Wiring Systems & Electrical Power Management (Connector End Views) Cadillac STS I

Ignition Mode Switch

Ignition Mode Switch Connector End Connector Part Information OEM: 12064769 Service: 12101762 10-Way F Metri-Pack 150 Series (NA) Pin Wire Color Circuit No. Function A L-BU/WH 5725 Ignition Mode Switch Mode Voltage Backup B D-BU 5719 Ignition Mode Switch Start LED Signal C YE 1491 Backlight Lamp Control D BK/WH 451 Ground E L-GN/WH 5723 Ignition Mode Switch Mode Voltage F L-GN 5724 Ignition Mode Switch Mode Control G PK 5722 Ignition Mode Switch LED Supply Voltage H OG 5721 Ignition Mode Switch Off LED Signal J L-GN 5720 Ignition Mode Switch Accessory LED Signal K L-BU 5726 Ignition Mode Switch Mode Control Backup

C100

C100 Engine to Body Harness Connector End (LH2) Connector Part Information OEM: 7283-5684-30 Service: NS 8-Way F YESC/USCAR Class 3 Sealed (BK) Connector Part Information OEM: 7282-5684-30 NS 8-Way M YESC/USCAR Class 3 Sealed (BK) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 L-BU/BK 1206 Left Front Strut Position Sensor Low Reference 1 L-BU/BK 1206 Left Front Strut Position Sensor Low Reference 2 PU/WH 1205 Left Front Strut Position Sensor Voltage Reference 2 PU/WH 1205 Left Front Strut Position Sensor Voltage Reference 3 TN/WH 1207 Left Front Strut Position Sensor Signal 3 TN/WH 1207 Left Front Strut Position Sensor Signal 4 L-BU/BK 1212 Right Front Strut Position Sensor Low Reference 4 L-BU/BK 1212 Right Front Strut Position Sensor Low Reference 5 PU/WH 1211 Right Front Strut Position Sensor Voltage Reference 5 PU/WH 1211 Right Front Strut Position Sensor Voltage Reference 6 TN/WH 1213 Right Front Strut Position Sensor Signal 6 TN/WH 1213 Right Front Strut Position Sensor Signal 7 OG/BK 1448 Left Front Strut Motor Increase Damping 7 OG/BK 1448 Left Front Strut Motor Increase Damping 8 L-GN 1005 Left Front Strut Motor Decrease Damping Control 8 L-GN 1005 Left Front Strut Motor Decrease Damping Control

Scheme 90

Scheme 91

C101

C101 Body to Engine Harness Connector End Connector Part Information OEM: 15326084 Service: 15306348 16-Way F GT 150, 280 Series Sealed 4.0 5.8 (BK) Connector Part Information OEM: 15326085 15306122 16-Way M GT 150, 280 Series Sealed 4.0 5.8 (BK) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A TN 884 Wheel Speed Sensor Signal Left Rear A TN 884 Wheel Speed Sensor Signal Left Rear B OG 885 Wheel Speed Sensor Low Reference Left Rear B OG 885 Wheel Speed Sensor Low Reference Left Rear C BN 882 Wheel Speed Sensor Signal Right Rear C BN 882 Wheel Speed Sensor Signal Right Rear D WH 883 Wheel Speed Sensor Low Reference Right Rear D WH 883 Wheel Speed Sensor Low Reference Right Rear E L-BU 715 Lateral Accelerometer Signal E L-BU 715 Lateral Accelerometer Signal F D-BU 716 Yaw Rate Sensor Signal (1) F D-BU 716 Yaw Rate Sensor Signal (1) G TN/BK 2500 High Speed GMLAN Serial Data (+) (1) (w/o TT7/TT8) G TN/BK 2500 High Speed GMLAN Serial Data (+) (1) (w/UE1 w/o K59) H TN 2501 High Speed GMLAN Serial Data (-) (1) (w/o TT7/TT8) H TN 2501 High Speed GMLAN Serial Data (-) (1) (w/UE1 w/o K59) J D-BU 1936 Primary Fuel Level Sensor Signal J D-BU 1936 Primary Fuel Level Sensor Signal K L-BU 1937 Secondary Fuel Level Sensor Signal K L-BU 1937 Secondary Fuel Level Sensor Signal L GY 596 5-Volt Reference (LY7) L GY 2709 Fuel Tank Pressure Sensor 5-Volt Reference L GY 2709 Fuel Tank Pressure Sensor 5-Volt Reference (LH2) M D-GN 890 Fuel Tank Pressure Sensor Signal M D-GN 890 Fuel Tank Pressure Sensor Signal N BK 452 Sensor Low Reference (LY7) N TN 2759 Fuel Tank Pressure Sensor Low Reference N BK 2759 Fuel Tank Pressure Sensor Low Reference (LH2) P PU/WH 1699 Combined Vehicle Inertial Sensor Lat/Long Rate Signal P PU/WH 1699 Combined Vehicle Inertial Sensor Lat/Long Rate Signal R D-GN/WH 465 Fuel Pump Primary Relay Control R D-GN/WH 465 Fuel Pump Primary Relay Control S WH 1310 EVAP Canister Vent Solenoid Control S WH 1310 EVAP Canister Vent Solenoid Control

Scheme 92

C102

C102 I/P to Engine Harness Connector End Connector Part Information OEM: 15336418 Service: 88987930 38-Way F GT 150, 280 Series Sealed 4.0 5.2 (BK) Connector Part Information OEM: 15317380 N/S 38-Way M GT 150, 280 Series Sealed 4.0 5.2 (BK) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A1 YE/BK 5728 ECM/TCM Serial Data Wake Up A1 YE/BK 5728 ECM/TCM Serial Data Wake Up A2 L-GN/BK 1338 Yaw Rate Sensor Signal (2) A2 L-GN/BK 1338 Yaw Rate Sensor Signal (2) A3 GY/BK 1337 Yaw Rate Sensor Volt Reference A3 GY/BK 1337 Yaw Rate Sensor Volt Reference A4-A5 - - Not Used A4-A5 - - Not Used A6 L-GN 1763 Steering Wheel Position Signal A A6 L-GN 1763 Steering Wheel Position Signal A A7 - - Not Used A7 - - Not Used A8 YE 5727 High Speed GMLAN Serial Data Wake Up A8 YE 5727 High Speed GMLAN Serial Data Wake Up B1 TN/BK 2500 High Speed GMLAN Serial Data (+) (1) (w/TT7/TT8/K59) B1 TN/BK 2500 High Speed GMLAN Serial Data (+) (1) (w/TT7/TT8/K59) B2 TN 2501 High Speed GMLAN Serial Data (-) (1) (w/TT7/TT8/K59) B2 TN 2501 High Speed GMLAN Serial Data (-) (1) (w/TT7/TT8/K59) B3-B4 - - Not Used B3-B4 - - Not Used B5 BN 818 Vehicle Speed Signal B5 BN 818 Vehicle Speed Signal B6 - - Not Used B6 - - Not Used B7 PU 1272 Accelerator Pedal Position Low Reference (2) B7 PU 1272 Accelerator Pedal Position Low Reference (2) B8-B9 - - Not Used B8-B9 - - Not Used B10 TN 1274 Accelerator Pedal Position 5-Volt Reference (2) B10 TN 1274 Accelerator Pedal Position 5-Volt Reference (2) B11 L-BU 1162 Accelerator Pedal Position Signal (2) B11 L-BU 1162 Accelerator Pedal Position Signal (2) B12 BN 1271 Accelerator Pedal Position Low Reference (1) B12 BN 1271 Accelerator Pedal Position Low Reference (1) C1 WH/BK 1164 Accelerator Pedal Position 5-Volt Reference (1) C1 WH/BK 1164 Accelerator Pedal Position 5-Volt Reference (1) C2 D-BU 1161 Accelerator Pedal Position Signal (1) C2 D-BU 1161 Accelerator Pedal Position Signal (1) C3 WH 17 Stop Lamp Switch Signal C3 WH 17 Stop Lamp Switch Signal C4 PU/WH 1205 Left Front Strut Position Sensor Voltage Reference (w/TT7/TT8 w/o F55) C4 PU/WH 1205 Left Front Strut Position Sensor Voltage Reference (w/TT7/TT8 w/o F55) C5 L-BU/BK 1206 Left Front Strut Position Sensor Low Reference (w/TT7/TT8 w/o F55) C5 L-BU/BK 1206 Left Front Strut Position Sensor Low Reference (w/TT7/TT8 w/o F55) C6 TN/WH 1207 Left Front Strut Position Sensor Signal (w/TT7/TT8 w/o F55) C6 TN/WH 1207 Left Front Strut Position Sensor Signal (w/TT7/TT8 w/o F55) C7 L-BU 1764 Steering Wheel Position Signal B C7 L-BU 1764 Steering Wheel Position Signal B C8-C9 - - Not Used C8-C9 - - Not Used C10 PK 5126 After Boil Heater Pump Supply Voltage (LY7 only) C10 PK 5126 After Boil Heater Pump Supply Voltage (LY7 only) C11 - - Not Used C11 - - Not Used C12 PU 5526 Tap Up/Tap Down Switch Signal C12 PU 5526 Tap Up/Tap Down Switch Signal D1 - - Not Used D1 - - Not Used D2 BN/WH 419 Check Engine Indicator Control D2 BN/WH 419 Check Engine Indicator Control D3 - - Not Used D3 - - Not Used D4-D5 - - Not Available D4-D5 - - Not Available D6 BN 2039 Run Ignition 3 Voltage D6 PK 2039 Run/Crank Ignition 1 Voltage D7-D8 - - Not Used D7-D8 - - Not Used

Scheme 93

Scheme 94

C104

C104 Engine to Valley Jumper Harness Connector End (LH2) Connector Part Information OEM: 15326849 Service: 88986260 12-Way F GT 150 Series Sealed 4.0 (BK) Connector Part Information OEM: 15326854 NS 12-Way M GT 150 Series Sealed 4.0 (BK) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A YE 573 Crankshaft Position Sensor Signal (1) A YE 573 Crankshaft Position Sensor Signal (1) B PU 574 Crankshaft Position Sensor Low Reference (1) B PU 574 Crankshaft Position Sensor Low Reference (1) C L-GN 1867 Crankshaft Position Sensor 12-Volt Reference C L-GN 1867 Crankshaft Position Sensor 12-Volt Reference D BK/WH 1551 Signal Ground D BK/WH 651 Signal Ground E L-GN 5282 Camshaft Phaser Exhaust Solenoid (1) E L-GN 5282 Camshaft Phaser Exhaust Solenoid (1) F PU 5284 Camshaft Phaser Intake Solenoid (1) F PU 5284 Camshaft Phaser Intake Solenoid (1) G D-BU 496 Knock Sensor Signal (1) G D-BU 496 Knock Sensor Signal (1) H GY 1716 Knock Sensor Low Reference (1) H GY 1716 Knock Sensor Low Reference (1) J L-BU 1876 Knock Sensor Signal (2) J L-BU 1876 Knock Sensor Signal (2) K GY 2303 Knock Sensor Low Reference (2) K GY 2303 Knock Sensor Low Reference (2) L OG/BK 5272 Camshaft Phaser Intake Solenoid (2) L OG/BK 5272 Camshaft Phaser Intake Solenoid (2) M WH/BK 5283 Camshaft Phaser Exhaust Solenoid (2) M WH/BK 5283 Camshaft Phaser Exhaust Solenoid (2)

Scheme 95

C105

C105 Engine to Starter Harness Connector End (LH2) Connector Part Information OEM: 12065172 Service: 1-Way F 280 Series Sealed (BK) Connector Part Information OEM: 12065171 Service: 1-Way M 280 Series Sealed (BK) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A PU 6 Starter Solenoid Crank Voltage A PU 6 Starter Solenoid Crank Voltage

C106

C106 Engine to POA Jumper Harness Connector End (LY7) Connector Part Information OEM: 12059472 Service: 12101830 7-Way F 150/280 Series GT (BK) Connector Part Information OEM: 12052200 12117321 7-Way M 150/480 Series (BK) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A PK/BK 5291 Engine Main Relay Fused Control (2) A PK/BK 5291 Engine Main Relay Fused Control (2) B - - Not Used B - - Not Used C D-GN 59 A/C Compressor Clutch Supply Voltage C D-GN 59 A/C Compressor Clutch Supply Voltage D PK/BK 5292 Engine Main Relay Fused Control (3) D PK/BK 5292 Engine Main Relay Fused Control (3) E PU 6 Starter Solenoid Crank Voltage E PU 6 Starter Solenoid Feed F PK/BK 5293 Engine Main Relay Fused Control (4) F PK/BK 5293 Engine Main Relay Fused Control (4) G BK/WH 751 Signal Ground G BK/WH 1451 Signal Ground

Scheme 96

C107

C107 Forward Lamp to Left Repeater Lamp Harness Connector End Connector Part Information OEM: 12040872 Service: 2-Way M Weather Pack (BK) Connector Part Information OEM: 12015792 Service: 2-Way F Weather Pack (BK) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A L-BU/WH 1314 Left Front Turn Signal Lamp Supply Voltage A D-BU/WH 519 Left Front Turn Signal Lamp Supply Voltage B BK 250 Ground B BK 250 Ground

C108

C108 Forward Lamp to Right Repeater Lamp Harness Connector End Connector Part Information OEM: 12010973 Service: 2-Way M Weather Pack (BK) Connector Part Information OEM: 12015792 Service: 2-Way F Weather Pack (BK) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A D-BU/WH 1315 Right Front Turn Signal Lamp Supply Voltage A D-BU/WH 519 Right Front Turn Signal Lamp Supply Voltage B BK 250 Ground B BK 250 Ground

C109

C109 A/C Jumper Connector End (LY7) Connector Part Information OEM: 12052641 Service: 2-Way F Metri-Pack 150 Series (BK) Connector Part Information OEM: 12162000 Service: 2-Way M Metri-Pack 150 Series (BK) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A D-GN 59 A/C Compressor Clutch Supply Voltage A D-GN 59 A/C Compressor Clutch Supply Voltage B BK 750 Ground B BK 1450 Ground

C111

C111 Forward Lamp to I/P Harness Connector End (w/K59,TT6) Connector Part Information OEM: 7283-5553-30 Service: NS 6-Way F YESC/USCAR Class 3 Sealed (BK) Connector Part Information OEM: 7282-5553-30 NS 6-Way M YESC/USCAR Class 3 (BK) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 TN/BK 2500 High Speed GMLAN Serial Data (+) (1) 1 TN/BK 2500 High Speed GMLAN Serial Data (+) (1) 2 TN 2501 High Speed GMLAN Serial Data (-) (1) 2 TN 2501 High Speed GMLAN Serial Data (-) (1) 3 TN/BK 2500 High Speed GMLAN Serial Data (+) (1) 3 TN/BK 2500 High Speed GMLAN Serial Data (+) (1) 4 TN 2501 High Speed GMLAN Serial Data (-) (1) 4 TN 2501 High Speed GMLAN Serial Data (-) (1) 5 YE 5727 High Speed GMLAN Serial Data Wake Up 5 YE 5727 High Speed GMLAN Serial Data Wake Up 6 - - Not Used 6 - - Not Used

Scheme 97

C112

C112 Forward Lamp to I/P Harness Connector End Connector Part Information OEM: 15326863 Service: 15306410 16-Way F GT 150 Series Sealed 4.0 (BK) Connector Part Information OEM: 15326868 15306364 16-Way M 150 Series Sealed (BK) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A L-BU/BK 1206 Left Front Strut Position Sensor Low Reference (w/TT7/TT8, w/o F55) A L-BU/BK 1206 Left Front Strut Position Sensor Low Reference (w/TT7/TT8, w/o F55) B PU/WH 1205 Left Front Strut Position Sensor Voltage Reference (w/TT7/TT8, w/o F55) B PU/WH 1205 Left Front Strut Position Sensor Voltage Reference (w/TT7/TT8, w/o F55) C TN/WH 1207 Left Front Strut Position Sensor Signal (w/TT7/TT8, w/o F55) C TN/WH 1207 Left Front Strut Position Sensor Signal (w/TT7/TT8, w/o F55) D L-GN/BK 1209 Left Rear Strut Position Sensor Low Reference (w/TT7/TT8, w/o F55) D L-GN/BK 1209 Left Rear Strut Position Sensor Low Reference (w/TT7/TT8, w/o F55) E OG/BK 1208 Left Rear Strut Position Sensor Voltage Reference (w/TT7/TT8, w/o F55) E OG/BK 1208 Left Rear Strut Position Sensor Voltage Reference (w/TT7/TT8, w/o F55) F L-GN/WH 1210 Left Rear Strut Position Sensor Signal (w/TT7/TT8, w/o F55) F L-GN/WH 1210 Left Rear Strut Position Sensor Signal (w/TT7/TT8, w/o F55) G YE 5727 High Speed GMLAN Serial Data Wake Up (w/TT7/TT8, K59) G YE 5727 High Speed GMLAN Serial Data Wake Up (w/TT7/TT8, K59) H - - Not Used H - - Not Used J L-GN/BK 5731 Tire Pressure Receiver Low Reference (w/UH3) J L-GN/BK 5731 Tire Pressure Receiver Low Reference (w/UH3) K L-BU/BK 5732 Tire Pressure Receiver Supply Voltage (w/UH3) K L-BU/BK 5732 Tire Pressure Receiver Supply Voltage (w/UH3) L GY 5733 Left Front Tire Pressure Receiver Signal (w/UH3) L GY 5733 Left Front Tire Pressure Receiver Signal (w/UH3) M OG 5734 Right Front Tire Pressure Receiver Signal (w/UH3) M OG 5734 Right Front Tire Pressure Receiver Signal (w/UH3) N TN/BK 2500 High Speed GMLAN Serial Data (+) (1) (w/TT7/TT8) N TN/BK 2500 High Speed GMLAN Serial Data (+) (1) (w/TT7/TT8) P TN 2501 High Speed GMLAN Serial Data (-) (1) (w/TT7/TT8) P TN 2501 High Speed GMLAN Serial Data (-) (1) (w/TT7/TT8) R TN/BK 2500 High Speed GMLAN Serial Data (+) (1) (w/TT7/TT8) R TN/BK 2500 High Speed GMLAN Serial Data (+) (1) (w/TT7/TT8) S TN 2501 High Speed GMLAN Serial Data (-) (1) (w/TT7/TT8) S TN 2501 High Speed GMLAN Serial Data (-) (1) (w/TT7/TT8)

C113

C113 Engine to Forward Lamp Harness Connector End (LH2) Connector Part Information OEM: 7283-5596-10 Service: NS 2-Way F 6.3 (D-GY) Connector Part Information OEM: 7282-5596-10 NS 2-Way M 6.3 Series Weather Pack (D-GY) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 BK 1150 Ground 1 BK 1150 Ground 2 BK 1150 Ground 2 BK 1150 Ground

C115

C115 Fuel Injector Harness Connector End (LY7) Connector Part Information OEM: 19632141 Service: NS 10-Way F Amp (BK) Connector Part Information OEM: 19623521 Service: NS 10-Way M Amp (BK) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 PK/BK 5291 Engine Main Relay Fused Control (2) 1 WH 5291 Engine Main Relay Fused Control (2) 2 PK/BK 5292 Engine Main Relay Fused Control (3) 2 WH 5292 Engine Main Relay Fused Control (3) 3 TN 1744 Fuel Injector Control (1) 3 TN 1744 Fuel Injector Control (1) 4 PK/BK 1746 Fuel Injector Control (3) 4 PK/BK 1746 Fuel Injector Control (3) 5 TN/WH 845 Fuel Injector Control (5) 5 TN/WH 845 Fuel Injector Control (5) 6 L-GN/BK 1745 Fuel Injector Control (2) 6 L-GN/BK 1745 Fuel Injector Control (2) 7 L-BU/BK 844 Fuel Injector Control (4) 7 L-BU/BK 844 Fuel Injector Control (4) 8 YE/BK 846 Fuel Injector Control (6) 8 YE/BK 846 Fuel Injector Control (6) 9-10 - - Not Used 9-10 - - Not Used

Scheme 98

Scheme 99

C120

C120 Forward Lamp Harness to Headlamp Assembly - Left Harness Connector End Connector Part Information OEM: 7283-5577-10 Service: 6-Way F YESC/USCAR Class 3 Sealed (GY) Connector Part Information OEM: Service: NS 6-Way F YESC/USCAR Class 3 Sealed (BK) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 L-GN 11 Headlamp High Beam Supply Voltage (w/TT6) 1 D-GN 11 Headlamp High Beam Supply Voltage (w/TT6) 1 D-GN/WH 711 Left Headlamp High Beam Supply Voltage (w/TT7/TT8) 1 D-GN/WH 711 Left Headlamp High Beam Supply Voltage (w/TT7/TT8) 2 BK 250 Ground (w/o TT6/TT7/TT8) 2 BK 250 Ground (w/o TT6/TT7/TT8) 2 YE 712 Left Headlamp Low Beam Supply Voltage (w/TT6/TT7/TT8) 2 YE 712 Left Headlamp Low Beam Supply Voltage (w/TT6/TT7/TT8) 3 PU 709 Left Park Lamp Supply Voltage (w/TT6) 3 BN 709 Left Park Lamp Supply Voltage (w/TT6) 3 PU 1472 Left Park Lamp Relay Control (w/TT7/TT8) 3 PU 1472 Left Park Lamp Relay Control (w/TT7/TT8) 4 - - Not Used 4 - - Not Used 4 D-GN/WH 711 Left Headlamp High Beam Supply Voltage (w/o TT6/TT7/TT8) 4 D-GN/WH 711 Left Headlamp High Beam Supply Voltage (w/o TT6/TT7/TT8) 5 BK 712 Ground 5 BK 712 Ground 5 BK 712 Ground 6 PU 709 Left Park Lamp Supply Voltage (w/o TT6/TT7/TT8) 6 PU 709 Left Park Lamp Supply Voltage (w/o TT6/TT7/TT8)

Scheme 100

C121

C121 Forward Lamp Harness to Headlamp Assembly - Right Harness Connector End Connector Part Information OEM: 7283-5577-10 Service: 6-Way F YESC/USCAR Class 3 Sealed (GY) Connector Part Information OEM: Service: NS 6-Way F YESC/USCAR Class 3 Sealed (BK) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 L-GN 11 Headlamp High Beam Supply Voltage (w/TT6) 1 D-GN 11 Headlamp High Beam Supply Voltage (w/TT6) 1 L-GN/BK 311 Right Headlamp High Beam Supply Voltage (w/TT7/TT8) 1 D-GN/WH 711 Right Headlamp High Beam Supply Voltage (w/TT7/TT8) 2 BK 250 Ground (w/o TT6/TT7/TT8) 2 BK 250 Ground (w/o TT6/TT7/TT8) 2 TN/WH 312 Right Headlamp Low Beam Supply Voltage (w/TT6/TT7/TT8) 2 YE 312 Right Headlamp Low Beam Supply Voltage (w/TT6/TT7/TT8) 3 BN/WH 309 Right Park Lamp Supply Voltage (w/TT6) 3 BN 309 Right Park Lamp Supply Voltage (w/TT6) 3 BN/WH 1473 Right Park Lamp Supply Voltage (w/TT7/TT8) 3 BN/WH 1473 Right Park Lamp Supply Voltage (w/TT7/TT8) 4 - - Not Used 4 - - Not Used - - Not Used 4 L-GN/BK 311 Right Headlamp High Beam Supply Voltage (w/o TT6/TT7/TT8) 4 L-GN/BK 311 Right Headlamp High Beam Supply Voltage (w/o TT6/TT7/TT8) 5 BK 312 Ground 5 BK 312 Ground 5 BK 312 Ground 6 BN/WH 309 Right Park Lamp Supply Voltage (w/o TT6/TT7/TT8) 6 BN/WH 309 Right Park Lamp Supply Voltage (w/o TT6/TT7/TT8)

C122

C122 Forward Lamp Harness to Turn Signal/Fog Lamp Assembly - LF Harness Connector End Connector Part Information OEM: 7283-5577-10 Service: 6-Way F YESC/USCAR Class 3 Sealed (GY) Connector Part Information OEM: Service: NS 6-Way F YESC/USCAR Class 3 Sealed (BK) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 WH/BK 1314 Left Front Turn Signal Lamp Supply Voltage 1 L-BU 1314 Left Front Turn Signal Lamp Supply Voltage 2 PU 2234 Front Fog Lamp Supply Voltage 2 YE 2234 Front Fog Lamp Supply Voltage 3-5 - - Not Used 3-5 - - Not Used 6 BK 250 Ground 6 BK 250 Ground

C123

C123 Forward Lamp Harness to Turn Signal/Fog Lamp Assembly - RF Harness Connector End Connector Part Information OEM: 7283-5577-10 Service: 6-Way F YESC/USCAR Class 3 Sealed (GY) Connector Part Information OEM: Service: NS 6-Way F YESC/USCAR Class 3 Sealed (BK) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 L-GN/BK 1315 Right Front Turn Signal Lamp Supply Voltage 1 L-BU 1315 Right Front Turn Signal Lamp Supply Voltage 2 PU 2234 Front Fog Lamp Supply Voltage 2 YE 2234 Front Fog Lamp Supply Voltage 3-5 - - Not Used 3-5 - - Not Used 6 BK 250 Ground 6 BK 250 Ground

C139

C139 Engine to Even Bank Coil/Module Harness Connector End (LH2) Connector Part Information 15317367 7-Way F GT 150 Series (BK) Connector Part Information 15326553 7-Way M GT 150 Series (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A PK/BK 5292 Ignition 1 Voltage A PK/BK 5292 Ignition 1 Voltage B BK/WH 1451 Ground B BK/WH 1451 Ground C BN/WH 2130 Low Reference C BN/WH 2130 Low Reference D D-GN/WH 2124 IC 4 Control D D-GN/WH 2124 IC 4 Control E L-BU/WH 2126 IC 6 Control E L-BU/WH 2126 IC 6 Control F PU/WH 2128 IC 8 Control F PU/WH 2128 IC 8 Control G OG/WH 2122 IC 2 Control G OG/WH 2122 IC 2 Control

Scheme 101

C140

C140 Engine to Odd Bank Coil/Module Harness Connector End (LH2) Connector Part Information 15317367 7-Way F GT 150 Series (BK) Connector Part Information 15326553 7-Way M GT 150 Series (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A PK/BK 5291 Ignition 1 Voltage A PK/BK 5291 Ignition 1 Voltage B BK/WH 1451 Ground B BK/WH 1451 Ground C BN 2129 Low Reference C BN 2129 Low Reference D D-GN 2125 IC 5 Control D D-GN 2125 IC 5 Control E L-BU 2123 IC 3 Control E L-BU 2123 IC 3 Control F PU 2121 IC 1 Control F PU 2121 IC 1 Control G OG 2127 IC 7 Control G OG 2127 IC 7 Control

C175

C175 Engine Harness to Transmission Connector End Connector Part Information OEM: 9432001 Service: 10756491 20-Way F (BK) Connector Part Information OEM: 10756491 Service: 10756491 20-Way M (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 YE 400 OSS High Signal 1 YE 400 OSS High Signal 2 OG/BK 1786 Park/Neutral Signal 2 OG/BK 1786 Park/Neutral Signal 3 PU 401 OSS Low Signal 3 PU 401 OSS Low Signal 4 BK 1551 Ground (w/LH2) 4 BK 1551 Ground (w/LH2) 4 BK 751 Ground (w/LY7) 4 BK 751 Ground (w/LY7) 5 PU 898 Shift Solenoid Valve 3 High Control 5 PU 898 Shift Solenoid Valve 3 High Control 6 TN 2762 Low Reference 6 TN 2762 Low Reference 7 YE 772 Transmission Range Switch Signal B 7 YE 772 Transmission Range Switch Signal B 8 L-BU/WH 1229 PC Solenoid Valve Low Control 8 L-BU/WH 1229 PC Solenoid Valve Low Control 9 YE/BK 1223 2-3 Shift Solenoid Valve Control 9 YE/BK 1223 2-3 Shift Solenoid Valve Control 10 YE/BK 1227 TFT Sensor Signal 10 YE/BK 1227 TFT Sensor Signal 11 WH 776 Transmission Range Switch Signal P 11 WH 776 Transmission Range Switch Signal P 12 - - Not Used 12 - - Not Used 13 OG/BK 1228 PC Solenoid Valve High Control 13 OG/BK 1228 PC Solenoid Valve High Control 14 L-GN 1222 1-2 Shift Solenoid Valve Control 14 L-GN 1222 1-2 Shift Solenoid Valve Control 15 D-BU/WH 1231 AT ISS Low Signal 15 D-BU/WH 1231 AT ISS Low Signal 16 TN/WH 771 Transmission Range Switch Signal A 16 TN/WH 771 Transmission Range Switch Signal A 17 OG 1525 Solenoid Supply Voltage 17 OG 1525 Solenoid Supply Voltage 18 OG/BK 1230 AT ISS High Signal 18 OG/BK 1230 AT ISS High Signal 19 GY 773 Transmission Range Switch Signal C 19 GY 773 Transmission Range Switch Signal C 20 BN 418 TCC PWM Solenoid Valve Control 20 BN 418 TCC PWM Solenoid Valve Control

Scheme 102

C200

C200 Body to I/P Harness Right Connector End Connector Part Information OEM: 15359287 Service: 15359287 40-Way F GT 150, 280 Series (BK) Connector Part Information OEM: 15359284 15359284 40-Way M GT 150, 280 Series (BK) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A1 PU 6858 Headlamp Automatic High Beam Dim Supply Voltage (w/TT6) A1 PU 6858 Headlamp Automatic High Beam Dim Supply Voltage (w/TT6) A2 D-BU 6856 Headlamp Automatic High Beam Dim Enable (w/TT6) A2 D-BU 6856 Headlamp Automatic High Beam Dim Enable (w/TT6) A3 YE 32 Instrument Panel Lamp Fuse Supply Voltage (1) A3 YE 32 Instrument Panel Lamp Fuse Supply Voltage (1) YE 32 Instrument Panel Lamp Fuse Supply Voltage (1) A4 BN/WH 309 Right Park Lamp Supply Voltage (w/UE1, TT7/TT8) A4 BN/WH 309 Right Park Lamp Supply Voltage A5 BK 450 Ground A5 BK 450 Ground A6 D-BU/WH 149 Courtesy Lamp Supply Voltage A6 D-BU/WH 149 Courtesy Lamp Supply Voltage A7 WH 111 Hazard Switch Signal A7 WH 111 Hazard Switch Signal A8 - - Not Used A8 - - Not Used B1 PU 1952 Right Front Tweeter Speaker (-) (w/YQ2) B1 PU 1952 Right Front Tweeter Speaker (-) (w/YQ2) B1 TN 1875 Right Front Speaker (+) (2) (w/YQ3/YQ4/YQ6/YQ7) B1 TN 1875 Right Front Speaker (+) (2) (w/YQ3/YQ4/YQ6/YQ7) B2 L-GN 1852 Right Front Tweeter Speaker (+) (w/YQ2) B2 L-GN 1852 Right Front Tweeter Speaker (+) (w/YQ2) B2 TN/WH 1975 Right Front Speaker (-) (2) (w/YQ3/YQ4/YQ6/YQ7) B2 TN/WH 1975 Right Front Speaker (-) (2) (w/YQ3/YQ4/YQ6/YQ7) B3 TN/BK 2500 High Speed GMLAN Serial Data (+) (1) (K59 w/UE1, TT7/TT8) B3 TN/BK 2500 High Speed GMLAN Serial Data (+) (1) (K59 w/UE1, TT7/TT8) B4 TN 2501 High Speed GMLAN Serial Data (-) (1) (K59 w/UE1, TT7/TT8) B4 TN 2501 High Speed GMLAN Serial Data (-) (1) (K59 w/UE1, TT7/TT8) B5 TN/WH 1969 Headlamp High Beam Relay Control (w/TT6) B5 L-GN/BK 5731 Tire Pressure Receiver Low Reference (w/TT6) B5 L-GN/BK 5731 Tire Pressure Receiver Low Reference (w/UH3) B5 TN/WH 1969 Headlamp High Beam Relay Control (w/UH3) B6 GY 5127 After Boil Heater Relay Control (w/LH2, V92/V03) B6 GY 5127 After Boil Heater Relay Control (w/LH2, V92/V03) B7 PK 5126 After Boil Heater Pump Supply Voltage (w/LH2, V92/V03) B7 PK 5126 After Boil Heater Pump Supply Voltage (w/LH2, V92/V03) B8 L-BU/BK 5732 Tire Pressure Receiver Supply Voltage (w/UH3) B8 L-BU/BK 5732 Tire Pressure Receiver Supply Voltage (w/UH3) B9 GY 157 Interior Lamp Control B9 GY 157 Interior Lamp Control GY 157 Interior Lamp Control B10 OG 300 Run Ignition 3 Voltage B10 OG 300 Run Ignition 3 Voltage B11 D-GN 1409 Right Front Discriminating Sensor Signal B11 D-GN 1409 Right Front Discriminating Sensor Signal B12 GY 5600 Right Front Discriminating Sensor Low Reference B12 GY 5600 Right Front Discriminating Sensor Low Reference C1 TN/OG 5045 Left Front Discriminating Sensor Low Reference C1 TN/OG 5045 Left Front Discriminating Sensor Low Reference C2 YE 1834 SIR Forward Sensor Signal (1) C2 YE 1834 SIR Forward Sensor Signal (1) C3 PU 5526 Tap Up/Tap Down Switch Signal C3 PU 5526 Tap Up/Tap Down Switch Signal C4 PU 5531 Hood Closed Switch Signal C4 PU 5531 Hood Closed Switch Signal C5 YE 5530 Hood Open Switch Signal C5 YE 5530 Hood Open Switch Signal C6 TN 481 Rain Sense Signal (1) (CE1) C6 TN 481 Rain Sense Signal (1) (CE1) C7 L-GN 482 Rain Sense Signal (2) (CE1) C7 L-GN 482 Rain Sense Signal (2) (CE1) C8 OG 5734 Right Front Tire Pressure Receiver Signal (w/UH3) C8 OG 5734 Right Front Tire Pressure Receiver Signal (w/UH3) C9 BK/WH 451 Ground C9 BK/WH 451 Ground C10 YE 1491 Backlight Lamp Control C10 YE 1491 Backlight Lamp Control C11 PK 1639 Run/Crank Ignition 1 Voltage C11 PK 1639 Run/Crank Ignition 1 Voltage C12 BN 818 Vehicle Speed Signal C12 BN 818 Vehicle Speed Signal C12 BN 818 Vehicle Speed Signal (w/YQ4/YQ6/YQ7) D1 YE 243 Accessory Voltage D1 YE 243 Accessory Voltage D2 - - Not Used D2 - - Not Used D3 TN/BK 2500 High Speed GMLAN Serial Data (+) (1) (w/UE1, TT7/TT8) D3 TN/BK 2500 High Speed GMLAN Serial Data (+) (1) (w/UE1, TT7/TT8) D4 TN 2501 High Speed GMLAN Serial Data (-) (1) (w/UE1, TT7/TT8) D4 TN 2501 High Speed GMLAN Serial Data (-) (1) (w/UE1, TT7/TT8) D5 L-GN 6857 Headlamp Automatic High Beam Dim Status (w/TT6) D5 GY 5733 Left Front Tire Pressure Receiver Signal (w/TT6) D5 GY 5733 Left Front Tire Pressure Receiver Signal (w/UH3) D5 L-GN 6857 Headlamp Automatic High Beam Dim Status (w/UH3) D6 - - Not Used D6 - - Not Used D7 L-GN/BK 1338 Yaw Rate Sensor Signal (2) D7 L-GN/BK 1338 Yaw Rate Sensor Signal (2) L-GN/BK 1338 Yaw Rate Sensor Signal (2) D8 GY/BK 1337 Yaw Rate Sensor Volt Reference D8 GY/BK 1337 Yaw Rate Sensor Volt Reference GY/BK 1337 Yaw Rate Sensor Volt Reference

Scheme 103

C201

C201 Body to I/P Harness Right Center Connector End Connector Part Information OEM: 7283-6376-30 Service: NS 26-Way F Hybrid (BK) Connector Part Information OEM: 7282-6376-30 NS 26-Way M Hybrid (GY) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 L-BU 1960 Front Center Speaker (-) (w/YQ2, YQ3/YQ4/YQ6/YQ7) 1 L-BU 1960 Front Center Speaker (-) 2 YE 1860 Front Center Speaker (+) (w/YQ2, YQ3/YQ4/YQ6/YQ7) 2 YE 1860 Front Center Speaker (+) 3 L-BU/WH 1314 Left Front Turn Signal Lamp Supply Voltage 3 L-BU/WH 1314 Left Front Turn Signal Lamp Supply Voltage 4 D-BU/WH 1315 Right Front Turn Signal Lamp Supply Voltage 4 D-BU/WH 1315 Right Front Turn Signal Lamp Supply Voltage 5 D-GN/WH 1932 Shift Select Switch Park Signal 5 D-GN/WH 1932 Shift Select Switch Park Signal D-GN/WH 1932 Shift Select Switch Park Signal (w/UA2) 6 D-GN 5525 Tap Up/Tap Down Enable Signal 6 D-GN 5525 Tap Up/Tap Down Enable Signal 7 GN/YE 6847 Shift Select Switch Park Supply Voltage 7 GN/YE 6847 Shift Select Switch Park Supply Voltage 8 PK 3 Run/Crank Ignition 1 Voltage 8 PK 3 Run/Crank Ignition 1 Voltage 9 - - Not Used 9 - - Not Used 10 D-GN 1947 Left Front Low Level Audio (-) (w/YQ2, YQ3/YQ4/YQ6/YQ7) 10 D-GN 1947 Left Front Low Level Audio (-) 11 TN 511 Left Front Low Level Audio Signal (w/YQ2, YQ3/YQ4/YQ6/YQ7) 11 TN 511 Left Front Low Level Audio Signal 12 L-BU/WH 5725 Ignition Mode Switch Mode Voltage Backup 12 L-BU/WH 5725 Ignition Mode Switch Mode Voltage Backup 13 L-BU 5726 Ignition Mode Switch Mode Control Backup 13 L-BU 5726 Ignition Mode Switch Mode Control Backup 14 PK 5165 Antenna 14-Volt Switched Supply Voltage 14 PK 5165 Antenna 14-Volt Switched Supply Voltage 15 BN 253 Trunk Release Relay Control 15 BN 253 Trunk Release Relay Control 16 - - Not Used 16 - - Not Used 17 BK/WH 851 Signal Ground 17 BK/WH 851 Signal Ground BK/WH 851 Signal Ground 18 D-GN/WH 512 Right Front Low Level Audio Signal 18 D-GN/WH 512 Right Front Low Level Audio Signal 19 BARE 2012 Right Front Audio Drain Wire 19 BARE 2012 Right Front Audio Drain Wire 20 L-GN 1948 Right Front Low Level Audio (-) 20 L-GN 1948 Right Front Low Level Audio (-) 21-25 - - Not Used 21-25 - - Not Used 26 RD/WH 2240 Battery Positive Voltage 26 RD/WH 2240 Battery Positive Voltage RD/WH 2240 Battery Positive Voltage

Scheme 104

C202

C202 I/P to Steering Column Harness Connector End Connector Part Information OEM: 15359287 Service: 15359287 40-Way F GT 150, 280 Series (BK) Connector Part Information OEM: 15359284 15359284 40-Way M GT 150, 280 Series (BK) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A1 L-BU 187 Rear Fog Lamp Switch Signal (T79) A1 L-BU 187 Rear Fog Lamp Switch Signal (T79) A2 OG 192 Front Fog Lamp Switch Signal A2 OG 192 Front Fog Lamp Switch Signal A3 L-BU 283 Driver Power Seat Rear Vertical Motor Down Control A3 BN 283 Driver Power Seat Rear Vertical Motor Down Control A4 PK 2111 Steering Column Tilt Motor Up Control A4 PK 2111 Steering Column Tilt Motor Up Control A5 TN 782 Memory Seat/Mirror Sensor Low Reference (w/A45) A5 TN 782 Memory Seat/Mirror Sensor Low Reference (w/A45) A5 TN 782 Memory Seat/Mirror Sensor Low Reference (w/A45) A6 BK 350 Ground A6 BK 350 Ground A7 BN/WH 301 Park Lamp Switch On Signal A7 BN/WH 301 Park Lamp Switch On Signal A8 PU 1783 Twilight Sentinel Delay Signal A8 PU 1783 Twilight Sentinel Delay Signal B1 WH 103 Headlamp Switch On Signal B1 WH 103 Headlamp Switch On Signal B2 L-BU 1485 Flash To Pass Switch Supply Voltage B2 L-BU 1485 Flash To Pass Switch Supply Voltage B3 BN 1356 Flash To Pass Switch Signal B3 BN 1356 Flash To Pass Switch Signal B4 YE/BK 1418 Left Rear Turn Signal Switch Signal B4 YE/BK 1418 Left Rear Turn Signal Switch Signal B5 - - Not Used B5 D-GN/WH 1419 Right Rear Turn Signal Switch Signal B6 - - Not Used B6 YE 43 Accessory Voltage B7 D-BU/WH 1415 Right Front Turn Signal Switch Signal B7 D-BU/WH 1415 Right Front Turn Signal Switch Signal B8 L-BU/WH 1414 Left Front Turn Signal Switch Signal B8 L-BU/WH 1414 Left Front Turn Signal Switch Signal B9 GY 478 Windshield Wiper Switch Signal (2) B9 GY 478 Windshield Wiper Switch Signal (2) GY 478 Windshield Wiper Switch Signal (2) B10 D-GN 5060 Low Speed GMLAN Serial Data (w/UA2) B10 D-GN 5060 Low Speed GMLAN Serial Data (w/UA2) B11 TN 28 Horn Relay Control B11 TN 28 Horn Relay Control B12 WH 1538 Headlamp On With Wipers Signal B12 WH 1538 Headlamp On With Wipers Signal C1 PU 1375 Remote Radio Control Head Accessory Supply Voltage C1 PK 1375 Remote Radio Control Head Accessory Supply Voltage C2 YE 1491 Backlight Lamp Control C2 YE 1491 Backlight Lamp Control C3 D-BU 1796 Steering Column Radio Control Signal C3 D-BU 1796 Steering Column Radio Control Signal C4 D-BU 477 Windshield Wiper Switch Signal (1) C4 D-BU 477 Windshield Wiper Switch Signal (1) C5 GY 1884 Cruise Control Set/Coast/Resume/Accelerate Switch Signal C5 L-BU/WH 1884 Cruise Control Set/Coast/Resume/Accelerate Switch Signal C6 PU 92 Windshield Wiper Motor High Speed Control C6 PU 92 Windshield Wiper Motor High Speed Control C7 D-GN/WH 1932 Shift Select Switch Park Signal (w/UA2) C7 D-GN/WH 1932 Shift Select Switch Park Signal (w/UA2) C8 YE 2097 Steering Column Tilt and Telescope Down Switch Signal C8 YE 2097 Steering Column Tilt and Telescope Down Switch Signal C9 PK 2094 Steering Column Tilt and Telescope Forward Switch Signal C9 PU 2094 Steering Column Tilt and Telescope Forward Switch Signal C10 GY 2096 Steering Column Tilt and Telescope Up Switch Signal C10 GY 2096 Steering Column Tilt and Telescope Up Switch Signal C11 PK 1239 Run/Crank Ignition 1 Voltage C11 PK 1239 Run/Crank Ignition 1 Voltage C12 OG 2154 Steering Column Tilt Motor Signal (w/A45) C12 OG 2154 Steering Column Tilt Motor Signal (w/A45) D1 OG 2153 Steering Column Telescope Motor Signal (w/A45) D1 OG 2153 Steering Column Telescope Motor Signal (w/A45) D2 RD/WH 1640 Battery Positive Voltage D2 RD 1640 Battery Positive Voltage D3 D-BU 287 Driver Power Seat Front Vertical Motor Down Control D3 TN 287 Driver Power Seat Front Vertical Motor Down Control D4 OG 2098 Steering Column Telescope Motor Forward D4 OG 2098 Steering Column Telescope Motor Forward D5 OG 2095 Steering Column Tilt and Telescope Rearward Switch Signal D5 OG 2095 Steering Column Tilt and Telescope Rearward Switch Signal D6 BK/WH 351 Ground (w/UA2) D6 BK/WH 351 Ground (w/UA2) D7 GY 788 Memory Mirror Position Sensor 5-Volt Reference (w/A45) D7 GY 788 Memory Mirror Position Sensor 5-Volt Reference (w/A45) D8 WH 5741 Steering Column Lock Module Lock Enable Relay Control (w/UA2) D8 WH 5741 Steering Column Lock Module Lock Enable Relay Control (w/UA2)

C204

C204 Body to I/P Harness Left Center Connector End Connector Part Information OEM: 7283-6376-30 Service: NS 26-Way F Hybrid (BK) Connector Part Information OEM: 7282-6376-30 NS 26-Way M Hybrid (GY) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 BARE 1792 Drain Wire (w/UE1) 1 BARE 1792 Drain Wire 2 L-BU/WH 5338 Right TV Audio Signal (w/U2K, YQ6/YQ7) 2 L-BU/WH 5338 Right TV Audio Signal (w/U2K, YQ6/YQ7) 3 GY/BK 5339 TV Audio Low Reference (w/U2K, YQ6/YQ7) 3 GY/BK 5339 TV Audio Low Reference (w/U2K, YQ6/YQ7) 4 BARE 5345 Auxiliary Audio Screen (1) (w/U2K, YQ6/YQ7) 4 BARE 5345 Auxiliary Audio Screen (1) (w/U2K, YQ6/YQ7) 5 PK 5149 Voice Recognition Audio Signal (w/UE1) 5 GY 655 Cellular Telephone Microphone Signal 5 GY 655 Cellular Telephone Microphone Signal (w/TT7/TT8) 6 PK/BK 5152 Voice Recognition Audio Low Reference (w/UE1) 6 PK/BK 5152 Voice Recognition Audio Low Reference 6 BARE 1782 Drain Wire (w/TT7/TT8) 7 BARE 1705 Drain Wire (w/YQ6/YQ7) 7 BARE 1705 Drain Wire (w/YQ6/YQ7) 8 - - Not Used 8 - - Not Used 9 BARE 2099 Left Rear Audio Drain Wire (w/YQ3/YQ4/YQ6/YQ7) 9 BARE 2099 Left Rear Audio Drain Wire (w/YQ3/YQ4/YQ6/YQ7) 10 BN/WH 599 Left Rear Low Level Audio Signal (w/YQ3/YQ4/YQ6/YQ7) 10 BN/WH 599 Left Rear Low Level Audio Signal (w/YQ3/YQ4/YQ6/YQ7) 11 BN 1999 Left Rear Low Level Audio (-) (w/YQ3/YQ4/YQ6/YQ7) 11 BN 1999 Left Rear Low Level Audio (-) (w/YQ3/YQ4/YQ6/YQ7) 12 D-BU 546 Right Rear Low Level Audio Signal (w/YQ3/YQ4/YQ6/YQ7) 12 D-BU 546 Right Rear Low Level Audio Signal (w/YQ3/YQ4/YQ6/YQ7) 13 TN 1946 Right Rear Low Level Audio (-) (w/YQ3/YQ4/YQ6/YQ7) 13 TN 1946 Right Rear Low Level Audio (-) (w/YQ3/YQ4/YQ6/YQ7) 14 GY 5836 Amplifier Audio Prompt Signal (-) (w/YQ4/YQ6/YQ7) 14 GY 5836 Amplifier Audio Prompt Signal (-) (w/YQ4/YQ6/YQ7) 15 PU 5837 Amplifier Audio Prompt Signal (+) (w/YQ4/YQ6/YQ7) 15 PU 5837 Amplifier Audio Prompt Signal (+) (w/YQ4/YQ6/YQ7) 16 BARE 5838 Amplifier Audio Prompt Drain Wire (w/YQ3/YQ4/YQ6/YQ7) 16 BARE 5838 Amplifier Audio Prompt Drain Wire (w/YQ3/YQ4/YQ6/YQ7) 17 D-BU 6760 Center Channel Low Level Audio Signal (w/YQ3/YQ4/YQ6/YQ7) 17 D-BU 6760 Center Channel Low Level Audio Signal (w/YQ3/YQ4/YQ6/YQ7) 18 WH 6765 Subwoofer Low Level Audio Signal (w/YQ3/YQ4/YQ6/YQ7) 18 WH 6765 Subwoofer Low Level Audio Signal (w/YQ3/YQ4/YQ6/YQ7) 19 OG 6761 Center Channel Low Level Audio Signal (-) (w/YQ3/YQ4/YQ6/YQ7) 19 OG 6761 Center Channel Low Level Audio Signal (-) (w/YQ3/YQ4/YQ6/YQ7) 20 YE 5385 Vehicle Identification Communication System Bus Request Signal (w/YQ7) 20 YE 5385 Vehicle Identification Communication System Bus Request Signal (w/YQ7) 21 GY 5383 Vehicle Identification Communication System Bus Request Signal (w/YQ7) 21 GY 5383 Vehicle Identification Communication System High Signal (w/YQ7) 22 BN 5384 Vehicle Identification Communication System Low Signal (w/YQ7) 22 BN 5384 Vehicle Identification Communication System Low Signal (w/YQ7) 23 YE 43 Accessory Voltage (w/YQ7) 23 YE 43 Accessory Voltage (w/YQ7) 24 BARE 814 Drain Wire (w/YQ7) 24 BARE 814 Drain Wire (w/YQ7) 25 L-GN/WH 5337 Left TV Audio Signal (w/U2K, YQ6/YQ7) 25 L-GN/WH 5337 Left TV Audio Signal (w/U2K, YQ6/YQ7) 25 - - Not Used 25 BARE 654 Drain Wire (w/TT7/TT8) 26 GY 5231 Video RGB Low Reference (w/YQ6/YQ7) 26 GY 5231 Video RGB Low Reference (w/YQ6/YQ7)

C205

C205 Body to I/P Harness Left Connector End Connector Part Information OEM: 15359287 Service: 15359287 40-Way F GT (BK) Connector Part Information OEM: 15359284 15359284 40-Way M GT (BK) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A1 YE 1956 Left Front Tweeter Speaker (-) (w/YQ2) A1 YE 1956 Left Front Tweeter Speaker (-) (w/YQ2) A1 TN/WH 1974 Left Front Speaker (-) (2) (w/YQ3/YQ4/YQ6/YQ7) A1 TN/WH 1974 Left Front Speaker (-) (2) (w/YQ3/YQ4/YQ6/YQ7) A2 TN 1856 Left Front Tweeter Speaker (+) (w/YQ2) A2 TN 1856 Left Front Tweeter Speaker (+) (w/YQ2) A2 L-BU 1874 Left Front Speaker (+) (2) (w/YQ3/YQ4/YQ6/YQ7) A2 L-BU 1874 Left Front Speaker (+) (2) (w/YQ3/YQ4/YQ6/YQ7) A3 D-BU 287 Driver Power Seat Front Vertical Motor Down Control A3 D-BU 287 Driver Power Seat Front Vertical Motor Down Control A4-A5 - - Not Used A4-A5 - - Not Used A6 BK 350 Ground A6 BK 350 Ground BK 350 Ground A7 - - Not Used A7 - - Not Used A8 - - Not Used A8 - - Not Used B1 WH 17 Stop Lamp Switch Signal B1 WH 17 Stop Lamp Switch Signal B1 WH 17 Stop Lamp Switch Signal WH 17 Stop Lamp Switch Signal B2 - - Not Used B2 - - Not Used B3 PK 3 Run/Crank Ignition 1 Voltage B3 PK 3 Run/Crank Ignition 1 Voltage B4 TN 782 Memory Seat/Mirror Sensor Low Reference (w/A45) B4 TN 782 Memory Seat/Mirror Sensor Low Reference (w/A45) B5 GY 788 Memory Mirror Position Sensor 5-Volt Reference (w/A45) B5 GY 788 Memory Mirror Position Sensor 5-Volt Reference (w/A45) B6-B8 - - Not Used B6-B8 - - Not Used B9 PK 1239 Run/Crank Ignition 1 Voltage B9 PK 1239 Run/Crank Ignition 1 Voltage B10 - - Not Used B10 - - Not Used B11 OG 2154 Steering Column Tilt Motor Signal (w/A45) B11 OG 2154 Steering Column Tilt Motor Signal (w/A45) B12 OG 2153 Steering Column Telescope Motor Signal (w/A45) B12 OG 2153 Steering Column Telescope Motor Signal (w/A45) C1 - - Not Used C1 - - Not Used C2 RD/WH 1440 Battery Positive Voltage C2 RD/WH 1440 Battery Positive Voltage C3 YE 5727 High Speed GMLAN Serial Data Wake Up (w/F55) C3 YE 5727 High Speed GMLAN Serial Data Wake Up (w/F55) C4 RD/WH 3640 Battery Positive Voltage C4 RD/WH 3640 Battery Positive Voltage C5-C8 - - Not Used C5-C8 - - Not Used C9 PU 709 Left Park Lamp Supply Voltage (w/UE1, TT7/TT8) C9 PU 709 Left Park Lamp Supply Voltage (w/UE1, TT7/TT8) C10 L-GN/BK 1209 Left Rear Strut Position Sensor Low Reference (w/TT7/TT8, w/o F55) C10 L-GN/BK 1209 Left Rear Strut Position Sensor Low Reference (w/TT7/TT8, w/o F55) C11 OG/BK 1208 Left Rear Strut Position Sensor Voltage Reference (w/TT7/TT8, w/o F55) C11 OG/BK 1208 Left Rear Strut Position Sensor Voltage Reference (w/TT7/TT8, w/o F55) C12 L-GN/WH 1210 Left Rear Strut Position Sensor Signal (w/TT7/TT8, w/o F55) C12 L-GN/WH 1210 Left Rear Strut Position Sensor Signal (w/TT7/TT8, w/o F55) D1 BK/WH 351 Ground D1 BK/WH 351 Ground D1 BK/WH 351 Ground (w/UA2) D2 D-GN 5060 Low Speed GMLAN Serial Data D2 D-GN 5060 Low Speed GMLAN Serial Data D3 - - Not Used D3 - - Not Used D4 OG 2098 Steering Column Telescope Motor Forward D4 OG 2098 Steering Column Telescope Motor Forward D5 PK 2111 Steering Column Tilt Motor Up Control D5 PK 2111 Steering Column Tilt Motor Up Control D6 L-BU 283 Driver Power Seat Rear Vertical Motor Down Control D6 L-BU 283 Driver Power Seat Rear Vertical Motor Down Control D7-D8 - - Not Used D7 - - Not Used

C209

C209 I/P to Combo Jumper Harness Connector End Connector Part Information OEM: 12064760 Service: 12085208 4-Way F Metri-Pack 150 Series (BK) Connector Part Information OEM: 12065658 N/S 4-Way M Metri-Pack 150 Series (BK) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A L-BU/BK 590 Solar Sensor Driver Signal A L-BU/BK 590 Solar Sensor Driver Signal B GY 1548 Passenger Solar Sensor Signal B GY 1548 Passenger Solar Sensor Signal C YE 61 Outside Ambient Temperature Sensor Low Reference C YE 61 Outside Ambient Temperature Sensor Low Reference D WH 278 Ambient Light Sensor Signal D WH 278 Ambient Light Sensor Signal

Scheme 105

C212

C212 Body to Console Harness Connector End Connector Part Information OEM: 7282-3442-40 Service: NS 12-Way M YESC (GY) Connector Part Information OEM: 7283-5540-40 NS 12-Way F YESC 1.5 Series (GY) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 OG 5756 Center Console Speaker (+) (w/YQ3/YQ4/YQ6/YQ7) 1 OG 5756 Center Console Speaker (+) (w/YQ3/YQ4/YQ6/YQ7) 2 PU/WH 5715 Keyless Entry Active Antenna Supply Voltage 2 PU/WH 5715 Keyless Entry Active Antenna Supply Voltage 3 YE 1491 Backlight Lamp Control 3 YE 1491 Backlight Lamp Control 4 OG/BK 5718 Keyless Entry Active Antenna Low Reference 4 OG/BK 5718 Keyless Entry Active Antenna Low Reference 5 GY 5717 Keyless Entry Active Antenna Data Signal 5 GY 5717 Keyless Entry Active Antenna Data Signal 6 L-BU 5716 Keyless Entry Active Antenna Clock Signal 6 L-BU 5716 Keyless Entry Active Antenna Clock Signal 7 OG/BK 5766 Console Center Speaker (-) (w/YQ3/YQ4/YQ6/YQ7) 7 OG/BK 5766 Console Center Speaker (-) (w/YQ3/YQ4/YQ6/YQ7) 8 YE 18 Left Rear Stop/Turn Lamp Supply Voltage 8 YE 18 Left Rear Stop/Turn Lamp Supply Voltage 9 TN 219 Keyless Entry Antenna Low Reference (1) 9 TN 219 Keyless Entry Antenna Low Reference (1) 10 BK 450 Ground 10 BK 450 Ground 11 PU 218 Keyless Entry Antenna Signal (1) 11 PU 218 Keyless Entry Antenna Signal (1) 12 WH 111 Hazard Switch Signal 12 WH 111 Hazard Switch Signal

Scheme 106

C213

C213 Console to Body Harness Connector End (w/KA6) Connector Part Information OEM: 7283-5683-60 Service: NS 10-Way F 1.5 Series (GN) Connector Part Information OEM: 7282-5683-60 NS 10-Way M 1.5 Series (GN) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 YE 182 Heated Seat Control Module Enable Signal 1 YE 182 Heated Seat Control Module Enable Signal 2 BN 1634 Right Rear Heated Seat Switch Signal 2 BN 1634 Right Rear Heated Seat Switch Signal 3 BN 1637 Left Rear Heated Seat Switch Signal 3 BN 1637 Left Rear Heated Seat Switch Signal 4 TN/WH 1638 Left Rear Heated Seat High Indicator Control 4 TN/WH 1638 Left Rear Heated Seat High Indicator Control 5 BN/WH 6585 Left Rear Heated Seat Medium Indicator Control 5 BN/WH 6585 Left Rear Heated Seat Medium Indicator Control 6 PK 1631 Left Rear Heated Seat Low Indicator Control 6 PK 1631 Left Rear Heated Seat Low Indicator Control 7 TN/WH 1635 Right Rear Heated Seat High Indicator Control 7 TN/WH 1635 Right Rear Heated Seat High Indicator Control 8 PK 1636 Right Rear Heated Seat Low Indicator Control 8 PK 1636 Right Rear Heated Seat Low Indicator Control 9 D-BU/WH 6586 Right Rear Heated Seat Medium Indicator Control 9 D-BU/WH 6586 Right Rear Heated Seat Medium Indicator Control 10 - - Not Used 10 - - Not Used

Scheme 107

C214

C214 HVAC Motor Assembly Connector End Connector Part Information OEM: 7283-6453-60 Service: NS 16-Way F YESC 1.5 (GN) Connector Part Information OEM: 7282-5683-60 NS 16-Way M YESC 1.5 (GN) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 GY/BK 2778 Passenger Air Temperature Motor Control 1 GY/BK 2778 Passenger Air Temperature Motor Control 2 WH/BK 1236 Passenger Air Temperature Door Control 2 WH/BK 1236 Passenger Air Temperature Door Control 3 D-BU 1646 Passenger Air Temperature Door Position Signal 3 D-BU 1646 Passenger Air Temperature Door Position Signal 4 YE 1318 Lower Mode Door Control 4 YE 1318 Lower Mode Door Control 5 TN 2273 Mode Door Control 5 TN 2273 Mode Door Control 6 YE/BK 1814 Lower Mode Door Position Signal 6 YE/BK 1814 Lower Mode Door Position Signal 7 D-GN 5518 Passenger Compartment Rear Air Temperature Sensor Signal 7 D-GN 5518 Passenger Compartment Rear Air Temperature Sensor Signal 8 L-BU 5517 Passenger Compartment Rear Air Temperature Sensor Low Reference 8 L-BU 5517 Passenger Compartment Rear Air Temperature Sensor Low Reference 9 BN 5516 Passenger Compartment Rear Air Temperature Motor Control 9 BN 5516 Passenger Compartment Rear Air Temperature Motor Control 10 GY 705 5-Volt Reference 10 GY 705 5-Volt Reference 11 YE 1791 Air Temperature Door Control Low Reference 11 YE 1791 Air Temperature Door Control Low Reference 12 L-BU 733 Air Temperature Door Position Signal 12 L-BU 733 Air Temperature Door Position Signal 13 D-BU 1199 Air Temperature Door Control 13 D-BU 1199 Air Temperature Door Control 14 YE 61 Outside Ambient Temperature Sensor Low Reference 14 YE 61 Outside Ambient Temperature Sensor Low Reference 15 GY 731 A/C Refrigerant Low Temperature Sensor Signal 15 GY 731 A/C Refrigerant Low Temperature Sensor Signal 16 - - Not Used 16 - - Not Used

C276

C276 Steering Column Harness Connector End Connector Part Information OEM: 12064769 Service: NS 10-Way F Metri-Pack 150 Series (WH) Connector Part Information OEM: NS 10-Way M Metri-Pack 150 Series (WH) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A TN 28 Horn Relay Control A TN 28 Horn Relay Control B BK 350 Ground B BK 350 Ground C - - Not Used C - - Not Used D PK 1239 Run/Crank Ignition 1 Voltage D PK 1239 Run/Crank Ignition 1 Voltage E BK 350 Ground E BK 350 Ground F YE 1491 Backlight Lamp Control F YE 1491 Backlight Lamp Control G D-BU 1796 ACC Gap Adjustment/Radio Control Signal G D-BU 1796 ACC Gap Adjustment/Radio Control Signal H PU 1375 Remote Radio Control Head Accessory Voltage Supply Voltage H PU 1375 Remote Radio Control Head Accessory Voltage Supply Voltage J-K - - Not Used J-K - - Not Used

C277

C277 Steering Column Harness Connector End Connector Part Information OEM: 12064769 Service: NS 8-Way F Metri-Pack 150 Series (BU) Connector Part Information OEM: NS 8-Way M Metri-Pack 150 Series (BU) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A TN 28 Horn Relay Control A TN 28 Horn Relay Control B BK 350 Ground B BK 350 Ground C - - Not Used C - - Not Used D PK 1239 Run/Crank Ignition 1 Voltage D PK 1239 Run/Crank Ignition 1 Voltage E BK 350 Ground E BK 350 Ground F YE 1491 Backlight Lamp Control F YE 1491 Backlight Lamp Control G D-BU 1796 ACC Gap Adjustment/Radio Control Signal G D-BU 1796 ACC Gap Adjustment/Radio Control Signal H PU 1375 Remote Radio Control Head Accessory Voltage Supply Voltage H PU 1375 Remote Radio Control Head Accessory Voltage Supply Voltage

Scheme 108

C300

C300 Body to Driver Seat Harness Connector End Connector Part Information OEM: 7283-6376-30 Service: NS 26-Way F Hybrid (BK) Connector Part Information OEM: 7282-6376-30 NS 26-Way M Hybrid (GY) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 RD/WH 3740 Battery Positive Voltage 1 RD/WH 3740 Battery Positive Voltage 2 GY 791 PWM Serial Data (w/KA1/KB6) 2 GY 791 PWM Serial Data (w/KA1/KB6) 3-4 - - Not Used 3-4 - - Not Used 5 BK/WH 551 Signal Ground 5 BK/WH 551 Signal Ground 6 TN 782 Memory Seat/Mirror Sensor Low Reference (w/A45) 6 TN 782 Memory Seat/Mirror Sensor Low Reference (w/A45) 7 GY 788 Memory Mirror Position Sensor 5-Volt Reference (w/A45) 7 GY 788 Memory Mirror Position Sensor 5-Volt Reference (w/A45) 8 BK 550 Ground 8 BK 550 Ground 9 PK 5017 Driver Seat Belt Switch Low Reference 9 PK 5017 Driver Seat Belt Switch Low Reference 10 OG 5919 Driver Seat Fan Speed Control 10 OG 5919 Driver Seat Fan Speed Control 11 D-GN 5060 Low Speed GMLAN Serial Data 11 D-GN 5060 Low Speed GMLAN Serial Data 12 BK/WH 5611 Passenger Seat Belt Tension Sensor Signal 12 PU 5611 Passenger Seat Belt Tension Sensor Signal 13 PK 2077 Driver Heated Seat Element Supply Voltage (w/KA1/KB6) 13 PK 2077 Driver Heated Seat Element Supply Voltage (w/KA1/KB6) 14 RD/WH 2840 Battery Positive Voltage 14 RD/WH 2840 Battery Positive Voltage 15 - - Not Used 15 - - Not Used 16 TN/WH 238 Driver Seat Belt Switch Signal 16 TN/WH 238 Driver Seat Belt Switch Signal 17-18 - - Not Used 17-18 - - Not Used 19 OG 2154 Steering Column Tilt Motor Signal (w/A45) 19 OG/WH 2154 Steering Column Tilt Motor Signal (w/A45) 20 OG 2153 Steering Column Telescope Motor Signal (w/A45) 20 OG 2153 Steering Column Telescope Motor Signal (w/A45) 21 - - Not Used 21 - - Not Used 22 WH 790 PWM Serial Data (w/KA1/KB6) 22 WH 790 PWM Serial Data (w/KA1/KB6) 23 - - Not Used 23 - - Not Used 24 BK/WH 551 Signal Ground 24 BK/WH 551 Signal Ground 25 YE/BK 2079 Driver Heated Seat NTC Signal (w/KA1/KB6) 25 YE/BK 2079 Driver Heated Seat NTC Signal (w/KA1/KB6) 26 YE 2080 Driver Heated Seat NTC Low Reference (w/KA1/KB6) 26 YE 2080 Driver Heated Seat NTC Low Reference (w/KA1/KB6)

C301

C301 Body to Driver Seat Harness Connector End Connector Part Information OEM: 7283-6447-40 Service: NS 14-Way F YESC Hybrid (GY) Connector Part Information OEM: 7282-5622-40 NS 14-Way M YESC Hybrid (GY) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 PK 2111 Steering Column Tilt Motor Up Control 1 PK 2111 Steering Column Tilt Motor Up Control 2 - - Not Used 2 - - Not Used 3 D-GN 5757 Left Front Seat Left Speaker (+) (w/YQ3/YQ4/YQ6/YQ7) 3 D-GN 5757 Left Front Seat Left Speaker (+) (w/YQ3/YQ4/YQ6/YQ7) 4 D-GN/WH 5767 Left Front Seat Left Speaker (-) (w/YQ3/YQ4/YQ6/YQ7) 4 D-GN/WH 5767 Left Front Seat Left Speaker (-) (w/YQ3/YQ4/YQ6/YQ7) 5-6 - - Not Used 5 - - Not Used 7 L-BU 283 Driver Power Seat Rear Vertical Motor Down Control 7 L-BU 283 Driver Power Seat Rear Vertical Motor Down Control 8 OG 2098 Steering Column Telescope Motor Forward 8 OG 2098 Steering Column Telescope Motor Forward 9 - - Not Used 9 - - Not Used 10 GY 5758 Left Front Seat Right Speaker (+) (w/YQ3/YQ4/YQ6/YQ7) 10 GY 5758 Left Front Seat Right Speaker (+) (w/YQ3/YQ4/YQ6/YQ7) 11 GY/BK 5768 Left Front Seat Right Speaker (-) (w/YQ3/YQ4/YQ6/YQ7) 11 GY/BK 5768 Left Front Seat Right Speaker (-) (w/YQ3/YQ4/YQ6/YQ7) 12-13 - - Not Used 12-13 - - Not Used 14 D-BU 287 Driver Power Seat Front Vertical Motor Down Control 14 D-BU 287 Driver Power Seat Front Vertical Motor Down Control

Scheme 109

C302

C302 Body to Rear Seat Harness Connector End (w/KA6) Connector Part Information OEM: 7283-5536-40 Service: NS 16-Way F YESC/USCAR Class 3 (GY) Connector Part Information OEM: 7282-5536-40 NS 16-Way M YESC/USCAR Class 3 (L-GY) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 - - Not Used 1 - - Not Used 2 BN 1634 Right Rear Heated Seat Switch Signal 2 BN 1634 Right Rear Heated Seat Switch Signal 3 - - Not Used 3 - - Not Used 4 BN 1637 Left Rear Heated Seat Switch Signal 4 BN 1637 Left Rear Heated Seat Switch Signal 5 BN 341 Run Ignition 3 Voltage 5 BN 341 Run Ignition 3 Voltage 6 - - Not Used 6 - - Not Used 7 TN/WH 1638 Left Rear Heated Seat High Indicator Control 7 TN/WH 1638 Left Rear Heated Seat High Indicator Control 8 BN/WH 6585 Left Rear Heated Seat Medium Indicator Control 8 BN/WH 6585 Left Rear Heated Seat Medium Indicator Control 9 PK 1631 Left Rear Heated Seat Low Indicator Control 9 PK 1631 Left Rear Heated Seat Low Indicator Control 10 YE 182 Heated Seat Control Module Enable Signal 10 YE 182 Heated Seat Control Module Enable Signal 11 - - Not Used 11 - - Not Used 12 TN/WH 1635 Right Rear Heated Seat High Indicator Control 12 TN/WH 1635 Right Rear Heated Seat High Indicator Control 13 D-BU/WH 6586 Right Rear Heated Seat Medium Indicator Control 13 D-BU/WH 6586 Right Rear Heated Seat Medium Indicator Control 14 PK 1636 Right Rear Heated Seat Low Indicator Control 14 PK 1636 Right Rear Heated Seat Low Indicator Control 15 - - Not Used 15 - - Not Used 16 BK 850 Ground 16 BK 850 Ground

Scheme 110

C304

C304 Console to I/P Harness Connector End Connector Part Information OEM: 7283-6456-90 Service: NS 16-Way F YESC 1.5 (BU) Connector Part Information OEM: 7282-6456-90 NS 16-Way M YESC 1.5 (BU) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 RD/WH 2040 Battery Positive Voltage 1 RD/WH 2040 Battery Positive Voltage 2 GY 705 5-Volt Reference 2 GY 705 5-Volt Reference 2 GY 705 5-Volt Reference (w/KA6) 3 PU 722 Rear Mode Switch Signal (w/KA6) 3 PU 722 Rear Mode Switch Signal (w/KA6) 4 L-BU 733 Rear Temperature Switch Signal (w/KA6) 4 L-BU 733 Rear Temperature Switch Signal (w/KA6) 5 YE 61 Outside Ambient Temperature Sensor Low Reference 5 YE 61 Outside Ambient Temperature Sensor Low Reference 5 YE 61 Outside Ambient Temperature Sensor Low Reference (w/KA6) 6 BN/WH 1571 Traction Control Switch Signal (2) 6 BN/WH 1571 Traction Control Switch Signal (2) 7 PK 2060 Auxiliary Detection Signal (w/YQ4/YQ6/YQ7) 7 PK 2060 Auxiliary Detection Signal (w/YQ4/YQ6/YQ7) 8 GY 2599 Rear Mode Door Position Signal 8 GY 2599 Rear Mode Door Position Signal 9 L-GN/BK 5730 Rear Mode Door Control B 9 L-GN/BK 5730 Rear Mode Door Control B 10 L-GN/WH 5729 Rear Mode Door Control A 10 L-GN/WH 5729 Rear Mode Door Control A 11 BARE 814 Drain Wire (w/YQ4/YQ6/YQ7) 11 BARE 814 Drain Wire (w/YQ4/YQ6/YQ7) 12 WH 2058 Right Auxiliary Audio Signal (1) (w/YQ4/YQ6/YQ7) 12 WH 2058 Right Auxiliary Audio Signal (1) (w/YQ4/YQ6/YQ7) 13 YE 2059 Left Auxiliary Audio Signal (1) (w/YQ4/YQ6/YQ7) 13 YE 2059 Left Auxiliary Audio Signal (1) (w/YQ4/YQ6/YQ7) 14 - - Not Used 14 - - Not Used 15 PU 2056 Auxiliary Video High Signal (w/YQ3/YQ4/YQ6/YQ7) 15 PU 2056 Auxiliary Video High Signal (w/YQ3/YQ4/YQ6/YQ7) 16 BARE 814 Drain Wire (w/YQ3/YQ4/YQ6/YQ7) 16 BARE 814 Drain Wire (w/YQ3/YQ4/YQ6/YQ7)

Scheme 111

C305

C305 Body to Headliner Harness Connector End Connector Part Information OEM: 7282-6568-40 Service: NS 20-Way M (GY) Connector Part Information OEM: 7283-6388-40 NS 20-Way F (GY) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 BK/WH 851 Ground (w/TT6) 1 BK/WH 851 Ground (w/TT6) 2 BK 1489 Noise Reduction Microphone Drain Wire (w/YQ3/YQ4/YQ6/YQ7) 2 BK 1489 Noise Reduction Microphone Drain Wire (w/YQ3/YQ4/YQ6/YQ7) 3 D-GN 1488 Noise Reduction Microphone (+) (w/YQ3/YQ4/YQ6/YQ7) 3 D-GN 1488 Noise Reduction Microphone (+) (w/YQ3/YQ4/YQ6/YQ7) 4 TN/WH 1969 Headlamp High Beam Relay Control (w/TT6) 4 TN/WH 1969 Headlamp High Beam Relay Control (w/TT6) 5 D-BU 6856 Headlamp Automatic High Beam Dim Enable (w/TT6) 5 D-BU 6856 Headlamp Automatic High Beam Dim Enable (w/TT6) 6 PU 6858 Headlamp Automatic High Beam Dim Supply Voltage (w/TT6) 6 PU 6858 Headlamp Automatic High Beam Dim Supply Voltage (w/TT6) 7 L-GN 6857 Headlamp Automatic High Beam Dim Status (w/TT6) 7 L-GN 6857 Headlamp Automatic High Beam Dim Status (w/TT6) 8 BN 818 Vehicle Speed Signal (w/TT6) 8 BN 818 Vehicle Speed Signal (w/TT6) 9 WH 2370 Rear Parking Display Supply Voltage 9 WH 2370 Rear Parking Display Supply Voltage 10 OG 2371 Left Amber Indicator Control 10 OG 2371 Left Amber Indicator Control 11 D-BU 2372 Center Amber Indicator Control 11 D-BU 2372 Center Amber Indicator Control 12 GY 2373 Rear Parking Assist Red Indicator Control 12 GY 2373 Rear Parking Assist Red Indicator Control 13 YE 243 Accessory Voltage (w/CE1, UH3) 13 YE 243 Accessory Voltage (w/CE1, UH3) 14 TN 481 Rain Sense Signal (1) (w/CE1) 14 TN 481 Rain Sense Signal (1) (w/CE1) 15 L-GN 482 Rain Sense Signal (2) (w/CE1) 15 L-GN 482 Rain Sense Signal (2) (w/CE1) 16 YE 1491 Backlight Lamp Control (w/CF5) 16 YE 1491 Backlight Lamp Control (w/CF5) 17 RD/WH 3940 Battery Positive Voltage (w/UA2) 17 RD/WH 3940 Battery Positive Voltage (w/UA2) 18 PU 5059 Intrusion Sensor Alarm On Signal (w/UA2) 18 PU 5059 Intrusion Sensor Alarm On Signal (w/UA2) 19 YE 5058 Intrusion Sensor Armed Signal (w/UA2) 19 YE 5058 Intrusion Sensor Armed Signal (w/UA2) 20 - - Not Used 20 - - Not Used

Scheme 112

Scheme 113

C307

C307 Body to Front Passenger Seat Connector End Connector Part Information OEM: 7283-6376-30 Service: NS 26-Way F YESC Hybrid (BK) Connector Part Information OEM: 7282-6376-30 NS 26-Way M YESC Hybrid (GY) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 RD/WH 3740 Battery Positive Voltage 1 RD/WH 3740 Battery Positive Voltage 2 GY 791 PWM Serial Data (w/KA1/KB6) 2 GY 791 PWM Serial Data (w/KA1/KB6) 3 BN 41 Run Ignition 3 Voltage (w/KA1/KB6) 3 BN 41 Run Ignition 3 Voltage (w/KA1/KB6) 4 RD/WH 2540 Battery Positive Voltage (w/KA1/KB6) 4 RD/WH 2540 Battery Positive Voltage (w/KA1/KB6) 5-7 - - Not Used 5-7 - - Not Used 8 BK 650 Ground 8 BK 650 Ground 9 PK 5017 Driver Seat Belt Switch Low Reference 9 PK 5017 Driver Seat Belt Switch Low Reference 10 OG 5919 Driver Seat Fan Speed Control (w/KB6) 10 OG 5919 Driver Seat Fan Speed Control (w/KB6) 11 - - Not Used 11 - - Not Used 12 BK/WH 5611 Passenger Seat Belt Tension Sensor Signal 12 PU 5611 Passenger Seat Belt Tension Sensor Signal 13 PK 2077 Driver Heated Seat Element Supply Voltage (w/KA1/KB6) 13 PK 2077 Driver Heated Seat Element Supply Voltage (w/KA1/KB6) 14-15 - - Not Used 14-15 - - Not Used 16 TN/WH 238 Driver Seat Belt Switch Signal 16 TN/WH 238 Driver Seat Belt Switch Signal 17 - - Not Used 17 - - Not Used 18 YE 5759 Right Front Seat Left Speaker (+) (w/YQ3/YQ4/YQ6/YQ7) 18 YE 5759 Right Front Seat Left Speaker (+) (w/YQ3/YQ4/YQ6/YQ7) 19 YE/BK 5769 Right Front Seat Left Speaker (-) (w/YQ3/YQ4/YQ6/YQ7) 19 YE/BK 5769 Right Front Seat Left Speaker (-) (w/YQ3/YQ4/YQ6/YQ7) 20 L-GN 5760 Right Front Seat Right Speaker (+) (w/YQ3/YQ4/YQ6/YQ7) 20 L-GN 5760 Right Front Seat Right Speaker (+) (w/YQ3/YQ4/YQ6/YQ7) 21 L-GN/BK 5770 Right Front Seat Right Speaker (-) (w/YQ3/YQ4/YQ6/YQ7) 21 L-GN/BK 5770 Right Front Seat Right Speaker (-) (w/YQ3/YQ4/YQ6/YQ7) 22 WH 790 PWM Serial Data (w/KA1/KB6) 22 WH 790 PWM Serial Data (w/KA1/KB6) 23 - - Not Used 23 - - Not Used 24 BK/WH 651 Ground 24 BK/WH 651 Ground 25 YE/BK 2079 Driver Heated Seat NTC Signal (w/KA1/KB6) 25 YE/BK 2079 Driver Heated Seat NTC Signal (w/KA1/KB6) 26 YE 2080 Driver Heated Seat NTC Low Reference (w/KA1/KB6) 26 YE 2080 Driver Heated Seat NTC Low Reference (w/KA1/KB6)

C308

C308 Body to Headliner Connector End Connector Part Information OEM: 7282-6456-90 Service: NS 16-Way M YESC (BU) Connector Part Information OEM: 7283-6456-90 NS 16-Way F YESC (BU) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 YE/BK 2516 Keypad Green LED (w/UE1) 1 YE/BK 2516 Keypad Green LED (w/UE1) 2 D-GN/WH 2514 Keypad Signal (w/UE1) 2 D-GN/WH 2514 Keypad Signal (w/UE1) 3 L-GN/BK 2515 Keypad Supply Voltage (w/UE1) 3 L-GN/BK 2515 Keypad Supply Voltage (w/UE1) 4 BN/WH 2517 Keypad Red LED (w/UE1) 4 BN/WH 2517 Keypad Red LED (w/UE1) 5 GY 655 Cellular Telephone Microphone Signal 5 GY 655 Cellular Telephone Microphone Signal 6 BARE 1782 Drain Wire 6 BARE 1782 Drain Wire 7 D-BU/WH 149 Courtesy Lamp Supply Voltage 7 D-BU/WH 149 Courtesy Lamp Supply Voltage 8 GY 157 Interior Lamp Control 8 GY 157 Interior Lamp Control 9 L-GN/BK 5711 Keyless Entry Antenna Low Reference (2) 9 L-GN/BK 5711 Keyless Entry Antenna Low Reference (2) 10 L-GN 5707 Keyless Entry Antenna Signal (2) 10 L-GN 5707 Keyless Entry Antenna Signal (2) 11 PK 1691 Automatic Day/Night Mirror Low Reference 11 PK 1691 Automatic Day/Night Mirror Low Reference 12 GY 1690 Automatic Day/Night Mirror Signal 12 GY 1690 Automatic Day/Night Mirror Signal 13 PK 1339 Run/Crank Ignition 1 Voltage 13 PK 1339 Run/Crank Ignition 1 Voltage 14 L-GN 24 Backup Lamp Supply Voltage 14 L-GN 24 Backup Lamp Supply Voltage 15 BK 850 Ground 15 BK 850 Ground 16 BN 253 Trunk Release Relay Control (w/UG1) 16 BN 253 Trunk Release Relay Control (w/UG1)

C309

C309 Headliner to Sunroof Jumper Connector End (w/CF5) Connector Part Information OEM: 7282-5533-40 Service: NS 10-Way M YESC 1.5 (L-GY) Connector Part Information OEM: 7283-6456-90 NS 10-Way F YESC 1.5 (L-GY) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 - - Not Used 1 - - Not Used 2 L-BU 5027 Sunroof Switch Data (1) 2 L-BU 5027 Sunroof Switch Data (1) 3 BN 5028 Sunroof Switch Data (2) 3 BN 5028 Sunroof Switch Data (2) 4 OG 5029 Sunroof Switch Data (3) 4 OG 5029 Sunroof Switch Data (3) 5 PK 5031 Sunroof Switch Data (5) 5 PK 5031 Sunroof Switch Data (5) 6 PU 5032 Sunroof Switch Data (6) 6 PU 5032 Sunroof Switch Data (6) 7 TN 5030 Sunroof Switch Data (4) 7 TN 5030 Sunroof Switch Data (4) 8 - - - 8 RD/WH - Not Used 9 - - - 9 BU/WH - Not Used 10 - - - 10 GN/WH - Not Used

Scheme 114

C310

C310 Body to Sunroof Connector End (w/CF5) Connector Part Information OEM: 7282-5628-40 Service: NS 3-Way M YESC Hybrid (GY) Connector Part Information OEM: 7283-5628-40 NS 3-Way F YESC Class 3 (L-GY) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 BK 1050 Ground 1 BK 1050 Ground 2 TN 755 Sunroof Enable Signal 2 BK 755 Sunroof Enable Signal 3 RD/WH 2640 Battery Positive Voltage 3 D-BU 2640 Battery Positive Voltage

Scheme 115

C311

C311 Body to Automatic Transmission Shift Lever Assembly Connector End Connector Part Information OEM: 15332153 Service: 10-Way F GT 150 Series (BK) Connector Part Information OEM: 15332158 Service: 10-Way M GT 150 Series (BK) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A GN/YE 6847 Shift Select Switch Park Supply Voltage A GN/YE 6847 Shift Select Switch Park Supply Voltage B D-GN 5525 Tap Up/Tap Down Trans Enable Switch B D-GN 5525 Tap Up/Tap Down Trans Enable Switch C YE 1491 Backlight Lamps Control C YE 1491 Backlight Lamps Control D BN 41 Run Ignition 3 Voltage D BN 41 Run Ignition 3 Voltage E RD/WH 3940 Battery Positive Voltage E RD/WH 3940 Battery Positive Voltage F D-GN/WH 1932 Ignition Lock Cylinder Control Actuator Supply Voltage F D-GN/WH 1932 Ignition Lock Cylinder Control Actuator Supply Voltage G BK 450 Ground G BK 450 Ground H PU 5526 TCC Brake Switch H PU 5526 TCC Brake Switch J - - Not Used J - - Not Used K D-GN/WH 1135 A/T Shift Lock Control Solenoid Supply Voltage K D-GN/WH 1135 A/T Shift Lock Control Solenoid Supply Voltage

C315

C315 Rear Seat Heated Cushion to Heated Back Jumper Connector End (w/KA6) Connector Part Information OEM: 12064766 Service: 12101875 8-Way F Metri-Pack 150 Series (BU) Connector Part Information OEM: 12064767 N/S 8-Way M Metri-Pack 150 Series (NA) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A D-BU 9170 Return A D-BU 9170 Return B L-BU 9171 Cushion Sensor B L-BU 9171 Cushion Sensor C WH 9331 Heat Return C WH 9331 Heat Return D GY 9173 Cushion Heat Output D GY 9173 Cushion Heat Output E PK 9177 Return E PK 9177 Return F OG 9176 Cushion Sensor F OG 9176 Cushion Sensor G WH/BK 9330 Heat Return G WH/BK 9330 Heat Return H D-GN 9174 Cushion Heat Output H D-GN 9174 Cushion Heat Output

C400

C400 Body to Rear Fascia Harness Connector End Connector Part Information OEM: 15326815 Service: 15306396 4-Way F GT 150 Series Sealed 4.0 (BK) Connector Part Information OEM: 15326820 15326820 4-Way M GT 150 Series (BK) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A OG 122 Rear Fog Lamp Supply Voltage (w/TT7/TT8) A OG 122 Rear Fog Lamp Supply Voltage (w/TT7/TT8) B BK 1050 Ground B BK 1050 Ground C PU 1472 Left Park Lamp Relay Control (w/TT7/TT8) C PU 709 Left Park Lamp Supply Voltage C PU 709 Left Park Lamp Supply Voltage (w/UE1) D BN/WH 309 Right Park Lamp Supply Voltage (w/UE1) D BN/WH 309 Right Park Lamp Supply Voltage D BN/WH 1473 Right Park Lamp Supply Voltage (w/TT7/TT8)

Scheme 116

C401

C401 Body to Rear Fascia Harness Connector End (UD7) Connector Part Information OEM: 15326835 Service: 88986452 8-Way F GT 150 Series Sealed 4.0 (BK) Connector Part Information OEM: 15326840 N/S 8-Way M GT 150 Series Sealed 4.0 (BK) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A D-BU 2374 Object Sensor Supply Voltage A D-BU 2374 Object Sensor Supply Voltage B YE 2375 Left Rear Corner Object Sensor Signal B YE 2375 Left Rear Corner Object Sensor Signal C GY 2379 Object Sensor Low Reference C GY 2379 Object Sensor Low Reference D OG 2376 Left Rear Middle Object Sensor Signal D OG 2376 Left Rear Middle Object Sensor Signal E D-GN 2377 Right Rear Middle Object Sensor Signal E D-GN 2377 Right Rear Middle Object Sensor Signal F PU 2378 Right Rear Corner Object Sensor Signal F PU 2378 Right Rear Corner Object Sensor Signal G OG 5708 Keyless Entry Antenna Signal (3) G OG 5708 Keyless Entry Antenna Signal (3) H OG/BK 5712 Keyless Entry Antenna Low Reference (3) H OG/BK 5712 Keyless Entry Antenna Low Reference (3)

C402

C402 Body to Rear Fascia Connector End (UH3 or V92) Connector Part Information OEM: 15326835 Service: 88986452 8-Way F GT 150 Series Sealed 4.0 (BK) Connector Part Information OEM: 15326840 N/S 8-Way M GT 150 Series Sealed 4.0 (BK) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A L-GN/BK 5731 Tire Pressure Receiver Low Reference (w/UH3) A L-GN/BK 5731 Tire Pressure Receiver Low Reference (w/UH3) B L-BU/BK 5732 Tire Pressure Receiver Supply Voltage (w/UH3) B L-BU/BK 5732 Tire Pressure Receiver Supply Voltage (w/UH3) C YE 5736 Left Rear Tire Pressure Receiver Signal (w/UH3) C YE 5736 Left Rear Tire Pressure Receiver Signal (w/UH3) D PU 5735 Right Rear Tire Pressure Receiver Signal (w/UH3) D PU 5735 Right Rear Tire Pressure Receiver Signal (w/UH3) E YE 18 Left Rear Stop/Turn Lamp Supply Voltage (w/TT7/TT8/V92) E YE 18 Left Rear Stop/Turn Lamp Supply Voltage (w/TT7/TT8/V92) F D-GN 19 Right Rear Stop/Turn Lamp Supply Voltage (w/TT7/TT8/V92) F D-GN 19 Right Rear Stop/Turn Lamp Supply Voltage (w/TT7/TT8/V92) G L-BU 20 Stop Lamp Supply Voltage (w/TT7/TT8/V92) G L-BU 20 Stop Lamp Supply Voltage (w/TT7/TT8/V92) H BK 850 Ground (w/TT7/TT8/V92) H BK 850 Ground (w/TT7/TT8/V92)

C420

C420 Body to Fuel Tank Jumper Connector End Connector Part Information OEM: 15326661 Service: 88986245 10-Way M GT 280 Series Sealed 5.8 (BK) Connector Part Information OEM: 15326660 15326907 10-Way F GT 280 Series Sealed 5.8 (BK) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A GY 120 Fuel Pump Supply Voltage A GY 120 Fuel Pump Supply Voltage B D-GN 890 Fuel Tank Pressure Sensor Signal B D-GN 890 Fuel Tank Pressure Sensor Signal C GY 2709 Fuel Tank Pressure Sensor 5-Volt Reference C GY 2709 Fuel Tank Pressure Sensor 5-Volt Reference D WH 1310 EVAP Canister Vent Solenoid Control D WH 1310 EVAP Canister Vent Solenoid Control E TN 2759 Fuel Tank Pressure Sensor Low Reference E TN 2759 Fuel Tank Pressure Sensor Low Reference F D-BU 1936 Primary Fuel Level Sensor Signal F D-BU 1936 Primary Fuel Level Sensor Signal G L-BU 1937 Secondary Fuel Level Sensor Signal G L-BU 1937 Secondary Fuel Level Sensor Signal H - - Not Used H - - Not Used J RD/WH 1540 Battery Positive Voltage J RD/WH 1540 Battery Positive Voltage K BK 1050 Ground K BK 1050 Ground

Scheme 117

C500

C500 Body to Left Front Door Harness Connector End Connector Part Information OEM: 7283-6447-40 Service: NS 14-Way F Hybrid (BK) Connector Part Information OEM: 7282-6385-40 NS 14-Way M Hybrid (BK) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 RD/WH 1040 Battery Positive Voltage 1 RD/WH 1040 Battery Positive Voltage 2 RD/WH 640 Battery Positive Voltage 2 RD/WH 640 Battery Positive Voltage 3 PK 1691 Automatic Day/Night Mirror Low Reference 3 PK 1691 Automatic Day/Night Mirror Low Reference 4 BK/WH 351 Signal Ground 4 BK/WH 351 Ground 5 YE 1956 Left Front Tweeter Speaker (-) 5 YE 1956 Left Front Tweeter Speaker (-) 6 TN 1856 Left Front Tweeter Speaker (+) 6 TN 1856 Left Front Tweeter Speaker (+) 7 BK 350 Ground 7 BK 350 Ground 8 D-BU 5882 Left Front Door Handle Switch Signal (2) 8 D-BU 5882 Left Front Door Handle Switch Signal (2) 9 PK 5709 Keyless Entry Antenna Signal (4) 9 PK 5709 Keyless Entry Antenna Signal (4) 10 PK/BK 5713 Keyless Entry Antenna Low Reference (4) 10 PK/BK 5713 Keyless Entry Antenna Low Reference (4) 11 PU/WH 5754 Amplifier Powered Woofer Control (1) (w/YQ3/YQ4/YQ6/YQ7) 11 PU/WH 5754 Amplifier Powered Woofer Control (1) (w/YQ3/YQ4/YQ6/YQ7) 12 GY 1690 Automatic Day/Night Mirror Signal 12 GY 1690 Automatic Day/Night Mirror Signal 13 D-GN 5060 Low Speed GMLAN Serial Data 13 D-GN 5060 Low Speed GMLAN Serial Data 14 BK/WH 850 Ground (w/YQ3/YQ4/YQ6/YQ7) 14 BK/WH 850 Ground (w/YQ3/YQ4/YQ6/YQ7)

Scheme 118

C501

C501 LF Door to LF Door Trim Harness Connector End Connector Part Information OEM: 7283-4848-30 Service: NS 12-Way F Dock and Lock (BK) Connector Part Information OEM: 7282-4848-30 NS 12-Way M Dock and Lock (BK) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 D-GN 5060 Low Speed GMLAN Serial Data 1 D-GN 5060 Low Speed GMLAN Serial Data 2 RD/WH 640 Battery Positive Voltage 2 RD/WH 640 Battery Positive Voltage 3 - - Not Used 3 - - Not Used 4 PU/WH 5754 Amplifier Powered Woofer Control (1) 4 PU/WH 5754 Amplifier Powered Woofer Control (1) 5 L-BU/WH 6576 Driver Door Courtesy Lamp Control Low 5 L-BU/WH 6576 Driver Door Courtesy Lamp Control Low 6 YE 1491 Backlight Lamp Control 6 YE 1491 Backlight Lamp Control 7 PK/BK 5968 Driver Door Lock Status Indicator Signal Ground 7 PK/BK 5968 Driver Door Lock Status Indicator Signal Ground 8 PU/WH 5965 Driver Door Lock Status Indicator Supply Voltage 8 PU/WH 5965 Driver Door Lock Status Indicator Supply Voltage 9 BK/WH 351 Signal Ground 9 BK/WH 351 Signal Ground 10-12 - - Not Used 10-12 - - Not Used

Scheme 119

Scheme 120

C502

C502 LF Door to LF Handle Jumper Connector End Connector Part Information OEM: 7283-5553-10 Service: NS 6-Way F YESC 1.5 (D-GY) Connector Part Information OEM: 7282-5553-10 NS 6-Way M YESC 1.5 (D-GY) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 PK 5709 Keyless Entry Antenna Signal (4) 1 PK 5709 Keyless Entry Antenna Signal (4) 2 PK/BK 5713 Keyless Entry Antenna Low Reference (4) 2 PK/BK 5713 Keyless Entry Antenna Low Reference (4) 3 BK/WH 351 Ground 3 BK/WH 351 Ground 4 BN 5881 Left Front Door Handle Switch Signal (3) 4 BN 5881 Left Front Door Handle Switch Signal (3) 5 D-BU 5882 Left Front Door Handle Switch Signal (2) 5 D-BU 5882 Left Front Door Handle Switch Signal (2) 6 BK/WH 351 Ground 6 BK/WH 351 Ground

C600

C600 Body to RF Door Harness Connector End Connector Part Information OEM: 7283-5622-40 Service: NS 14-Way F Hybrid (BK) Connector Part Information OEM: 7282-6385-40 NS 14-Way M Hybrid (BK) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 RD/WH 1040 Battery Positive Voltage 1 RD/WH 1040 Battery Positive Voltage 2 RD/WH 740 Battery Positive Voltage 2 RD/WH 740 Battery Positive Voltage 3 - - Not Used 3 - - Not Used 4 BK/WH 451 Signal Ground 4 BK/WH 451 Ground 5 PU 1952 Right Front Tweeter Speaker (-) 5 PU 1952 Right Front Tweeter Speaker (-) 6 L-GN 1852 Right Front Tweeter Speaker (+) 6 L-GN 1852 Right Front Tweeter Speaker (+) 7 BK 450 Ground 7 BK 450 Ground 8 PK 5879 Right Front Door Handle Switch Signal (2) 8 PK 5879 Right Front Door Handle Switch Signal (2) 9 YE 5710 Keyless Entry Antenna Signal (5) 9 YE 5710 Keyless Entry Antenna Signal (5) 10 YE/BK 5714 Keyless Entry Antenna Low Reference (5) 10 YE/BK 5714 Keyless Entry Antenna Low Reference (5) 11 PK/BK 5755 Amplifier Powered Woofer Control (2) (w/YQ3/YQ4/YQ6/YQ7) 11 PK/BK 5755 Amplifier Powered Woofer Control (2) (w/YQ3/YQ4/YQ6/YQ7) 12 - - Not Used 12 - - Not Used 13 D-GN 5060 Low Speed GMLAN Serial Data 13 D-GN 5060 Low Speed GMLAN Serial Data 14 BK/WH 850 Ground (w/YQ3/YQ4/YQ6/YQ7) 14 BK/WH 850 Ground (w/YQ3/YQ4/YQ6/YQ7)

C601

C601 RF Door to RF Door Trim Harness Connector End Connector Part Information OEM: 7283-4848-30 Service: NS 12-Way F Dock and Lock (BK) Connector Part Information OEM: 7282-4848-30 NS 12-Way M Dock and Lock (BK) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 PU/WH 5754 Amplifier Powered Woofer Control (1) 1 PU/WH 5754 Amplifier Powered Woofer Control (1) 2 L-BU/WH 6576 Driver Door Courtesy Lamp Control Low 2 L-BU/WH 6576 Driver Door Courtesy Lamp Control Low 3 YE 1491 Backlight Lamp Control 3 YE 1491 Backlight Lamp Control 3 YE 1491 Backlight Lamp Control 4 OG 1189 Power Window Switch Right Front Low Reference 4 OG 1189 Power Window Switch Right Front Low Reference 5 WH 1185 Power Window Switch Left Rear Up Signal 5 WH 1185 Power Window Switch Left Rear Up Signal 6 L-BU 244 Passenger Door Lock Switch Lock Control 6 L-BU 244 Passenger Door Lock Switch Lock Control 7 D-BU 245 Passenger Door Lock Switch Unlock Control 7 D-BU 245 Passenger Door Lock Switch Unlock Control 8 PU 2765 Power Window Switch Right Front Express Signal 8 PU 2765 Power Window Switch Right Front Express Signal 9 PU 5971 Passenger Door Lock Status Indicator Signal Ground 9 PU 5971 Passenger Door Lock Status Indicator Signal Ground 10 PU/WH 5967 Passenger Door Lock Status Indicator Supply Voltage 10 PU/WH 5967 Passenger Door Lock Status Indicator Supply Voltage 11 - - Not Used 11 - - Not Used 12 BK/WH 451 Ground 12 BK/WH 451 Ground

C602

C602 RF Door to RF Handle Jumper Connector End Connector Part Information OEM: 7283-5553-10 Service: NS 6-Way F YESC 1.5 (D-GY) Connector Part Information OEM: 7282-5553-10 NS 6-Way M YESC 1.5 (D-GY) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 YE 5710 Keyless Entry Antenna Signal (5) 1 YE 5710 Keyless Entry Antenna Signal (5) 2 YE/BK 5714 Keyless Entry Antenna Low Reference (5) 2 YE/BK 5714 Keyless Entry Antenna Low Reference (5) 3 BK/WH 451 Ground 3 BK/WH 451 Ground 4 GY 5878 Right Front Door Handle Switch Signal (3) 4 GY 5878 Right Front Door Handle Switch Signal (3) 5 PK 5879 Right Front Door Handle Switch Signal (2) 5 GY 5879 Right Front Door Handle Switch Signal (2) 6 BK/WH 451 Ground 6 D-GN 451 Ground

C700

C700 Body to LR Door Harness Connector End Connector Part Information OEM: 7283-6447-40 Service: NS 14-Way F Hybrid (GY) Connector Part Information OEM: 7282-6385-40 NS 14-Way M Hybrid (GY) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 RD/WH 1040 Battery Positive Voltage 1 RD/WH 1040 Battery Positive Voltage 2 RD/WH 840 Battery Positive Voltage 2 RD/WH 840 Battery Positive Voltage 3 - - Not Used 3 - - Not Used 4 BK/WH 351 Ground 4 BK/WH 351 Signal Ground 5 WH 1959 Left Rear Midrange Speaker (-) 5 WH 1959 Left Rear Midrange Speaker (-) 6 TN 1859 Left Rear Midrange Speaker (+) 6 TN 1859 Left Rear Midrange Speaker (+) 7 BK 350 Ground 7 BK 350 Ground 8-10 - - Not Used 8-10 - - Not Used 11 D-BU/WH 149 Courtesy Lamp Supply Voltage 11 D-BU/WH 149 Courtesy Lamp Supply Voltage 12 GY 157 Interior Lamp Control 12 GY 157 Interior Lamp Control 13 D-GN 5060 Low Speed GMLAN Serial Data 13 D-GN 5060 Low Speed GMLAN Serial Data 14 - - Not Used 14 - - Not Used

C701

C701 LR Door to LR Door Trim Harness Connector End Connector Part Information OEM: 7283-4848-30 Service: NS 12-Way F Dock and Lock (BK) Connector Part Information OEM: 7282-4848-30 NS 12-Way M Dock and Lock (BK) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 D-BU/WH 149 Courtesy Lamp Supply Voltage 1 D-BU/WH 149 Courtesy Lamp Supply Voltage 2 GY 157 Interior Lamp Control 2 GY 157 Interior Lamp Control 3 YE 1491 Backlight Lamp Control 3 YE 1491 Backlight Lamp Control 4 BK/WH 351 Ground 4 BK/WH 351 Ground 5 YE 1187 Power Window Switch Left Rear Down Signal 5 YE 1187 Power Window Switch Left Rear Down Signal 6 TN 1859 Left Rear Midrange Speaker (+) 6 TN 1859 Left Rear Midrange Speaker (+) 7 WH 1959 Left Rear Midrange Speaker (-) 7 WH 1959 Left Rear Midrange Speaker (-) 8 D-GN 1184 Power Window Switch Right Front Up Signal 8 D-GN 1184 Power Window Switch Right Front Up Signal 9 D-GN 5048 Power Window Switch Left Rear Express Signal 9 D-GN 5048 Power Window Switch Left Rear Express Signal 10-12 - - Not Used 10-12 - - Not Used

C800

C800 Body to RR Door Harness Connector End Connector Part Information OEM: 7283-6447-40 Service: NS 14-Way F Hybrid (GY) Connector Part Information OEM: 7282-6385-40 NS 14-Way M Hybrid (GY) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 RD/WH 1040 Battery Positive Voltage 1 RD/WH 1040 Battery Positive Voltage 2 RD/WH 840 Battery Positive Voltage 2 RD/WH 840 Battery Positive Voltage 3 - - Not Used 3 - - Not Used 4 BK/WH 451 Ground 4 BK/WH 451 Signal Ground 5 OG 1955 Right Rear Midrange Speaker (-) 5 OG 1955 Right Rear Midrange Speaker (-) 6 TN 1855 Right Rear Midrange Speaker (+) 6 TN 1855 Right Rear Midrange Speaker (+) 7 BK 450 Ground 7 BK 450 Ground 8-10 - - Not Used 8-10 - - Not Used 11 D-BU/WH 149 Courtesy Lamp Supply Voltage 11 D-BU/WH 149 Courtesy Lamp Supply Voltage 12 GY 157 Interior Lamp Control 12 GY 157 Interior Lamp Control 13 D-GN 5060 Low Speed GMLAN Serial Data 13 D-GN 5060 Low Speed GMLAN Serial Data 14 - - Not Used 14 - - Not Used

C801

C801 RR Door to RR Door Trim Harness Connector End Connector Part Information OEM: 7283-4848-30 Service: NS 12-Way F Dock and Lock (BK) Connector Part Information OEM: 7282-4848-30 NS 12-Way M Dock and Lock (BK) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 D-BU/WH 149 Courtesy Lamp Supply Voltage 1 D-BU/WH 149 Courtesy Lamp Supply Voltage 2 GY 157 Interior Lamp Control 2 GY 157 Interior Lamp Control 3 YE 1491 Backlight Lamp Control 3 YE 1491 Backlight Lamp Control 4 BK/WH 451 Ground 4 BK/WH 451 Ground 5 OG 1189 Power Window Switch Left Rear Down Signal 5 OG 1189 Power Window Switch Left Rear Down Signal 6 TN 1855 Right Rear Midrange Speaker (+) 6 TN 1855 Right Rear Midrange Speaker (+) 7 OG 1955 Right Rear Midrange Speaker (-) 7 OG 1955 Right Rear Midrange Speaker (-) 8 WH 1185 Power Window Switch Right Rear Up Signal 8 WH 1185 Power Window Switch Right Rear Up Signal 9 D-GN 5049 Power Window Switch Right Rear Express Signal 9 D-GN 5049 Power Window Switch Right Rear Express Signal 10-12 - - Not Used 10-12 - - Not Used

SP100

Splice Pack SP100 Connector End (K59/TT6) Connector Part Information OEM: 7283-1081-10 8-Way F (BK) Pin Wire Color Circuit No. Function 1 TN/BK 2500 High Speed GMLAN Serial Data (+) (1) (w/K59) 2 - - Not Used 3 TN 2501 High Speed GMLAN Serial Data (-) (1) (w/TT6, K59, TT7/TT8) 4 TN 2501 High Speed GMLAN Serial Data (-) (1) (w/TT6, K59, TT7/TT8) 5 TN/BK 2500 High Speed GMLAN Serial Data (+) (1) (w/TT6, K59, TT7/TT8) 6 TN/BK 2500 High Speed GMLAN Serial Data (+) (1) (w/TT6, K59, TT7/TT8) 7 TN 2501 High Speed GMLAN Serial Data (-) (1) (w/K59) 8 - - Not Used

SP201

Splice Pack SP201 Connector End Connector Part Information OEM: 7123-1509 Service: See Catalog 33-Way F (WH) Indexing May Vary Pin Wire Color Circuit No. Function 1 BK/WH 351 Ground 2 - - Not Used 3 BK/WH 351 Ground 4 BK/WH 351 Ground 5 BK/WH 351 Ground 6 BK/WH 351 Ground (w/UV6) 7 - - Not Used 8 PK 3 Run/Crank Ignition 1 Voltage 9 - - Not Used 10 PK 3 Run/Crank Ignition 1 Voltage 11 PK 3 Run/Crank Ignition 1 Voltage 12 D-GN 5060 Low Speed GMLAN Serial Data 13 D-GN 5060 Low Speed GMLAN Serial Data 14 D-GN 5060 Low Speed GMLAN Serial Data 15 D-GN 5060 Low Speed GMLAN Serial Data 16 D-GN 5060 Low Speed GMLAN Serial Data 17 D-GN 5060 Low Speed GMLAN Serial Data (w/UA2/UV6) 18 - - Not Used 19 D-GN 5060 Low Speed GMLAN Serial Data (w/UA2/UV6) 20 D-GN 5060 Low Speed GMLAN Serial Data (w/UA2) 21 D-GN 5060 Low Speed GMLAN Serial Data (w/UV6) 22 - - Not Used 23 YE 1491 Backlight Lamp Control 24 YE 1491 Backlight Lamp Control 25 YE 1491 Backlight Lamp Control 26 YE 1491 Backlight Lamp Control 27 YE 1491 Backlight Lamp Control 28-29 - - Not Used 30 YE 5727 High Speed GMLAN Serial Data Wake Up 31 YE 5727 High Speed GMLAN Serial Data Wake Up 32 YE 5727 High Speed GMLAN Serial Data Wake Up 33 YE 5727 High Speed GMLAN Serial Data Wake Up (w/UE1, K59, TT7/TT8)

SP300

Splice Pack SP300 Connector End Connector Part Information OEM: 7123-1509 Service: See Catalog 33-Way F (WH) Indexing May Vary Pin Wire Color Circuit No. Function 1 D-GN 5060 Low Speed GMLAN Serial Data 2 D-GN 5060 Low Speed GMLAN Serial Data 3 D-GN 5060 Low Speed GMLAN Serial Data 4 D-GN 5060 Low Speed GMLAN Serial Data 5 D-GN 5060 Low Speed GMLAN Serial Data 6 D-GN 5060 Low Speed GMLAN Serial Data 7 - - Not Used 8 D-BU/WH 149 Courtesy Lamp Supply Voltage 9 - - Not Used 10 D-BU/WH 149 Courtesy Lamp Supply Voltage 11 D-BU/WH 149 Courtesy Lamp Supply Voltage 12 D-BU/WH 149 Courtesy Lamp Supply Voltage 13 D-BU/WH 149 Courtesy Lamp Supply Voltage 14 D-BU/WH 149 Courtesy Lamp Supply Voltage 15 D-BU/WH 149 Courtesy Lamp Supply Voltage 16 D-BU/WH 149 Courtesy Lamp Supply Voltage 17 D-BU/WH 149 Courtesy Lamp Supply Voltage 18 - - Not Used 19 YE 1491 Backlight Lamp Control 20 YE 1491 Backlight Lamp Control 21 YE 1491 Backlight Lamp Control (w/CF5) 22 YE 1491 Backlight Lamp Control 23 D-GN 5060 Low Speed GMLAN Serial Data 24 D-GN 5060 Low Speed GMLAN Serial Data (w/U2K) 25 D-GN 5060 Low Speed GMLAN Serial Data 26 D-GN 5060 Low Speed GMLAN Serial Data 27 D-GN 5060 Low Speed GMLAN Serial Data 28-29 - - Not Used 30 OG 300 Run Ignition 3 Voltage 31 OG 300 Run Ignition 3 Voltage 32 OG 300 Run Ignition 3 Voltage 33 - - Not Used

SP303

Splice Pack SP303 Connector End Connector Part Information 7283-7088 18-Way F (WH) Pin Wire Color Circuit No. Function 1 PK 5017 Driver Seat Belt Switch Low Reference 2 PK 5017 Driver Seat Belt Switch Low Reference 3 GY 157 Interior Lamp Control 4 GY 157 Interior Lamp Control 5 D-GN 5060 Low Speed GMLAN Serial Data (w/UE1) 6 D-GN 5060 Low Speed GMLAN Serial Data 7 GY 157 Interior Lamp Control 8 GY 157 Interior Lamp Control 9 - - Not Used 10 PK 5017 Driver Seat Belt Switch Low Reference 11 - - Not Used 12 GY 157 Interior Lamp Control 13-14 - - Not Used 15 D-GN 5060 Low Speed GMLAN Serial Data 16 D-GN 5060 Low Speed GMLAN Serial Data 17 GY 157 Interior Lamp Control 18 GY 157 Interior Lamp Control
