Instrument Panel Trim and Console Trim Cadillac SRX II

Exterior/interior Trim 39 illustrations ~1475 words

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Brake Pedal Assembly to the Instrument Panel Tie Bar Bolts21 N.m15 lb ft
Front Floor Console Armrest Fasteners2.5 N.m22 lb in
Front Floor Console Compartment Cup Holder Fastener2.5 N.m22 lb in
Front Floor Console Compartment Door Lock Fasteners2.5 N.m22 lb in
Front Floor Console Compartment Fastener2.5 N.m22 lb in
Front Floor Console Cover Trim Plate Fasteners2.5 N.m22 lb in
Front Floor Console Fastener2.5 N.m22 lb in
Front Floor Console Front Fasteners9.5 N.m84 lb in
Front Floor Console Lower Rear Trim Panel Fasteners2.5 N.m22 lb in
Front Floor Console Rear Compartment Fasteners2.5 N.m22 lb in
Front Floor Console Rear Fasteners6 N.m53 lb in
Front Floor Console Trim Panel Fastener2.5 N.m22 lb in
Front Floor Console Trim Plate Fastener2.5 N.m22 lb in
Instrument Panel Center Compartment Fasteners2.5 N.m22 lb in
Instrument Panel Cluster Trim Plate Fasteners2.5 N.m22 lb in
Instrument Panel Compartment Door Compartment Fasteners2.5 N.m22 lb in
Instrument Panel Compartment Fasteners2.5 N.m22 lb in
Instrument Panel Drivers Knee Bolster Panel Fasteners2.5 N.m22 lb in
Instrument Panel Drivers Knee Bolster Reinforcement Fasteners9 N.m80 lb in
Instrument Panel Inflatable Restraint to the Instrument Panel Assembly9 N.m80 lb in
Instrument Panel Lower Trim Panel Fasteners2.5 N.m22 lb in
Instrument Panel Lower Trim Panel Outer Filler Fastener2.5 N.m22 lb in
Instrument Panel Tie Bar to the HVAC module Bolts6 N.m53 lb in
Instrument Panel Tie Bar to the Vehicle Bolts22 N.m16 lb ft
Instrument Panel Tie Bar to the Vehicle Nuts22 N.m16 lb ft
Instrument Panel to the Vehicle Bolt2.5 N.m22 lb in
Instrument Panel to the Vehicle Nuts9 N.m80 lb in
Instrument Panel Upper Trim Panel Fasteners2.5 N.m22 lb in

Scheme 54

Scheme 54: Instrument Panel Insulator Panel Replacement - Right Side
Scheme 54: Instrument Panel Insulator Panel Replacement - Right Side
CalloutComponent Name
1Instrument Panel Insulator Panel Retainers (Qty: 4)
2Instrument Panel Insulator Panel Assembly Procedure Disconnect the electrical connections. When replacing the instrument panel insulator panel, transfer all necessary components. When reinstalling the instrument panel right insulator, ensure the tab located on the right edge of the insulator is engaged behind the right body hinge pillar trim panel.

Scheme 55

Scheme 55: Instrument Panel Insulator Panel Replacement - Left Side
Scheme 55: Instrument Panel Insulator Panel Replacement - Left Side
CalloutComponent Name
Preliminary Procedure: Remove the drivers knee bolster panel. Refer to Driver Knee Bolster Panel Replacement .
1Instrument Panel Insulator Panel Retainers (Qty: 4)
2Instrument Panel Insulator Panel Assembly Procedure Disconnect the electrical connections. When replacing the instrument panel insulator panel, transfer all necessary components.

Scheme 56

Scheme 56: Instrument Panel Trim Panel Replacement
Scheme 56: Instrument Panel Trim Panel Replacement
CalloutComponent Name
1Instrument Panel Assembly Refer to Instrument Panel Assembly Removal .
2Instrument Panel Upper Trim Panel Refer to Instrument Panel Upper Trim Panel Replacement .
3Instrument Panel Trim Panel Procedures Note location and routing of the instrument panel flood lamp electrical wires in order to ensure proper reinstallation. Disconnect the electrical connection. When replacing the instrument panel trim panel, transfer all necessary components.

Scheme 57

Scheme 57: Instrument Panel Accessory Switch Trim Panel Replacement - Left Side
Scheme 57: Instrument Panel Accessory Switch Trim Panel Replacement - Left Side
CalloutComponent Name
1Instrument Panel Assembly Refer to Instrument Panel Assembly Removal .
2Instrument Panel Upper Trim Panel Refer to Instrument Panel Upper Trim Panel Replacement .
3Instrument Panel Accessory Switch Trim Panel Procedures Note location and routing of the instrument panel flood lamp electrical wires in order to ensure proper reinstallation. Disconnect the electrical connection. When replacing the instrument panel accessory switch panel, transfer all necessary components.

Scheme 58

Scheme 58: Instrument Panel Accessory Switch Trim Panel Replacement - Center
Scheme 58: Instrument Panel Accessory Switch Trim Panel Replacement - Center
CalloutComponent Name
1Instrument Panel Accessory Trim Panel Assembly Procedures Use a flat bladed plastic trim tool in order to release the retainer clips securing the accessory trim panel to the instrument panel assembly. Disconnect the electrical connections. When replacing the instrument panel accessory trim plate, transfer all necessary components.

Scheme 59

Scheme 59: Driver Knee Bolster Panel Replacement
Scheme 59: Driver Knee Bolster Panel Replacement
CalloutComponent Name
Preliminary Procedure: Remove the left instrument panel side trim panel. Refer to Instrument Panel Side Trim Panel Replacement .
1Instrument Panel Drivers Knee Bolster Panel Fasteners (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten: 2.5 N.m (22 lb in)
2Instrument Panel Drivers Knee Bolster Panel Assembly Procedure: Grasp the instrument panel knee bolster panel and pull rearward releasing the retainer clips securing the instrument panel knee bolster to the instrument panel assembly.
CAUTION
Refer to Fastener Caution .

Scheme 60

Scheme 60: Driver Knee Bolster Reinforcement Replacement
Scheme 60: Driver Knee Bolster Reinforcement Replacement
CalloutComponent Name
Preliminary Procedure: Remove the instrument panel drivers knee bolster assembly. Refer to Driver Knee Bolster Panel Replacement .
1Instrument Panel Drivers Knee Bolster Reinforcement Fasteners (Qty: 4) CAUTION: Refer to Fastener Caution . Tighten: 9 N.m (80 lb in)
2Instrument Panel Drivers Knee Bolster Reinforcement
CAUTION
Refer to Fastener Caution .

Scheme 61

Scheme 61: Instrument Panel Side Trim Panel Replacement
Scheme 61: Instrument Panel Side Trim Panel Replacement
CalloutComponent Name
1Instrument Panel Side Trim Panel Assembly (Right or Left) Procedure: Use a flat bladed plastic trim tool in order to release the retainer clips securing the instrument panel side trim panel to the instrument panel assembly.

Scheme 62

Scheme 62: Instrument Panel Upper Trim Panel Replacement
Scheme 62: Instrument Panel Upper Trim Panel Replacement
CalloutComponent Name
Preliminary Procedure Remove the instrument panel assembly from the vehicle. Refer to Instrument Panel Assembly Removal . Remove the windshield defroster nozzle duct. Refer to Windshield Defroster Nozzle Duct Replacement . Remove the instrument panel sound deadening material.
1Instrument Panel Upper Trim Panel Fasteners (Qty: 17) CAUTION: Refer to Fastener Caution . Tighten: 2.5 N.m (22 lb in)
2Instrument Panel Upper Trim Panel Procedure: Grasp the instrument panel upper trim panel and pull upward releasing the retainer clips securing the instrument panel upper trim panel to the carrier assembly.
CAUTION
Refer to Fastener Caution .

Scheme 63

Scheme 63: Instrument Panel Cluster Trim Plate Cover Replacement
Scheme 63: Instrument Panel Cluster Trim Plate Cover Replacement
CalloutComponent Name
1Instrument Panel Cluster Trim Plate Cover Assembly Procedure: Use a flat bladed plastic trim tool in order to release the retainer clips securing the cluster trim plate cover to the cluster bezel.

Scheme 64

Scheme 64: Instrument Panel Cluster Trim Plate Replacement
Scheme 64: Instrument Panel Cluster Trim Plate Replacement
CalloutComponent Name
Preliminary Procedure: Remove the instrument cluster trim plate cover. Refer to Instrument Panel Cluster Trim Plate Cover Replacement .
1Instrument Panel Cluster Trim Plate Fasteners (Qty: 3) CAUTION: Refer to Fastener Caution . Tighten: 2.5 N.m (22 lb in)
2Instrument Panel Cluster Trim Plate Assembly Procedure Use a flat bladed plastic trim tool in order to release the steering column upper trim panel seal retainers. Grasp the instrument panel cluster trim plate and pull rearward releasing the retainer clips securing the cluster panel to the instrument panel assembly.
CAUTION
Refer to Fastener Caution .

Scheme 65

Scheme 65: Instrument Panel Lower Trim Panel Outer Filler Replacement
Scheme 65: Instrument Panel Lower Trim Panel Outer Filler Replacement
CalloutComponent Name
Preliminary Procedures Remove the right instrument panel side trim panel. Refer to Instrument Panel Side Trim Panel Replacement . Remove the instrument panel compartment assembly. Refer to Instrument Panel Compartment Replacement .
1Instrument Panel Lower Trim Panel Outer Filler Fastener (Qty: 4) CAUTION: Refer to Fastener Caution . Tighten: 2.5 N.m (22 lb in)
2Instrument Panel Lower Trim Panel Outer Filler Assembly
CAUTION
Refer to Fastener Caution .

Scheme 66

Scheme 66: Instrument Panel Lower Trim Panel Replacement - Left Side
Scheme 66: Instrument Panel Lower Trim Panel Replacement - Left Side
CalloutComponent Name
Preliminary Procedure: Use a flat bladed plastic trim tool and release the retainer clips securing the front forward edge of the left front floor console extension enough to access the instrument panel lower trim panel fastener. Do NOT remove the complete front floor console extension panel, only release the retainer clips securing the forward edge.
1Instrument Panel Lower Trim Panel Fastener CAUTION: Refer to Fastener Caution . Tighten: 2.5 N.m (22 lb in)
2Instrument Panel Lower Trim Panel Assembly Procedure: Grasp the instrument panel lower trim panel and pull rearward disengaging the retainer clips securing the panel to the instrument panel assembly.
CAUTION
Refer to Fastener Caution .

Scheme 67

Scheme 67: Instrument Panel Lower Trim Panel Replacement - Right Side
Scheme 67: Instrument Panel Lower Trim Panel Replacement - Right Side
CalloutComponent Name
Preliminary Procedure: Use a flat bladed plastic trim tool and release the retainer clips securing the front forward edge of the left front floor console extension enough to access the instrument panel lower trim panel fastener. Do NOT remove the complete front floor console extension panel, only release the retainer clips securing the forward edge.
1Instrument Panel Lower Trim Panel Fasteners (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten: 2.5 N.m (22 lb in)
2Instrument Panel Lower Trim Panel Assembly Procedure: Grasp the instrument panel lower trim panel and pull rearward disengaging the retainer clips securing the panel to the instrument panel assembly.
CAUTION
Refer to Fastener Caution .

Scheme 68

Scheme 68: Instrument Panel Center Compartment Replacement
Scheme 68: Instrument Panel Center Compartment Replacement
CalloutComponent Name
Preliminary Procedure: Remove the front floor console trim plate. Refer to Front Floor Console Trim Plate Replacement .
1Instrument Panel Center Compartment Fasteners (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten: 2.5 N.m (22 lb in)
2Instrument Panel Center Compartment Assembly Procedures Grasp the instrument panel center compartment and pull rearward releasing the retainer clips securing the compartment to the instrument panel assembly. Disconnect the electrical connections, if applicable.
CAUTION
Refer to Fastener Caution .

Scheme 69

Scheme 69: Instrument Panel Compartment Replacement
Scheme 69: Instrument Panel Compartment Replacement
CalloutComponent Name
Preliminary Procedures Remove the right instrument panel insulator panel. Refer to Instrument Panel Insulator Panel Replacement - Right Side . Remove the right instrument panel side trim panel. Refer to Instrument Panel Side Trim Panel Replacement . Remove the right instrument panel lower trim panel. Refer to Instrument Panel Lower Trim Panel Replacement - Right Side .
1Instrument Panel Compartment Air Outlet Procedure: Use a flat bladed plastic trim tool in order to release the outlet assembly from the instrument compartment.
2Instrument Panel Compartment Fasteners (Qty: 9) CAUTION: Refer to Fastener Caution . Tighten: 2.5 N.m (22 lb in)
3Instrument Panel Compartment Assembly Procedures Disconnect the electrical connections. When replacing the instrument panel compartment assembly, transfer all necessary components.
CAUTION
Refer to Fastener Caution .

Scheme 70

Scheme 70: Instrument Panel Compartment Door Replacement
Scheme 70: Instrument Panel Compartment Door Replacement
CalloutComponent Name
Preliminary Procedures Remove the instrument panel compartment assembly. Refer to Instrument Panel Compartment Replacement . Remove the instrument panel compartment door dampener assembly. Refer to Instrument Panel Compartment Door Dampener Replacement (Lower Compartment) or Instrument Panel Compartment Door Dampener Replacement (Center Compartment) .
1Instrument Panel Compartment Door Assembly Procedure: Unsnap the instrument panel compartment door assembly from the instrument compartment door opening frame assembly.

Scheme 71

Scheme 71: Instrument Panel Compartment Door Compartment Replacement
Scheme 71: Instrument Panel Compartment Door Compartment Replacement
CalloutComponent Name
1Instrument Panel Compartment Door Compartment Fasteners (Qty: 4) CAUTION: Refer to Fastener Caution . Tighten: 2.5 N.m (22 lb in)
2Instrument Panel Compartment Door Compartment Assembly
CAUTION
Refer to Fastener Caution .

Scheme 72

Scheme 72: Instrument Panel Compartment Door Opening Frame (Lower Compartment)
Scheme 72: Instrument Panel Compartment Door Opening Frame (Lower Compartment)
CalloutComponent Name
1Instrument Panel Compartment Door Dampener Assembly Refer to Instrument Panel Compartment Door Dampener Replacement (Lower Compartment) or Instrument Panel Compartment Door Dampener Replacement (Center Compartment) .
2Instrument Panel Compartment Door Assembly Refer to Instrument Panel Compartment Door Replacement .
3Instrument Panel Compartment Door Opening Frame Procedure: When replacing the instrument panel compartment door opening frame assembly, transfer all necessary components.

Scheme 73

Scheme 73: Instrument Panel Compartment Door Opening Frame Replacement (Center Compartment)
Scheme 73: Instrument Panel Compartment Door Opening Frame Replacement (Center Compartment)
CalloutComponent Name
Preliminary Procedures: Remove the instrument panel center compartment assembly. Refer to Instrument Panel Center Compartment Replacement .
1Coin Catcher Lower Bin
2Instrument Panel Center Compartment Door Opening Frame Procedure: Gently release the six securing tabs securing the compartment door frame to the compartment assembly.

Scheme 74

Scheme 74: Instrument Panel Compartment Door Latch Replacement
Scheme 74: Instrument Panel Compartment Door Latch Replacement
CalloutComponent Name
Preliminary Procedures: Remove the instrument panel center compartment assembly. Refer to Instrument Panel Center Compartment Replacement .
1Instrument Panel Center Compartment Door Latch Procedure Open the compartment door assembly. Squeeze the tabs securing the latch to the compartment assembly and push the latch outward removing it from the compartment.

Removal Procedure

  1. Lift up on the instrument panel compartment door latch.
  2. Use a suitable tool and depress the retaining tumbler (1) through the access hole indicated.
  3. With the retaining tumbler (1) depressed, remove the instrument panel compartment door lock cylinder (2) from the instrument panel compartment door latch assembly.

Installation Procedure

  1. Position the instrument panel compartment door lock cylinder (2) to the opening in the compartment door latch, while depressing the retainer tumbler (1).
  2. Insert the instrument panel door lock cylinder (2) fully into the latch assembly.
  3. An audible click should be heard when the door lock cylinder (2) is fully seated into the latch assembly.
  4. Ensure proper operation of the instrument panel compartment door lock.

Scheme 75

Scheme 75: Instrument Panel Compartment Door Dampener Replacement (Lower Compartment)
Scheme 75: Instrument Panel Compartment Door Dampener Replacement (Lower Compartment)
CalloutComponent Name
1Instrument Panel Compartment Assembly Refer to Instrument Panel Compartment Replacement .
2Instrument Panel Compartment Door Dampener Fastener
3Instrument Panel Compartment Door Dampener Procedure: Rotate the compartment door dampener assembly while pulling outward to remove the dampener from the instrument panel compartment assembly

Scheme 76

Scheme 76: Instrument Panel Compartment Door Dampener Replacement (Center Compartment)
Scheme 76: Instrument Panel Compartment Door Dampener Replacement (Center Compartment)
CalloutComponent Name
Preliminary Procedures: Remove the instrument panel center compartment assembly. Refer to Instrument Panel Center Compartment Replacement .
1Instrument Panel Center Compartment Door Dampener Fasteners (Qty: 2) CAUTION: Refer to Fastener Caution .
2Instrument Panel Center Compartment Door Dampener
CAUTION
Refer to Fastener Caution .

Scheme 77

Scheme 77: Instrument Panel Upper Trim Cover Replacement (Without U43 or U44)
Scheme 77: Instrument Panel Upper Trim Cover Replacement (Without U43 or U44)
CalloutComponent Name
1Instrument Panel Upper Trim Cover Procedure: Use a flat bladed plastic trim tool in order to remove the trim plate from the instrument panel.
  1. Remove the front seats. Refer to «Driver or Passenger Seat Replacement»(/cadillac/srx/ii-2009-2012/remont/seats/#seat-hardware-seat-trim-and-upholstery) .
  2. Remove the front floor console. Refer to «Front Floor Console Replacement»(/cadillac/srx/ii-2009-2012/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  3. Disconnect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/cadillac/srx/ii-2009-2012/remont/charging-system/#battery-charging-system-and-starting-system) .
  4. Remove the right and left instrument panel side trim panels. Refer to «Instrument Panel Side Trim Panel Replacement»(/cadillac/srx/ii-2009-2012/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  5. Remove the right and left body hinge pillar trim panel. Refer to «Body Hinge Pillar Trim Panel Replacement»(/cadillac/srx/ii-2009-2012/remont/exteriorinterior-trim/#interior-trim-system-and-paneling) .
  6. Remove the steering column assembly. Refer to «Steering Column Replacement»(/cadillac/srx/ii-2009-2012/remont/steering-column-switches/#steering-wheel-and-steering-column) .
  7. Remove the instrument cluster. Refer to «Instrument Cluster Replacement»(/cadillac/srx/ii-2009-2012/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges) .
  8. Remove the radio. Refer to «Radio Replacement»(/cadillac/srx/ii-2009-2012/remont/entertainment-systems/#cellular-systems-entertainment-systems-navigation-systems) .
  9. Remove the instrument panel compartment assembly. Refer to «Instrument Panel Compartment Replacement»(/cadillac/srx/ii-2009-2012/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  10. Remove the windshield defroster nozzle grille. Refer to «Windshield Defroster Nozzle Grille Replacement»(/cadillac/srx/ii-2009-2012/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) .
  11. Remove the right and left windshield garnish moldings. Refer to «Windshield Garnish Molding Replacement»(/cadillac/srx/ii-2009-2012/remont/exteriorinterior-trim/#interior-trim-system-and-paneling) .
  12. Note location and routing of the instrument panel wiring harness prior to removal in order to ensure proper installation.
  13. Disconnect the electrical connections.
  14. Remove the 2 nuts (1) securing the instrument panel inflatable restraint to the instrument panel assembly.
  15. Remove the 7 bolts/screws (1) securing the instrument panel assembly to the vehicle.
  16. Remove the 4 nuts (1) securing the instrument panel assembly to the vehicle.
  17. With the aid of an assistant, remove the instrument panel assembly (1) from the vehicle.
  18. Set the instrument panel assembly down and adequately support it in order to prevent any damage.
  1. With the aid of an assistant, align the instrument panel assembly (1) to the vehicle.
  2. Loosely install the 4 nuts (1).
  3. Loosely install the 7 bolts/screws (1).
  4. Tighten the 7 bolt/screws securing the instrument panel to the vehicle 2.5 N.m (22 lb in).
  5. Tighten the 4 nuts securing the instrument panel assembly to the vehicle 9 N.m (80 lb in).
  6. Install the 2 nuts (1) securing the instrument panel inflatable restraint to the instrument panel assembly, tighten to 9 N.m (80 lb in).
  7. Ensure the wiring harness is routed properly as was noted in the removal procedures.
  8. Connect the electrical connections.
  9. Install the right and left windshield garnish moldings. Refer to «Windshield Garnish Molding Replacement»(/cadillac/srx/ii-2009-2012/remont/exteriorinterior-trim/#interior-trim-system-and-paneling) .
  10. Install the windshield defroster nozzle grille. Refer to «Windshield Defroster Nozzle Grille Replacement»(/cadillac/srx/ii-2009-2012/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) .
  11. Install the instrument panel compartment assembly. Refer to «Instrument Panel Compartment Replacement»(/cadillac/srx/ii-2009-2012/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  12. Install the radio. Refer to «Radio Replacement»(/cadillac/srx/ii-2009-2012/remont/entertainment-systems/#cellular-systems-entertainment-systems-navigation-systems) .
  13. Install the instrument cluster. Refer to «Instrument Cluster Replacement»(/cadillac/srx/ii-2009-2012/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges) .
  14. Install the steering column assembly. Refer to «Steering Column Replacement»(/cadillac/srx/ii-2009-2012/remont/steering-column-switches/#steering-wheel-and-steering-column) .
  15. Install the right and left body hinge pillar trim panel. Refer to «Body Hinge Pillar Trim Panel Replacement»(/cadillac/srx/ii-2009-2012/remont/exteriorinterior-trim/#interior-trim-system-and-paneling) .
  16. Install the right and left instrument panel side trim panels. Refer to «Instrument Panel Side Trim Panel Replacement»(/cadillac/srx/ii-2009-2012/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  17. Connect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/cadillac/srx/ii-2009-2012/remont/charging-system/#battery-charging-system-and-starting-system) .
  18. Install the front floor console. Refer to «Front Floor Console Replacement»(/cadillac/srx/ii-2009-2012/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  19. Install the front seats. Refer to «Driver or Passenger Seat Replacement»(/cadillac/srx/ii-2009-2012/remont/seats/#seat-hardware-seat-trim-and-upholstery) .
  1. Recover the air conditioning refrigerant. Refer to «Refrigerant Recovery and Recharging»(/cadillac/srx/ii-2009-2012/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning)
  2. Drain the engine cooling system. Refer to «Cooling System Draining and Filling (Static Fill LF1)»(/cadillac/srx/ii-2009-2012/remont/cooling-system-mechanical/#engine-cooling-system) or «Cooling System Draining and Filling - Vac-N-Fill(GE 47716)»(/cadillac/srx/ii-2009-2012/remont/cooling-system-mechanical/#engine-cooling-system) or «Cooling System Draining and Filling (Static Fill LAU)»(/cadillac/srx/ii-2009-2012/remont/cooling-system-mechanical/#engine-cooling-system)
  3. Remove the heater inlet hose from the heater core tube. Refer to «Heater Inlet Hose Replacement (LF1)»(/cadillac/srx/ii-2009-2012/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) or «Heater Inlet Hose Replacement (LAU)»(/cadillac/srx/ii-2009-2012/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning)
  4. Remove the heater outlet hose from the heater core tube. Refer to «Heater Outlet Hose Replacement (LF1)»(/cadillac/srx/ii-2009-2012/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) or «Heater Outlet Hose Replacement (LAU)»(/cadillac/srx/ii-2009-2012/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning)
  5. Remove the evaporator hose assembly from the thermal expansion valve. Refer to «Air Conditioning Condenser and Air Conditioning Evaporator Tube Replacement»(/cadillac/srx/ii-2009-2012/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning)
  6. Within the engine compartment area remove the fastener (1) securing the HVAC module assembly to the vehicle body.
  7. Remove the instrument panel assembly from the vehicle. Refer to «Instrument Panel Assembly Removal»(/cadillac/srx/ii-2009-2012/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim)
  8. Remove the communication interface module and bracket assembly. Refer to «Communication Interface Module Bracket Replacement»(/cadillac/srx/ii-2009-2012/remont/entertainment-systems/#cellular-systems-entertainment-systems-navigation-systems)
  9. Remove the body control module and bracket. Refer to «Body Control Module Bracket Replacement»(/cadillac/srx/ii-2009-2012/remont/communication-devices/#data-communication-system)
  10. Remove the four bolts (1) securing the brake pedal assembly to the instrument panel tie bar.
  11. Remove the eleven bolts (1) securing the instrument panel tie bar to the vehicle.
  12. Note location and routing of the instrument panel wiring harness around the instrument panel tie bar prior to removal to ensure proper reinstallation.
  13. Disconnect any retainers securing the instrument panel wiring harness to the tie bar assembly and position the wiring harness out of the way.
  14. With the aid of an assistant remove the instrument panel tie bar and HVAC module assembly as a unit (1) from the vehicle.
  15. Remove the two bolts (1) securing the HVAC module (3) to the instrument panel tie bar assembly (4).
  16. Remove the four nuts (2) securing the HVAC module (3) to the instrument panel tie bar assembly (4).
  17. Separate the HVAC module (3) from the instrument panel tie bar assembly (4).
  1. When replacing the instrument panel tie bar assembly, transfer all necessary components.
  2. Align the HVAC module (3) to the instrument panel tie bar assembly (4).
  3. Loosely install the four nuts (2) securing the HVAC module (3) to the instrument panel tie bar assembly (4).
  4. Loosely install the two bolts (1) securing the HVAC module (3) to the instrument panel tie bar assembly (4).
  5. Tighten the four nuts and the two bolts securing the HVAC module (3) to the instrument panel tie bar assembly (4) to 6 N.m (53 lb in).
  6. With the aid of an assistant position the instrument panel tie bar and HVAC module assembly as a unit (1) into the vehicle.
  7. Reposition the wiring harness as was noted in the removal procedure and re-secure any retainers removed in order to secure the instrument panel wiring harness to the tie bar assembly.
  8. Loosely install the eleven bolts (1) securing the instrument panel tie bar to the vehicle.
  9. Once all eleven bolts (1) are loosely installed, tighten the bolts to 22 N.m (16 lb ft).
  10. Loosely install the four bolts (1) securing the brake pedal assembly to the instrument panel tie bar.
  11. Once all four bolts (1) are loosely installed, tighten the bolts to 21 N.m (15 lb ft)
  12. Install the body control module and bracket. Refer to «Body Control Module Bracket Replacement»(/cadillac/srx/ii-2009-2012/remont/communication-devices/#data-communication-system)
  13. Install the communication interface module and bracket assembly. Refer to «Communication Interface Module Bracket Replacement»(/cadillac/srx/ii-2009-2012/remont/entertainment-systems/#cellular-systems-entertainment-systems-navigation-systems)
  14. Install the instrument panel assembly from the vehicle. Refer to «Instrument Panel Assembly Removal»(/cadillac/srx/ii-2009-2012/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim)
  15. Within the engine compartment area install the fastener (1) securing the HVAC module assembly to the vehicle body, tighten the fastener (1) to 1.4 N.m (12 lb in).
  16. Install the evaporator hose assembly to the thermal expansion valve. Refer to «Air Conditioning Condenser and Air Conditioning Evaporator Tube Replacement»(/cadillac/srx/ii-2009-2012/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning)
  17. Install the heater outlet hose to the heater core tube. Refer to «Heater Outlet Hose Replacement (LF1)»(/cadillac/srx/ii-2009-2012/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) or «Heater Outlet Hose Replacement (LAU)»(/cadillac/srx/ii-2009-2012/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning)
  18. Install the heater inlet hose to the heater core tube. Refer to «Heater Inlet Hose Replacement (LF1)»(/cadillac/srx/ii-2009-2012/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) or «Heater Inlet Hose Replacement (LAU)»(/cadillac/srx/ii-2009-2012/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning)
  19. Refill the engine cooling system. Refer to «Cooling System Draining and Filling (Static Fill LF1)»(/cadillac/srx/ii-2009-2012/remont/cooling-system-mechanical/#engine-cooling-system) or «Cooling System Draining and Filling - Vac-N-Fill(GE 47716)»(/cadillac/srx/ii-2009-2012/remont/cooling-system-mechanical/#engine-cooling-system) or «Cooling System Draining and Filling (Static Fill LAU)»(/cadillac/srx/ii-2009-2012/remont/cooling-system-mechanical/#engine-cooling-system)
  20. Recharge the air conditioning refrigerant system. Refer to «Refrigerant Recovery and Recharging»(/cadillac/srx/ii-2009-2012/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning)

Scheme 78

Scheme 78: Front Floor Console Compartment Door Lock Replacement
Scheme 78: Front Floor Console Compartment Door Lock Replacement
CalloutComponent Name
Preliminary Procedure: Remove the front floor console upper rear trim panel. Refer to Front Floor Console Rear Trim Panel Replacement - Upper .
1Front Floor Console Compartment Door Lock Fasteners (Qty: 3) CAUTION: Refer to Fastener Caution . Tighten: 2.5 N.m (22 lb in)
2Front Floor Console Compartment Door Lock Assembly
CAUTION
Refer to Fastener Caution .

Scheme 79

Scheme 79: Front Floor Compartment Cup Holder Replacement
Scheme 79: Front Floor Compartment Cup Holder Replacement
CalloutComponent Name
1Front Floor Console Trim Plate Assembly Refer to Front Floor Console Trim Plate Replacement .
2Front Floor Console Compartment Cup Holder Fastener (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten: 2.5 N.m (22 lb in)
3Front Floor Console Compartment Cup Holder Assembly
CAUTION
Refer to Fastener Caution .

Scheme 80

Scheme 80: Front Floor Console Compartment Replacement
Scheme 80: Front Floor Console Compartment Replacement
CalloutComponent Name
Preliminary Procedures Remove the driver and passenger front seats. Refer to Driver or Passenger Seat Replacement . Remove the front floor console upper rear trim panel. Refer to Front Floor Console Rear Trim Panel Replacement - Upper . Remove the front floor console lower rear trim panel. Refer to Front Floor Console Rear Trim Panel Replacement - Lower . Remove the front floor console trim plate. Refer to Front Floor Console Trim Plate Replacement . Remove the front floor console right and left trim panels. Refer to Front Floor Console Trim Panel Replacement .
1Front Floor Console Compartment Fastener (Qty: 8) CAUTION: Refer to Fastener Caution . Tighten: 2.5 N.m (22 lb in)
2Front Floor Console Compartment Assembly Procedure Disconnect the electrical connections. When replacing the front floor console compartment, transfer all necessary components.
CAUTION
Refer to Fastener Caution .

Scheme 81

Scheme 81: Front Floor Console Trim Panel Replacement
Scheme 81: Front Floor Console Trim Panel Replacement
CalloutComponent Name
Preliminary Procedures Remove the driver or passenger front seat. Refer to Driver or Passenger Seat Replacement . Remove the front floor console upper rear trim panel. Refer to Front Floor Console Rear Trim Panel Replacement - Upper . Remove the front floor console lower rear trim panel. Refer to Front Floor Console Rear Trim Panel Replacement - Lower . Remove the front floor console trim plate. Refer to Front Floor Console Trim Plate Replacement .
1Front Floor Console Trim Panel Fastener (Qty: 4) 2 per panel CAUTION: Refer to Fastener Caution . Tighten: 2.5 N.m (22 lb in)
2Front Floor Console Trim Panel Assembly (Right or Left)
CAUTION
Refer to Fastener Caution .

Scheme 82

Scheme 82: Front Floor Console Cover Trim Plate Replacement - Right Side
Scheme 82: Front Floor Console Cover Trim Plate Replacement - Right Side
CalloutComponent Name
Preliminary Procedure: Use a flat bladed plastic trim tool and release the retainer clips securing the front forward edge of the left front floor console extension enough to access the instrument panel lower trim panel fastener. Do NOT remove the complete front floor console extension panel, only release the retainer clips securing the forward edge.
1Front Floor Console Cover Trim Plate Fasteners (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten: 2.5 N.m (22 lb in)
2Front Floor Console Cover Trim Plate Assembly Procedure: Use a flat bladed plastic trim tool in order to release the retainer clips securing the front half of the front floor console cover trim plate to the instrument panel assembly.
CAUTION
Refer to Fastener Caution .

Scheme 83

Scheme 83: Front Floor Console Cover Trim Plate Replacement - Left Side
Scheme 83: Front Floor Console Cover Trim Plate Replacement - Left Side
CalloutComponent Name
Preliminary Procedure: Use a flat bladed plastic trim tool and release the retainer clips securing the front forward edge of the left front floor console extension enough to access the instrument panel lower trim panel fastener. Do NOT remove the complete front floor console extension panel, only release the retainer clips securing the forward edge.
1Front Floor Console Cover Trim Plate Fasteners (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten: 2.5 N.m (22 lb in)
2Front Floor Console Cover Trim Plate Assembly Procedure: Use a flat bladed plastic trim tool in order to release the retainer clips securing the front half of the front floor console cover trim plate to the instrument panel assembly.
CAUTION
Refer to Fastener Caution .

Scheme 84

Scheme 84: Front Floor Console Rear Trim Panel Replacement - Upper
Scheme 84: Front Floor Console Rear Trim Panel Replacement - Upper
CalloutComponent Name
1Front Floor Console Upper Rear Trim Panel Assembly Procedure Grasp the lower edge of the front floor console upper rear trim panel and pull outward just enough to release the lower retainer clips. While holding the lower edge outward lift upward releasing the upper retainer clips securing the front floor console upper trim panel to the console assembly. Disconnect the electrical connections. When replacing the front floor console upper rear trim panel, transfer all necessary components.

Scheme 85

Scheme 85: Front Floor Console Rear Trim Panel Replacement - Lower
Scheme 85: Front Floor Console Rear Trim Panel Replacement - Lower
CalloutComponent Name
Preliminary Procedure: Remove the front floor console upper rear trim panel. Refer to Front Floor Console Rear Trim Panel Replacement - Upper .
1Front Floor Console Lower Rear Trim Panel Fasteners (Qty: 4) CAUTION: Refer to Fastener Caution . Tighten: 2.5 N.m (22 lb in)
2Front Floor Console Lower Rear Trim Panel Assembly Procedure: When replacing the front floor console lower rear trim panel, transfer all necessary components.
CAUTION
Refer to Fastener Caution .

Scheme 86

Scheme 86: Front Floor Console Extension Replacement
Scheme 86: Front Floor Console Extension Replacement
CalloutComponent Name
Preliminary Procedure: Remove the right or left front seat assembly. Refer to Driver or Passenger Seat Replacement .
1Front Floor Console Extension Assembly (Right or Left) Procedure: Use a flat bladed plastic trim tool in order to release the retainer clips securing the front floor console extensions to the front floor console assembly.

Scheme 87

Scheme 87: Front Floor Console Rear Compartment Replacement
Scheme 87: Front Floor Console Rear Compartment Replacement
CalloutComponent Name
1Front Floor Console Lower Rear Trim Panel Refer to Front Floor Console Rear Trim Panel Replacement - Lower .
2Front Floor Console Rear Compartment Fastener (Qty: 4) CAUTION: Refer to Fastener Caution . Tighten: 2.5 N.m (22 lb in)
3Front Floor Console Rear Compartment Assembly Procedure: When replacing the front floor console rear compartment, transfer all necessary components.
CAUTION
Refer to Fastener Caution .

Scheme 88

Scheme 88: Front Floor Console Replacement
Scheme 88: Front Floor Console Replacement
CalloutComponent Name
Preliminary Procedure Remove the front floor console right and left extensions. Refer to Front Floor Console Extension Replacement . Remove the right and left front floor console cover trim plate assemblies. Refer to Front Floor Console Cover Trim Plate Replacement - Right Side and Front Floor Console Cover Trim Plate Replacement - Left Side . Remove the left and right instrument panel lower trim panels. Refer to Instrument Panel Lower Trim Panel Replacement - Left Side and Instrument Panel Lower Trim Panel Replacement - Right Side . Disconnect the automatic transmission control cable. Refer to Range Selector Lever Cable Replacement .
1Front Floor Console Fastener Covers (Qty: 4) Procedure: Use a flat bladed plastic trim tool in order to remove the fastener covers from the console assembly.
2Front Floor Console Rear Fasteners (Qty: 4) CAUTION: Refer to Fastener Caution . Tighten: 6 N.m (53 lb in)
3Front Floor Console Front Fasteners (Qty: 8) Tighten: 9.5 N.m (7 lb ft)
4Front Floor Console Assembly Procedure Disconnect the electrical connections. When replacing the front floor console assembly, transfer all necessary components.
CAUTION
Refer to Fastener Caution .

Scheme 89

Scheme 89: Front Floor Console Armrest Replacement
Scheme 89: Front Floor Console Armrest Replacement
CalloutComponent Name
Preliminary Procedure: Remove the front floor console upper rear trim panel assembly. Refer to Front Floor Console Rear Trim Panel Replacement - Upper .
1Front Floor Console Armrest Fasteners (Qty: 3) CAUTION: Refer to Fastener Caution . Tighten: 2.5 N.m (22 lb in)
2Front Floor Console Armrest Assembly
CAUTION
Refer to Fastener Caution .

Scheme 90

Scheme 90: Front Floor Console Trim Plate Replacement
Scheme 90: Front Floor Console Trim Plate Replacement
CalloutComponent Name
Preliminary Procedures Remove the right and left front floor console cover trim plate assemblies. Refer to Front Floor Console Cover Trim Plate Replacement - Right Side and Front Floor Console Cover Trim Plate Replacement - Left Side . Remove the automatic transmission control boot assembly. Refer to Transmission Control Lever Boot Replacement . Remove the front floor console upper rear trim panel assembly. Refer to Front Floor Console Rear Trim Panel Replacement - Upper . Remove the front floor console armrest assembly. Refer to Front Floor Console Armrest Replacement .
1Front Floor Console Trim Plate Fastener Cover (Qty: 2)
2Front Floor Console Trim Plate Fastener (Qty: 6) CAUTION: Refer to Fastener Caution . Tighten: 2.5 N.m (22 lb in)
3Front Floor Console Fastener (Qty: 2) Tighten: 2.5 N.m (22 lb in)
4Front Floor Console Trim Plate Assembly Procedure Disconnect the electrical connections. When replacing the front floor console trim plate, transfer all necessary components.
CAUTION
Refer to Fastener Caution .

Scheme 91

Scheme 91: Front Floor Console Applique Replacement
Scheme 91: Front Floor Console Applique Replacement
CalloutComponent Name
Preliminary Procedure: Remove the right and left front floor console cover trim plate assemblies. Refer to Front Floor Console Cover Trim Plate Replacement - Right Side and Front Floor Console Cover Trim Plate Replacement - Left Side .
1Front Floor Console Applique Procedure: Grasp the front floor console applique and pull upward releasing the retainer clips securing the front floor console applique to the front floor console assembly.

Scheme 92

Scheme 92: Roof Console Replacement
Scheme 92: Roof Console Replacement
CalloutComponent Name
1Roof Console Assembly Procedures Grasp the roof console assembly and pull downward to release the retainer clips securing the roof console assembly to the headliner. Disconnect the electrical connections. When replacing the roof console assembly, transfer all necessary components.

More articles — Body & Frame
