Fastener Tightening Specifications
| Application | Specification | |
|---|---|---|
| Metric | English | |
| Front Bumper Fascia Reinforcement Screw | 6 N.m | 53 lb in |
| Front Bumper Impact Bar Nut | 25 N.m | 18 lb ft |
| Rear Bumper Energy Absorber Bolt | 25 N.m | 18 lb ft |
| Rear Bumper Energy Absorber Nut | 6 N.m | 53 lb in |
| Rear Bumper Fascia Bracket Bolt | 3 N.m | 27 lb in |
| Rear Bumper Fascia Nuts | 6 N.m | 53 lb in |
| Rear Bumper Fascia Screw | 3 N.m | 27 lb in |
| Rear Bumper Impact Bar Bolt | 25 N.m | 18 lb ft |
Fastener Tightening Specifications
Inspection After Collision
If a severe collision dislodges the bumper from the original position, you may need to replace the following components
- The bumper fascia
- The bumper energy absorber
- The bumper impact bar
Scheme 6
| Callout | Component Name |
|---|---|
| NOTE: Refer to Fastener Notice in Cautions and Notices. Fastener Tightening Specifications: Refer to Fastener Tightening Specifications . | |
| Front Bumper Fascia Extension Replacement Preliminary Procedures Lift and support the vehicle. Refer to Lifting and Jacking the Vehicle in General Information. Remove the air deflector. Refer to Air Deflector Replacement - Front in Body Front End. | |
| 1 | Retainer, Front Compartment Sight Shield (Qty: 2) |
| 2 | Shield Assembly, Front Compartment Front Sight |
| 3 | Retainer, Front Compartment Sight Shield (Qty: 2) |
| 4 | Shield Assembly, Right Front Compartment Sight |
| 5 | Retainer, Front Compartment Sight Shield (Qty: 2) |
| 6 | Shield Assembly, Left Front Compartment Sight |
| 7 | Retainer, Front Bumper Fascia Extension (Qty: 22) |
| 8 | Extension, Front Bumper Fascia (Qty: 2) |
| Front Bumper Fascia Assembly Replacement Preliminary Procedures Lift and support the vehicle. Refer to Lifting and Jacking the Vehicle in General Information. Remove the air deflector. Refer to Air Deflector Replacement - Front in Body Front End. | |
| 1 | Retainer, Front Compartment Sight Shield (Qty: 2) |
| 2 | Shield Assembly, Front Compartment Sight |
| 3 | Retainer, Front Compartment Sight Shield (Qty: 2) |
| 4 | Shield Assembly, Right Front Compartment Sight |
| 5 | Retainer, Front Compartment Sight Shield (Qty: 2) |
| 6 | Shield Assembly, Left Front Compartment Sight |
| 7 | Retainer, Front Bumper Fascia Extension (Qty: 22) |
| 8 | Extension, Front Bumper Fascia (Qty: 2) |
| 9 | Connector, Front Side Marker Light Tip: Disconnect the front side marker and fog light connectors. |
| 10 | Nut, Front Bumper Fascia Reinforcement (Qty: 2) Tighten: 9 N.m (80 lb in) |
| 11 | Screw, Front Bumper Fascia Reinforcement (Qty: 2) Tighten: 9 N.m (80 lb in) |
| 12 | Fascia Assembly, Front Bumper Tip: Remove the fascia to tie bar push in retainers (Qty: 4) Disconnect the headlamp washer hose assembly, if equipped. |
| Front Bumper Fascia Reinforcement Replacement Preliminary Procedures Lift and support the vehicle. Refer to Lifting and Jacking the Vehicle in General Information. Remove the air deflector. Refer to Air Deflector Replacement - Front in Body Front End. | |
| 1 | Retainer, Radiator Support Sight Shield (Qty: 6) |
| 2 | Shield Assembly, Radiator Support Sight |
| 3 | Retainer, Front Compartment Sight Shield (Qty: 2) |
| 4 | Shield Assembly, Right Front Compartment Sight |
| 5 | Retainer, Front Compartment Sight Shield (Qty: 2) |
| 6 | Shield Assembly, Left Front Compartment Sight |
| 7 | Retainer, Front Bumper Fascia Extension (Qty: 22) |
| 8 | Extension, Front Bumper Fascia (Qty: 2) |
| 9 | Connector, Front Side Marker Light Tip: Remove and replace the front side marker and fog light connectors. |
| 10 | Nut, Front Bumper Fascia Reinforcement (Qty: 2) Tighten: 9 N.m (80 lb in) |
| 11 | Screw, Front Bumper Fascia Reinforcement (Qty: 2) Tighten: 9 N.m (80 lb in) |
| 12 | Fascia Assembly, Front Bumper Tip: Remove the fascia to tie bar push in retainers (Qty: 4) Disconnect the headlamp washer hose assembly, if equipped. |
| 13 | Retainer, Front Bumper Fascia Reinforcement (Qty: 2) Tip: Cut the retainer with diagonal cutters to remove, and install using a new retainer. |
| 14 | Reinforcement, Front Bumper Fascia (Qty: 2) |
| Front Bumper Impact Bar Assembly Replacement Preliminary Procedures Lift and support the vehicle. Refer to Lifting and Jacking the Vehicle in General Information. Remove the air deflector. Refer to Air Deflector Replacement - Front in Body Front End. | |
| 1 | Retainer, Radiator Support Sight Shield (Qty: 6) |
| 2 | Shield Assembly, Radiator Support Sight |
| 3 | Retainer, Front Compartment Sight Shield (Qty: 2) |
| 4 | Shield Assembly, Right Front Compartment Sight |
| 5 | Retainer, Front Compartment Sight Shield (Qty: 2) |
| 6 | Shield Assembly, Left Front Compartment Sight |
| 7 | Retainer, Front Bumper Fascia Extension (Qty: 22) |
| 8 | Extension, Front Bumper Fascia (Qty: 2) |
| 9 | Connector, Front Side Marker Light Tip: Remove and replace the front side marker and fog light connectors. |
| 10 | Nut, Front Bumper Fascia Reinforcement (Qty: 2) Tighten: 9 N.m (80 lb in) |
| 11 | Screw, Front Bumper Fascia Reinforcement (Qty: 2) Tighten: 9 N.m (80 lb in) |
| 12 | Fascia Assembly, Front Bumper Tip: Remove the fascia to tie bar push in retainers (Qty: 4) Disconnect the headlamp washer hose assembly, if equipped. |
| 15 | Nut, Front Bumper Impact Bar (Qty: 8) Tighten: 25 N.m (18 lb ft) |
| 16 | Bar Assembly, Front Bumper Impact |
| Front Bumper Fascia Lower Deflector Replacement | |
| 17 | Retainer, Front Bumper Fascia Lower Deflector (Qty: 6) |
| 18 | Deflector, Front Bumper Fascia Lower |
| NOTE |
|---|
| Refer to Fastener Notice in Cautions and Notices. |
Fascia, Extension, Reinforcement, Impact Bar Replacement - Front Bumper
Scheme 7
| Callout | Component Name |
|---|---|
| NOTE: Refer to Fastener Notice in Cautions and Notices. Fastener Tightening Specifications: Refer to Fastener Tightening Specifications . | |
| Rear Bumper Fascia Replacement Preliminary Procedure Lift and support the vehicle. Refer to Lifting and Jacking the Vehicle in General Information. Remove the rear wheelhouse liner. Refer to Wheelhouse Liner Panel Replacement - Rear in Body Rear End. | |
| 1 | Screw, Rear Bumper Fascia Tip: The screw is located inside of the wheel opening. Tighten: 3 N.m (27 lb in) |
| 2 | Plate Assembly, Rear Compartment Sill Trim |
| 3 | Nuts, Rear Bumper Fascia (Qty: 4) Tighten: 6 N.m (53 lb in) |
| 4 | Retainer, Rear Bumper Fascia (Qty: 3) Tip: Cut the old retainer with diagonal cutters to remove, and install using a new retainer. |
| 5 | Fascia Assembly, Rear Bumper Tighten: 6 N.m (53 lb in) |
| Rear Bumper Impact Bar Assembly Replacement Preliminary Procedure Lift and support the vehicle. Refer to Lifting and Jacking the Vehicle in General Information. Remove the rear wheelhouse liner. Refer to Wheelhouse Liner Panel Replacement - Rear in Body Rear End. | |
| 1 | Screw, Rear Bumper Fascia Tip: The screw is located inside of the wheel opening. Tighten: 3 N.m (27 lb in) |
| 2 | Plate Assembly, Rear Compartment Sill Trim |
| 3 | Nuts, Rear Bumper Fascia (Qty: 4) Tighten: 6 N.m (53 lb in) |
| 4 | Retainer, Rear Bumper Fascia (Qty: 3) Tip: Cut the old retainer with diagonal cutters to remove, and install using a new retainer. |
| 5 | Fascia Assembly, Rear Bumper Tighten: 6 N.m (53 lb in) |
| 6 | Bolts, Rear Bumper Impact Bar (Qty: 8) Tighten: 25 N.m (18 lb ft) |
| 7 | Bar Assembly, Rear Bumper Impact |
| Rear Bumper Energy Absorber Assembly Replacement Preliminary Procedure Lift and support the vehicle. Refer to Lifting and Jacking the Vehicle in General Information. Remove the rear wheelhouse liner. Refer to Wheelhouse Liner Panel Replacement - Rear in Body Rear End. | |
| 1 | Screw, Rear Bumper Fascia Tip: The screw is located inside of the wheel opening. Tighten: 3 N.m (27 lb in) |
| 2 | Plate Assembly, Rear Compartment Sill Trim |
| 3 | Nuts, Rear Bumper Fascia (Qty: 4) Tighten: 6 N.m (53 lb in) |
| 4 | Retainer, Rear Bumper Fascia (Qty: 3) Tip: Cut the old retainer with diagonal cutters to remove, and install using a new retainer. |
| 5 | Fascia Assembly, Rear Bumper Tighten: 6 N.m (53 lb in) |
| 6 | Bolts, Rear Bumper Impact Bar (Qty: 8) Tighten: 25 N.m (18 lb ft) |
| 7 | Bar Assembly, Rear Bumper Impact |
| 8 | Bolt, Rear Bumper Energy Absorber (Qty: 2) Tighten: 25 N.m (18 lb ft) |
| 9 | Nut, Rear Bumper Energy Absorber (Qty: 4) Tighten: 25 N.m (18 lb ft) |
| 10 | Absorber Assembly, Rear Bumper Energy |
| Rear Bumper Fascia Bracket Replacement Preliminary Procedure Lift and support the vehicle. Refer to Lifting and Jacking the Vehicle in General Information. Remove the rear wheelhouse liner. Refer to Wheelhouse Liner Panel Replacement - Rear in Body Rear End. | |
| 1 | Screw, Rear Bumper Fascia Tip: The screw is located inside of the wheel opening. Tighten: 3 N.m (27 lb in) |
| 2 | Plate Assembly, Rear Compartment Sill Trim |
| 3 | Nuts, Rear Bumper Fascia (Qty: 4) Tighten: 6 N.m (53 lb in) |
| 4 | Retainer, Rear Bumper Fascia (Qty: 3) Tip: Cut the old retainer with diagonal cutters to remove, and install using a new retainer. |
| 5 | Fascia Assembly, Rear Bumper Tighten: 6 N.m (53 lb in) |
| 11 | Bolt, Rear Bumper Fascia Bracket (Qty: 10) Tighten: 3 N.m (27 lb in) |
| 12 | Bracket, Rear Bumper Fascia (Qty: 2) |
| Rear Bumper Fascia Insert Replacement | |
| 13 | Retainer, Rear Bumper Fascia Insert (Qty: 2) |
| 14 | Insert, Rear Bumper Fascia |
| Rear Bumper Fascia Energy Absorber Replacement Preliminary Procedure Lift and support the vehicle. Refer to Lifting and Jacking the Vehicle in General Information. Remove the rear wheelhouse liner. Refer to Wheelhouse Liner Panel Replacement - Rear in Body Rear End. | |
| 1 | Screw, Rear Bumper Fascia Tighten: 3 N.m (27 lb in) |
| 2 | Plate Assembly, Rear Compartment Sill Trim |
| 3 | Nuts, Rear Bumper Fascia (Qty: 4) Tighten: 6 N.m (53 lb in) |
| 4 | Retainer, Rear Bumper Fascia (Qty: 3) Tip: Cut the old retainer with diagonal cutters to remove, and install using a new retainer. |
| 5 | Fascia Assembly, Rear Bumper Tighten: 6 N.m (53 lb in) |
| 15 | Absorber, Rear Bumper Fascia Energy |
| NOTE |
|---|
| Refer to Fastener Notice in Cautions and Notices. |
Fascia, Bracket, Bar, Absorber Replacement - Rear Bumper
Scheme 8
| Callout | Component Name |
|---|---|
| Fastener Tightening Specifications: Refer to Fastener Tightening Specifications . | |
| Radiator Grille Assembly Replacement Preliminary Procedures Remove the front compartment sight shields. Refer to Sight Shields, Hood Adjuster, Hood Bumper, Hood Latch Replacement in Body Front End. Remove the fascia to tie bar push in retainers (Qty: 4) and pull the top of the front fascia out far enough to gain access to the fascia grille retainers. | |
| 1 | Retainer, Radiator Grille (Qty: 4) Tip: There are two push in retainers on each side of the grille. |
| 2 | Grille Assembly, Radiator |
| 3 | Insert, Radiator Grille |
| Radiator Lower Grille Assembly Replacement Preliminary Procedure: Remove the lower air deflector assembly. Refer to Air Deflector Replacement - Front in Body Front End. | |
| 4 | Filler, Radiator Grille Opening |
| 5 | Bezel, Radiator Grille Opening |
| 6 | Screen Assembly, Radiator Grille |
Fascia Grille Replacement
Bumper and Fascia Description
General Motors passenger vehicle bumpers are designed to withstand a collision into a fixed barrier at 8 km/h (5 mph). After absorbing the energy of the collision, the bumper energy absorbers rebound to 80-90 percent of their original position. The bumper energy absorbing capability of the front and the rear bumper systems are achieved through one of the following components in each bumper
- A honeycomb type energy absorbing structure
- A foam type energy absorbing structure
- An impact bar bracket energy absorbing structure
The front and the rear bumper fascias are made of urethane. Urethane withstands minor impact and returns to the original shape.
Refer to General Plastic Repair Instructions in Plastic Panel Information and Repair for repair or refinishing information on the bumper fascia.
