Handle Switch Circuit
2. DTC B2981 Right Front Door Handle Switch Circuit
3. DTC B3848 Interior Door Handle Switch Circuit
4. DTC B3849 Left Front/Driver Exterior Door Handle Switch Circuit

Battery voltage must be between 9-16 volts.

1. The RCDLR detects a short to ground on an interior or exterior door handle switch signal circuit.
2. Condition must be present for greater than 180 seconds.

The RCDLR will ignore the door handle switch input.

1. The condition responsible for setting the DTC no longer exists.
2. You issue a scan tool CLEAR DTCs command.

The following conditions may cause an intermittent malfunction

1. There is an intermittent short to ground in a door handle switch signal circuit.
2. An interior or exterior door handle switch is shorted to ground internally.
3. A interior or exterior door handle switch was activated for longer than 180 seconds.
4. Thoroughly inspect the wiring and connectors. An incomplete inspection of the wiring and connectors may result in misdiagnosis causing part replacement with the reappearance of the malfunction. If an intermittent malfunction exists, refer to «Testing for Intermittent Conditions and Poor Connections»(/cadillac/xlr/i-2003-2009/remont/body-electrical/#how-to-diagnosis-repair-the-wiring-systems-testing__testing-for-intermittent-conditions-and-poor) in Wiring Systems.

DTC B1474, B2981, B3848, or B3849 (RCDLR)

The driver door module (DDM) and passenger door module (PDM) receive mirror position signals from the mirror horizontal and vertical position sensors. These signals are used by the door modules for memory recall functions of the driver and passenger mirrors. The door modules command the mirror memory settings based upon the voltage level received back from the position sensors. Each door module provides a 5 volt supply, a signal, and ground circuit for each of the position sensors. The horizontal and vertical position sensors are variable resistors that the door modules monitor voltage levels across. When a memory setting is recalled, the door modules command the mirror motors in the appropriate directions until the stored position sensor voltage levels are achieved. The DDM and PDM monitor the signal circuits to determine if the voltage level is out of range. For more detailed information concerning power mirror operation refer to Outside Mirror Description and Operation .

This diagnostic procedure supports the following DTCs

1. DTC B1580 Mirror Horizontal Position Sensor Circuit
2. DTC B1590 Mirror Vertical Position Sensor Circuit

Battery voltage must be between 9-16 volts.

These DTCs will set if

1. A mirror position sensor signal voltage is below 0.5 volts for 2 seconds.
2. A mirror position sensor signal voltage is above 4.5 volts for 2 seconds.

1. The door module will ignore the failed position sensor.
2. The door module will ignore memory set or recall for the mirrors.
3. Manual mirror movements will be allowed.

1. The condition responsible for setting the DTC no longer exists.
2. You issue a scan tool CLEAR DTCs command.

1. If DTC B1580 and B1590 are both set, the low reference circuit may be open, or the 5 volt reference circuit may be open, short to ground or short to voltage.
2. Thoroughly inspect the wiring and connectors. An incomplete inspection of the wiring and connectors may result in misdiagnosis causing part replacement with the reappearance of the malfunction. If an intermittent malfunction exists, refer to «Testing for Intermittent Conditions and Poor Connections»(/cadillac/xlr/i-2003-2009/remont/body-electrical/#how-to-diagnosis-repair-the-wiring-systems-testing__testing-for-intermittent-conditions-and-poor) in Wiring Systems.

DTC B1580 or B1590

The driver door module (DDM) and passenger door module (PDM) each provide motor control output functions for their respective mirrors. These output controls allow each door module to command their respective power mirrors in horizontal and vertical positions. The driver door switch assembly (DDSA) sends a serial data message to the door modules when the mirror switch is activated to the up, down, left or right positions. When the door modules detect an active mirror command from the DDSA, they will command the respective mirror motor in the appropriate direction. Each door module commands their respective mirror motors by applying a ground or voltage to the control circuit, depending on the desired mirror position. For more detailed information concerning power mirror operation refer to Outside Mirror Description and Operation .

This diagnostic procedure supports the following DTCs

1. DTC B1600 Mirror Motor 1 (vertical) Circuit
2. DTC B1605 Mirror Motor 2 (horizontal) Circuit

Battery voltage must be between 9-16 volts.

1. The DDM or PDM detects a short to ground or voltage in the mirror motor control circuit.
2. The condition must be present for 2 seconds.

1. When DTC B1600 is present, the vertical mirror control will be disabled.
2. When DTC B1605 is present, the horizontal mirror control will be disabled.

1. The condition responsible for setting the DTC no longer exists.
2. You issue a scan tool CLEAR DTCs command.

The following conditions may cause an intermittent malfunction

1. There is an intermittent short to ground or voltage in a mirror motor control circuit.
2. A mirror motor is shorted internally.
3. Thoroughly inspect the wiring and connectors. An incomplete inspection of the wiring and connectors may result in misdiagnosis causing part replacement with the reappearance of the malfunction. If an intermittent malfunction exists, refer to «Testing for Intermittent Conditions and Poor Connections»(/cadillac/xlr/i-2003-2009/remont/body-electrical/#how-to-diagnosis-repair-the-wiring-systems-testing__testing-for-intermittent-conditions-and-poor) in Wiring Systems.

DTC B1600 or B1605

The outside rearview mirror control switch is contained within the driver door switch assembly (DDSA). The DDSA contains a microprocessor which takes the signal generated by the outside rearview mirror control switch and assigns a digital message to the switch signal. The DDSA sends this message via class 2 serial data to the driver door module (DDM) to move the left mirror or the passenger door module (PDM) to move the right mirror. The DDM or PDM then applies voltage and ground to the appropriate circuits of the appropriate mirror motor to move the mirror vertically and/or horizontally. The mirror motors are reversible. For more detailed information concerning outside rearview mirror operation refer to Outside Mirror Description and Operation .

This diagnostic procedure supports the following DTCs

1. DTC B1697 Mirror Left-Up Control Switch Circuit Low
2. DTC B1702 Mirror Left-Down Control Switch Circuit Low
3. DTC B1707 Mirror Right-Up Control Switch Circuit Low
4. DTC B1712 Mirror Right-Down Control Switch Circuit Low

Battery voltage must be between 9-16 volts.

1. The DDSA detects that the switch contacts are activated.
2. Condition must be present for greater than 30 seconds.

Stores DTC B1697, B1702, B1707, or B1712 in DDSA memory.

1. The condition responsible for setting the DTC no longer exists.
2. You issue a scan tool CLEAR DTCs command.

Thoroughly inspect the wiring and connectors. An incomplete inspection of the wiring and connectors may result in misdiagnosis causing part replacement with the reappearance of the malfunction. If an intermittent malfunction exists, refer to Testing for Intermittent Conditions and Poor Connections in Wiring Systems.

DTC B1697, B1702, B1707, or B1712

The remote control door lock receiver (RCDLR), driver door module (DDM), passenger door module (PDM) and body control module (BCM) control the output functions of the power door latches. These output functions allow the RCDLR and BCM to command the power door latch motors to Unlatch.

When the RCDLR receives an input from one of the door handle switches, it checks the Lock/Unlock status of the door. If the status of the door is Unlock, the RCDLR applies the ground for the appropriate power door latch.

At the same time that the RCDLR is receiving its input, the DDM or PDM is also receiving the same input. When the DDM or PDM receives its input from the door handle switch, it checks the window indexing status of the door. If the window is below the index point, it sends a serial data message to the BCM to apply voltage for the appropriate power door latch. If the window is above the index point, it will first index the window, then send a serial data message to the BCM to apply voltage for the power door latch. For more detailed information concerning power window operation, refer to Power Windows Description and Operation .

The RCDLR monitors the door latch enable control circuit voltage. If the voltage level is greater than 8 volts for longer than 2 minutes, a DTC is set.

This diagnostic procedure supports the following DTC

1. DTC B2517 Left Front/Driver Door Latch Circuit
2. DTC B2518 Right Front/Passenger Door Latch Circuit

Battery voltage must be between 9-16 volts.

1. The RCDLR detects voltage greater than 8 volts in the door latch enable control circuit.
2. Condition must be present for longer than 2 minutes.

Stores DTC B2517 or B2518 in RCDLR memory.

1. The condition responsible for setting the DTC no longer exists.
2. You issue a scan tool CLEAR DTCs command.

1. If the DTC does not reset after the code is cleared, it may be that the door latch enable control circuit is short to voltage. If the voltage circuit that the door lock enable control circuit is shorted to is fused, then the fuse for the voltage circuit would open when a door handle switch is activated and the RCDLR pulls the door lock enable control circuit low. Check related systems for an open fuse.
2. An intermittent short to voltage in a door latch control, or a door latch enable control circuit may cause an intermittent malfunction.
3. If the DTC does not reset after the code is cleared, then the problem may be intermittent. Refer to «Testing for Intermittent Conditions and Poor Connections»(/cadillac/xlr/i-2003-2009/remont/body-electrical/#how-to-diagnosis-repair-the-wiring-systems-testing__testing-for-intermittent-conditions-and-poor) .

DTC B2517 or B2518

The driver door lock switch lock and unlock signal circuits provide inputs to the driver door switch assembly (DDSA) when the driver door lock switch is activated to the Lock or Unlock position. These inputs allow the DDSA to detect a door Lock or Unlock request. The DDSA provides power to the driver door lock switch. When the door lock switch is activated to the Lock or Unlock position, ground is supplied by G201. When the DDSA detects low voltage on a signal circuit, the DDSA will send a message on the class 2 serial data line to the remote control door lock receiver (RCDLR) to enter the power door latches in Lock or Unlock status. The DDSA monitors the signal circuits to determine how long the ground has been applied. For more detailed information concerning power door lock operation refer to Power Door Locks Description and Operation .

This diagnostic procedure supports the following DTCs

1. DTC B3142 Driver Unlock Switch Circuit Low
2. DTC B3152 Driver Lock Switch Circuit Low

Battery voltage must be between 9.0-16.0 volts.

1. The DDSA detects a short to ground on the driver door lock switch lock or unlock signal circuit.
2. Condition must be present for greater than 30 seconds.

Stores DTC B3142 or B3152 in DDSA memory.

1. The condition responsible for setting the DTC no longer exists.
2. You issue a scan tool CLEAR DTCs command.

1. The following conditions may cause an intermittent malfunction: There is an intermittent short to ground in the driver door lock switch lock or unlock signal circuit. The driver door lock switch is shorted to ground internally or is sticking. The driver door lock switch was pressed for longer than 30 seconds.
2. Thoroughly inspect the wiring and connectors. An incomplete inspection of the wiring and connectors may result in misdiagnosis causing part replacement with the reappearance of the malfunction. If an intermittent malfunction exists, refer to «Testing for Intermittent Conditions and Poor Connections»(/cadillac/xlr/i-2003-2009/remont/body-electrical/#how-to-diagnosis-repair-the-wiring-systems-testing__testing-for-intermittent-conditions-and-poor) in Wiring Systems.

DTC B3142 or B3152

The passenger door lock switch signal circuits provide inputs to the passenger door module (PDM) when the passenger door lock switch is activated to the Lock or Unlock position. These inputs allow the PDM to detect a door Lock or Unlock request. The PDM provides power to the passenger door lock switch. When the door lock switch is activated to the Lock or Unlock position, ground is supplied by G202. When the PDM detects low voltage on a signal circuit, it will send a message on the serial data line to the remote control door lock receiver (RCDLR) to enter the power door latches in Lock or Unlock status. For more detailed information concerning power door lock operation refer to Power Door Locks Description and Operation .

This diagnostic procedure supports the following DTCs

1. DTC B3145 Right Front/Passenger Unlock Switch Circuit Low
2. DTC B3155 Right Front/Passenger Lock Switch Circuit Low

Battery voltage must be between 9-16 volts.

1. The PDM detects a short to ground in the passenger door lock switch lock or unlock signal circuits.
2. Condition must be present for greater than 20 seconds.

1. The condition responsible for setting the DTC no longer exists.
2. You issue a scan tool CLEAR DTCs command.

The following conditions may cause an intermittent malfunction

1. There is an intermittent short to ground in the passenger door lock switch lock or unlock signal circuits.
2. The passenger door lock switch is shorted to ground internally or is sticking.
3. The passenger door lock switch was pressed for longer than 20 seconds.
4. Thoroughly inspect the wiring and connectors. An incomplete inspection of the wiring and connectors may result in misdiagnosis causing part replacement with the reappearance of the malfunction. If an intermittent malfunction exists, refer to «Testing for Intermittent Conditions and Poor Connections»(/cadillac/xlr/i-2003-2009/remont/body-electrical/#how-to-diagnosis-repair-the-wiring-systems-testing__testing-for-intermittent-conditions-and-poor) in Wiring Systems.

DTC B3145 or B3155

The power window motor front passenger up and down control and power window switch right front express signal circuits provide inputs to the passenger door module (PDM) when the passenger window switch is activated to the UP, DOWN, EXPRESS UP or EXPRESS DOWN positions. These inputs allow the PDM to detect a window UP, DOWN, EXPRESS UP or EXPRESS DOWN request. The PDM provides power to the passenger window switch. When the window switch is activated to the UP, DOWN, EXPRESS UP or EXPRESS DOWN position, ground is supplied by G202. When the PDM detects low voltage on one of the circuits, it will command the window in the UP, DOWN, EXPRESS UP or EXPRESS DOWN direction. The PDM monitors the circuits to determine how long the ground has been applied. If the PDM detects that a ground is applied for greater than 20 seconds, a DTC is set. For more detailed information concerning power window operation refer to Power Windows Description and Operation .

This diagnostic procedure supports the following DTCs

1. DTC B3170 Right Front Window Up Switch Circuit
2. DTC B3175 Right Front Window Down Switch Circuit
3. DTC B3280 Right Front Window Express Up or Down Circuit

Battery voltage must be between 9-16 volts.

1. The PDM detects a short to ground in a window switch circuit.
2. Condition must be present for greater than 20 seconds.

1. When DTC B3170 is present, inputs from the passenger window UP switch are ignored.
2. When DTC B3175 is present, inputs from the passenger window DOWN switch are ignored.
3. When DTC B3280 is present, inputs from the passenger window EXPRESS switch are ignored.

1. The condition responsible for setting the DTC no longer exists.
2. You issue a scan tool CLEAR DTCs command.

The following conditions may cause an intermittent malfunction

1. There is an intermittent short to ground in the window switch circuit.
2. The window switch is shorted to ground internally or is sticking.
3. The window switch was pressed for longer than 20 seconds.
4. Thoroughly inspect the wiring and connectors. An incomplete inspection of the wiring and connectors may result in misdiagnosis causing part replacement with the reappearance of the malfunction. If an intermittent malfunction exists, refer to «Testing for Intermittent Conditions and Poor Connections»(/cadillac/xlr/i-2003-2009/remont/body-electrical/#how-to-diagnosis-repair-the-wiring-systems-testing__testing-for-intermittent-conditions-and-poor) in Wiring Systems.

DTC B3170, B3175, or B3280

The driver door module (DDM) and passenger door module (PDM) check for hall sensor pulses and relay feedback of their respective window motors at least once every 50 milliseconds. When the DDM or PDM detects no hall sensor pulses or relay feedback in the window motor, a DTC is set. For more detailed information concerning power window operation refer to Power Windows Description and Operation .

This diagnostic procedure supports the following DTC

DTC B3205 Left Front/Driver Window Motor Circuit

Battery voltage must be between 9-16 volts.

1. The DDM or PDM detects no hall sensor pulses from the power window motor.
2. The DDM or PDM detects no relay feedback from the power window motor.

Loss of normalization

1. The condition responsible for setting the DTC no longer exists.
2. You issue a scan tool CLEAR DTCs command.

The following conditions may cause an intermittent malfunction

1. There is an intermittent sticking or binding condition on a window causing the window to be unable to move.
2. A window motor is shorted internally.
3. Thoroughly inspect the wiring and connectors. An incomplete inspection of the wiring and connectors may result in misdiagnosis causing part replacement with the reappearance of the malfunction. If an intermittent malfunction exists, refer to «Testing for Intermittent Conditions and Poor Connections»(/cadillac/xlr/i-2003-2009/remont/body-electrical/#how-to-diagnosis-repair-the-wiring-systems-testing__testing-for-intermittent-conditions-and-poor) in Wiring Systems.

DTC B3205

The window switches are contained within the driver door switch assembly (DDSA). The DDSA internally supplies power and ground to the contacts of each of the integral window switches. When one of the switches is operated, the switch contacts close, providing the DDSA with a specific window switch signal. The DDSA processes this signal, assigns a digital message to it, and sends the message to the driver door module (DDM) or passenger door module (PDM) via the class 2 serial data circuit. The door module, upon receiving the message, examines other relevant information available on the class 2 serial data line in order to determine if conditions are correct for window operation to occur. If conditions are correct, the door module applies power and ground to the associated window motor and circuits in order to move the window. For more detailed information concerning power window operation refer to Power Windows Description and Operation .

This diagnostic procedure supports the following DTCs

1. DTC B3377 Left Front Window Up Switch Circuit Low
2. DTC B3382 Left Front Window Down Switch Circuit Low
3. DTC B3387 Right Front Window Up Switch Circuit Low
4. DTC B3392 Right Front Window Down Switch Circuit Low
5. DTC B3467 Left Front Window Express Up or Down Circuit Low
6. DTC B3472 Right Front Window Express Up or Down Circuit Low

Battery voltage must be between 9.0-16.0 volts.

1. The DDSA detects that the switch contacts are activated.
2. Condition must be present for greater than 30 seconds.

Stores DTC B3377, B3382, B3387, B3392, B3467 or B3472 in DDSA memory.

1. The condition responsible for setting the DTC no longer exists.
2. You issue a scan tool CLEAR DTCs command.

The following conditions may cause an intermittent malfunction

1. A window switch was activated for longer than 30 seconds.
2. The DDSA is shorted internally.

DTC B3377, B3382, B3387, B3392, B3467, or B3472

The driver door module (DDM) and passenger door module (PDM) check for hall sensor pulses of their respective window motors at least once every 50 milliseconds. When the DDM or PDM detects no hall sensor pulses in the window motor, a DTC is set. For more detailed information concerning power window operation refer to Power Windows Description and Operation .

This diagnostic procedure supports the following DTC

DTC B3542 Left Front/Driver Window Obstruction Sensor Control Circuit

Battery voltage must be between 9-16 volts.

1. The DDM or PDM detects no hall sensor pulses from the power window motor.
2. A RAM memory check error has been detected.
3. A window lifter motor error has been detected.
4. Under/overrun of position counter detected.

No window express modes are possible.

1. The condition responsible for setting the DTC no longer exists.
2. You issue a scan tool CLEAR DTCs command.

The following conditions may cause an intermittent malfunction

1. There is an intermittent sticking or binding condition on a window causing the window to be unable to move.
2. A window motor is shorted internally.
3. Thoroughly inspect the wiring and connectors. An incomplete inspection of the wiring and connectors may result in misdiagnosis causing part replacement with the reappearance of the malfunction. If an intermittent malfunction exists, refer to «Testing for Intermittent Conditions and Poor Connections»(/cadillac/xlr/i-2003-2009/remont/body-electrical/#how-to-diagnosis-repair-the-wiring-systems-testing__testing-for-intermittent-conditions-and-poor) in Wiring Systems.

DTC B3542

Symptoms - Doors

1. Perform the «Diagnostic System Check - Vehicle»(/cadillac/xlr/i-2003-2009/remont/oem-general-information/#vehicle-dtc-information) in Vehicle DTC Information before using the symptom tables in order to verify that all of the following are true: There are no DTCs set. The control modules can communicate via the serial data link.
2. Review the system description and operation in order to familiarize yourself with the system functions. Refer to the following: «Power Windows Description and Operation»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) «Power Door Locks Description and Operation»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) «Door Ajar Indicator Description and Operation»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) «Outside Mirror Description and Operation»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) «Automatic Day-Night Mirror Description and Operation»(/cadillac/xlr/i-2003-2009/remont/heated-glassdefoggers/#stationary-windows)

Visual/Physical Inspection

1. Inspect for aftermarket devices which could affect the operation of the power windows, power door locks, or power mirrors. Refer to «Checking Aftermarket Accessories»(/cadillac/xlr/i-2003-2009/remont/body-electrical/#how-to-diagnosis-repair-the-wiring-systems-testing__checking-aftermarket-accessories) in Wiring Systems.
2. Inspect the easily accessible or visible system components for obvious damage or conditions which could cause the symptom.

Intermittent

Faulty electrical connections or wiring may be the cause of intermittent conditions. Refer to Testing for Intermittent Conditions and Poor Connections in Wiring Systems.

Symptom List

Refer to a symptom diagnostic procedure from the following list in order to diagnose the symptom

1. «Power Window Inoperative - Driver Door»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__power-window-inoperative-driver-door)
2. «Power Window Inoperative - Passenger Door»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__power-window-inoperative-passenger-door)
3. «Door Ajar Indicator Malfunction»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__door-ajar-indicator-malfunction)
4. «Power Door Latch Inoperative - Driver Door»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__power-door-latch-inoperative-driver)
5. «Power Door Latch Inoperative - Passenger Door»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__power-door-latch-inoperative-passenger)
6. «Door Lock Indicator Malfunction»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__door-lock-indicator-malfunction)
7. «Power Door Locks Inoperative - One Door or Switch»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__power-door-locks-inoperative-one)
8. «Power Mirrors Inoperative»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__power-mirrors-inoperative)
9. «Power Mirror Folding Inoperative»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__power-mirror-folding-inoperative)
10. «Outside Mirrors Automatic Day-Night Feature Inoperative»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__outside-mirrors-automatic-day-night-feature-inoperative)
11. «Power Mirror - Mirror Tilt Inoperative in Reverse»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__power-mirror-mirror-tilt-inoperative)
12. «Heated Mirrors Inoperative»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__heated-mirrors-inoperative)

Power Window Inoperative - Driver Door

Power Window Inoperative - Driver Door

Power Window Inoperative - Passenger Door

Power Window Inoperative - Passenger Door

Door Ajar Indicator Malfunction

Door Ajar Indicator Malfunction

Power Door Latch Inoperative - Driver Door

Power Door Latch Inoperative - Driver Door

Power Door Latch Inoperative - Passenger Door

Power Door Latch Inoperative - Passenger Door

Door Lock Indicator Malfunction

Door Lock Indicator Malfunction

Power Door Locks Inoperative - One Door or Switch

Power Door Locks Inoperative - One Door or Switch

Power Mirrors Inoperative

Power Mirrors Inoperative

Power Mirror Folding Inoperative

Power Mirror Folding Inoperative

Outside Mirrors Automatic Day-Night Feature Inoperative

Outside Mirrors Automatic Day-Night Feature Inoperative

Power Mirror - Mirror Tilt Inoperative in Reverse

Power Mirror - Mirror Tilt Inoperative in Reverse

Heated Mirrors Inoperative

Heated Mirrors Inoperative

Removal Procedure

1. Remove the door trim panel. Refer to «Door Trim Panel Replacement»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
2. Remove the inner energy absorber from the door panel.
3. Remove 4 retaining screws from the rear of the armrest.
4. Remove 1 retaining screw from the forward end of the armrest assembly.
5. Disconnect the armrest wire harness and remove the armrest assembly.
6. Remove the armrest pull trim cover. Pull to disengage the retainers.
7. Remove the retaining screws from the trim cover applique.
8. Remove the applique from the armrest.
9. Remove the door latch release switch from the armrest trim cover applique.

Installation Procedure

1. Install the door latch release switch to the armrest trim cover applique.
2. Install the applique to the armrest.
3. Install the retaining screws to the trim cover applique. Tighten: Tighten the screws to 1.9 N.m (17 lb in).
4. Install the trim cover to the armrest. Push on the armrest to engage the retainers.
5. Connect the wire harness to the door armrest assembly.
6. Install the armrest to the door trim panel. Secure the armrest with 4 retaining screws at the rear and 1 screw at the forward end of the armrest assembly. Tighten: Tighten the screws to 10 N.m (89 lb in).
7. Install the inner energy absorber to the door panel.
8. Install the door trim panel. Refer to «Door Trim Panel Replacement»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .

1. Remove the door trim panel. Refer to «Door Trim Panel Replacement»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
2. Remove the inner energy absorber from the door panel.
3. Remove 4 retaining screws from the rear of the armrest.
4. Remove 1 retaining screw from the forward end of the armrest assembly.
5. Disconnect the armrest wire harness and remove the armrest assembly.
6. Remove the armrest pull trim cover. Pull to disengage the retainers.
7. Remove the retaining screws from the trim cover applique.
8. Remove the applique from the armrest.
9. Remove the door latch release switch from the armrest trim cover applique.

1. Install the door latch release switch to the armrest trim cover applique.
2. Install the applique to the armrest.
3. Install the retaining screws to the trim cover applique. Tighten: Tighten the screws to 1.9 N.m (17 lb in).
4. Install the trim cover to the armrest. Push on the armrest to engage the retainers.
5. Connect the wire harness to the door armrest assembly.
6. Install the armrest to the door trim panel. Secure the armrest with 4 retaining screws at the rear and 1 screw at the forward end of the armrest assembly. Tighten: Tighten the screws to 10 N.m (89 lb in).
7. Install the inner energy absorber to the door panel.
8. Install the door trim panel. Refer to «Door Trim Panel Replacement»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .

1. Using a flat-bladed plastic tool, carefully pry up at the base of the door lock indicator bezel at the door trim panel.
2. Remove the door lock indicator. Use care when routing the wire harness from the door trim panel.
3. Disconnect the harness connector from the door lock indicator.

1. Disconnect the harness connector from the door lock indicator.
2. Routing the wire harness and connect to the door trim panel.
3. Install the door lock indicator to the door trim panel. Push to engage the retaining tabs.

1. Remove the door trim panel. Refer to «Door Trim Panel Replacement»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
2. Remove the retainer screws from the back of the door trim panel.
3. Remove the upper trim from the door.
4. Remove the energy absorber from the door panel.
5. Remove the 4 retaining screws from the rear of the armrest and 1 screw from the forward end of the armrest assembly.
6. Disconnect the electrical connector and remove the armrest assembly.
7. Remove the front door switch assembly from the pocket in the door trim panel.
8. Disconnect the door switch electrical connector.
9. Remove the door switch assemblies from the door switch bezel.

1. Install the door switch assemblies to the door switch bezel. Push to engage the switch to the bezel.
2. Connect the door switch electrical connector.
3. Install the front door switch assembly to the pocket in the door trim panel.
4. Remove any protective tape prior to installation of the armrest.
5. Connect the electrical connector to the armrest assembly.
6. Install the 4 retaining screws to the rear of the armrest and 1 screw to the forward end of the armrest assembly.
7. Install the energy absorber to the door panel.
8. Install the upper trim to the door.
9. Install the retainer screws to the back of the door trim panel. Tighten: Tighten the screws to 4 N.m (35 lb in).
10. Install the door trim panel. Refer to «Door Trim Panel Replacement»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .

1. Remove the door trim panel. Refer to «Door Trim Panel Replacement»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
2. Remove the retainer screws from the back of the upper trim panel.
3. Remove the upper trim from the door.
4. Remove the inner energy absorber from the door panel.
5. Remove 4 retaining screws from the rear of the armrest.
6. Remove 1 retaining screw from the forward end of the armrest assembly.
7. Disconnect the armrest wire harness and remove the armrest assembly.
8. Remove the power window switch assembly from the pocket in the door trim panel.
9. Disconnect the wire harness to the power window switch.
10. Remove the power window switch from the armrest switch plate applique.

1. Install the power window switch to the armrest switch plate applique. Push to engage the switch to the applique.
2. Connect the wire harness to the power window switch assembly.
3. Install the power window switch assembly into the pocket in the door trim panel.
4. Remove any protective tape.
5. Connect the wire harness to the door armrest assembly.
6. Install the armrest to the door trim panel. Secure the armrest with 4 retaining screws at the rear and 1 screw at the forward end of the armrest assembly. Tighten: Tighten the screws to 10 N.m (89 lb in).
7. Install the inner energy absorber to the door panel.
8. Install the upper trim to the door.
9. Install the retainers at the back of the door trim panel. Tighten: Tighten the retainers to 10 N.m (89 lb in).
10. Install the door trim panel. Refer to «Door Trim Panel Replacement»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .

1. Remove the door trim panel. Refer to «Door Trim Panel Replacement»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
2. Remove the retainer screws from the back of the upper trim panel.
3. Remove the upper trim from the door.
4. Remove the inner energy absorber from the door panel.
5. Remove 4 retaining screws from the rear of the armrest.
6. Remove 1 retaining screw from the forward end of the armrest assembly.
7. Disconnect the armrest wire harness and remove the armrest assembly.
8. Remove the power window switch assembly from the pocket in the door trim panel.
9. Disconnect the wire harness to the power window switch.
10. Remove the power window switch from the armrest switch plate applique.

1. Install the power window switch to the armrest switch plate applique. Push to engage the switch to the applique.
2. Connect the wire harness to the power window switch assembly.
3. Install the power window switch assembly into the pocket in the door trim panel.
4. Remove any protective tape.
5. Connect the wire harness to the door armrest assembly.
6. Install the armrest to the door trim panel. Secure the armrest with 4 retaining screws at the rear and 1 screw at the forward end of the armrest assembly. Tighten: Tighten the screws to 10 N.m (89 lb in).
7. Install the inner energy absorber to the door panel.
8. Install the upper trim to the door.
9. Install the retainers at the back of the door trim panel. Tighten: Tighten the retainers to 10 N.m (89 lb in).
10. Install the door trim panel. Refer to «Door Trim Panel Replacement»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .

1. Remove the door trim panel. Refer to «Door Trim Panel Replacement»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
2. Remove the retainer screws from the back of the upper trim panel.
3. Remove the upper trim from the door.
4. Remove the inner energy absorber from the door panel.
5. Remove 4 retaining screws from the rear of the armrest.
6. Remove 1 retaining screw from the forward end of the armrest assembly.
7. Disconnect the armrest wire harness and remove the armrest assembly.
8. Remove the power door lock switch assembly from the pocket in the door trim panel.
9. Disconnect the wire harness to the power door lock switch.
10. Remove the power door lock switch from the armrest switch plate applique.

1. Install the power door lock switch to the armrest switch plate applique. Push to engage the switch to the applique.
2. Connect the wire harness to the door lock switch assembly.
3. Install the lock switch assembly into the pocket in the door trim panel.
4. Remove any protective tape.
5. Connect the wire harness to the door armrest assembly.
6. Install the armrest to the door trim panel. Secure the armrest with 4 retaining screws at the rear and 1 screw at the forward end of the armrest assembly. Tighten: Tighten the screws to 10 N.m (89 lb in).
7. Install the inner energy absorber to the door panel.
8. Install the upper trim to the door.
9. Install the retainers at the back of the door trim panel. Tighten: Tighten the retainers to 10 N.m (89 lb in).
10. Install the door trim panel. Refer to «Door Trim Panel Replacement»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .

1. Remove the door trim panel. Refer to «Door Trim Panel Replacement»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
2. Remove the retainer screws from the back of the upper trim panel.
3. Remove the upper trim from the door.
4. Remove the inner energy absorber from the door panel.
5. Remove 4 retaining screws from the rear of the armrest.
6. Remove 1 retaining screw from the forward end of the armrest assembly.
7. Disconnect the armrest wire harness and remove the armrest assembly.
8. Remove the power door lock switch assembly from the pocket in the door trim panel.
9. Disconnect the wire harness to the power door lock switch.
10. Remove the power door lock switch from the armrest switch plate applique.

1. Install the power door lock switch to the armrest switch plate applique. Push to engage the switch to the applique.
2. Connect the wire harness to the door lock switch assembly.
3. Install the lock switch assembly into the pocket in the door trim panel.
4. Remove any protective tape.
5. Connect the wire harness to the door armrest assembly.
6. Install the armrest to the door trim panel. Secure the armrest with 4 retaining screws at the rear and 1 screw at the forward end of the armrest assembly. Tighten: Tighten the screws to 10 N.m (89 lb in).
7. Install the inner energy absorber to the door panel.
8. Install the upper trim to the door.
9. Install the retainers at the back of the door trim panel. Tighten: Tighten the retainers to 10 N.m (89 lb in).
10. Install the door trim panel. Refer to «Door Trim Panel Replacement»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .

1. Remove the door trim panel. Refer to «Door Trim Panel Replacement»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
2. Remove the retainer screws from the back of the upper trim panel.
3. Remove the upper trim from the door.
4. Remove the inner energy absorber from the door panel.
5. Remove 4 retaining screws from the rear of the armrest.
6. Remove 1 retaining screw from the forward end of the armrest assembly.
7. Disconnect the armrest wire harness and remove the armrest assembly.
8. Remove the power mirror switch assembly from the pocket in the door trim panel.
9. Disconnect the wire harness to the power mirror switch.
10. Remove the power mirror switch from the armrest switch plate applique.

1. Install the power mirror switch to the armrest switch plate applique. Push to engage the switch to the applique.
2. Connect the wire harness to the power mirror switch assembly.
3. Install the power mirror switch assembly into the pocket in the door trim panel.
4. Remove any protective tape.
5. Connect the wire harness to the door armrest assembly.
6. Install the armrest to the door trim panel. Secure the armrest with 4 retaining screws at the rear and 1 screw at the forward end of the armrest assembly. Tighten: Tighten the screws to 10 N.m (89 lb in).
7. Install the inner energy absorber to the door panel.
8. Install the upper trim to the door.
9. Install the retainers at the back of the door trim panel. Tighten: Tighten the retainers to 10 N.m (89 lb in).
10. Install the door trim panel. Refer to «Door Trim Panel Replacement»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .

1. Remove the door trim panel. Refer to «Door Trim Panel Replacement»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
2. Remove the retainer screws from the back of the upper trim panel.
3. Remove the upper trim from the door.
4. Remove the inner energy absorber from the door panel.
5. Remove 4 retaining screws from the rear of the armrest.
6. Remove 1 retaining screw from the forward end of the armrest assembly.
7. Disconnect the armrest wire harness and remove the armrest assembly.
8. Remove the front door switch assembly from the pocket in the door trim panel.
9. Disconnect the wire harness to the front door switch.
10. Remove the front door switch from the armrest switch plate applique.

1. Install the front door switch to the armrest switch plate applique. Push to engage the switch to the applique.
2. Connect the wire harness to the front door switch assembly.
3. Install the front door switch assembly into the pocket in the door trim panel.
4. Remove any protective tape.
5. Connect the wire harness to the door armrest assembly.
6. Install the armrest to the door trim panel. Secure the armrest with 4 retaining screws at the rear and 1 screw at the forward end of the armrest assembly. Tighten: Tighten the screws to 10 N.m (89 lb in).
7. Install the inner energy absorber to the door panel.
8. Install the upper trim to the door.
9. Install the retainers at the back of the door trim panel. Tighten: Tighten the retainers to 10 N.m (89 lb in).
10. Install the door trim panel. Refer to «Door Trim Panel Replacement»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .

1. Remove the energy absorber from the inner door panel.
2. Remove 4 retaining screws at the rear of the armrest and 1 screw at the forward end.
3. Disconnect the armrest electrical connectors and remove the armrest assembly.
4. Remove the pull trim cover from the armrest. Pull to disengage the retainers.
5. Remove the retaining screws which secure the applique to the armrest.
6. Remove the applique from the armrest.
7. Remove the retaining screws from the inside handle bezel.
8. Remove the bezel from the armrest.

1. Install the inside handle bezel to the armrest.
2. Install the retaining screws to the inside handle bezel. Tighten: Tighten the screws to 1.9 N.m (17 lb in).
3. Install the applique to the armrest.
4. Install the retaining screws which secure the applique to the armrest. Tighten: Tighten the screws to 1.9 N.m (17 lb in).
5. Install the pull trim cover to the armrest. Push to engage the retainers.
6. Connect the armrest electrical connectors.
7. Install the armrest assembly to the door trim panel. Insert 4 retaining screws at the rear of the armrest and 1 screw at the forward end. Tighten: Tighten the screws to 10 N.m (89 lb in).
8. Install the energy absorber to the inner door panel.
9. Install the door trim panel. Refer to «Door Trim Panel Replacement»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .

1. Remove the inside handle bezel from the armrest. Refer to «Door Inside Handle Bezel Replacement»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
2. Remove the armrest.

1. Install the armrest.
2. Install the inside handle bezel to the armrest. Refer to «Door Inside Handle Bezel Replacement»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .

Scheme 31

Remove the armrest pull trim cover. Pull to disengage the retainers.

Install the armrest pull trim cover. Push to engage the retainers.

1. Remove the door trim panel. Refer to «Door Trim Panel Replacement»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
2. Remove the screws attaching the duct.
3. Remove the duct with the boot and the deflector.
4. Remove the deflector from the duct.

1. Install the deflector to the duct.
2. Install the duct with the boot to the trim panel.
3. Secure the duct with screws to the door trim panel. Tighten: Tighten the screws to 2.5 N.m (22 lb in).
4. Install the door trim panel. Refer to «Door Trim Panel Replacement»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .

1. Remove the door trim panel. Refer to «Door Trim Panel Replacement»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
2. Remove the screws that retain the map pocket trim assembly to the door trim.
3. Remove the map pocket trim panel from the door trim.

1. Install the map pocket trim panel to the door trim panel.
2. Install the retaining screws which secure the map pocket to the door trim panel. Tighten: Tighten the screws to 1 N.m (9 lb in).
3. Install the door trim panel. Refer to «Door Trim Panel Replacement»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .

Tools Required

J 38778 Door Trim Pad Clip Remover

1. Lower the window.
2. Remove the reflector lens with a trim tool.
3. If the reflector lens does not come off in the previous step, insert a screwdriver into the hole at the rearward edge of the lamp housing. Holding the screwdriver, use a door trim removal tool to depress the top and bottom clip (closest to the rearward end of the housing). Refer to Step 10 for housing removal from the door trim pad.
4. Turn the housing 90 degrees outward.
5. Remove the one bolt behind the housing of the reflector.
6. Remove the rubber closeout pad inside the bottom of the armrest wood handle.
7. Remove the 2 bolts in the handle. Use needle nose pliers to remove the bolts from the trim pad after they are completely loosened.
8. Insert J 38778 into the slot provided in the trim panels.
9. Pry the door trim panel away from the door, moving rearward to the back of the door, then forward to the front speaker. When the panel is sufficiently loosened, grasp with both hands and lift up and towards you. The top of the door trim pad has a metal retainer that holds the door trim pad to the top of the door.
10. This metal retainer has 3 downward flanges that hold it to the top of the door, as shown in illustration.
11. With the door trim removed, the courtesy lamp housing can be extracted from the hole in the back of the door trim pad. Rotate the lamp over on its side and lift out of the hole.
12. Disconnect the harness.
13. Inspect both male and female retainer halves for damage or wear. Replace as necessary.

1. Connect the electrical connector behind the speaker.
2. Lower the door glass.
3. Line up the retainer pins to the grommets in the door. The pins are long enough to reasonably stay put while the top of the door is installed.
4. Set the hanger bracket at the top of the door to the door inner flange. Ensure that all 3 sections are snug on the flange.
5. Lightly hit the 3 locations at the front of the door and then the 4 locations at the rear of the door with the palm of your hand.
6. To prevent collapsing the rivnut, hand start the bolt behind the courtesy lamp. Tighten: Tighten the nut to 10 N.m (89 lb in).
7. Install the 2 handle bolts. Tighten: Tighten the bolts to 6 N.m (53 lb in).
8. Install the covers over the bolts.
9. Plug in the courtesy lamp.
10. With the reflector lens back on the courtesy lamp housing, push straight in with the palm of your hand to seat the lens.

Door Control Module Replacement

Refer to Door Window Regulator Replacement .

Refer to Control Module References for programming and setup information.

1. Remove the door trim panel. Refer to «Door Trim Panel Replacement»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
2. Remove the door energy absorber. Heat will aid in removal.

1. Glue the door energy absorber to the door trim panel. Use hot melt glue. Glue the complete surface of the absorber.
2. Install the door trim panel. Refer to «Door Trim Panel Replacement»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .

1. Remove the door trim panel. Refer to «Door Trim Panel Replacement»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
2. Peel the water deflector (1) from the door inner panel.

1. Peel the backing paper from the adhesive on the new deflector.
2. Position the deflector (1) over the large opening in the door.
3. Beginning at the bottom of the water deflector press firmly to secure the adhesive.
4. Install the door trim panel. Refer to «Door Trim Panel Replacement»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .

Up/Down Adjustment Procedure

1. Loosen the upper hinge to hinge pillar bolts.
2. Reposition the hinge up to raise or down to lower the door.
3. Tighten the upper hinge bolts. Tighten: Tighten the door hinge to hinge pillar bolts to 30 N.m (22 lb in).
4. Loosen the lower hinge to hinge pillar bolts.
5. Reposition the hinge.
6. Tighten the lower hinge bolts. Tighten: Tighten the door hinge to hinge pillar bolts to 30 N.m (22 lb in).
7. Repeat the procedure for additional adjustment if necessary.

In/Out Adjustment Procedure

1. Loosen the upper hinge to door bolts.
2. Reposition the hinge outward to adjust the door inward or inward to adjust the door outward.
3. Tighten the upper hinge to door bolts. Tighten: Tighten the door hinge to door bolts to 30 N.m (22 lb in).
4. Loosen the lower hinge to door bolts.
5. Reposition the hinge.
6. Tighten the lower hinge to door bolts. Tighten: Tighten the door hinge to door bolts to 30 N.m (22 lb in).
7. Repeat procedure for additional adjustment if necessary.

1. Mark the harness grommet at the edge of the hinge pillar opening, to aid in determining the depth of the grommet on reassembly.
2. Disconnect the harness grommet from the hinge pillar.
3. Disconnect the electrical connectors.
4. Mark the location of the hinges on the pillar.
5. Support the door.
6. Remove the bolts attaching the hinges to the hinge pillar.
7. Remove the door.
8. Transfer the parts as necessary.

1. Position the door to the opening, aligning the hinges to the marks.
2. Install the bolts attaching the hinges to the hinge pillar. Tighten: Tighten the door hinge to hinge pillar bolts to 30 N.m (22 lb ft).
3. Connect the harness electrical connectors.
4. Install the harness grommet into the hinge pillar, aligning the depth mark with the edge of the hinge pillar opening.
5. Adjust the door as necessary by loosening the hinge bolts, and repositioning the hinge and/or the door.
6. Adjust the door window as necessary.

Scheme 32

Front Side Door Hinge Replacement

This procedure covers the removal of either the driver or the passenger door release electric touch pad.

1. Open the door by using the touch pad or the floor mounted actuator.
2. Remove the fasteners (3) from the touch pad (1).
3. Remove the touch pad from the mounted position.
4. Disconnect the electrical connector (2).
5. Remove the touch pad.

1. Connect the touch pad electrical connector (2).
2. Position the touch pad onto the door.
3. Install the fasteners (3). Tighten: Tighten the fasteners to 2 N.m (18 lb in).
4. Verify the operation of the electric touch pad door release.

1. Move the seat to the rear position.
2. Remove both trim plugs from the fastener sockets (1) of the floor mounted door release.
3. Remove the push pin (2) from the front seat riser cover. The cover is nearest to the floor mounted door release.
4. Tilt the seat riser cover forward for clearance to the rear fastener of the door release.
5. Remove both fasteners (1) from the door release.
6. Remove the fasteners (1) from the backside of the door release actuator.
7. Separate the release halves, and unseat the cable sheath (2) from the housing.
8. Rotate the door release towards the rear, while guiding the cable between the actuator halves.
9. Disengage the cable end (1) from the latch actuating lever.

1. With the door release actuator facing the rear, engage the cable end (1) to the release actuating lever.
2. Rotate the door release assembly forward, while guiding the cable between the actuator halves.
3. Position the cable sheath (2) in the actuator, and join the halves.
4. Install the fasteners (1) to the backside of the door release actuator. Tighten: Tighten the fasteners to 2 N.m (18 lb in).
5. Position the door release actuator to the door sill.
6. Install both fasteners (1) to the door release. Tighten: Tighten the fasteners to 10 N.m (89 lb in).
7. Install both fastener trim plugs (1) to the door release actuator.
8. Align the seat riser cover to the hole in the riser. Fasten the push pin (2).

1. Move the seat to the rear position.
2. Remove both trim plugs (1) from the fastener sockets of the floor-mounted door release.
3. Remove the push pin (2) from the front seat riser cover, which is nearest to the floor-mounted door release.
4. Tilt the seat riser cover forward for clearance to the rear fastener of the door release.
5. Remove both fasteners (1) from the door release.
6. Move the seat to the forward position.
7. Disconnect the battery.
8. Remove the door sill trim. Refer to «Carpet Retainer Replacement»(/cadillac/xlr/i-2003-2009/remont/exteriorinterior-trim/#interior-trim) .
9. Remove the B-Pillar interior trim. Refer to «Rear Quarter Trim Panel Replacement»(/cadillac/xlr/i-2003-2009/remont/exteriorinterior-trim/#interior-trim) .
10. Remove the mastic cover (1) from the door latch access hole in the body.
11. Remove the fasteners (2) from the B-Pillar mounted door latch.
12. Remove the latch (1) from the body access hole.
13. Slide the electrical connector lock (1) to the open position. Remove the connector from the door latch.
14. Remove the latch cover fasteners from the rear of the latch.
15. Release the cable sheath ends. Remove the latch cover.
16. Remove the cable end by rotating the cable a quarter turn to disengage from the latch actuating lever. The floor-mounted release cable is attached to the lower lever on the latch.
17. Attach a mechanic's wire to the latch end of the cable to assist in guiding the replacement cable back into position.
18. Pull the cable from the release handle end. Guide the cable through the hole in the carpeting.

1. Attach the replacement cable end to the mechanic's wire.
2. Pull the mechanic's wire back through the carpet, guiding the cable toward the latch.
3. Install the cable end on the latch by rotating the cable a quarter turn to engage the cable end to the latch actuating lever.
4. Seat the cables into the molded latch cover recess. Install the latch cover.
5. Install the latch cover fasteners to the latch. Tighten: Tighten the screws to 2 N.m (18 lb in).
6. Install the electrical connector. Slide the connector lock (1) to the seated position on the door latch mechanism.
7. Place the latch in the body access hole, aligning the fastener holes to the body.
8. Install the fasteners (1) through the cover plate (2) and to the B-Pillar mounted door latch (3). Tighten: Tighten the fasteners to 10 N.m (89 lb in).
9. Connect the battery.
10. Verify the operation of the latch using the front and rear manual release. Verify the key fob, the door touch pad, and the door panel electrical actuators.
11. Install the new mastic cover (1) over the latch access hole in the body.
12. Install the B-Pillar interior trim. Refer to «Rear Quarter Trim Panel Replacement»(/cadillac/xlr/i-2003-2009/remont/exteriorinterior-trim/#interior-trim) .
13. Install the door sill trim. Refer to «Carpet Retainer Replacement»(/cadillac/xlr/i-2003-2009/remont/exteriorinterior-trim/#interior-trim) .
14. Move the seat to the rear most position.
15. Install both fasteners (1) to the floor-mounted door handle release. Tighten: Tighten the fasteners to 10 N.m (89 lb in).
16. Install both fastener trim plugs (1) to the door handle release.
17. Align the seat riser cover to the hole in the riser. Fasten the push pin (2).

1. Unscrew and remove both cargo net hooks from the driver side trim panel in the rear compartment.
2. Pull the trim away from the body.
3. Guide the end of the door release cable through the slit in the trim panel, toward the body. The release is in the driver side trim panel, behind a trap door with the fuel door release.
4. Remove the fastener (1) from the retaining bracket that holds the rear-mounted door release cable.
5. Lift the driver side carpet from the rear compartment floor to expose the rear-mounted door release cable.
6. Separate the fingers (2) of the retainers in order to free the cable (1).
7. Disconnect the battery.
8. Remove the doorsill trim. Refer to «Carpet Retainer Replacement»(/cadillac/xlr/i-2003-2009/remont/exteriorinterior-trim/#interior-trim) .
9. Remove the B-Pillar interior trim. Refer to «Rear Quarter Trim Panel Replacement»(/cadillac/xlr/i-2003-2009/remont/exteriorinterior-trim/#interior-trim) .
10. Remove the mastic cover (1) from the door latch access hole in the body.
11. Remove the fasteners (1) from the B-Pillar mounted door latch (3).
12. Remove the latch (1) from the body access hole.
13. Slide the electrical connector lock (1) to the unlocked position. Remove the connector from the door latch.
14. Remove the fasteners from the rear latch cover securing the cables.
15. Release the cable sheath ends. Remove the latch cover.
16. Remove the cable end by rotating the cable a quarter turn to disengage from the latch actuating lever. The floor mounted release cable is attached to the lower lever on the latch.
17. Attach a mechanic's wire to the latch end of the cable in order to assist in guiding the replacement cable back into position.
18. Pull the cable from the rear compartment end, and guide it out through the trim panel in the rear compartment.

1. Attach the replacement cable end to the mechanic's wire.
2. Pull the mechanics wire back through the carpet, guiding the cable toward the latch.
3. Install the cable end on the latch by rotating the cable a quarter turn to engage the cable end to the latch actuating lever.
4. Seat the cables into the molded latch cover recess. Install the latch cover.
5. Install the latch cover fasteners to the latch. Tighten: Tighten the fasteners to 2 N.m (18 lb in).
6. Install the electrical connector. Slide the connector lock (1) to the seated position on the door latch mechanism.
7. Place the latch (1) in the body access hole, aligning the fastener holes to the body.
8. Install the fasteners (1) through the cover plate (2) and to the B-Pillar mounted door latch (3). Tighten: Tighten the fasteners to 10 N.m (89 lb in).
9. Install the fastener (1) to the bracket retaining the rear door release cable (2). Tighten: Tighten the fasteners to 3 N.m (27 lb in).
10. Guide the end of the door release cable through the slit in the trim panel toward the rear compartment area.
11. Seat the trim panel to the body, and screw in both cargo net hooks to the driver side trim panel in the rear compartment.
12. Connect the battery.
13. Verify the operation of the latch using the front and rear manual release. Verify the key fob, the door touch pad, and the door panel electrical actuators.
14. Install the new mastic cover (1) over the latch access hole in the body.
15. Install the B-Pillar interior trim. Refer to «Rear Quarter Trim Panel Replacement»(/cadillac/xlr/i-2003-2009/remont/exteriorinterior-trim/#interior-trim) .
16. Install the doorsill trim. Refer to «Carpet Retainer Replacement»(/cadillac/xlr/i-2003-2009/remont/exteriorinterior-trim/#interior-trim) .

1. Move the seat to the forward position, with the seat back also tilted forward.
2. Disconnect the battery.
3. Remove the door sill trim. Refer to «Carpet Retainer Replacement»(/cadillac/xlr/i-2003-2009/remont/exteriorinterior-trim/#interior-trim) .
4. Remove the B-pillar trim panel (1). Refer to «Body Lock Pillar Trim Panel Replacement»(/cadillac/xlr/i-2003-2009/remont/exteriorinterior-trim/#interior-trim) .
5. Remove the mastic cover (1) from the door lock access hole in the body.
6. Remove the fasteners (1) from the B-Pillar mounted door lock (3).
7. Remove the lock (1) from the body access hole.
8. Slide the electrical connector lock (1) to the open position, and remove the connector (2) from the door lock.
9. Remove the fasteners from rear lock cover securing the cables.
10. Unseat the cable sheath ends, and remove the lock cover.
11. Remove the cable ends by rotating the cable a quarter turn to disengage from the lock-actuating lever.
12. Remove the lock from the vehicle.

1. Remove the rear cover from the replacement lock.
2. Install the cable ends onto the replacement lock by engaging the cable end into the lock-actuating lever, and rotating the cable a quarter turn.
3. Seat the cable's sheath into the molded lock cover recess, and install the lock cover fasteners. Tighten: Tighten the screws to 2 N.m (19 lb in).
4. Install the electrical connector (2), and slide the connector lock (1) to the seated position on the door lock mechanism.
5. Place the lock (1) in the B-Pillar body access hole, aligning the fastener (3) holes to the body.
6. Install the fasteners (1) through the cover plate (2) and to the B-Pillar mounted door lock (3). Tighten: Tighten the screws to 10 N.m (89 lb in).
7. Install a new mastic cover (1) over the door lock access hole.
8. Reconnect the battery.
9. Verify the manual and electrical functions of the lock. Door lock release handle - interior floor mounted Door lock release handle - rear compartment mounted Door lock release handle - interior door panel push button Door lock release handle - exterior door touch pad
10. Install the B-pillar trim panel. Refer to «Body Lock Pillar Trim Panel Replacement»(/cadillac/xlr/i-2003-2009/remont/exteriorinterior-trim/#interior-trim) .
11. Install the door sill cover. Refer to «Carpet Retainer Replacement»(/cadillac/xlr/i-2003-2009/remont/exteriorinterior-trim/#interior-trim) .
12. Move the seat to the original position.

Scheme 33

1. Raise the door window.
2. Remove the door panel. Refer to «Door Trim Panel Replacement»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
3. Remove the large water deflector (1) for inside access to the rear of the door.
4. Mark the striker location on the outer door edge.
5. Remove the striker fasteners (1) from the inside of the door.
6. Remove the striker (2).

1. Position the striker (2) onto the door, with the latching pin toward the door latch.
2. Install the fasteners (1) snugly onto the striker.
3. Align the striker (2) to the previous marks. Tighten the fasteners. Tighten: Tighten the door lock striker screws to 24 N.m (18 lb ft).
4. If you are unable to locate the previous striker marks, perform the following steps: With the striker installed, and the fasteners snug but still adjustable, have an assistant hold the outer door panel flush with the quarter panel. Tighten the striker fasteners from the interior of the vehicle while the door is flush with the quarter panel. Tighten: Tighten the door lock striker screws to 24 N.m (18 lb ft).
5. Install the large water deflector (1) to the rear of the door.
6. Install the door panel. Refer to «Door Trim Panel Replacement»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
7. Verify the fit of the panels, and the operation of the door latch by using the manual and electric door release.

Scheme 34

The mechanical components of the door are lubricated during assembly. If additional lubrication is required to any door hardware mechanism, lubricate with Lubriplate Spray-Lube GM P/N 1052349 (Canadian P/N 992723), Lubriplate Auto-Lube GM P/N 1052196 (Canadian P/N 5264008), or equivalent. Lubrication of the door hinge roller is not recommended, lubricating the door hinge roller may allow the door hinge roller to slide against the door check link contacting surfaces causing uneven wear to the door hinge roller.

Door Window Adjustment

Door Module Initialization Procedure

1. Close the door.
2. Raise the window by holding the up arrow on the power window switch.
3. Hold the up arrow for three seconds after the window is closed.
4. Release the switch.
5. Hold the up arrow again for three seconds.

Keep in mind that nothing can be obstructing the window from closing or opening. If you continue the initialization, the window will only Express-Up or Express-Down, to the spot where the obstruction occurred. The Express features will not work until the system has been reinitialized.

Window Adjustment - Door

1. Raise the window.
2. Disconnect the battery.
3. Remove the door trim panel. Refer to «Door Trim Panel Replacement»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
4. Remove the mastic sealer from the window clamp access holes.
5. Loosen the window clamp bolts.
6. Jiggle the window to break the window loose from the clamps rubber seals. Verify that the rubber inserts are not dislodged, or stuck on the window glass.
7. Note the imprinted reference mark on the glass. Position the mark to the trailing edge of the rearmost clamp on the window regulator.
8. Apply masking tape to the leading (1), and top edges (2) of the outer window glass.
9. Place a mark on the leading edge tape (1) 8 mm (0.3 in) from the top of the glass.
10. Place a mark on the top edge masking tape (2) 10 mm (0.4 in) from the top of the glass.
11. Adjust the window using one of the following methods: Put a socket on the clamp bolt and use the socket to move the window. Adjust the window forward or rearward first. Adjust the front height second. Adjust the rear height last. Sit in the vehicle with the door closed and with the aid of an assistant standing outside of the vehicle, position the window in the door opening. Adjust the window forward or rearward first. Adjust the front height second. Adjust the rear height last.
12. Slide the window in the window clamps as necessary. The glass should penetrate the leading seal (1) 8 mm (0.3 in). The glass should penetrate the top seal at (2) and (3) 10 mm (0.4 in). The gap should be evenly spaced at (4) and (5).
13. Tighten the window clamps. Tighten: Tighten the window regulator window clamp bolts to 16 N.m (12 lb ft).
14. Install new mastic sealer to the window clamp access holes.
15. Open the door and carefully guide the glass past the seals.
16. Install the door trim panel. Refer to «Door Trim Panel Replacement»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
17. Reconnect the battery.
18. Lower the door glass and perform door module reprogramming after closing the door.
19. To perform minor height and minor tip-in adjustments. Refer to «Door Window Tip-In Adjustment»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__door-window-tip-in-adjustment) and «Door Window Minor Height Adjustment»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__door-window-minor-height-adjustment) .

Door Window Tip-In Adjustment

Tools Required

#6 Inverted TORX® Socket

1. Position the window fully up.
2. Remove the large access plug from under the front of the door.
3. Loosen the window regulator front channel mounting nut.
4. Remove the reflector from the trim panel
5. Loosen the jack screw jam nut.
6. Adjust tip in with the jack screw. Turn the jack screw clockwise to tip the window outward. Turn the jack screw counterclockwise to tip the window inward. One turn of the screw equals approximately 1 N.m (0.04 in) change at the top of the window.
7. Tighten the jack screw jam nut.
8. Lower the window.
9. Tighten the window regulator channel front mounting nut.
10. Raise the window and check the alignment.
11. Install the access plug under the front of the door.
12. Install the reflector in the door trim panel.

Door Window Minor Height Adjustment

Use this procedure when window height is off less than 3 mm (0.12 in).

1. Open the door and remove the small front access plug and the rear access plug from the underside of the door.
2. Adjust the front and the rear window regulator jack screws equally.
3. Close the door and check the window alignment.
4. Open the door and install the access plugs.

Door Window Major Height Adjustment

1. Raise the door window.
2. Remove the door trim panel. Refer to «Door Trim Panel Replacement»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
3. Remove the mastic sealer from the window clamp access holes.
4. Loosen the window clamps on the window regulator.
5. Jiggle the window to break the window loose from the clamps rubber seals. Verify that the rubber inserts are not dislodged, or stuck on the window.
6. Note the imprinted reference mark on the glass. Position the mark to the trailing edge of the rearmost clamp on the window regulator.
7. Apply masking tape to the leading (1), and top edges (2) of the outer window.
8. Place a mark on the leading edge tape (1) 8 mm (0.3 in) from the top of the window.
9. Place a mark on the top tape edges at (2), 10 mm (0.4 in) from the top of the window.
10. Adjust the window using one of the following methods: Put a socket on the clamp bolt and use the socket to move the window. Adjust the window forward or rearward first. Adjust the front height second. Adjust the rear height last. Sit in the vehicle with the door closed and with the aid of an assistant standing outside of the vehicle, position the window in the door opening. Adjust the window forward or rearward first. Adjust the front height second. Adjust the rear height last.
11. Slide the window in the window clamps as necessary. The window should penetrate the leading seal (1) 8 mm (0.3 in). The window should penetrate the top seal at (2) and (3) 10 mm (0.4 in).
12. Tighten the window clamps. Tighten: Tighten the window regulator window clamp bolts to 16 N.m (12 lb ft).
13. Carefully open the door, noting any interference between the window and seals.
14. Install new mastic sealer to the window clamp access holes.
15. Install the door trim panel. Refer to «Door Trim Panel Replacement»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
16. Perform minor height and minor tip-in adjustments as necessary. Refer to «Door Window Tip-In Adjustment»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__door-window-tip-in-adjustment) and «Door Window Minor Height Adjustment»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__door-window-minor-height-adjustment) .

Scheme 35

1. Lower the door window.
2. Disconnect the battery.
3. Remove the door trim panel. Refer to «Door Trim Panel Replacement»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
4. Disconnect the door panel electrical connector.
5. Remove the large water deflector (1) for inside access to the rear of the door.
6. Remove the small mastic seals (1) near the top of the door for access to the upper regulator mounting fasteners.
7. Remove the small plug on the bottom of the door for access to the lower regulator mounting fastener.
8. Remove the radio speaker fasteners (4).
9. Remove the electrical connector lock. Disconnect the electrical harness. Remove the radio speaker from the door.
10. Remove the door window. Refer to «Door Window Replacement»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
11. Disconnect the regulator motor electrical connector (3).
12. Slide the connector lock (1) up. Separate the harness.
13. Mark the location of the regulator to aid in reassembly. Note the position and depth of the regulator mounting pads for positioning new parts.
14. Remove the nuts from the regulator lower channel studs.
15. Remove the nuts from the regulator motor studs.
16. Remove the nuts from the upper regulator channel studs.
17. Compact the regulator and remove the regulator through the inner door access opening.

1. If replacing the window regulator with a new part, adjust the replacement assembly jack screws to match the old regulator settings.
2. Compact the regulator assembly, and insert the entire unit with the motor forward, into the door.
3. Position the motor studs through the door inner panel.
4. Install the nuts to the motor studs. Tighten: Tighten the window regulator motor nuts to 10 N.m (89 lb in).
5. Guide the regulator channel studs into, and through the holes in the door.
6. Loosely install the nuts to the regulator channel studs.
7. Connect the electrical connector (3) to the motor (1).
8. Slide the connector lock (1) to the seated position.
9. Install the window. Refer to «Door Window Replacement»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
10. Adjust the window to align with the door opening. Refer to «Door Window Major Height Adjustment»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__door-window-major-height-adjustment) and «Door Window Tip-In Adjustment»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__door-window-tip-in-adjustment) .
11. Connect the battery.
12. Connect the door window switch, and run window regulator clamps up to meet glass.
13. Tighten the window regulator clamps to secure the glass. Tighten: Tighten the window regulator clamps to 16 N.m (12 lb ft).
14. Tighten the nuts to the regulator channel studs in the following order: Upper forward Upper rearward Tighten: Tighten the regulator channel stud nuts to 10 N.m (89 lb in).
15. Run window glass to the full down position.
16. Tighten the nuts to the regulator channel studs in the following order: Lower forward Lower rearward Tighten: Tighten the regulator channel stud nuts to 10 N.m (89 lb in).
17. Install the small mastic seals in the window clamp sight access holes.
18. Connect the harness electrical connector to the speakers. Install the connector lock.
19. Install the uppermost screws (4) mounting the speaker assembly to the door.
20. Verify proper fit of speaker tab (2), noting the index notch in the door.
21. Install the remaining screws (4). Tighten: Tighten the door speaker assembly screws to 3 N.m (27 lb in).
22. Install the water deflector (1).
23. Connect the door panel electrical connector.
24. Install the door trim panel. Refer to «Door Trim Panel Replacement»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
25. Inspect the window fit, adjust as necessary. Refer to «Door Window Major Height Adjustment»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__door-window-major-height-adjustment) or «Door Window Tip-In Adjustment»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__door-window-tip-in-adjustment) or «Door Window Minor Height Adjustment»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__door-window-minor-height-adjustment) .
26. Install the access plug into the bottom of the door.
27. Verify the operation of the window(s), mirror(s), and door switch electrical functions.
28. Reinitialize the windows. Refer to «Power Window Reinitialization»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__power-window-reinitialization) .

1. Position the window full up to access the window clamp fasteners.
2. Remove the door trim panel. Refer to «Door Trim Panel Replacement»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
3. Remove the mastic (1) covering the window clamp access holes.
4. Loosen the window clamp fasteners.
5. Lightly rock the window to break the window loose from the clamps rubber seals. Verify that the rubber inserts are not dislodged, or stuck on the window glass.
6. Remove the window, through the top of the door.

1. Install the window, through the top of the door, to the regulator that is in the full up position.
2. Note the imprinted reference mark on the glass. Position the mark to the trailing edge of the rearmost clamp on the window regulator.
3. Loosely tighten the window clamp fasteners to allow for adjustment of the window.
4. Apply masking tape to the leading (1), and top edges (2) of the outer window glass.
5. Place a mark on the leading edge tape (1) 8 mm (0.3 in) from the top of the glass.
6. Place a mark on the top tape edges (2), 10 mm (0.4 in) from the top of the glass.
7. Adjust the window using one of the following methods: Put a socket on the clamp bolt and use the socket to move the window. Adjust the window forward or rearward first. Adjust the front height second. Adjust the rear height last. Sit in the vehicle with the door closed and with the aid of an assistant standing outside of the vehicle, position the window in the door opening. Adjust the window forward or rearward first. Adjust the front height second. Adjust the rear height last.
8. Slide the window in the window clamps as necessary. The window should penetrate the leading seal (1) 8 mm (0.3 in). The window should penetrate the top seal at (2) and (3) 10 mm (0.4 in).
9. Tighten the window clamps. Tighten: Tighten the window regulator window clamp bolts to 16 N.m (12 lb ft).
10. Carefully open the door and guide the window past the seals.
11. Install new mastic sealer (1) to the window clamp access holes.
12. Install the door trim panel. Refer to «Door Trim Panel Replacement»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
13. Lower the door glass and perform door module reprogramming after closing the door. Refer to: «Door Window Adjustment»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__door-window-adjustment)
14. To perform minor height and minor tip-in adjustments. Refer to «Door Window Tip-In Adjustment»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__door-window-tip-in-adjustment) and «Door Window Minor Height Adjustment»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__door-window-minor-height-adjustment) .

Power Window Reinitialization

The reinitialization of the power windows will be necessary anytime a door module has been disconnected, replaced, or the vehicles battery has been disconnected or discharged. The power window will be reinitialized when the door module learns the full up and full down positions.

To reinitialize a power window

1. Close the door for the window being reinitialized.
2. Turn ON the ignition, with the engine OFF.
3. Run the window to the full up position and hold the switch continuously for a minimum of 0.5 seconds.
4. Run the window to the full down position and hold the switch continuously for a minimum of 0.5 seconds.

1. Lower the window into the door
2. Remove the plastic retainers (1) from the sealing strip at the front and rear of the door.
3. Lift the sealing strip (2) from the rear of the door.
4. Remove the sealing strip (2).

1. Place the sealing strip (2) on the lip of the door. Guide the seal end mating surfaces together, and seat the strip.
2. Align the sealing strip retainers (1) to the slots in the door.
3. Push the retainers (1) into the slots.
4. Verify the operation of the seal against the window.

1. Lower the window into the door.
2. Remove the door panel. Refer to «Door Trim Panel Replacement»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
3. Lift the sealing strip (1) from the door.
4. Remove the sealing strip.

1. Place the sealing strip (1) on the lip of the door.
2. Guide the seal end mating surfaces together, and seat the strip.
3. Install the door panel. Refer to «Door Trim Panel Replacement»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
4. Verify the operation of the seal against the window.

1. Remove the push-pin retainers from the ends (2) of the weatherstrip.
2. Remove the weatherstrip (1) and retainers from the door.
3. Remove any weatherstrip retainers that remain in the door. The new weatherstrip comes with retainers.

1. Starting at one end of the weatherstrip (1) align the retainers on the weatherstrip with the holes in the door.
2. Press the retainers firmly into the holes in the door. Align the ends of the weatherstrip to the molded ends (2).
3. Insert and press the push-pin retainers through the weatherstrip molded ends into the door.

1. Lower the door window.
2. Remove the door trim panel. Refer to «Door Trim Panel Replacement»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
3. Disconnect the electrical/audio connector.
4. Remove the mirror nut access plugs.
5. Disconnect the electrical connector(s).
6. Disconnect the mirror harness from the retainers.
7. Remove the fasteners (1) from the mirror studs.
8. Remove the mirror with the harness and gasket.

1. Position the mirror with the gasket and harness to the door.
2. Install the fasteners (1) to the mirror. Tighten: Tighten the mirror nuts to 10 N.m (89 lb in).
3. Route the harness and secure the harness with the harness retainers.
4. Connect the electrical connector(s).
5. Install the mirror nut access plugs.
6. Reconnect the electrical/audio connector.
7. Install the door trim panel. Refer to «Door Trim Panel Replacement»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .

1. Remove the door trim panel. Refer to «Door Trim Panel Replacement»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
2. Disconnect the electrical connector to the mirror wire harness.
3. Remove the mirror face. Refer to «Outside Rearview Mirror Glass Replacement»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
4. Remove the screws from the mirror motor.
5. Pull the motor electrical harness through the mirror housing.
6. Remove the motor from the mirror housing.

1. Position the motor to the mirror housing.
2. Pull the motor electrical harness through the mirror housing to the inside door panel.
3. Install the screws to the mirror motor. Tighten: Tighten the mirror motor screws to 10 N.m (89 lb in).
4. Install the mirror face to the mirror housing. Refer to «Outside Rearview Mirror Glass Replacement»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
5. Connect the electrical connector to the mirror wire harness.
6. Inspect the operation of the mirror.
7. Install the door trim panel. Refer to «Door Trim Panel Replacement»(/cadillac/xlr/i-2003-2009/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .

Scheme 36

1. Push in on one edge of the mirror face, tilting the mirror support to allow finger access.
2. Grasp the face support firmly, and pull the support from the mirror body.
3. Disconnect the wire connectors from the support (heated mirror).
4. Remove the two jackscrews from the mirror face support. Bend the jackscrew over. Press down on the side of the jackscrew, popping the jackscrew from the mirror face support. Save the jackscrews for reinstallation to the mirror motor.

1. The jackscrew springs must be positioned down, compressing the fingers at the bottom of the jackscrews. Push on the jackscrews, to install into the mirror motor.
2. Rotate both jackscrews to position the ball flanges to be inline with the attaching hub. This will correctly position the parts to the mirror face support. (This is shown in the above graphic).
3. Connect the electrical connectors to the mirror face support (heated mirror).
4. Align the support to the mirror motor.
5. With the palm of your gloved hand, press firmly on the center of the mirror glass support until the support engages onto the motor.
6. Push the mirror face support onto the jackscrews. Right mirror. Rotate the mirror face support down and press firmly on the lower side engaging the mirror face support to the lower jackscrew. Left mirror. Rotate the mirror face support up, and press firmly on the upper side, engaging the mirror face support to the upper jackscrew. Rotate the mirror face support, and press firmly on the outer side, engaging the mirror face support to the outer jackscrew. The jackscrews will give a clicking noise when properly seated.

Power Windows System Components

1. Driver door module (DDM)
2. Passenger door module (PDM)
3. Driver door switch assembly (DDSA)
4. Passenger door power window switch
5. Class 2 serial data link
6. DOOR CONTROLS circuit breaker (30-amp)
7. ACCA/DRIV DR SW fuse (10-amp)

Power Windows Operation

The vehicle is equipped with power windows controlled by door modules. The passenger door window can be operated, either from a power window switch built into the driver door switch assembly (DDSA), or from a power window switch mounted locally on the passenger door. The driver door window can be operated only from the driver door power window switch built into the DDSA.

When the driver door module (DDM) receives a driver door window switch request from the DDSA, the DDM examines the request and checks for messages from other vehicle control modules prohibiting the window movement. If no prohibitive messages have been received, the DDM will apply power and ground to the driver door window motor to move the window as requested.

When the passenger door module (PDM) receives a window switch request from either the DDSA or the window switch mounted locally to it, the PDM will examine the request and check for messages from other vehicle control modules prohibiting the window movement. If no prohibitive messages have been received, the door module will apply power and ground to its associated window motor to move the window as requested.

Window Express Down Feature

Both windows are equipped with the Express Down feature. This feature allows a window to be fully opened by momentarily pressing the window switch to the second detente of the Down position. The passenger window can be expressed down from either the appropriate window switch built into the driver door switch assembly (DDSA) or from the window switch mounted to the passenger door. When either switch is operated to Express Down, both the Down contacts and the Express contacts of the switch being used are closed to ground and the signal is interpreted as an Express Down request. If the window is operated from the passenger door window switch, the passenger door module (PDM) interprets the signal and the window is lowered. If the passenger window is operated from the driver door, the DDSA interprets the signal and communicates via class 2 serial data with the PDM to request the Express Down command to lower the window.

If a door module loses power for any reason such as a vehicle battery disconnect, the power window must be reinitialized once power has been restored. For more detailed information concerning power window reinitialization refer to Power Window Reinitialization .

Normalization

Normalization allows the driver door module (DDM) or passenger door module (PDM) to detect the top position of the window and to calculate actual window position in relation to Zero-Position. The door control module will store this end position once it has been detected when the window has reached the full up position and the user has applied the up function of the switch continuously for a minimum of 0.5 second. Each time the glass stalls short before the Zero-position or stalls short above it, the actual stall position becomes the new Zero-position, if the stall time is at least 0.5 second. It is not possible to normalize the window if the door is open, because the glass stops on the index position. If the door is open and the normalization is lost due to battery disconnect, the actual position of the glass after power is switched ON again will become the Zero-position, and if the door module receives a door open status the glass shall index down.

Window Indexing

The window indexing feature is used to lower the driver and passenger power windows approximately 4 mm when the door is opened. This is necessary to allow the top edge of the window to clear the window weatherstrip. This feature will also raise the window to the fully seated position once the door is closed.

This feature is enabled in the down direction by an input from either the interior or exterior door handle switch. The appropriate door module will then drive the appropriate window motor to lower the window.

This feature is enabled in the up direction by the input from the appropriate door open switch when the door is closed. The appropriate door module will then drive the appropriate window motor to raise the window.

Power Door Latch System Components

The power door latch system contains the following components

1. Remote control door lock receiver (RCDLR)
2. Body control module (BCM)
3. Driver door module (DDM)
4. Passenger door module (PDM)
5. Driver exterior door handle switch
6. Driver interior door handle switch
7. Passenger exterior door handle switch
8. Passenger interior door handle switch
9. The ECM/TCM Fuse 11 15 Amp mini-fuse for the RCDLR
10. The BATT 3 Fuse 29 60 Amp mega-fuse for the BCM
11. The Door Controls 30 Amp circuit breaker for the DDM and PDM

Driver Power Door Latch Unlatch Operation

The remote control door lock receiver (RCDLR), driver door module (DDM) and body control module (BCM) control the output functions of the driver power door latch. These output functions allow the RCDLR and BCM to command the driver power door latch motor to Unlatch.

When the RCDLR receives an input from either the driver exterior door handle switch or driver interior door handle switch, it checks the Lock/Unlock status of the driver door. If the status of the driver door is Unlock, the RCDLR applies the ground for the driver power door latch.

At the same time that the RCDLR is receiving its input, the DDM is also receiving the same input. When the DDM receives its input from the door handle switch, it checks the window indexing status of the driver door. If the window is below the index point, it sends a serial data message to the BCM to apply voltage for the driver power door latch. If the window is above the index point, it will first index the window, then send a serial data message to the BCM to apply voltage for the driver power door latch. For a better description of window indexing, refer to Power Windows Description and Operation .

Passenger Power Door Latch Unlatch Operation

The remote control door lock receiver (RCDLR), passenger door module (PDM) and body control module (BCM) control the output functions of the passenger power door latch. These output functions allow the RCDLR and BCM to command the passenger power door latch motor to Unlatch.

When the RCDLR receives an input from either the passenger exterior door handle switch or passenger interior door handle switch, it checks the Lock/Unlock status of the passenger door. If the status of the passenger door is Unlock, the RCDLR applies the ground for the passenger power door latch.

At the same time that the RCDLR is receiving its input, the PDM is also receiving the same input. When the PDM receives its input from the door handle switch, it checks the window indexing status of the passenger door. If the window is below the index point, it sends a serial data message to the BCM to apply voltage for the passenger power door latch. If the window is above the index point, it will first index the window, then send a serial data message to the BCM to apply voltage for the passenger power door latch. For a better description of window indexing, refer to Power Windows Description and Operation .

Power Door Lock System Components

The power door lock system contains the following components

1. Remote control door lock receiver (RCDLR)
2. Driver door switch (DDS)
3. Passenger door module (PDM)
4. Driver door lock switch
5. Passenger door lock switch
6. The Door Controls 30 Amp circuit breaker for the PDM
7. The ACCA/Driv Dr Sw 10 Amp mini-fuse for the DDS

Driver Door Lock and Unlock Operation

The driver door lock switch lock and unlock signal circuits provide input to the DDS when the driver door lock switch is activated to the Lock or Unlock position. These inputs allow the DDS to detect a door lock or unlock request. The DDS provides power to the driver door lock switch. When the driver door lock switch is activated, ground is supplied by G201. When the DDS detects low voltage on a signal circuit, the DDS will send a message on the serial data line to the RCDLR to place the driver and passenger doors in lock or unlock status, disabling or enabling the power door latch.

Passenger Door Lock and Unlock Operation

The passenger door lock switch lock and unlock signal circuits provide input to the PDM when the passenger door lock switch is activated to the Lock or Unlock position. These inputs allow the PDM to detect a door lock or unlock request. The PDM provides power to the driver door lock switch. When the driver door lock switch is activated, ground is supplied by G202. When the PDM detects low voltage on a signal circuit, the PDM will send a message on the serial data line to the RCDLR to place the driver and passenger doors in lock or unlock status, disabling or enabling the power door latch.

Automatic Door Locks

The automatic door lock feature provides for the locking and unlocking of one or both of the doors automatically when shifting the transmission. When the vehicle doors are closed, ignition turned ON, and the transmission is shifted out of PARK, all doors will lock. When the vehicle is stopped and the transmission is shifted into PARK, one or both of the doors will unlock.

Operation of the automatic door lock system depends upon door status information gathered by the BCM, and examined by the remote control door lock receiver (RCDLR). The system will not operate properly if the RCDLR, which is the door lock master, detects that a vehicle door is open. Each door latch contains a door open switch. Each door open switch receives voltage from the BCM and are grounded independently. When a door is open, the switch closes, voltage flows through the switch, and the BCM interprets the flow of voltage as a door open input. The BCM sends this information over the Class 2 serial data circuit where it is detected by the RCDLR. If the RCDLR determines that one of the vehicle doors is open, automatic door locking will not be permitted.

Automatic door locking is programmed during the manufacturing process, but it can be custom programmed by the operator to fit individual preferences. For information concerning custom programming available and programming instructions, refer to the vehicles owners manual.

Power Door Lock Deadbolt Operation (Export)

Export vehicles may be equipped with the deadbolt feature, which includes a reversible deadbolt motor contained within each door latch assembly. Each deadbolt motor is wired to the driver door module (DDM) through 2 circuits; the deadbolt lock control circuit and the deadbolt unlock control circuit. To deadbolt a door, the body control module (BCM) locks the door by momentarily applying voltage to the door latch motor control circuit. The remote control door lock receiver (RCDLR) applies ground to the door latch enable control circuit to complete the circuit to the door latch motor. To complete the deadbolting, the DDM momentarily applies voltage to the deadbolt lock control circuit and ground to the deadbolt unlock control circuit. If the content theft feature is armed at the same time, the interior door lock switches will not operate the locks.

To undeadbolt the door, the DDM reverses the polarity, applying battery voltage to the deadbolt unlock control circuit, and ground to the deadbolt lock control circuit.

Door Ajar Indicator

The driver information center (DIC) located at the bottom of the instrument panel cluster (IPC), illuminates the LEFT DOOR AJAR or RIGHT DOOR AJAR indicator when the body control module (BCM) detects that one of the doors is open. The IPC receives a class 2 message from the BCM indicating the door ajar status. If this message is displayed and the vehicle speed is greater than 3 mph, a chime will sound.

Power Mirror System Components

1. Driver door module (DDM)
2. Passenger door module (PDM)
3. Driver door switch (DDS)
4. Driver door outside rearview mirror
5. Passenger door outside rearview mirror
6. The Door Controls 30 Amp circuit breaker for the PDM
7. The ACCA/Driv Dr Sw 10 Amp mini-fuse for the DDS

Power Mirror Operation

The power mirrors are controlled by the DDS, the DDM and the PDM. The DDS decodes mirror control switch activations and the door modules apply voltage and ground to the respective mirror motors to move the mirrors to the desired positions.

Power Mirror Switches

The DDS contains 2 built-in switches, the mirror select switch and the mirror position switch. The mirror select switch is used to select the mirror to be adjusted. The mirror position switch is used to move the mirror to the desired position. The mirror select switch and mirror position switch receive voltage and ground from the DDS. The DDS reports the activity of these 2 switches to the DDM and the PDM via the class 2 serial data circuit.

Mirror Motors

Each mirror has 2 reversible mirror motors for position adjustment. These are the vertical motor and the horizontal motor. Each mirror motor is wired to the associated door module through 2 motor control circuits. The door modules control the reversible motors by applying battery voltage and ground to the appropriate motor control circuits. The door module reverses the polarity of the voltage and ground it applies to the motor control circuits in order to move the motor in an opposite direction.

Memory Mirrors

The memory mirrors are controlled by the mirror position sensors, the DDS, the DDM and the PDM. The DDS is used in decoding memory switch activations and the mirror position sensors provide the door modules with mirror position information. The door modules store the mirror position information and supply the voltage and ground necessary to run the mirror motors.

For memory mirror operations, each outside rearview mirror has 4 additional circuits and contains a vertical position sensor and a horizontal position sensor. The position sensors are attached to the corresponding position motor and are an integral part of each mirror motor. The position sensors, which are potentiometer type sensors, provide constant information, in the form of feedback voltage, to the associated door module, indicating the vertical and horizontal position of the mirror. Each door module supplies 5-volt reference voltage, through a 5-volt reference circuit, and ground through a mirror sensor low reference circuit, to the position sensors.

Power Folding Mirrors

This feature allows the operator to simultaneously retract both mirrors to a fully folded position. The DDS has an additional power folding mirrors switch built in and, each mirror contains an additional power folding mirror motor. When the switch is activated to fold the mirrors, the DDS interprets the signal input and sends the command to the DDM and the PDM. The DDM and the PDM then each apply battery voltage and ground to the appropriate circuits of their respective power folding motors in order to retract both mirrors. When the switch is activated to unfold the mirrors, the door modules reverse the polarity of the voltage and ground applied to the motors in order to move both mirrors to the fully extended position.

Heated Mirrors

The mirrors heat during the defrost/defog cycles for the rear window. The heated mirrors are wired to the DDM and the PDM. The DDM and the PDM receive a class 2 message from the instrument panel cluster (IPC) via the rear integration module (RIM) commanding the heated mirrors ON. The DDM and PDM first examine information from the dash integration module (DIM) to determine if vehicle conditions are correct for the heated mirrors function to be permitted. If conditions are correct, the DDM then applies battery voltage and ground to the driver side mirror heater element, and the PDM applies battery voltage and ground to the passenger side mirror heater element.

Mirrors - Outside Automatic Day/Night Feature

The automatic day/night feature of the driver outside rearview mirror is controlled by the inside rearview mirror. The inside rearview mirror supplies a signal and a low reference to the driver outside rearview mirror. The voltage on the signal circuit of the driver outside rearview mirror varies between 0.5 to 1.5 volts depending on light conditions present at the inside rearview mirror. At night, with the automatic day-night feature enabled, the driver outside rearview mirror will automatically darken with the inside rearview mirror to reduce the glare from the headlamps from behind. The voltage on the signal circuit of the driver outside rearview mirror will be near 1.5 volts. In the daytime, the mirrors are in a normal state. The voltage on the signal circuit of the driver outside rearview mirror may be less than or near 0.5 volts. Refer to Automatic Day-Night Mirror Description and Operation in Stationary Windows for further description and operation of the inside rearview mirror.

See also:
• Diagnostic System Check - Vehicle
• Testing for Intermittent Conditions and Poor Connections
• Connector Repairs
• Control Module References
• Symptoms - Engine Electrical
• Circuit Testing
• Wiring Repairs
• Automatic Day-Night Mirror Description and Operation
• Checking Aftermarket Accessories
• Door Control Module Programming and Setup
• Relay Replacement (Within an Electrical Center)
• Vehicle Personalization
• Fastener Notice
• Battery Disconnect Caution
• Carpet Retainer Replacement
• Express Down Feature Caution
• DTC B1011
• Power Window Inoperative - Driver Door
• Power Window Inoperative - Passenger Door
• Door Ajar Indicator Malfunction
• Power Door Latch Inoperative - Driver Door
• Power Door Latch Inoperative - Passenger Door
• Door Lock Indicator Malfunction
• Power Door Locks Inoperative - One Door or Switch
• Power Mirrors Inoperative
• Power Mirror Folding Inoperative
• Outside Mirrors Automatic Day-Night Feature Inoperative
• Power Mirror - Mirror Tilt Inoperative in Reverse
• Heated Mirrors Inoperative
• Power Window Reinitialization
• Symptoms - Doors
• Fastener Tightening Specifications
• Door Window Tip-In Adjustment
• Door Window Minor Height Adjustment
• Door Window Major Height Adjustment
• Door Window Adjustment
