Automatic Transmission Schematic Icons
Automatic Transmission Schematic Icons Icon Icon Definition NOTE: The OBD II symbol is used on the circuit diagrams in order to alert the technician that the circuit is essential for proper OBD II emission control circuit operation. Any circuit which fails and causes the malfunction indicator lamp (MIL) to turn ON, or causes emissions-related component damage, is identified as an OBD II circuit. IMPORTANT: Twisted-pair wires provide an effective "shield" that helps protect sensitive electronic components from electrical interference. If the wires were covered with shielding, install new shielding. In order to prevent electrical interference from degrading the performance of the connected components, you must maintain the proper specification when making any repairs to the twisted-pair wires shown : The wires must be twisted a minimum of 9 turns per 31 cm (12 in) as measured anywhere along the length of the wires The outside diameter of the twisted wires must not exceed 6.0 mm
Scheme 1
Scheme 1: Automatic Transmission Schematic Icons
Scheme 2
Scheme 3
Scheme 3: Automatic Transmission Controls Schematics
Scheme 4
Scheme 5
Scheme 5: Automatic Transmission Electronic Component Views
| Callout | Component Name |
| 42 | Output Speed Sensor (OSS) |
| 44 | Input Speed Sensor (ISS) |
| 55 | Transmission Fluid Temperature (TFT) Sensor - Part of Automatic Transmission Wiring Harness (55) |
| 352 | TCC PWM Solenoid Valve |
| 357 | Pressure Control Solenoid (PCS) Assembly |
| 368 | 1-2 Shift Solenoid (SS) Valve Assembly |
| 369 | 2-3 Shift Solenoid (SS) Valve Assembly |
| 376 | 4-5 Shift Solenoid (SS) Valve Assembly |
| 602 | Transmission Manual Shift Shaft Switch Assembly |
Scheme 6
Scheme 6: Disassembled Views
| Callout | Component Name |
| 1 | Torque Converter Assembly |
| 2 | Torque Converter Housing to Main Case Bolt |
| 3 | Torque Converter Housing Assembly - Model Dependent |
| 4 | Torque Converter Housing Fluid Seal Assembly |
| 5 | Reverse Clutch Housing Thrust Washer - Selective |
| 6 | Direct and Reverse Clutch Assembly |
| 7 | Forward and Coast Clutch Assembly |
| 8 | Input Sun Gear - W/Forward Clutch Roller Inner Race Shaft |
| 9 | Direct Clutch Hub Thrust Washer |
| 10 | Direct Clutch Assembly- W/Input and Reaction Carrier in Hub |
| 11 | Input and Reaction Carrier Inner Shaft Thrust Washer |
| 12 | Intermediate Clutch Sprag Assembly |
| 14 | Intermediate and Overdrive Clutch Housing Retainer Ring - Selective |
| 15 | Overdrive Clutch Housing Assembly |
| 16 | Low Clutch Sprag Assembly |
| 17 | Low Clutch Roller Thrust Bearing |
| 18 | Center Support |
| 19 | Input and Reaction Carrier Assembly |
| 20 | Input and Reaction Carrier Thrust Bearing |
| 21 | Output Shaft Assembly W/Rear Internal Gear - Model Dependent |
| 22 | Input and Reaction Carrier Washer Selective, - Model Dependent |
| 23 | Input and Reaction Carrier Thrust Bearing |
| 24 | Automatic Transmission Case Assembly |
| 70 | Transmission Cooler Bypass Valve - Model Dependent |
| 71 | Transmission Cooler Bypass Bolt - Model Dependent |
| 72 | Transmission Cooler Bypass Seals - Model Dependent |
Scheme 7
| Callout | Component Name |
| 24 | Automatic Transmission Case Assembly |
| 25 | Automatic Transmission Case Extension Gasket - Model Dependent |
| 25 | Automatic Transmission Case Extension Gasket - Model Dependent |
| 26 | Output Shaft Bearing - Model Dependent |
| 27 | Automatic Transmission Case Extension - Model Dependent |
| 27 | Automatic Transmission Case Extension - Model Dependent |
| 28 | Output Shaft Bearing - Model Dependent |
| 28 | Output Shaft Bearing - Model Dependent |
| 29 | Automatic Transmission Prop Shaft - Model Dependent |
| 30 | Output Shaft Assembly Retainer - Model Dependent |
| 31 | Automatic Transmission Prop Shaft Flange - Model Dependent |
| 32 | Automatic Transmission Prop Shaft Flange - O-Ring Seal - Model Dependent |
| 33 | Automatic Transmission Prop Shaft Thrust Washer - Model Dependent |
| 34 | Prop Shaft Flange Nut - Model Dependent |
| 35 | Automatic Transmission Case Extension Bolt - Model Dependent |
| 35 | Automatic Transmission Case Extension Bolt - Model Dependent |
| 36 | Automatic Transmission Fluid Level Hole Plug |
| 37 | Automatic Transmission Fluid Level Hole Plug O-Ring Seal |
| 38 | Center Support Fluid Passage Sleeve |
| 39 | Overdrive Clutch Fluid Passage Sleeve |
| 40 | Automatic Transmission Pressure Test Plug |
| 42 | Output Speed Sensor |
| 43 | Output Speed Sensor Bolt |
| 44 | Input Speed Sensor |
| 45 | Input Speed Sensor Bolt |
| 46 | Automatic Transmission Fluid Pump Cover Gasket |
| 47 | Control Valve Body and Accumulator Assembly |
| 49 | Control Valve Body Bolt M6 x 1.0 x 50 |
| 50 | Control Valve Body Bolt M6 x 1.0 x 38 |
| 51 | Control Valve Body Bolt M6 x 1.0 x 50 |
| 52 | Manual Shaft Detent Assembly |
| 53 | Control Valve Body Bolt M6 x 1.0 x 68 |
| 54 | Wiring Harness Clip |
| 55 | Automatic Transmission Wiring Harness |
| 56 | Automatic Transmission Wiring Harness - O-Ring seal - 2 |
| 57 | Automatic Transmission Filter Seal - 2 |
| 59 | Automatic Transmission Fluid Filter |
| 60 | Automatic Transmission Fluid Pan Gasket |
| 61 | Automatic Transmission Fluid Pan Magnet |
| 62 | Automatic Transmission Fluid Pan Assembly |
| 63 | Automatic Transmission Fluid Pan Drain Plug |
| 64 | Automatic Transmission Fluid Pan Drain Plug Seal |
| 65 | Automatic Transmission Fluid Pan Bolt |
| 66 | Automatic Transmission Pressure Test Plug O-Ring Seal |
| 67 | Input and Reaction Carrier Thrust Washer - Model Dependent |
| 68 | Automatic Transmission Prop Shaft Flange Seal - Model Dependent |
Scheme 8
| Callout | Component Name |
| 200 | Reverse Clutch Housing Fluid Seal Ring - 3 |
| 201 | Input Shaft Bearing Assembly |
| 202 | Automatic Transmission Fluid Pump Cover Assembly |
| 203 | Check Valve Retainer and Ball Assembly |
| 203 | Check Valve Retainer and Ball Assembly |
| 204 | Valve Bushing/Spring Retainer |
| 204 | Valve Bushing/Spring Retainer |
| 205 | Line Boost Valve Bushing Seal |
| 206 | Line Boost Valve Bushing |
| 207 | Line Boost Valve |
| 208 | Line Boost Valve Spring |
| 209 | Pressure Regulator Valve Spring |
| 210 | Pressure Regulator Valve |
| 211 | Automatic Transmission Fluid Pump Retainer Pin |
| 211 | Automatic Transmission Fluid Pump Retainer Pin |
| 212 | Automatic Transmission Pump Cover Seal |
| 213 | Automatic Transmission Fluid Pump Screen Assembly |
| 214 | Brass Orifice Insert |
| 215 | Turbine Shaft Bushing |
| 216 | Automatic Transmission Fluid Pump Slide - Selective |
| 217 | Automatic Transmission Fluid Pump Slide Seal Support |
| 218 | Automatic Transmission Fluid Pump Slide Seal |
| 219 | Automatic Transmission Fluid Pump Slide Ring |
| 220 | Automatic Transmission Fluid Pump Slide Ring |
| 221 | Automatic Transmission Fluid Pump Vane Ring |
| 222 | Automatic Transmission Fluid Pump Vane |
| 223 | Automatic Transmission Fluid Pump Rotor - Selective |
| 224 | Automatic Transmission Fluid Pump Rotor Guide |
| 225 | Automatic Transmission Fluid Pump Vane Ring |
| 226 | Torque Converter Bushing |
| 227 | Torque Converter Housing |
| 228 | Torque Converter Housing Seal Bolt M4 x 0.7 x 10.0 - 4 |
| 229 | Torque Converter Housing Seal |
| 231 | Automatic Transmission Fluid Pump Slide Pin Assembly |
| 232 | Orifice Sleeve |
| 233 | Orifice Cup Plug - 2 |
| 233 | Orifice Cup Plug - 2 |
| 234 | TCC Control Valve Spring |
| 234 | TCC Control Valve Spring |
| 235 | TCC Control Valve |
| 236 | Automatic Transmission Fluid Pump Retainer Pin |
| 237 | TCC Enable Valve |
| 238 | Pressure Relief Ball Valve Spring |
| 239 | Pressure Relief Ball Valve |
| 240 | Automatic Transmission Fluid Pump Bolt M6 x 1.0 x 40 |
| 241 | Automatic Transmission Fluid Pump Bolt M8 x 1.25 x 40 |
| 242 | Automatic Transmission Fluid Pump Slide O-ring Seal |
Scheme 9
| Callout | Component Name |
| 300 | Control Valve Body Bolt M6 x 1.0 x 38 - 7 |
| 301 | Control Valve Top Channel Plate |
| 302 | Control Valve Channel Plate Ball Check Spring |
| 303 | Control Valve Channel Plate Gasket |
| 304 | Control Valve Bottom Channel Plate |
| 305 | Control Valve Body Gasket |
| 306 | Control Valve Body Ball Check Valve |
| 307 | Control Valve Body Spacer Plate |
| 308 | TCC PWM Solenoid Valve Filter Assembly |
| 309 | Control Valve Body Spacer Plate Gasket |
| 310 | Control Valve Rear Body Assembly |
| 311 | Control Valve Front Body Assembly |
| 312 | Pressure Control Solenoid Valve Filter Assembly |
| 313 | Direct Clutch Accumulator Piston Spring - Model Dependent |
| 314 | Direct Clutch Accumulator Piston Fluid Seal Ring - Model Dependent |
| 315 | Direct Clutch Accumulator Piston - Model Dependent |
| 316 | Direct Clutch Accumulator Piston Fluid Seal Ring - Model Dependent |
| 317 | Direct Clutch Accumulator Housing - Model Dependent |
| 318 | Accumulator Housing Bolt M6 x 1.0 x 30 - 12 - Model Dependent |
| 318 | Accumulator Housing Bolt M6 x 1.0 x 30 - 12 |
| 318 | Accumulator Housing Bolt M6 x 1.0 x 30 - 12 |
| 318 | Accumulator Housing Bolt M6 x 1.0 x 30 - 12 |
| 319 | Overdrive Clutch Accumulator Piston Spring |
| 320 | Overdrive Clutch Accumulator Piston Fluid Seal Ring |
| 321 | Overdrive Clutch Accumulator Piston |
| 322 | Overdrive Clutch Accumulator Piston Fluid Seal Ring |
| 323 | Overdrive Clutch Accumulator Housing |
| 324 | Intermediate Clutch Accumulator Piston Spring |
| 325 | Intermediate Clutch Accumulator Piston Fluid Seal Ring |
| 326 | Intermediate Clutch Accumulator Piston |
| 327 | Intermediate Clutch Accumulator Piston Fluid Seal Ring |
| 328 | Intermediate Clutch Accumulator Housing |
| 329 | 2nd Clutch Accumulator Piston Spring - Model Dependent |
| 330 | 2nd Clutch Accumulator Piston Seal Ring - Model Dependent |
| 331 | 2nd Clutch Accumulator Piston - Model Dependent |
| 332 | 2nd Clutch Accumulator Piston Seal Ring - Model Dependent |
| 333 | 2nd Clutch Accumulator Housing - Model Dependent |
| 334 | 2nd Clutch Accumulator Piston Inner Spring - Model Dependent |
Scheme 10
| Callout | Component Name |
| 340 | Front Control Valve Body |
| 341 | Safety Mode Valve |
| 342 | Safety Mode Valve Spring |
| 343 | Valve Spring Retainer - 3 |
| 343 | Valve Spring Retainer - 3 |
| 343 | Valve Spring Retainer - 3 |
| 344 | 3-4 Shift Valve Spring |
| 345 | 3-4 Shift Valve |
| 346 | 3-4 Shift Control Valve |
| 347 | TCC Regulator Apply Valve Spring |
| 348 | TCC Regulator Apply Valve |
| 349 | Solenoid Valve - O-Ring Seal |
| 350 | Solenoid Valve - O-Ring Seal |
| 351 | Solenoid Valve Retainer - 2 |
| 351 | Solenoid Valve Retainer - 2 |
| 352 | TCC PWM Solenoid Valve |
| 353 | Feed Limit Valve |
| 354 | Feed Limit Valve Spring |
| 355 | Pressure Control Solenoid - O-Ring Seal |
| 356 | Pressure Control Solenoid - O-Ring Seal |
| 357 | Pressure Control (PC) Solenoid Assembly |
Scheme 11
| Callout | Component Name |
| 343 | Valve Spring Retainer |
| 343 | Valve Spring Retainer |
| 343 | Valve Spring Retainer |
| 349 | Solenoid Valve - O-Ring Seal |
| 349 | Solenoid Valve - O-Ring Seal |
| 349 | Solenoid Valve - O-Ring Seal |
| 350 | Solenoid Valve - O-Ring Seal |
| 350 | Solenoid Valve - O-Ring Seal |
| 350 | Solenoid Valve - O-Ring Seal |
| 351 | Solenoid Valve Retainer |
| 351 | Solenoid Valve Retainer |
| 351 | Solenoid Valve Retainer |
| 365 | Rear Control Valve Body |
| 366 | 1-2 Shift Control Valve |
| 367 | 1-2 Shift Control Valve Spring |
| 368 | 1-2 Shift Solenoid (SS) Valve Assembly |
| 369 | 2-3 Shift Solenoid (SS) Valve Assembly |
| 370 | 2-3 Shift Control Valve |
| 371 | 2-3 Shift Valve |
| 372 | 2-3 Shift Valve Spring |
| 373 | 4-5 Shift Valve Spring |
| 374 | 4-5 Shift Valve |
| 375 | 4-5 Shift Control Valve |
| 376 | 4-5 Shift Solenoid (SS) Valve Assembly |
| 377 | Manual Valve |
| 378 | Manual Valve Link Washer - Waved |
| 379 | Manual Valve Link |
| 380 | Manual Valve Link Retainer |
| 381 | Low Pressure Control Valve Bore Plug |
| 382 | Low Pressure Control Valve Spring |
| 383 | Low Pressure Control Valve |
| 384 | Low Pressure Control Valve Bore Retainer |
| 385 | Reverse Lockout Valve |
| 386 | Reverse Lockout Valve Spring |
| 387 | 1-2 Shift Valve |
| 388 | 1-2 Shift Valve Spring |
Scheme 12
| Callout | Component Name |
| 400 | Reverse Clutch Housing Bushing |
| 401 | Reverse Clutch - W/Input Housing Assembly |
| 402 | Reverse Clutch Piston Inner Seal |
| 403 | Reverse Clutch Housing Ball Check Valve |
| 404 | Reverse Clutch Piston |
| 405 | Direct Clutch Housing Ball Check Valve |
| 406 | Direct Clutch Piston Assembly |
| 407 | Direct and Reverse Clutch Spring |
| 408 | Direct and Reverse Clutch Spring Retainer |
| 409 | Direct and Reverse Clutch Spring Retainer Ring |
| 410 | Direct Clutch Apply Plate |
| 411 | Direct Clutch Plate Assembly - Outer Spline - 4 |
| 412 | Direct Clutch Plate Assembly - Inner Spline - 4 |
| 413 | Direct Clutch Backing Plate |
| 414 | Direct Clutch Backing Plate Retainer Ring - Selective |
| 415 | Reverse Clutch Spacer |
| 416 | Reverse Clutch Apply Plate |
| 417 | Reverse Clutch Plate Assembly - Outer Spline - 2 |
| 418 | Reverse Clutch Plate Assembly - Inner Spline - 2 |
| 419 | Reverse Clutch Backing Plate |
| 420 | Reverse Clutch Backing Plate Retainer Ring - Selective |
Scheme 13
| Callout | Component Name |
| 430 | Input Shaft - O-Ring Seal |
| 431 | Input Shaft Fluid Seal Ring |
| 432 | Input Shaft Fluid Seal Ring - 3 |
| 433 | Forward Clutch - W/Input Housing Assembly |
| 434 | Forward Clutch Housing Ball Check Valve Assembly |
| 435 | Forward Clutch Bushing |
| 436 | Forward Clutch Piston Assembly |
| 437 | Coast Clutch Piston Ball Check Valve Assembly |
| 438 | Coast Clutch Piston Assembly |
| 439 | Forward and Coast Clutch Spring |
| 440 | Forward and Coast Clutch Spring Retainer Ring |
| 441 | Coast Clutch Spacer Plate - Selective |
| 442 | Coast Clutch Apply Plate |
| 443 | Coast Clutch Plate Assembly - Outer Spline - 3 |
| 444 | Coast Clutch Plate Assembly - Inner Spline - 3 |
| 445 | Coast Clutch Backing Plate |
| 446 | Coast Clutch Housing |
| 447 | Forward Clutch Apply Plate |
| 448 | Forward Clutch Plate Assembly - Outer Spline - 4 |
| 449 | Forward Clutch Plate Assembly - Inner Spline - 4 |
| 450 | Forward Clutch Backing Plate |
| 451 | Forward Clutch Backing Plate Retainer Ring - Selective |
Scheme 14
| Callout | Component Name |
| 455 | Forward Clutch Roller Inner Race Thrust Ring |
| 456 | Forward Clutch Roller Inner Bearing |
| 457 | Input Sun Gear Shaft Assembly |
| 458 | Forward Clutch Roller Outer Race Washer |
| 459 | Forward Clutch Sprag Outer Race |
| 460 | Forward Clutch Sprag Assembly Retainer Rings - 2 |
| 460 | Forward Clutch Sprag Assembly Retainer Rings - 2 |
| 461 | Forward Clutch Sprag Assembly |
| 462 | Orificed Cup Plug - Lube |
Scheme 15
| Callout | Component Name |
| 465 | Input and Reaction Carrier Bushing - 2 |
| 465 | Input and Reaction Carrier Bushing - 2 |
| 466 | Direct Clutch Drum |
Scheme 16
| Callout | Component Name |
| 470 | Overdrive and Reverse Clutch - W/Hub Assembly |
| 471 | Intermediate Clutch Roller Thrust Washer |
| 472 | Intermediate Clutch Sprag Assembly Retainer Rings - 2 |
| 472 | Intermediate Clutch Sprag Assembly Retainer Rings - 2 |
| 473 | Intermediate Clutch Sprag Assembly |
| 474 | Intermediate Clutch Sprag Outer Race |
| 475 | Intermediate Clutch Roller Thrust Washer |
| 476 | Intermediate Clutch Roller Thrust Bearing Assembly |
| 477 | Intermediate Clutch Roller Thrust Bearing Assembly Retainer |
Scheme 17
| Callout | Component Name |
| 480 | Overdrive Clutch Backing Plate Retainer Ring - Selective |
| 481 | Overdrive Clutch Backing Plate |
| 482 | Overdrive Clutch Plate Assembly - Inner Spline |
| 483 | Overdrive Clutch Plate Assembly - Outer Spline |
| 484 | Overdrive Clutch Spacer |
| 485 | Overdrive Clutch Spring Retainer Ring |
| 486 | Overdrive Clutch Piston Spring |
| 487 | Overdrive Clutch Piston Assembly |
| 488 | Intermediate Clutch Backing Plate Retainer Ring - Selective |
| 489 | Intermediate Clutch Backing Plate |
| 490 | Intermediate Clutch Plate Assembly - Inner Spline - 3 |
| 491 | Intermediate Clutch Plate Assembly - Outer Spline - 3 |
| 492 | Intermediate Clutch Apply Plate |
| 493 | Overdrive Clutch Housing |
| 494 | Intermediate Clutch Spring |
| 495 | Intermediate Clutch Piston Assembly |
| 496 | Intermediate Clutch Housing |
| 497 | Intermediate Clutch Housing Retainer Ring |
Scheme 18
| Callout | Component Name |
| 500 | Low Clutch Roller Retainer |
| 501 | Low Clutch Roller Thrust Washer |
| 501 | Low Clutch Roller Thrust Washer |
| 502 | Low Clutch Sprag Assembly Retainer Rings - 2 |
| 502 | Low Clutch Sprag Assembly Retainer Rings - 2 |
| 503 | Low Clutch Sprag Assembly |
| 504 | Low Clutch Sprag Outer Race |
| 505 | Low Clutch Sprag Inner Race |
Scheme 19
| Callout | Component Name |
| 510 | Low and Reverse Clutch Plate Retainer Ring - Selective |
| 511 | Low and Reverse Clutch Backing Plate |
| 512 | Low and Reverse Clutch Plate Assembly - Inner Spline - 5 |
| 513 | Low and Reverse Clutch Plate Assembly - Outer Spline - 5 |
| 514 | Low and Reverse Clutch Apply Plate |
| 515 | Low and Reverse Clutch Spring Retainer Ring |
| 516 | Low and Reverse Clutch Spring |
| 517 | Low and Reverse Clutch Piston |
| 518 | Center Support |
| 519 | Input and Reaction Bearing Assembly |
| 520 | 2nd Clutch Piston |
| 521 | 2nd Clutch Spring |
| 522 | 2nd Clutch Spring Retainer Ring |
| 523 | 2nd Clutch Apply Plate |
| 524 | 2nd Clutch Plate Assembly - Outer Spline - 5 |
| 525 | 2nd Clutch Plate Assembly - Inner Spline - 5 |
| 526 | 2nd Clutch Backing Plate |
| 527 | 2nd Clutch Backing Plate Retainer Ring - Selective |
| 528 | 2nd Coast Clutch Piston Assembly |
| 529 | 2nd Coast Clutch Spring |
| 530 | 2nd Coast Clutch Spring Retainer Ring |
| 531 | 2nd Coast Clutch Spacer |
| 532 | 2nd Coast Clutch Plate Assembly - Outer Spline - 3 |
| 533 | 2nd Coast Clutch Plate Assembly - Inner Spline - 3 |
| 534 | 2nd Coast Clutch Backing Plate |
| 535 | 2nd Coast Clutch Plate -Backing Plate -Retainer Ring -Selective |
Scheme 20
| Callout | Component Name |
| 540 | Input and Reaction Carrier Outer Retainer Ring |
| 541 | Input and Reaction Bearing Assembly |
| 542 | 2nd Clutch Roller Inner Race Bearing Assembly |
| 543 | 2nd Clutch Sprag Retainer |
| 544 | 2nd Clutch Roller Outer Race Washer |
| 544 | 2nd Clutch Roller Outer Race Washer |
| 545 | 2nd Clutch Sprag Outer Race |
| 546 | 2nd Clutch Sprag Assembly Retainer - 2 |
| 546 | 2nd Clutch Sprag Assembly Retainer - 2 |
| 547 | 2nd Clutch Sprag Assembly |
| 548 | Input and Reaction Carrier Bushing |
| 549 | 2nd Clutch Sprag Inner Race |
| 550 | Reaction Internal Gear |
| 551 | Reaction Internal Gear Flange Washer |
| 552 | Reaction Carrier Bushing - 2 |
| 552 | Reaction Carrier Bushing - 2 |
| 553 | Input and Reaction Carrier |
| 554 | Input and Reaction Bearing Assembly |
Scheme 21
| Callout | Component Name |
| 560 | Rear Internal Gear |
| 561 | Input and Reaction Carrier Bushing |
| 562a | Output Shaft Assembly - AWD |
| 562b | Output Shaft Assembly - 2WD |
| 562c | Output Shaft Assembly - XLR |
| 563 | Rear Internal Retainer Ring |
| 564 | Cup Plug |
Scheme 22
| Callout | Component Name |
| 600 | Manual Shaft Detent Lever |
| 601 | Manual Shaft Detent Lever Pin |
| 602 | Transmission Manual Shift Shaft Switch Assembly |
| 603 | Manual Shaft Detent Lever Pin |
| 604 | Transmission Case |
| 605 | Manual Shift Shaft Seal - Model Dependent |
| 605 | Manual Shift Shaft Seal - Model Dependent |
| 606a | Manual Shift Shaft - 2WD Excluding XLR - Model Dependent |
| 606b | Manual Shift Shaft - AWD and XLR - Model Dependent |
| 607 | Park Pawl Actuator Bracket |
| 608 | Park Pawl Actuator Bracket |
| 609 | Park Pawl Actuator Bracket Bolt M8 x 1.25 x 25 - 2 |
| 610 | Park Pawl Shaft |
| 611 | Park Pawl Spring |
| 612 | Park Pawl |
| 613 | Park Pawl Actuator Assembly |
| 614 | Cup Plug - Model Dependent |
| 615 | Transmission Manual Shift Shaft Spacer - Model Dependent |
Scheme 23
Scheme 23: Component Location
| Callout | Component Name |
| 17 | Low Clutch Roller Thrust Bearing |
| 20 | Input and Reaction Carrier Thrust Bearing |
| 23 | Input and Reaction Carrier Thrust Bearing |
| 26 | Output Shaft Bearing |
| 28 | Output Shaft Bearing |
| 201 | Input Shaft Bearing Assembly |
| 215 | Turbine Shaft Bushing |
| 226 | Torque Converter Bushing |
| 400 | Reverse Clutch Housing Bushing |
| 435 | Forward Clutch Bushing |
| 456 | Forward Clutch Roller Inner Bearing |
| 461 | Forward Clutch Sprag Assembly |
| 465 | Input and Reaction Carrier Bushing Assembly - 2 |
| 465 | Input and Reaction Carrier Bushing Assembly - 2 |
| 473 | Intermediate Clutch Sprag Assembly |
| 476 | Intermediate Clutch Roller Thrust Bearing Assembly |
| 503 | Low Clutch Sprag Assembly |
| 519 | Input and Reaction Bearing Assembly |
| 541 | Input and Reaction Bearing Assembly |
| 542 | 2nd Clutch Roller Inner Race Bearing Assembly |
| 547 | 2nd Clutch Sprag Assembly |
| 548 | Input and Reaction Carrier Bushing |
| 552 | Reaction Carrier Bushing - 2 |
| 552 | Reaction Carrier Bushing - 2 |
| 554 | Input and Reaction Bearing Assembly |
| 561 | Input and Reaction Carrier Bushing |
Scheme 24
| Callout | Component Name |
| 4 | Torque Converter Housing Fluid Seal Assembly |
| 29 | Transmission Prop Shaft Flange Seal |
| 32 | Transmission Prop Shaft Flange - O-ring Seal |
| 38 | Center Support Fluid Passage Sleeve |
| 39 | Overdrive Clutch Fluid Passage Sleeve |
| 56 | A/Transmission Wiring Harness - O-ring Seal - 2 |
| 57 | Automatic Transmission Filter Seal - 2 |
| 64 | Automatic Transmission Fluid Pan Drain Plug Seal |
| 200 | Reverse Clutch Housing Fluid Seal Ring - 3 |
| 218 | Automatic Transmission Fluid Pump Slide Seal |
| 220 | Automatic Transmission Fluid Pump Slide Ring |
| 229 | Torque Converter Housing Seal |
| 242 | Automatic Transmission Fluid Pump Slide O-ring Seal |
| 314 | Clutch Accumulator Piston Fluid Seal Ring |
| 316 | Clutch Accumulator Piston Fluid Seal Ring |
| 402 | Reverse Clutch Piston Inner Seal |
| 404 | Reverse Clutch Piston |
| 406 | Direct Clutch Piston Assembly |
| 430 | Input Shaft - O-Ring Seal |
| 431 | Input Shaft Fluid Seal Ring |
| 432 | Input Shaft Fluid Seal Ring - 3 |
| 436 | Forward Clutch Piston Assembly |
| 438 | Coast Clutch Piston Assembly |
| 487 | Overdrive Clutch Piston Assembly |
| 495 | Intermediate Clutch Piston Assembly |
| 517 | Low and Reverse Clutch Piston |
| 520 | 2nd Clutch Piston |
| 528 | 2nd Coast Clutch Piston Assembly |
| 605 | Manual Shift Shaft Seal |
Transmission General Description (5L40-E/5L50-E)
The Hydra-matic 5L40-E is a fully automatic, five speed, rear wheel drive, electronically controlled transmission. It consists primarily of a four-element torque converter, one planetary gear set, friction and mechanical clutches and a hydraulic pressurization and control system.
The TCM commands shift solenoids, within the transmission, on and off to control shift timing. The TCM controls shift feel through the pressure control solenoid. The TCM also controls the apply and release of the torque converter clutch which allows the engine to deliver the maximum fuel efficiency without sacrificing vehicle performance. The hydraulic system primarily consists of a vane type pump, two control valve bodies, two channel plates, converter housing and case. The pump maintains the working pressures needed to stroke the clutch pistons that apply or release the friction components. These friction components, when applied or released, support the automatic shifting qualities of the transmission. The friction components used in this transmission consist of nine multiple disc clutches. The multiple disc clutches combine with four mechanical sprag clutches, to deliver six different gear ratios through the gear set. The gear set then transfers torque through the output shaft.
The transmission can be operated in any one of the seven different modes.
- P - Park position enables the engine to be started while preventing the vehicle from rolling either forward or backward. For safety reasons, the vehicle parking brake should be used in addition to the transmission Park position. Since the output shaft is mechanically locked to the case through the parking pawl and rear internal gear, Park position should not be selected until the vehicle has come to a complete stop.
- R - Reverse enables the vehicle to be operated in a rearward direction.
- N - Neutral position enables the engine to start and operate without driving the vehicle. If necessary, this position should be selected to restart the engine while the vehicle is moving.
- OD - Overdrive range should be used for all normal driving conditions for maximum efficiency and fuel economy. Overdrive range allows the transmission to operate in each of the five forward gear ratios. Downshifts to a lower gear, or higher gear ratio are available for safe passing by depressing the accelerator or by manually selecting a lower gear with the shift selector.
- 4 - Manual Fourth can be used for conditions where it may be desirable to use only four gear ratios. These conditions include towing a trailer and driving on hilly terrain as described above. This range is also helpful for engine braking when descending slight grades. Upshifts and downshifts are the same as in Overdrive range for first, second, third and fourth gears except that the transmission will not shift into fifth gear. Manual Fourth can be selected at any vehicle speed but will downshift into fourth gear only if vehicle speed is low enough not to overrev the engine, calibratable in TCM.
- 3 - Manual Third adds more performance for congested traffic and hilly terrain. It has the same starting ratio, first gear, as Manual Fourth but prevents the transmission from shifting above Third gear. Thus, Manual Third can be used to retain third gear for acceleration and engine braking as desired. Manual Third can be selected at any vehicle speed but will downshift into third gear only if vehicle speed is low enough not to overrev the engine, calibratable in TCM.
- 2 - Manual Second adds more performance for congested traffic and hilly terrain. It has the same starting ratio, first gear, as Manual Third but prevents the transmission from shifting above second gear. Thus, Manual Second can be used to retain second gear for acceleration and engine braking as desired. Manual Second can be selected at any vehicle speed but will downshift into second gear only if vehicle speed is low enough not to overrev the engine, calibratable in TCM.
When the vehicle speed slows down to a speed low enough not to overrev the engine, calibratable in TCM, the transmission will automatically downshift into first gear. This is particularly beneficial for maintaining maximum engine braking when descending steep grades.
Transmission Component and System Description
The mechanical components of the 5L40/5L50-E are as follows
- A torque converter with an electronically controlled capacity clutch (ECCC) This transmission is equipped with an electronically controlled capacity clutch (ECCC). The pressure plate does not fully lock to the torque converter cover. Instead, the pressure plate maintains a small amount of slippage, about 20 RPM, in SECOND, THIRD and FOURTH gears, depending on the vehicle application. ECCC was developed to reduce the possibility of noise, vibration or chuggle caused by TCC apply. Typical apply speeds are 49-52 km/h (30-32 mph) in THIRD gear and 65-73 km/h (40-45 mph) in FOURTH gear. Full lockup is available at highway speeds on some applications.
- Direct and reverse clutch assembly
- Forward and coast clutch assembly
- Input sungear shaft and forward sprag clutch assembly
- Output shaft assembly, with rear internal gear
- Intermediate clutch sprag assembly
- Overdrive clutch housing
- Low clutch sprag
- Center support
- Input and reaction carrier
- Fluid pump assembly
- Control valve body and accumulator assembly
The electrical components of the 5L40/5L50-E are as follows
- 1-2, 2-3 and 4-5 shift solenoids
- Transmission manual shift shaft switch assembly
- Transmission pressure control (PC) solenoid
- TCC pulse width modulation (PWM) solenoid valve
- Transmission fluid temperature (TFT) sensor
- Input speed sensor (ISS)
- Output speed sensor (OSS)
For more information, refer to Electronic Component Description (5L40-E/5L50-E) or Electronic Component Description (5L50-E) .
Limp Home Mode Description
If a major electrical system failure occurs which could affect vehicle safety or damage the transmission during normal operation, the TCM enters a default mode. In the default mode, the transmission operates in the following manner
- The pressure control solenoid is off and the line pressure is at maximum in order to minimize clutch slippage.
- The TCC solenoid is off. The converter clutch is disabled.
- All three of the shift solenoids are off. The transmission will operate in fifth gear if the vehicle has successfully completed a 1-2 upshift in the current ignition cycle. If the vehicle has not completed a 1-2 upshift in the current ignition cycle, the transmission will operate in fourth gear. If the transmission is operating in fifth gear, fourth gear may be obtained if the engine is stopped briefly and re-started.
In default mode, the gear selector lever is ineffective at selecting forward gear ranges. In fourth or fifth gear, heat builds up in the transmission quickly, particularly in stop and go traffic. Excessive heat build-up may cause transmission failure if the vehicle is driven for extended distances in default mode.
