Engine Controls and Fuel - 4.6L - Introduction: Diagnosis Cadillac STS I facelift

Diagnostic Starting Point - Engine Controls

Begin the system diagnosis with Diagnostic System Check - Vehicle . The Diagnostic System Check - Vehicle will provide the following information

1. The identification of the control modules which command the system
2. The ability of the control modules to communicate through the serial data circuit
3. The identification of any stored diagnostic trouble codes (DTCs) and the codes' statuses

The use of the Diagnostic System Check - Vehicle will identify the correct procedure for diagnosing the system and where the procedure is located.

DIAGNOSTIC CODE INDEX

DIAGNOSTIC CODE INDEX

Conditions for Running the Throttle Learn Procedure

With Scan Tool - Reset

1. DTCs P0101, P0102, P0103, P0107, P0108, P0111, P0112, P0113, P0506, and P0507 are not set.
2. Ignition ON, engine OFF.
3. The vehicle speed sensor (VSS) is 0 km/h (0 mph).

Without Scan Tool - Learn

1. DTCs P0101, P0102, P0103, P0107, P0108, P0111, P0112, P0113, P0506, and P0507 are not set.
2. The engine speed is between 450-4,000 RPM.
3. The manifold absolute pressure (MAP) is greater than 5 kPa.
4. The mass air flow (MAF) is greater than 2 g/s.
5. The ignition 1 voltage is greater than 10 volts.

Throttle Body Inspection and Cleaning

1. Remove the fuel injector sight shield. Refer to «Fuel Injector Sight Shield Replacement»(ref-338203-S10562039982009081700000) .
2. Remove the air cleaner outlet duct. Refer to «Air Cleaner Outlet Duct Replacement»(ref-338170-S38900360272009081700000) .
3. Inspect the throttle body bore and the throttle body plate for deposits. You will need to open the throttle plate in order to inspect all surfaces.
4. Clean the throttle body bore and the throttle plate using a clean shop towel with GM top engine cleaner, P/N 1052626 (Canadian P/N 993026) or AC Delco Carburetor Tune-up Conditioner, P/N X66P, or equivalent product.
5. Install the air cleaner outlet duct. Refer to «Air Cleaner Outlet Duct Replacement»(ref-338170-S38900360272009081700000) .
6. Install the fuel injector sight shield. Refer to «Fuel Injector Sight Shield Replacement»(ref-338203-S10562039982009081700000) .
7. Perform the Throttle Body Learn procedure. Refer to «Throttle Learn»(ref-338172-S31876752452009081700000) .

Inspection Procedure

1. Turn OFF the ignition.
2. Remove the EVAP canister purge valve. Refer to «Evaporative Emission Canister Purge Solenoid Valve Replacement»(ref-338170-S41193668772009081700000) .
3. Lightly tap the EVAP canister purge valve on a hard surface.
4. Inspect for carbon particles exiting either of the vacuum ports. If no carbon particles were detected, but a blockage was detected during a diagnostic procedure, install the original EVAP canister purge valve. Continue with the cleaning procedure. If carbon particles are found during the inspection procedure, continue with the cleaning procedure. If a diagnostic procedure directed you to replace the EVAP canister purge valve and no carbon particles were detected, replace the EVAP canister purge valve. Return to the published service procedure.

Emissions Diagnosis For State I/M Programs

This OBD II equipped vehicle is designed to diagnose any conditions that could lead to excessive levels of the following emissions

1. Hydrocarbons (HC)
2. Carbon monoxide (CO)
3. Oxides of nitrogen (NOx)
4. Evaporative emission (EVAP) system losses

Should this vehicles on-board diagnostic system (ECM) detect a condition that could result in excessive emissions, the ECM turns ON the malfunction indicator lamp (MIL) and stores a DTC that is associated with the condition.

Underhood Inspection

Note. This inspection is very important and must be done carefully and thoroughly.

Perform a careful underhood inspection when performing any diagnostic procedure or diagnosing the cause of an emission test failure. This can often lead to repairing a condition without further steps. Use the following guidelines when performing an inspection

1. Inspect all of the vacuum hoses for correct routing, pinches, cuts, or disconnects.
2. Inspect any hoses that are difficult to see.
3. Inspect all of the wires in the engine compartment for the following conditions: Burned or chafed spots Pinched wires Contact with sharp edges Contact with hot exhaust manifolds

Scheme 71

The engine control module (ECM) is the control center for the throttle actuator control (TAC) system. The ECM determines the driver's intent based on input form the accelerator pedal position sensors, then calculates the appropriate throttle response based on the throttle position sensors. The ECM achieves throttle positioning by providing a pulse width modulated voltage to the throttle actuator motor. The throttle blade is spring loaded in both directions, and the default position is slightly open.

Large Leak Test

This tests for large leaks and restrictions to the purge path in the evaporative emission (EVAP) system. When the enabling criteria has been met, the control module commands the EVAP vent solenoid valve ON and the EVAP purge solenoid valve ON, allowing vacuum into the EVAP system. The control module monitors the fuel tank pressure (FTP) sensor voltage to verify that the system is able to reach a predetermined level of vacuum within a set amount of time.

Small Leak Test

The engine off natural vacuum (EONV) diagnostic is the small-leak detection diagnostic for the evaporative emission (EVAP) system. While previous leak detection methods were performed with the engine running, the EONV diagnostic monitors the EVAP system pressure or vacuum with the ignition OFF. Because of this, it may be normal for the control module to remain active for up to 40 minutes after the ignition is turned OFF. This is important to remember when performing a parasitic draw test on vehicles equipped with EONV.

The EONV utilizes the temperature changes in the fuel tank immediately following a drive cycle to use the naturally occurring vacuum or pressure in the fuel tank. When the vehicle is driven, the temperature rises in the tank. After the vehicle is parked, the temperature in the tank continues to rise for a period of time, then starts to drop. The EONV diagnostic relies on this temperature change and the corresponding pressure change in a sealed system, to determine if an EVAP system leak is present.

The EONV diagnostic is designed to detect leaks as small as 0.51 mm (0.020 in). The diagnostic can determine if a small leak is present based on vacuum or pressure readings in the EVAP system. When the system is sealed, a finite amount of pressure or vacuum will be observed. When a 0.51 mm (0.020 in) leak is present, often little or no pressure or vacuum is observed. If the test reports a failing value, DTC P0442 will set.

Canister Vent Restriction Test

If the evaporative emission (EVAP) vent system is restricted, fuel vapors will not be properly purged from the EVAP canister. The control module tests this by commanding the EVAP purge solenoid valve ON, commanding the EVAP vent solenoid valve OFF, and monitoring the fuel tank pressure (FTP) sensor for an increase in vacuum. If the vacuum increases more than a calibrated value, DTC P0446 will set.

Purge Solenoid Valve Leak Test

If the evaporative emission (EVAP) purge solenoid valve does not seal properly fuel vapors could enter the engine at an undesired time, causing driveability concerns. The control module tests for this by commanding the EVAP purge solenoid valve OFF and the vent solenoid valve ON, sealing the system, and monitors the fuel tank pressure (FTP) for an increase in vacuum. If the control module detects that the EVAP system vacuum increases above a calibrated value, DTC P0496 will set.
