Scheme 109
Scheme 109: Disassembled Views
| Callout | Component Name |
|---|
| 1 | Bolt |
| 2 | Nut |
| 3 | Throttle Body |
| 4 | Throttle Body Seal |
| 5 | Manifold Absolute Pressure (MAP) Sensor O-ring Seal |
| 6 | MAP Sensor |
| 7 | Sequential Multi-Port Fuel Injector Assembly with Fuel Rail |
| 8 | Bolt |
| 9 | Fuel Injection Fuel Rail Bracket |
| 10 | Evaporative (EVAP) Emission Canister Purge Tube |
| 11 | EVAP Emission Canister Purge Solenoid Valve |
| 12 | EVAP Emission Canister Purge Tube |
| 13 | Bolt |
| 14 | Fuel Injection Fuel Rail Stop |
| 15 | Bolt |
| 16 | Intake Manifold |
| 17 | Intake Manifold Seal |
| 18 | Intake Manifold Gasket |
| 19 | Engine Coolant Air Bleed Plug |
| 20 | Engine Oil Pressure Sensor |
| 21 | Bolt |
| 22 | Bolt |
| 23 | Engine Coolant Air Bleed Pipe |
| 24 | Engine Coolant Air Bleed Pipe O-ring Seal |
| 25 | Engine Valley Cover |
| 26 | O-ring Seal |
| 27 | Gasket |
| 28 | Engine Block |
Scheme 110
| Callout | Component Name |
|---|
| 1 | Bolt |
| 2 | Nut |
| 3 | Throttle Body |
| 4 | Throttle Body Seal |
| 5 | Manifold Absolute Pressure (MAP) Sensor O-ring Seal |
| 6 | MAP Sensor |
| 7 | Sequential Multi-Port Fuel Injector Assembly with Fuel Rail |
| 8 | Bolt |
| 9 | Fuel Injection Fuel Rail Bracket |
| 10 | Evaporative (EVAP) Emission Canister Purge Tube |
| 11 | EVAP Emission Canister Purge Solenoid Valve |
| 12 | EVAP Emission Canister Purge Tube |
| 13 | Bolt |
| 14 | Fuel Injection Fuel Rail Stop |
| 15 | Bolt |
| 16 | Intake Manifold |
| 17 | Intake Manifold Seal |
| 18 | Intake Manifold Gasket |
| 19 | Engine Coolant Air Bleed Plug |
| 20 | Engine Oil Pressure Sensor |
| 21 | Valve Lifter Oil Filter |
| 22 | Valve Lifter Oil Filter Seal |
| 23 | Bolt |
| 24 | Bolt |
| 25 | Engine Coolant Air Bleed Pipe |
| 26 | Engine Coolant Air Bleed Pipe O-ring Seal |
| 27 | Engine Valley Cover |
| 28 | Gasket |
| 29 | Engine Block |
Scheme 111
| Callout | Component Name |
|---|
| 100 | Engine Block |
| 209 | Valve Lifter |
| 210 | Valve Lifter Guide |
| 211 | Valve Lifter Guide Bolt |
| 212 | Valve Push Rod |
| 213 | Valve Rocker Arm |
| 214 | Valve Rocker Arm Pivot Support Bolt |
| 215 | Valve Rocker Arm Pivot Support |
| 216 | Cylinder Head Core Hole Plug |
| 217 | Cylinder Head Gasket |
| 218 | Cylinder Head |
| 220 | Cylinder Head Bolt - M10 |
| 221 | Cylinder Head Bolt - M8 |
| 222 | Valve Stem Oil Seal |
| 223 | Valve Spring |
| 224 | Valve Spring Cap |
| 225 | Valve Stem Key |
| 226 | Cylinder Head Core Hole Plug |
| 227 | Intake Valve |
| 228 | Exhaust Valve |
| 229 | Cylinder Head Plug |
| 230 | Cylinder Head Locating Pin |
| 422 | Oil Fill Tube O-Ring Seal |
| 423 | Oil Fill Tube |
| 424 | Oil Fill Cap |
| 450 | Oil Fill Cap O-Ring Seal |
| 504 | Valve Rocker Arm Cover Gasket |
| 504 | Valve Rocker Arm Cover Gasket |
| 505 | Valve Rocker Arm Cover |
| 505 | Valve Rocker Arm Cover |
| 516 | Valve Rocker Arm Cover Bolt |
| 600 | Exhaust Manifold |
| 601 | Exhaust Manifold Gasket |
| 602 | Exhaust Manifold Flange Bolt |
| 603 | Exhaust Manifold Heat Shield |
| 604 | Exhaust Manifold Heat Shield Bolt |
| 700 | Positive Crankcase Ventilation (PCV) Hose - Fresh Air |
| 716 | PCV Hose - Dirty Air |
| 719 | Ignition Coil Bracket |
| 720 | Ignition Coil Bracket Stud |
| 721 | Ignition Coil Wire Harness Assembly |
| 722 | Ignition Coil |
| 723 | Ignition Coil Bolt |
| 724 | Spark Plug Wire |
| 725 | Engine Coolant Temperature Sensor |
| 726 | Spark Plug |
Scheme 112
| Callout | Component Name |
|---|
| 100 | Engine Block |
| 209 | Valve Lifter - Non-Active Fuel Management |
| 210 | Valve Lifter Guide |
| 211 | Valve Lifter Guide Bolt |
| 212 | Valve Push Rod |
| 213 | Valve Rocker Arm |
| 214 | Valve Rocker Arm Pivot Support Bolt |
| 215 | Valve Rocker Arm Pivot Support |
| 216 | Cylinder Head Core Hole Plug |
| 217 | Cylinder Head Gasket |
| 218 | Cylinder Head |
| 219 | Valve Lifter - Active Fuel Management |
| 220 | Cylinder Head Bolt - M10 |
| 221 | Cylinder Head Bolt - M8 |
| 222 | Valve Stem Oil Seal |
| 223 | Valve Spring |
| 224 | Valve Spring Cap |
| 225 | Valve Stem Key |
| 226 | Cylinder Head Core Hole Plug |
| 227 | Intake Valve |
| 228 | Exhaust Valve |
| 229 | Cylinder Head Plug |
| 230 | Cylinder Head Locating Pin |
| 422 | Oil Fill Tube O-Ring Seal |
| 423 | Oil Fill Tube |
| 424 | Oil Fill Cap |
| 450 | Oil Fill Cap O-Ring Seal |
| 504 | Valve Rocker Arm Cover Gasket |
| 504 | Valve Rocker Arm Cover Gasket |
| 505 | Valve Rocker Arm Cover |
| 505 | Valve Rocker Arm Cover |
| 516 | Valve Rocker Arm Cover Bolt |
| 600 | Exhaust Manifold |
| 601 | Exhaust Manifold Gasket |
| 602 | Exhaust Manifold Flange Bolt |
| 603 | Exhaust Manifold Heat Shield |
| 604 | Exhaust Manifold Heat Shield Bolt |
| 700 | Positive Crankcase Ventilation (PCV) Hose - Fresh Air |
| 716 | PCV Hose - Dirty Air |
| 719 | Ignition Coil Bracket |
| 720 | Ignition Coil Bracket Bolt |
| 721 | Ignition Coil Wire Harness Assembly |
| 722 | Ignition Coil |
| 723 | Ignition Coil Bolt |
| 724 | Spark Plug Wire |
| 725 | Engine Coolant Temperature Sensor |
| 726 | Spark Plug |
Scheme 113
| Callout | Component Name |
|---|
| 1 | Water Pump Inlet Bolt |
| 2 | Water Pump Inlet |
| 3 | Engine Coolant Thermostat |
| 4 | Water Pump Bolt |
| 5 | Water Pump |
| 6 | Water Pump Gasket |
| 7 | Oil Level Indicator |
| 8 | Oil Level Indicator O-Ring Seal |
| 9 | Oil Level Indicator Tube Bolt |
| 10 | Oil Level Indicator Tube |
| 11 | Oil Level Indicator Tube O-Ring |
| 12 | Engine Block |
| 13 | Camshaft Bearing |
| 14 | Camshaft |
| 15 | Camshaft Sprocket Locating Pin |
| 16 | Camshaft Retainer |
| 17 | Camshaft Retainer Bolt |
| 18 | Camshaft Position (CMP) Actuator |
| 19 | CMP Actuator Solenoid Valve |
| 20 | Crankshaft Sprocket |
| 21 | Timing Chain |
| 22 | Timing Chain Tensioner |
| 23 | Timing Chain Tensioner Bolt |
| 24 | Engine Front Cover Gasket |
| 25 | Engine Front Cover |
| 26 | Engine Front Cover Bolt |
| 27 | CMP Actuator Magnet Gasket |
| 28 | CMP Actuator Magnet |
| 29 | CMP Actuator Hub Cover Bolt |
| 30 | CMP Sensor Bolt |
| 31 | CMP Sensor O-Ring Seal |
| 32 | CMP Sensor |
| 33 | CMP Sensor Wire Harness Assembly |
| 34 | CMP Sensor Wire Harness Assembly Bolt |
| 35 | Crankshaft Front Oil Seal |
| 36 | Crankshaft Balancer |
| 37 | Crankshaft Balancer Bolt |
| 38 | Oil Pump Bolt |
| 39 | Oil Pump |
| 40 | Oil Pressure Relief Valve |
| 41 | Oil Pressure Relief Valve Spring |
| 42 | Oil Pressure Relief Valve Bore Plug |
| 42 | Oil Pump Driven Gear |
| 44 | Oil Pump Drive Gear |
| 45 | Oil Pump Cover |
| 46 | Oil Pump Cover Bolt |
Scheme 114
| Callout | Component Name |
|---|
| 100 | Engine Block |
| 132 | Flex Plate - Automatic Transmission |
| 133 | Flywheel Bolt |
| 141 | Crankshaft Rear Oil Seal |
| 517 | Crankshaft Rear Oil Seal Housing Bolt |
| 518 | Crankshaft Rear Oil Seal Housing |
| 519 | Crankshaft Rear Oil Seal Housing Gasket |
Scheme 115
| Callout | Component Name |
|---|
| 1 | Engine Block |
| 2 | Piston Pin Retainer |
| 3 | Piston Pin |
| 4 | Piston Ring Set |
| 5 | Piston |
| 6 | Connecting Rod |
| 7 | Connecting Rod Bearing |
| 8 | Connecting Rod Cap |
| 9 | Connecting Rod Bolt |
| 10 | Crankshaft Bearing |
| 11 | Crankshaft Thrust Bearing |
| 12 | Crankshaft Balancer Key |
| 13 | Crankshaft |
| 14 | Crankshaft Bearing Cap Stud - M10 |
| 15 | Crankshaft Bearing Cap Bolt - M10 |
| 16 | Crankshaft Bearing Cap |
| 17 | Crankshaft Bearing Cap Bolt - M8 |
| 18 | Crankshaft Oil Deflector |
| 19 | Crankshaft Oil Deflector Nut |
| 20 | Oil Pan Gasket |
| 21 | Oil Pan Baffle Bolt |
| 22 | Oil Pan Baffle |
| 23 | Oil Pan Closeout Cover |
| 24 | Oil Pan Closeout Cover Bolt |
| 25 | Active Fuel Management Oil Pressure Relief Valve |
| 26 | Oil Pan Cover Gasket |
| 27 | Oil Pan Cover |
| 28 | Oil Pan Cover Bolt |
| 29 | Oil Filter Fitting |
| 30 | Oil Filter |
| 31 | Oil Pan Bolt |
| 32 | Oil Pan Bolt |
| 33 | Oil Pan |
| 34 | Oil Pan Drain Plug |
| 35 | Oil Pan Closeout Cover |
| 36 | Oil Pan Closeout Cover Bolt |
| 37 | Oil Pump Suction Pipe Nut |
| 38 | Oil Pump Suction Pipe Bolt |
| 39 | Oil Pump Screen Assembly with Oil Pump Suction Pipe |
| 40 | Oil Pump O-Ring Seal |
Scheme 116
| Callout | Component Name |
|---|
| 1 | Oil Gallery Plug - Front |
| 2 | Engine Block |
| 3 | Oil Gallery Plug Washer |
| 4 | Oil Gallery Plug - Side - M16 |
| 5 | Knock Sensor Bolt |
| 6 | Knock Sensor |
| 7 | Engine Block Coolant Drain Hole Plug - M28 |
| 8 | Engine Coolant Heater |
| 9 | Engine Coolant Heater Washer |
| 10 | Engine Block Coolant Drain Hole Plug - M16 |
| 11 | Engine Block Coolant Drain Hole Plug Washer |
| 12 | Crankshaft Position (CKP) Sensor Bolt |
| 13 | CKP Sensor |
| 14 | CKP Sensor O-Ring |
| 15 | Oil Gallery Plug - Rear |
| 16 | Oil Gallery Plug O-Ring |
| 17 | Transmission Housing Locating Pin |
Scheme 117
| Callout | Component Name |
|---|
| 408 | Bolt |
| 409 | Oil Pump Housing Cover |
| 410 | Oil Pump Drive Gear |
| 412 | Oil Pump Driven Gear |
| 413 | Oil Pump |
| 414 | Oil Pump Pressure Relief Valve |
| 415 | Oil Pump Pressure Relief Valve Spring |
| 416 | Oil Pump Housing Plug |
Scheme 118
Scheme 118: Engine Identification
The vehicle identification number (VIN) is located on the left side rear of the engine block (1) and is typically a 9 digit number stamped or laser-etched onto the engine at the vehicle assembly plant.
- The first digit identifies the division.
- The second digit identifies the model year.
- The third digit identifies the assembly plant.
- The fourth through ninth digits are the last 6 digits of the VIN.
