Accessory Power Socket Cadillac STS I

Body Electrical 2 illustrations ~371 words

Scheme 88

Scheme 88: Cigar Lighter/Auxiliary Outlets Schematics
Scheme 88: Cigar Lighter/Auxiliary Outlets Schematics

Scheme 89

Scheme 89: Power Outlet Component Views
Scheme 89: Power Outlet Component Views
CalloutComponent Name
1Auxiliary Power Outlet - Console
2Auxiliary Audio/Video Control
3HVAC Control Module - Rear Auxiliary (KA6)
4LR Heated Seat Switch - part of the Rear Auxiliary Module
5RR Heated Seat Switch - part of the Rear Auxiliary Module
6Mode Select Switch - Auxiliary (KA6)
7Auxiliary Power Outlet - Rear
8Hazard Switch
9Traction Control Switch

Power Outlet Connector End Views

Auxiliary Power Outlet - Console Connector End Connector Part Information OEM: 12176446 Service: 3-Way F Metri-Pack 280 Series, Flexlock (BK) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function A RD/WH 2040 Battery Positive Voltage C BK 450 Ground

Auxiliary Power Outlet - Front Connector End Connector Part Information OEM: 12129489 Service: 3-Way Metri-Pack 280 Series, Flexlock (BK) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function A RD/WH 2040 Battery Positive Voltage B YE 6817 LED Backlight Dimming Control C BK 450 Ground

Auxiliary Power Outlet - Rear Connector End Connector Part Information OEM: 12129489 Service: 3-Way Metri-Pack 280 Series, Flexlock (BK) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function A RD/WH 2040 Battery Positive Voltage C BK 450 Ground

Tools Required

J 42059 Cigar Lighter Socket Remover. See Special Tools .

Removal Procedure

  1. Remove the cigar lighter fuse.
  2. Remove the cigar lighter element.
  3. Remove the cigar lighter socket by placing one side of the T portion of the tool J 42059 into the tab window and then the other should be angled into the opposite tab window, then pull the lighter socket straight out. See «Special Tools»(/cadillac/sts/i-2004-2007/remont/body-electrical/#accessory-power-socket__special-tools) .
  4. Remove the tool from the lighter socket.
  5. Pull the cigar lighter socket (3) and cigar lighter retainer (2) out of the ash tray.
  6. Disconnect the electrical connector (1) from the cigar lighter (3).
  7. Remove the cigar lighter retainer (2) from the cigar lighter socket (3).

Installation Procedure

  1. Install the cigar lighter retainer (1) to the ash tray, by pressing the retainer into place until fully seated.
  2. Connect the electrical connector (2) to cigar lighter socket (1).
  3. Align the cigar lighter (2) key way, to the key slot in the retainer ring (1).
  4. Press the cigar lighter into place until the cigar lighter socket is fully seated.
  5. Install the cigar lighter fuse.
  6. Install the cigar lighter element.

Special Tools

Special Tools Illustration Tool Number/ Description J 42059 Cigar Lighter Socket Remover
