VIN LOCATION
The Vehicle Identification Number (VIN) is located on the left side of the dash panel at the base of the windshield. The VIN chart explains the code characters.
SERVICE PARTS IDENTIFICATION LABEL
This label specifies the vehicle's VIN, wheelbase, paint information, and a list of all production options and special equipment. It is located either inside the spare tire cover or inside the trunk lid.
VIN CODE ID EXPLANATION
Numbers preceding the explanations in the legend below refer to the sequence of characters as listed on VIN identification label. See VIN example below.
VIN Code ID Explanation. Scheme 7
SEVERE & NORMAL SERVICE DEFINITIONS
Note. Use the Severe Service schedule if the vehicle to be serviced is operated under ANY (one or more) of these conditions
Service is recommended at mileage intervals based on vehicle operation. Service schedules are based on the following primary operating conditions
Severe Service
- Short Trips (4 Miles Or Less)
- Towing Or Heavily Loaded
- Severe Dust Conditions
- Hot Weather, Stop-And-Go Driving
- Extensive Idling Conditions (Taxi Or Delivery Type Service)
Normal Service
- Driven More Than 10 Miles Daily
- No Severe Service Operating Conditions
Transaxle Service (All Engines)
Change automatic transmission fluid and filter every 15,000 miles.
Scheme 8
SERVICE LABOR TIMES
Note. For 1990 and newer vehicles, labor times are provided, where available, within appropriate SERVICE INTERVAL table in SCHEDULED SERVICES article.
WHEEL & TIRE SPECIFICATIONS
Wheel and tire information can be found on the decal located on the rear of the driver's door or door pillar.
WHEEL TIGHTENING
Wheel lug nuts should be tightened to 100 ft. lbs. (136 N.m).
BATTERY SPECIFICATIONS
| CAUTION | When battery is disconnected, vehicles equipped with computers may lose memory data. When battery power is restored, driveability problems may exist on some vehicles. These vehicles may require a relearn procedure. See COMPUTER RELEARN PROCEDURES article in the GENERAL INFORMATION section. |
SUPPLEMENTAL RESTRAINT SYSTEM (AIR BAG)
Note. See the AIR BAGS article in the ACCESSORIES/SAFETY EQUIPMENT Section.
Modifications or improper maintenance, including incorrect removal and installation of the Supplemental Restraint System (SRS), can adversely affect system performance. DO NOT cover, obstruct or change the steering wheel horn pad in any way, as such action could cause improper function of the system. Use only plain water when cleaning the horn pad. Solvents or cleaners could adversely affect the air bag cover and cause improper deployment of the system.
| WARNING | To avoid injury from accidental air bag deployment, read and carefully follow all warnings and service precautions. See appropriate AIR BAGS article in ACCESSORIES/SAFETY EQUIPMENT. |
Modification to the air bag system component or wiring can adversely affect system performance and possibly cause injury.
| CAUTION | The Diagnostic Energy Reserve Module (DERM) can maintain enough voltage to cause a deployment of the inflator module for up to 10 minutes after the ignition switch is turned off and the battery is disconnected. Many of the service procedures require disconnection of the inflator module to avoid an accidental deployment. |
| CAUTION | Disconnect negative battery cable before servicing any air bag system, steering column or passenger side dash component. After any repair, turn ignition key to the ON position from passenger's side of vehicle in case of accidental air bag inflation |
AIR CONDITIONING SERVICING
| CAUTION | Avoid breathing R-134a refrigerant and PAG lubricant vapors, exposure may irritate eyes, nose and throat. To remove R-134a from system use R-134a recycling equipment that meets SAE J2210 specifications. If accidental system discharge occurs, ventilate work area before resuming service. |
| WARNING | R-134a service equipment or vehicle A/C systems SHOULD NOT be pressure tested or leak tested with compressed air. Some mixtures of air/R134a have shown to be combustible at elevated pressures. These mixtures are dangerous and may cause fire and/or explosions. See AIR CONDITIONING SERVICE article in GENERAL INFORMATION section. |
ANTI-LOCK BRAKE SYSTEM
The anti-lock brake system contains electronic equipment that can be susceptible to interference caused by improperly installed or high output radio transmitting equipment. Since this interference could cause the possible loss of the anti-lock braking capability, such equipment should be installed by qualified professionals.
On models equipped with anti-lock brake systems, ALWAYS observe the following cautions
- DO NOT attempt to bleed hydraulic system without first referring to the appropriate ANTI-LOCK BRAKE SYSTEM article in the BRAKES Section.
- DO NOT mix tire sizes. As long as tires remain close to the original diameter, increasing the width is acceptable. Rolling diameter must be identical for all 4 tires. Some manufacturers recommend tires of the same brand, style and type. Failure to follow this precaution may cause inaccurate wheel speed readings.
- Use ONLY recommended brake fluids. DO NOT use silicone brake fluids in an ABS-equipped vehicle.
REPLACING BLOWN FUSES
Before replacing a blown fuse, remove ignition key, turn off all lights and accessories to avoid damaging the electrical system. Be sure to use fuse with the correct indicated amperage rating. The use of an incorrect amperage rating fuse may result in a dangerous electrical system overload.
BATTERY WARNING
| WARNING | When battery is disconnected, vehicles equipped with computers may lose memory data. When battery power is restored, driveability problems may exist on some vehicles. These vehicles may require a relearn procedure. See COMPUTER RELEARN PROCEDURES article in GENERAL INFORMATION section. |
BRAKE PAD WEAR INDICATOR
| CAUTION | Indicator will cause a squealing or scraping noise, warning that brake pads need replacement. |
CATALYTIC CONVERTER
| CAUTION | To prevent catalytic converter overheating, DO NOT allow engine to idle for more than 20 minutes. |
COOLANT (PROPYLENE-GLYCOL FORMULATIONS)
| CAUTION | To avoid possible damage to vehicle use only ethylene-glycol based coolants with a mixture ratio from 44-68% anti-freeze. DO NOT use 100% anti-freeze as it will cause the formation of cooling system deposits. This results in coolant temperatures of over 300° F (149°C) which can melt plastics. 100% anti-freeze has a freeze point of only -8° F (-22°C). |
| CAUTION | Propylene-Glycol Mixtures has a smaller temperature range than Ethylene-Glycol. The temperature range (freeze-boil) of a 50/50 Anti-Freeze/Water Mix is as follows: Propylene-Glycol -26° F (-32°C) - 257° F (125°C) Ethylene-Glycol -35° F (-37°C) - 263° F (128°C) |
| CAUTION | Propylene-Glycol/Ethylene-Glycol Mixtures can cause the destabilization of various corrosion inhibitors. Also Propylene-Glycol/Ethylene-Glycol has a different specific gravity than Ethylene-Glycol coolant, which will result in inaccurate freeze point calculations. |
ELECTROSTATIC DISCHARGE SENSITIVE (ESD) PARTS
| WARNING | Many solid state electrical components can be damaged by static electricity (ESD). Some will display a warning label, but many will not. Discharge personal static electricity by touching a metal ground point on the vehicle prior to servicing any ESD sensitive component. |
FUEL SYSTEM SERVICE
| WARNING | Relieve fuel system pressure prior to servicing any fuel system component. |
HALOGEN BULBS
| WARNING | Halogen bulbs contain pressurized gas which may explode if overheated. DO NOT touch glass portion of bulb with bare hands. Eye protection should be worn when handling or working around halogen bulbs. |
METHANOL GASOLINE
| CAUTION | Fuel that is more than 5% methanol should not be used in this vehicle. It can corrode metal parts in the fuel system, and damage plastic and rubber parts. Even at 5% methanol or less, solvents and corrosion preventers must be used with this fuel to avoid these problems. |
RADIATOR CAP
| CAUTION | Always disconnect the fan motor when working near the radiator fan. The fan is temperature controlled and could start at any time even when the ignition key is in the OFF position. DO NOT loosen or remove radiator cap when cooling system is hot. |
RADIATOR FAN
| WARNING | Keep hands away from radiator fan. Fan is controlled by a thermostatic switch which may come on or run for up to 15 minutes even after engine is turned off. |
SPARK PLUGS
Note. Allow engine to cool before removing spark plugs from aluminum cylinder heads.
WARRANTY INFORMATION
| CAUTION | Due to the different warranties offered in various regions and the variety of after-market extended warranties available, please refer to the warranty package that came with the vehicle to verify all warranty options. |
BUMPER-TO-BUMPER PLUS LIMITED WARRANTY (CADILLAC)
The complete vehicle (except tires, battery and damage due to owner negligence) is covered for 4 years or 50,000 miles, whichever occurs first. After the first year or 12,000 miles, repairs are subject to a 25 deductible per repair visit (100 per repair visit for 1989 models). Maintenance items are covered up to their first scheduled replacement interval only.
SUPPLEMENTAL COVERAGE (CADILLAC)
Upon expiration of the Bumper to Bumper Plus Limited Warranty, and subject to a 25 deductible per repair visit, repairs of all parts and assemblies on the entire vehicle as manufactured by Cadillac are covered for 7 years or 100,000 miles, whichever occurs first. Routine maintenance items, such as brake linings, spark plugs and filters, and damage due to misuse of vehicle are not covered.
SUPPLEMENTAL INFLATABLE RESTRAINT WARRANTY
Covers supplemental restraint system (if equipped) for 3 years, regardless of mileage.
CORROSION WARRANTY
Any body-sheet metal panel that is perforated due to corrosion is covered for 6 years or 100,000 miles whichever occurs first.
EMISSIONS "DEFECT" WARRANTY/"PERFORMANCE" WARRANTY (EXCEPT CALIFORNIA)
Defect Warranty ensures that vehicle meets applicable EPA regulations and that vehicle's emission control system is free from defects in materials and workmanship for a period of 5 years or 50,000 miles, whichever occurs first.
The Performance Warranty covers all costs of repairing or adjusting any components or parts as needed in order for the vehicle to pass a federally required state or local emissions test.
Other emission control parts related to these components are covered by the Performance Warranty, where applicable. If another part fails due to the failure of one of these components, both parts are covered. See customer's copy of warranty information for specific items covered.
EMISSION "PERFORMANCE" WARRANTY (CALIFORNIA)
If vehicle fails a Smog Check inspection, all necessary repairs and adjustments will be made by manufacturer to ensure that vehicle passes the inspection. Warranty begins at warranty start date and lasts for a period of 3 years or 50,000 miles, whichever occurs first.
EMISSION "DEFECT" WARRANTY (CALIFORNIA)
If any emission-related part on the vehicle is defective, the part will be repaired or replaced by manufacturer. Warranty begins at warranty start date and lasts for a period of 3 years or 50,000 miles, whichever occurs first.
Some emission-related parts are warranted for 7 years or 70,000 miles whichever occurs first, and will be repaired or replaced by manufacturer if found to be defective in material or workmanship. See customer's copy of warranty information for specific items covered.
FUSE PANEL LOCATION
The fuse block is located to the left of the steering column under the dashboard, behind a carpeted cover on the right side of the dash, behind a panel inside the glove box in the trunk compartment or in the engine compartment. For fuse application on models not shown in illustrations, refer to the Fuse Usage Chart on back of fuse panel cover.
Scheme 9
Fuse & Circuit Breaker Identification
- 1 - 10 Amp Electronic Level Control
- 2 - 20 Amp Power Mirrors, Courtesy Lights, Trunk Light, Vanity Mirrors, Reading Lights, Warning Lights, Door Locks
- 3 - 10 Amp Power Antenna
- 4 - 20 Amp Chime Module, Cigarette Lighter
- 5 - 15 Amp Central Power Supply
- 6 - 20 Amp Level Control Compressor
- 7 - 15 Amp Dimming Mirror, Theft Deterrent Module, Chime Module, Brake Switch
- 8 - 3 Amp Cruise Control
- 9 - 7.5 Amp Climate Control, Electronic Level Control, Rear Defogger
- 10 - 3 Amp Body Computer
- 11 - 10 Amp Radio
- 12 - 25 Amp Wipers/Washers
- 13 - 15 Amp Trunk Release
- 14 - 15 Amp Courtesy Light Relay, Accessory Power, High Beam Headlights, Twilight Sentinel
- 15 - 15 Amp Taillights, Parking Lights
- 16 - 20 Amp Stoplights, Hazard Lights, Turn Signal Module
- 17 - 10 Amp Radio
- 18 - 10 Amp Turn Hazard Module, Information Center, Body Computer, Transaxle Position Switch, Door Locks, Fuel Tank Unit
- 19 - 15 Amp Parking Lights, Taillights, Side Marker Lights, Opera Light, License Light, Trunk Light
- 20 - 25 Amp Delco-Bose Sound System
- 21 - 10 Amp (Circuit Breaker) Headlights
- 22 - 20 Amp (Circuit Breaker) Headlights
- 23 - 30 Amp (Circuit Breaker)
- 24 - 30 Amp (Circuit Breaker)
- 25 - 30 Amp (Circuit Breaker) Windows, Sunroof, Trunk Release, Accessories
FUSE PANEL IDENTIFICATION (1990-91 ELDORADO)
The fuse panel is located in the glove box behind the access panel. The interior relay center is under the right side of the instrument panel (remove screws from black hush panel). The underhood relay center is located in the engine compartment on the L/H fender apron.
Scheme 10
- 1 - 10 Amp ELC EXH Electronic Level Control
- 2 - 20 Amp BODY Power Mirrors, Reading/Footwell/Courtesy Lights, Trunk Light, Vanity Mirrors Illumination, Door Courtesy & Warning Lights, Automatic/Power Door Locks, Door Locks Fiber Optic Light
- 3 - 10 Amp ANT Power Antenna
- 4 - 20 Amp CIGAR Chime Module, Cigarette Lighters, Keyless Entry Module
- 5 - 15 Amp CPS Central Power Supply
- 6 - 20 Amp ELC COMP Electronic Level Control Compressor
- 7 - 5 Amp BLOWER FDBK Blower Motor
- 8 - 3 Amp CRUISE Cruise Control, Turn Signal Switch, Power Control Module, Instrument Cluster, No Charge Indicator
- 9 - 7.5 Amp HVAC Climate Control, Electronic Level Control, Rear Defogger, Daytime Running Lights (Canada)
- 10 - 3 Amp BCM Body Computer Module
- 11 - 10 Amp RADIO Radio
- 12 - 25 Amp WIPERS Wipers/Washers
- 13 - 15 Amp DECK LID Keyless Entry Module, Trunk Release
- 14 - 10 Amp BCM PWR Courtesy Light Relay, Retained Accessory Power, HI/LO Beam Headlights, Twilight Sentinel
- 15 - 15 Amp TAIL LPS Twilight Parking Light, Underhood, Side Marker, Front Park/Turn, Opera, Tail & License Lights, Instrument Cluster, Body Computer Module, Chime Module, Turn/Hazard Module
- 16 - 20 Amp STOP/HAZ Stoplights, Turn Signal Chime Module, Turn/Hazard Module, Cruise Brake/Stoplight Switch
- 17 - 10 Amp RDO-PWR Radio, Keyless Entry Module
- 18 - 10 Amp IGN 1-ISO Turn Hazard Module, Information Center, Body Computer Module, DERM, Transaxle Position Switch, Keyless Entry Module, Fuel Gauge
- 19 - 15 Amp SIR Diagnostic Energy Reserve Module (DERM)
- 20 - 30 Amp DEFOG Heated Mirrors, Rear Defogger
- 21 - 10 Amp LO BEAM (Circuit Breaker) Low Beam Headlights, Daytime Running Lights
- 22 - 20 Amp HI BEAM (Circuit Breaker) High Beam Headlights
- 23 - 30 Amp SEATS (Circuit Breaker) Power Door Locks, Power Seats
- 24 - 30 Amp RAP (Circuit Breaker) Retained Accessory Power, Front Door Ajar Switches, Express Down Window Module, Trunk Release, Astro Roof, Power Windows
- 25 - Not Used
Scheme 11
Fuse & Relay Identification
- 1 - 15 Amp IGN-1 Automatic Day/Night Mirror, Power Control Module, Chime Module, Theft Deterrent, Converter Clutch Solenoid
- 2 - 10 Amp FUEL PUMP Powertrain Control Module, Fuel Pump
- 3 - 20 Amp FUEL DOOR Fuel Door Release, Glove Box Light
- 4 - 20 Amp TRUNK LID PULL DN Trunk Lid Pull Down
- 5 - 25 Amp BOSE Delco/Bose Radio System
- 6 - Not Used
- 7 - 10 Amp ABS/CCR/HW Electronic Brake Control Module, Computer Command Ride, Heated Windshield
- 8 - 3 Amp CRANK Diagnostic/Energy Control Module, Body Computer Module
- A - Not Used
- B - Relay High Beam
- C - Relay Fuel Pump
- D - Relay Twilight Crank
- E - Relay Low Beam
- F - Relay Twilight Park Light
- G - Relay Twilight Headlight
- H - Relay Retained Accessory Power 1
- J - Relay Retained Accessory Power 2
- K - Not Used
Scheme 12
- 1 - 15 Amp A/C A/C Compressor Clutch
- 2 - 10 Amp COOL. FAN A/C Compressor Clutch, Body Computer Module, Coolant Fan Relays, Low Refrigerant Switch
- 3 - 10 Amp ECS Emission Control System, Automatic Transaxle, Power Steering Cutout Switch, Power Control Module
- 4 - 20 Amp HORN Horns
- 5 - 7.5 Amp INJ Fuel Injectors 2, 3, 5 & 8
- 6 - 7.5 Amp INJ Fuel Injectors 1, 4, 6 & 7
- 7 - 10 Amp PCM-16N Power Control Module, Pass Key Decoder Module
- 8 - Not Used
- A - Not Used
- B - Relay Cooling Fan
- C - Relay Cooling Fan
- D - Relay Cooling Fan
- E - Not Used
- F - Not Used
- G - Relay Daytime Running Lights (Canada)
- H - Relay Horn
- J - Relay A/C Compressor Clutch
- K - Not Used
