Scheme 466
Scheme 466: Seat Adjuster Motor Assembly - Driver X1 (AN3)
| Connector Part Information Harness Type: Driver Seat OEM Connector: 7283-6466-40 Service Connector: 19153175 Description: 6-Way F YESC 2.8MM (GY) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: Not Available Release Tool/Test Probe: Not Available |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 1 YE | 282 | Driver Seat Rear Vertical Motor Up Control |
| 2 | 1 D-GN | 286 | Driver Seat Front Vertical Motor Up Control |
| 3 | 1 TN | 285 | Driver Seat Horizontal Motor Forward Control |
| 4 | 1 L-BU | 283 | Driver Seat Rear Vertical Motor Down Control |
| 5 | 1 D-BU | 287 | Driver Seat Front Vertical Motor Down Control |
| 6 | 1 L-GN | 284 | Driver Seat Horizontal Motor Rearward Control |
Seat Adjuster Motor Assembly - Driver X1 (AN3)
Scheme 467
Scheme 467: Seat Adjuster Motor Assembly - Driver X2 (AN3)
| Connector Part Information Harness Type: Driver Seat OEM Connector: 7283-5532-40 Service Connector: 89046849 Description: 6-Way F 1.5 Series (GY) |
|---|
| Terminal Part Information Terminal/Tray: 7116-4100-08/9 Core/Insulation Crimp: E/C Release Tool/Test Probe: 12094430/J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.35 BN/WH | 557 | Front Vertical Motor Position Sensor Signal |
| 2 | 0.35 GY | 6206 | Low Reference |
| 3 | 0.35 D-GN | 569 | Horizontal Motor Position Sensor Signal |
| 4 | | | Not Used |
| 5 | 0.35 TN | 568 | Rear Vertical Motor Position Sensor Signal |
| 6 | 0.35 TN | 6207 | 5-Volt Reference |
Seat Adjuster Motor Assembly - Driver X2 (AN3)
Seat Adjuster Motor Assembly - Driver (without AN3 and without HP2)
| Connector Part Information Harness Type: Driver Seat OEM Connector: 7283-6466-40 Service Connector: 19153175 Description: 6-Way F YESC 2.8MM (GY) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: Not Available Release Tool/Test Probe: Not Available |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 3 YE | 282 | Driver Power Seat Rear Vertical Motor Up Control |
| 2 | 3 D-GN | 286 | Driver Power Seat Front Vertical Motor Up Control |
| 3 | 3 TN | 285 | Driver Power Seat Horizontal Motor Forward Control |
| 4 | 3 L-BU | 283 | Driver Power Seat Rear Vertical Motor Down Control |
| 5 | 3 D-BU | 287 | Driver Power Seat Front Vertical Motor Down Control |
| 6 | 3 L-GN | 284 | Driver Power Seat Horizontal Motor Rearward Control |
Seat Adjuster Motor Assembly - Driver (without AN3 and without HP2)
Seat Adjuster Motor Assembly - Passenger (AG2 without HP2)
| Connector Part Information Harness Type: Passenger Seat OEM Connector: 7283-6466-40 Service Connector: 19153175 Description: 6-Way F YESC 2.8MM (GY) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: Not Available Release Tool/Test Probe: Not Available |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 3 YE | 288 | Passenger Seat Rear Vertical Motor Up Control |
| 2 | 3 D-GN | 297 | Passenger Seat Front Vertical Motor Up Control |
| 3 | 3 TN | 296 | Passenger Seat Horizontal Motor Forward Control |
| 4 | 3 L-BU | 289 | Passenger Seat Rear Vertical Motor Down Control |
| 5 | 3 D-BU | 298 | Passenger Seat Front Vertical Motor Down Control |
| 6 | 3 L-GN | 290 | Passenger Seat Horizontal Motor Rearward Control |
Seat Adjuster Motor Assembly - Passenger (AG2 without HP2)
Scheme 468
Scheme 468: Seat Adjuster Switch - Driver (AN3)
| Connector Part Information Harness Type: Driver Seat OEM Connector: 15326931 Service Connector: 15306309 Description: 10-Way F GT 280 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 15304711/8 Core/Insulation Crimp: E/A Release Tool/Test Probe: 15315247/J-35616-4A (PU) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.35 D-GN | 1518 | Front Vertical Up Switch Signal |
| B | | | Not Used |
| C | 0.35 L-GN | 1523 | Horizontal Rearward Switch Signal |
| D | 0.35 TN | 1522 | Horizontal Forward Switch Signal |
| E | 0.35 PU/WH | 6205 | 12-Volt Reference |
| F | 0.35 YE | 1519 | Rear Vertical Up Switch Signal |
| G | 0.35 D-GN/WH | 1270 | Recline Rearward Switch Signal |
| H | 0.35 GY/BK | 1269 | Recline Forward Switch Signal |
| J | 0.35 L-BU | 1521 | Rear Vertical Down Switch Signal |
| K | 0.35 D-BU | 1520 | Front Vertical Down Switch Signal |
Seat Adjuster Switch - Driver (AN3)
Scheme 469
Scheme 469: Seat Adjuster Switch - Driver (without AN3)
| Connector Part Information Harness Type: Driver Seat OEM Connector: 15326924 Service Connector: 15306174 Description: 8-Way F GT 280 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: Not Available Release Tool/Test Probe: Not Available |
| Pin | Wire | Circuit | Function |
|---|
| A | 3 D-GN | 286 | Driver Seat Front Vertical Motor Up Control |
| B | 3 BK | 1150 | Ground |
| C | 3 TN | 285 | Driver Seat Horizontal Motor Forward Control |
| D | 3 RD/WH | 5040 | Battery Positive Voltage |
| E | 3 YE | 282 | Driver Seat Rear Vertical Motor Up Control |
| F | 3 L-GN | 284 | Driver Seat Horizontal Motor Rearward Control |
| G | 3 L-BU | 283 | Driver Seat Rear Vertical Motor Down Control |
| H | 3 D-BU | 287 | Driver Seat Front Vertical Motor Down Control |
Seat Adjuster Switch - Driver (without AN3)
Seat Adjuster Switch - Passenger (AG2 with AN3)
| Connector Part Information Harness Type: Passenger Seat OEM Connector: 15326931 Service Connector: 15306309 Description: 10-Way F GT 280 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: Not Available Release Tool/Test Probe: Not Available |
| Pin | Wire | Circuit | Function |
|---|
| A | 3 D-BU | 298 | Passenger Seat Front Vertical Motor Down Control |
| B | 3 BK | 1250 | Ground |
| C | 3 L-GN | 290 | Passenger Seat Horizontal Motor Rearward Control |
| D | 3 TN | 296 | Passenger Seat Horizontal Motor Forward Control |
| E | 0.35 RD/WH | 1440 | Battery Positive Voltage |
| F | 3 L-BU | 289 | Passenger Seat Rear Vertical Motor Down Control |
| G | 3 D-BU | 77 | Passenger Seat Recline Motor Rearward |
| H | 3 D-GN | 76 | Passenger Seat Recline Motor Forward |
| J | 3 YE | 288 | Passenger Seat Rear Vertical Motor Up Control |
| K | 3 D-GN | 297 | Passenger Seat Front Vertical Motor Up Control |
Seat Adjuster Switch - Passenger (AG2 with AN3)
Seat Adjuster Switch - Passenger (AG2 without AN3)
| Connector Part Information Harness Type: Passenger Seat OEM Connector: 15326924 Service Connector: 15306174 Description: 8-Way F GT 280 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: Not Available Release Tool/Test Probe: Not Available |
| Pin | Wire | Circuit | Function |
|---|
| A | 3 D-BU | 298 | Passenger Seat Front Vertical Motor Down Control |
| B | 3 BK | 1250 | Ground |
| C | 3 TN | 296 | Passenger Seat Horizontal Motor Forward Control |
| D | 3 RD/WH | 1440 | Battery Positive Voltage |
| E | 3 L-BU | 289 | Passenger Seat Rear Vertical Motor Down Control |
| F | 3 L-GN | 290 | Passenger Seat Horizontal Motor Rearward Control |
| G | 3 YE | 288 | Passenger Seat Rear Vertical Motor Up Control |
| H | 3 D-GN | 297 | Passenger Seat Front Vertical Motor Up Control |
Seat Adjuster Switch - Passenger (AG2 without AN3)
Scheme 470
Scheme 470: Seat Back Ventilation Heating and Cooling Module - Driver (KB6)
| Connector Part Information Harness Type: Driver Seat OEM Connector: E3575-001 Service Connector: Service by Harness - See Part Catalog Description: 8-Way F 1.5mm Unsealed (BK) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: Not Available Release Tool/Test Probe: Not Available |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 1 BN | 6193 | Driver Seat Back Heated/Cool Ventilation Module Heat Control |
| 2 | 0.35 D-GN | 5918 | Driver Seat Blower Voltage Reference |
| 3 | 3 OG | 6194 | Driver Seat Back Heated/Cool Ventilation Module Cool Control |
| 4 | 0.35 GY | 5912 | Low Reference |
| 5 | 0.35 D-BU | 2425 | Driver Seat Back Temperature Sensor Signal |
| 6 | | | Not Used |
| 7 | 0.35 TN | 7010 | Driver Seat Back Blower Speed Control |
| 8 | 0.35 PK | 2426 | Low Reference |
Seat Back Ventilation Heating and Cooling Module - Driver (KB6)
Seat Back Ventilation Heatng and Cooling Module - Passenger (KB6)
| Connector Part Information Harness Type: Passenger Seat OEM Connector: E3575-001 Service Connector: Service by Harness - See Part Catalog Description: 8-Way F 1.5mm Unsealed (BK) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: Not Available Release Tool/Test Probe: Not Available |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 1 YE | 6197 | Passenger Seat Back Heated/Cool Ventilation Module Heat Control |
| 2 | 0.35 WH | 5194 | Passenger Seat Blower Voltage Reference |
| 3 | 1 D-BU/WH | 6198 | Passenger Seat Back Heated/Cool Ventilation Module Cool Control |
| 4 | 0.35 L-GN | 5916 | Low Reference |
| 5 | 0.35 TN | 2436 | Passenger Seat Back Temperature Sensor Signal |
| 6 | | | Not Used |
| 7 | 0.35 WH/BU | 7011 | Passenger Seat Back Blower Speed Control |
| 8 | 0.35 TN | 2482 | Low Reference |
Seat Back Ventilation Heatng and Cooling Module - Passenger (KB6)
Scheme 471
Scheme 471: Seat Belt Buckle - Driver
| Connector Part Information Harness Type: Driver Seat OEM Connector: 12052833 Service Connector: 12117275 Description: 2-Way M Metri-Pack 150 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12047767/2 Core/Insulation Crimp: E/A Release Tool/Test Probe: 12094429/J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.35 TN/WH | 238 | Driver Seat Belt Switch Signal |
| B | 0.35 PK | 5057 | Low Reference |
Seat Belt Buckle - Driver
Seat Belt Buckle - Passenger X1
| Connector Part Information Harness Type: Passenger Seat OEM Connector: 12052833 Service Connector: 12117275 Description: 2-Way M Metri-Pack 150 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12047767/2 Core/Insulation Crimp: E/A Release Tool/Test Probe: 12094429/J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.35 OG | 1362 | Passenger Seat Belt Switch Signal |
| B | 0.35 PK | 5057 | Low Reference |
Seat Belt Buckle - Passenger X1
Scheme 472
Scheme 472: Seat Belt Buckle - Passenger X2
| Connector Part Information Harness Type: Passenger Seat OEM Connector: 12110293 Service Connector: 12117025 Description: 3-Way F Metri-Pack 150 Series, Sealed (BK) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: Service by Harness - See Part Catalog Release Tool/Test Probe: Service by Harness - See Part Catalog |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.35 D-GN | 5612 | Low Reference |
| B | 0.5 BK/WH | 5613 | Passenger Seat Belt Tension Sensor Voltage Reference |
| C | 0.35 D-GN/WH | 5611 | Passenger Seat Belt Tension Sensor Signal |
Seat Belt Buckle - Passenger X2
Scheme 473
Scheme 473: Seat Belt Pretensioner - Driver
| Connector Part Information Harness Type: Body OEM Connector: 12110505 Service Connector: 15306044 Description: 2-Way F Metri-Pack 150 Series (YE) |
|---|
| Terminal Part Information Terminal/Tray: Service with Pigtail Core/Insulation Crimp: N/A Release Tool/Test Probe: 12094429/J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.5 OG/BK | 3478 | Seat Belt Pretensioner - Left - Low Control |
| B | 0.5 TN/WH | 3477 | Seat Belt Pretensioner - Left - High Control |
Seat Belt Pretensioner - Driver
Seat Belt Pretensioner - Passenger
| Connector Part Information Harness Type: Body OEM Connector: 12110505 Service Connector: 15306044 Description: 2-Way F Metri-Pack 150 Series (YE) |
|---|
| Terminal Part Information Terminal/Tray: Service with Pigtail Core/Insulation Crimp: N/A Release Tool/Test Probe: 12094429/J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.5 OG | 3476 | Seat Belt Pretensioner - Right - Low Control |
| B | 0.5 L-GN | 3475 | Seat Belt Pretensioner - Right - High Control |
Seat Belt Pretensioner - Passenger
Scheme 474
Scheme 474: Seat Climate Control Module X1 (KB6)
| Connector Part Information Harness Type: Passenger Seat OEM Connector: 15326110 Service Connector: 15306171 Description: 12-Way F 280 GT Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: Service by Harness - See Part Catalog Release Tool/Test Probe: Service by Harness - See Part Catalog |
| Pin | Wire | Circuit | Function |
|---|
| A | 1 PK/BK | 6199 | Passenger Seat Cushion Heated/Cool Ventilation Module Heat Control |
| B | 1 BK/WH | 6200 | Passenger Seat Cushion Heated/Cool Ventilation Module Cool Control |
| C | 1 YE | 6197 | Passenger Seat Back Heated/Cool Ventilation Module Heat Control |
| D | 1 D-BU/WH | 6198 | Passenger Seat Back Heated/Cool Ventilation Module Cool Control |
| E | 3 RD/WH | 4740 | Battery Positive Voltage |
| F | | | Not Used |
| G | 1 D-GN | 6195 | Driver Seat Cushion Heated/Cool Ventilation Module Heat Control |
| H | 1 PU | 6196 | Driver Seat Cushion Heated/Cool Ventilation Module Cool Control |
| J | 1 BN | 6193 | Driver Seat Back Heated/Cool Ventilation Module Heat Control |
| K | 1 OG | 6194 | Driver Seat Back Heated/Cool Ventilation Module Cool Control |
| L | | | Not Used |
| M | 3 BK | 1250 | Ground |
Seat Climate Control Module X1 (KB6)
Scheme 475
Scheme 475: Seat Climate Control Module X2 (KB6)
| Connector Part Information Harness Type: Passenger Seat OEM Connector: 15431080 Service Connector: 88988292 Description: 10-Way F Micro-Pack 64 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: Service by Harness - See Part Catalog Release Tool/Test Probe: Service by Harness - See Part Catalog |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.35 PK | 239 | Ignition Voltage |
| 2 | 0.35 GY | 2434 | Passenger Seat Cushion Temperature Sensor Signal |
| 3 | 0.35 PK | 2435 | Low Reference |
| 4 | 0.35 TN | 2436 | Passenger Seat Back Temperature Sensor Signal |
| 5 | 0.35 TN | 2482 | Low Reference |
| 6 | | | Not Used |
| 7 | 0.35 YE/BK | 2079 | Driver Seat Cushion Temperature Sensor Signal |
| 8 | 0.35 YE | 2080 | Low Reference |
| 9 | 0.35 D-BU | 2425 | Driver Seat Back Temperature Sensor Signal |
| 10 | 0.35 PK | 2426 | Low Reference |
Seat Climate Control Module X2 (KB6)
Scheme 476
Scheme 476: Seat Climate Control Module X3 (KB6)
| Connector Part Information Harness Type: Passenger Seat OEM Connector: 15394150 Service Connector: Service by Harness - See Part Catalog Description: 16-Way F (BK) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: Service by Harness - See Part Catalog Release Tool/Test Probe: Service by Harness - See Part Catalog |
| Pin | Wire | Circuit | Function |
|---|
| 1-2 | | | Not Used |
| 3 | 0.35 D-BU | 7012 | Passenger Seat Cushion Blower Speed Control |
| 4 | 0.35 WH/D-BU | 7011 | Passenger Seat Back Blower Speed Control |
| 5 | | | Not Used |
| 6 | 0.35 WH | 5908 | Right Heated/Cooled Seat Mode Signal |
| 7 | 0.35 L-GN | 5916 | Low Reference |
| 8 | 0.35 WH | 5914 | 5-Volt Reference |
| 9 | 0.35 PU | 6433 | Serial Data |
| 10 | | | Not Used |
| 11 | 0.35 OG | 7009 | Driver Seat Cushion Blower Speed Control |
| 12 | 0.35 TN | 7010 | Driver Seat Back Blower Speed Control |
| 13 | | | Not Used |
| 14 | 0.35 D-GN | 5906 | Left Heated/Cooled Seat Mode Signal |
| 15 | 0.35 GY | 5912 | Low Reference |
| 16 | 0.35 D-GN | 5918 | Climate Control Seat Blower Supply Voltage |
Seat Climate Control Module X3 (KB6)
Scheme 477
Scheme 477: Seat Cushion Ventilation Heating and Cooling Module - Driver (KB6)
| Connector Part Information Harness Type: Driver Seat OEM Connector: E3578-003 Service Connector: Service by Harness - See Part Catalog Description: 8-Way M (BK) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: Not Available Release Tool/Test Probe: Not Available |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 1 D-GN | 6195 | Driver Seat Cushion Heated/Cool Ventilation Module Heat Control |
| 2 | 0.35 D-GN | 5918 | Driver Seat Blower Voltage Reference |
| 3 | 1 PU | 6196 | Driver Seat Cushion Heated/Cool Ventilation Module Cool Control |
| 4 | 0.35 GY | 5912 | Low Reference |
| 5 | 0.35 YE/BK | 2079 | Driver Seat Cushion Temperature Sensor Signal |
| 6 | | | Not Used |
| 7 | 0.35 OG | 7009 | Driver Seat Cushion Blower Speed Control |
| 8 | 0.35 YE | 2080 | Low Reference |
Seat Cushion Ventilation Heating and Cooling Module - Driver (KB6)
Seat Cushion Ventilation Heating and Cooling Module - Passenger (KB6)
| Connector Part Information Harness Type: Passenger Seat OEM Connector: E3578-003 Service Connector: Service by Harness - See Part Catalog Description: 8-Way M (BK) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: Service by Harness - See Part Catalog Release Tool/Test Probe: Service by Harness - See Part Catalog |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 1 PK/BK | 6199 | Passenger Seat Cushion Heated/Cool Ventilation Module Heat Control |
| 2 | 0.35 WH | 5914 | Passenger Seat Blower Voltage Reference |
| 3 | 1 BK/WH | 6200 | Passenger Seat Cushion Heated/Cool Ventilation Module Cool Control |
| 4 | 0.35 L-GN | 5916 | Low Reference |
| 5 | 0.35 GY | 2434 | Passenger Seat Cushion Temperature Sensor Signal |
| 6 | | | Not Used |
| 7 | 0.35 D-BU | 7012 | Passenger Seat Cushion Blower Speed Control |
| 8 | 0.35 PK | 2435 | Low Reference |
Seat Cushion Ventilation Heating and Cooling Module - Passenger (KB6)
Scheme 478
Scheme 478: Seat Front Vertical Motor - Driver (HP2)
| Connector Part Information Harness Type: Driver Seat OEM Connector: 968182-1 Service Connector: Service by Harness - See Part Catalog Description: 4-Way F (BK) |
|---|
| Terminal Part Information Pins: 1, 2 Terminal/Tray: 4-965999-1/25 Core/Insulation Crimp: 4/A Release Tool/Test Probe: 12093647/J-35616-4A (PU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 2 D-GN | 286 | Driver Power Seat Front Vertical Motor Up Control |
| 2 | 2 D-BU | 287 | Driver Power Seat Front Vertical Motor Down Control |
| 3-4 | | | Not Used |
Seat Front Vertical Motor - Driver (HP2)
Seat Front Vertical Motor - Passenger (HP2)
| Connector Part Information Harness Type: Passenger Seat OEM Connector: 968182-1 Service Connector: Service by Harness - See Part Catalog Description: 4-Way F (BK) |
|---|
| Terminal Part Information Pins: 1, 2 Terminal/Tray: 4-965999-1/25 Core/Insulation Crimp: 4/A Release Tool/Test Probe: 12093647/J-35616-4A (PU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 2 D-BU | 298 | Front Passenger Seat Front Vertical Motor Up Control |
| 2 | 2 D-GN | 297 | Front Passenger Seat Front Vertical Motor Down Control |
| 3-4 | | | Not Used |
Seat Front Vertical Motor- Passenger (HP2)
Seat Horizontal Motor - Driver (HP2)
| Connector Part Information Harness Type: Driver Seat OEM Connector: 968182-1 Service Connector: Service by Harness - See Part Catalog Description: 4-Way F (BK) |
|---|
| Terminal Part Information Pins: 1, 2 Terminal/Tray: 4-965999-1/25 Core/Insulation Crimp: 4/A Release Tool/Test Probe: 12093647/J-35616-4A (PU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 2 TN | 285 | Driver Power Seat Horizontal Motor Forward Control |
| 2 | 2 L-GN | 284 | Driver Seat Horizontal Motor Rearward Control |
| 3-4 | | | Not Used |
Seat Horizontal Motor - Driver (HP2)
Seat Horizontal Motor - Passenger (HP2)
| Connector Part Information Harness Type: Passenger Seat OEM Connector: 968182-1 Service Connector: Service by Harness - See Part Catalog Description: 4-Way F (BK) |
|---|
| Terminal Part Information Pins: 1, 2 Terminal/Tray: 4-965999-1/25 Core/Insulation Crimp: 4/A Release Tool/Test Probe: 12093647/J-35616-4A (PU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 2 L-GN | 290 | Driver Power Seat Horizontal Motor Rearward Control |
| 2 | 2 TN | 296 | Driver Power Seat Horizontal Motor Forward Control |
| 3-4 | | | Not Used |
Seat Horizontal Motor - Passenger (HP2)
Scheme 479
Scheme 479: Seat Lumbar Horizontal Motor - Driver (AN3)
| Connector Part Information Harness Type: Driver Seat Jumper OEM Connector: 12020556 Service Connector: 12020556 Description: 2-Way F Metri-Pack 280 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12124304/2 Core/Insulation Crimp: A/B Release Tool/Test Probe: 12094430/J-35616-40 (BU) |
| Pin | Wire | Circuit | Function |
|---|
| A | 2 D-BU | 611 | Driver Seat Lumbar Motor Forward Control |
| B | 2 PK | 610 | Driver Seat Lumbar Motor Rearward Control |
Seat Lumbar Horizontal Motor - Driver (AN3)
Seat Lumbar Horizontal Motor - Passenger (AN3)
| Connector Part Information Harness Type: Passenger Seat Jumper OEM Connector: 12020556 Service Connector: 12020556 Description: 2-Way F Metri-Pack 280 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12124304/2 Core/Insulation Crimp: A/B Release Tool/Test Probe: 12094430/J-35616-40 (BU) |
| Pin | Wire | Circuit | Function |
|---|
| A | 2 D-BU | 211 | Passenger Seat Lumbar Motor Forward Control |
| B | 2 WH | 210 | Passenger Seat Lumbar Motor Rearward Control |
Seat Lumbar Horizontal Motor - Passenger (AN3)
Scheme 480
Scheme 480: Seat Lumbar Horizontal Motor Position Sensor - Driver (AN3)
| Connector Part Information Harness Type: Driver Seat Jumper OEM Connector: 50-57-9403 Service Connector: 21019417 Description: 3-Way F SL Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: Not Available Release Tool/Test Probe: Not Available |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.35 TN | 6207 | 5-Volt Reference |
| 2 | 0.35 YE | 1063 | Driver Seat Lumbar Horizontal Position Sensor |
| 3 | 0.35 GY | 6206 | Low Reference |
Seat Lumbar Horizontal Motor Position Sensor - Driver (AN3)
Scheme 481
Scheme 481: Seat Lumbar Switch - Driver (AN3)
| Connector Part Information Harness Type: Driver Seat OEM Connector: 12052854 Service Connector: 88953358 Description: 7-Way F Metri-Pack 280 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12034046/2 Core/Insulation Crimp: E/A Release Tool/Test Probe: 12094430/J-35616-4A (PU) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.35 YE/BK | 1067 | Driver Seat Lumbar Down Switch Signal |
| B | 0.35 D-BU | 1064 | Driver Seat Lumbar Rearward Switch Signal |
| C | 0.35 YE | 1065 | Driver Seat Lumbar Forward Switch Signal |
| D-E | | | Not Used |
| F | 0.35 WH | 1066 | Driver Seat Lumbar Up Switch Signal |
| G | 0.35 PU/WH | 6205 | 12-Volt Reference |
Seat Lumbar Switch - Driver (AN3)
Seat Lumbar Switch - Passenger (AN3)
| Connector Part Information Harness Type: Passenger Seat OEM Connector: 12052854 Service Connector: 88953358 Description: 7-Way F Metri-Pack 280 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: Not Available Release Tool/Test Probe: Not Available |
| Pin | Wire | Circuit | Function |
|---|
| A | 3 OG | 792 | Passenger Seat Lumbar Up Switch Signal |
| B | 3 D-BU | 211 | Passenger Seat Lumbar In Switch Signal |
| C | 3 WH | 210 | Passenger Seat Lumbar Out Switch Signal |
| D | | | Not Used |
| E | 3 BK | 1250 | Ground |
| F | 3 PK | 793 | Passenger Seat Lumbar Down Switch Signal |
| G | 3 RD/WH | 1440 | Battery Positive Voltage |
Seat Lumbar Switch - Passenger (AN3)
Seat Lumbar Vertical Motor - Driver (AN3)
| Connector Part Information Harness Type: Driver Seat Jumper OEM Connector: 12020556 Service Connector: 12020556 Description: 2-Way F Metri-Pack 480 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12124304/2 Core/Insulation Crimp: A/B Release Tool/Test Probe: 12094430/J-35616-40 (BU) |
| Pin | Wire | Circuit | Function |
|---|
| A | 2 TN | 768 | Driver Seat Lumbar Motor Up Control |
| B | 1 PU | 767 | Driver Seat Lumbar Motor Down Control |
Seat Lumbar Vertical Motor - Driver (AN3)
Seat Lumbar Vertical Motor - Passenger (AN3)
| Connector Part Information Harness Type: Passenger Seat Jumper OEM Connector: 12020556 Service Connector: 12020556 Description: 2-Way F Metri-Pack 480 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12124304/2 Core/Insulation Crimp: A/B Release Tool/Test Probe: 12094430/J-35616-40 (BU) |
| Pin | Wire | Circuit | Function |
|---|
| A | 2 PK | 793 | Passenger Seat Lumbar Motor Up Control |
| B | 2 OG | 792 | Passenger Seat Lumbar Motor Down Control |
Seat Lumbar Vertical Motor - Passenger (AN3)
Seat Lumbar Vertical Motor Position Sensor - Driver (AN3)
| Connector Part Information Harness Type: Driver Seat Jumper OEM Connector: 50-57-9403 Service Connector: 21019417 Description: 3-Way F SL Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: Not Available Release Tool/Test Probe: Not Available |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.35 GY | 6206 | Low Reference |
| 2 | 0.35 TN/BK | 1062 | Driver Seat Lumbar Vertical Position Sensor Signal |
| 3 | 0.35 TN | 6207 | 5-Volt Reference |
Seat Lumbar Vertical Motor Position Sensor - Driver (AN3)
Seat Rear Vertical Motor - Driver (HP2)
| Connector Part Information Harness Type: Driver Seat OEM Connector: 968182-1 Service Connector: Service by Harness - See Part Catalog Description: 4-Way F (BK) |
|---|
| Terminal Part Information Pins: 1, 2 Terminal/Tray: 4-965999-1/25 Core/Insulation Crimp: 4/A Release Tool/Test Probe: 12093647/J-35616-4A (PU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 2 L-BU | 283 | Driver Power Seat Rear Vertical Motor Down Control |
| 2 | 2 YE | 282 | Driver Power Seat Rear Vertical Motor Up Control |
| 3-4 | | | Not Used |
Seat Rear Vertical Motor - Driver (HP2)
Seat Rear Vertical Motor - Passenger (HP2)
| Connector Part Information Harness Type: Passenger Seat OEM Connector: 968182-1 Service Connector: Service by Harness - See Part Catalog Description: 4-Way F (BK) |
|---|
| Terminal Part Information Pins: 1, 2 Terminal/Tray: 4-965999-1/25 Core/Insulation Crimp: 4/A Release Tool/Test Probe: 12093647/J-35616-4A (PU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 2 YE | 288 | Front Passenger Power Seat Rear Vertical Motor Down Control |
| 2 | 2 L-BU | 289 | Front Passenger Seat Rear Vertical Motor Up Control |
| 3-4 | | | Not Used |
Seat Rear Vertical Motor - Passenger (HP2)
Scheme 482
Scheme 482: Seat Recline Motor - Driver (AN3)
| Connector Part Information Harness Type: Driver Seat OEM Connector: 12129081 Service Connector: 12129081 Description: 2-Way F Metri-Pack 280 Series, Flexlock (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12110844/4 Core/Insulation Crimp: C/A Release Tool/Test Probe: 15315247/J-35616-4A (PU) |
| Pin | Wire | Circuit | Function |
|---|
| A | 1 L-GN | 276 | Driver Seat Recline Motor Forward Control |
| B | 1 L-BU | 277 | Driver Seat Recline Motor Rearward Control |
Seat Recline Motor - Driver (AN3)
Seat Recline Motor - Passenger (AN3)
| Connector Part Information Harness Type: Passenger Seat OEM Connector: 12129081 Service Connector: 12129081 Description: 2-Way F Metri-Pack 280 Series, Flexlock (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12110844/4 Core/Insulation Crimp: C/A Release Tool/Test Probe: 15315247/J-35616-4A (PU) |
| Pin | Wire | Circuit | Function |
|---|
| A | 3 D-GN | 76 | Passenger Seat Recline Motor Forward Control |
| B | 3 D-BU | 77 | Passenger Seat Recline Motor Rearward Control |
Seat Recline Motor - Passenger (AN3)
Scheme 483
Scheme 483: Seat Recline Position Sensor - Driver (AN3)
| Connector Part Information Harness Type: Driver Seat OEM Connector: 39-01-4030 Service Connector: Service by Harness - See Part Catalog Description: 3-Way F Molex Connector (NA) |
|---|
| Terminal Part Information Terminal/Tray: 39-00-0038/23 Core/Insulation Crimp: K/K Release Tool/Test Probe: J-38125-560/J-35616-12 (BU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.35 GY | 6206 | Low Reference |
| 2 | 0.35 WH/BK | 570 | Driver Seat Recline Motor Position Sensor Signal |
| 3 | 0.35 TN | 6207 | 5-Volt Reference |
Seat Recline Position Sensor - Driver (AN3)
Scheme 484
Scheme 484: Security Indicator Lamp (SPO Alarm)
| Connector Part Information Harness Type: SPO Accessory OEM Connector: 12047662 Service Connector: 12085535 Description: Metri-Pack 150 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12064971/5 Core/Insulation Crimp: E/C Release Tool/Test Probe: 12094429/J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.5 RD/WH | 4540 | Battery Positive Voltage |
| B | 0.5 GY | 728 | Security Indicator Control |
Security Indicator Lamp (SPO Alarm)
Scheme 485
Scheme 485: Serial Data Gateway (SDG) Module X1 (HP2)
| Connector Part Information Harness Type: Instrument Panel OEM Connector: 15489824 Service Connector: 15126711 Description: 20-Way F 0.64 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: SAITS-A03T-M064/14 Core/Insulation Crimp: P/P Release Tool/Test Probe: J-38125-215A/J-35616-64B (L-BU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.5 D-BU | 932 | APM Wake-Up Signal |
| 2 | 0.5 TN | 968 | Wake Up Signal |
| 3-10 | | | Not Used |
| 11 | 0.5 L-BU | 6106 | PTLAN |
| 12 | 0.5 L-BU | 6106 | PTLAN |
| 13 | 0.5 D-BU | 6105 | PTLAN + |
| 14 | 0.5 D-BU | 6105 | PTLAN + |
| 15 | 0.5 TN | 2501 | High Speed GMLAN Serial Data Bus |
| 16 | 0.5 TN | 2501 | High Speed GMLAN Serial Data Bus |
| 17 | 0.5 TN/BK | 2500 | High Speed GMLAN Serial Data Bus + |
| 18 | 0.5 TN/BK | 2500 | High Speed GMLAN Serial Data Bus + |
| 19 | 0.35 D-GN | 5060 | Low Speed GMLAN Serial Data |
| 20 | | | Not Used |
Serial Data Gateway (SDG) Module X1 (HP2)
Scheme 486
Scheme 486: Serial Data Gateway (SDG) Module X2 (HP2)
| Connector Part Information Harness Type: Instrument Panel OEM Connector: 15491304 Service Connector: 15126710 Description: 20-Way F USCAR 0.64 Series (GY) |
|---|
| Terminal Part Information Terminal/Tray: SAITS-A03T-M064/14 Core/Insulation Crimp: P/P Release Tool/Test Probe: J-38125-215A/J-35616-64B (L-BU) |
| Pin | Wire | Circuit | Function |
|---|
| 1-3 | | | Not Used |
| 4 | 0.35 D-BU | 919 | High Voltage Circuit Impact Detection Signal |
| 5-7 | | | Not Used |
| 8 | 0.5 RD/WH | 4240 | Battery Positive Voltage |
| 9-14 | | | Not Used |
| 15 | 0.35 D-BU | 918 | Low Reference |
| 16 | 0.35 L-BU | 5986 | Serial Data Communication Enable |
| 17 | | | Not Used |
| 18 | 0.5 BK | 1050 | Ground |
| 19 | 0.35 D-BU | 5985 | Serial Data Wake-Up Signal |
| 20 | 0.35 PK | 239 | Ignition Voltage |
Serial Data Gateway (SDG) Module X2 (HP2)
Scheme 487
Scheme 487: Shock Absorber Actuator- Left Front (Z55)
| Connector Part Information Harness Type: Chassis OEM Connector: 15305168 Service Connector: 12167117 Description: 2-Way F Metri-Pack 150 Series, Sealed (GY) Suspension Damper Adapter OEM Connector: 15359261 Service Connector: 88953232 Description: 2-Way M Metri-Pack 150 Series, Sealed (GY) |
|---|
| Terminal Part Information Terminal/Tray: 12048074/2 Core/Insulation Crimp: E/1 Release Tool/Test Probe: 12094429/J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.5 L-BU/WH | 1107 | Left Front Damper Control |
| B | 0.5 GY | 1113 | Low Reference |
Shock Absorber Actuator - Left Front (Z55)
Scheme 488
Scheme 489
Scheme 489: Shock Absorber Actuator - Left Rear (Z55)
| Connector Part Information Harness Type: Chassis OEM Connector: 15355009 Service Connector: 15306332 Description: 2-Way F Metri-Pack 150.2 Series, Sealed (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12124075/5 Core/Insulation Crimp: E/C Release Tool/Test Probe: 12180559-1/J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.5 D-BU/WH | 1114 | Left Rear Damper Control |
| B | 0.5 D-GN | 1115 | Low Reference |
Shock Absorber Actuator - Left Rear (Z55)
Shock Absorber Actuator - Right Front (Z55)
| Connector Part Information Harness Type: Chassis OEM Connector: 15305168 Service Connector: 12167117 Description: 2-Way F Metri-Pack 150 Series, Sealed (GY) Suspension Damper Adapter OEM Connector: 15359261 Service Connector: 88953232 Description: 2-Way M Metri-Pack 150 Series, Sealed (GY) |
|---|
| Terminal Part Information Terminal/Tray: 12048074/2 Core/Insulation Crimp: E/1 Release Tool/Test Probe: 12094429/J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.5 L-BU/BK | 1116 | Right Front Damper Control |
| B | 0.5 GY/BK | 1117 | Low Reference |
Shock Absorber Actuator - Right Front (Z55)
Shock Absorber Actuator - Right Rear (Z55)
| Connector Part Information Harness Type: Chassis OEM Connector: 15355009 Service Connector: 15306332 Description: 2-Way F Metri-Pack 150.2 Series, Sealed (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12124075/5 Core/Insulation Crimp: E/C Release Tool/Test Probe: 12180559-1/J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.5 D-BU/BK | 1118 | Right Rear Damper Control |
| B | 0.5 D-GN | 1119 | Low Reference |
Shock Absorber Actuator - Right Rear (Z55)
Scheme 490
Scheme 490: Side Marker Lamp - Left Front (X88 or Z88)
| Connector Part Information Harness Type: Left Headlamp OEM Connector: 7112-534-4WB Service Connector: Service by Harness - See Part Catalog Description: 2-Way F (GY) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: Not Available Release Tool/Test Probe: Not Available |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.8 BN | 2509 | Left Park Lamps Control |
| B | 0.8 BK | 250 | Ground (X88) |
| 1 BK | 1750 | Ground (Z88) |
Side Marker Lamp - Left Front (X88 or Z88)
Scheme 491
Scheme 491: Side Marker Lamp - Left Rear (X88 with E52 or TB7)
| Connector Part Information Harness Type: Left Rear Lamp OEM Connector: 15324946 Service Connector: 19115078 Description: 2-Way F Lamp Socket Base W2 Sealed (BK) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: Not Available Release Tool/Test Probe: Not Available |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.8 BN | 2509 | Left Rear Park Lamps Control |
| 0.8 BN | 2509 | Left Rear Park Lamps Control |
| B | 0.8 BK | 1750 | Ground |
| 0.8 BK | 1750 | Ground |
Side Marker Lamp - Left Rear (X88 with E52 or TB7)
Scheme 492
Scheme 492: Side Marker Lamp - Left Rear (X88 without E52 or TB7)
| Connector Part Information Harness Type: Left Rear Lamp OEM Connector: 12052641 Service Connector: 12102747 Description: 2-Way F Metri-Pack 150 Series Sealed (BK) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: Not Available Release Tool/Test Probe: Not Available |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.8 BN | 2609 | Right Rear Park Lamps Control |
| 0.8 BN | 2609 | Right Rear Park Lamps Control |
| B | 0.8 BK | 1750 | Ground |
| 0.8 BK | 1750 | Ground |
Side Marker Lamp - Left Rear (X88 without E52 or TB7)
Scheme 493
Scheme 493: Side Marker Lamp - Left Rear (Z88)
| Connector Part Information Harness Type: Left Rear Lamp OEM Connector: 16530675 Service Connector: Service by Harness - See Part Catalog Description: 2-Way F Sealed (L-GY) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: Not Available Release Tool/Test Probe: Not Available |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.8 BN | 2509 | Left Rear Park Lamps Control |
| 0.8 BN | 2509 | Left Rear Park Lamps Control |
| B | 0.8 BK | 1750 | Ground |
| 0.8 BK | 1750 | Ground |
Side Marker Lamp - Left Rear (Z88)
Side Marker Lamp - Right Front (X88 or Z88)
| Connector Part Information Harness Type: Right Headlamp OEM Connector: 7112-534-4WB Service Connector: Service by Harness - See Part Catalog Description: 2-Way F (GY) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: Not Available Release Tool/Test Probe: Not Available |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.8 BN | 2609 | Right Park Lamps Control |
| B | 0.8 BK | 250 | Ground (X88) |
| 1 BK | 1750 | Ground (Z88) |
Side Marker Lamp - Right Front (X88 or Z88)
Side Marker Lamp - Right Rear (X88 with E52 or TB7)
| Connector Part Information Harness Type: Right Rear Lamp OEM Connector: 15324946 Service Connector: 19115078 Description: 2-Way F Lamp Socket Base W2 (BK) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: Not Available Release Tool/Test Probe: Not Available |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.8 BN | 2609 | Right Rear Park Lamps Control |
| 0.8 BN | 2609 | Right Rear Park Lamps Control |
| B | 0.8 BK | 1750 | Ground |
| 0.8 BK | 1750 | Ground |
Side Marker Lamp - Right Rear (X88 with E52 or TB7)
Scheme 494
Scheme 494: Side Marker Lamp - Right Rear (X88 without E52 or TB7)
| Connector Part Information Harness Type: Right Rear Lamp OEM Connector: 1012202 Service Connector: Service by Harness - See Part Catalog Description: 2-Way F W2 Socket Sealed (GY) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: Not Available Release Tool/Test Probe: Not Available |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.8 BN | 2609 | Right Rear Park Lamps Control |
| B | 0.8 BK | 1750 | Ground |
Side Marker Lamp - Right Rear (X88 without E52 or TB7)
Side Marker Lamp - Right Rear (Z88)
| Connector Part Information Harness Type: Right Rear Lamp OEM Connector: 16530675 Service Connector: Service by Harness - See Part Catalog Description: 2-Way F Sealed (L-GY) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: Not Available Release Tool/Test Probe: Not Available |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.8 BN | 2509 | Right Rear Park Lamps Control |
| 0.8 BN | 2509 | Right Rear Park Lamps Control |
| B | 0.8 BK | 1750 | Ground |
| 0.8 BK | 1750 | Ground |
Side Marker Lamp - Right Rear (Z88)
Scheme 495
Scheme 495: Side Object Sensor - Left (UFT)
| Connector Part Information Harness Type: Chassis OEM Connector: 13643695 Service Connector: 88988939 Description: 6-Way F 31404 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: SAIT-A03T-M064/14 Core/Insulation Crimp: P/P Release Tool/Test Probe: J-38125-215A/J-35616-64B (L-BU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | | | Not Used |
| 2 | 0.5 RD/WH | 840 | Battery Positive Voltage |
| 3 | 0.5 D-GN | 5060 | Low Speed GMLAN Serial Data |
| 4 | 0.5 D-GN | 5060 | Low Speed GMLAN Serial Data |
| 5 | 0.5 BK | 1350 | Ground |
| 6 | | | Not Used |
Side Object Sensor - Left (UFT)
Side Object Sensor - Right (UFT)
| Connector Part Information Harness Type: Chassis OEM Connector: 13649636 Service Connector: 88988939 Description: 6-Way F 31404 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: SAIT-A03T-M064/14 Core/Insulation Crimp: P/P Release Tool/Test Probe: J-38125-215A/J-35616-64B (L-BU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | | | Not Used |
| 2 | 0.5 RD/WH | 840 | Battery Positive Voltage |
| 3 | | | Not Used |
| 4 | 0.5 D-GN | 5060 | Low Speed GMLAN Serial Data |
| 5 | 0.5 BK | 1350 | Ground |
| 6 | 0.5 BK | 1350 | Ground |
Side Object Sensor - Right (UFT)
Scheme 496
Scheme 496: Speaker - Center I/P (UQS)
| Connector Part Information Harness Type: Instrument Panel OEM Connector: 12052832 Service Connector: 12101825 Description: 2-Way F Metri-Pack 150 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12047767/2 Core/Insulation Crimp: E/A Release Tool/Test Probe: 12094429/J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.8 L-BU | 1960 | Front Center Speaker Output (-) |
| B | 0.8 YE | 1860 | Front Center Speaker Output (+) |
Speaker - Center I/P (UQS)
Scheme 497
Scheme 497: Speaker - Left D-Pillar (Y91 with E52)
| Connector Part Information Harness Type: Body OEM Connector: 12064869 Service Connector: 12117323 Description: 2-Way F Metri-Pack 150 Series (BU) |
|---|
| Terminal Part Information Terminal/Tray: 12047767/2 Core/Insulation Crimp: E/A Release Tool/Test Probe: 12094429/J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.8 WH | 1959 | Left Rear Midrange Speaker Output (-) |
| B | 0.8 TN | 1859 | Left Rear Midrange Speaker Output (+) |
Speaker - Left D-Pillar (Y91 with E52)
Speaker - Left D-Pillar (E52, except Y91)
| Connector Part Information Harness Type: Body OEM Connector: 12052832 Service Connector: 12101825 Description: 2-Way F Metri-Pack 150 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12047767/2 Core/Insulation Crimp: E/A Release Tool/Test Probe: 12094429/J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.8 YE | 116 | Left Rear Speaker Output (-) |
| B | 0.8 BN | 199 | Left Rear Speaker Output (+) |
Speaker - Left D-Pillar (E52, except Y91)
Speaker - Left Front (UQ3)
| Connector Part Information Harness Type: Driver Door OEM Connector: 12052832 Service Connector: 12101825 Description: 2-Way F Metri-Pack 150 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12064971/5 Core/Insulation Crimp: E/C Release Tool/Test Probe: 12094429/J-35616-14 (GN) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.5 GY | 118 | Left Front Speaker Output (-) |
| B | 0.5 TN | 201 | Left Front Speaker Output (+) |
Speaker - Left Front (UQ3)
Speaker - Left Front (UQA or UQS)
| Connector Part Information Harness Type: Driver Door OEM Connector: 12064869 Service Connector: 12117323 Description: 2-Way F Metri-Pack 150 Series (BU) |
|---|
| Terminal Part Information Terminal/Tray: 12047767/2 Core/Insulation Crimp: E/A Release Tool/Test Probe: 12094429/J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.8 GY | 118 | Left Front Speaker Output (-) |
| B | 0.8 TN | 201 | Left Front Speaker Output (+) |
Speaker - Left Front (UQA or UQS)
Scheme 498
Scheme 498: Speaker - Left Front Tweeter
| Connector Part Information Harness Type: Instrument Panel OEM Connector: 12015199 Service Connector: 12101821 Description: 2-Way F Metri-Pack 280 Series (TN) |
|---|
| Terminal Part Information Terminal/Tray: 12066214/2 Core/Insulation Crimp: F/D Release Tool/Test Probe:12094430/J-35616-4A (PU) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.8 D-GY | 118 | Left Front Speaker Output (-) (except Z75 and Z88) |
| 0.8 GY | 118 | Left Front Speaker Output (-) (Z75 or Z88) |
| 0.8 L-GY | 118 | Left Front Speaker Output (-) |
| B | 0.8 TN | 201 | Left Front Speaker Output (+) (except Z75 and Z88) |
| 0.8 TN | 201 | Left Front Speaker Output (+) (Z75 or Z88) |
| 0.8 TN | 201 | Left Front Speaker Output (+) |
Speaker - Left Front Tweeter
Speaker - Left Rear (UQ3)
| Connector Part Information Harness Type: Left Rear Door OEM Connector: 12052832 Service Connector: 12101825 Description: 2-Way F Metri-Pack 150 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12064971/5 Core/Insulation Crimp: E/C Release Tool/Test Probe: 12094429/J-35616-14 (GN) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.5 YE | 116 | Left Rear Speaker Output (-) |
| B | 0.5 BN | 199 | Left Rear Speaker Output (+) |
Speaker - Left Rear (UQ3)
Speaker - Left Rear (UQA or UQS)
| Connector Part Information Harness Type: Left Rear Door OEM Connector: 12064869 Service Connector: 12117323 Description: 2-Way F Metri-Pack 150 Series (BU) |
|---|
| Terminal Part Information Terminal/Tray: 12047767/2 or 15326030/2 Core/Insulation Crimp: E/A Release Tool/Test Probe: 12094429/J-35616-14 (GN) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.8 YE | 116 | Left Rear Speaker Output (-) |
| B | 0.8 BN | 199 | Left Rear Speaker Output (+) |
Speaker - Left Rear (UQA or UQS)
Speaker - Right D-Pillar (Y91 with E52)
| Connector Part Information Harness Type: Body OEM Connector: 12064869 Service Connector: 12117323 Description: 2-Way F Metri-Pack 150 Series (BU) |
|---|
| Terminal Part Information Terminal/Tray: 12047767/2 Core/Insulation Crimp: E/A Release Tool/Test Probe: 12094429/J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.8 OG | 1955 | Right Rear Midrange Speaker Output (-) |
| B | 0.8 TN | 1855 | Right Rear Midrange Speaker Output (+) |
Speaker - Right D-Pillar (Y91 with E52)
Speaker - Right D-Pillar (E52, except Y91)
| Connector Part Information Harness Type: Body OEM Connector: 12052832 Service Connector: 12101825 Description: 2-Way F Metri-Pack 150 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12047767/2 Core/Insulation Crimp: E/A Release Tool/Test Probe: 12094429/J-35616-14 (GN) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.8 L-BU | 115 | Right Rear Speaker Output (-) |
| B | 0.8 D-BU | 46 | Right Rear Speaker Output (+) |
Speaker - Right D-Pillar (E52, except Y91)
Speaker - Right Front (UQ3)
| Connector Part Information Harness Type: Passenger Door OEM Connector: 12052832 Service Connector: 12101825 Description: 2-Way F Metri-Pack 150 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12064971/5 Core/Insulation Crimp: E/C Release Tool/Test Probe: 12094429/J-35616-14 (GN) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.8 D-GN | 117 | Right Front Speaker Output (-) |
| B | 0.8 L-GN | 200 | Right Front Speaker Output (+) |
Speaker - Right Front (UQ3)
Speaker - Right Front (UQS or UQA)
| Connector Part Information Harness Type: Passenger Door OEM Connector: 12064869 Service Connector: 12117323 Description: 2-Way F Metri-Pack 150 Series (BU) |
|---|
| Terminal Part Information Terminal/Tray: 12047767/2 Core/Insulation Crimp: E/A Release Tool/Test Probe: 12094429/J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.8 D-GN | 117 | Right Front Speaker Output (-) |
| B | 0.8 L-GN | 200 | Right Front Speaker Output (+) |
Speaker - Right Front (UQS or UQA)
Speaker - Right Front Tweeter
| Connector Part Information Harness Type: Instrument Panel OEM Connector: 12015199 Service Connector: 12101821 Description: 2-Way F Metri-Pack 280 Series (TN) |
|---|
| Terminal Part Information Terminal/Tray: 12066214/2 Core/Insulation Crimp: F/D Release Tool/Test Probe:12094430/J-35616-4A (PU) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.8 D-GN | 117 | Right Front Speaker Output (-) (except Z75 and Z88) |
| 0.8 D-GN | 117 | Right Front Speaker Output (-) (Z75 or Z88) |
| 0.8 D-GN | 117 | Right Front Speaker Output (-) |
| B | 0.8 L-GN | 200 | Right Front Speaker Output (+) (except Z75 and Z88) |
| 0.8 L-GN | 200 | Right Front Speaker Output (+) (Z75 or Z88) |
| 0.8 L-GN | 200 | Right Front Speaker Output (+) |
Speaker - Right Front Tweeter
Speaker - Right Rear (UQ3)
| Connector Part Information Harness Type: Right Rear Door OEM Connector: 12052832 Service Connector: 12101825 Description: 2-Way F Metri-Pack 150 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12064971/5 Core/Insulation Crimp: E/C Release Tool/Test Probe: 12094429/J-35616-14 (GN) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.5 L-BU | 115 | Right Rear Speaker Output (-) |
| B | 0.5 D-BU | 46 | Right Rear Speaker Output (+) |
Speaker - Right Rear (UQ3)
Speaker - Right Rear (UQA or UQS)
| Connector Part Information Harness Type: Right Rear Door OEM Connector: 12064869 Service Connector: 12117323 Description: 2-Way F Metri-Pack 150 Series (BU) |
|---|
| Terminal Part Information Terminal/Tray: 12047767/2 or 15326030/2 Core/Insulation Crimp: E/A Release Tool/Test Probe: 12094429/J-35616-14 (GN) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.8 L-BU | 115 | Right Rear Speaker Output (-) |
| B | 0.8 D-BU | 46 | Right Rear Speaker Output (+) |
Speaker - Right Rear (UQA or UQS)
Scheme 499
Scheme 499: Speaker - Subwoofer (UQA or UQS)
| Connector Part Information Harness Type: Floor Console OEM Connector: 12064760 Service Connector: 12085208 Description: 4-Way F Metri-Pack 150 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12047767/2 Core/Insulation Crimp: E/A Release Tool/Test Probe: 12094429/J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.8 L-GN/BK | 1794 | Left or Rear Subwoofer Speaker Output (-) |
| B | 0.8 D-BU/WH | 346 | Left or Rear Subwoofer Speaker Output (+) |
| C | 0.8 D-GN | 1795 | Right Subwoofer Speaker Output (+) |
| D | 0.8 L-BU/BK | 315 | Right Subwoofer Speaker Output (-) |
Speaker - Subwoofer (UQA or UQS)
Scheme 500
Scheme 500: Spot Lamp - Left (7X6 or 7X7)
| Connector Part Information Harness Type: Instrument Panel OEM Connector: 12047683 Service Connector: 12101828 Description: 1-Way M Metri-Pack 150 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: Not Available Release Tool/Test Probe: Not Available |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.5 RD/WH | 2640 | Battery Positive Voltage |
Spot Lamp - Left (7X6 or 7X7)
Spot Lamp - Right (7X6)
| Connector Part Information Harness Type: Instrument Panel OEM Connector: 12047683 Service Connector: 12101828 Description: 1-Way M Metri-Pack 150 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: Pending Core/Insulation Crimp: Pending Release Tool/Test Probe: Pending |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.5 RD/WH | 2640 | Battery Positive Voltage |
Starter Motor X1 (except HP2)
| Terminal Part Information Harness Type: Engine Terminal: 02965719 Core/Insulation Crimp: N/A Description: Ring Terminal |
| Pin | Wire | Circuit | Function |
|---|
| B | 3 PU | 6 | Starter Solenoid Crank Voltage |
Starter Motor X1 (except HP2)
Starter Motor X2 (except HP2)
| Terminal Part Information Harness Type: Engine Terminal: 00012720 Core/Insulation Crimp: N/A Description: Ring Terminal |
| Pin | Wire | Circuit | Function |
|---|
| S | 32 RD | 1 | Battery Positive Voltage |
Starter Motor X2 (except HP2)
Scheme 501
Scheme 501: Steering Angle Sensor
| Connector Part Information Harness Type: Steering Column OEM Connector: 12052444 Service Connector: 12101874 Description: 8-Way F Micro-Pack 100 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12146447/3 Core/Insulation Crimp: E/C Release Tool/Test Probe: 12031876-1/J-35616-6 (BN) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.35 GY | 6044 | 5-Volt Reference |
| 2 | 0.35 OG/BK | 6045 | Low Reference |
| 3 | 0.35 YE | 6046 | Steering Angle Sensor Phase A |
| 4 | 0.35 D-BU | 6047 | Steering Angle Sensor Phase B |
| 5 | 0.35 TN | 6048 | Steering Angle Sensor Phase C |
| 6 | 0.35 L-GN | 6043 | Steering Angle Sensor Signal |
| 7-8 | | | Not Used |
Scheme 502
Scheme 502: Steering Wheel/Column Tilt Switch (N48)
| Connector Part Information Harness: Steering Column OEM: 12064759 Service: 12117322 Description: 3-Way M Metri-Pack 150 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: Service by Harness - See Part Catalog Release Tool/Test Probe: Service by Harness - See Part Catalog |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.35 YE | 2097 | Steering Column Tilt Down Signal |
| B | 0.35 PU/WH | 6205 | 12-Volt Reference |
| C | 0.35 GY | 2096 | Steering Column Tilt Up Signal |
Steering Wheel/Column Tilt Switch (N48)
Scheme 503
Scheme 503: Steering Wheel Control Switch - Left (K34 or KA9)
| Connector Part Information Harness Type: Steering Wheel OEM Connector: 15405522 Service Connector: Service by Harness - See Part Catalog Description: 10-Way F Receptacle 0.64 Series (GY) Terminal Part Information Terminal/Tray: 1393364-2/7 Core/Insulation Crimp: K/K Release Tool/Test Probe: 15315247/J-35616-64B (L-BU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.35 PK/BK | 1444 | 12-Volt Reference |
| 2 | | | Not Used |
| 3 | 0.35 GY | 1884 | Cruise Control Switch Signal |
| 4-5 | | | Not Used |
| 6 | 0.35 BN | 6136 | Control |
| 7 | | | Not Used |
| 8 | 0.35 BK | 1050 | Ground |
| 9 | 0.35 D-GN/WH | 7158 | Cruise Control Indicator Dimming Control |
| 10 | | | Not Used |
Steering Wheel Control Switch - Left (K34 or KA9)
Scheme 504
Scheme 504: Steering Wheel Control Switch - Right (UK3)
| Connector Part Information Harness Type: Steering Wheel OEM Connector: 15422579 Service Connector: Service by Harness - See Part Catalog Description: 4-Way F 0.64 Series (BK) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.35 L-GN | 6818 | Steering Wheel Resistor Ladder Signal 1 |
| 2 | 0.35 PK/BK | 1444 | 12-Volt Reference or I/P Dimming Control |
| 3 | 0.35 BN | 6136 | Control |
| 4 | 0.35 BK | 1050 | Ground |
Steering Wheel Control Switch - Right (UK3)
Scheme 505
Scheme 505: Steering Wheel Tilt Actuator (N48)
| Connector Part Information Harness Type: Steering Column OEM Connector: 12045688 Service Connector: 12101827 Description: 8-Way M Metri-Pack 150 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: Service by Harness - See Part Catalog Release Tool/Test Probe: Service by Harness - See Part Catalog |
| Pin | Wire | Circuit | Function |
|---|
| A | 1 BN | 2112 | Tilt Actuator Down |
| B | 1 PK | 2111 | Tilt Actuator Up |
| C | 0.5 OG | 2154 | Tilt Actuator Position Signal |
| D | 0.5 TN | 6207 | 5-Volt Reference |
| E | 0.5 GY | 6206 | Low Reference |
| F-H | | | Not Used |
Steering Wheel Tilt Actuator (N48)
Scheme 506
Scheme 506: Stop Lamp Switch
| Connector Part Information Harness Type: Brake/Clutch OEM Connector: 15466671 Service Connector: 19149301 Description: 4-Way F GT 280 Series (L-GY) |
|---|
| Terminal Part Information Terminal/Tray: 15304711/8 Core/Insulation Crimp: E/A Release Tool/Test Probe: 15315247/J-35616-4A (PU) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.35 L-BU/WH | 6311 | Brake Signal |
| B | 0.35 PK | 239 | Ignition Voltage |
| C | 0.35 OG/WH | 812 | 12-Volt Reference or I/P Dimming Voltage Reference |
| D | 0.35 PU | 7062 | Brake Pedal Switch Normally Closed Contact Signal |
Scheme 507
Scheme 507: Sunroof Control Module (CF5)
| Connector Part Information Harness Type: Sunroof OEM Connector: KET MG 651056 Service Connector: Service by Harness - See Part Catalog Description: 10-Way F 090-II Series (WH) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: Not Available Release Tool/Test Probe: Not Available |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 2 RD/WH | 3140 | Battery Positive Voltage |
| 2 | 2 BK | 1050 | Ground |
| 3 | 0.35 D-GN | 2074 | Sunroof Switch Express Signal |
| 4 | | | Not Used |
| 5 | 0.35 YE | 43 | Ignition Voltage |
| 6 | 0.35 WH | 5429 | Ignition Voltage |
| 7 | 0.35 BN | 100 | Sunroof Switch Open Signal |
| 8 | 0.35 PK | 2075 | Sunroof Switch Close Vent Signal |
| 9 | 0.35 L-BU | 110 | Sunroof Switch Close Switch Signal |
| 10 | 0.35 OG/BK | 144 | Sunroof Switch Open Vent Signal |
Sunroof Control Module (CF5)
Scheme 508
Scheme 508: Sunroof Switch (CF5)
| Connector Part Information Harness Type:Sunroof OEM Connector: 12103492 Service Connector: 89046705 Description: 8-Way F Receptacle 0.64 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 16-02-1110/20 Core/Insulation Crimp: H/H Release Tool/Test Probe: J-38125-213/J-35616-64B (L-BU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.35 D-GN | 2074 | Sunroof Switch Express Signal |
| 2 | 0.35 OG/BK | 144 | Sunroof Switch Open Vent Signal |
| 3 | 0.35 BN/WH | 230 | Instrument Panel Lamp Dimming Control |
| 4 | 0.35 L-BU | 110 | Sunroof Switch Close Signal |
| 5 | 0.35 BK | 1050 | Ground |
| 6 | 0.35 BN | 100 | Sunroof Switch Open Signal |
| 7 | | | Not Used |
| 8 | 0.35 PK | 2075 | Sunroof Switch Close Vent Signal |
Scheme 509
Scheme 509: Sunshade - Left
| Connector Part Information Harness Type: Headliner OEM Connector: 12047663 Service Connector: 12085481 Description: 2-Way M Metri-Pack 150 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12047581/2 Core/Insulation Crimp: E/C Release Tool/Test Probe: 12094429/J-35616-3 (GY) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.35 OG | 6815 | Inadvertent Power Control |
| B | 0.35 BK | 1050 | Ground |
Sunshade - Right
| Connector Part Information Harness Type: Headliner OEM Connector: 12047663 Service Connector: 12085481 Description: 2-Way M Metri-Pack 150 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12047581/2 Core/Insulation Crimp: E/C Release Tool/Test Probe: 12094429/J-35616-3 (GY) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.35 OG | 6815 | Inadvertent Power Control |
| B | 0.35 BK | 1050 | Ground |
Scheme 510
Scheme 510: Suspension Position Sensor - Left Front (Z55)
| Connector Part Information Harness Type: Chassis OEM Connector: 12162280 Service Connector: 12085538 Description: 3-Way F Metri-Pack 150.2 Series, Sealed (GY) |
|---|
| Terminal Part Information Terminal/Tray: 12124075/5 Core/Insulation Crimp: E/C Release Tool/Test Probe: 12180559-1/J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.5 PU/WH | 1205 | 5-Volt Reference |
| B | 0.5 TN/WH | 1207 | Left Front Suspension Position Sensor Signal |
| C | 0.5 L-BU/BK | 1206 | Low Reference |
Suspension Position Sensor - Left Front (Z55)
Suspension Position Sensor - Left Rear (Z55 or G69)
| Connector Part Information Harness Type: Chassis OEM Connector: 12162280 Service Connector: 12085538 Description: 3-Way F Metri-Pack 150.2 Series, Sealed (GY) |
|---|
| Terminal Part Information Terminal/Tray: 12124075/5 Core/Insulation Crimp: E/C Release Tool/Test Probe: 12180559-1/J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.5 OG | 1208 | 5-Volt Reference |
| B | 0.5 L-GN/WH | 1210 | Left Rear Suspension Position Sensor Signal |
| C | 0.5 L-GN/BK | 1209 | Low Reference |
Suspension Position Sensor - Left Rear (Z55 or G69)
Suspension Position Sensor - Right Front (Z55)
| Connector Part Information Harness Type: Chassis OEM Connector: 12162280 Service Connector: 12085538 Description: 3-Way F Metri-Pack 150.2 Series, Sealed (GY) |
|---|
| Terminal Part Information Terminal/Tray: 12124075/5 Core/Insulation Crimp: E/C Release Tool/Test Probe: 12180559-1/J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.5 PU | 1211 | 5-Volt Reference |
| B | 0.5 TN | 1213 | Right Front Suspension Position Sensor Signal |
| C | 0.5 L-BU/BK | 1212 | Low Reference |
Suspension Position Sensor - Right Front (Z55)
Suspension Position Sensor - Right Rear (Z55 or G69)
| Connector Part Information Harness Type: Chassis OEM Connector: 12162280 Service Connector: 12085538 Description: 3-Way F Metri-Pack 150.2 Series, Sealed (GY) |
|---|
| Terminal Part Information Terminal/Tray: 12124075/5 Core/Insulation Crimp: E/C Release Tool/Test Probe: 12180559-1/J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.5 OG/BK | 1214 | Right Rear Suspension Position Sensor Voltage Reference |
| B | 0.5 L-GN/WH | 1216 | Right Rear Suspension Position Sensor Signal |
| C | 0.5 L-GN/BK | 1215 | Low Reference |
Suspension Position Sensor - Right Rear (Z55 or G69)
