Engine Control System - Service & Adjustment Specifications Cadillac DeVille Concours I final

Specifications 9 illustrations ~363 words

MODEL IDENTIFICATION

Vehicle model is identified by fourth character of Vehicle Identification Number (VIN). VIN is stamped on metal pad on top of left end of instrument panel, near windshield. See MODEL IDENTIFICATION table.

Body Code (1)Model
"C"Park Avenue
"E"Eldorado
"F"Camaro & Firebird
"G"Aurora & Riviera
"H"Bonneville, Eighty Eight, LeSabre & LSS
"J"Cavalier & Sunfire
"K"(2) DeVille & Seville
"M"Metro & Firefly (Canadian)
"N"Alero, Cutlass, Grand Am & Malibu
"S"Prizm
"V"Catera
"W"Century, Grand Prix, Intrigue, Lumina, Monte Carlo & Regal
"Y"Corvette
"Z"Saturn
(1) Vehicle body code is fourth character of VIN. (2) Includes Concours and D'Elegance.
(1)Vehicle body code is fourth character of VIN.
(2)Includes Concours and D'Elegance.

MODEL IDENTIFICATION

INTRODUCTION

Use this article to quickly find specifications related to servicing and on-vehicle adjustments. This is a quick-reference article to use when you are familiar with proper adjustment procedures and only need a specification.

BATTERY CAPACITY

ApplicationCold Crank Amps @ 0°F (-18°C)Reserve Capacity Minutes
1.0L & 1.3L39071
1.8L31090
1.9L52585
2.2L52590
2.4L60090
3.0L525110
3.1L
"N" Body60090
"W" Body600115
3.4L60090
3.5L690115
3.8L
"C" & "G" Bodies880150
"F" Body69090
"H" Body770115
"W" Body
VIN K690115
VIN 1770115
4.0L880150
4.6L
DeVille & Eldorado480150
Seville880150
5.7L
"F" Body52590
"Y" Body60090

BATTERY SPECIFICATIONS

ENGINE OIL CAPACITY

Application(2) Quantity Qts. (L)
1.0L & 1.3L3.5 (3.3)
1.8L3.9 (3.7)
1.9L, 2.2L & 2.4L4.0 (3.8)
3.0L & 3.5L6.0 (5.8)
3.1L, 3.4L & 3.8L4.5 (4.3)
4.0L7.0 (6.6)
4.6L7.5 (7.1)
5.7L
Camaro & Firebird5.5 (5.2)
Corvette6.5 (6.1)
(1) Fluid capacities listed are approximate. Always fill to FULL mark. (2) Includes oil filter capacity.
(1)Fluid capacities listed are approximate. Always fill to FULL mark.
(2)Includes oil filter capacity.

FLUID CAPACITY (CRANKCASE) (1)

COOLING SYSTEM FLUID CAPACITY

Application(2) Quantity Qts. (L)
1.0L4.1 (3.9)
1.3L
Automatic Transmission5.0 (4.7)
Manual Transmission4.9 (4.6)
1.8L
Automatic Transmission6.4 (6.1)
Manual Transmission6.6 (6.2)
1.9L7.0 (6.6)
2.2L10.3 (9.7)
2.4L
"J" Body10.7 (10.1)
"N" Body
Alero & Grand Am11.3 (10.7)
Malibu10.6 (10.0)
3.0L10.6 (10.0)
3.1L
"N" Body13.6 (12.9)
"W" Body
Except Grand Prix11.7 (11.0)
Grand Prix11.0 (10.4)
3.4L12.5 (11.8)
3.5L12.3 (11.7)
3.8L
"C", "G" & "H" Bodies13.0 (12.3)
"F" Body
Automatic Transmission11.4 (10.8)
Manual Transmission11.7 (11.0)
"W" Body
Grand Prix, Regal & Intrigue12.3 (11.7)
Lumina & Monte Carlo11.7 (11.0)
4.0L13.0 (12.3)
4.6L12.5 (11.8)
5.7L
"F" Body
Automatic Transmission11.8 (11.2)
Manual Transmission11.9 (11.3)
"Y" Body
Automatic Transmission12.6 (11.9)
Manual Transmission12.9 (12.2)
(1) Fluid capacities listed are approximate. Always fill to FULL mark. (2) Includes heater.
(1)Fluid capacities listed are approximate. Always fill to FULL mark.
(2)Includes heater.

FLUID CAPACITY (COOLING SYSTEM) (1)

AUTOMATIC TRANSAXLE/TRANSMISSION FLUID CAPACITY

Application(3) Quantity Qts. (L)
1.3L1.6 (1.5)
1.8L
3-Speed2.6 (2.5)
4-Speed4.0 (3.8)
1.9L4.2 (4.0)
2.2L
3T404.0 (3.8)
2.2L, 2.4L & 3.1L
4T40-E6.9 (6.5)
3.0L
With 245 mm Converter7.0 (6.6)
With 260 mm Converter8.0 (7.8)
3.1L
4T60-E7.4 (7.0)
3.4L
4T45-E6.6 (6.5)
3.5L
4T65-E7.4 (7.0)
3.8L
"C", "G", "H" & "W" Bodies7.4 (7.0)
"F" Body5.0 (4.7)
4.0L & 4.6L11.0 (10.4)
5.7L5.0 (4.7)
(1) Fluid capacities listed are approximate. Always fill to FULL mark. (2) Drain and refill capacity only. Does not include torque converter. (3) Dexron-III.
(1)Fluid capacities listed are approximate. Always fill to FULL mark.
(2)Drain and refill capacity only. Does not include torque converter.
(3)Dexron-III.

FLUID CAPACITY (AUTOMATIC TRANSAXLE/TRANSMISSION) (1) (2)

MANUAL TRANSAXLE/TRANSMISSION FLUID CAPACITY

ApplicationQuantity Qts. (L)
1.0L & 1.3L(2) 2.5 (2.4)
1.8L(2) 2.0 (1.9)
1.9L(3) 2.6 (2.5)
2.2L & 2.4L(4) 2.0 (1.9)
3.8L & 5.7L(3) 4.1 (3.9)
(1) Fluid capacities listed are approximate. Always fill to FULL mark. (2) SAE 75W-90 GL-4 gear oil. (3) Dexron-III or Dexron-IIE. (4) Synchromesh Transmission Fluid (GM 12345349).
(1)Fluid capacities listed are approximate. Always fill to FULL mark.
(2)SAE 75W-90 GL-4 gear oil.
(3)Dexron-III or Dexron-IIE.
(4)Synchromesh Transmission Fluid (GM 12345349).

FLUID CAPACITY (MANUAL TRANSAXLE/TRANSMISSION) (1)

SERVICE INTERVALS & SPECIFICATIONS

ComponentMiles
Air Filter30,000
Accessory Drive Belt (1)
1.0L & 1.3L30,000
1.9L18,000
All Others60,000
Engine Coolant
1.0L, 1.3L & 1.8L30,000
1.9L100,000
All Others150,000
Fuel Filter
1.0L, 1.3L, 1.9L & 3.0L100,000
All Others(2)
Oil & Filter
3.0L5000
3.1L, 3.5L, 3.8L & 4.6L7500
All Others3000
Spark Plugs
1.0L, 1.3L, 1.8L & 1.9L30,000
All Others100,000
(1) Inspect and replace if necessary. (2) Periodic replacement is not required. Check and replace as necessary.
(1)Inspect and replace if necessary.
(2)Periodic replacement is not required. Check and replace as necessary.

REPLACEMENT INTERVALS

Application(1) Belt Deflection
1.0L & 1.3L
A/C Compressor & Power Steering Pump.28-.35" (7-9 mm)
Generator/Water Pump
New Belt.20-.28" (5-7 mm)
Used Belt (2).24-.32" (6-8 mm)
All Others(3)
(1) Deflection is with 22 lbs. (10 kg) pressure applied midway on longest belt run. (2) Used belt is a belt in operation for more than 5 minutes. (3) Adjustment of serpentine belt is not necessary. Belt tension is maintained by spring-tensioned idler pulley (some equipped with belt wear indicator).
(1)Deflection is with 22 lbs. (10 kg) pressure applied midway on longest belt run.
(2)Used belt is a belt in operation for more than 5 minutes.
(3)Adjustment of serpentine belt is not necessary. Belt tension is maintained by spring-tensioned idler pulley (some equipped with belt wear indicator).

BELT ADJUSTMENT

ENGINE COMPRESSION

Check engine compression with engine at normal operating temperature, all spark plugs removed and throttle wide open.

ApplicationSpecification
Normal Compression Pressure
1.0L199 psi (14.0 kg/cm 2 )
1.3L192 psi (13.5 kg/cm 2 )
1.8L218 psi (15.3 kg/cm 2 )
1.9L185-205 psi (13.0-14.4 kg/cm 2 )
2.2L, 2.4L, 3.0L, 3.1L, 3.4L, 3.8L, 4.0L, 4.6L & 5.7L(1)
3.5L(2)
Minimum Compression Pressure
1.0L & 1.3L156 psi (11.0 kg/cm 2 )
1.8L145 psi (10.2 kg/cm 2 )
1.9L180 psi (12.7 kg/cm 2 )
2.2L, 2.4L, 3.0L, 3.1L, 3.4L, 3.8L, 4.0L, 4.6L & 5.7L(1)
3.5L(2)
(1) Lowest compression reading should not be less than 70 percent of highest compression reading. No cylinder compression reading should be less than 100 psi (7.0 kg/cm 2 ). (2) Lowest compression reading should not be less than 70 percent of highest compression reading. No cylinder compression reading should be less than 140 psi (9.8 kg/cm 2 ).
(1)Lowest compression reading should not be less than 70 percent of highest compression reading. No cylinder compression reading should be less than 100 psi (7.0 kg/cm 2 ).
(2)Lowest compression reading should not be less than 70 percent of highest compression reading. No cylinder compression reading should be less than 140 psi (9.8 kg/cm 2 ).

COMPRESSION SPECIFICATIONS

VALVE CLEARANCE

ApplicationIn. (mm)
Prizm
Intake(1) .006-.010 (.15-.25)
Exhaust(1) .010-.014 (.25-.35)
All Others(2)
(1) Adjustments are made with engine cold 77°F (25°C). (2) Equipped with hydraulic lifters. Adjustment is not required.
(1)Adjustments are made with engine cold 77°F (25°C).
(2)Equipped with hydraulic lifters. Adjustment is not required.

VALVE CLEARANCE SPECIFICATIONS

HIGH TENSION WIRE RESISTANCE

ApplicationOhms
1.0L3000-6700 Per Foot
1.3L1200-3000 Per Foot
1.8L25,000 Or Less
1.9LLess Than 12,000
2.2LLess Than 30,000
3.0L2000-3000
3.1L5000-8000
3.4L & 3.8L(1)
4.0L & 4.6L15,000 Or Less
(1) Replace wire if resistance exceeds 600 ohms per foot.
(1)Replace wire if resistance exceeds 600 ohms per foot.

HIGH TENSION WIRE RESISTANCE

SPARK PLUGS

ApplicationSpark Plug TypeSpark Plug No.
1.0LACR42XLS
1.3LDensoK20PR-U11
NGKBKR6E-11
1.8LDensoK16TR11
NGKBKR5EKB11
1.9L SOHCAC41-628
1.9L DOHCAC41-627
2.2LAC41-928
2.4LAC41-942
3.0LBoschFLR9LTE
3.1L & 3.4LAC41-940
3.5LGM12556183
3.8LAC41-921
4.0LAC41-950
4.6LAC41-929
5.7LAC41-931

SPARK PLUG TYPE

ApplicationGap In. (mm)Torque Ft. Lbs. (N.m)
1.0L & 1.3L.040-.043 (1.0-1.1)21 (28)
1.8L.043 (1.1)13 (18)
1.9L.040 (1.0)20 (27)
2.2L.050 (1.27)13 (18)
2.4L.050 (1.27)13 (18)
3.0L.035-.043 (.9-1.1)19 (25)
3.1L & 3.8L.060 (1.52)20 (27)
3.4L.060 (1.52)11 (15)
3.5L.050 (1.27)15 (20)
4.0L & 4.6L.050 (1.27)11 (15)
5.7L.060 (1.52)(1)
(1) Tighten to 15 ft. lbs. (20 N.m) when using NEW cylinder head. Tighten to 11 ft. lbs. (15 N.m) for all subsequent installations.
(1)Tighten to 15 ft. lbs. (20 N.m) when using NEW cylinder head. Tighten to 11 ft. lbs. (15 N.m) for all subsequent installations.

SPARK PLUG SPECIFICATIONS

FIRING ORDER

Note. For firing order, refer to appropriate illustration. (Scheme 1)- (Scheme 9).

Scheme 1

Scheme 1: Firing Order (1.0L)

Scheme 2

Scheme 2: Firing Order (1.3L, 1.8L, 1.9L, 2.2L & 2.4L)

Scheme 3

Scheme 3: Firing Order (3.0L)

Scheme 4

Scheme 4: Firing Order (3.1L & 3.4L)

Scheme 5

Scheme 5: Firing Order (3.5L)

Scheme 6

Scheme 6: Firing Order (3.8L - Except "F" Body)

Scheme 7

Scheme 7: Firing Order (3.8L - "F" Body)

Scheme 8

Scheme 8: Firing Order (4.0L & 4.6L)

Scheme 9

Scheme 9: Firing Order (5.7L)

IGNITION TIMING

Note. All models except Metro & Firefly (Canadian) 1.0L are equipped with an electronic computer-controlled ignition system. Timing on these systems is not adjustable. On Metro & Firefly (Canadian) 1.0L, move distributor to adjust ignition timing. Refer to underhood emissions label for specification.

FUEL PUMP

Application(1) KOEO psi (kg/cm 2 )
1.0L23-31 (1.6-2.2)
1.3L39-44 (2.7-3.1)
1.8L44-50 (3.1-3.5)
1.9L40-55 (2.8-3.9)
2.2L, 3.1L, 3.4L & 3.5L41-47 (2.9-3.3)
2.4L
With EGR41-47 (2.9-3.3)
Without EGR52-58 (3.7-4.1)
3.0L40-48 (2.8-3.4)
3.8L, 4.0L & 4.6L48-55 (3.4-3.9)
5.7L55-60 (3.9-4.2)
(1) KOEO is ignition ON and engine OFF.
(1)KOEO is ignition ON and engine OFF.

FUEL PUMP PERFORMANCE

INJECTOR RESISTANCE

Application(1) Ohms
1.0L10.5-11.5
1.3L12-13
1.8L13.4-14.4
1.9L11.5-12.5
2.2L1.9-2.2
2.4L11.4-12.6
3.0L(2)
3.1L, 3.4L, 3.8L, 4.0L, 4.6L & 5.7L11.4-12.6
3.5L11.6-12.8
(1) Injector resistance specification is at 50-95°F (10-35°C). (2) Information is not available from manufacturer.
(1)Injector resistance specification is at 50-95°F (10-35°C).
(2)Information is not available from manufacturer.

INJECTOR RESISTANCE SPECIFICATIONS

IDLE SPEED & MIXTURE

Note. Idle mixture is controlled by Powertrain Control Module (PCM). Idle speed is preset by manufacturer and is not adjustable.

THROTTLE POSITION (TP) SENSOR

Note. TP sensor is not adjustable unless specified otherwise. For further testing procedures, refer to appropriate SELF-DIAGNOSTICS or SYSTEM & COMPONENT TESTING article.

Note. On Corvette, throttle control is electronic with NO mechanical link from engine to accelerator pedal. The PCM and Throttle Actuator Control (TAC) module monitor the position of accelerator pedal based on signals from a nonadjustable Accelerator Pedal Position (APP) sensor. The APP sensor is mounted above accelerator pedal.

Application(1) Volts
1.0L(2)
1.3L0.2-1.0 To 3.0-4.8
1.8L0.3-0.8 To 3.2-4.9
1.9L0.2-0.6 To 4.5-4.9
2.2L & 2.4L0.35-4.65
3.0L0.3-0.9 To 4.0-5.0
3.1L, 3.4L, 3.5L, 3.8L, 4.0L & 4.6L(3)
5.7L
"F" Body(3)
"Y" Body
Sensor No. 1(4)
Sensor No. 2(5)
(1) Voltage range is from idle position to wide open throttle position. (2) Ensure engine is at normal operating temperature. Connect a DVOM (backprobe) between ground and TP sensor signal circuit at PCM. See appropriate wiring diagram in WIRING DIAGRAMS article. Voltage reading should be 0.98-1.02 volts with a .140" (3.5 mm) feeler gauge placed between throttle stop screw and throttle lever. Adjust or replace as necessary. (3) Voltage range is less than one volt at closed throttle to greater than 4 volts at wide open throttle. (4) Voltage range is less than one volt at closed throttle to 3.5 volts at wide open throttle. (5) Voltage range is 3.8 volts at closed throttle to less than one volt at wide open throttle.
(1)Voltage range is from idle position to wide open throttle position.
(2)Ensure engine is at normal operating temperature. Connect a DVOM (backprobe) between ground and TP sensor signal circuit at PCM. See appropriate wiring diagram in WIRING DIAGRAMS article. Voltage reading should be 0.98-1.02 volts with a .140" (3.5 mm) feeler gauge placed between throttle stop screw and throttle lever. Adjust or replace as necessary.
(3)Voltage range is less than one volt at closed throttle to greater than 4 volts at wide open throttle.
(4)Voltage range is less than one volt at closed throttle to 3.5 volts at wide open throttle.
(5)Voltage range is 3.8 volts at closed throttle to less than one volt at wide open throttle.

TP SENSOR ADJUSTMENT VOLTAGE
