Installation Cadillac DeVille Concours

Installation

1. To install, reverse removal procedure. Ensure EBTCM electrical connector tab is locked down. Tighten components to specification. See «TORQUE SPECIFICATIONS»(/cadillac/deville-concours/1994-1998/remont/anti-locktraction-control/#anti-lock-brake-system__torque-specifications) . Refill brake master cylinder, bleed brakes and check for leaks. See «AUTO BLEED PROCEDURE»(/cadillac/deville-concours/1994-1998/remont/anti-locktraction-control/#anti-lock-brake-system__auto-bleed-procedure) under BLEEDING BRAKE SYSTEM.
2. Using Tech 1, select F4: MISC TESTS and then F1: AUTO TEST. Check if any Diagnostic Trouble Code(s) (DTCs) have set, and repair as necessary.

Scheme 63

1. EBTCM is located in the engine compartment, mounted to Brake Pressure Modulator (BPM) valve. Disconnect negative battery cable. Remove air cleaner and radiator cover. Remove EBTCM/BPM assembly-to-bracket nuts. Raise and support EBTCM/BPM assembly with wood block.
2. Disconnect EBTCM electrical connector, ensure connector tab is released. Remove front insulator and insulator mounting bolt. Remove EBTCM-to-BPM bolts. Separate EBTCM from BPM by gently pulling forward. DO NOT pry EBTCM from BPM. If seal is damaged, EBTCM must be replaced. (Scheme 64)

To install, reverse removal procedure. Tighten components to specification. See TORQUE SPECIFICATIONS . Ensure EBTCM electrical connector tab is locked down. Using Tech 1, select F4: MISC TESTS and then F1: AUTO TEST. Check if any DTCs have set, and repair as necessary.

Scheme 64
