Secondary and Configurable Customer Controls: Other Cadillac STS I facelift

Memory Modules 1 illustration ~193 words

Circuit/System Verification

Ignition ON, observe the scan tool steering wheel controls counts while pressing the steering wheel control switch. The reading should change with each switch pressed and display counts when inactive.

Repair Procedures

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

  1. «Steering Wheel Control Switch Assembly Replacement»(ref-338161-S09046035982009081700000)
  2. «Control Module References»(ref-338152-S12253781062009081700000) for IPM replacement, setup, and programming
IMPORTANTPerform the Diagnostic System Check - Vehicle before using the Symptom Tables in order to verify that all of the following conditions are true: There are no DTCs set. The control modules can communicate via the serial data link. Review the system operation in order to familiarize yourself with the system functions. Refer to Steering Wheel Controls Description and Operation .

Intermittent

Faulty electrical connections or wiring may be the cause of intermittent conditions. Refer to Testing for Intermittent Conditions and Poor Connections .

Reference Information

Schematic Reference

Steering Wheel Secondary/Configurable Control Schematics

Connector End View Reference

Component Connector End Views

Description and Operation

Steering Wheel Controls Description and Operation

Electrical Information Reference

  1. «Circuit Testing»(ref-338151-S30248766082009081700000)
  2. «Connector Repairs»(ref-338151-S41110648952009081700000)
  3. «Testing for Intermittent Conditions and Poor Connections»(ref-338151-S41477264612009081700000)
  4. «Wiring Repairs»(ref-338151-S09708660722009081700000)

Scan Tool Reference

Control Module References

Ignition ON, observe the scan tool steering wheel controls counts while pressing the steering wheel control switch. The reading should change with each switch pressed and display counts when inactive.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

  1. «Steering Wheel Control Switch Assembly Replacement»(ref-338161-S09046035982009081700000)
  2. «Control Module References»(ref-338152-S12253781062009081700000) for IPM replacement, setup, and programming

Scheme 2

Scheme 2: Steering Wheel Control Switch Assembly Replacement
Scheme 2: Steering Wheel Control Switch Assembly Replacement
CalloutComponent Name
WARNING: Refer to SIR Warning . Preliminary Procedure: Remove the inflatable restraint steering wheel module. Refer to Inflatable Restraint Steering Wheel Module Replacement .
1Steering Wheel Trim Cover Bolt (Qty: 4) CAUTION: Refer to Fastener Caution . Tighten: 2 N.m (18 lb in)
2Steering Wheel Trim Cover (Qty: 2) Tip: Remove switch and bezel straight out from steering wheel assembly, removing at an angle can cause damage to the foam behind the bezel.
3Steering Wheel Control Switch Assembly (Qty: 2) Procedure Radio control switch assembly is shown. Cruise control switch assembly is similar. Disconnect the electrical connectors. Make sure the steering wheel control switches are properly seated to the steering wheel trim cover during installation.
WARNING
Refer to SIR Warning .
CAUTION
Refer to Fastener Caution .
