Seat Belt System Cadillac SRX I

Restraints Control Systems 3 illustrations ~3280 words

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Front Seat Belt to Seat Frame Nut42 N.m31 lb ft
Front Seat Retractor Bolt26 N.m19 lb in
Left and Right Rear Shoulder Belt Retractor Bolts and Nuts70 N.m52 lb ft
Pivot Cover Screws2 N.m18 lb in
Rear Seat Belt Anchor Bolts45 N.m33 lb ft
Rear Seat Buckle Bolts and Nut42 N.m31 lb ft
Rear Seat Center Shoulder Belt Retractor Bolt42 N.m31 lb ft
Seat Belt Roller Assembly Bolt52 N.m38 lb ft
Seat Belt Roller Assembly Cover Screws5 N.m44 lb in

Fastener Tightening Specifications

Seat Belt Schematic Icons

Seat Belt Schematic Icons Icon Icon Definition CAUTION: When performing service on or near the SIR components or the SIR wiring, the SIR system must be disabled. Refer to SIR Disabling and Enabling Zones. Failure to observe the correct procedure could cause deployment of the SIR components, personal injury, or unnecessary SIR system repairs

Scheme 1

Scheme 1: Seat Belt Schematics
Scheme 1: Seat Belt Schematics

Scheme 2

Scheme 2: Seat Belt Component Views
Scheme 2: Seat Belt Component Views
CalloutComponent Name
1Inflatable Restraint Steering Wheel Module Coil Connectors
2Inflatable Restraint Steering Wheel Module
3Inflatable Restraint I/P Module
4Inflatable Restraint I/P Module Connector
5Inflatable Restraint Roof Rail Module Connector - Right, Left Similar
6Inflatable Restraint Roof Rail Module - Right, Left Similar
7Inflatable Restraint Roof Rail Module Tether - Right, Left Similar
8Inflatable Restraint Sensing and Diagnostic Module (SDM) Connector
9Inflatable Restraint SDM
10Inflatable Restraint Side Impact Module - Left, Right Similar
11Seat Belt Pretentioner / Seat Belt Switch - Left, Right Similar
12Front Seat Belt Retractor - Left, Right Similar

Seat Belt Connector End Views

Seat Belt Switch - Left Connector Part Information 12047663 2-Way M Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A PK 5017 Seat Belt Switch Low Reference B WH/TN 238 Left Seat Belt Switch Signal

Diagnostic Starting Point - Seat Belts

Begin the system diagnosis by reviewing the Seat Belt System Description and Operation . Reviewing the description and operation information will help you determine the correct symptom diagnostic procedure when a malfunction exists. Reviewing the description and operation information will also help you determine if the condition described by the customer is normal operation.

Refer to Symptoms - Seat Belts in order to identify the correct procedure for diagnosing the system and where the procedure is located.

Operational and Functional Checks

IMPORTANTIf the vehicle has been in a collision, refer to Repairs and Inspections Required After a Collision for additional information.

Perform the following inspection from the driver seat

  1. Turn the ignition switch to the ON position. Verify proper operation of the seat belt reminder lamp with the belt buckled and with the belt unbuckled.
  2. Inspect the shoulder belt guide in order to ensure that the following conditions are met: The shoulder belt guide swivels freely. The seat belt webbing is seated flat in the guide slot. The seat belt webbing does not bind.
  3. Verify that the seat belt buckle faces inboard and is accessible.
  4. Verify that the seat belt retractor units are securely attached.
  5. Verify that the seat belt anchor bolts are secure.
  6. Fully extend the seat belt webbing. Verify that the seat belt webbing does not have any twists or tears.
  7. Allow the seat belt webbing to retract. Verify that the seat belt webbing returns freely and completely back into the retractor.
  8. Snap the seat belt latch plate into the buckle.
  9. Sharply tug on the seat belt latch plate and the buckle. Verify that the seat belt latch plate and the buckle remain locked when tugged.
  10. Push the button on the buckle. Verify that the seat belt latch plate releases easily from the buckle. Verify that the button returns to its original position.

Perform the following inspection procedure from the passenger seat.

  1. Verify the Automatic Locking Retractor (ALR) feature operates properly by performing the following checks. Pull the seat belt all the way out of the retractor until it stops. Slowly allow the belt to retract partially, while listening for a ratcheting sound. Sharply tug on the belt ensuring that the retractor lock sets and does not allow the belt to be pulled from the retractor. After performing steps 1.1 through 1.3 ensure the belt fully retracts.
  2. Repeat the inspection procedure steps 2 through 10 from the passengers seat.

Perform the following steps in order to inspect the center seat belts

  1. Verify that the center seat belts are accessible.
  2. Verify that the center seat belts have no twists or tears in the webbing.
  3. Snap the center seat belt latch plate into the buckle.
  4. Sharply tug on the seat belt latch plate and the buckle. Verify that the seat belt latch plate and the buckle remain locked when tugged.
  5. Push the button on the buckle. Verify that the seat belt latch plate releases easily from the buckle. Verify that the button returns to its original position.

Repeat the inspection procedure, steps 2-10, from the rear seats.

Repeat the center seat belt inspection procedure, steps 1-5, from the rear seat.

Emergency Locking Retractors

CAUTIONPerform this test in an area clear of other vehicles or obstructions. Do not conduct this test on the open road. A large, empty parking lot is suitable. Failure to observe this precaution may result in damage to the vehicle and possible personal injury.

Scheme 3

Scheme 3
Scheme 3
  1. Fasten the seat belts, an assistant is needed when the retractor under test is not part of the driver seat belt.
  2. Accelerate the vehicle slowly to 16 km/h (10 mph) and apply the brakes firmly.
  3. Verify that the seat belt locks when braking firmly.
  4. If the belt does not lock, proceed with the following steps. IMPORTANT: When performing this check, note the position that the retractors are mounted. Some retractors are not mounted at a zero degree inclination. Remove the seat belt retractor assembly. Tilt the seat belt retractor slowly. Ensure that the seat belt webbing can be pulled from the retractor at an inclination of 15 degrees forward or less, from the retractors mounted position. Ensure the retractor cannot be pulled from the retractor at an inclination of 45 degrees forward or more. If a seat belt retractor does not operate as described, replace the retractor assembly.

Symptoms - Seat Belts

IMPORTANTReview the seat belt system description and operation in order to familiarize yourself with the system and how it functions. Refer to Seat Belt System Description and Operation .

Visual/Physical Inspection

  1. Inspect for aftermarket devices which could affect the operation of the seat belt system. Refer to «Checking Aftermarket Accessories»(/cadillac/srx/i-2003-2009/remont/body-electrical/#how-to-diagnosis-repair-the-wiring-systems-testing__checking-aftermarket-accessories) in Wiring Systems.
  2. Inspect the easily accessible or visible system components for obvious damage or conditions which could cause the symptom.

Intermittent

Faulty electrical connections or wiring may be the cause of intermittent conditions. Refer to Testing for Intermittent Conditions and Poor Connections in Wiring Systems.

Symptom List

Refer to the following symptom diagnostic procedure in order to diagnose the symptom

Seat Belt Indicator Circuit Malfunction

StepActionYesNo
Schematic Reference: Seat Belt Schematics
1Did you review the Seat Belt System Description and Operation and perform the necessary inspections?Go to Step 2Go to Symptoms - Seat Belts
2Turn ON the ignition, with the engine OFF. Monitor the fasten safety belt indicator while buckling and unbuckling the driver seat belt. Does the system operate properly?Go to Testing for Intermittent Conditions and Poor Connections in Wiring SystemsGo to Step 3
3Buckle the driver seat belt. With a scan tool, observe the Driver Side Belt Status parameter in the SIR scan tool data list. Does the scan tool indicate that the Driver Side Belt Status parameter displays Buckled?Go to Step 4Go to Step 5
4Replace the instrument panel cluster (IPC). Refer to Control Module References in Computer/Integrating Systems for replacement, setup, and programming. Did you complete the replacement?Go to Step 8
5Turn OFF the ignition. Disconnect the inflatable restraint sensing and diagnostic module (SDM) connector. Refer to Inflatable Restraint Sensing and Diagnostic Module Replacement in SIR. Disconnect the seat belt switch - LF connector. Test the seat belt switch - left signal circuit for an open or high resistance. Did you find and correct the condition?Go to Step 8Go to Step 6
6Test the seat belt switch - left ground circuit for an open or high resistance. Did you find and correct the condition?Go to Step 8Go to Step 7
7Replace the seat belt switch - LF. Refer to Seat Belt Buckle Pretensioner Replacement in SIR. Did you complete the replacement?Go to Step 8
8Reconnect all components and connectors. Operate the system in order to verify the repair. Did you find and correct the condition?System OKGo to Step 3

Seat Belt Indicator Circuit Malfunction

Seat Belt Service Precautions

  1. Do not bleach or dye the seat belt webbing. Use only the following items in order to clean the seat belt webbing: A mild soap and water solution A soft brush or cloth
  2. Keep sharp edges and damaging objects away from the seat belts. Avoid bending or damaging any part of the seat belt buckle or the latch plate. Replace any seat belts which are cut or damaged in any way.
  3. Use only the correct seat belt anchor bolts/screws and tighten the anchor bolts/screws to the correct torque value. Refer to «Fastener Tightening Specifications»(/cadillac/srx/i-2003-2009/remont/restraints-control-systems/#seat-belt-system__fastener-tightening-specifications) . When installing seat belt anchor bolts, start the bolt by hand to ensure that the bolt is threaded straight.
  4. Some seat belts and retractors require service as a set, with service replacement parts only. Do not attempt to repair to individual components that require service as a set.
  5. Verify that the replacement part number is correct for the vehicle at that seating position. Do not substitute a seat belt from a different seating position.

Repairs and Inspections Required After a Collision

CAUTIONRestraint systems can be damaged in a collision. To help avoid injury and ensure that all parts in need of replacement are replaced: Replace any seat belt system that was in use during the collision serious enough to deploy any automatic restraint device such as air bags and seat belt pretensioners. This not only includes seat belt systems in use by people of adult size, but seat belt systems used to secure child restraints, infant carriers and booster seats, including LATCH system and top tether anchorages. Replace any seat belt system that has torn, worn, or damaged components. This not only includes adult seat belt systems, but built-in child restraints and LATCH system components, if any. Replace any seat belt system if you observe the words "REPLACE" or "CAUTION", or if a yellow tag is visible. Do not replace a seat belt if only the child seat caution label is visible. Replace any seat belt system if you are doubtful about its condition. This not only includes adult seat belt systems, but built-in child restraints, LATCH system components, and any restraint system used to secure infant carriers, child restraints, and booster seats. Do NOT replace single seat belt system components in vehicles that have been in a collision as described above. Always replace the entire seat belt system with the buckle, guide and retractor assembly, which includes the latch and webbing material.

After a minor collision where no automatic restraint device was deployed, seat belt system replacement may not be necessary, unless some of the parts are torn, worn, or damaged.

Removal Procedure

  1. Remove the seat from the vehicle. Refer to «Seat Replacement - Rear No. 1»(/cadillac/srx/i-2003-2009/remont/seats/#seat-system) in Seats.
  2. Remove the left seat cushion. Refer to «Seat Cushion Replacement - Rear No.1 - Left»(/cadillac/srx/i-2003-2009/remont/seats/#seat-system) in Seats.
  3. Remove the pivot trim cover screws (1).
  4. Remove the outer pivot covers.
  5. Remove the seat belt buckle bolt (1).
  6. Remove the seat belt buckle.

Installation Procedure

  1. Position the seat belt buckle to the seat frame.
  2. Install the seat buckle bolt (1). Tighten: Tighten the bolt to 42 N.m (31 lb ft).
  3. Install the pivot cover screws (1). Tighten: Tighten the screws to 2 N.m (18 lb in).
  4. Install the seat cushion. Refer to «Seat Cushion Replacement - Rear No.1 - Left»(/cadillac/srx/i-2003-2009/remont/seats/#seat-system) in Seats.
  5. Install the seat into the vehicle. Refer to «Seat Replacement - Rear No. 1»(/cadillac/srx/i-2003-2009/remont/seats/#seat-system) in Seats.
  1. Remove the seat from the vehicle. Refer to «Seat Replacement - Rear No. 1»(/cadillac/srx/i-2003-2009/remont/seats/#seat-system) in Seats.
  2. Remove the left seat cushion. Refer to «Seat Cushion Replacement - Rear No.1 - Left»(/cadillac/srx/i-2003-2009/remont/seats/#seat-system) in Seats.
  3. Remove the pivot trim cover screws (1).
  4. Remove the outer pivot covers.
  5. Remove the seat belt buckle bolt (1).
  6. Remove the seat belt buckle.
  1. Position the seat belt buckle to the seat frame.
  2. Install the seat belt buckle bolt (1). Tighten: Tighten the bolt to 42 N.m (31 lb ft).
  3. Install the pivot cover screws (1). Tighten: Tighten the screws to 2 N.m (18 lb in).
  4. Install the seat cushion. Refer to «Seat Cushion Replacement - Rear No.1 - Left»(/cadillac/srx/i-2003-2009/remont/seats/#seat-system) in Seats.
  5. Install the seat into the vehicle. Refer to «Seat Replacement - Rear No. 1»(/cadillac/srx/i-2003-2009/remont/seats/#seat-system) in Seats.
  1. Remove the rear seat. Refer to «Seat Replacement - Rear No. 2 - Folding»(/cadillac/srx/i-2003-2009/remont/seats/#seat-system) in Seats.
  2. Lay the seat with the seat back down.
  3. Remove the seat belt buckle nut which is located under the seat motor (1) on the seat frame.
  4. Remove the seat buckle.
  1. Install the seat belt buckle to the seat frame.
  2. Install the seat belt buckle nut. Tighten: Tighten the seat belt buckle nut to 42 N.m (31 lb ft).
  3. Install the rear seat. Refer to «Seat Replacement - Rear No. 2 - Folding»(/cadillac/srx/i-2003-2009/remont/seats/#seat-system) in Seats.
  1. Remove the front seat back trim cover. Refer to «Seat Replacement - Bucket»(/cadillac/srx/i-2003-2009/remont/seats/#seat-system) in Seats.
  2. Remove the front seat cover and pad. Refer to «Seat Back Cover and Pad Replacement - Front»(/cadillac/srx/i-2003-2009/remont/seats/#seat-system) in Seats.
  3. Remove the screws retaining the roller assembly cover and remove the cover.
  4. Remove the bolt retaining the seat belt retractor to the seat frame.
  5. Remove the seat belt lower retaining nut (2).
  6. Remove the seat belt retractor assembly.
  1. Ensure that the seat belt is not twisted before installing the retractor.
  2. Install the seat belt (2) to the mounting stud. Ensure that the anti-rotation tab on the seat belt is located properly in the seat frame before tightening the retaining nut.
  3. Install the retaining nut. Tighten: Tighten the nut to 42 N.m (31 lb ft).
  4. Position the seat belt over the roller assembly. Ensure that the seat belt is not twisted.
  5. Install the seat belt retractor. Ensure that the anti-rotation tab on the seat belt retractor is located properly on the seat frame before tightening the retractor fastener.
  6. Install the retaining bolt. Tighten: Tighten the bolt to 26 N.m (19 lb ft).
  7. Install the roller assembly cover.
  8. Install the roller assembly screws. Tighten: Tighten the fasteners to 5 N.m (44 lb in).
  9. Ensure proper operation of the seat belt retractor.
  10. Reinstall the seat back cover. Refer to «Seat Back Cover and Pad Replacement - Front»(/cadillac/srx/i-2003-2009/remont/seats/#seat-system) in Seats.
  11. Install the front seat. Refer to «Seat Replacement - Bucket»(/cadillac/srx/i-2003-2009/remont/seats/#seat-system) in Seats.
  12. Confirm proper operation of the seat belt retractors.
  1. Remove the seat back trim. Refer to «Seat Back Trim Replacement - Front»(/cadillac/srx/i-2003-2009/remont/seats/#seat-system) in Seats.
  2. Remove the head restraint. Refer to «Head Restraint Replacement - Front Seat»(/cadillac/srx/i-2003-2009/remont/seats/#seat-system) in Seats.
  3. Remove the head restraint retainers. Refer to «Head Restraint Retainer Replacement - Front Seat»(/cadillac/srx/i-2003-2009/remont/seats/#seat-system) in Seats.
  4. Remove the seat back cover far enough to gain access to the roller assembly. Refer to «Seat Back Cover and Pad Replacement - Front»(/cadillac/srx/i-2003-2009/remont/seats/#seat-system) in Seats.
  5. Remove the seat belt roller assembly cover screws.
  6. Remove the seat belt roller assembly cover.
  7. Lift the seat belt over the roller assembly.
  8. Remove the seat belt roller assembly bolt (1) from the lower seat frame.
  9. Remove the roller assembly.
  1. Install the seat belt roller assembly into the seat frame.
  2. Install the roller assembly bolt (1). Tighten: Tighten the retaining nuts to 52 N.m (38 lb ft).
  3. Install the seat belt roller assembly cover.
  4. Install the seat belt roller assembly screws. Tighten: Tighten the screws to 5 N.m (44 lb in).
  5. Ensure that the seat belt is not twisted.
  6. Install the seat back cover. Refer to «Seat Back Cover and Pad Replacement - Front»(/cadillac/srx/i-2003-2009/remont/seats/#seat-system) in Seats.
  7. Install the seat back trim cover. Refer to «Seat Back Trim Replacement - Front»(/cadillac/srx/i-2003-2009/remont/seats/#seat-system) in Seats.
  8. Install the head restraint retainers. Refer to «Head Restraint Retainer Replacement - Front Seat»(/cadillac/srx/i-2003-2009/remont/seats/#seat-system) in Seats.
  9. Install the head restraint. Refer to «Head Restraint Replacement - Front Seat»(/cadillac/srx/i-2003-2009/remont/seats/#seat-system) in Seats.
  10. Ensure the seat belt operates correctly.
  1. Remove the side door opening frame garnish molding. Refer to «Garnish Molding Replacement - Side Door Opening Frame»(/cadillac/srx/i-2003-2009/remont/exteriorinterior-trim/#interior-trim) in Interior Trim.
  2. Remove the body side rear trim panel. Refer to «Trim Panel Replacement - Body Side Rear (w/o TB5)»(/cadillac/srx/i-2003-2009/remont/exteriorinterior-trim/#interior-trim) or «Trim Panel Replacement - Body Side Rear (w/TB5)»(/cadillac/srx/i-2003-2009/remont/exteriorinterior-trim/#interior-trim) in Interior Trim.
  3. Remove the rear seat belt upper guide shoulder bolt (1).
  4. Remove the bolt that retains the seat belt retractor assembly (2) to the body.
  5. Remove the rear seat in order to remove the left side anchor bolt. Refer to «Seat Replacement - Rear No. 1»(/cadillac/srx/i-2003-2009/remont/seats/#seat-system) in Seats.
  6. Remove the rear seat belt lower anchor bolt.
  7. Remove the seat belt retractor assembly from the vehicle.
  1. Install the seat belt retractor assembly (2) to the vehicle. Tighten: Tighten the rear seat belt retractor bolts to 70 N.m (52 lb ft).
  2. Install the body side rear trim panel. Refer to «Trim Panel Replacement - Body Side Rear (w/o TB5)»(/cadillac/srx/i-2003-2009/remont/exteriorinterior-trim/#interior-trim) or «Trim Panel Replacement - Body Side Rear (w/TB5)»(/cadillac/srx/i-2003-2009/remont/exteriorinterior-trim/#interior-trim) in Interior Trim.
  3. Insert the seat belt through the side door opening garnish trim.
  4. Install the rear seat belt upper guide with the bolt. Ensure that the seat belt webbing is not twisted. Tighten: Tighten the bolt to 70 N.m (52 lb ft).
  5. Install the side door opening frame garnish molding. Refer to «Garnish Molding Replacement - Side Door Opening Frame»(/cadillac/srx/i-2003-2009/remont/exteriorinterior-trim/#interior-trim) in Interior Trim.
  6. Install the rear seat. Refer to «Seat Replacement - Rear No. 1»(/cadillac/srx/i-2003-2009/remont/seats/#seat-system) in Seats.
  7. Install the rear seat belt lower anchor bolt. Ensure that the seat belt webbing is not twisted. Tighten: Tighten the rear seat belt anchor bolt to 45 N.m (33 lb ft).
  1. Remove the seat. Refer to «Seat Replacement - Rear No. 1»(/cadillac/srx/i-2003-2009/remont/seats/#seat-system) in Seats.
  2. Remove the left seat back. Refer to «Seat Back Replacement - Rear No.1 - Left»(/cadillac/srx/i-2003-2009/remont/seats/#seat-system) in Seats.
  3. Remove the seat back cover and pad. Refer to «Seat Back Cover and Pad Replacement - Rear No.1 - Left»(/cadillac/srx/i-2003-2009/remont/seats/#seat-system) in Seats.
  4. Remove the latch release assembly. Refer to «Seat Back Release Latch Replacement - Rear No. 1»(/cadillac/srx/i-2003-2009/remont/seats/#seat-system) in Seats.
  5. Remove the head restraints. Refer to «Head Restraint Replacement - Rear No. 1»(/cadillac/srx/i-2003-2009/remont/seats/#seat-system) in Seats.
  6. Remove the head restraint guides. Refer to «Head Restraint Guide Replacement - Rear No. 1»(/cadillac/srx/i-2003-2009/remont/seats/#seat-system) in Seats.
  7. Remove the seat belt retractor bolt (1) from the seat frame.
  8. Lift the seat belt retractor out of the seat frame.
  1. Install the seat belt retractor into the seat frame.
  2. Install the seat belt retractor bolt (1) into the seat frame. Tighten: Tighten the bolt to 42 N.m (31 lb ft).
  3. Install the seat back cover and pad. Refer to «Seat Back Cover and Pad Replacement - Rear No.1 - Left»(/cadillac/srx/i-2003-2009/remont/seats/#seat-system) in Seats.
  4. Install the latch release assembly. Refer to «Seat Back Release Latch Replacement - Rear No. 1»(/cadillac/srx/i-2003-2009/remont/seats/#seat-system) in Seats.
  5. Install the head restraint guides. Refer to «Head Restraint Guide Replacement - Rear No. 1»(/cadillac/srx/i-2003-2009/remont/seats/#seat-system) in Seats.
  6. Install the head restraints. Refer to «Head Restraint Replacement - Rear No. 1»(/cadillac/srx/i-2003-2009/remont/seats/#seat-system) in Seats.
  7. Install the left seat back. Refer to «Seat Back Replacement - Rear No.1 - Left»(/cadillac/srx/i-2003-2009/remont/seats/#seat-system) in Seats.
  8. Install the seat. Refer to «Seat Replacement - Rear No. 1»(/cadillac/srx/i-2003-2009/remont/seats/#seat-system) in Seats.
  1. Remove the body side rear upper garnish molding. Refer to «Garnish Molding Replacement - Body Side Rear Upper (w/o TB5)»(/cadillac/srx/i-2003-2009/remont/exteriorinterior-trim/#interior-trim) or «Garnish Molding Replacement - Body Side Rear Upper (w/TB5)»(/cadillac/srx/i-2003-2009/remont/exteriorinterior-trim/#interior-trim) in Interior Trim.
  2. Remove the body side rear trim panel. Refer to «Trim Panel Replacement - Body Side Rear (w/o TB5)»(/cadillac/srx/i-2003-2009/remont/exteriorinterior-trim/#interior-trim) or «Trim Panel Replacement - Body Side Rear (w/TB5)»(/cadillac/srx/i-2003-2009/remont/exteriorinterior-trim/#interior-trim) in Interior Trim.
  3. Remove the bolt that retains the seat belt retractor assembly (2) to the body.
  4. Remove the seat belt retractor assembly from the vehicle.
  1. Install the seat belt retractor assembly (2) to the vehicle. Tighten: Tighten the rear seat belt retractor bolts to 70 N.m (52 lb ft).
  2. Install the body side rear trim panel. Refer to «Trim Panel Replacement - Body Side Rear (w/o TB5)»(/cadillac/srx/i-2003-2009/remont/exteriorinterior-trim/#interior-trim) or «Trim Panel Replacement - Body Side Rear (w/TB5)»(/cadillac/srx/i-2003-2009/remont/exteriorinterior-trim/#interior-trim) in Interior Trim.
  3. Insert the seat belt through the body side rear upper garnish molding.
  4. Install the rear seat belt upper guide bolt (1). Ensure that the seat belt webbing is not twisted. Tighten: Tighten the bolt to 70 N.m (52 lb ft).
  5. Install the body side rear upper garnish molding. Refer to «Garnish Molding Replacement - Body Side Rear Upper (w/o TB5)»(/cadillac/srx/i-2003-2009/remont/exteriorinterior-trim/#interior-trim) or «Garnish Molding Replacement - Body Side Rear Upper (w/TB5)»(/cadillac/srx/i-2003-2009/remont/exteriorinterior-trim/#interior-trim) in Interior Trim.
IMPORTANTIf the vehicle has been in a collision, refer to Repairs and Inspections Required After a Collision for additional information.

The front seat belt system includes a driver and/or passenger seat belt retractor and buckle.

The driver's seat belt system, includes a seat belt switch in the driver seat buckle which controls a reminder lamp and a tone alarm.

  1. When the driver seat belt is buckled, the driver's door is closed, and the ignition switch is turned ON, the following events will occur: The tone alarm will not operate. The reminder lamp will not operate.
  2. When the driver's seat belt is not buckled, the driver's door is closed, and the ignition switch is in ON position, the following events will occur: The tone alarm will operate for 4 to 8 seconds and then go OFF. The reminder lamp will operate for 20 seconds, until the driver seat belt is buckled.

The rear seat belt system includes the following components

  1. The rear seat belt retractor is located under the rear shelf trim panel and is attached to the rear shelf body panel.
  2. The center rear seat belt buckle and the outer seat belt buckle are located in the center of the seat cushion and they are attached to the rear floor pan.

Child Seat Restraint System

CAUTIONA child in a rear-facing child restraint can be seriously injured if the right-front passengers air bag inflates. This is because the back of a rear-facing child restraint would be very close to the inflating air bag. NEVER use a rear-facing child restraint in this vehicle. If a forward-facing child restraint is suitable for your child, ALWAYS move the front passenger seat as far back as it will go and then install the child restraint. Be sure the child restraint position does not conflict with any additional requirements provided by the manufacturer. For more information, refer to the vehicle owners manual and the instruction that came with the child restraint.

The child seat may only be used in a forward facing seating location. The child seat should be installed and secured according to the manufacturer's directions. If the child seat has a top strap, the seat will need to be anchored. Passengers should not be allowed to sit at locations where the seat belts are being used to secure the child seat.

All vehicles are equipped with a dual-mode type retractor with emergency and automatic locking features. The automatic locking feature is for restraint of a child seat. The child seat can be secured by pulling the seat belt all the way out to lock it. Then, tighten the seat belt around the child seat.

If a child seat is to be used in the second seat position, a special dealer-installed anchor must be used in order to anchor the child seat top strap. (This only applies to the seats designed with the top strap provision and for the vehicles sold in Canada). In order to ensure the correct top strap angle, the child seat is only to be used at the seating position for which the top strap anchor is installed.

The inflatable restraint sensing and diagnostic module (SDM) receives a discrete input from the left front seat belt switch. The left front seat belt switch is closed when the seat belt is unbuckled.

Fasten Safety Belt Indicator (ISO Symbol) (Red)

The fasten safety belt indicator may only be ON during RUN. The instrument panel cluster (IPC) illuminates the fasten safety belt indicator under the following conditions

  1. During the bulb check.
  2. The inflatable restraint sensing and diagnostic module (SDM) sends the status of the driver's seat belt switch to the IPC via a class 2 message. If the seat belt is unfastened, the IPC will illuminate the fasten safety belt indicator for 72 seconds or until the seat belt is fastened. If the seat belt is unfastened within 8 seconds following the bulb check, the IPC sends a class 2 serial message requesting 5 chimes to sound.
