Circuit/System Description
The Info Display Module monitors itself for internal failures and reports its condition to the Human Machine Interface Control Module when requested. The info display also reports electronic identification information when requested.
The human machine interface control module monitors the internal circuitry for excessive temperature. When a temperature outside of the range is detected, the module sets the DTC and limits its operation to avoid damage.
The audio amplifier monitors the internal circuitry for excessive temperature. When the amplifier senses an internal circuitry temperature greater than 95°C (203°F), the amplifier will set DTC B1024 11 and shut down until the internal circuitry cools below 90°C (194°F). No external circuit diagnosis is involved.
The Media Oriented Systems Transport (MOST) is a high-speed multimedia network technology. The serial MOST bus uses a ring topology and synchronous data communication to transmit audio, video, data and control information between any devices attached.
The audio amplifier is a participant on the MOST network. The audio amplifier receives audio inputs and control information from the MOST bus.
Each of the audio output channel circuits (+) and (-), at the audio amplifier have a DC bias voltage that is approximately one half of the battery voltage. When using a DMM, each of the audio output channel circuits will measure approximately 6.5V DC. The audio being played on the system is produced by a varying AC voltage that is centered around the DC bias voltage on the same circuit. The AC voltage is what causes the speaker cone to move and produce sound.
Certain devices in the entertainment system must be programmed with specific software and other information to operate correctly. This DTC is the result of an unsuccessful USB programming event of the device. The symptom byte information is for engineering reference only. No external circuit diagnosis is involved
The infotainment system has a USB port and SD card reader slot located in the center console. The USB port and the card reader slot interface with a hub device, internal to the auxiliary jack, USB, and memory card receptacle assembly. The auxiliary jack, USB, and memory card receptacle assembly receives fused battery voltage and ground from the harness to power the internal hub device as well as providing additional amperage to power USB devices.
The internal hub device interfaces directly with the human machine interface control module via a standard USB cable. A Mini type USB connector is used to connect the cable at the USB port and at the human machine interface control module and at the auxiliary jack, USB, and memory card receptacle. Standard USB male to female connections are typically used for connecting USB cables together where an in-line connection is required. An in-line cable connection is typically found between the console and I/P harness.
USB Port
The USB port allows connectivity to the infotainment system from portable media players or a USB storage device (memory stick/ flash drive). When a device is connected to the USB port, the system detects the device and switches to USB as the audio source. Once connected, the device can be controlled from the radio controls.
Not all portable media player devices or file types are compatible. Refer to the owner's manual for information on USB devices, control, and operation.
SD Card Reader
The infotainment uses the SD card reader as a mass storage device, similar to a USB storage device.
Refer to the owners manual for information on media types supported via the SD card reader.
The infotainment system has a USB port and SD card reader slot located in the center console. The USB port and the card reader slot interface with a hub device, internal to the auxiliary jack, USB, and memory card receptacle assembly. The auxiliary jack, USB, and memory card receptacle assembly receives fused battery voltage and ground from the harness to power the internal hub device as well as providing additional amperage to power USB devices.
The internal hub device interfaces directly with the human machine interface control module via a standard USB cable. A mini type USB connector is used to connect the cable at the USB port and at the human machine interface control module and at the auxiliary jack, USB, and memory card receptacle. Standard USB male to female connections are typically used for connecting USB cables together where an in-line connection is required. An in-line cable connection is typically found between the console and I/P harness.
USB Port
The USB port allows connectivity to the infotainment system from portable media players or a USB storage device (memory stick/ flash drive). When a device is connected to the USB port, the system detects the device and switches to USB as the audio source. Once connected, the device can be controlled from the radio controls.
Not all portable media player devices or file types are compatible. Refer to the owner's manual for information on USB devices, control, and operation.
SD Card Reader
The infotainment uses the SD card reader as a mass storage device, similar to a USB storage device.
Refer to the owners manual for information on media types supported via the SD card reader.
The multi-band antenna is located on the roof of the vehicle. The radio antenna is enabled when the radio is turned on. The radio provides battery voltage to the antenna using the center conductor of the antenna coaxial cable. When a 12 V signal is seen by the antenna on the center conductor of the antenna coax, both AM and FM signals are amplified.
The digital radio receiver, located inside the radio, receives digital radio information from the digital radio antenna located on the outside of the vehicle. The digital radio receiver is connected to the digital radio antenna via a shielded coax cable. The digital radio antenna contains an amplifier which is powered by the radio through the coax cable.
When the radio is initially installed in the vehicle, the radio receives VIN information via serial data. The radio stores a portion of the VIN and compares this sequence to the VIN information received each time the radio powers on. The VIN in the radio is a single one-time learn.
The radio theft deterrent system is intended to disable or limit radio functionality if incorrect vehicle information is received by the radio. The radio disables functionality if the VIN information received by the radio does not match the VIN information that has been learned by the radio. This DTC is generated by the module when the Theft Protection is activated.
The rear seat entertainment system has an auxiliary input assembly that contains a USB port, an SD card reader, RCA type audio/video jacks, and a wired headphone jack with volume control. Refer to the Owners Manual for information on compatible devices and supported media types/formats.
The USB port and SD card reader slot interface with a hub device, internal to the assembly. The assembly receives fused battery voltage and ground from the harness to power the internal hub device as well as providing additional amperage to power USB devices.
The internal hub device interfaces directly with the disc player via a standard USB cable. A Mini type USB connector is used to connect the cable at the disc player and the auxiliary input assembly. Mini type USB male to female connections are used for connecting USB cables together where an in-line connection is required. An in-line cable connection is typically found between the console and I/P harness.
The USB port allows connectivity to the rear seat entertainment system from portable media players or a USB storage device (memory stick/ flash drive). The rear seat entertainment uses the SD card reader as a mass storage device, similar to a USB storage device.
Once a supported device is connected to the USB port or SD card reader, the device may be sourced to one or both of the rear displays using the remote control.
The infotainment system Info Display Module is supplied battery voltage and ground . The Human Machine Interface Control Module communicates with the info display via a dedicated cable for the LVDS data circuits. All video information to the display, as well as backlighting dimming level, and screen touch signals, are communicated over the LVDS data circuits.
If the Human Machine Interface Control Module detects the display is not responding to the output on the LVDS circuits, the Human Machine Interface Control Module sets the DTC.
The rear displays are located in the back of the driver and front passenger seats. The rear seatback display screens show video from the disc player.
The seatback displays receive power and ground from the vehicle harness. A discrete control circuit from the disc player is used to control the power state of the displays. The displays receive all other video, audio, and control information via the LVDS cable. The LVDS cable connected to the rear displays contains two pairs of data circuits to provide separate information to each of the rear displays.
If the media disc player detects that one or both of the rear displays is not responding to the output on the LVDS circuits, the media disc player sets the DTC.
The Media Disc Player monitors itself for internal failures and reports its condition to the radio via serial data when in use.
When the Media Disc Player is initially installed in the vehicle, it receives VIN information via serial data. The Media Disc Player stores a portion of the VIN and compares this sequence to the VIN information received each time the Media Disc Player powers on. The VIN in the Media Disc Player is a single one-time learn.
The Media Disc Player theft deterrent system is intended to disable or limit Media Disc Player functionality if incorrect vehicle information is received by the Media Disc Player. The Media Disc Player disables functionality if the VIN information received by the Media Disc Player does not match the VIN information that has been learned by the Media Disc Player. This DTC is generated by the module when the Theft Protection is activated.
The backup power source provides voltage to the telematics communication interface control module , to be able to successfully place a call in the event of a main battery disconnect during a collision event.
The telematics communication interface control module provides the cellular phone microphone with a supplied voltage on the cellular phone microphone high signal circuit. When the microphone is in use, voice data from the user is sent back to the telematics communication interface control module on the microphone low signal circuit.
The navigation antenna is connected to the telematics communication interface control module and the human machine interface control module through the navigation signal splitter. The navigation signal splitter distributes the navigation signal to both the telematics communication interface control module and the human machine interface control module. The telematics communication interface control module supplies 5 V through the coax cable to power the internal antenna amplifier through the signal splitter. The human machine interface control module supplies 5 V through the center conductor of the coax cable to power the splitter.
The cellular phone and navigation antenna is connected to the telematics communication interface control module. This module supplies 5 V to the cellular phone and navigation antenna to power the internal amplifier. When the vehicle is equipped with the optional navigation radio, a navigation antenna signal splitter is installed to distribute the GPS signal to both the telematics communication interface control module and the navigation radio. The navigation radio supplies 5 V through the GPS antenna coaxial cable to the navigation antenna signal splitter to power the internal navigation radio signal amplifier.
The OnStar® button assembly consists of 3 buttons: Call/Answer, OnStar® Call Center, and OnStar® Emergency. The telematics communication interface control module supplies the OnStar® button assembly with 10 V via the 10 V reference circuit . Each of the buttons, when pressed, completes the circuit across a resistor allowing a specific voltage to be returned to the telematics communication interface control module over the keypad signal circuit. Depending upon the voltage range returned, the telematics communication interface control module is able to identify which button has been pressed.
Bluetooth ® wireless technology is a short-range communications technology intended to replace the cables connecting portable and/or fixed devices while maintaining high levels of security. The operating range of the signal is approximately 30 feet.
The Bluetooth ® antenna is a small fixed antenna connected directly to the telematics communication interface control module and is used to send and receive signals from a Bluetooth ® enabled cellular phone.
The term application refers to any piece of software that works on a system (hardware) that is being operated by its own software. Applications are typically small software programs which uses the hardware to perform a specific task, as opposed to operating the entire system.
The rear seat entertainment system has an auxiliary input assembly that contains a USB port, an SD card reader, RCA type audio/video jacks, and a wired headphone jack with volume control. Refer to the Owners Manual for information on compatible devices and supported media types/formats.
USB Port and SD Card Reader
The USB port and SD card reader slot interface with a hub device, internal to the assembly. The assembly receives fused battery voltage and ground from the harness to power the internal hub device as well as providing additional amperage to power USB devices.
The internal hub device interfaces directly with the media disc player via a standard USB cable. A Mini type USB connector is used to connect the cable at the media disc player and the auxiliary input assembly. Mini type USB male to female connections are used for connecting USB cables together where an in-line connection is required. An in-line cable connection is typically found between the console and I/P harness.
The USB port allows connectivity to the rear seat entertainment system from portable media players or a USB storage device (memory stick/ flash drive). The rear seat entertainment uses the SD card reader as a mass storage device, similar to a USB storage device.
Once a supported device is connected to the USB port or SD card reader, the device may be sourced to on or both of the rear displays using the remote control.
Audio/Video Input
The local video input is the standard yellow RCA color-coded jacks. A composite video signal from a device can be attached to this input and is then available to be sourced to one or both of the rear screens. To use this video input, connect the auxiliary device cables to the RCA jacks and power ON both the auxiliary device and the rear seat entertainment system.
Power for the device is not supplied by this connection. The rear seat entertainment system cannot control the operation of devices connected to the RCA jacks. All operation of the device must be done using the controls available on the device.
Wired Headphone Jack
The wired headphone jack is used to connect an additional set of headphones to the system. Audio for the wired headphone jack can be from either the left or the right screen source, and is selected using the remote control.
Audio to the wired headphone jack is transmitted through the vehicle harness from the media disc player. A rotary control near the headphone jack is used to adjust the volume.
The infotainment system has a auxiliary jack, USB, and memory card receptacle assembly located in the center console. The two USB ports and the card reader slot interface with a hub device, internal to the assembly. The assembly receives fused battery voltage and ground from the harness to power the internal hub device as well as providing additional amperage to power USB devices.
The internal hub device interfaces directly with the human machine interface control module via a standard USB cable. A Mini type USB connector is used to connect the cable at the human machine interface control module and at the auxiliary jack, USB, and memory card receptacle assembly. Standard USB male to female connections are typically used for connecting USB cables together where an in-line connection is required. An in-line cable connection is typically found between the console and I/P harness.
Auxiliary Audio Input Jack
The 3.5 mm (1/8 in.) auxiliary audio input jack is located in the console. When a portable audio playback device is connected to the auxiliary jack, an internal switch opens the detection signal circuit . The radio detects the device and AUX becomes available as an audio source. Audio signals from the device are sent to the radio from the auxiliary input jack via the left, right, and common audio signal circuits.
USB Port
The USB port allows connectivity to the infotainment system from portable media players or a USB storage device (memory stick/ flash drive). When a device is connected to the USB port, the system detects the device and USB becomes available as an audio source. Once connected, the device can be controlled from the radio controls.
Not all portable media player devices or file types are compatible. Refer to the owner's manual for information on USB devices, control, and operation.
SD Card Reader
The infotainment uses the SD card reader as a mass storage device, similar to a USB storage device.
Refer to the owners manual for information on media types supported via the SD card reader.
The Bluetooth ® antenna is internal to, or is a small fixed antenna connected directly to, the telematics communication interface control module and is used to send and receive signals from a Bluetooth ® enabled cellular phone. The antenna utilizes no cabling and is not external to the vehicle.
In order to use hands-free calling, the cellular phone must be paired to the vehicle. Up to five devices can be paired to the vehicle at one time, but only one can be connected at any given time. To pair a phone, the customer must know how to operate the Bluetooth ® functionality of their phone. The pairing process must only be done one time for each phone, unless that phone's information is deleted. For safety reasons, the pairing process is disabled while the vehicle is moving.
Bluetooth ® wireless technology is a short-range communications technology intended to replace the cables connecting portable and/or fixed devices while maintaining high levels of security. The operating range of the signal is approximately 30 feet.
The available features and functions are determined by the type of device and the software within the devices being used. For a feature or function to operate, it must be supported in both devices.
The Bluetooth ® hardware is internal to the human machine interface control module. The human machine interface control module supports streaming of data (music, voice, information) from cellular phones and other mobile devices that support those features. The human machine interface control module is also capable of interfacing with cellular phones for hands-free features.
Refer to the vehicle owner manual, supplements, and the device manufacturer's information for information on devices, control, operation. and pairing instructions.
The media disc player is a separate component from the radio. The media disc player receives power, ground and serial data from the vehicle harness. The media disc player receives control information and outputs audio to the infotainment system over the MOST bus.
When equipped with the rear seat entertainment system, the media disc player is also the control module for the rear seat entertainment system, responsible for video output, infrared audio, rear screen controls and source selections.
The eject switch for the media disc player is a touch type switch that is part of the instrument panel multifunction switch assembly. The switch assembly receives battery voltage and ground from the vehicle harness. A discrete eject signal circuit is provided to the switch assembly from the media disc player. When the switch is touched, the signal circuit is pulled low through the assembly and the media disc player ejects the disc.
The media disc player is a separate component from the radio. The media disc player receives power, ground and serial data from the vehicle harness. The media disc player receives control information and outputs audio to the infotainment system over the MOST bus.
The eject switch for the media disc player is a touch type switch that is part of the instrument panel multifunction switch assembly. The switch assembly receives battery voltage and ground from the vehicle harness. A discrete eject signal circuit is provided to the switch assembly from the media disc player. When the switch is touched, the signal circuit is pulled low through the assembly and the media disc player ejects the disc.
The digital radio receiver, located inside the radio, receives digital radio information from the digital radio antenna located on the outside of the vehicle. The digital radio receiver is connected to the digital radio antenna via a shielded coax cable. The digital radio antenna contains an amplifier which is powered by the radio through the coax cable.
The telematics communication interface control module provides the Cellular Phone Microphone with a supplied voltage on the cellular phone microphone signal circuit. When the cellular phone microphone is in use, voice data from the user is sent back to the telematics communication interface control module on the signal circuit.
When an OnStar® keypress is made, a serial data message is sent to the audio system to mute all radio functions and output OnStar® originated audio. After the audio system is muted, the telematics communication interface control module transmits signals to the audio system on the audio signal and audio common circuits.
The navigation antenna is connected to the telematics communication interface control module. The module supplies 5 V to the antenna to power the internal amplifier through the center conductor of the antenna coax cable.
When the vehicle is equipped with the optional navigation system, a navigation signal splitter is installed to distribute the navigation signal to both the telematics communication interface control module and the human machine interface control module. The telematics communication interface control module supplies 5 V through the coax cable to power the internal antenna amplifier through the signal splitter.
The telematics communication interface control module has the capability of commanding the horn, initiating door lock/unlock, or operating the exterior lamps using the serial data circuits. These functions are commanded by the OnStar® Call Center per a customer request.
The OnStar® button assembly consists of 3 buttons: Call/Answer, OnStar® Call Center, and OnStar® Emergency. The telematics communication interface control module supplies the OnStar® button assembly with 10 V via the 10 V reference circuit . Each of the buttons, when pressed, completes the circuit across a resistor allowing a specific voltage to be returned to the telematics communication interface control module over the keypad signal circuit. Depending upon the voltage range returned, the telematics communication interface control module is able to identify which button has been activated.
The multi-band antenna is located on the roof of the vehicle. The radio antenna is enabled when the radio is turned on. The radio provides battery voltage to the antenna using the center conductor of the antenna coaxial cable. When a 12 V signal is seen by the antenna on the center conductor of the antenna coax, both AM and FM signals are amplified.
The Media Oriented Systems Transport (MOST) is a high-speed multimedia network technology. The serial MOST bus uses a ring topology and synchronous data communication to transmit audio, video, data and control information between any devices attached.
The audio amplifier is a participant on the MOST network. The audio amplifier receives audio inputs and control information from the MOST bus.
Each of the audio output channel circuits (+) and (-), at the audio amplifier have a DC bias voltage that is approximately one half of the battery voltage. When using a DMM, each of the audio output channel circuits will measure approximately 6.5V DC. The audio being played on the system is produced by a varying AC voltage that is centered around the DC bias voltage on the same circuit. The AC voltage is what causes the speaker cone to move and produce sound.
The navigation antenna is connected to the telematics communication interface control module directly or through the navigation signal splitter if the vehicle is equipped with a navigation radio. The navigation signal splitter distributes the navigation signal to both the telematics communication interface control module and the human machine interface control module or radio. The telematics communication interface control module supplies 5 V through the coax cable to power the internal antenna amplifier through the signal splitter. The Human Machine Interface Control Module supplies 5 V through the center conductor of the coax cable to power the splitter.
The rear displays are located in the back of the driver and front passenger seats. The rear seatback display screens show video from the media disc player, or an AUX input device.
The seatback displays receive power and ground from the vehicle harness. A discrete control circuit from the media disc player is used to control the power state of the displays. The displays receive all other video, audio, and control information via the LVDS cable.
The left display contains the infrared transmitters for the wireless headphones. During operation, the infrared transmitters may be visible as illuminated LEDs. The LEDs are not on visible on the right video screen. Both displays contain an infrared receiver for the remote control.
The wireless remote control is used to operate the system from the rear seat. Infrared signals from the remote control are received by the infrared receivers in each of the seatback displays. The remote control can be used to turn the rear screens on or off, to change system settings, and to select the source for the screens from the media available to the infotainment system. Refer to the Owners Manual for additional information on remote control functions.
The rear displays are located in the back of the driver and front passenger seats. The rear seatback display screens show video from the media disc player, or an AUX input device.
The seatback displays receive power and ground from the vehicle harness. A discrete control circuit from the media disc player is used to control the power state of the displays. The displays receive all other video, audio, and control information via the LVDS cable.
The left display contains the infrared transmitters for the wireless headphones. During operation, the infrared transmitters may be visible as illuminated LEDs. The LEDs are not on visible on the right video screen. Both displays contain an infrared receiver for the remote control.
A power button on the headphone is used to turn the headphone on. A red LED illuminated when the headphone is turned ON. The headphones automatically turn OFF if they lose the infrared signal from the system for approximately 4 minutes in order to preserve their battery power. The signal may be lost if the system is turned off or if the headphones are out of range of the infrared signal transmitters.
Each set of headphones has a rotary volume control on one of the earpieces. To adjust the volume, adjust this control.
Audio to the wireless headphones is provided over 2 channels. Audio for channel 1 is from the source of the left display, audio for channel 2 is from the right display. This allows rear seat passengers to utilize the screens individually without disturbing one another. Pressing the button in the center of the headphone volume will switch the headphone between channels.
The telematics communication interface control module is capable of interpreting voice commands received over the cellular microphone circuit. Speech recognition allows the user to speak to one computer in the vehicle, and one reached over the cellular communication network. The module attempts to understand the users command, and responds by speaking back, or by taking the appropriate action, e.g. dialing the phone.
When voice recognition for the infotainment system is started, voice signals from the cellular phone microphone are passed through the telematics communication interface control module to the Human Machine Interface Control Module via the voice recognition audio circuits.
OnStar Description and Operation
This OnStar® system consists of the following components
- Telematics communication interface control module
- OnStar® three button assembly
- Microphone
- Cellular antenna
- Navigation antenna
- Bluetooth® antenna (If equipped)
- Back up battery (If equipped)
This system also interfaces with the factory installed vehicle audio system.
Scheme 15
| Callout | Component Name |
|---|---|
| HW | Hard-Wired |
| HW | Hard-Wired |
| HW | Hard-Wired |
| HW | Hard-Wired |
| HW | Hard-Wired |
| DB | Serial Data - GMLAN Low Speed |
| DD | Serial Data - GMLAN High Speed |
| B24 | B24 Cellular Phone Microphone |
| C3 | C3 Telematics Communication Interface Control Module Battery |
| S51 | S51 Telematics Button Assembly |
| T4G | T4G Cellular Phone, Navigation, and Digital Radio Antenna |
| T4S | T4S Wireless Communication Antenna - Bluetooth |
| K73 | K73 Telematics Communication Interface Control Module |
| A11 | A11 Radio |
| X84 | X84 Data Link Connector |
Mobile Identification Number and Mobile Directory Number
The telematics communication interface control module utilizes 2 numbers for cellular device identification, call routing and connection, a mobile identification number and a mobile directory number. The mobile identification number represents the number used by the cellular carrier for call routing purposes while the mobile directory number represents the number dialed to reach the cellular device.
Operation of the OnStar® Speech Recognition Systems
OnStar® users communicate with 2 speech recognition systems. Speech recognition allows the user to speak to one computer in the vehicle, and one reached over a phone line. The computer tries to understand the users command, and responds by speaking back, or by taking the appropriate action, e.g. dialing the phone.
- Personal Calling uses a speech recognition system that resides in the vehicle. When the user presses the phone button, the system states, Ready, and listens for the user's command. The user can speak commands to control the hands-free phone.
- Virtual advisor is a remote speech recognition system that the caller can access by making a phone call. The user connects to virtual advisor by requesting it during personal calling use. The user is then transferred to the virtual advisor server and talks to it via a cellular connection.
The OnStar® speech recognition systems use speech technology that is designed to understand a wide range of American English speakers. Although there is no one right way to speak English, the system will work best when users try to modify their pronunciation should they encounter difficulty. Users who do not obtain good results are advised to try the tips and workarounds found in this section.
| Concern | Tip for Better Result |
|---|---|
| Noise | Noise may confuse the speech recognition system. You usually get better performance from the system in quieter conditions: The HVAC fan creates noise. Turn it down or OFF for better speech system performance. Driving at high speeds creates louder engine noise and wind noise. You may get better results at lower speeds. An open window or an open sunroof allows more noise to enter the vehicle. Close all windows for better results. Noisy rainstorms can also reduce performance. If passengers are talking while you use the speech system, it may be confused by their speech. You will get better results if all occupants of the vehicle are quiet while the system is listening for commands. |
| When to Speak | In Personal Calling, the system is only listening after it prompts you to speak with a beep. When the system prompts you to speak, you have about 5 seconds to respond. If the system does not hear a response, it will prompt you again, or cancel the transaction. If you begin to speak too soon, try pausing for a half second before speaking after the beep. In the Virtual Advisor, the system is always listening for commands, even while it is speaking. |
| How to Speak | Speak forcefully, and clearly. The noisier the environment, the louder you need to speak. If you are in the driver seat, speak facing the front of the car. If you are a passenger, speak facing the rearview mirror. Speak calmly, and naturally. The system may sometimes fail your repeated attempts to give a command. If your speech is distorted by shouting or frustration, this may cause more errors. People with high-pitched voices may have better results by speaking in a deeper, lower-pitched voice. However, do not lower the volume of the voice. Avoid speaking with a rising intonation, like asking a question. Use a flat or falling intonation, like giving an answer. |
| What to Say | Personal Calling: One-word commands The Personal Calling system listens for only one word at a time. There are some exceptions, 2-word phrases that are spoken and understood as a single word, e.g. "virtual advisor", "voice feedback", and "my number". You can enter phone numbers only one digit at a time, and the system repeats each digit as it hears it. Say "Help" at the Ready prompt to hear the list of Personal Calling commands. Virtual Advisor can understand sentences with more than one word. It also expects to hear a 4-digit number all at once when it asks for your PIN. Say, "What are my choices?" to hear a list of commands that the Virtual Advisor understands. |
| Entering a phone number | If you have trouble getting numbers correctly into the system, store your frequently-called number in the directory, so the system will remember them. After you have stored a number with a nametag, then you simply say "call" and the nametag in order to call the number. If the system cannot understand your numbers, ask another person to help you enter your frequently-called numbers. This person can speak the numbers, then you can speak the nametag. |
| Storing or dialing a number | When you have finished speaking your phone number, you do not need to say "store" or "dial" to indicate that you are done. If you pause and say nothing, the system will ask you if you want to store or dial. Say "yes". |
| Creating nametags | Short nametags that are similar may be easily confused by the system. You may get better recognition of your nametags if you make them longer, for example "George Washington" without pause, instead of "George" only. If you want to use nametags while driving, it is best to store the nametag with some vehicle noise in the background. If you are in park while you are storing nametags, you can turn the fan on low or open windows in order to create some background noise. |
| Virtual Advisor 4-digit PIN | Say the 4 digits in a natural way, without pausing between digits. |
| Interrupting | When the Virtual Advisor is speaking, you can interrupt it with another command. The first word in your command helps to get its attention. If the Virtual Advisor has trouble understanding your commands when you interrupt, try speaking the first word loudly and clearly, then pause for an instant, then continue with the rest of the command. For example: "Get ... my weather" or "Lookup... a quote for General Motors". |
General Tips for Better Speech Recognition
Radio/Audio System Description and Operation
The entertainment system on this vehicle may have several different configurations available to it. To determine the specific configuration of the vehicle, please see the Service Parts ID Label, and refer to RPO Code List .
Each item in the list below represents topics covered in detail below.
- Data Communications
- Remote Radio Receiver
- Human Machine Interface Module
- Media Disc Player
- Audio Amplifier (If equipped)
- Speaker Operation
- Infotainment Controls and Display
- Antenna System
- Radio Reception
- Theft Deterrent
- Bluetooth ® (if equipped)
- Applications (if equipped)
- Auxiliary Audio Input Jack
- USB Port and SD Card Reader
- Navigation System Components and Features (if equipped)
- Valet Mode
- OnStar ®
- Steering Wheel Controls (If equipped)
- Auto Volume Control
Speaker Operation
Speakers turn electrical energy into mechanical energy to move air, using a permanent magnet and an electromagnet. The electromagnet is energized when the radio or amplifier (if equipped) delivers current to the voice coil on the speaker. The voice coil will form a north and south pole that will cause the voice coil and the speaker cone to move in relation to the permanent magnet. The current delivered to the speaker is rapidly changing alternating current (A/C). This causes the speaker cone to move in two directions producing sound.
Video Entertainment System Description and Operation
Each item in the list below represents topics covered below
- Rear Seat Entertainment System Components
- Media Disc Player
- Video Display Screens
- Remote Control
- Wireless Headphones
- Wired Headphone Jack
- Auxiliary Inputs
