Contents Wiring diagrams Section: Automatic HVAC System All sections

Heating, Ventilation, and Air Conditioning: Removal & Installation Cadillac SRX II facelift

Automatic HVAC System 31 illustrations ~1956 words

Remove and Replace Components/Sub-Assemblies - Exception to SI for Assembly Plant

HVAC Module Components - Exceptions for Part R&R

  1. Evaporator Core is replaced in the SI documentation. However, for assembly plant repair, the entire module with the evaporator core should be replaced as a unit. Install new seal washers on the evaporator.
  2. Heater Core is generally replaced as a separate unit. Unless SI details how to remove the heater core w/o disassembly of the HVAC module, the entire module is required to be replaced.
  3. Broken/Cracked HVAC Module Case - these defects are not to be repaired per SI directions. The plastic assembly or module requires replacement

Condensors - Exceptions for Part R&R

  1. Condensers are serviced in SI documentation as individual units. However, majority of units employed arrive as CRA's (Condenser Radiator Assembly) If the condenser or radiator require replacement, the replacement should be a replacement CRA.
  2. RD desiccant bag replacement. Internal desiccant bag replacement although authorized in SI, is not to be done at assembly plant. If material contamination - from failed compressor or desiccant bag is noted, entire assembly to be replaced and not flushed.

A/C Hoses/Lines- Exceptions for Part R&R

  1. Line Splice - line rub through or damage are to be replaced with new assemblies and not line spliced.
  2. In-Line filters - Assembly plant is not authorized to employ install these filters
  3. Compressor Suction line screens - Assembly plant is not authorized to install suction screens or screen blocks unless specifically authorized by platform engineering.

Control Heads and Sensors - Exceptions for Part R&R

  1. Replace and reprogram control head.
  2. R&R sensors - do not splice into wire harness.
  3. Replace electrical terminals per spec. Do not splice connectors.

Removal Procedure

  1. Disassemble the A/C refrigerant components. Refer to the appropriate repair procedure.
  2. Cap or tape the A/C refrigerant components.
  3. Remove the sealing washer (1) from the A/C refrigerant component.
  4. Inspect the seal washer for signs of damage to help determine the root cause of the failure.
  5. Inspect the A/C refrigerant components for damage or burrs. Repair if necessary.
  6. DISCARD the sealing washer.

Installation Procedure

  1. Inspect the new sealing washer for any signs of cracks, cuts, or damage. Do not use a damaged sealing washer.
  2. Remove the cap or tape from the A/C refrigerant components.
  3. Using a lint-free clean, dry cloth, clean the sealing surfaces of the A/C refrigerant components.
  4. Carefully install the NEW sealing washer (1) onto the A/C refrigerant component. The sealing washer (1) must completely bottom against the surface of the fitting.
  5. Assemble the remaining A/C refrigerant components. Refer to the appropriate repair procedure.
  1. Disassemble the A/C refrigerant components. Refer to the appropriate repair procedure
  2. Cap or tape the A/C refrigerant components.
  3. Remove the O-ring seal (1) from the A/C refrigerant component.
  4. Inspect the O-ring seal for signs of damage to help determine the root cause of the failure.
  5. Inspect the A/C refrigerant components for damage or burrs. Repair if necessary.
  6. DISCARD the O-ring seal.
  1. Inspect the new O-ring seal for any sign of cracks, cuts, or damage.
  2. Remove the cap or tape from the A/C refrigerant components.
  3. Using a lint-free clean, dry cloth, carefully clean the sealing surfaces of the A/C refrigerant components.
  4. Lightly coat the new O-ring seal with mineral base 525 viscosity refrigerant oil.
  5. Carefully slide the NEW O-ring seal (1) onto the A/C refrigerant component.
  6. The O-ring seal (1) must be fully seated.
  7. Assemble the A/C components. Refer to the appropriate repair procedure.
  1. Recover the refrigerant from the A/C system. Refer to «Refrigerant Recovery and Recharging (Belt Driven Compressor)»(ref-644713-S28190511042014072300000)
  2. Remove the intake manifold cover. refer to «Intake Manifold Cover Replacement»(ref-644732-S38415281782014072300000)
  3. Remove the air cleaner assembly. Refer to «Air Cleaner Assembly Replacement»(ref-644756-S26126150622014072300000)
  4. Remove the radiator air lower deflector. Refer to «Radiator Air Lower Deflector Replacement»(ref-644705-S13733901552014072300000)
  5. Remove the air conditioning condenser and air conditioning evaporator tube nut (1) at thermal expansion valve.
  6. Remove the air conditioning condenser and air conditioning evaporator tube (2) from thermal expansion valve.
  7. Remove the air conditioning condenser and air conditioning evaporator tube nut (1) at condenser.
  8. Remove the air conditioning condenser and air conditioning evaporator tube (2) from condenser.
  9. Remove the air conditioning condenser and evaporator hose nut (1) at air conditioning condenser and air conditioning evaporator tube.
  10. Remove the air conditioning condenser and evaporator hose (2) from air conditioning condenser and air conditioning evaporator tube
  11. Remove the air conditioning condenser and air conditioning evaporator tube nut (1) at the frame rail.
  12. Disengage tube retainers from body.
  13. Remove the air conditioning condenser and air conditioning evaporator tube (2) from vehicle.
  1. Install the air conditioning condenser and air conditioning evaporator tube (2) to the vehicle.
  2. Engage tube retainers from body.
  3. Install the air conditioning condenser and air conditioning evaporator tube nut (1) at the frame rail and tighten to 22 (16 lb ft).
  4. Install the air conditioning condenser and evaporator hose (2) from air conditioning condenser and air conditioning evaporator tube
  5. Install the air conditioning condenser and evaporator hose nut (1) at air conditioning condenser and air conditioning evaporator tube and tighten to 22 (16 lb ft).
  6. Install the air conditioning condenser and air conditioning evaporator tube (2) from condenser.
  7. Install the air conditioning condenser and air conditioning evaporator tube nut (1) at condenser and tighten to 22 (16 lb ft).
  8. Install the air conditioning condenser and air conditioning evaporator tube (2) from thermal expansion valve.
  9. Install the air conditioning condenser and air conditioning evaporator tube nut (1) at thermal expansion valve and tighten to 15 (11 lb ft).
  10. Install the radiator air lower deflector. Refer to «Radiator Air Lower Deflector Replacement»(ref-644705-S13733901552014072300000)
  11. Install the air cleaner assembly. Refer to «Air Cleaner Assembly Replacement»(ref-644756-S26126150622014072300000)
  12. Install the intake manifold cover. refer to «Intake Manifold Cover Replacement»(ref-644732-S38415281782014072300000)
  13. Evacuate and charge the A/C system. Refer to «Refrigerant Recovery and Recharging (Belt Driven Compressor)»(ref-644713-S28190511042014072300000)
  1. Recover the refrigerant from the A/C system. Refer to «Refrigerant Recovery and Recharging (Belt Driven Compressor)»(ref-644713-S28190511042014072300000)
  2. Raise and support the vehicle. Refer to «Air Cleaner Assembly Replacement»(ref-644756-S26126150622014072300000)
  3. Remove the front bumper fascia. Refer to «Front Bumper Fascia Replacement»(ref-644705-S24926557032014072300000)
  4. Disconnect the air conditioning pressure sensor electrical connector.
  5. Remove the air conditioning condenser and evaporator hose bolt (1) at the compressor.
  6. Remove the air conditioning condenser and evaporator hose (2) from the compressor.
  7. Remove the air conditioning condenser and evaporator hose nut (1) at the air conditioning condenser and air conditioning evaporator tube.
  8. Remove the air conditioning condenser and evaporator hose (2) from air conditioning condenser and air conditioning evaporator tube.
  9. Remove the air conditioning condenser and evaporator hose nut (1) at the condenser.
  10. Remove the air conditioning condenser and evaporator hose (2) from the condenser.
  11. Remove the air conditioning condenser and evaporator hose (2) from vehicle.
  12. Remove and discard all sealing washers.
  13. Transfer the air conditioning pressure sensor if necessary.
  1. Install new sealing washers. Refer to «Air Conditioning System Seal Replacement»(ref-644713-S17561598022014072300000)
  2. Install the air conditioning condenser and evaporator hose (2) to the condenser.
  3. Install the air conditioning condenser and evaporator hose nut (1) at the condenser and tighten to 22 N.m (16 lb ft).
  4. Install the air conditioning condenser and evaporator hose (2) to the air conditioning condenser and air conditioning evaporator tube.
  5. Install the air conditioning condenser and evaporator hose nut (1) to air conditioning condenser and air conditioning evaporator tube and tighten to 22 N.m (16 lb ft).
  6. Install the air conditioning condenser and evaporator hose (2) to the compressor.
  7. Install the air conditioning condenser and evaporator hose bolt (1) at compressor and tighten to 22 N.m (16 lb ft).
  8. Connect the air conditioning pressure sensor electrical connector.
  9. Install the front bumper fascia. Refer to «Front Bumper Fascia Replacement»(ref-644705-S24926557032014072300000)
  10. Lower the vehicle.
  11. Evacuate and charge the A/C system. Refer to «Refrigerant Recovery and Recharging (Belt Driven Compressor)»(ref-644713-S28190511042014072300000)
  1. Recover the refrigerant from the A/C system. Refer to «Refrigerant Recovery and Recharging (Belt Driven Compressor)»(ref-644713-S28190511042014072300000)
  2. Using the GE 46246 Valve Core Tool, remove the valve core from the service port.
  1. Install the valve core to the service port.
  2. Using the GE 46246 Valve Core Tool, tighten the valve core to 11 N.m (97 lb in).
  3. Evacuate and recharge the A/C system. Refer to «Refrigerant Recovery and Recharging (Belt Driven Compressor)»(ref-644713-S28190511042014072300000)
  4. Leak test the fittings of the component using GE 50078 Electronic Leak Detector.

Scheme 2

Scheme 2: Receiver and Dehydrator Replacement
Scheme 2: Receiver and Dehydrator Replacement
CalloutComponent Name
Preliminary Procedure Remove the air conditioner condenser. Refer to Air Conditioning Condenser Replacement
1Receiver and Dehydrator Bracket Blot. CAUTION: Refer to Fastener Caution . Tighten 6 N.m (53 lb in)
2Receiver and Dehydrator Bracket
3Receiver and Dehydrator Bolt Tighten 6 N.m (53 lb in)
4Receiver and Dehydrator Procedure Remove and discard O-ring seal. Refer to Air Conditioning O-Ring Seal Replacement
CAUTION
Refer to Fastener Caution .

Receiver and Dehydrator Replacement

Scheme 3

Scheme 3: Air Conditioning Evaporator Thermal Expansion Valve Replacement
Scheme 3: Air Conditioning Evaporator Thermal Expansion Valve Replacement
CalloutComponent Name
Preliminary Procedures Recover the refrigerant. Refer to Refrigerant Recovery and Recharging (Belt Driven Compressor) . Remove the air conditioning condenser and air conditioning evaporator tube from the TXV valve. Refer to Air Conditioning Condenser and Air Conditioning Evaporator Tube Replacement .
1Thermal Expansion Valve Bolt (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten 6 N.m (53 lb in)
2Thermal Expansion Valve TIP: Remove and discard the sealing washers. Refer to Air Conditioning System Seal Replacement .
CAUTION
Refer to Fastener Caution .

Air Conditioning Evaporator Thermal Expansion Valve Replacement

Scheme 4

Scheme 4: Air Conditioning (A/C) Refrigerant Pressure Sensor Replacement
Scheme 4: Air Conditioning (A/C) Refrigerant Pressure Sensor Replacement
CalloutComponent Name
Preliminary Procedures Recover the refrigerant. Refer to Refrigerant Recovery and Recharging (Belt Driven Compressor) . Remove the front bumper facia. Refer to Front Bumper Fascia Replacement
1A/C Refrigerant Pressure Sensor CAUTION: Refer to Fastener Caution . Tighten 5 N.m (44 lb in)
CAUTION
Refer to Fastener Caution .

Air Conditioning (A/C) Refrigerant Pressure Sensor Replacement

Scheme 5

Scheme 5: Evaporator Air Temperature Sensor Replacement
Scheme 5: Evaporator Air Temperature Sensor Replacement
CalloutComponent Name
Preliminary Procedures Remove the instrument panel compartment. Refer to Instrument Panel Compartment Replacement . Reposition any wiring or hoses to gain access to evaporator temperature sensor.
1Evaporator Temperature Sensor Procedure Disconnect the wiring connector Rotate sensor 1/4 turn counter clock wise to remove

Evaporator Air Temperature Sensor Replacement

Scheme 6

Scheme 6: Air Conditioning Condenser Replacement
Scheme 6: Air Conditioning Condenser Replacement
CalloutComponent Name
Preliminary Procedures Recover the refrigerant. Refer to Refrigerant Recovery and Recharging (Belt Driven Compressor) Remove the front bumper facia. Refer to Front Bumper Fascia Replacement Remove the radiator air side baffles. Refer to Radiator Air Side Baffle Replacement - Left Side , and Radiator Air Side Baffle Replacement - Right Side Remove the air conditioning condenser and air conditioning evaporator hose tube from the condenser. Refer to Air Conditioning Condenser and Air Conditioning Evaporator Tube Replacement Remove the air conditioning condenser and evaporator hose from the condenser. Refer to Air Conditioning Condenser and Evaporator Hose Replacement
1Air Conditioning Condenser Bolts (Qty 2) CAUTION: Refer to Fastener Caution . Tighten 9 N.m (80 lb in)
2Air Conditioning Condenser TIP: The air condition condenser is removed through the bottom.
CAUTION
Refer to Fastener Caution .

Air Conditioning Condenser Replacement

Scheme 7

Scheme 7: Heater and Air Conditioning Evaporator Module Replacement
Scheme 7: Heater and Air Conditioning Evaporator Module Replacement
Call outComponent Name
Preliminary Procedures Recover the refrigerant. Refer to Refrigerant Recovery and Recharging (Belt Driven Compressor) . Remove the heater inlet hose from the heater core tube. Refer to Heater Inlet Hose Replacement . Remove the heater outlet hose from the heater core tube. Refer to Heater Outlet Hose Replacement . Remove the air conditioning condenser and air conditioning evaporator tube from thermal expansion valve. Refer to Air Conditioning Condenser and Air Conditioning Evaporator Tube Replacement . Remove the instrument panel tie bar. Refer to Instrument Panel Tie Bar Replacement .
1Heater and Air Conditioning Evaporator and Blower Module Fastener CAUTION: Refer to Fastener Caution . Procedure With the aid of an assistant, remove the heater and air conditioning evaporator and blower module from the vehicle. Tighten 6 N.m (53 lb in)
CAUTION
Refer to Fastener Caution .

Heater and Air Conditioning Evaporator Module Replacement

Scheme 8

Scheme 8: Air Conditioning Evaporator Replacement
Scheme 8: Air Conditioning Evaporator Replacement
Call outComponent Name
Preliminary Procedure Remove the heater and air conditioning evaporator and blower module. Refer to Heater and Air Conditioning Evaporator Module Replacement . Disconnect the heater and air conditioning evaporator and blower module assembly electrical connectors.
1Remove Heater Core Screw and Bracket CAUTION: Refer to Fastener Caution . Tighten 2.5 N.m (23 lb in)
2Remove Heater Core retainer screw Procedure Pull out the heater core. Tighten 2.5 N.m (23 lb in)
3Heater and Blower and Air Conditioning Control Module Procedure Refer to Heater and Blower and Air Conditioning Control Module Replacement .
4A/C Evaporator Thermal Expansion Valve Fastener (Qty: 2) Tighten 6 (53 lb in)
5Air Conditioning Evaporator Thermal Expansion Valve Procedure Remove and discard sealing washers.
6Heater and Air Conditioning Evaporator and Blower Module Case Screw (Qty: 11) Tighten 1.5 N.m (9 lb in)
7Heater and Air Conditioning Evaporator and Blower Module Lower Case
8Air Conditioning Evaporator Core
CAUTION
Refer to Fastener Caution .

Air Conditioning Evaporator Replacement

  1. Drain the cooling system. Refer to «Cooling System Draining and Filling (Static Fill LF1)»(ref-644718-S00232456442014072300000) , «Cooling System Draining and Filling (GE 47716)»(ref-644718-S35370745522014072300000)
  2. Remove the intake manifold cover. Refer to «Intake Manifold Cover Replacement»(ref-644732-S38415281782014072300000)
  3. Disengage tension on the heater inlet hose clamp (1) at the engine using BO 38185 Hose Clamp Pliers.
  4. Remove the heater inlet hose (2) from the engine.
  5. Release the clip from the quick disconnect (1) and remove the heater inlet hose (2) from the heater core tube.
  6. Remove the heater inlet hose from the vehicle.
  1. Install heater inlet hose to the vehicle.
  2. Install the heater inlet hose (2) to the heater core.
  3. Install the heater inlet hose (2) to the engine.
  4. Engage tension on the heater inlet hose clamp (1) at the engine using BO 38185 Hose Clamp Pliers.
  5. Install the intake manifold cover. Refer to «Intake Manifold Cover Replacement»(ref-644732-S38415281782014072300000)
  6. Fill the cooling system. Refer to «Cooling System Draining and Filling (Static Fill LF1)»(ref-644718-S00232456442014072300000) , «Cooling System Draining and Filling (GE 47716)»(ref-644718-S35370745522014072300000)
  1. Drain the cooling system. Refer to «Cooling System Draining and Filling (Static Fill LF1)»(ref-644718-S00232456442014072300000) , «Cooling System Draining and Filling (GE 47716)»(ref-644718-S35370745522014072300000)
  2. Remove the intake manifold cover. Refer to «Intake Manifold Cover Replacement»(ref-644732-S38415281782014072300000)
  3. Disengage tension on the heater outlet hose clamp (1) at the engine using BO 38185 Hose Clamp Pliers.
  4. Remove the heater outlet hose (2) from the engine.
  5. Release the clip from the quick disconnect (1) and remove the heater outlet hose (2) from the heater core tube.
  6. Remove the heater outlet hose from the vehicle.
  1. Install heater outlet hose to the vehicle.
  2. Install the heater outlet hose (2) to the heater core.
  3. Install the heater outlet hose (2) to the engine.
  4. Engage tension on the heater outlet hose clamp (1) at the engine using BO 38185 Hose Clamp Pliers.
  5. Install the intake manifold cover. Refer to «Intake Manifold Cover Replacement»(ref-644732-S38415281782014072300000)
  6. Fill the cooling system. Refer to «Cooling System Draining and Filling (Static Fill LF1)»(ref-644718-S00232456442014072300000) , «Cooling System Draining and Filling (GE 47716)»(ref-644718-S35370745522014072300000)

Scheme 9

Scheme 9: Heater Core Outlet Tube Replacement
Scheme 9: Heater Core Outlet Tube Replacement
CalloutComponent Name
Preliminary Procedure Remove the heater and air conditioning evaporator case. Refer to Heater and Air Conditioning Evaporator Module Replacement .
1Heater Outlet Tube Boot
2Bracket Heater Core Outlet Tube Bolt CAUTION: Refer to Fastener Caution . Tighten 2.5 N.m (23 lb in)
3Heater Core Outlet Tube Brace
4Heater Core Outlet Tube Clamp
5Heater Core Outlet Tube
CAUTION
Refer to Fastener Caution .

Heater Core Outlet Tube Replacement

Scheme 10

Scheme 10: Heater Core Inlet Tube Replacement
Scheme 10: Heater Core Inlet Tube Replacement
CalloutComponent Name
Preliminary Procedure Remove the heater and air conditioning evaporator case. Refer to Heater and Air Conditioning Evaporator Module Replacement .
1Heater Outlet Tube Boot
2Bracket Heater Core Outlet Tube Bolt CAUTION: Refer to Fastener Caution . Tighten 2.5 N.m (23 lb in)
3Heater Core Outlet Tube Brace
4Heater Core Inlet Tube Clamp
5Heater Core Inlet Tube
CAUTION
Refer to Fastener Caution .

Heater Core Inlet Tube Replacement

Scheme 11

Scheme 11: Heater Inlet Hose Connector Replacement (LF1, LFW or LFX)
Scheme 11: Heater Inlet Hose Connector Replacement (LF1, LFW or LFX)
CalloutComponent Name
Preliminary Procedures Remove the heater inlet hose from heater core. Refer to Heater Outlet Hose Replacement
1Heater Inlet Hose Connector Clamp Procedure Reposition heater inlet hose connector clamp using BO 38185 Hose Clamp Pliers. Special Tools BO 38185 Hose Clamp Pliers For equivalent regional tools. Refer to Special Tools
2Heater Inlet Hose Connector

Heater Inlet Hose Connector Replacement (LF1, LFW or LFX)

Scheme 12

Scheme 12: Heater Outlet Hose Connector Replacement (LF1, LFW or LFX)
Scheme 12: Heater Outlet Hose Connector Replacement (LF1, LFW or LFX)
CalloutComponent Name
Preliminary Procedures Remove the heater outlet hose from heater core. Refer to Heater Outlet Hose Replacement
1Heater Outlet Hose Connector Clamp Procedure Reposition heater outlet hose connector clamp using BO 38185 Hose Clamp Pliers. Special Tools BO 38185 Hose Clamp Pliers For equivalent regional tools. Refer to Special Tools
2Heater Outlet Hose Connector

Heater Outlet Hose Connector Replacement (LF1, LFW or LFX)

Scheme 13

Scheme 13: Passenger Compartment Air Filter Replacement
Scheme 13: Passenger Compartment Air Filter Replacement
Call outComponent Name
Preliminary Procedure Remove instrument panel compartment door compartment. Refer to Instrument Panel Compartment Door Compartment Replacement .
1Passenger Compartment Air Filter Lid
2Passenger Compartment Air Filter

Passenger Compartment Air Filter Replacement

Scheme 14

Scheme 14: Air Inlet Housing Replacement
Scheme 14: Air Inlet Housing Replacement
CalloutComponent Name
Preliminary Procedures Remove the Heater and Air Conditioning Evaporator and Blower Module. Refer to Heater and Air Conditioning Evaporator Module Replacement . Disconnect the electrical connectors as necessary.
1Air Inlet Housing Fastener (Qty: 4) CAUTION: Refer to Fastener Caution . Tighten 2.5 N.m (23 lb in)
2Air Inlet Housing
CAUTION
Refer to Fastener Caution .

Air Inlet Housing Replacement

Scheme 15

Scheme 15: Blower Motor Replacement
Scheme 15: Blower Motor Replacement
CalloutComponent Name
Preliminary Procedure Remove the instrument panel (I/P) insulator panel - right side. Refer to Instrument Panel Insulator Panel Replacement - Right Side . Disconnect the blower motor electrical connector.
1Blower Motor Fastener (Qty: 3) CAUTION: Refer to Fastener Caution . Tighten 1.7 N.m (15 lb in)
2Blower Motor
CAUTION
Refer to Fastener Caution .

Blower Motor Replacement

Scheme 16

Scheme 16: Instrument Panel Outer Air Outlet Replacement - Left Side
Scheme 16: Instrument Panel Outer Air Outlet Replacement - Left Side
CalloutComponent Name
Peliminary Procedure Remove the Instrument Panel Left Instrument Panel Side Trim Panel. Refer to Instrument Panel Side Trim Panel Replacement .
1Instrument Panel Outer Air Outlet Fastener CAUTION: Refer to Fastener Caution . Tighten 2.5 N.m (22 lb in)
2Instrument Panel Outer Air Outlet Assembly Procedure Reach through the opening in the end of the instrument panel and depress the tabs on the bottom of the air outlet assembly. While depressing the tabs, pull the air outlet assembly outward releasing it from the instrument panel.
CAUTION
Refer to Fastener Caution .

Instrument Panel Outer Air Outlet Replacement - Left Side

Scheme 17

Scheme 17: Instrument Panel Center Air Outlet Replacement
Scheme 17: Instrument Panel Center Air Outlet Replacement
CalloutComponent Name
1Instrument Panel Center Trim Panel Procedure Refer to Instrument Panel Center Trim Panel Replacement .
2Instrument Panel Center Air Outlet Assembly Procedure Unsnap the air outlet assemblies from the radio control assembly.

Instrument Panel Center Air Outlet Replacement

Scheme 18

Scheme 18: Instrument Panel Outer Air Outlet Replacement - Right Side
Scheme 18: Instrument Panel Outer Air Outlet Replacement - Right Side
CalloutComponent Name
Preliminary Procedure Remove the Instrument Panel Right Instrument Panel Side Trim Panel. Refer to Instrument Panel Side Trim Panel Replacement .
1Instrument Panel Outer Air Outlet Fastener CAUTION: Refer to Fastener Caution . Tighten 2.5 N.m (22 lb in)
2Instrument Panel Outer Air Outlet Assembly Procedure Reach through the opening in the end of the instrument panel and depress the tabs on the bottom of the air outlet assembly. While depressing the tabs, pull the air outlet assembly outward releasing it from the instrument panel.
CAUTION
Refer to Fastener Caution .

Instrument Panel Outer Air Outlet Replacement - Right Side

Scheme 19

Scheme 19: Instrument Panel Compartment Air and Radio Cooling Duct Replacement
Scheme 19: Instrument Panel Compartment Air and Radio Cooling Duct Replacement
CalloutComponent Name
Preliminary Procedure Remove the radio control. Refer to Radio Control Assembly Replacement . Disconnect the blower motor electrical connector.
1Instrument Panel Compartment Air and Radio Cooling Duct Fastener (Qty: 2) CAUTION: Refer to Fastener Caution .
2Instrument Panel Compartment Air and Radio Cooling Duct
CAUTION
Refer to Fastener Caution .

Instrument Panel Compartment Air and Radio Cooling Duct Replacement

Scheme 20

Scheme 20: Floor Front Air Outlet Duct Replacement
Scheme 20: Floor Front Air Outlet Duct Replacement
Call outComponent Name
Preliminary Procedures Remove the front floor console. Refer to Front Floor Console Replacement .
1Front Floor Console Front Air Duct (Qty: 3) Procedure Disconnect and transfer sensor on left duct, if equipped.

Floor Front Air Outlet Duct Replacement

Scheme 21

Scheme 21: Front Floor Console Rear Air Outlet Replacement
Scheme 21: Front Floor Console Rear Air Outlet Replacement
CalloutComponent Name
1Front Floor Console Upper Cover Procedure Refer to Front Floor Console Rear Trim Panel Replacement - Upper .
2Front Floor Console Rear Air Outlet Assembly Procedure Unsnap the rear air outlet assembly from the front floor console upper rear cover.

Front Floor Console Rear Air Outlet Replacement

Scheme 22

Scheme 22: Windshield Defroster Nozzle Grille Replacement
Scheme 22: Windshield Defroster Nozzle Grille Replacement
CalloutComponent Name
1Windshield Defroster Nozzle Grille Assembly Procedure Use a flat bladed plastic trim tool in order to release the retainer clips securing the windshield defroster nozzle grille to the instrument panel assembly. When reinstalling the defroster nozzle grille start the installation at the left side of the vehicle and work to the right side of the vehicle. Do not begin the installation from the center.

Windshield Defroster Nozzle Grille Replacement

Scheme 23

Scheme 23: Windshield Defroster Nozzle Duct Replacement
Scheme 23: Windshield Defroster Nozzle Duct Replacement
CalloutComponent Name
Preliminary Procedure Remove the instrument panel assembly. Refer to Instrument Panel Assembly Removal . Remove the air distributor duct. Refer to Air Distributor Duct Replacement
1Windshield Defroster Nozzle Duct Fasteners (Qty: 8) CAUTION: Refer to Fastener Caution .
2Windshield Defroster Nozzle Duct
CAUTION
Refer to Fastener Caution .

Windshield Defroster Nozzle Duct Replacement

Scheme 24

Scheme 24: Air Distributor Duct Replacement
Scheme 24: Air Distributor Duct Replacement
CalloutComponent Name
Preliminary Procedures Remove the Instrument panel assembly . Refer to Instrument Panel Assembly Removal . Reposition any wiring or hoses to gain access to air duct.
1Air Distributor Duct Screw (Qty: 6) Tighten 1.5 N.m (13.2 lb in)
2Air Distributor Duct

Air Distributor Duct Replacement

Scheme 25

Scheme 25: Side Window Defogger Outlet Duct Replacement - Left Side
Scheme 25: Side Window Defogger Outlet Duct Replacement - Left Side
CalloutComponent Name
Preliminary Procedure Remove the instrument panel assembly. Refer to Instrument Panel Assembly Removal .
1Side Window Defogger Outlet Duct-Left Procedure Remove the Windshield Defroster Nozzle Duct Replacement. Refer to Windshield Defroster Nozzle Duct Replacement Remove the Side Window Defogger Outlet Duct-Left. Remove the Side Window Defogger Outlet Duct from vehicle.

Side Window Defogger Outlet Duct Replacement - Left Side

Scheme 26

Scheme 26: Side Window Defogger Outlet Duct Replacement - Right Side
Scheme 26: Side Window Defogger Outlet Duct Replacement - Right Side
CalloutComponent Name
Preliminary Procedure Remove the instrument panel assembly. Refer to Instrument Panel Assembly Removal .
1Side Window Defogger Outlet Duct-Rightt Procedure Remove the Windshield Defroster Nozzle Duct Replacement. Refer to Windshield Defroster Nozzle Duct Replacement Remove the Side Window Defogger Outlet Duct-Right. Remove the Side Window Defogger Outlet Duct from vehicle.

Side Window Defogger Outlet Duct Replacement - Right Side

Scheme 27

Scheme 27: Floor Air Outlet Duct Replacement - Left Side
Scheme 27: Floor Air Outlet Duct Replacement - Left Side
CalloutComponent Name
Preliminary Procedures Remove the instrument panel insulator panel- left side. Refer to Instrument Panel Insulator Panel Replacement - Left Side . Remove the instrument panel lower trim panel. Refer to Instrument Panel Lower Trim Panel Replacement - Left Side .
1Floor Air Outlet Duct Retainer (Qty: 4)
2Floor Air Outlet Duct

Floor Air Outlet Duct Replacement - Left Side

Scheme 28

Scheme 28: Floor Air Outlet Duct Replacement - Right Side
Scheme 28: Floor Air Outlet Duct Replacement - Right Side
CalloutComponent Name
Preliminary Procedure Remove the instrument panel compartment. Refer to Instrument Panel Compartment Replacement .
1Floor Air Outlet Duct Fastener (Qty: 4) CAUTION: Refer to Fastener Caution .
2Floor Air Outlet Duct
CAUTION
Refer to Fastener Caution .

Floor Air Outlet Duct Replacement - Right Side

Scheme 29

Scheme 29: Floor Rear Air Outlet Duct Replacement - Left Side
Scheme 29: Floor Rear Air Outlet Duct Replacement - Left Side
CalloutComponent Name
Preliminary Procedures Remove the front floor carpet. Refer to Front Floor Panel Carpet Replacement .
1Front Floor Air Outlet Duct
2Rear Floor Air Outlet Duct

Floor Rear Air Outlet Duct Replacement - Left Side

Scheme 30

Scheme 30: Floor Rear Air Outlet Duct Replacement - Right Side
Scheme 30: Floor Rear Air Outlet Duct Replacement - Right Side
CalloutComponent Name
Preliminary Procedures Remove the front floor carpet. Refer to Front Floor Panel Carpet Replacement .
1Front Floor Air Outlet Duct
2Rear Floor Air Outlet Duct

Floor Rear Air Outlet Duct Replacement - Right Side

Scheme 31

Scheme 31: Heater Core Replacement
Scheme 31: Heater Core Replacement
CalloutComponent Name
Preliminary Procedure Remove the left side instrument panel insulator panel. Refer to Instrument Panel Insulator Panel Replacement - Left Side . Remove the instrument panel lower trim panel. Refer to Instrument Panel Lower Trim Panel Replacement - Left Side . Drain and fill the engine cooling system. Refer to Cooling System Draining and Filling (Static Fill LF1) , Cooling System Draining and Filling (GE 47716) . Place a protective mat over the carpet.
1Heater Core Tube Clamp (Qty: 2) Procedure Pull back the carpet in the area of the heater core.
2Heater Core Tube Assembly Procedure Before disconnecting the heater core tubes from the heater core, place a small drain pan under the heater core tubes to capture any coolant drainage.
3Heater Core Tube Seal (Qty: 2) Procedure Discard the O-ring seal and replace with NEW.
4Heater Core Bracket Fastener CAUTION: Refer to Fastener Caution .
5Heater Core Bracket
6Heater Core Procedure Pull out the heater core.
CAUTION
Refer to Fastener Caution .

Heater Core Replacement

Scheme 32

Scheme 32: Auxiliary Blower Motor Replacement
Scheme 32: Auxiliary Blower Motor Replacement
CalloutComponent Name
Preliminary Procedure Remove the Floor console . Refer to Front Floor Console Replacement . Disconnect all electrical connector. Remove front floor air outlet duct. Refer to Floor Front Air Outlet Duct Replacement Remove the blower motor bracket fastener at bottom of blower assembly.
1Auxiliary Blower Motor Fastener (Qty: 9) CAUTION: Refer to Fastener Caution . Tighten 2.5 N.m (23 lb in)
2Auxiliary Blower Motor
CAUTION
Refer to Fastener Caution .

Auxiliary Blower Motor Replacement

More articles — Heating, Ventilation, and Air Conditioning
