Scheme 1
Scheme 2
| Callout | Component Name |
|---|---|
| 1 | Rear Parking Assist (RPA) Module |
Scheme 3
| Callout | Component Name |
|---|---|
| 1 | Rear Parking Assist (RPA) Object Sensor - Right Rear Corner |
| 2 | RPA Object Sensor - Right Rear Middle |
| 3 | RPA Object Sensor - Left Rear Middle |
| 4 | RPA Object Sensor - Left Rear Corner |
Scheme 4
| Callout | Component Name |
|---|---|
| 1 | Blower Motor Switch - Auxiliary (C57) |
| 2 | Blower Motor Switch - Rear Auxiliary (C57) |
| 3 | Courtesy/Reading Lamp - Rear |
| 4 | Rear Parking Assist (RPA) Display |
| 5 | Courtesy/Reading Lamp - Center |
| 6 | Courtesy/Reading Lamp - Front |
Scheme 5
| Callout | Component Name |
|---|---|
| 1 | Audio Amplifier |
| 2 | Rear Parking Assist (RPA) Diagnostic Connector |
Object Detection Connector End Views
Object Sensor - LR Corner Connector Part Information 15324398 3-Way F MQS Sealed (BK) Pin Wire Color Circuit No. Function 1 YE 2375 LR Corner Object Sensor Signal 2 GY 2379 Object Sensor Low Reference 3 D-BU 2374 Object Sensor Supply Voltage
Object Sensor - RR Corner Connector Part Information 15324398 3-Way F MQS Sealed (BK) Pin Wire Color Circuit No. Function 1 PU 2378 RR Corner Object Sensor Signal 2 GY 2379 Object Sensor Low Reference 3 D-BU 2374 Object Sensor Supply Voltage
Object Sensor - LR Middle Connector Part Information 15324398 3-Way F MQS Sealed (BK) Pin Wire Color Circuit No. Function 1 OG 2376 LR Middle Object Sensor Signal 2 GY 2379 Object Sensor Low Reference 3 D-BU 2374 Object Sensor Supply Voltage
Object Sensor - RR Middle Connector Part Information 15324398 3-Way F MQS Sealed (BK) Pin Wire Color Circuit No. Function 1 D-GN 2377 RR Middle Object Sensor Signal 2 GY 2379 Object Sensor Low Reference 3 D-BU 2374 Object Sensor Supply Voltage
Rear Object Sensor Control Module Connector Part Information 927690-1 26-Way F Amp (BK) Pin Wire Color Circuit No. Function 1 YE 2375 LR Corner Object Sensor Signal 2 OG 2376 LR Middle Object Sensor Signal 3 D-GN 2377 RR Middle Object Sensor Signal 4 PU 2378 RR Corner Object Sensor Signal 5 D-BU 2374 Object Sensor Supply Voltage 6 GY 2379 Object Sensor Low Reference 7-11 - - Not Used 12 BK 850 Ground 13 PK 1339 Ignition 1 Voltage 14 - - Not Used 15 L-GN 24 Backup Lamp Supply Voltage 16 L-GN 9800 Rear Parking Assist Diagnostic Input 17 - - Not Used 18 BN 818 Vehicle Speed Signal 19-21 - - Not Used 22 L-BU 9534 Rear Parking Aide Chime 23 WH 2370 Telltale Assembly Supply Voltage 24 GY 2373 Red Indicator Control 25 D-BU 2372 Center Amber Indicator Control 26 OG 2371 Left Amber Indicator Control
Rear Parking Assist (RPA) Diagnostic Connector Connector Part Information 08905615 1-Way F 56 Series (L-GY) Pin Wire Color Circuit No. Function A L-GN 9800 Rear Parking Assist Diagnostic Input
Rear Parking Assist (RPA) Display Connector Part Information 12045813 4-Way F Metri-Pack 150 Series (NA) Pin Wire Color Circuit No. Function A WH 2370 Telltale Assembly Supply Voltage B OG 2371 Left Amber Indicator Control C D-BU 2372 Center Amber Indicator Control D GY 2373 Red Indicator Control
Diagnostic Starting Point - Ultrasonic Rear Parking Assist
Begin the system diagnosis by reviewing the system Description and Operation. Refer to Object Detection Description and Operation . Reviewing the Description and Operation information will help you determine the correct symptom diagnostic procedure when a malfunction exists. Reviewing the Description and Operation information will also help you determine if the condition described by the customer is normal operation. Refer to Symptoms - Ultrasonic Rear Parking Assist in order to identify the correct procedure for diagnosing the system and where the procedure is located.
Diagnostic Trouble Code (DTC) Displaying
This vehicle is equipped with an on-board diagnostic display feature capable of displaying DTCs using the 3 indicators on the rear parking assist display. After the bulb check has been completed, the red outside indicator flashes to indicate a malfunction with the system. The module disables operation of the ultrasonic rear parking assist (URPA) system under this condition.
In order to enter the diagnostic mode, complete the following actions
- With the ignition turned OFF, short the rear parking assist diagnostic connector to ground while the vehicle is in PARK. Refer to «Object Detection Component Views»(/cadillac/srx/i-2003-2009/remont/collisionavoidance/#object-detection-system) for the location of the rear parking assist diagnostic connector.
- Turn the ignition ON.
- Place your foot on the brake.
- Shift the vehicle into REVERSE within 5 seconds. If the vehicle is not shifted into reverse within 5 seconds after turning the ignition ON, the diagnostic mode will still be initiated. However, a reverse input wiring fault will be registered as sequence #7 as shown in the Diagnostic Indicator table below. Refer to «Diagnostic Trouble Code (DTC) Clearing»(/cadillac/srx/i-2003-2009/remont/collisionavoidance/#object-detection-system__diagnostic-trouble-code-dtc-clearing) for specific steps on how to clear DTCs. After the reverse input wiring code is cleared, repeat the DTC displaying steps in order to enter the diagnostic mode.
When the diagnostic mode is first entered, the rear parking assist display displays the amber outside indicator and the red outside indicator. Then the indicators on the rear parking assist display will display one or more of the sequences in the table below to indicate where the fault exists within the rear parking assist system. Refer to Diagnostic Trouble Code (DTC) Clearing for the specific steps on how to clear diagnostic trouble codes.
| # | State/Fault Location | Amber Outside | Amber Middle | Red Outside | Flashing |
|---|---|---|---|---|---|
| 1 | Start of Diagnostics | X | X | ||
| 2 | RR Corner Object Sensor and Wiring | X | |||
| 3 | RR Middle Object Sensor and Wiring | X | X | ||
| 4 | LR Middle Object Sensor and Wiring | X | X | ||
| 5 | LR Corner Object Sensor and Wiring | X | |||
| 6 | Chime Warning Wiring | X | |||
| 7 | Reverse Input Wiring | X | X | ||
| 8 | IMPORTANT: This diagnostic pattern sets for an open sensor supply voltage circuit and sensor low reference circuit. Sensor Supply Voltage Circuit and Sensor Low Reference Circuit | X | X | X | X Flashes in the following sequence: Amber Outside Amber Outside and Amber Middle Amber Middle and Red Outside Red Outside |
| 9 | IMPORTANT: This diagnostic pattern sets for a short to ground in the sensor supply voltage circuit. Sensor Supply Voltage Circuit | X | X | X |
| IMPORTANT |
|---|
| This diagnostic pattern sets for an open sensor supply voltage circuit and sensor low reference circuit. |
| IMPORTANT |
|---|
| This diagnostic pattern sets for a short to ground in the sensor supply voltage circuit. |
Diagnostic Indicators
Diagnostic Trouble Code (DTC) Clearing
The rear parking assist diagnostic sequences may be cleared in one of the following ways
Vehicle Moving
| IMPORTANT | The sequences will not clear if the rear parking assist diagnostic connector is grounded. |
- Drive the vehicle forward at least 24 km/h (15 mph).
- Stop the vehicle.
- Turn the ignition OFF.
Vehicle Stopped
| IMPORTANT | The sequences will not clear if the rear parking assist diagnostic connector is grounded. |
- Turn the ignition ON.
- Place foot on the brake.
- Shift the vehicle into REVERSE within five seconds.
- Turn the ignition OFF.
Symptoms - Ultrasonic Rear Parking Assist
| IMPORTANT | Review the system operation in order to familiarize yourself with the system functions. Refer to Object Detection Description and Operation . |
Visual/Physical Inspection
- Inspect for aftermarket devices which could affect the operation of the system. Refer to «Checking Aftermarket Accessories»(/cadillac/srx/i-2003-2009/remont/body-electrical/#how-to-diagnosis-repair-the-wiring-systems-testing__checking-aftermarket-accessories) in Wiring Systems.
- Inspect the easily accessible or visible system components for obvious damage or conditions which could cause the symptom.
- Make sure the rear parking assist sensors located on the vehicle rear bumper are clear. Remove any snow, mud or ice that is blocking the sensors.
Intermittent
Faulty electrical connections or wiring may be the cause of intermittent conditions. Refer to Testing for Intermittent Conditions and Poor Connections in Wiring Systems.
Symptom List
Refer to a symptom diagnostic procedure from the following list in order to diagnose the symptom
- «Rear Parking Assist Malfunction»(/cadillac/srx/i-2003-2009/remont/collisionavoidance/#object-detection-system)
- «Rear Parking Assist Inoperative - Red Indicator Flashes»(/cadillac/srx/i-2003-2009/remont/collisionavoidance/#object-detection-system__rear-parking-assist-inoperative-red)
Diagnostic Aids
Before performing this procedure, ensure that the vehicle park brake is SET.
| Step | Action | Value(s) | Yes | No |
|---|---|---|---|---|
| Schematic Reference: Object Detection Schematics Connector End View Reference: Object Detection Connector End Views or Computer/Integrating Systems Connector End Views | ||||
| 1 | Did you review the operation and perform the necessary inspections? | Go to Step 2 | Go to Symptoms - Ultrasonic Rear Parking Assist | |
| 2 | Turn ON the ignition. Place foot on the BRAKE. Shift vehicle into REVERSE. Do all three display indicators illuminate for 2 seconds and then turn off? | Go to Testing for Intermittent Conditions and Poor Connections | Go to Step 3 | |
| 3 | Does the red indicator flash? | Go to Rear Parking Assist Inoperative - Red Indicator Flashes | Go to Step 4 | |
| 4 | Do all of the indicators but one indicator illuminate? | Go to Step 6 | Go to Step 5 | |
| 5 | Does any indicator remain on? | Go to Step 7 | Go to Step 10 | |
| 6 | Connect a test lamp between the control circuit of the inoperative indicator at the module connector and a good ground. Does the test lamp illuminate? | Go to Step 16 | Go to Step 8 | |
| 7 | Turn the ignition OFF. Disconnect the rear parking assist display. Turn ON the ignition. Connect a test lamp between the rear parking assist display supply voltage circuit and the malfunctioning indicator control circuit. Does the indicator illuminate? | Go to Step 9 | Go to Step 15 | |
| 8 | Test the control circuit of the inoperative indicator for the following: An open A short to battery voltage A high resistance Refer to Circuit Testing and to Wiring Repairs . Did you find and correct the condition? | Go to Step 19 | Go to Step 15 | |
| 9 | Test the control circuit of the indicator for a short to ground. Refer to Circuit Testing and Wiring Repairs . Did you find and correct the condition? | Go to Step 19 | Go to Step 16 | |
| 10 | Test the rear object sensor control module ground circuit for an open. Refer to Circuit Testing and Wiring Repairs . Did you find and correct the condition? | Go to Step 19 | Go to Step 11 | |
| 11 | Test the rear object sensor control module ignition 1 voltage circuit for an open and for a short to ground. Refer to Circuit Testing and. Wiring Repairs . Did you find and correct the condition? | Go to Step 19 | Go to Step 12 | |
| 12 | Test the backup lamp supply voltage circuit for an open or for a short to ground. Refer to Circuit Testing and Wiring Repairs . Did you find and correct the condition? | Go to Step 19 | Go to Step 13 | |
| 13 | Turn the ignition OFF. Disconnect the rear parking assist display. Turn the ignition ON. Connect a test lamp between the rear parking assist display supply voltage circuit and a good ground. Does the test lamp illuminate? | Go to Step 15 | Go to Step 14 | |
| 14 | Test the rear parking assist display supply voltage circuit for an open and for a short to ground. Refer to Circuit Testing and Wiring Repairs . Did you find and correct the condition? | Go to Step 19 | Go to Step 16 | |
| 15 | Inspect for poor connections at the harness connector of the rear parking assist display. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs . Did you find and correct the condition? | Go to Step 19 | Go to Step 17 | |
| 16 | Inspect for poor connections at the harness connector of the rear object sensor control module. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs . Did you find and correct the condition? | Go to Step 19 | Go to Step 18 | |
| 17 | Replace the rear parking assist display. Refer to Information Center Telltale Assembly Replacement . Did you complete the replacement? | Go to Step 19 | ||
| 18 | Replace the rear object sensor control module. Refer to Control Module References for replacement, setup, and programming. Did you complete the replacement? | Go to Step 19 | ||
| 19 | Operate the system in order to verify the repair. Did you correct the condition? | System OK | Go to Step 2 | |
Rear Parking Assist Malfunction
Rear Parking Assist Inoperative - Red Indicator Flashes
| Step | Action | Value(s) | Yes | No |
|---|---|---|---|---|
| Schematic Reference: Object Detection Schematics Connector End View Reference: Object Detection Connector End Views or Computer/Integrating Systems Connector End Views IMPORTANT: Before performing this procedure, ensure that the vehicle park brake is SET. | ||||
| 1 | Did you review the operation and perform the necessary inspections? | Go to Step 2 | Go to Symptoms - Ultrasonic Rear Parking Assist | |
| 2 | Turn ON the ignition. Place foot on the BRAKE. Shift the vehicle into REVERSE. Does the red indicator continue to flash after the bulb check? | Go to Step 3 | Go to Testing for Intermittent Conditions and Poor Connections | |
| 3 | Turn OFF the ignition. Remove all objects at least 2 meters from the rear bumper. Enter the diagnostic mode. Refer to Diagnostic Trouble Code (DTC) Displaying for more information. Does diagnostic indicator pattern #1, Diagnostic Trouble Code (DTC) Displaying , appear as shown in the diagnostic indicator table when you enter diagnostics? | Go to Step 4 | Go to Step 14 | |
| 4 | Does diagnostic indicator pattern #2, 3, 4, or 5, Diagnostic Trouble Code (DTC) Displaying , appear as shown in the diagnostic indicator table? | Go to Step 9 | Go to Step 5 | |
| 5 | Does diagnostic indicator pattern #6, Diagnostic Trouble Code (DTC) Displaying , appear as shown in the diagnostic indicator table? | Go to Step 10 | Go to Step 6 | |
| 6 | Does diagnostic indicator pattern #7, Diagnostic Trouble Code (DTC) Displaying , appear as shown in the diagnostic indicator table? | Go to Diagnostic Trouble Code (DTC) Displaying and to Diagnostic Trouble Code (DTC) Clearing | Go to Step 7 | |
| 7 | Does diagnostic indicator pattern #8, Diagnostic Trouble Code (DTC) Displaying , appear as shown in the diagnostic indicator table? | Go to Step 8 | Go to Step 17 | |
| 8 | Turn OFF the ignition. Disconnect only ONE rear object sensor. Perform the following actions after a rear object sensor is disconnected: Enter the diagnostic mode to determine if the diagnostic indicator pattern #8 will still be displayed. When the sensor causing the short to ground is disconnected, the diagnostic indicator pattern #8 will not be displayed. The diagnostic indicator pattern displayed will be any one of the diagnostic indicator patterns #2, #3, #4 and #5. Refer to Diagnostic Trouble Code (DTC) Displaying for more information on how to enter the diagnostic mode. Reconnect the rear object sensor when it is determined the sensor is not source of the short to ground. Clear the diagnostic trouble code (DTC). Refer to Diagnostic Trouble Code (DTC) Clearing . Repeat the above process for all rear object sensors to determine if the sensors are the source of the short to ground. Does diagnostic indicator pattern #8, Diagnostic Trouble Code (DTC) Displaying , still appear as shown in the diagnostic indicator table? | Go to Step 15 | Go to Step 16 | |
| 9 | Turn OFF the ignition. Connect the DMM between the signal circuit of the inoperative rear object sensor and the low reference circuit of the rear object sensor at the rear object sensor control module with the harness connected to the module. Turn ON the ignition. Place foot on BRAKE. Shift the vehicle into REVERSE. Measure the voltage between the signal circuit of the inoperative rear object sensor and the low reference circuit of the rear object sensor. Does the voltage measure greater than the specified value? | 7 V | Go to Step 17 | Go to Step 11 |
| 10 | Turn OFF the ignition. Disconnect the rear object sensor control module connector. Measure the voltage between the rear parking assist chime signal circuit and a good ground. Does the voltage measure greater than the specified value? | 9.5 V | Go to Step 17 | Go to Step 13 |
| 11 | Test the signal circuit of the inoperative rear object sensor for an open, for a short to ground and for a short to B+. Refer to Circuit Testing and Wiring Repairs . Did you find and correct the condition? | Go to Step 22 | Go to Step 12 | |
| 12 | Test the supply voltage circuit and the low reference circuit of the inoperative rear object sensor for an open between S408 or S407 and the rear object sensor. Refer to Circuit Testing and Wiring Repairs . Did you find and correct the condition? | Go to Step 22 | Go to Step 16 | |
| 13 | Test the rear parking assist chime signal circuit for an open and for a short to ground. Refer to Circuit Testing and Wiring Repairs . Did you find and correct the condition? | Go to Step 22 | Go to Step 18 | |
| 14 | Test the rear parking assist diagnostic circuit for an open and for a high resistance. Refer to Circuit Testing and Wiring Repairs . Did you find and correct the condition? | Go to Step 22 | Go to Step 17 | |
| 15 | Test the supply voltage circuit and the low reference circuit of the rear object sensors for the following: An open A short to ground A high resistance Refer to Circuit Testing and Wiring Repairs . Did you find and correct the condition? | Go to Step 22 | Go to Step 17 | |
| 16 | Inspect for poor connections at the harness connector of the rear object sensor. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs . Did you find and correct the condition? | Go to Step 22 | Go to Step 19 | |
| 17 | Inspect for poor connections at the harness connector of the rear object sensor control module. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs . Did you find and correct the condition? | Go to Step 22 | Go to Step 20 | |
| 18 | Inspect for poor connections at the harness connector of the rear integration module (RIM). Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs . Did you find and correct the condition? | Go to Step 22 | Go to Step 21 | |
| 19 | Replace the inoperative rear object sensor. Refer to Rear Object Sensor Replacement . Did you find and correct the condition? | Go to Step 22 | ||
| 20 | Replace the rear object sensor control module. Refer to Control Module References for replacement, setup, and programming. Did you complete the replacement? | Go to Step 22 | ||
| 21 | Replace the RIM. Refer to Control Module References for replacement, setup, and programming. Did you complete the replacement? | Go to Step 22 | ||
| 22 | Clear all codes. Refer to Diagnostic Trouble Code (DTC) Clearing . Operate the system in order to verify the repair. Did you correct the condition? | System OK | Go to Step 2 | |
| IMPORTANT |
|---|
| Before performing this procedure, ensure that the vehicle park brake is SET. |
Rear Parking Assist Inoperative - Red Indicator Flashes
Removal Procedure
- Pull downward on the front of the RPA bezel in order to release the retaining clips (3).
- Disconnect the electrical connector (2).
- Remove the RPA tell tale indicator from the bezel.
Installation Procedure
- Install the RPA tell tale indicator into the bezel.
- Connect the electrical connector (2).
- Locate the rear bezel hook retainers (1) into the headliner assembly.
- Push upward on the front of the RPA bezel in order to secure the retaining clips (3).
- Remove rear bumper fascia. Refer to «Fascia Replacement - Rear Bumper»(/cadillac/srx/i-2003-2009/remont/exterior-body-panels/#bumper-system) in Bumpers.
- Lift the locking tabs on the housing (4) and remove the rear object sensor (1).
- Squeeze the spring (1) and remove it from the housing (2).
- Release the tabs on the housing and remove.
- Remove the rear object sensor bezel from the rear fascia.
- Paint the new rear object sensor. Refer to «Basecoat/Clearcoat Paint Systems»(/cadillac/srx/i-2003-2009/remont/paintcoatings/#paint-and-coatings__basecoatclearcoat-paint-systems) in Paint/Coatings.
- Inspect the paint thickness to ensure it does not exceed 6 mm using a paint thickness gauge suitable for non-ferrous metals. Refer to «Paint Gages»(/cadillac/srx/i-2003-2009/remont/paintcoatings/#paint-and-coatings__paint-gages) in Paint/Coatings.
- Align the keyhole (2) with the key (1) and press the rear object sensor bezel flush to the fascia.
- Install the housing to the cutouts on the bezel through the back side of the fascia.
- Install the spring (1) to the housing (2).
- Install the decoupling ring (2) to the sensor (1).
- Insert the sensor into the housing (4) with the connector pointing toward the passenger side of the fascia. Press the sensor tabs into the cutouts on the housing (4).
- Connect the electrical connector.
- Install the rear bumper fascia. Refer to «Fascia Replacement - Rear Bumper»(/cadillac/srx/i-2003-2009/remont/exterior-body-panels/#bumper-system) in Bumpers.
- Remove the left rear body side trim. Refer to «Trim Panel Replacement - Body Side Rear (w/o TB5)»(/cadillac/srx/i-2003-2009/remont/exteriorinterior-trim/#interior-trim) or «Trim Panel Replacement - Body Side Rear (w/TB5)»(/cadillac/srx/i-2003-2009/remont/exteriorinterior-trim/#interior-trim) in Interior Trim.
- Disconnect the RPA module electrical connector (1).
- Remove the RPA module.
- Install the RPA module to the retainers.
- Connect the electrical connector (1).
- Install the rear body side trim. Refer to «Trim Panel Replacement - Body Side Rear (w/o TB5)»(/cadillac/srx/i-2003-2009/remont/exteriorinterior-trim/#interior-trim) or «Trim Panel Replacement - Body Side Rear (w/TB5)»(/cadillac/srx/i-2003-2009/remont/exteriorinterior-trim/#interior-trim) in Interior Trim.
Object Detection Description and Operation
The ultrasonic rear parking assist (URPA) can help a driver determine how close an object is to the rear bumper within a defined rearward field of view.
The rear parking assist display is located inside the vehicle by the rear window. Refer to Object Detection Component Views for the location of the display. The display has 3 indicators that can be seen through the rearview mirror or by turning around when seated in the driver seat.
When the ignition is ON and the vehicle is placed into reverse, the URPA performs a bulb check. During the bulb check, the 3 indicators on the display illuminate for approximately 2 seconds to indicate that the system is working. The URPA performs a bulb check and operates when the following conditions are present
- The ignition is ON
- The vehicle is placed in REVERSE (R)
- The vehicle speed is less than 5 km/h (3 mph) At speeds greater than 5 km/h (3 mph), the URPA is disable. The red indicator flashes to warn the driver that the URPA is disabled.
The URPA senses how close the vehicle is to an object. The distance is determined by the four ultrasonic sensors located on the rear bumper. When the system detects an object, one of the following will occur
- If the object is less than 0.3 m (11 in) away from the rear of the vehicle, the amber outside, amber middle, and the red outside indicators flash and the chime sounds continuously.
- If the object is less than 0.3-0.5 m (11-20 in) away from the rear of the vehicle, the amber outside, amber middle, and the red outside indicators are on and the chime sounds continuously.
- If the object is 0.5-1.0 m (20-40 in) away from the rear of the vehicle, the amber outside, and the amber middle indicators are on.
- If the object is 1.0-1.5 m (40 in to 5 ft) away from the rear of the vehicle, the amber outside indicator is on and the chime sounds one time on the first detection of an object.
URPA can detect objects 7.6 cm (3 in) wide and at least 25.4 cm (10 in) tall. It cannot detect objects above the level of the roof.
If the red indicator flashes continuously the on-board diagnostic needs to be entered to determine if a malfunction is present. Refer to Diagnostic Trouble Code (DTC) Displaying .
