Engine Cooling System: Component Locations Cadillac STS I facelift

Cooling System (Mechanical) 11 illustrations ~416 words

Special Tools

  1. J 24460-01 Cooling System Pressure Tester. See «Special Tools»(ref-338194-S08548216942009081700000) .
  2. J 42401 Radiator Cap/Surge Tank Test Adapter. See «Special Tools»(ref-338194-S08548216942009081700000) .
  1. J 24460-01 Cooling System Pressure Tester. See «Special Tools»(ref-338194-S08548216942009081700000) .
  2. J 46143 Cooling System Adapter. See «Special Tools»(ref-338194-S08548216942009081700000) .
  1. J 24460-01 Cooling System Pressure Tester. See «Special Tools»(ref-338194-S08548216942009081700000) .
  2. J 42401 Radiator Cap/Surge Tank Test Adapter. See «Special Tools»(ref-338194-S08548216942009081700000) .
  1. J 26568 Coolant and Battery Fluid Tester. See «Special Tools»(ref-338194-S08548216942009081700000) .
  2. J 42401 Radiator Cap and Surge Tank Test Adapter. See «Special Tools»(ref-338194-S08548216942009081700000) .
  3. GE-47716 Vac N Fill Coolant Refill Tool. See «Special Tools»(ref-338194-S08548216942009081700000) .

J 26568 Coolant and Battery Fluid Tester. See Special Tools .

J 26568 Coolant and Battery Tester. See Special Tools .

  1. J 26568 Coolant and Battery Fluid Tester. See «Special Tools»(ref-338194-S08548216942009081700000) .
  2. J 46143 Cooling System Adapter. See «Special Tools»(ref-338194-S08548216942009081700000) .
  3. GE-47716 Vac N Fill Coolant Refill Tool. See «Special Tools»(ref-338194-S08548216942009081700000) .

J 38185 Hose Clamp Pliers. See Special Tools .

J 38185 Hose Clamp Pliers. See Special Tools .

J 38185 Hose Clamp Pliers. See Special Tools .

J 38185 Hose Clamp Pliers. See Special Tools .

J 38185: Hose Clamp Pliers

J 38185: Hose Clamp Pliers

J 41240 Fan Clutch Wrench. See Special Tools .

J 41240 Fan Clutch Remove and Installer. See Special Tools .

J 28410 Gasket Remover. See Special Tools .

EN 46104 Water Pump Pulley Holding Tool. See Special Tools .

J 38185 Hose Clamp Pliers. See Special Tools .

J 38185 Hose Clamp Pliers. See Special Tools .

J 38185 Hose Clamp Pliers. See Special Tools .

  1. J 38185 Hose Clamp Pliers. See «Special Tools»(ref-338194-S08548216942009081700000) .
  2. J 38778 Door Trim Pad Clip Remover. See «Special Tools»(ref-338194-S08548216942009081700000) .

J 38185 Hose Clamp Pliers. See Special Tools .

J 38185: Hose Clamp Pliers

J 38185: Hose Clamp Pliers

J 38185 Hose Clamp Pliers. See Special Tools .

Illustration Tool Number/Description EN 46104 Water Pump Pulley Holding Tool GE 47716 Vac N Fill Coolant Refill Tool J 23688 Coolant and Battery Fluid Tester J 24460-01 Cooling System Pressure Tester J 24731 Tempil Stick J 26568 Coolant and Battery Fluid Tester J 28410 Gasket Remover (Aluminum Components) J 38185 Hose Clamp Pliers J 38778 Door Trim Pad Clip Remover J 41240 Fan Clutch Remover and Installer J 42401 Radiator Cap/Surge Tank Test Adapter J 46143 Cooling System Adapter

Scheme 12

Scheme 12: Special Tools
Scheme 12: Special Tools

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16

Scheme 17
