Special Tools
CH-48027 Digital Pressure Gage. See Special Tools .
| WARNING | Refer to Gasoline/Gasoline Vapors Warning . |
| WARNING | Remove the fuel tank cap and relieve the fuel system pressure before servicing the fuel system in order to reduce the risk of personal injury. After you relieve the fuel system pressure, a small amount of fuel may be released when servicing the fuel lines, the fuel injection pump, or the connections. In order to reduce the risk of personal injury, cover the fuel system components with a shop towel before disconnection. This will catch any fuel that may leak out. Place the towel in an approved container when the disconnection is complete. |
- If the fuel system requires repair, prevent fuel spillage by removing the fuel pump fuse. Refer to «Electrical Center Identification Views»(ref-338181-S33900845042009081700000) .
- Remove the engine cover, if required.
- Loosen the fuel fill cap in order to relieve the fuel tank vapor pressure.
- Remove the fuel rail service port cap.
- Wrap a shop towel around the fuel rail service port.
- Connect the CH-48027-3 (4) to the fuel rail service port.
- Connect the CH-48027-2 (2) to the CH-48027-3 (4).
- Place the hose on the CH-48027-2 (2) into an approved gasoline container.
- Open the valve on the CH-48027-2 (2) in order to bleed any fuel from the fuel rail.
- Close the valve on the CH-48027-2 (2).
- Remove the hose on the CH-48027-2 (2) from the approved gasoline container.
- Disconnect the CH-48027-2 (2) from the CH-48027-3 (4).
- Disconnect the CH-48027-3 (4) from the fuel rail service port.
- Remove the shop towel from around the fuel rail service port, and place in an approved gasoline container.
- Install the fuel rail service port cap.
- Install the engine cover, if required.
- Tighten the fuel fill cap.
CH-48027 Digital Pressure Gage. See Special Tools .
- J 37088-A Fuel Line Disconnect Tool Set. See «Special Tools»(ref-338169-S23212902312009081700000) .
- J 44581 Fuel Line Disconnect Tool. See «Special Tools»(ref-338169-S23212902312009081700000) .
- J 36850 Transjel Lubricant
- J 45004 Fuel Drain Hose. See «Special Tools»(ref-338169-S23212902312009081700000) .
J 45722 Fuel Sender Lock Ring Wrench
J 45747 Fuel Sender Unit Wrench. See Special Tools .
EN-48896 HP Fuel Pump Installation Alignment Gage. See Special Tools .
- EN-47909 Injector Bore and Sleeve Cleaning Kit. See «Special Tools»(ref-338169-S23212902312009081700000) .
- EN-48266 Injector Seal Installer and Sizer. See «Special Tools»(ref-338169-S23212902312009081700000) .
- J 2619-01 Slide Hammer
- J-37281-A Injector Remover. See «Special Tools»(ref-338169-S23212902312009081700000) .
- J 39313 Spark Plug Port Adapter
J 41413 EVAP Pressure and Purge Station
Illustration Tool Number/Description CH 48027 Digital Pressure Gage CH 48096 EVAP Service Access Port Tool EL 39021-460 Fuel Injector Test Adapter EN 47909 Injector Bore and Sleeve Cleaning Kit EN 48266 Injector Seal Installer/Sizer EN 48896 HP Fuel Pump Installation Alignment Gage GE 41415-50 Fuel Tank Cap Adapter J 2619-01 Slide Hammer J 26792 HEI Spark Tester J 34730-405 Injector Test Lamp J 35616-A/B-8637 Connector Test Adapter Kit J 35616-200 Test Light - Probe Kit J 37088-A Fuel Line Disconnect Tool Set J 37281-A Injector Remover J 37287 Fuel Line Shut-Off Adapters J 38522 Variable Signal Generator J 39021 Fuel Injector Coil and Balance Test J 39021-210 Injector Selector Switch Box J 41413-200 Evaporative Emission System Tester (EEST) J 41413-300 EVAP Cap and Plug Kit J 41413-SPT High Intensity White Light J 42960-02 Fuel Flapper Door Holder J 43244 Relay Puller Pliers J 44175 Fuel Composition Tester J 44581 Fuel Line Disconnect Tool J 44602 Injector Test Adapter J 45004 Fuel Tank Drain Hose J 45747 Fuel Sender Lock Ring Wrench
