Cellular System, Entertainment System, and Navigation System: Specifications Cadillac SRX II facelift

Entertainment Systems 14 illustrations

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Audio/Video Disc Player Adapter Screws2.5 N.m22 lb in
Communication Interface Module Bracket Bolt2.5 N.m22 lb in
Communication Interface Module Bracket Nuts9 N.m80 lb in
Heater and Air Conditioning and Radio Control Module Screws2.5 N.m22 lb in
Mobile Telephone Control Module Bracket Bolt2.5 N.m22 lb in
Mobile Telephone Control Module Bracket Nuts9 N.m80 lb in
Radio Control Switch Bolts2 N.m18 lb in
Radio Front Center Speaker Screws3 N.m27 lb in
Radio Front Side Door Speaker Bolts2.5 N.m22 lb in
Radio Rear Compartment Speaker Nuts6 N.m53 lb in
Radio Rear Side Door Speaker Bolt2.5 N.m22 lb in
Radio Screws9 N.m80 lb in
Radio, Video, Audio Disc Player, and Navigation Information Display Nut2.5 N.m22 lb in
Radio, Video, Audio Disc Player, and Navigation Information Display Screws2.5 N.m22 lb in
Rear Liftgate Speaker Bolts2.5 N.m22 lb in
Video Display Bolts9.5 N.m84 lb in

Fastener Tightening Specifications

Scheme 1

Scheme 1: Radio, Amplifier, and Multimedia Player Interface Module Power, Ground and Data Communication
Scheme 1: Radio, Amplifier, and Multimedia Player Interface Module Power, Ground and Data Communication

Scheme 2

Scheme 2: Antenna Signals
Scheme 2: Antenna Signals

Scheme 3

Scheme 3: Front Speaker (UQA or UQS)
Scheme 3: Front Speaker (UQA or UQS)

Scheme 4

Scheme 4: Rear Speaker (UQA or UQS)
Scheme 4: Rear Speaker (UQA or UQS)

Scheme 5

Scheme 5: Auxiliary Inputs
Scheme 5: Auxiliary Inputs

Scheme 6

Scheme 6: Digital Radio Signals (UBT)
Scheme 6: Digital Radio Signals (UBT)

Scheme 7

Scheme 7: Media Disc Player Power, Ground, Data Communication, and Disc Eject Switch
Scheme 7: Media Disc Player Power, Ground, Data Communication, and Disc Eject Switch

Scheme 8

Scheme 8: Navigation Power, Ground, Serial Data, and Signals (NQU)
Scheme 8: Navigation Power, Ground, Serial Data, and Signals (NQU)

Scheme 9

Scheme 9: Auxiliary Inputs (NQU)
Scheme 9: Auxiliary Inputs (NQU)

Scheme 10

Scheme 10: Power, Ground, Serial Data, and Antennas
Scheme 10: Power, Ground, Serial Data, and Antennas

Scheme 11

Scheme 11: Communication Signals and Control
Scheme 11: Communication Signals and Control

Scheme 12

Scheme 12: Seatback Displays Power Enable and Ground
Scheme 12: Seatback Displays Power Enable and Ground

Scheme 13

Scheme 13: Seatback Display Video Signals
Scheme 13: Seatback Display Video Signals

Scheme 14

Scheme 14: Video Inputs (UWG)
Scheme 14: Video Inputs (UWG)
