Scheme 241
Circuit/System Description
The vehicle is fitted with 12 V accessory power receptacles. The X80A, X80B, X80D, and X80 G accessory power outlets are controlled by an ignition operated relay and are operational when the ignition is turned to either the On or the Accessories positions. The X80C accessory power outlet is controlled by the battery and is always operational.
12 Volt Power Outlet Receptacle Description and Operation
The X80A, X80B, X80D, and X80 G 12 V accessory power receptacles are controlled by an ignition operated relay and are operational when the ignition is turned to either the On or the Accessories positions.
The X80C accessory power outlet is controlled by the battery and is always operational.
See also:
• COMPONENT CONNECTOR END VIEWS - INDEX
