Steering Wheel and Steering Column Cadillac SRX I

Ignition Switch/steering Lock 7 illustrations ~6696 words

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Ignition Lock Cylinder Case Screws7 N.m62 lb in
Intermediate Shaft Bolts30 N.m22 lb ft
Intermediate Shaft to the Steering Column Pinch Bolt48 N.m35 lb ft
Intermediate Shaft to the Steering Gear Pinch Bolt50 N.m37 lb ft
Steering Column Mounting Nuts25 N.m18 lb ft
Steering Column Trim Cover Screws Lower3.5 N.m31 lb in
Steering Column Trim Cover Screws Upper1.5 N.m13 lb in
Steering Wheel Control Harness Retainer Screws2.3 N.m20 lb in
Steering Wheel Control Switch Screws2.3 N.m20 lb in
Steering Wheel Nut41 N.m30 lb ft
Turn Signal Multifunction Switch Screw Side7 N.m62 lb in
Turn Signal Multifunction Switch Screw Top3 N.m27 lb in
Upper Intermediate Shaft to Lower Intermediate Shaft Pinch Bolt30 N.m22 lb ft

Fastener Tightening Specifications

Scheme 1

Scheme 1: Column/Ignition Lock Schematics
Scheme 1: Column/Ignition Lock Schematics

Scheme 2

Scheme 2: Steering Wheel Schematics
Scheme 2: Steering Wheel Schematics

Scheme 3

Scheme 3: Steering Column Disassembled View
Scheme 3: Steering Column Disassembled View
CalloutComponent Name
1Upper Trim Cover
2Lower Trim Cover
3Steering Column Closeout Trim
4Flange Prevail Torque Nut
5Retaining Ring
6SIR Coil
7Wave Washer
8Bearing Retainer
9Cam Orientation Plate
10Turn Signal Cancel Cam
11Upper Bearing Spring
12Upper Bearing Inner Race
13Inner Race
14Switch Mounting Bracket
15Turn Signal and Multifunction Switch Assembly
16Steering Column Tilt Head Assembly
17Wire Strap
18Spring Guide
19Tilt Spring
20Release Lever Pin
21Pan Head Tapping Screws
22Wire Straps
23Pan Head Tapping Screws
24Window Washer and Wiper Switch Assembly
25Wire Straps
26Theft Deterrent
27Ignition Lock Cylinder Case
28Race and Upper Shaft
29Centering Sphere
30Joint Preload Spring
31Lower Steering Shaft
32Pivot Pins
33Wire Strap
34Steering Column Jacket Assembly
35Steering Column Position Sensor
36Sensor Clip
37Sensor Seal
38Boot
39Bolt Retainer
40Pinch Bolt
41Intermediate Shaft Assembly

Scheme 4

Scheme 4: Steering Wheel and Column Component Views
Scheme 4: Steering Wheel and Column Component Views
CalloutComponent Name
1Inflatable Restraint Steering Wheel Module Coil
2C208
3Inflatable Restraint Steering Wheel Module Connector C1
4Inflatable Restraint Steering Wheel Module Connector C2
5Turn Signal/Multifunction Switch
6Turn Signal/Multifunction Switch Connector C4
7Turn Signal/Multifunction Switch Connector C3
8Turn Signal/Multifunction Switch Connector C2
9Turn Signal/Multifunction Switch Connector C1
10Steering Wheel Position Sensor
11C203
12Fuse Block - Steering Column
13C202
14Theft Deterrent Control Module Connector
15Ignition Lock Cylinder Control Actuator Connector
16Ignition Switch Connector
17Ignition Key Alarm Switch (Part of steering column harness)
18Windshield Wiper/Washer Switch Connector
19Windshield Wiper/Washer Switch
20Theft Deterrent Control Module
21Ignition Switch (Hidden) and Ignition Lock Cylinder Case
22Ignition Lock Cylinder Control Actuator

Steering Wheel and Column Connector End Views

Ignition Lock Cylinder Control Actuator Connector Part Information 12052832 2-Way F Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A PU 5025 Ignition Key/Shifter Interlock Switch Supply Voltage B RD/WH 540 Battery Positive Voltage

Diagnostic Starting Point - Steering Wheel Controls

Begin the system diagnosis with Diagnostic System Check - Vehicle . The Diagnostic System Check - Vehicle will provide the following information

  1. The identification of the control modules which command the system
  2. The ability of the control modules to communicate through the serial data circuit
  3. The identification of any stored diagnostic trouble codes (DTCs) and their status

The use of the Diagnostic System Check - Vehicle will identify the correct procedure for diagnosing the system and where the procedure is located.

Diagnostic Aids

Before diagnosis of the steering wheel controls, ensure the primary controls of the associated component are functioning properly.

  1. If the vehicle is equipped with RPO U2R or U2S the steering wheel controls are connected to the radio.
  2. If the vehicle is not equipped with RPO U2V or U2X the steering wheel controls are connected to the CD changer which is a serviceable component of the navigation radio.
StepActionValuesYesNo
Schematic Reference : Steering Wheel Schematics Connector Reference : Entertainment Connector End Views
1Did you perform the Diagnostic System Check - Vehicle?Go to Step 2Go to Diagnostic System Check - Vehicle
2Turn ON the ignition, with the engine OFF. Turn ON the radio. Operate all of the steering wheel controls. Do all of the steering wheel controls operate properly?Go to Testing for Intermittent Conditions and Poor ConnectionsGo to Step 3
3Test the remote radio control supply voltage circuit for a short to ground or open. Refer to Circuit Testing and Wiring Repairs . Did you find and correct the condition?Go to Step 10Go to Step 4
4CAUTION: When performing service on or near the SIR components or the SIR wiring, the SIR system must be disabled. Refer to SIR Disabling and Enabling Zones. Failure to observe the correct procedure could cause deployment of the SIR components, personal injury, or unnecessary SIR system repairs. Test the resistance of the steering wheel control switches. Press the steering wheel control switches to the correct function, one at a time, and compare the measured values to those shown. Measure the resistance between the remote radio control supply voltage circuit and the steering wheel controls signal circuit at the radio or CD changer. Are the measured resistances approximately equal to the specified values?Mute: 1.3K ohms Source: 1.5K ohms Voice Recognition: 1.9K ohms Preset Seek: 2.4K ohms Volume Up: 3.1K ohms Volume Down: 4.3K ohms Seek Up: 7K ohms Seek Down: 14K ohmsGo to Step 5Go to Step 7
5Test the steering wheel controls signal circuit for a short, high resistance or an open. Refer to Circuit Testing and Wiring Repairs . Did you find and correct the condition?Go to Step 10Go to Step 6
6Inspect for poor connections at the harness connector of the radio. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs . Did you find and correct the condition?Go to Step 10Go to Step 9
7Inspect for poor connections at the harness connector of the steering wheel radio controls. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs . Did you find and correct the condition?Go to Step 10Go to Step 8
8Replace the appropriate steering wheel radio control. Refer to Steering Wheel Control Switch Assembly Replacement . Did you complete the replacement?Go to Step 10
9Replace the radio or CD changer radio if applicable. Refer to Control Module References for replacement, setup, and programming or Remote CD Changer Replacement . Did you complete the replacement?Go to Step 10
10Operate the system in order to verify the repair. Did you correct the condition?System OKGo to Step 2
CAUTION
When performing service on or near the SIR components or the SIR wiring, the SIR system must be disabled. Refer to SIR Disabling and Enabling Zones. Failure to observe the correct procedure could cause deployment of the SIR components, personal injury, or unnecessary SIR system repairs.

Steering Wheel Controls Inoperative

Symptoms - Steering Wheel and Column

Review the system description and operation in order to familiarize yourself with the system functions. Refer to Steering Wheel and Column Description and Operation .

Visual/Physical Inspection

  1. Inspect for aftermarket devices which could affect the operation of the steering wheel and column.
  2. Inspect the easily accessible or visible system components for obvious damage or conditions which could cause the symptom.

Symptoms List

Refer to a symptom diagnostic procedure from the following list in order to diagnose the symptom

  1. «Lock System Does Not Unlock»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column__lock-system-does-not-unlock)
  2. «Lock System Does Not Lock»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column__lock-system-does-not-lock)
  3. «Lock System Sticks in Start»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column__lock-system-sticks-in-start)
  4. «Key Cannot Be Removed in the Off Lock Position»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column__key-cannot-be-removed-in-the)
  5. «High Lock Effort»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column__high-lock-effort)
  6. «Noise in Steering Column»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column__noise-in-steering-column)
  7. «Looseness in Steering Column»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column__looseness-in-steering-column)
  8. «Steering Column Tilt Function Inoperative»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column__steering-column-tilt-function-inoperative)
  9. «Ignition Can/Cannot Be Turned Off with Transmission in Any Gear»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column)

Symptoms - Steering Wheel Controls

IMPORTANTPerform the Diagnostic System Check - Vehicle , before using the Symptom Tables in order to verify that all of the following conditions are true: There are no DTCs set. The control modules can communicate via the serial data link. Review the system operation in order to familiarize yourself with the system functions. Refer to Steering Wheel Controls Description and Operation .
  1. Inspect for aftermarket devices which may affect the operation of the Steering Wheel Controls System. Refer to «Checking Aftermarket Accessories»(/cadillac/srx/i-2003-2009/remont/body-electrical/#how-to-diagnosis-repair-the-wiring-systems-testing__checking-aftermarket-accessories) .
  2. Inspect for easily accessible or visible system components for obvious damage or conditions which may cause the symptom.

Intermittent

Faulty electrical connections or wiring may be the cause of intermittent conditions. Refer to Testing for Intermittent Conditions and Poor Connections .

Symptom List

Refer to Steering Wheel Controls Inoperative in order to diagnose the symptom.

Steering Column Tilt Function Inoperative

StepActionYesNo
1Did you review the Steering Wheel and Column Description and Operation and perform the necessary inspections?Go to Step 2Go to Symptoms - Steering Wheel and Column
2Verify that the steering column tilt function is inoperative. Does the steering column tilt function operate normally?System OKGo to Step 3
3Verify that the shoe is not seized on the pivot pin. Is the shoe seized on the pivot pin?Go to Step 9Go to Step 4
4Inspect the shoe grooves for dirt, burrs, or rust. Are the shoe grooves free of dirt, burrs, and rust?Go to Step 9Go to Step 5
5Inspect weak or broken shoe lock spring. Is the shoe lock spring weak or broken?Go to Step 9Go to Step 6
6Inspect the pivot pins for binding. Are the pivot pins binding?Go to Step 10Go to Step 7
7Inspect for a weak or broken wheel tilt spring. Is the wheel tilt spring weak or broken?Go to Step 11Go to Step 8
8Inspect the steering column wiring harness for tightness. Is the steering column wiring harness too tight?Go to Step 12Go to Step 3
9Replace the tilt head. Refer to Steering Column Jacket Replacement . Is the repair complete?Go to Step 13
10Replace the pivot pins. Refer to Steering Column Jacket Replacement . Is the repair complete?Go to Step 13
11Replace the tilt spring. Refer to Tilt Spring Replacement . Is the repair complete?Go to Step 13
12Reroute the steering column wiring harness to the correct location. Is the steering column wiring harness routed properly?Go to Step 13
13Operate the steering column tilt function in order to verify the repair. Did you correct the condition?System OKGo to Step 3

Steering Column Tilt Function Inoperative

Test Description

The numbers below refer to the step numbers on the diagnostic table.

  1. 3: This step tests for voltage at the coil side of the lock cylinder relay.
  2. 4: This step verifies that the dash integration module (DIM) is providing ground to the lock cylinder relay.
  3. 5: This step tests if ground is constantly being applied to the ignition lock cylinder control actuator.
StepActionYesNo
Schematic Reference: Column/Ignition Lock Schematics Connector End View Reference: Steering Wheel and Column Connector End Views
1Operate the system. Does the system operate normally?Go to Testing for Intermittent Conditions and Poor ConnectionsGo to Step 2
2Push the ignition lock cylinder control actuator release button which is on the underside of the ignition key cylinder. Turn the key to the OFF position and remove the key. Were you able to turn the key to the OFF position and remove the key?Go to Step 3Go to Lock System Does Not Lock
3Turn OFF the ignition. Disconnect the ignition lock cylinder control actuator. Turn ON the ignition, with the engine OFF. Connect a test lamp between the battery positive voltage circuit and the ignition key/shifter interlock switch supply voltage circuit of the ignition lock cylinder control actuator with a test lamp. Does the test lamp illuminate?Go to Step 8Go to Step 4
4Probe the battery positive voltage circuit of the ignition lock cylinder control actuator with a test lamp connected to a good ground. Does the test lamp illuminate?Go to Step 5Go to Step 12
5Turn OFF the ignition. Reconnect the ignition lock cylinder control actuator connector. Disconnect the automatic transmission shift lock actuator connector. Turn ON the ignition, with the engine OFF. Connect a test lamp between the ignition key/shifter interlock switch supply voltage circuit and the ignition lock cylinder control switch signal circuit. Does the test lamp illuminate?Go to Step 10Go to Step 6
6Probe the ignition lock cylinder control switch signal circuit and with a test lamp connected to B+. Does the test lamp illuminate?Go to Step 13Go to Step 7
7Test the ignition lock cylinder control switch signal circuit for an open. Refer to Circuit Testing and Wiring Repairs . Did you find and correct the condition?Go to Step 17Go to Step 11
8Test the ignition key/shifter interlock switch supply voltage circuit for a short to ground. Refer to Circuit Testing and Wiring Repairs . Did you find and correct the condition?Go to Step 17Go to Step 9
9Inspect for poor connections at the ignition lock cylinder control actuator. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs . Did you find and correct the condition?Go to Step 17Go to Step 14
10Inspect for poor connections at the automatic transmission shift lock actuator. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs . Did you find and correct the condition?Go to Step 17Go to Step 15
11Inspect for poor connections at the harness connector of the dash integration module (DIM). Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs . Did you find and correct the condition?Go to Step 17Go to Step 16
12Repair the battery positive voltage circuit of the ignition lock cylinder control actuator. Refer to Wiring Repairs . Did you complete the repair?Go to Step 17
13Repair the voltage supply circuit of the ignition lock cylinder control switch. Refer to Wiring Repairs . Did you complete the repair?Go to Step 17
14Replace the ignition lock cylinder control actuator. Did you complete the replacement?Go to Step 17
15Replace the automatic transmission shift lock actuator. Refer to Automatic Transmission Shift Lock Actuator Replacement . Did you complete the replacement?Go to Step 17
16IMPORTANT: Perform the set up procedure for the DIM. Replace the DIM. Refer to Control Module References .Did you complete the replacement?Go to Step 17
17Operate the system in order to verify the repair. Did you correct the condition?System OKGo to Step 3
IMPORTANT
Perform the set up procedure for the DIM.

Ignition Can/Cannot Be Turned Off with Transmission in Any Gear

Lock System Does Not Unlock

StepActionYesNo
DEFINITION: The lock system does not allow the key to rotate out of the OFF position.
1Did you review the Steering Wheel and Column Description and Operation?Go to Step 2Go to Steering Wheel and Column Description and Operation
2Verify that the lock system does not unlock. Does the lock system operate normally?System OKGo to Step 3
3Inspect for an incorrect, worn, or damaged key. Is the key incorrect, worn, or damaged?Go to Step 7Go to Step 4
4Inspect for a faulty lock cylinder. Is the lock cylinder damaged?Go to Step 8Go to Step 5
5Inspect the ignition lock cylinder case assembly for looseness. Is the ignition lock cylinder case assembly loose?Go to Step 9Go to Step 6
6Inspect the ignition switch assembly for damage. Is the ignition switch assembly damaged?Go to Step 10Go to Step 3
7Replace the key. Refer to Key and Lock Cylinder Coding in General Information. Did you complete the repair?Go to Step 11
8Replace the lock cylinder. Refer to Ignition Lock Cylinder Replacement . Did you complete the repair?Go to Step 11
9Tighten the ignition lock cylinder case assembly. Refer to Fastener Tightening Specifications . Did you complete the repair?Go to Step 11
10Replace the ignition switch. Refer to Ignition Switch Replacement . Did you complete the repair?Go to Step 11
11Operate the system in order to verify the repair. Did you correct the condition?System OKGo to Step 3

Lock System Does Not Unlock

Lock System Does Not Lock

StepActionYesNo
DEFINITION: The lock system will not allow the key to be turned to the OFF lock position.
1Did you review the Steering Wheel and Column Description and Operation?Go to Step 2Go to Steering Wheel and Column Description and Operation
2Verify that the lock system does not lock. Does the lock system operate normally?System OKGo to Step 3
3Inspect for a faulty lock cylinder or release button. Is the lock cylinder or release button damaged?Go to Step 7Go to Step 4
4Inspect the shift linkage adjustment. Is the shift linkage adjusted incorrectly?Go to Step 8Go to Step 5
5Inspect the ignition switch for damage. Is the ignition switch damaged?Go to Step 9Go to Step 6
6Inspect the park lock for damage. Is the park lock damaged?Go to Step 10Go to Step 3
7Replace the lock cylinder. Refer to Ignition Lock Cylinder Replacement . Did you complete the repair?Go to Step 10
8Adjust the shift linkage. Did you complete the repair?Go to Step 10
9Replace the ignition switch. Refer to Ignition Switch Replacement . Did you complete the repair?Go to Step 10
10Replace the park lock. Did you complete the repair?Go to Step 11
11Operate the system in order to verify the repair. Did you correct the condition?System OKGo to Step 3

Lock System Does Not Lock

Lock System Sticks in Start

StepActionYesNo
1Did you review the Steering Wheel and Column Description and Operation?Go to Step 2Go to Steering Wheel and Column Description and Operation
2Verify that the lock system sticks in the START position. Does the lock system operate normally?System OKGo to Step 3
3Inspect the ignition lock cylinder case assembly for damage. Is the ignition lock cylinder case assembly damaged?Go to Step 6Go to Step 4
4Inspect the lock cylinder for damage. Is the lock cylinder damaged?Go to Step 7Go to Step 5
5Inspect the ignition switch for damage. Is the ignition switch damaged?Go to Step 8Go to Step 3
6Tighten the ignition lock cylinder case assembly mounting bolts. Refer to Fastener Tightening Specifications . Did you complete the repair?Go to Step 9
7Replace the lock cylinder. Refer to Ignition Lock Cylinder Replacement . Did you complete the repair?Go to Step 9
8Replace the ignition switch. Refer to Ignition Switch Replacement . Did you complete the repair?Go to Step 9
9Operate the system in order to verify the repair. Did you correct the condition?System OKGo to Step 3

Lock System Sticks in Start

Key Cannot Be Removed in the Off Lock Position

StepActionYesNo
1Did you review the Steering Wheel and Column Description and Operation?Go to Step 2Go to Steering Wheel and Column Description and Operation
2Verify that the key cannot be removed from the lock cylinder in the OFF position. Does the lock system operate normally?System OKGo to Step 3
3Inspect the automatic transmission shift linkage. Is the adjustment correct?Go to Step 5Go to Step 4
4Adjust the shift linkage. Refer to Shift Control Linkage Adjustment in Automatic Transmission - 5L40-E/5L50-E. Did you correct the condition?System OKGo to Step 5
5Inspect for incorrect, worn, or damaged key. Is the key incorrect, worn, or damaged?Go to Step 7Go to Step 6
6Inspect for a faulty lock cylinder or release button. Is the lock cylinder or release button damaged?Go to Step 8Go to Step 5
7Replace the key. Refer to Key and Lock Cylinder Coding in General Information. Did you complete the repair?Go to Step 9
8Replace the lock cylinder. Refer to Ignition Lock Cylinder Replacement . Did you complete the repair?Go to Step 9
9Operate the system in order to verify the repair. Did you correct the condition?System OKGo to Step 3

Key Cannot Be Removed in the Off Lock Position

High Lock Effort

StepActionYesNo
1Did you review the Steering Wheel and Column Description and Operation?Go to Step 2Go to Steering Wheel and Column Description and Operation
2Verify that the lock system has a high lock effort. Does the lock system operate normally?System OKGo to Step 3
3Inspect for an incorrect, worn, or damaged key. Is the key incorrect, worn, or damaged?Go to Step 7Go to Step 4
4Inspect for a faulty lock cylinder. Is the lock cylinder damaged?Go to Step 8Go to Step 5
5Inspect the ignition lock cylinder case assembly for damage. Is the ignition lock cylinder case assembly damaged?Go to Step 9Go to Step 6
6Inspect the ignition switch assembly for damage. Is the ignition switch assembly damaged?Go to Step 10Go to Step 7
7Replace the key. Refer to Key and Lock Cylinder Coding in General Information. Did you complete the repair?Go to Step 11
8Replace the lock cylinder. Refer to Ignition Lock Cylinder Replacement . Did you complete the repair?Go to Step 11
9Tighten the ignition lock cylinder case assembly. Refer to Fastener Tightening Specifications . Did you complete the repair?Go to Step 11
10Replace the ignition switch. Refer to Ignition Switch Replacement . Did you complete the repair?Go to Step 11
11Operate the system in order to verify the repair. Did you correct the condition?System OKGo to Step 3

High Lock Effort

Noise in Steering Column

StepActionYesNo
1Did you review the Steering Wheel and Column Description and Operation and perform the necessary inspections?Go to Step 2Go to Symptoms - Steering Wheel and Column
2Verify that noise is present in the steering column during operation. Is noise present in the steering column during operation?Go to Step 3System OK
3Inspect the steering column components for looseness. Is the steering column components loose?Go to Step 10Go to Step 4
4Inspect the SIR coil for noise. Is the SIR coil noisy?Go to Step 11Go to Step 5
5Inspect the horn contact ring for lubrication. Is the horn contact ring lubricated?Go to Step 12Go to Step 6
6Inspect the lock plate retaining ring for the correct installation. Is the lock plate retaining ring installed properly?Go to Step 13Go to Step 7
7Inspect the shaft bearing for the following conditions: Damage Lubrication Wear Proper seating Are the bearings in need of repair or replacement?Go to Step 14Go to Step 8
8Inspect the spherical joint for lubrication. Is the spherical joint lubricated?Go to Step 15Go to Step 9
9Inspect the steering column coupling for looseness. Is the steering column coupling loose?Go to Step 16Go to Step 3
10NOTE: Refer to Fastener Notice in Cautions and Notices. Tighten the steering column components to specifications. Refer to Fastener Tightening Specifications .Did you complete the repair?Go to Step 17
11Replace the SIR coil. Refer to Inflatable Restraint Steering Wheel Module Coil Replacement in SIR. Did you complete the repair?Go to Step 17
12Lubricate the horn contact ring. Did you complete the repair?Go to Step 17
13Install the lock plate retaining ring properly. Did you complete the repair?Go to Step 17
14Repair the shaft bearings as necessary. Refer to Steering Column Jacket Replacement . Did you complete the repair?Go to Step 17
15Lubricate the spherical joints. Did you complete the repair?Go to Step 17
16NOTE: Refer to Fastener Notice in Cautions and Notices. Tighten the steering column coupling to specifications. Refer to Fastener Tightening Specifications .Did you complete the repair?Go to Step 17
17Operate the system in order to verify the repair. Did you correct the condition?System OKGo to Step 3
NOTE
Refer to Fastener Notice in Cautions and Notices.
NOTE
Refer to Fastener Notice in Cautions and Notices.

Noise in Steering Column

Looseness in Steering Column

StepActionYesNo
1Did you review the Steering Wheel and Column Description and Operation and perform the necessary inspections?Go to Step 2Go to Symptoms - Steering Wheel and Column
2Verify that the steering column is loose. Is the steering column loose?Go to Step 3System OK
3Inspect the steering column mounting brackets for looseness. Are the steering column mounting brackets loose?Go to Step 7Go to Step 4
4Verify that the steering column bracket capsule is not sheared. Is the steering column bracket capsule sheared?Go to Step 8Go to Step 5
5Inspect the upper and lower tilt head screws for looseness. Are the support screws loose?Go to Step 9Go to Step 6
6Inspect the intermediate shaft for worn joints or looseness. Is the intermediate joint worn or loose?Go to Step 10Go to Step 2
7Tighten the brackets to specifications. Refer to Fastener Tightening Specifications . Did you complete the repair?Go to Step 11
8Replace the jacket assembly. Refer to Steering Column Jacket Replacement . Did you complete the replacement?Go to Step 11
9Tighten the upper and lower tilt head screws to specifications. Refer to Fastener Tightening Specifications . Did you complete the repair?Go to Step 11
10Tighten or replace the intermediate shaft as needed. Refer to Intermediate Steering Shaft Replacement - Upper Intermediate Steering Shaft Replacement - Lower . Did you complete the repair?Go to Step 11
11Operate the system in order to verify the repair. Did you correct the condition?System OKGo to Step 3

Looseness in Steering Column

Removal Procedure

  1. Remove the steering column. Refer to «Steering Column Replacement»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column) .
  2. Remove the intermediate shaft seal from the mod plate.

Installation Procedure

  1. Install the intermediate shaft seal to the mod plate, ensuring the seal between the intermediate shaft seal and mod plate.
  2. Install the steering column. Refer to «Steering Column Replacement»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column) .
  3. Enable the SIR system. Refer to «SIR Disabling and Enabling Zone 3»(/cadillac/srx/i-2003-2009/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
  1. Disable the SIR system. Refer to «SIR Disabling and Enabling Zone 3»(/cadillac/srx/i-2003-2009/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
  2. Remove the steering column. Refer to «Steering Column Replacement»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column) .
  3. Remove the upper intermediate shaft to steering column retaining bolt.
  4. Remove the upper intermediate shaft from the steering column.
  1. Install the upper intermediate shaft to the steering column as noted during removal.
  2. Install the upper intermediate shaft to the steering column retaining bolt. Tighten: Tighten the bolt to 48 N.m (35 lb ft).
  3. Install the steering column. Refer to «Steering Column Replacement»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column) .
  4. Enable the SIR system. Refer to «SIR Disabling and Enabling Zone 3»(/cadillac/srx/i-2003-2009/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.

Tools Required

J 42640 Steering Column Anti-Rotation Pin

  1. Turn the steering wheel so that the front wheels are pointing straight ahead.
  2. Turn the ignition lock cylinder to the lock position and remove the key.
  3. Install the J 42640 through the access hole in the lower steering column trim cover in order to lock the steering column.
  4. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/cadillac/srx/i-2003-2009/remont/hoistjack/#general-information) in General Information.
  5. Remove the upper to center intermediate shaft retaining bolt.
  6. Remove the lower intermediate shaft to the power steering gear retaining bolt.
  7. Disconnect the lower intermediate shaft from the power steering gear.
  8. Disconnect the center intermediate shaft from the upper intermediate shaft
  9. Remove the center intermediate shaft with the lower intermediate shaft attached.
  10. Remove the lower to center intermediate shaft retaining bolt.
  11. Remove the center intermediate shaft from the lower intermediate shaft.
  1. Install the lower intermediate shaft to the upper intermediate shaft.
  2. Install the lower to center intermediate shaft retaining bolt. Tighten: Tighten the bolt to 30 N.m (23 lb ft).
  3. Connect the center intermediate shaft to the upper intermediate shaft.
  4. Install the center to upper intermediate shaft retaining bolt. Tighten: Tighten the bolt to 30 N.m (23 lb ft).
  5. Connect the lower intermediate shaft to the power steering gear.
  6. Install the lower intermediate shaft to power steering gear retaining bolt. Tighten: Tighten the bolt to 50 N.m (37 lb ft).
  7. Lower the vehicle.
  8. Remove J 42640 from the steering column lower trim cover access hole.

J 42640 Steering Column Anti-Rotation Pin

  1. Turn the steering wheel so that the front wheels are pointing straight ahead.
  2. Turn the ignition lock cylinder to the lock position and remove the key.
  3. Lock the steering column through the access hole in the lower steering column trim cover using the J 42640 .
  4. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/cadillac/srx/i-2003-2009/remont/hoistjack/#general-information) .
  5. Remove the center intermediate shaft to the lower intermediate shaft retaining bolt (3).
  6. Remove the lower intermediate shaft to the power steering gear retaining bolt (4).
  7. Disconnect the lower intermediate shaft from the power steering gear.
  8. Remove the lower intermediate shaft from the center intermediate shaft.
  1. Connect the lower intermediate shaft to the center intermediate shaft.
  2. Connect the lower intermediate shaft to the power steering gear.
  3. Install the lower intermediate shaft to the power steering gear retaining bolt. Tighten: Tighten the bolt to 50 N.m (37 lb ft).
  4. Install the center intermediate shaft to the lower intermediate shaft retaining bolt (3). Tighten: Tighten the bolt to 30 N.m (23 lb ft).
  5. Lower the vehicle.
  6. Remove the J 42640 from the steering column lower trim cover access hole.

Steering Column Accident Damage Inspection

  1. Vehicles involved in accidents resulting in frame damage, major body or sheet metal damage, or where the steering column has been impacted, or where supplemental inflatable restraint systems deployed may also have a damaged or misaligned steering column.
  2. Inspect the capsules on the steering column bracket assembly. All capsules must be securely seated in the bracket slots and checked for any loose conditions when pushed or pulled by hand.
  3. Observe how the bracket is attached to the jacket assembly. If the capsules are not securely seated and the bracket is bolted to the jacket assembly, replace only the bracket. If the capsules are not securely seated and the bracket is welded to the jacket assembly, replace only the jacket assembly.
  4. Inspect for jacket assembly collapse by measuring the distance from the lower edge of the upper jacket to a defined point on the lower jacket. Replace the jacket assembly if the measured dimensions are not within specifications.
  5. Inspect for tab (1) breakage on the bearing and adapter assembly.
  6. Visually inspect the steering shaft for sheared injected plastic (1). If the steering shaft shows sheared plastic, replace the steering shaft.
  7. Any frame damage that could cause a bent steering shaft must have the steering shaft runout checked. Using a dial indicator at the lower end of the steering shaft, rotate the steering wheel. The runout must not exceed 1.60 mm (0.0625 in).
  1. Disable the SIR system. Refer to «SIR Disabling and Enabling Zone 3»(/cadillac/srx/i-2003-2009/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
  2. Remove the tilt lever. Refer to «Tilt Lever Replacement»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column) .
  3. Remove the steering column lock cylinder. Refer to «Ignition Lock Cylinder Replacement»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column) .
  4. Disconnect the adjuster pedal switch connector which is located by the switch.
  5. Remove the 2 pan head tapping screws (2) from the lower trim cover (1).
  6. Remove the lower trim cover (2).
  7. If necessary, remove the adjuster pedal switch assembly (2) from the lower trim cover (1).
  8. Remove the TORX® head screw (2) from the upper trim cover (1).
  9. Remove the upper trim cover (1).
  1. Install the upper trim cover (1) and secure by using the TORX® head screw (2). Tighten: Tighten the screws to 1.5 N.m (13 lb in).
  2. If necessary, install the adjuster pedal switch assembly (2) into the lower trim cover (1).
  3. Install the lower trim cover (1).
  4. Install the 2 pan head tapping screws (2) into the lower trim cover (1). Tighten: Tighten the screws to 3.5 N.m (31 lb in).
  5. Connect the adjuster pedal switch connector.
  6. Install the steering column lock cylinder. Refer to «Ignition Lock Cylinder Replacement»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column) .
  7. Install the tilt lever. Refer to «Tilt Lever Replacement»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column) .
  8. Enable the SIR system. Refer to «SIR Disabling and Enabling Zone 3»(/cadillac/srx/i-2003-2009/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
  1. Disable the SIR system. Refer to «SIR Disabling and Enabling Zone 3»(/cadillac/srx/i-2003-2009/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
  2. Remove the upper and lower trim covers. Refer to «Steering Column Trim Covers Replacement»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column) .
  3. Remove the theft deterrent control module (2) from the ignition lock cylinder case (1).
  4. Disconnect the connector located by the ignition switch.
  5. Remove the 2 tapping screws (2) from the ignition switch assembly (1).
  6. Remove the ignition switch (1) from the ignition lock cylinder case.
  1. Install the ignition switch (1) and secure by using the 2 tapping screws (2). Tighten: Tighten the screws to 7 N.m (62 lb in).
  2. Connect the connector to the ignition switch.
  3. Install the theft deterrent control module (2) onto the ignition lock cylinder case (1).
  4. Install the upper and lower trim covers. Refer to «Steering Column Trim Covers Replacement»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column) .
  5. Enable the SIR system. Refer to «SIR Disabling and Enabling Zone 3»(/cadillac/srx/i-2003-2009/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
  1. Disconnect the negative battery cable. Refer to «Battery Negative Cable Disconnect/Connect Procedure»(/cadillac/srx/i-2003-2009/remont/charging-system/#battery-charging-system-and-starting-system) in Engine Electrical.
  2. Turn the ignition switch to the START position.
  3. Insert the awl into the lower steering column trim cover access hole.
  4. Press in the release button using the awl.
  5. Release the ignition switch to the RUN position.
  6. Remove the ignition lock cylinder.
  1. Install the ignition lock cylinder by doing the following procedure: Align the positioning locking tab slot on the lock module to the positioning tab on the ignition lock cylinder. Push the lock cylinder in until the locking tab locks in the lock module.
  2. Connect the negative battery cable. Refer to «Battery Negative Cable Disconnect/Connect Procedure»(/cadillac/srx/i-2003-2009/remont/charging-system/#battery-charging-system-and-starting-system) in Engine Electrical.
  1. Disable the SIR system. Refer to «SIR Disabling and Enabling Zone 3»(/cadillac/srx/i-2003-2009/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
  2. Remove the turn signal cancel cam and upper bearing. Refer to «Turn Signal Cancel Cam and Upper Bearing Inner Race Replacement»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column__turn-signal-cancel-cam-and-upper) .
  3. Remove the theft deterrent control module. Refer to «Theft Deterrent Control Module Replacement»(/cadillac/srx/i-2003-2009/remont/door-locks-anti-theft-systems/#theft-deterrent-system) in Theft Deterrent.
  4. Remove the ignition lock cylinder. Refer to «Ignition Lock Cylinder Replacement»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column)
  5. Remove the ignition switch assembly. Refer to «Ignition Switch Replacement»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column) .
  6. Remove 3 pan head tapping screws (2) from the ignition lock cylinder case assembly (1). Remove the ignition lock cylinder case from the steering column.
  1. Align the ignition lock cylinder case assembly (1) with the steering column tilt head assembly.
  2. Secure the ignition lock cylinder case assembly (1) to the steering column using 3 pan head tapping screws (2). Tighten: Tighten the screws to 7 N.m (62 lb in).
  3. Install the ignition switch assembly. Refer to «Ignition Switch Replacement»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column) .
  4. Install the ignition lock cylinder. Refer to «Ignition Lock Cylinder Replacement»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column) .
  5. Install the theft deterrent control module. Refer to «Theft Deterrent Control Module Replacement»(/cadillac/srx/i-2003-2009/remont/door-locks-anti-theft-systems/#theft-deterrent-system) in Theft Deterrent.
  6. Install the turn signal cancel cam and upper bearing. Refer to «Turn Signal Cancel Cam and Upper Bearing Inner Race Replacement»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column__turn-signal-cancel-cam-and-upper) .
  7. Enable the SIR system. Refer to «SIR Disabling and Enabling Zone 3»(/cadillac/srx/i-2003-2009/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
  1. Disable the SIR system. Refer to «SIR Disabling and Enabling Zone 3»(/cadillac/srx/i-2003-2009/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
  2. Remove the upper and lower trim covers. Refer to «Steering Column Trim Covers Replacement»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column) .
  3. Tilt the column to the CENTER position.
  4. Disconnect the connectors from the turn signal and multifunction switch assembly. Remove 2 pan head tapping screws from the turn signal and multifunction switch assembly.
  5. Remove the turn signal and multifunction switch assembly.
  1. Install the turn signal and multifunction switch assembly.
  2. Secure by using 2 pan head tapping screws. Tighten Tighten the screw on the top of the column to 3 N.m (27 lb in). Tighten the screw in the front to 7 N.m (62 lb in).
  3. Connect the connectors to the turn signal and multifunction switch assembly.
  4. Install the upper and lower trim covers. Refer to «Steering Column Trim Covers Replacement»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column) .
  5. Enable the SIR system. Refer to «SIR Disabling and Enabling Zone 3»(/cadillac/srx/i-2003-2009/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
  1. Grasp the tilt lever.
  2. Pull the tilt lever straight out from steering column.
  1. Align the tilt lever into the steering column.
  2. Slide the tilt lever handle into the steering column until it locks into position.
  1. Disable the SIR system. Refer to «SIR Disabling and Enabling Zone 3»(/cadillac/srx/i-2003-2009/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
  2. Remove the steering wheel inflatable restraint module. Refer to «Inflatable Restraint Steering Wheel Module Replacement»(/cadillac/srx/i-2003-2009/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
  3. Disconnect the electrical connectors for the steering wheel control switch.
  4. Remove the retaining screws from the steering wheel control switch.
  5. Remove the retainer and screw from the steering wheel control harness.
  6. Carefully pull the control switch assembly away from the steering wheel.
  7. Remove the control switch assembly from the steering wheel.
  8. Remove the wire harness from the control switch assembly.
  1. Install the wire harness to the steering wheel control switch assembly.
  2. Align the control switch assembly engagement tabs to the steering wheel. Push in on the control switch assembly in order to secure the assembly to the steering wheel.
  3. Install the control harness retainer and screw. Tighten: Tighten the screw to 2.3 N.m (20 lb in).
  4. Install the control switch assembly screws Tighten: Tighten the screws to 2.3 N.m (20 lb in).
  5. Connect the electrical connector to the steering wheel control.
  6. Secure the connector to the retaining clip.
  7. Install the inflatable restraint module. Refer to «Inflatable Restraint Steering Wheel Module Replacement»(/cadillac/srx/i-2003-2009/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
  8. Enable the SIR. Refer to «SIR Disabling and Enabling Zone 3»(/cadillac/srx/i-2003-2009/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.

Steering Wheel Replacement

Tools Required

  1. J 1859-A Steering Wheel Puller. See «Special Tools»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column__special-tools) .
  2. J 42578 Steering Wheel Puller Legs. See «Special Tools»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column__special-tools) .
  1. Disable the SIR system. Refer to «SIR Disabling and Enabling Zone 3»(/cadillac/srx/i-2003-2009/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
  2. Remove the inflatable restraint steering wheel module. Refer to «Inflatable Restraint Steering Wheel Module Replacement»(/cadillac/srx/i-2003-2009/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
  3. Disconnect the steering column electrical connector.
  4. Remove the steering wheel retaining nut.
  5. Install J 42578 and J 1859-A to the steering wheel. See «Special Tools»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column__special-tools) .
  6. Using J 42578 and J 1859-A , remove the steering wheel. See «Special Tools»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column__special-tools) .
  1. Install the steering wheel.
  2. Install the steering wheel retaining nut. Tighten: Tighten the nut to 41 N.m (30 lb ft).
  3. Connect the steering column electrical connector.
  4. Install the inflator module. Refer to «Inflatable Restraint Steering Wheel Module Replacement»(/cadillac/srx/i-2003-2009/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
  5. Enable the SIR system. Refer to «SIR Disabling and Enabling Zone 3»(/cadillac/srx/i-2003-2009/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.

Repair Procedure

  1. Remove the steering wheel. Refer to «Steering Wheel Replacement»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column__steering-wheel-replacement) .
  2. Wash the wood section of the wheel with wax and grease remover.
  3. Mask off the non-wood area of the steering wheel.
  4. Sand with 400 grit sand paper first. Finish sanding with 600 grit.
  5. Wash the wood section of the wheel again with wax and grease remover.
  6. Clear coat the steering wheel. Refer to the 2003 GM Approved Refinish Materials Booklet, GM 4901 M-D-2003 (English) or M-D-F2003 (French).
  7. Install the steering wheel. Refer to «Steering Wheel Replacement»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column__steering-wheel-replacement) .
  1. Disable the SIR system. Refer to «SIR Disabling and Enabling Zone 3»(/cadillac/srx/i-2003-2009/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
  2. Remove the upper and lower trim covers. Refer to «Steering Column Trim Covers Replacement»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column) .
  3. Use the tilt lever to tilt the column to the UP position.
  4. Remove one end of the tilt spring (1) from the steering column support assembly (2) and the other end from the steering column tilt head assembly (3) by using the following procedure: Pry up the tilt spring (1) until a bulge occurs and most of the tilt spring tension is removed. Secure the tilt spring (1) with locking pliers. Continue prying up the tilt spring (1) until the tilt spring disengages from the post on the steering column support assembly (2) and from the steering column tilt head assembly (3).
  5. Remove the spring guide (1) from the tilt spring (2).
  1. Use the tilt lever to tilt the column to the UP position.
  2. Install the spring guide (1) into the tilt spring (2).
  3. Install the tilt spring (1) onto the steering column support assembly (2) and onto the steering column tilt head assembly by using the following procedure: Install the tilt spring (1) onto the steering column tilt head assembly. Install the tilt spring (1) onto the post on the steering column support assembly (2).
  4. Install the upper and lower trim covers. Refer to «Steering Column Trim Covers Replacement»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column) .
  5. Enable the SIR system. Refer to «SIR Disabling and Enabling Zone 3»(/cadillac/srx/i-2003-2009/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.

J 21854-01 Pivot Pin Remover. See Special Tools .

  1. Disable the SIR system. Refer to «SIR Disabling and Enabling Zone 3»(/cadillac/srx/i-2003-2009/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
  2. Remove the steering column from the vehicle. Refer to «Steering Column Replacement»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column) .
  3. Remove the ignition lock cylinder case. Refer to «Ignition Lock Cylinder Case Replacement»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column) .
  4. Remove the turn signal and multifunction switch assembly. Refer to «Multifunction, Turn Signal Switch Replacement»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column) .
  5. Remove the tilt spring. Refer to «Tilt Spring Replacement»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column) .
  6. Remove the 2 pivot pins (3) from the steering column tilt head assembly (1) using J 21854-01 . See «Special Tools»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column__special-tools) .
  7. Install the tilt lever into the steering column tilt head assembly (1).
  8. Pull back on the tilt lever and at the same time pull the steering column tilt head assembly (1) down and away from the steering column.
  9. Remove the steering column tilt head assembly (1) with the steering shaft assembly (3) from the steering column jacket assembly (2).
  10. Remove the tilt lever.
  11. Remove the lower bearing and sensor. Refer to «Steering Wheel Position Sensor or Steering Shaft Lower Bearing Replacement»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column) .
  12. Remove the steering shaft (1) from the steering column tilt head assembly.
  1. Install the steering shaft (1) into the steering column tilt head assembly.
  2. Install the lower bearing and sensor. Refer to «Steering Wheel Position Sensor or Steering Shaft Lower Bearing Replacement»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column) .
  3. Install the steering shaft (3) into the steering column tilt head assembly (1). Install the tilt head assembly (1) and the steering shaft (3) into the steering column jacket assembly (2).
  4. Align the steering column tilt head assembly with the pivot pin holes on the steering column jacket assembly.
  5. Lubricate the pivot pins with GM P/N 12346293 (Canadian P/N 99723). Install the 2 pivot pins into the steering column support assembly.
  6. Stake the pins in 3 places.
  7. Install the tilt spring assembly only. Refer to «Tilt Spring Replacement»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column) .
  8. Install the turn signal and multifunction switch assembly only. Refer to «Multifunction, Turn Signal Switch Replacement»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column) .
  9. Install the ignition lock cylinder case assembly. Refer to «Ignition Lock Cylinder Case Replacement»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column) .
  10. Install the steering column to the vehicle. Refer to «Steering Column Replacement»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column) .
  11. Enable the SIR system. Refer to «SIR Disabling and Enabling Zone 3»(/cadillac/srx/i-2003-2009/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.

Turn Signal Cancel Cam and Upper Bearing Inner Race Replacement

Tools Required

  1. J 23653-SIR Lock Plate Compressor. See «Special Tools»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column__special-tools) .
  2. J 42137 Cam Orientation Plate Adapter. See «Special Tools»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column__special-tools) .
  1. Disable the SIR system. Refer to «SIR Disabling and Enabling Zone 3»(/cadillac/srx/i-2003-2009/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
  2. Remove the SIR coil. Refer to «Inflatable Restraint Steering Wheel Module Coil Replacement»(/cadillac/srx/i-2003-2009/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
  3. Remove and discard the bearing retainer using J 23653-SIR and J 42137 . See «Special Tools»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column__special-tools) .
  4. Remove the shaft lock (2) or the cam orientation plate (1).
  5. Remove the turn signal cancel cam assembly (3).
  6. Remove the upper bearing spring (4).
  7. Remove the upper bearing inner race seat (5).
  8. Remove the inner race (6).
  1. Install the inner race (6).
  2. Install the upper bearing inner race seat (5).
  3. Install the upper bearing spring (4).
  4. Install the turn signal cancel cam (3).
  5. Install the shaft lock (2) or the cam orientation plate (1).
  6. Install the new bearing retainer using J 23653-SIR and J 42137 . See «Special Tools»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column__special-tools) .
  7. Install the SIR coil. Refer to «Inflatable Restraint Steering Wheel Module Coil Replacement»(/cadillac/srx/i-2003-2009/remont/airbag/#supplemental-inflatable-restraint-system) .
  8. Enable the SIR system. Refer to «SIR Disabling and Enabling Zone 3»(/cadillac/srx/i-2003-2009/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.

J 42640 Steering Column Anti Rotation Pin

  1. Disable the SIR system. Refer to «SIR Disabling and Enabling Zone 3»(/cadillac/srx/i-2003-2009/remont/airbag/#supplemental-inflatable-restraint-system) .
  2. Turn the steering wheel so that the front wheels are pointing straight ahead.
  3. Turn the ignition lock cylinder to the lock position and remove the key.
  4. Insert J 42640 into the steering column access hole in order to lock the steering column. This will maintain the correct orientation.
  5. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/cadillac/srx/i-2003-2009/remont/hoistjack/#general-information) .
  6. Remove the retaining bolt that secures the intermediate - upper to the intermediate shaft - center.
  7. Lower the vehicle.
  8. Remove the knee bolster. Refer to «Knee Bolster Bracket Replacement - Left»(/cadillac/srx/i-2003-2009/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .
  9. Remove the steering column trim covers. Refer to «Steering Column Trim Covers Replacement»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column) .
  10. Disconnect the steering column electrical connectors.
  11. Support the steering column.
  12. Remove the steering column mounting nuts.
  13. Remove the steering column.
  14. Remove the retaining bolt that secures the upper intermediate shaft to the steering column.
  15. Remove the upper intermediate shaft from the steering column.
  1. Install the upper intermediate shaft to the steering column.
  2. Install the retaining bolt that secures the upper intermediate shaft to the steering column. Tighten: Tighten the bolt to 48 N.m (35 lb ft).
  3. Install the steering column.
  4. Install the steering column mounting nuts. Tighten: Tighten the nuts to 25 N.m (18 lb ft).
  5. Connect the steering column electrical connectors.
  6. Install the knee bolster. Refer to «Knee Bolster Bracket Replacement - Left»(/cadillac/srx/i-2003-2009/remont/gauges-instrument-panels/#instrument-panel-gages-and-console) .
  7. Install the steering column trim covers. Refer to «Steering Column Trim Covers Replacement»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column) .
  8. Raise the vehicle.
  9. Install the intermediate shaft - upper to the intermediate shaft - center.
  10. Install the retaining bolt that secures the intermediate shaft - upper to the intermediate shaft - center. Tighten: Tighten the bolt to 48 N.m (35 lb ft).
  11. Lower the vehicle.
  12. Unlock the steering column by removing J 42640 from the steering column lower trim cover access hole.
  13. Enable the SIR system. Refer to «SIR Disabling and Enabling Zone 3»(/cadillac/srx/i-2003-2009/remont/airbag/#supplemental-inflatable-restraint-system) .
  1. Disable the SIR system. Refer to «SIR Disabling and Enabling Zone 3»(/cadillac/srx/i-2003-2009/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
  2. Remove the steering column tilt head (1). Refer to «Steering Column Tilt Head Replacement»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column) .
  3. Check the steering column for accident damage. Refer to «Steering Column Accident Damage Inspection»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column__steering-column-accident-damage-inspection) .
  1. Install the steering column tilt head (1). Refer to «Steering Column Tilt Head Replacement»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column) .
  2. Enable the SIR system. Refer to «SIR Disabling and Enabling Zone 3»(/cadillac/srx/i-2003-2009/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
  1. Disable the SIR system. Refer to «SIR Disabling and Enabling Zone 3»(/cadillac/srx/i-2003-2009/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
  2. Remove the upper and lower trim covers. Refer to «Steering Column Trim Covers Replacement»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column)
  3. Remove the wire harness strap.
  4. Remove the theft deterrent control module. Refer to «Theft Deterrent Control Module Replacement»(/cadillac/srx/i-2003-2009/remont/door-locks-anti-theft-systems/#theft-deterrent-system) in Theft Deterrent.
  5. Rotate the key alarm connector (1) 90 degrees.
  6. Gently pull the key alarm connector (1) out of the ignition lock cylinder case assembly (2).
  7. Disconnect the connector from the ignition switch assembly.
  8. Remove the wires encased in the ignition switch clip located on the side of the ignition switch.
  9. Disconnect all connectors attached to the wire harness assembly.
  1. Connect all of the connectors from the new wire harness assembly.
  2. Push the key alarm connector (1) into the ignition lock cylinder case assembly (2).
  3. Rotate the key alarm connector (1) 90 degrees so that the key alarm connector (1) locks into place.
  4. Install the theft deterrent control module. Refer to «Theft Deterrent Control Module Replacement»(/cadillac/srx/i-2003-2009/remont/door-locks-anti-theft-systems/#theft-deterrent-system) in Theft Deterrent.
  5. Install the wires back into the ignition switch clip located on the side of the ignition switch.
  6. Install the wire harness strap.
  7. Install the upper and lower trim covers. Refer to «Steering Column Trim Covers Replacement»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column) .
  8. Enable the SIR system. Refer to «SIR Disabling and Enabling Zone 3»(/cadillac/srx/i-2003-2009/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.

J 21854-01 Pivot Pin Remover. See Special Tools .

  1. Disable the SIR system. Refer to «SIR Disabling and Enabling Zone 3»(/cadillac/srx/i-2003-2009/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
  2. Remove the steering column from the vehicle. Refer to «Steering Column Replacement»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column) .
  3. Remove the turn signal switch housing. Refer to «Steering Column Tilt Head Replacement»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column) .
  4. Remove the tilt spring only. Refer to «Tilt Spring Replacement»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column) .
  5. Remove 2 pivot pins (1) from the steering column support assembly using J 21854-01 . See «Special Tools»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column__special-tools) .
  6. Remove the boot seal (5).
  7. If sensor is not present, remove the following: The steering shaft seal (4) The sensor retainer (3)
  8. If sensor is present, remove the following: The sensor locator (2) The sensor assembly (1)
  1. If sensor is not present, install the following: The sensor retainer (3) The steering shaft seal (4)
  2. If sensor is present, install the following The sensor assembly (1) The sensor assembly must be aligned to the 9 o'clock position. The sensor locator (2)
  3. Install the boot seal (5)
  4. Install the steering shaft assembly (2) into the steering column tilt head assembly (1).
  5. Install the tilt head assembly (1) and the steering shaft (3) into the steering column jacket assembly (2).
  6. Lubricate the pivot pins with GM P/N 12346293 (Canadian P/N 992723). Install the 2 pivot pins onto the steering column support assembly. Stake the pins in 3 places.
  7. Install the tilt spring assembly only. Refer to «Tilt Spring Replacement»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column) .
  8. Install the turn signal switch housing. Refer to «Steering Column Tilt Head Replacement»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column) .
  9. Install the steering column to the vehicle. Refer to «Steering Column Replacement»(/cadillac/srx/i-2003-2009/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column) .
  10. Enable the SIR system. Refer to «SIR Disabling and Enabling Zone 3»(/cadillac/srx/i-2003-2009/remont/airbag/#supplemental-inflatable-restraint-system) in SIR.
  1. Verify the type of steering wheel position sensor.
  2. From the technicians point of view, the FRONT of the sensor (1) connector will be on the right.
  3. Remove the connector from the sensor.
  4. Remove the sensor (1) from the adapter and bearing assembly.
  5. To install the sensor, proceed to step 1 in the installation section.
  6. From the technicians point of view, the FRONT of the sensor will have: A foam ring (2) A pin hole (1) for centering the pin. Note the location of the pin hole. A flush rotor flange cuff (4)
  7. Make an alignment mark on the flush rotor flange cuff (3).
  8. Remove the connector from the sensor.
  9. Remove the sensor from the adapter and bearing assembly.
  10. To install the sensor, proceed to step 5 in the installation procedure.
  11. From the technicians point of view, the FRONT of the sensor will have: A raised rotor flange cuff (3) An alignment mark (2) on the rotor flange cuff (3) for installation A pin hole (1) for the centering pin. Note the location of the pin hole.
  12. Remove the connector from the sensor.
  13. Remove the sensor from the adapter and bearing assembly.
  14. To install the sensor, proceed to step 9 in the installation procedure.
  15. From the technicians point of view, the FRONT of the sensor will have: A raised rotor flange cuff (3) An alignment mark (2) on the rotor flange cuff (3) for installation A pin hole (1) for the centering pin. Note location of the pin hole. A sensor clip in FRONT of the sensor
  16. Remove the connector from the sensor.
  17. Remove the sensor clip from the sensor.
  18. Remove the sensor from the adapter and bearing assembly.
  19. To install the sensor, proceed to step 13 in the installation procedure.
  20. From the technicians point of view, the FRONT of the sensor will have: A flush rotor flange cuff (3) A pin hole (1) for the centering pin. Note the location of the pin hole. An alignment mark (2) on the flush rotor flange cuff (3) for installation
  21. Remove the connector from the sensor.
  22. Remove the sensor from the adapter and bearing assembly.
  23. To install the sensor, proceed to step 17 in the installation procedure.
  24. From the technicians point of view, the FRONT of the sensor will have: A flush rotor flange cuff (4) A pin hole (2) for the centering pin-Note the location of the pin hole. An alignment mark (3) on the flush rotor flange cuff (4) for installation A foam ring (1)
  25. Remove the connector from the sensor.
  26. Remove the sensor from the adapter and bearing assembly.
  27. To install the sensor, proceed to step 21 in the installation procedure.
  1. If installing a new sensor, it will come with a pin installed in the sensor. Do not remove the pin until the sensor is seated.
  2. From the technicians point of view, the FRONT of the sensor (1) connector will be on your right. From the technicians point of view, the BACK of the sensor (2) connector will be on your left.
  3. Looking at the FRONT of the sensor, align the sensor with the steering shaft and install into the adapter and bearing assembly.
  4. Install the connector to the sensor.
  5. From the technicians point of view, the FRONT of the sensor will have: A foam ring (4) A pin hole (7) for the centering pin-Note the location of the pin hole. A flushed rotor flange cuff (6) An alignment mark (5) for installation
  6. From the technicians point of view, the BACK of the sensor will have: Double D flats (1) A foam ring (3) An alignment tab (2) for installing into the adapter and bearing assembly A view of the inside of the connector
  7. Looking at the FRONT of the sensor, align the sensor with the steering shaft and install into the adapter and bearing assembly.
  8. Install the connector to the sensor.
  9. From the technicians point of view, the FRONT of the sensor will have: A pin hole (3) for the centering pin-Note location of the pin hole. A raised rotor flange cuff (5) An alignment mark (4) for installation
  10. From the technicians point of view, the BACK of the sensor will have: Double D flats (1) An alignment tab (2) for installing into the adapter and bearing assembly
  11. Looking at the FRONT of the sensor, align the sensor with the steering shaft and install into the adapter and bearing assembly.
  12. Install the connector to the sensor.
  13. From the technicians point of view, the FRONT of the sensor will have: A pin hole (2) for the centering pin- Note the location of the pin hole. A raised rotor flange cuff (4) An alignment mark (3) for installation
  14. From the technicians point of view, the BACK of the sensor will have an alignment tab (1) for installation. This sensor does not have double D flats.
  15. Looking at the FRONT of the sensor, align the sensor with the steering shaft and install into the adapter and bearing assembly.
  16. Install the connector to the sensor.
  17. From the technicians point of view, the FRONT of the sensor will have: A pin hole (2) for the centering pin-Note the location of the pin hole. A flush rotor flange cuff (4) An alignment mark (3) for installation
  18. From the technicians point of view, the BACK of the sensor will have an alignment tab (1) for installation. This sensor does not have double D flats.
  19. Looking at the FRONT of the sensor, align the sensor with the steering shaft and install into the adapter and bearing assembly.
  20. Install the connector to the sensor.
  21. From the technicians point of view, the FRONT of the sensor will have: A pin hole (3) for the centering pin-Note location of the pin hole. A flush rotor flange cuff (5) An alignment mark (4) for installation A foam ring (6)
  22. From the technicians point of view, the BACK of the sensor will have: Double D flats (1) An alignment tab (2) for installing into the adapter and bearing assembly
  23. Looking at the FRONT of the sensor, align the sensor with the steering shaft and install into the adapter and bearing assembly.
  24. Install the connector to the sensor.

Inflatable Restraint Steering Wheel Module Coil Centering

  1. Verify the following before centering the SIR coil: The wheels on the vehicle are straight ahead. The block tooth (1) of the steering shaft assembly is in the 12 o'clock position. The ignition switch is in the LOCK position.
  2. If the front (5) of the SIR coil has a centering window (4), and on the back side (2) a spring service lock (1), perform the following steps: Hold the SIR coil with the face up. While depressing the spring service lock, rotate the coil hub clockwise until the coil ribbon stops. Rotate the coil hub slowly, counterclockwise, until the centering window appears yellow and both arrows (3) line up. Release spring service lock between the locking tab. The SIR coil is now centered. Align the centered SIR coil with the horn tower and slide onto the steering shaft assembly.
  3. If the front (4) of the SIR coil has a centering window (3) and no spring service lock on the back side (1), perform the following steps: Hold the SIR coil with the face up. Rotate the coil hub clockwise until the coil ribbon stops. Rotate the coil hub slowly, counterclockwise until the centering window appears yellow and both arrows (2) line up. This is the CENTER position. While holding the coil hub in the CENTER position, align the SIR coil with the horn tower and slide onto the steering shaft assembly.
  4. If no centering window is present on the front side (3) of the SIR coil, but a spring service lock (1) is on the back side (2), perform the following steps: Hold the SIR coil with the back side up. While depressing the spring service lock, rotate the coil hub in the direction of the arrow (4) until the coil ribbon stops. Still pressing the spring service lock, rotate the coil hub in the opposite direction 2 1/2 revolutions. Release the spring service lock between locking tabs. The SIR coil is now centered. Align the centered SIR coil with the horn tower and slide onto the steering shaft assembly.
  5. For no centering window on the front side (2) of the SIR coil and no spring service lock on the back side (1), perform the following steps: Hold the SIR coil with the face up. Rotate the coil hub in the direction of the arrow (3) until the coil ribbon stops. Rotate the coil hub, slowly, counterclockwise, for 2 1/2 revolutions. This is the CENTER position. While maintaining the coil hub in the CENTER position, align the centered SIR coil with the horn tower and slide onto the steering shaft assembly.

Steering Wheel Controls Description and Operation

The audio steering wheel control switches duplicate the function of the primary controls of the associated component, through a network of multiple momentary contact switches and a series of resistors. The radio supplies voltage to the switches and monitors the return signal for a specific voltage drop to occur unique to the one pressed. The radio then identifies the switch selected to activate the feature, otherwise sends a serial data message that is received by the component controlled, activating the feature.

This section is intended to diagnosis the circuits between the radio and the audio steering wheel control switches. If the primary control for the device is inoperative, refer to the appropriate section for the component the steering wheel control switch is functioning.

Steering Wheel and Column Description and Operation

The steering wheel and column has 4 primary functions

  1. Vehicle steering
  2. Vehicle security
  3. Driver convenience
  4. Driver safety

Vehicle Steering

The steering wheel is the first link between the driver and the vehicle. The steering wheel is fastened to a steering shaft within the column. At the lower end of the column, the intermediate shaft connects the column to the steering gear.

Vehicle Security-Some Vehicle Models

Theft deterrent components are mounted and designed into the steering column. The following components allow the column to be locked in order to minimize theft

  1. The ignition switch
  2. The steering column lock
  3. The ignition cylinder

Driver Convenience

The steering wheel and column may also have driver controls attached for convenience and comfort. The following controls may be mounted on or near the steering wheel or column.

  1. The turn signal switch
  2. The hazard switch
  3. The headlamp dimmer switch
  4. The wiper/washer switch
  5. The horn pad/cruise control switch
  6. The redundant radio/entertainment system controls
  7. The tilt or tilt/telescoping functions
  8. The navigation/OnStar® features
  9. The HVAC controls

Driver Safety

The energy-absorbing steering column compresses in the event of a front-end collision, which reduces the chance of injury to the driver. The mounting capsules break away from the mounting bracket in the event of an accident.

Ignition Lock Cylinder Control Actuator

If the vehicle is equipped with a floor mounted console gear shifter, it has a ignition lock cylinder control actuator system in the steering column. The ignition lock cylinder control actuator's purpose is to prevent the ignition key from being turned to the OFF position when the transmission is in gear and the vehicle may still be moving. The column ignition lock system consists of a ignition lock cylinder control actuator, and a park position switch that is located in the A/T shift lock control switch. The ignition lock cylinder control actuator contains a pin that is spring loaded out to mechanically prevent the ignition key cylinder from being turned to the lock position when vehicle transmission is not in the Park position. If vehicle power is lost, and/or the transmission is not in the Park position the operator will not be able to turn the ignition key to the lock position and will not be able to remove the ignition key from the column.

Special Tools

Special Tools Illustration Tool Number/Description J 1859-A Steering Wheel Puller J 21854-01 Pivot Pin Remover J 23653-SIR Lock Plate Compressor J 42137 Cam Orientation Plate Adapter J 42578 Steering Wheel Puller Legs J 42640 Steering Column Anti-Rotation Pin

Scheme 5

Scheme 5: Special Tools
Scheme 5: Special Tools

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7

See also:
• Diagnostic System Check - Vehicle
• Entertainment Connector End Views
• Testing for Intermittent Conditions and Poor Connections
• Circuit Testing
• Wiring Repairs
• Connector Repairs
• Control Module References
• Remote CD Changer Replacement
• Checking Aftermarket Accessories
• Automatic Transmission Shift Lock Actuator Replacement
• Key and Lock Cylinder Coding
• Shift Control Linkage Adjustment
• Fastener Notice
• Inflatable Restraint Steering Wheel Module Coil Replacement
• SIR Caution
• Battery Negative Cable Disconnect/Connect Procedure
• Theft Deterrent Control Module Replacement
• Knee Bolster Bracket Replacement - Left
• Steering Wheel Schematics
• Steering Wheel and Column Description and Operation
• Lock System Does Not Unlock
• Lock System Does Not Lock
• Lock System Sticks in Start
• Key Cannot Be Removed in the Off Lock Position
• High Lock Effort
• Noise in Steering Column
• Looseness in Steering Column
• Steering Column Tilt Function Inoperative
• Steering Wheel Controls Description and Operation
• Symptoms - Steering Wheel and Column
• Steering Wheel and Column Connector End Views
• Fastener Tightening Specifications
• Turn Signal Cancel Cam and Upper Bearing Inner Race Replacement
• Special Tools
• Steering Wheel Replacement
• Steering Column Accident Damage Inspection
