Automatic Transmission - 5l40-e/5l50-e - (Overhaul) Cadillac STS I

Fastener Tightening Specifications

Fastener Tightening Specifications

Fluid Capacity Specifications

Fluid Capacity Specifications (5L40-E)

End Play Specifications (5L40-E)

Output Shaft End Play Chart - 5L40-E

End Play Specifications (5L50-E)

Output Shaft End Play Chart - 5L50-E

Clutch Piston Travel Specifications

Clutch Travel Specifications

Clutch Plate Selection Specifications

Clutch Plate Selection Specifications

Reverse Clutch Housing Selective Thrust Washer Specifications

Reverse Clutch Housing Thrust Washer Chart

Intermediate and Overdrive Clutch Housing Retaining Ring Specifications

Intermediate and Overdrive Clutch Housing Retainer Ring Specification

Fluid Pump Specifications

Fluid Pump Specifications

Transmission General Specifications

Transmission General Specifications

Scheme 72

Scheme 73

Scheme 74

Scheme 75

Scheme 76

Scheme 77

Scheme 78

Scheme 79

Scheme 80

Scheme 81

Scheme 82

Scheme 83

Scheme 84

Scheme 85

Scheme 86

Scheme 87

Scheme 88

Scheme 89

Scheme 90

Scheme 91

Torque Converter Assembly Removal

1. Remove the torque converter assembly (1).
2. Remove the input turbine shaft seal (430).

Holding Fixture Installation

Tools Required

J 8763-B Holding Fixture and Base. See Special Tools .

1. Install the J 8763-B onto the transmission assembly. See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .
2. Install the transmission assembly into the tool base and use the pin to lock the holding fixture in place.

Draining Transmission Fluid

1. Remove the fluid pan drain plug (63) and seal (64), and allow the transmission fluid to drain.
2. Put transmission in park.
3. Remove the prop shaft flange nut (34).
4. Remove the prop shaft flange washer (33) and seal (32).
5. Remove the prop shaft flange (31) and the output shaft assembly retainer (30).
6. Slowly rotate the transmission to a vertical position, with the bell housing facing up, and allow any excess fluid to drain.

Extension Housing Removal

1. Remove the case extension bolts (35).
2. Remove the case extension (27).
3. Remove the case extension gasket (25).
4. Remove the input and reaction carrier thrust washer (67) - some models.

Pan and Filter Assembly Removal

Tools Required

1. J 23129 Universal Seal Remover. See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .
2. J 6125-1B Slide Hammer Adapter. See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .

1. Rotate the transmission so that the fluid pan (62) is facing up.
2. Remove the fluid pan bolts (65), the fluid pan (62) and the gasket (60).
3. Remove the fluid filter (59) from the case (24).
4. Assemble J 23129 and J 6125-1B to remove the fluid filter seals (57) from the case (24). See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .

Wiring Harness Removal

1. Using a small screwdriver pry the wiring harness (55) off of the following components: Pressure Control Solenoid (357) TCC PWM Solenoid (352) 1-2 Shift Solenoid (368) 2-3 Shift Solenoid (369) 4-5 Shift Solenoid (376) Manual Shift Shaft Switch (602) Input Speed Sensor (44) Output Speed Sensor (42)
2. Remove the connector retainer (54) from the case (24).
3. Remove the wiring harness (55) from the case (24).

Control Valve Body Accumulator Assembly Removal

1. Remove the control valve body bolts (49, 51).
2. Remove the control valve body bolts (53).
3. Remove the manual shaft detent assembly (52).
4. Remove the control valve body (47) from the case (24).
5. Remove the center support fluid passage sleeve (38) and the overdrive clutch fluid passage sleeve (39) from the case (24).

Output Shaft Speed Sensor Removal

1. Remove the output speed sensor bolt (43).
2. Remove the output speed sensor (42) and spacer (41) from the case (24).

Input Speed Sensor Removal

1. Remove the input speed sensor bolt (45).
2. Remove the input speed sensor (44) from the case (24).

Torque Converter Housing Removal

1. Rotate the transmission 90 degrees so that the converter housing is facing up. Remove the torque converter housing bolts (2) from the torque converter housing (3).
2. Remove the torque converter housing assembly (3) from the case (24).
3. Remove the torque converter housing fluid seal assembly (4).
4. Remove the fluid pump cover gasket (46).

Direct and Reverse Clutch - Forward and Coast Clutch Removal

1. Remove the forward and coast clutch assembly (7) and the direct and reverse clutch assembly (6) from the case (24).
2. Lift the direct and reverse clutch assembly (6) off of the forward and coast clutch assembly (7).

Scheme 92

Remove the input sun gear shaft (8) from the case (24).

Scheme 93

Remove the direct clutch hub assembly (10) from the case (24).

Scheme 94

Remove the intermediate clutch sprag assembly (12) from the case (24).

Overdrive Clutch Housing Removal

Tools Required

J 45126 Snap Ring Pliers. See Special Tools .

1. Use J 45126 to remove the snap ring (14). See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .
2. Remove the overdrive clutch housing (15) from the case (24).

Low Clutch Sprag Removal

1. Remove the low clutch sprag (16) from the case (24).
2. Remove the low clutch roller thrust bearing (17).

Center Support Removal

Tools Required

J 45127 Center Support Removal Tool. See Special Tools .

Scheme 95

Use J 45127 to remove the center support (18) from the case (24). See Special Tools .

Input and Reaction Carrier Removal

1. Remove the input and reaction carrier (19) from the case (24).
2. Remove the input and reaction carrier thrust bearing (20) from the case (24).

Output Shaft Removal

1. Remove the output shaft assembly (21) from the case (24).
2. Remove the input and reaction carrier washer (22) some models, from the case (24).
3. Remove the input and reaction carrier thrust bearing (23) some models, from the case (24).

Parking System Components Removal

1. Rotate the transmission 90 degrees. Remove the manual shaft detent lever pin (601) from the case.
2. Remove the manual shift shaft (606) from the case.
3. Disconnect the park pawl actuator assembly (613) from the manual shaft detent lever (600).
4. Remove the manual shaft detent lever (600), spacer (615) - some models and the manual shaft shift switch assembly (602) from the case.
5. Use a small screwdriver in order to pry the manual shaft shift seal (605) from the case.
6. Remove the park pawl actuator assembly (613) from the case.
7. Remove the park pawl shaft (610), park pawl spring (611) and the park pawl (612) from the case.
8. Remove the park pawl actuator bracket bolts (609) from the case.
9. Remove the park pawl actuator brackets (607, 608) from the case.
10. Inspect the cup plug (614) for signs of leaks.

Case Assembly Inspection

1. Inspect the components that are still on the transmission case for the following conditions: Loose, cross-threaded, or damaged threads on the transmission oil cooler fittings A loose, missing, or damaged transmission name plate
2. Inspect the transmission case for the following conditions: Gasket sealing surfaces that are damaged or have porosity Bolt and screw holes that are stripped or damaged - repair with thread insert Damaged or porous case and fluid passages Damaged snap ring grooves or housing splines A loose, cross threaded, or damaged pressure test plug and fluid level hole plug

Case Components Disassemble

1. Inspect the transmission vent assembly for damage or being plugged. If the vent is damaged the torque converter housing (227) must be replaced.
2. Remove the pressure test plug (40).
3. Remove the level hole plug (36) and fluid level hole plug o-ring (37) from the case (604).

Case Components Assemble

1. Inspect the pressure test hole plug (40) and O-ring (66) for damage.
2. Install the pressure test plug (40) and O-ring (66). Tighten: Tighten the pressure test plug to 11 N.m (8 lb ft).
3. Inspect the level hole plug (36) and O-ring (37) for damage.
4. Install the transmission fluid level hole plug O-ring (37) and the transmission level hole plug (36). Tighten: Tighten the level hole plug to 20 N.m (15 lb ft).

Parking System Components Installation

Tools Required

J 44767 Seal Installer. See Special Tools .

1. Inspect the park system components for the following: Worn park pawl actuator brackets (607, 608) A damaged or bent park pawl actuator assembly (613) A damaged manual shaft detent lever (600) A damaged manual shaft shift switch assembly (602) A worn or stripped manual shaft (606) A worn or damaged park pawl shaft (610), park pawl spring (611), and park pawl (612) A worn or damaged spacer (615), - some models.
2. Install the park pawl actuator brackets (607, 608) onto the case.
3. Install the bracket bolts (609). Tighten: Tighten the bracket bolts to 22 N.m (16 lb ft).
4. Install the park pawl (612), the park pawl spring (611), and the park pawl shaft (610) into the case.
5. Install the park pawl actuator (613) into the case.
6. Assemble the shift switch assembly (602) and spacer (615) - some models onto the detent lever (600).
7. Assemble the park pawl actuator (613) into the detent lever (600).
8. Install the manual shaft (606) into the case.
9. Align the groove for the new manual shaft pin (601) with the pin hole in the detent lever/shift switch assembly.
10. Install the manual shaft pin (601) into the manual shift shaft (606).
11. Install a NEW manual shaft seal (605) onto J 44767 . See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .
12. Use a J 44767 to install the NEW manual shaft seal (605) into the case (604). See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .

Output Shaft and Rear Internal Ring Gear Disassemble

1. Remove the snap ring (563).
2. Remove the output shaft (562) from the rear internal gear (560).

Output Shaft and Rear Internal Ring Gear Assemble

1. Inspect the output shaft (562) and the rear internal gear (560) for the following: Damaged or worn bushings Damaged splines Damaged or worn snap ring (563) Damaged or worn gear teeth Damaged or worn snap ring groove Damaged or cross-threaded threads Damaged or worn bearings
2. Install the output shaft (562) onto the rear internal gear (560).
3. Install the snap ring (563) onto the rear internal ring gear (560). Be sure it is seated in the groove.
4. Rotate the transmission 90 degrees.
5. Install the output shaft assembly (21) into the case (24).

Input and Reaction Carrier Disassemble

1. Remove the snap ring (540).
2. Remove the input and reaction bearing (541).
3. Remove the 2nd clutch roller inner race bearing (542).
4. Remove the 2nd clutch sprag (549).
5. Remove the reaction internal gear flange washer (551).

Input and Reaction Carrier Assemble

Tools Required

J 36850 Assembly Lubricant

1. Inspect the reaction internal gear and the 2nd clutch sprag for the following: Damaged or worn gear teeth Damaged or worn splines
2. Inspect the input and reaction carrier for the following: Damaged or worn teeth Damaged or worn splines Worn or nicked bushings Worn or damaged bearings
3. Using J 36850 install the reaction internal gear flange washer (551).
4. Check that the 2nd clutch sprag rotation freewheels and locks up in the correct direction.
5. Install the 2nd clutch sprag (549) onto the input and reaction carrier (553).
6. Install the 2nd clutch roller inner race bearing assembly (542) onto the input and reaction carrier (553).
7. Install the input and reaction bearing assembly (541) onto the input and reaction carrier (553).
8. Install the input and reaction carrier outer ring (540) onto the input and reaction carrier (553).
9. Install the input and reaction carrier thrust bearing (20) into the case (24).
10. Install the input and reaction carrier (19) into the case (24).

Center Support Disassemble

Tools Required

J 23327 Clutch Spring Compressor

1. Remove the snap ring (510).
2. Remove the low and reverse backing plate (511).
3. Remove the clutch plates (512, 513). Refer to «Clutch Plate Selection Specifications»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__clutch-plate-selection-specifications) .
4. Remove the low and reverse apply plate (514).
5. Use J 23327 to compress the low and reverse clutch spring (516).
6. Remove the low reverse clutch spring retainer ring (515).
7. Remove J 23327 from the center support.
8. Remove the clutch spring (516) from the center support.
9. Remove the low and reverse piston (517) from the center support (518).
10. Remove the 2nd coast clutch plate retainer ring (535) from the center support (518).
11. Remove the 2nd coast clutch backing plate (534) from the center support (518).
12. Remove the clutch plates (532, 533). Refer to «Clutch Plate Selection Specifications»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__clutch-plate-selection-specifications) .
13. Remove the 2nd coast clutch spacer (531) from the center support (518).
14. Remove the 2nd coast clutch spring retainer (530).
15. Remove the 2nd coast clutch spring (529) from the center support (518).
16. Remove the 2nd coast clutch piston (528) from the center support (518).
17. Remove the retainer ring (527) from the center support (518).
18. Remove the 2nd clutch backing plate (526) from the center support (518).
19. Remove the clutch plates (524, 525) from the center support (518). Refer to «Clutch Plate Selection Specifications»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__clutch-plate-selection-specifications) .
20. Remove the 2nd clutch apply plate (523) from the center support (518).
21. Use J 23327 to compress the 2nd clutch piston spring (521).
22. Remove the retainer ring (522) from the center support (518).
23. Remove the J 23327 from the center support (518).
24. Remove the 2nd clutch piston spring (521) from the center support (518).
25. Remove the 2nd clutch piston (520) from the center support (518).

Center Support Assemble

Tools Required

1. J 23327 Clutch Spring Compressor
2. J 45127 Center Support Removal Tool. See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .
3. J 45136 Seal Protector. See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .
4. J 45140 Seal Protector. See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .
5. J-45688 Piston Installer - Pusher. See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .
6. J 46239-1 Second Coast Clutch Outer Protector. See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .
7. J 46239-2 Second Coast Clutch Inner Protector. See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .
8. J 46239-3 Second Coast Clutch Pusher. See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .
9. J-46240-1 Seal Protector. See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .
10. J 46240-2 Seal Protector. See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .

1. Inspect the center support components for the following: Plugged fluid passages Worn or damaged splines Worn or damaged pistons Worn or damaged clutch plates
2. Install J-46240-1 (2), and J 45145 (3) into the housing. See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .
3. Install the 2nd clutch piston (520).
4. Install the 2nd clutch piston spring (521) into the center support (518).
5. Use J 23327 to compress the 2nd clutch piston spring (521).
6. Install the 2nd clutch spring retainer ring (522) into the center support (518).
7. Remove J 23327 from the center support (518).
8. Install the 2nd clutch apply plate (523) into the center support (518).
9. Install the 2nd clutch plates. Start by installing the 2nd clutch plate (524) with external splines. Alternate with the 2nd clutch plate (525) with internal splines. Refer to «Clutch Plate Selection Specifications»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__clutch-plate-selection-specifications) .
10. Install the 2nd clutch backing plate (526) into the center support (518).
11. Install the 2nd clutch backing plate retainer ring (527) into the center support (518).
12. Measure the distance between the 2nd clutch backing plate and the bottom of the gage bar. Measure three times in different locations on the backing plate. Record this as H1.
13. Apply 65 PSI (448.17 kPa) of air pressure to the specified port. Measure the distance between the 2nd clutch backing plate and the bottom of the gage bar. Measure three times in different locations on the backing plate. Record this as H2.
14. Subtract H2 from H1 this is the 2nd clutch pack travel. Refer to «Clutch Piston Travel Specifications»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__clutch-piston-travel-specifications) .
15. Using J 46239-1 (3), J 46239-2 (2) and J 46239-3 (1), install the 2nd coast clutch piston (528). See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .
16. Install the 2nd coast clutch spring (529) into the center support (518).
17. Using J 23327 compress the 2nd coast clutch spring (529).
18. Install the 2nd coast clutch spring retainer (530) into the center support (518).
19. Remove J 23327 .
20. Install the 2nd coast clutch spacer (531) into the center support (518).
21. Install the 2nd coast clutch plates. Starting with the 2nd coast clutch plate (532) with external splines. Alternate with the 2nd coast clutch plate (533) with internal splines. Refer to «Clutch Plate Selection Specifications»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__clutch-plate-selection-specifications) .
22. Install the 2nd coast clutch backing plate (534).
23. Install the 2nd coast clutch backing plate retainer ring (535).
24. Measure the distance between the 2nd coast clutch backing plate and the bottom of the gage bar. Measure three times in different locations on the backing plate. Record this as H1.
25. Apply 65 PSI (448.17 kPa) of air pressure to the specified port. Measure the distance between the 2nd coast clutch backing plate and the bottom of the gage bar. Measure three times in different locations on the backing plate. Record this as H2.
26. Subtract H2 from H1 this is the 2nd coast clutch pack travel. Refer to «Clutch Piston Travel Specifications»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__clutch-piston-travel-specifications) .
27. Use the J-46240-1 (2), J-45688 (1) and the J 45136 (3) to install the low and reverse clutch piston (517) into the center support (518). See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .
28. Use J 23327 , compress the low and reverse clutch piston spring (516).
29. Install the low and reverse clutch spring retainer ring (515) into the center support (518).
30. Install the low and reverse apply plate (514) into the center support (518).
31. Install the low and reverse clutch plates. Start with the low and reverse clutch plate (513) with external splines. Alternate with the low and reverse clutch plate (512) with internal splines. Refer to «Clutch Plate Selection Specifications»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__clutch-plate-selection-specifications) .
32. Install the low and reverse clutch backing plate (511) and the retainer ring (510) into the center support (518).
33. Measure the distance between the low and reverse clutch backing plate and the bottom of the gage bar. Measure three times in different locations on the backing plate. Record this as H1.
34. Apply 65 PSI (448.17 kPa) of air pressure to the specified port. Measure the distance between the low and reverse clutch backing plate and the bottom of the gage bar. Measure three times in different locations on the backing plate. Record this as H2.
35. Subtract H2 from H1 this is the low reverse clutch pack travel. Refer to «Clutch Piston Travel Specifications»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__clutch-piston-travel-specifications) .
36. Using J 45127 install the center support (18) into the case. See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .

Low Clutch Sprag Assemble

1. Inspect the low clutch sprag for the following: Worn or damaged splines Scoring on the inside diameter of the races Wear or cracks
2. Check that the low clutch sprag rotation freewheels and locks up in the correct direction.
3. Install the low clutch roller thrust bearing (17).
4. Install the low clutch sprag (16) into the case (24).

Overdrive and Intermediate Clutch Disassemble

Tools Required

1. J 23327 Clutch Spring Compressor
2. J 44764 Clutch Spring Compressor. See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .

1. Remove the overdrive clutch retainer (480) from the overdrive clutch housing (493).
2. Remove the overdrive clutch backing plate (481) from the overdrive clutch housing (493).
3. Remove the overdrive clutch plates (482, 483). Refer to «Clutch Plate Selection Specifications»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__clutch-plate-selection-specifications) .
4. Remove the overdrive clutch spacer (484) from the overdrive clutch housing (493).
5. Use J 44764 and J 23327 to compress the overdrive clutch piston spring (486). See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .
6. Remove the overdrive clutch piston spring retainer ring (485) from the overdrive clutch housing (493).
7. Remove J 44764 and J 23327 from the overdrive clutch housing (493). See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .
8. Remove the overdrive clutch spring (486) from the overdrive clutch housing (493).
9. Remove the overdrive clutch piston (487) from the overdrive clutch housing (493).
10. Remove the intermediate clutch backing plate retainer ring (488) from the overdrive clutch housing (493).
11. Remove the intermediate clutch backing plate (489) from the overdrive clutch housing (493).
12. Remove the intermediate clutch plates (490, 491) from the overdrive clutch housing (493). Refer to «Clutch Plate Selection Specifications»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__clutch-plate-selection-specifications) .
13. Remove the intermediate clutch apply plate (492) from the overdrive clutch housing (493).
14. Use J 44764 and J 23327 to compress the intermediate clutch housing (496). See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .
15. Remove the intermediate clutch housing retainer ring (497) from the overdrive clutch housing (493).
16. Remove J 44764 and J 23327 from the overdrive clutch housing (493). See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .
17. Remove the intermediate clutch housing (496), and the intermediate clutch spring (494) from the overdrive clutch housing (493).
18. Remove the intermediate clutch piston (495) from the overdrive clutch housing (496).

Overdrive and Intermediate Clutch Assemble

Tools Required

1. J 23327 Clutch Spring Compressor
2. J 44764 Clutch Spring Compressor. See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .
3. J 45126 Snap Ring Pliers. See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .
4. J 45135 Seal Protector. See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .

1. Inspect the housing for the following: Plugged feed passages Worn or damaged splines Damaged or worn springs Damaged or worn pistons Worn or damaged clutch plates
2. Install the intermediate piston (495) into the intermediate clutch housing (496).
3. Install the intermediate clutch spring (494).
4. Install the intermediate housing (496).
5. Use J 44764 and J 23327 to compress the housing. See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .
6. Install the intermediate clutch housing retainer ring (497).
7. Remove J 44764 and J 23327 . See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .
8. Install the intermediate apply plate (492).
9. Install the intermediate clutch plates. Starting with the intermediate clutch plates (491) with external splines. Alternating with the intermediate clutch plates (490) internal splines. Refer to «Clutch Plate Selection Specifications»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__clutch-plate-selection-specifications) .
10. Install the backing plate (489).
11. Install the intermediate backing plate retainer ring (488).
12. Measure the distance between the intermediate clutch backing plate and the bottom of the gage bar. Measure three times in different locations on the backing plate. Record this as H1.
13. Apply 65 PSI (448.17 kPa) of air pressure to the specified port. Measure the distance between the intermediate clutch backing plate and the bottom of the gage bar. Measure three times in different locations on the backing plate. Record this as H2.
14. Subtract H2 from H1 this is the clutch pack travel. Refer to «Clutch Piston Travel Specifications»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__clutch-piston-travel-specifications) .
15. Use J 45135 (2) and J 44764 (1) to install the overdrive piston (487). See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .
16. Install the overdrive piston spring (486).
17. Use J 44764 and J 23327 to compress the overdrive clutch piston spring (486). See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .
18. Install the overdrive clutch spring retainer (485).
19. Remove J 44764 and J 23327 . See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .
20. Install the overdrive clutch spacer (484).
21. Install the overdrive clutch plates. Starting with the overdrive clutch plates (483) with external splines. Alternating with the overdrive clutch plates (482) with internal splines. Refer to «Clutch Plate Selection Specifications»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__clutch-plate-selection-specifications) .
22. Install the overdrive backing plate (481).
23. Install the overdrive clutch retainer ring (480).
24. Measure the distance between the overdrive clutch backing plate and the bottom of the gage bar. Measure three times in different locations on the backing plate. Record this as H1.
25. Apply 65 PSI (448.17 kPa) of air pressure to the specified port. Measure the distance between the overdrive clutch backing plate and the bottom of the gage bar. Measure three times in different locations on the backing plate. Record this as H2.
26. Subtract H2 from H1 this is the clutch pack travel. Refer to «Clutch Piston Travel Specifications»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__clutch-piston-travel-specifications) .
27. Install the overdrive clutch housing (15) into the case (24).
28. Measure the distance from the bottom of the gauge bar to the top of the overdrive and intermediate clutch. Record this as M1.
29. Measure the distance from the bottom of the gage Bar to the bottom of the intermediate and overdrive retainer ring groove in the case. Record this as M2.
30. Subtract M2 from M1. This will be dimension M.
31. Measure the intermediate and overdrive clutch housing retaining ring (14). Refer to «Intermediate and Overdrive Clutch Housing Retaining Ring Specifications»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__intermediate-and-overdrive-clutch-housing-retaining) for the correct size washer.
32. Using J 45126 install the intermediate and overdrive clutch housing retainer ring (14) into the case (24). See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .

Intermediate Clutch Sprag Inspection

1. Inspect the intermediate sprag clutch for the following conditions: Scoring Wear or cracks
2. Check that the intermediate sprag clutch rotation freewheels and locks up in the correct direction.

Intermediate Clutch Sprag Assemble

Tools Required

J 36850 Transjel Lubricant

1. Apply J 36850 to the input and reaction carrier inner shaft thrust washer (11) and install into the intermediate sprag clutch assembly (12).
2. Install the intermediate sprag clutch assembly (12) into the case (24).

Direct Clutch Hub Assemble

1. Inspect the housing for the following: Worn or damaged splines Worn or damaged bushings Wear, cracks and scoring on the shaft
2. Install the direct clutch housing hub thrust washer (9) into the housing (10).
3. Install the direct clutch housing (10) into the case (24).

Input Sun Gear Shaft Disassemble

1. Remove the forward clutch sprag outer race (459).
2. Remove the forward clutch outer race washer (458).
3. Remove the forward clutch sprag assembly retaining rings (460).
4. Remove the forward clutch sprag (461).
5. Remove the forward clutch roller inner race thrust ring (455).
6. Remove the inner bearing (456).

Input Sun Gear Shaft Assemble

1. Inspect the outer race and input shaft for the following: Worn or damaged splines Scoring inside the diameter of the race Wear or cracks
2. Inspect the sprag elements for flat spots.
3. Inspect the cage for distortion or broken ribbon tabs.
4. Inspect the inner bearing for cracks.
5. Install the inner roller bearing (456).
6. Install the new inner race thrust ring (455).
7. Install the outer race washer (458) onto the outer race (459).
8. Install the retaining rings (460) and the forward clutch sprag (461) onto the outer race (459).
9. Install the sprag assembly (460, 461, 459) onto the sun gear shaft (457).
10. Check that the forward clutch sprag rotation freewheels and locks up in the correct direction.
11. Install the input sun gear shaft (8) into the case (24).

Forward and Coast Clutch Disassemble

Tools Required

J 43074 Forward Clutch Piston Spring Compressor. See Special Tools .

1. Remove the forward clutch backing plate retainer ring (451).
2. Remove the forward clutch backing plate (450).
3. Remove the forward clutch plates (448, 449). Refer to «Clutch Plate Selection Specifications»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__clutch-plate-selection-specifications) .
4. Remove the forward apply plate (447).
5. Remove the coast clutch housing (446).
6. Remove the coast backing plate (445).
7. Remove the coast clutch plates (443, 444). Refer to «Clutch Plate Selection Specifications»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__clutch-plate-selection-specifications) .
8. Remove the coast apply plate (442).
9. Remove the coast clutch spacer plate (441).
10. Use the J 43074 to compress the forward and coast clutch spring (439). See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .
11. Remove the retainer ring (440).
12. Remove J 43074 . See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .
13. Remove the clutch spring (439).
14. Remove the coast clutch piston (438).
15. Remove the forward clutch piston (436).
16. Remove the input shaft fluid seal (431).
17. Remove the input shaft fluid seals (432).

Forward and Coast Clutch Assemble

Tools Required

1. J 43074 Forward Clutch Piston Spring Compressor. See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .
2. J 45130-1 Seal Installer Sizer. See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .
3. J 45130-2 Seal Installer Pusher. See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .
4. J 45130-3 Seal Protector. See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .
5. J 45132 Seal Protector. See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .
6. J 45134 Seal Protector. See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .

1. Inspect the forward clutch housing (433) for the following: Plugged feed passages Damaged ball check valve (434) Worn or damaged splines Seal ring groove nicks or burrs Cracked or blocked fluid passages in the input shaft Worn or damaged clutch plates
2. Inspect the input shaft fluid seals (431, 432) for worn or damaged seals.
3. Slide J 45130-3 (2) over the input shaft, and position J 45130-3 (2) at the seal groove closest to the housing. See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) . Coat J 45130-3 (2) with transmission fluid.
4. Guide a NEW seal (431) onto J 45130-3 (2) and slide the seal into the groove with J 45130-2 (1). See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .
5. Remove J 45130-3 (2). See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .
6. Install the input shaft fluid seals (432).
7. Size the seals (431, 432) with J 45130-1 . See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .
8. Leave J 45130-1 in place for at least five minutes. See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) . If possible, leave J 45130-1 in place until you install the assembly into the transmission case.
9. Inspect the forward piston and the coast clutch piston for the following: Cracks or damage to seal grooves Wear on the piston Worn or damaged clutch plates
10. Use J 45134 to install the forward clutch piston (436). See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .
11. Use J 45132 to install the coast clutch piston (438). See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .
12. Inspect the forward and coast clutch piston spring for the following: Damaged cage Distorted or missing springs
13. Install the piston spring (439).
14. Use J 43074 to compress the spring and install the retainer ring (440). See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .
15. Measure the distance from the top of the forward clutch housing to the coast clutch piston (438), record this as dimension C.
16. Measure the distance from the top of the forward clutch housing to the forward clutch piston (436), record this as dimension B.
17. Subtract dimension C from dimension B. This is now dimension A.
18. Install the coast clutch backing plate (445) into the coast clutch housing (446).
19. Install the coast clutch plates into the coast clutch housing (446). Starting with the coast clutch plate (443) with outer splines. Alternating with the coast clutch plate (444) with inner splines. Refer to «Clutch Plate Selection Specifications»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__clutch-plate-selection-specifications) .
20. Install the coast clutch apply plate into the coast clutch housing (446).
21. Install the coast clutch spacer plate (441) into the coast clutch housing (446).
22. Measure the distance from the top of the coast clutch housing (446) to the top of the coast clutch spacer plate (441), record this as dimension B.
23. Subtract dimension B from dimension A, this is clutch pack travel.
24. Install the coast clutch spacer plate (441).
25. Install the coast clutch apply plate (442).
26. Install the coast clutch plates. Starting with the coast clutch plate (443) with the outer splines. Refer to «Clutch Plate Selection Specifications»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__clutch-plate-selection-specifications) .
27. Alternating with the coast clutch plate (444) with inner splines.
28. Install the coast clutch backing plate (444).
29. Install the coast clutch housing (446).
30. Install the forward clutch apply plate (447).
31. Install the forward clutch plates. Starting with the forward clutch plate (448) with outer splines. Alternating with the forward clutch plate (449) with inner splines. Refer to «Clutch Plate Selection Specifications»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__clutch-plate-selection-specifications) .
32. Install the forward clutch backing plate (450).
33. Install the forward clutch backing plate retainer ring (451).
34. Measure the distance between the forward clutch backing plate and the bottom of the gage bar. Measure three times in different locations on the backing plate. Record this as H1.
35. Apply air pressure to the specified port. Measure the distance between the forward clutch backing plate and the bottom of the gage bar. Measure three times in different locations on the backing plate. Record this as H2.
36. Subtract H2 from H1 this is the clutch pack travel. Refer to «Clutch Piston Travel Specifications»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__clutch-piston-travel-specifications) .
37. At this time you do not install the forward and coast clutch assembly (7) into the transmission case. Set aside until told to do so.

Direct and Reverse Clutch Disassemble

Tools Required

1. J 38734 Intermediate Spring Compressor Adapter
2. J 45139 Compressor Plate. See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .

1. Remove the reverse clutch backing plate retainer (420).
2. Remove the backing plate (419).
3. Remove the clutch plates (418, 417). Refer to «Clutch Plate Selection Specifications»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__clutch-plate-selection-specifications) .
4. Remove the apply plate (416).
5. Remove the reverse clutch spacer (415).
6. Remove the direct clutch backing plate retainer ring (414).
7. Remove the backing plate (413).
8. Remove the clutch plates (412, 411). Refer to «Clutch Plate Selection Specifications»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__clutch-plate-selection-specifications) .
9. Remove the apply plate (410).
10. Use J 38734 and J 45139 to compress the direct and reverse piston spring (407). See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .
11. Remove the direct and reverse clutch spring retainer ring (409).
12. Remove J 38734 and J 45139 . See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .
13. Remove the spring retainer (408).
14. Remove the spring (407).
15. Remove the direct clutch piston (406).
16. Remove the reverse clutch piston (404).
17. Remove the reverse clutch piston inner seal (402).

Direct and Reverse Clutch Assemble

Tools Required

1. J 38734 Intermediate Spring Compressor Adapter
2. J 45133 Seal Protector. See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .
3. J 45139 Compressor Plate. See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .

1. Inspect the reverse clutch housing for the following: Plugged feed passages Worn or damaged splines Seal ring groove nicks or burrs Cracked or blocked fluid passages Worn or damaged bushing
2. Inspect the reverse clutch piston and the direct clutch piston for the following: Cracks or damage to seal grooves Wear on the piston Inner seal damage Damaged ball check valve Worn or damaged clutch plates
3. Install the reverse clutch piston inner seal (402).
4. Install the reverse clutch piston (404).
5. Install J 45133 onto the direct and reverse clutch assembly (6). See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .
6. Install the direct clutch piston (406).
7. Install the piston spring (407).
8. Install the piston spring retainer (408).
9. Use J 38734 (1) and J 45139 (2) to compress the direct and reverse piston spring. See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .
10. Install the direct and reverse clutch spring retainer ring (409).
11. Install the apply plate (410).
12. Install the clutch plates (412, 411), starting with the direct clutch plate (411) with outer splines, alternating with the direct clutch plate (412) with inner splines. Refer to «Clutch Plate Selection Specifications»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__clutch-plate-selection-specifications) .
13. Install the backing plate (413).
14. Install the backing plate retainer (414).
15. Measure the distance between the direct clutch backing plate and the bottom of the gage bar. Measure three times in different locations on the backing plate. Record this as H1.
16. Apply 65 PSI (448.17 kPa) of air pressure to the specified port. Measure the distance between the direct clutch backing plate and the bottom of the gage bar. Measure three times in different locations on the backing plate. Record this as H2.
17. Subtract H2 from H1. This is the clutch pack travel. Refer to «Clutch Piston Travel Specifications»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__clutch-piston-travel-specifications) .
18. Install the reverse clutch spacer (415).
19. Install the apply plate (416).
20. Install the clutch plates (417, 418), starting with clutch plates (417) with outer splines, alternating with clutch plates (418) with inner splines. Refer to «Clutch Plate Selection Specifications»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__clutch-plate-selection-specifications) .
21. Install the reverse clutch backing plate (419).
22. Install the reverse clutch backing plate retainer (420).
23. Measure the distance between the reverse clutch backing plate and the bottom of the gage bar. Measure three times in different locations on the backing plate. Record this as H1.
24. Apply 65 PSI (448.17 kPa) of air pressure to the specified port. Measure the distance between the reverse clutch backing plate and the bottom of the gage bar. Measure three times in different locations on the backing plate. Record this as H2.
25. Subtract H2 from H1 this is the clutch pack travel. Refer to «Clutch Piston Travel Specifications»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__clutch-piston-travel-specifications) .

Direct and Reverse Clutch - Forward and Coast Clutch Installation

1. Place the direct and reverse clutch assembly (6) onto the forward and coast clutch assembly (7).
2. Install the direct and reverse clutch assembly (6) and the forward and coast clutch assembly (7) into the case (24).

Fluid Pump Removal

1. Remove the oil pump to torque converter housing bolts (240, 241).
2. Remove the oil pump cover (202).
3. Remove the pump vane ring (221).
4. Remove the pump vanes (222).
5. Remove the pump rotor (223).
6. Remove the pump rotor guide (224).
7. Remove the pump vane ring (225).
8. Remove the pump slide spring (219).
9. Remove the pump slide (216).
10. Remove the fluid pump slide pin (231).
11. Remove the pump slide ring (220, 242).
12. Remove the fluid pump support (217) and the fluid pump slide seal (218).

Fluid Pump Disassemble

1. Remove the reverse clutch housing seal rings (200).
2. Remove the line boost valve retainer (204).
3. Remove the line boost valve bushing (206) and the line boost valve (207).
4. Remove the line boost valve bushing seal (205).
5. Remove the line boost valve spring (208) and the pressure regulator valve spring (209).
6. Remove the pressure regulator valve (210).
7. Remove the fluid pump cover screen pin (211).
8. Remove the pump cover screen (213).
9. Remove the fluid pump cover seal (212).
10. Remove the pressure relief ball pin (211).
11. Remove the pressure relief spring (238) and the pressure relief ball (239).
12. Remove the TCC control valve pin (204).
13. Remove the TCC control valve spring (234) and the TCC control valve (235).
14. Inspect the input shaft bearing (201) for the following: Damaged bearing cage Pitted bearings Scored bearings

Torque Converter Seal Removal

Tools Required

J 45000 Seal Remover. See Special Tools .

1. Remove the two bolts (228).
2. Remove the torque converter seal using J 45000 . See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .

Fluid Pump Assemble

Tools Required

J 21368 Pump Body Cover Alignment Band

1. Inspect the bushing (215) for wear - not serviceable.
2. Inspect the oil pump parts for the following: Worn, scored or gouged pump slide Cracks, wear or damage to the rotor or vanes Cuts or damage to the seals Broken priming springs
3. Inspect the oil pump housing for the following: Porosity Interconnected oil passages Damaged machined surfaces
4. Inspect the valves (207, 210, 235) and springs (208, 209, 234, 238, 219) for the following: Nicks or burrs on the valves Worn, distorted or cracked springs
5. Install the TCC control valve (235) and the TCC control valve spring (234).
6. Install the TCC control valve spring retainer (204).
7. Install the pressure relief valve (239) and spring (238).
8. Install the pressure valve spring retainer (211).
9. Install the pump cover seal (212) onto the new pump cover screen (213).
10. Install the pump cover screen (213).
11. Install the pump cover screen pin (211).
12. Install the pressure regulator valve (210), the pressure regulator valve spring (209), and the line boost valve spring (208).
13. Install the line boost valve bushing seal (205) onto the bushing (206).
14. Install the line boost valve (207) and the bushing (206).
15. Install the line boost valve bushing retainer (204).
16. Install the reverse clutch housing fluid seal rings (200).
17. Measure the distance from the bottom of the gage bar to the pump body. Refer to «Fluid Pump Specifications»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__fluid-pump-specifications) .
18. Measure the thickness of pump slide (216).
19. Select the proper size, refer to «Fluid Pump Specifications»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__fluid-pump-specifications) .
20. Measure the thickness of the pump rotor (223).
21. Select the proper size rotor refer to «Fluid Pump Specifications»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__fluid-pump-specifications) .
22. Install the fluid pump support (217), the slide seal (218) and the fluid pump slide rings (220), and the fluid pump slide o-ring seal (242) onto the pump slide (216).
23. Install the slide pin (231).
24. Install the pump slide (216).
25. Using a screwdriver install the slide spring (219).
26. Install the fluid pump vane ring (225).
27. Install the pump rotor guide (224).
28. Install the pump rotor (223).
29. Install the pump vanes (222).
30. Install the pump vane ring (221).
31. Install the pump cover housing (202) onto the converter housing (224).
32. Install J 21368 and tighten.
33. Install the oil pump housing bolts (240, 241). Tighten: Tighten the fluid pump housing bolts (240) to 11 N.m (8 lb ft). Tighten the fluid pump housing bolts (241) to 22 N.m (16 lb ft).
34. Remove J 21368 .

Torque Converter Housing Installation

Tools Required

J 36850 Transjel Lubricant

1. Measure the distance from the bottom of the gage bar to the top of the direct and reverse clutch assembly (6). Record this as dimension X. Refer to the «Reverse Clutch Housing Selective Thrust Washer Specifications»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__reverse-clutch-housing-selective-thrust-washer) to determine the correct size to use.
2. Use J 36850 to install the NEW torque converter fluid seal (4) onto the torque converter housing. Use J 36850 to install the reverse clutch housing thrust washer (5).
3. Install the NEW fluid pump cover gasket (46).
4. Install the torque converter housing (3) onto the case (24).
5. Install the torque converter housing bolts (2) and hand tighten.
6. Tighten the torque converter housing bolts in sequence. Tighten: Tighten the housing bolts to 22 N.m (16 lb ft).

Torque Converter Seal Installation

Tools Required

1. J 8092 Universal Driver Handle
2. J 44766 Seal Installer. See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .

1. Assemble J 8092 onto J 44766 . See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .
2. Install the seal (229) onto J 44766 . See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .
3. Install the NEW seal (229) into the housing (3).
4. Install the NEW seal bolts (228). Tighten: Tighten the seal bolts to 3.6 N.m (31.86 lb in).
5. Install the NEW input shaft seal (430).

Control Valve Body Accumulator Assembly Disassemble

1. Remove the 2nd clutch accumulator housing bolts (318).
2. Remove the 2nd clutch accumulator housing (333) and spring (329).
3. Remove the intermediate clutch housing bolts (318).
4. Remove the intermediate clutch accumulator housing (328), and spring (324).
5. Remove the overdrive clutch accumulator housing bolts (318).
6. Remove the overdrive clutch accumulator housing (323), and spring (319).
7. Remove the direct clutch accumulator housing bolts (318).
8. Remove the direct accumulator housing (317), and spring (313).
9. Release the piston with air pressure.
10. Remove the 2nd clutch accumulator piston (331) from the 2nd clutch accumulator housing (333).
11. Remove the 2nd clutch accumulator piston rings (332, 330).
12. Release the piston with air pressure.
13. Remove the intermediate clutch accumulator piston (326) from the intermediate clutch accumulator housing (328).
14. Remove the intermediate clutch accumulator piston fluid seal rings (325, 327).
15. Release the piston with air pressure.
16. Remove the overdrive clutch accumulator piston (321) from the overdrive clutch accumulator housing (323).
17. Remove the overdrive clutch accumulator piston fluid seal ring (320, 322).
18. Release the piston with air pressure.
19. Remove the direct accumulator housing piston (315) from the direct accumulator housing (317).
20. Remove the direct clutch accumulator piston fluid seal rings (314, 316).
21. Remove the control valve body bolts (50, 300).
22. Remove the control valve body channel plate (301).
23. Remove the channel plate ball check spring (302) and the gasket (303).
24. Remove the control valve body channel plate (304).
25. Remove the checkballs (306) and the gasket (305).
26. Remove the control valve body spacer plate (307).
27. Remove the filters (308, 312).
28. Remove the spacer plate gasket (309).

Rear Control Valve Body Inspection

1. Inspect the rear control valve body (365) for the following conditions: Damaged or porous casting Damaged sealing surfaces Debris in fluid passages
2. Use a small pick or screwdriver, before disassembly, to inspect the rear control valve body (365) components for the following conditions: Valves binding or sticking in their bores or bushings Broken missing or damaged springs Missing or damaged retainers Damaged solenoid valves Debris in valve line ups or solenoid valves
3. During disassembly, inspect the rear control valve body (365) for the following conditions: Worn or damaged valves, valve bores or bushings Broken, missing or damaged springs Missing or damaged retainers Damaged solenoid valves Debris in valve line ups or solenoid valve

Rear Control Valve Body Disassemble

1. Remove the 1-2 shift valve retainer (343).
2. Remove the 1-2 shift valve spring (388).
3. Remove the 1-2 shift valve (387).
4. Remove the reverse lock out valve retainer (343).
5. Remove the reverse lock out spring (386).
6. Remove the reverse lock out valve (385).
7. Remove the low pressure control valve bore retainer (384).
8. Remove the bore plug (381).
9. Remove the low pressure control valve spring (382).
10. Remove the low pressure control valve (383).
11. Remove the manual valve link retainer (380).
12. Remove the manual valve link (379).
13. Remove the manual valve link retainer (378).
14. Remove the manual valve (377).
15. Remove the 1-2 shift solenoid retainer (351).
16. Remove the 1-2 shift solenoid (368).
17. Remove the 1-2 shift control valve retainer (343).
18. Remove the 1-2 shift control valve spring (367).
19. Remove the 1-2 shift control valve (366).
20. Remove the 2-3 shift solenoid retainer (351).
21. Remove the 2-3 shift solenoid (369).
22. Remove the 2-3 shift control valve (370).
23. Remove the 2-3 shift valve (371).
24. Remove the 2-3 shift valve spring (372).
25. Remove the 4-5 shift solenoid retainer (351).
26. Remove the 4-5 shift solenoid (376).
27. Remove the 4-5 shift control valve (375).
28. Remove the 4-5 shift valve (374).
29. Remove the 4-5 shift valve spring (373).

Rear Control Valve Body Assemble

1. Install the 4-5 shift valve spring (373).
2. Install the 4-5 shift valve (374).
3. Install the 4-5 shift control valve (375).
4. Install the 4-5 shift solenoid (376).
5. Install the 4-5 shift solenoid retainer (351).
6. Install the 2-3 shift valve spring (372).
7. Install the 2-3 shift valve (371).
8. Install the 2-3 shift control valve (370).
9. Install the 2-3 shift solenoid (369).
10. Install the 2-3 shift solenoid retainer (351).
11. Install the 1-2 shift control valve (366).
12. Install the 1-2 shift control valve spring (367).
13. Install the 1-2 shift control valve retainer (343).
14. Install the 1-2 shift solenoid (368).
15. Install the 1-2 shift solenoid retainer (351).
16. Install the manual valve link retainer (380).
17. Install the manual valve link (379).
18. Install the manual valve link retainer (378).
19. Install the manual valve (377).
20. Install the low pressure control valve (383).
21. Install the low pressure control valve spring (382).
22. Install the bore plug (381).
23. Install the low pressure control valve bore retainer (384).
24. Install the reverse lock out valve (385).
25. Install the reverse lock out spring (386).
26. Install the reverse lock out valve retainer (343).
27. Install the 1-2 shift valve (387).
28. Install the 1-2 shift valve spring (388).
29. Install the 1-2 shift valve retainer (343).

Front Control Valve Body Inspection

1. Inspect the front control valve body (340) for the following conditions: Damaged or porous casting Damaged sealing surfaces Debris in fluid passages
2. Use a small pick or screwdriver, before disassembly, to inspect the front control valve body (340) components for the following conditions: Valves binding or sticking in their bores or bushings Broken missing or damaged springs Missing or damaged retainers Damaged solenoid valves Debris in valve line ups or solenoid valves
3. During disassembly, inspect the front control valve body for the following conditions: Worn or damaged valves, valve bores or bushings Broken, missing or damaged springs Missing or damaged retainers Damaged solenoid valves Debris in valve line ups or solenoid valve

Front Control Valve Body Disassemble

1. Remove the safety mode valve retainer (343).
2. Remove the safety mode valve spring (342).
3. Remove the safety mode valve (341).
4. Remove the 3-4 shift valve retainer (343).
5. Remove the 3-4 shift valve spring (344).
6. Remove the 3-4 shift valve (345).
7. Remove the 3-4 shift control valve (346).
8. Remove the TCC PWM solenoid valve retainer (351).
9. Remove the TCC PWM solenoid (352).
10. Remove the TCC regulator apply valve (348).
11. Remove the TCC regulator apply valve spring (347).
12. Remove the feed limit valve retainer (343).
13. Remove the feed limit valve spring (354).
14. Remove the feed limit valve (353).
15. Remove the pressure control solenoid retainer (351).
16. Remove the pressure control solenoid (357).

Front Control Valve Body Assemble

1. Install the pressure control solenoid (357).
2. Install the pressure control solenoid retainer (351).
3. Install the feed limit valve (353).
4. Install the feed limit valve spring (354).
5. Install the feed limit valve retainer (343).
6. Install the TCC PWM solenoid valve spring (347).
7. Install the TCC regulator apply valve (348).
8. Install the TCC PWM solenoid (352).
9. Install the TCC PWM solenoid retainer (351).
10. Install the 3-4 shift control valve (346).
11. Install the 3-4 shift valve (345).
12. Install the 3-4 shift valve spring (344).
13. Install the 3-4 shift control valve retainer (343).
14. Install the safety mode valve (341).
15. Install the safety mode valve spring (342).
16. Install the safety mode valve retainer (343).

Control Valve Body Accumulator Assembly Assemble

Tools Required

1. J 36850 Transjel Lubricant
2. J 39068 Valve Body Guide Pins. See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .

1. Install J 39068 onto the front and rear control valve bodies. See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .
2. Install the NEW control valve body spacer plate gasket (309) onto the valve bodies.
3. Install the new solenoid valve filter assemblies (308, 312) onto the control valve body spacer plate (307).
4. Install the control valve body spacer plate (307) onto the valve bodies.
5. Use J 36850 to install the 12 checkballs (306) onto the spacer plate (304).
6. Install the new control valve body gasket (305) onto the spacer plate (307).
7. Install the control valve body channel plate (304).
8. Use J 36850 to install the control valve channel plate check ball spring (302) onto the channel plate (304).
9. Install the NEW control valve body channel plate gasket (303) onto the channel plate (304).
10. Install the control valve channel plate (301) onto the channel plate gasket (303).
11. Install the control valve body bolts (50, 300) into the valve body. Tighten: Tighten the control valve body bolts (50, 300) to 11 N.m (8 lb ft).
12. Remove the J 39068 from the valve body (47). See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .
13. Install the direct clutch accumulator piston fluid seal rings (314, 316) onto the direct clutch accumulator piston (315).
14. Install the direct clutch accumulator piston (315) into the direct clutch accumulator housing (317).
15. Install the overdrive clutch accumulator piston fluid seal rings (320, 322) onto the overdrive clutch accumulator piston (321).
16. Install the overdrive accumulator piston (321) into the overdrive clutch accumulator housing (323).
17. Install the intermediate clutch accumulator fluid seal rings (325, 327) onto the intermediate clutch accumulator piston (326).
18. Install the intermediate clutch accumulator piston (326) into the intermediate clutch accumulator housing (328).
19. Install the 2nd clutch accumulator piston fluid seal rings (330, 332) onto the 2nd clutch accumulator piston (331).
20. Install the 2nd clutch accumulator piston (331) into the 2nd clutch accumulator housing (333).
21. Install the direct clutch accumulator spring (313).
22. Install the direct clutch accumulator housing (317) onto the valve body (47).
23. Install the direct clutch accumulator housing bolts (318) into the valve body (47). Tighten: Tighten the accumulator housing bolts (318) to 11 N.m (8 lb ft).
24. Install the overdrive clutch accumulator spring (319).
25. Install the overdrive clutch accumulator housing (323) onto the valve body.
26. Install the overdrive clutch accumulator housing bolts (318) into the valve body. Tighten: Tighten the accumulator housing bolts (318) to 11 N.m (8 lb ft).
27. Install the intermediate clutch accumulator spring (324).
28. Install the intermediate clutch accumulator housing (328) onto the valve body.
29. Install the intermediate clutch accumulator housing bolts (318) into the valve body. Tighten: Tighten the accumulator housing bolts (318) to 11 N.m (8 lb ft).
30. Install the 2nd clutch accumulator spring (329).
31. Install the 2nd clutch accumulator housing (333) onto the valve body.
32. Install the 2nd clutch accumulator housing bolts (318) into the valve body. Tighten: Tighten the accumulator housing bolts (318) to 11 N.m (8 lb ft).

Input Speed Sensor Installation

1. Rotate the transmission 90 degrees.
2. Install the input speed sensor (44) into the case (24).
3. Install the input speed sensor bolt (45) into the case (24). Tighten: Tighten the input speed sensor bolt (45) to 11 N.m (8 lb ft).

Output Shaft Speed Sensor Installation

1. Install the output speed sensor (42) into the case.
2. Install the output speed sensor bolt (43) into the case. Tighten: Tighten the output speed sensor bolt (43) to 11 N.m (8 lb ft).

Control Valve Body Accumulator Assembly Installation

1. Install the NEW overdrive clutch fluid passage sleeve (39) into the case (24).
2. Install the NEW center support fluid passage sleeve (38) into the case (24).
3. Install the control valve body accumulator assembly (47) onto the case (24).
4. Install the detent lever spring (52) onto the case (24).
5. Install the control valve body bolts (53) into the case (24) and hand tighten.
6. Install the control valve body accumulator assembly bolts (49, 51) into the case (24) and hand tighten.
7. Tighten the control valve body accumulator bolts (49, 50, 51) in sequence. Tighten: Tighten the control valve body accumulator bolts (49, 50, 51) to 11 N.m (8 lb ft).
8. Install a 0.8 mm spacer (1) between the manual shaft detent lever (600) and the manual shaft detent assembly (52).
9. Tighten the detent assembly bolts (53). Tighten: Tighten the control valve body bolts (53) to 11 N.m (8 lb ft).
10. Remove the spacer (1).

Wiring Harness Installation

1. Install the wiring harness connector (55) thru the case (24). Hold the connector and install the wiring harness connector retainer (54).
2. Route the harness to the valve body and connect the following components: Pressure Control Solenoid (357) TCC PWM Solenoid (352) 1-2 Shift Solenoid (368) 2-3 Shift Solenoid (369) 4-5 Shift Solenoid (376) Internal Mode Switch - IMS (602) Input Speed Sensor (44) Output Speed Sensor (42)

Pan and Filter Assembly Installation

1. Inspect the following components: Transmission fluid pan for distortion, cracks, score marks Inspect the fluid pan bolts for thread damage Inspect the transmission pan magnet for cracks and tears
2. Install the transmission fluid filter (59) and fluid filters seals (57) into the case (24).
3. Install the drain plug seal (64) into the fluid pan drain plug (63).
4. Install the fluid pan drain plug (63). Tighten: Tighten the fluid pan drain plug to 20 N.m (15 lb ft).
5. Install the fluid pan magnet (61) onto the fluid pan (62).
6. Install the NEW fluid pan gasket (60) onto the fluid pan (62).
7. Install the fluid pan (62) onto the case.
8. Install the fluid pan bolts (65) into the case Tighten: Tighten the fluid pan bolts to 11 N.m (8 lb ft).

Extension Housing Installation (5L40-E/5L50-E 2WD Excluding XLR)

Tools Required

J 44765 Seal Installer. See Special Tools .

1. Inspect both inner and outer output shaft bearings for the following: Damaged cage Roller pitted
2. If either bearing is damaged replace extension housing.
3. Rotate the transmission 90 degrees.
4. Measure from the bottom to the face of the output shaft. Record this as dimension B. Refer to the «End Play Specifications (5L40-E)»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__end-play-specifications-5l40-e) or «End Play Specifications (5L50-E)»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__end-play-specifications-5l50-e) to determine the correct washer size.
5. Install the input and reaction carrier washer (22).
6. Install the input and reaction carrier thrust bearing (23) onto the extension housing.
7. Install the extension housing gasket (25) onto the extension housing (27).
8. Install the extension housing (27) onto the case.
9. Install the extension housing bolts (35). Tighten: Tighten the extension housing bolts to 22 N.m (16 lb ft).
10. Using J 44765 install the prop shaft flange seal (29). See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .

Extension Housing Installation (5L40-E/5L50-E AWD Including XLR)

Tools Required

J 44765 Seal Installer. See Special Tools .

1. Inspect both inner and outer output shaft bearings for the following: Damaged cage Roller pitted
2. If either bearing is damaged, replace the extension housing.
3. Rotate the transmission 90 degrees.
4. Measure from the bottom to the face of the bearing. Record this as dimension B. Refer to the «End Play Specifications (5L40-E)»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__end-play-specifications-5l40-e) or «End Play Specifications (5L50-E)»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__end-play-specifications-5l50-e) to determine the correct washer size.
5. Install the extension housing gasket (25) onto the extension housing (27).
6. Install the extension housing (27) onto the case.
7. Install the extension housing bolts (35). Tighten: Tighten the extension housing bolts to 22 N.m (16 lb ft).
8. Using J 44765 install the prop shaft flange seal (29) - 5L40-E/5L50-E AWD. See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .
9. Using J 46741 install the prop shaft flange seal (68) - XLR only. See «Special Tools»(/cadillac/sts/i-2004-2007/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-overhaul__special-tools) .

Prop Flange Assemble

1. Install the NEW output shaft assembly retainer (30).
2. Install the NEW prop shaft flange o-ring seal (32) into the prop shaft flange (31).
3. Install the prop shaft flange (31).
4. Put the transmission in Park.
5. Install the NEW prop shaft flange thrust washer (33) and NEW prop shaft flange nut (34) using GM P/N 89021297. Tighten: Tighten the prop shaft flange nut (34) to 57 N.m (42 lb ft).

Scheme 96

Remove J 8763-B from the transmission. See Special Tools .

Torque Converter Assembly Installation

1. Install the turbine shaft seal (430).
2. Install the torque converter assembly (1).

Park - Engine Running

When the gear selector lever is in the Park (P) position and the engine is running, fluid is drawn into the oil pump and line pressure is directed to the pressure regulator valve.

Scheme 97

Reverse

When the gear selector lever is moved to the Reverse (R) position - from the Park position, the following changes occur in the transmission's hydraulic and electrical systems

Reverse Clutch Applies

Scheme 98

Neutral - Engine Running

When the gear selector lever is moved to the Neutral (N) position, the hydraulic and electrical system operation is identical to Park (P) range. However, if Neutral is selected after the vehicle was operating in Reverse (R), the following changes would occur in the hydraulic system

Low and Reverse Clutch Releases

Scheme 99

Overdrive Range, First Gear (Before First 1-2 Shift)

When the gear selector lever is moved to the Overdrive range position (D), from the Neutral (N) position, before the first 1-2 shift has occurred, the following changes occur to shift the transmission into Overdrive Range - First Gear.

Scheme 100

Overdrive Range, First Gear (After First 1-2 Shift)

When the gear selector lever is moved to the Overdrive range position (D), from the Neutral (N) position, after the first 1-2 shift has occurred, the following changes occur to shift the transmission into Overdrive Range - First Gear.

Scheme 101

Overdrive Range, Second Gear

As vehicle speed increases, the transmission control module (TCM) receives input signals from both the input and output speed sensors, the throttle position (TP) sensor and other vehicle sensors to determine the precise moment to energize or "turn ON" the 1-2 shift solenoid (SS) valve.

Scheme 102

Overdrive Range, Third Gear

As vehicle speed increases, the TCM receives input signals from both speed sensors, the TP sensor and other vehicle sensors to determine the precise moment to de-energize or "turn OFF" the 2-3 shift solenoid (SS) valve. The 2-3 solenoid is OFF when the TCM removes the path to ground for that electrical circuit. This allows 2-3 signal fluid to exhaust at the 2-3 SS valve.

Scheme 103

Overdrive Range, Fourth Gear

As vehicle speed increases, the TCM receives input signals from both speed sensors, the TP sensor and other vehicle sensors to determine the precise moment to de-energize or "turn OFF'" the 1-2 shift solenoid (SS) valve, and to energize or "turn ON" the 4-5 SS valve.

Scheme 104

Overdrive Range, Fifth Gear - Torque Converter Clutch (TCC) Released

Overdrive Range - Fifth Gear is used to maximize engine efficiency and fuel economy under most normal driving conditions. In order to shift the transmission into Fifth gear, the TCM receives input signals from both speed sensors, the TP sensor and other vehicle sensors to determine the precise moment to de-energize or "turn OFF" the 4-5 shift solenoid (SS) valve.

Scheme 105

Overdrive Range, Fifth Gear - Torque Converter Clutch (TCC) Applied

When the TCC pressure plate is applied, it is held against the torque converter cover. Since it is splined to the converter turbine hub, it provides a mechanical coupling - direct drive of the engine to the transmission gear sets. This mechanical coupling eliminates the small amount of slippage that occurs in the fluid coupling of a torque converter, resulting in a more efficient transfer of engine torque through the transmission and to the drive wheels.

Scheme 106

Manual Fourth Gear

Manual Fourth - Fourth Gear - Drive Range may be selected at any time while the vehicle is being operated in a forward gear range. However, TCM control prevents the transmission from shifting into Fifth gear. When the gear selector lever is moved to Drive Range (4) from Overdrive Range (D), the manual valve also moves. Changes to the hydraulic and electrical systems are as follows

Coast Clutch Applies

In Manual Fourth - Fourth Gear, the TCC will not release if Manual Fourth was selected while the vehicle was operating in Overdrive Range - Fifth Gear with the TCC applied. Under normal operating conditions, the converter clutch operates the same way in Manual Fourth - Fourth Gear as in Overdrive Range - Fourth Gear.

Scheme 107

Manual Third Gear

Manual Third - Third Gear may be selected at any time while the vehicle is being operated in a forward gear range. However, TCM control prevents the transmission from shifting above Third gear. When the gear selector lever is moved to Manual Third range from Manual Fourth - Fourth Gear, the manual valve also moves. Changes to the hydraulic and electrical systems are as follows

Shift Accumulation

In Manual Third - Third Gear, the TCC will not release if Manual Third was selected while the vehicle was operating in Overdrive Range - Fifth Gear with the TCC applied. Under normal operating conditions, the converter clutch operates the same way in Manual Third - Third Gear as in Overdrive Range - Third Gear.

Scheme 108

Manual Second Gear

Manual Second - Second Gear may be selected at any time while the vehicle is being operated in a forward gear range. However, TCM control prevents the transmission from upshifting above Second gear. When the gear selector lever is moved to Manual Second from Manual Third - Third Gear, the manual valve also moves. Changes to the hydraulic and electrical systems are as follows

Second Coast Clutch Applied

If the converter clutch was applied when Manual Second was selected it will release during downshifting. Under normal operating conditions the converter clutch will not re-apply in Second gear.

Scheme 109

Manual Second - First Gear

Manual Second - First Gear is commanded by the TCM, when vehicle speed is low enough not to overrev the engine - calibratable in the TCM, in order to achieve maximum engine braking. Changes to the hydraulic and electrical systems are as follows

Scheme 110

Scheme 111

Scheme 112

Scheme 113

Scheme 114

Scheme 115

Scheme 116

Scheme 117

Scheme 118

Scheme 119

Scheme 120

Scheme 121

Scheme 122

Special Tools

Special Tools Illustration Tool Number/Description J 6125-1B Slide Hammer Adapter J 7079-2 Universal Driver Handle J 8092 Universal Driver Handle J 8763-02 Holding Fixture and Base J 21368 Pump Body Cover Alignment Band J 23129 Universal Seal Remover J 23327 Clutch Spring Compressor J 36850 Transjel Lubricant J 38734 Intermediate Spring Compressor Adapter J 39068 Valve Body Guide Pins J 43074 Clutch Spring Compressor J 44764 Clutch Spring Compressor J 44765 Seal Installer J 44766 Seal Installer J 44767 Seal Installer J 45000 Seal Remover J 45126 Snap Ring Pliers J 45127 Center Support Removal Tool J 45130-1 Seal Installer Sizer J 45130-2 Seal Installer Pusher J 45130-3 Seal Protector J 45132 Seal Protector J 45133 Seal Protector J 45134 Seal Protector J 45135 Seal Protector J 45136 Seal Protector J 45139 Compressor Plate J 45140 Seal Protector J 45688 Piston Installer - Pusher J 46239-1 Second Coast Clutch Outer Protector J 46239-2 Second Coast Clutch Inner Protector J 46239-3 Second Coast Clutch Pusher J 46240-1 Seal Protector J 46240-2 Seal Protector J 46741 Seal Protector

Scheme 123

Scheme 124

Scheme 125

Scheme 126

Scheme 127

Scheme 128

Scheme 129

Scheme 130

Scheme 131

Scheme 132

Scheme 133

Scheme 134

Scheme 135

Scheme 136

Scheme 137

Scheme 138

Scheme 139

Scheme 140

Scheme 141

See also:
• Special Tools
• Clutch Plate Selection Specifications
• Clutch Piston Travel Specifications
• Intermediate and Overdrive Clutch Housing Retaining Ring Specifications
• Fluid Pump Specifications
• Reverse Clutch Housing Selective Thrust Washer Specifications
• End Play Specifications (5L40-E)
• End Play Specifications (5L50-E)
