Decimal and Metric Equivalents

Fraction (in)Decimal (in)Metric (mm)
1/640.0156250.39688
1/320.031250.79375
3/640.0468751.19062
1/160.06251.5875
5/640.0781251.98437
3/320.093752.38125
7/640.1093752.77812
1/80.1253.175
9/640.1406253.57187
5/320.156253.96875
11/640.1718754.36562
3/160.18754.7625
13/640.2031255.15937
7/320.218755.55625
15/640.2343755.95312
1/40.256.35
17/640.2656256.74687
9/320.281257.14375
19/640.2968757.54062
5/160.31257.9375
21/640.3281258.33437
11/320.343758.73125
23/640.3593759.12812
3/80.3759.525
25/640.3906259.92187
13/320.4062510.31875
27/640.42187510.71562
7/160.437511.1125
29/640.45312511.50937
15/320.4687511.90625
31/640.48437512.30312
1/20.512.7
33/640.51562513.09687
17/320.5312513.49375
35/640.54687513.89062
9/160.562514.2875
37/640.57812514.68437
19/320.5937515.08125
39/640.60937515.47812
5/80.62515.875
41/640.64062516.27187
21/320.6562516.66875
43/640.67187517.06562
11/160.687517.4625
45/640.70312517.85937
23/320.7187518.25625
47/640.73437518.65312
3/40.7519.05
49/640.76562519.44687
25/320.7812519.84375
51/640.79687520.24062
13/160.812520.6375
53/640.82812521.03437
27/320.8437521.43125
55/640.85937521.82812
7/80.87522.225
57/640.89062522.62187
29/320.9062523.01875
59/640.92187523.41562
15/160.937523.8125
61/640.95312524.20937
31/320.9687524.60625
63/640.98437525.00312
11.025.4

Arrows and Symbols

This service manual uses various symbols in order to describe different service operations.

Scheme 1

Scheme 1: Arrows and Symbols
CalloutComponent Name
1Front of Vehicle
2View Detail
2View Detail
3Ambient Air Mixed with Another Gas or Indicate Temperature Change
4Motion or Direction
5View Angle
6Dimension (1:2)
7Ambient/Clean Air Flow or Cool Air Flow
8Lubrication Point - Oil or Fluid
9Task Related
10Sectioning (1:3)
11Gas Other Than Ambient Air or Hot Air Flow
12Lubrication Point - Grease or Jelly
13Multidirectional Arrow

Customer Concern Verification Sheets

The GM Customer Concern Verification Sheets have been designed to improve communications between the service customer and the technician. The more clearly the technician understands the concern and its symptoms, the more likely the concern will be fixed right the first time.

The GM-wide Customer Concern Verification Sheets are available in Dealer World. The Customer Concern Verification Sheets may be printed and reproduced locally.

Dealers

All U.S. Dealers participating in the Common Training Program can enroll through the Common Training System Website at https://www.gmtraining.com. Within the website, there are individual training paths that are designed to assist in planning the training needs for each individual. Technicians should advise their Service Manager of their training needs including course names and course numbers. Dealers who have questions about Common Training should contact the Common Training help desk at 1-888-748-2686. The help desk is available Monday through Friday, 8:00 am-8:00 pm Eastern Standard Time, excluding holidays. For GM Access support, contact the GM Access Help Desk at 1-888-337-1010.

Fleets

GM Fleet customers with GM Warranty In-Shop agreements are able to participate in service technical training through Common Training/GM Service Technical College (STC).

Assistance for all GM fleet customers using GM STC products and services is provided on the Internet via www.gmtraining.com using the "Contact Us" button on the site and/or the Common Training Help Desk at 1-888-748-2687. To order GM STC Training Materials, please contact the GM Training Materials Headquarters at 1-800-393-4831.

Most GM STC course materials have associated charges.

To purchase authentic GM STC Training Materials, contact the GM Training Materials Headquarters at 1-800-393-4831.

Non-GM Dealer Technicians

Technicians training for non-GM dealers is available through ACDelco. This training is for ACDelco customers employed in the automotive or truck service industry.

ACDelco courses are available at all approved GM Training Centers. Availability and schedules can be obtained by calling 1-800-825-5886 or contact us via the web at www.acdelcotechconnect.com and select the training button. Clinics are also offered through ACDelco Warehouse Distributors. Contract your dealer directly for more information.

Scheme 2

Scheme 2: Vehicle, Engine and Transmission ID and VIN Location, Derivative and Usage
PositionDefinitionCharacterDescription
The vehicle identification number (VIN) plate (1) is the legal identifier of the vehicle. The VIN plate is located on the upper left corner of the instrument panel (I/P) and can be seen through the windshield from the outside of the vehicle.
1Country of Origin1USA
2ManufacturerGGeneral Motors
3Make6Cadillac
4 5Carline/SeriesD/ACTS Base
D/BCTS Base with Navigation
D/CCTS Base (AWD)
D/DCTS Base with Navigation (AWD)
D/ECTS Luxury Collection
D/FCTS Luxury Collection with Navigation
D/GCTS Luxury Collection (AWD)
D/HCTS Luxury Collection with Navigation (AWD)
D/JCTS Performance Collection
D/KCTS Performance Collection with Navigation
D/LCTS Performance Collection (AWD)
D/MCTS Performance Collection with Navigation (AWD)
D/NCTS Premium Collection
D/PCTS Premium Collection with Navigation
D/RCTS Premium Collection (AWD)
D/SCTS Premium Collection with Navigation (AWD)
D/TCTS - RHD
D/VCTS - V
6Body Type5Sedan - 4 Door, 4 Window, Notchback
8Station Wagon - 4 Door
7Restraint SystemEActive Manual Belts, Airbags-Driver and Passenger-Front, Front Seat Side, Roof Side, with Occupant Sensor
8Engine CodeGRPO LF1, Gas, 6 Cylinder, 3.0L, SIDI, DOHC, VVT, Aluminum, GM
VRPO LLT, Gas, 6 Cylinder, 3.6L, SIDI, V6, Aluminum, 60 Degrees, 224 KW, GM
PRPO LSA, Gas, 8 Cylinder, 6.2L, SFI, ER, Aluminum, INTR CLR SC, GM
9Check DigitVariesCheck Digit
10Model YearA2010
11Plant Location0Lansing, MI
12-17Plant Sequence Number100001

Vehicle Identification Number (VIN) System

PositionDefinitionCharacterDescription
All engines and transmissions are stamped with a partial vehicle identification number (VIN). This table identifies the different VIN derivative characters and their respective positions.
1Division6Cadillac
2Model YearA2010
3Plant Location0Lansing, MI
4-9Plant Sequence Number100001
A VIN derivative can be used to determine if a vehicle contains the original engine or transmission by matching the VIN derivative positions to their accompanying positions in the complete VIN.

VIN Derivative Characters

VIN Derivative PositionEquivalent VIN Position
13
210
311
4-912-17

VIN Positions

3.0L RPO LF1 and 3.6L RPO LLT Engine ID and VIN Derivative Locations

6.2L RPO LSA Engine ID and VIN Derivative Locations

6L45/6L50/6L80/6L90 RPO MYA, MYB and MYD Transmission ID and VIN Derivative Location

Scheme 3

Scheme 3: Vehicle Certification, Tire Placard, Anti-Theft, and Service Parts ID Label
CalloutDescription
Vehicle Certification Label The vehicle certification label is located on the driver door and displays the following assessments: Gross Vehicle Weight Rating (GVWR) Gross Axle Weight Rating (GAWR), front and rear The gross vehicle weight (GVW) is the weight of the vehicle and everything it carries. The gross vehicle weight must not exceed the GVWR. Include the following items when figuring the GVW: The base vehicle weight (factory weight) The weight of all vehicle accessories The weight of the driver and the passengers The weight of the cargo
1Name of Manufacturer
2Gross Vehicle Weight Rating
3Gross Axle Weight Rating (FRONT, REAR)
4Canadian Safety Mark (w/RPO Z49)
5Certification Statement
6Vehicle Class Type (Pass Car, etc.)
7Vehicle Identification Number
8Date of Manufacture (Mo/Yr)
Tire Placard The tire placard label is located on the driver door and displays the following assessments
9Specified Occupant Seating Positions
10Maximum Vehicle Capacity Weight
11Original Equipment Tire Size
12Tire Pressure, Front, Rear, and Spare (Cold)
Service Parts ID Label The vehicle service parts identification label is located in the rear compartment under the spare tire cover. The label is use to help identify the vehicle original parts and options.
13Vehicle Identification Number
14Engineering Model Number (Vehicle Division, Line and Body Style)
15Interior Trim Level and Decor
16Exterior (Paint Color) WA Number
17Paint Technology
18Special Order Paint Colors and Numbers
19Vehicle Option Content
20Anti-Theft Label The Federal law requires that General Motors label certain body parts on this vehicle with the VIN. The purpose of the law is to reduce the number of motor vehicle thefts by helping in the tracing and recovery of parts from stolen vehicles. Labels are permanently affixed to an interior surface of the part. The label on the replacement part contains the letter R, the manufacturer's logo, and the DOT symbol. The anti-theft label must be covered before any painting, and rustproofing procedures, and uncovered after the procedures. Failure to follow the precautionary steps may result in liability for violation of the Federal Vehicle Theft Prevention Standard and possible suspicion to the owner that the part was stolen.

RPO Code List

The following table provides the description of the regular production option (RPO) codes that are available on the vehicle. The vehicle's RPO list is printed on the Service Parts Identification Label.

RPODescription
01CTrim Color Seat - Light Titanium
01DTrim Color Seat - Light Cashmere
01GTrim Color Seat - Ebony
03FSteering Wheel Color - Figured Sapele
1ADTrim Color Door Panel - Light Titanium
1AETrim Color Door Panel - Light Cashmere
1AHTrim Color Door Panel - Ebony
1SZDiscount Option Package
2A5Molding Door Interior - Figured Sapele
2CKMolding Door Intr Sapele Midnight
3A6Molding I/P - Figured Sapele
3ASMolding I/P - Sapele Midnight
4ACInterior Trim - Cocoa/Light Cashmere
4ALInterior Trim - Ebony/Ebony
4AMInterior Trim - Ebony/Light Titanium
4ARInterior Trim - Ebony/Light Cashmere
53FSteering Wheel Color - Panel, Suede
5AAKnob - Mahogany
5ABKnob - Figured Sapele
5ACKnob - Panel, Suede
5AHKnob - Sapele Midnight
A26Window - European Glazing, All
A45Memory - Seat Adjuster, Mirror, Power, Driver, Personalization
A82Restraint - Head
ACMIdentification Lead Units
AFAInterior Trim Configuration - Number 1
AFBInterior Trim Configuration - Number 2
AFCInterior Trim Configuration - Number 3
AFDInterior Trim Configuration - Number 4
AFEInterior Trim Configuration - Number 5
AFFInterior Trim Configuration - Number 6
AFGInterior Trim Configuration - Number 7
AFHInterior Trim Configuration - Number 8
AH8Adjuster Passenger Seat - Power, 8 Way
AL0Sensor Indicator - Inflatable Restraint, Front Passenger/Child Presence Detector
AL2Control - Seat, Power Lumbar
AM9Seat Rear - Split Back, Folding
AP9Net - Convenience
AQ9Seat - Front Bucket, Luxury
ARHNet - Pet Guard/Luggage
AT8Restraint Provisions - Child, Rear Seat, Rear Facing
ATGLock Control, Entry - Remote Entry, Standard Range
ATHLock Control, Entry - Remote Entry, Extended Range, Passive Entry
AX4Restraint Conversion Seat, Man, European
AXJVehicle Type - Passenger Car
AY0Restraint System - Seat, Inflatable, Driver and Passenger Front, Seat Side, Roof Side
B3THood - Active, Pedestrian Protection
B3VTest Extended Water
B57Ornamentation - Exterior, Deluxe
BAGParts Package - Export
BNKCover - Engine Compartment, Appearance
BTMSwitch - Engine Start, Keyless
BTRIdentification Reconciliation
BTVControl - Remote Engine Start
C3URoof - Sun, Glass. Sliding, Electric, Transparent Glass Fixed
C53Pump - Vacuum, High Altitude
CBGAccessory - Underhood Appearance Package
CE4Washer - Headlamp, High Pressure
CFNRoof - Sun, Glass, Sliding, Electric-Not Installed
CJ2HVAC System - Air Conditioner Front, Auto Temperature Control, Auxiliary Temperature Control
CJ6Country - Ireland
CJ8Country - Bulgaria
CJ9Country - Romania
CK4Country - Greece
CR2Country - Slovenia
CR5Country - Croatia
CR6Country - Poland
CR7Country - Hungary
CS0Country - Czech Republic
CT0Country - Slovakia
CT1Country - Belgium
CT2Country - Austria
CT3Country - Germany
CT4Country - Luxembourg
CT5Country - Netherlands
CT6Country - Italy
CT7Country - Denmark
CT8Country - Portugal
CT9Country - Spain
CU0Country - Ukraine
CU1Country - Norway
CU2Country - Finland
CU3Country - France
CU4Country - Sweden
CU5Country - Switzerland
CU6Country - Taiwan
CU7Country - Kuwait
CU8Country - Saudi Arabia
CU9Country - United Kingdom
CV0Country - Albania
CV3Country - Mexico
CV4Country - Israel
CV5Country - Japan
CV9Country - Turkey
CW1Country - Korea
CW2Country - Gulf Areas (Bahrain, Kuwait, Oman, Qatar, Saudi Arabia, UAE)
CW4Country - Caribbean (Antigua, Antilles, Bahamas, Barbados, Bermuda, Cay, Haiti, Dominican, Jamaica, Nassau, S.M., Trinidad)
CY5Country - Serbia
CY9Country - Estonia
CZ1Country - Central America (Beliz, Costa Rica, El Salvador, Guatemala, Honduras, Nicaragua, Panama)
CZ2Country - China
CZ3Country - Russia
CZ5Country - South Africa
CZ6Country - Kazakhstan
CZ8Country - Macedonia
CZ9Country - Malta
D26Mirror Outside - Left and Right Hand, Remote Control, Electric, Heated, Power Folding
D2ICountry - Lithuania
D30Color Override Approved Color and Trim Combinations (All Products)
D3CCountry - Bosnia-Herzegovina
D3NCountry - Yugoslavia
D3ZCountry - Andorra
D4ACountry - Latvia
DCPProcessing - Directions and Connections Service Package
DD8Mirror Inside Rearview - Light Sensitive
DL7Mirror Outside - Left Hand and Right Hand, Remote Control, Electric, Heated, Power Folding, Color
DR5Mirror Outside - Left Hand and Right Hand, Remote Control, Electric, Heated, Manual Folding, Color
DT4Ashtray - Cigarette Lighter
E6RCountry - Greenland
E7MCountry - Montenegro
EAMTrim Seat - Urethane, Leatherette
EBSTrim Seat - Leather, Nuance Sandstone
ECHTrim Seat - Suede, Perf
EF7Country - United States of America (USA)
EPPIdentification EPA MASS Certification
EXPExport
F55Chassis - Continuously Variable Real Time Damping Magneto Rheological
FBLTrim Door - Vinyl, Wrapped Corinthian
FBYTrim Door - Perforated Suede Insert - Note: For Polypropylene, Use R.P.O. (FCP)
FCNFrequencies - China
FE1Suspension System - Soft Ride
FE2Suspension System - Ride, Handling
FE3Suspension System - Sport
FE4Suspension System - Special Ride and Handling
FE9Certification - Emission, Federal
G80Axle Positraction - Limited Slip
GAMVehicle Government (G.S.A. Sales)
GANPrimary Color - Exterior, Switchblade Silver Met (G)
GBAPrimary Color - Exterior, Black (G)
GBEPrimary Color - Exterior, Crystal Claret Tintcoat (G)
GBNPrimary Color - Exterior, Carbon Flush Met (G)
GBOPrimary Color - Exterior, White Diamond Tricoat (G)
GGXPrimary Color - Exterior, Paragon Bronze Met (G)
GIMPrimary Color - Exterior, Tiara Tan Met (10)
GIPPrimary Color - Exterior, Dark Brahma Jewel Met (G)
GJWPrimary Color - Exterior, Bermuda Blue Met (214M)
GKPPrimary Color - Exterior, Mary Kay Pearl Tri-Coat V (10)
GLHPrimary Color - Exterior, Kevlava Gray Met (417P)
GT4Axle Rear - 3.73 Ratio
GU5Axle Rear - 3.23 Ratio
GU6Axle Rear - 3.42 Ratio
J55Brake System - Heavy Duty
J56Brake System - Power, Front and Rear Disc, Antilock, Front and Rear Wheel, Heavy Duty
J63Brake System - Power, Front and Rear Disc, Antilock, Front and Rear Wheel, Heavy Duty, Front Two Piece Rotors
J77Brake Parking - Electronically Operated
JE5Brake System - Power, Antilock, Front and Rear Wheel
JJAPT Dress Subassembly - Installed (Modular Optimization Method Only)
JJBPT Dress Subassembly - Not Installed (Modular Optimization Method Only)
JJDI/P Subassembly - Not Installed (Modular Optimization Method Only)
JJJSuspension Front - Installed (Modular Optimization Method Only)
JJKSuspension Rear - Installed (Modular Optimization Method Only)
JJLSuspension Front - Not Installed (Modular Optimization Method Only)
JJMSuspension Rear - Not Installed (Modular Optimization Method Only)
JNGShaft - Propeller, Painted
K05Heater Engine - Block
K14Filter - Air, Auto Recirculating
KA1Heater - Seat, Front
KA3Heater Engine - Block, 220V
KB6Heater - Seat, Cooling, Front
KB7Control - Manual Shift, Automatic Transmission
KG4Generator - 150 AMP
KG9Generator - 140 AMP
KJ1Language Label - Chinese/English
KNRCooling System Axle
LALPlant Code - Lansing, MI, USA (Grand River)
LF1Engine - Gas, 6 Cyl, 3.0L, SIDI, DOHC, VVT, Aluminum, GM
LLTEngine - Gas, 6 Cyl, 3.6L, SIDI, V6, Alum, 60 Degrees, GM
LSAEngine - Gas, 8 Cyl, 6.2L, SFI, ER, Alum, INTR CLR SC, GM
MAEMarketing Area Europe
MAJMarketing Area Central America
MAKMarketing Area Russia and Eastern Europe
MAMMarketing Area Middle East
MG9Transmission - Manual 6 Speed, TREMEC, 85mm, 2.66 1st, 0.63 6th
MN6Merchandised Transmission - Manual 6 Speed Provisions
MTFProvisions - Fire Extinguisher Mounting
MV7Transmission - Manual 6 Speed, AISIN, 85mm, 4.1555 1st, 0.7516 6th, O/D
MX0Merchandised Transmission - Auto Provisions, O/D
MX7Merchandised Transmission - Auto Provisions, O/D, AWD (All Wheel Drive)
MYATransmission - Auto 6 Speed, HMD, 6L45
MYBTransmission - Automatic 6 Speed, 6L50
MYDTransmission - Automatic 6 Speed, HMD 6L90
N05Lock Control - Fuel Filler Cap
N08Lock Control - Fuel Filler Door, Remote Control
N30Steering Wheel - Deluxe
N34Steering Wheel - Leather, 3 Spokes
N38Steering Column - Tilt, Telescoping, Power
N93Wheel 17x7.5, Aluminum
NA3Emission System - Japan
NB8Emission Override California System
NB9Emission Override Emissions Override, State-Specific
NC7Emission Override Federal System
NE1Certification - Emission, Geographically Restricted Registration for Vehicles up to 14,000 lbs GVW (Use 2003 Mdl Yr)
NE9Emission System - EEC 09
NP5Steering Wheel - Leather Wrapped
NQUEmission System - Korean, ULEV
NT4Emission System EEC 05
NT7Emission System - Federal, TIER 2
NU1Emission System - California, Lev 2
NU5Emission System California, BIN 4
NUAEmission System California, 150K LEV 2
OANIdentification PPV In Plant
OAPIdentification Pilot
OAQIdentification Pilot - Production
OARIdentification Pre - Production
OATIdentification Launch
OAVIdentification Pre-Launch
OEWIdentification Pre-Selling
P61Wheel - 17.0 X 8.0, Aluminum, Painted, Flanged
P63Wheel - 18.0 X 8.5, Aluminum, Polished, Unflanged
P75Wheel - 18.0 X 8.5, Aluminum, Painted, Unflanged
P80Wheel - 19.0 X 9.0 Front and 19.0 X 9.5 Rear, Aluminum, Painted, Unflanged
PB4Lock Control - Wheel
PJ2Wheel - 19 X 805, Aluminum, Polished
Q0MTire All - 245/45ZR19 98Y BW HWY
Q32Wheel - 19.0 X 9.0 Front and 19.0 X 9.5 Rear, Aluminum, Painted, Unflanged
Q42Tire All - 255/40R19 Front and 285/35R19 Rear
QCHTire All - P235/55R17-98H BW R/PE ST TL AL3
QKETire All - P235/50R18-97V BW TL AL3
QKPTire All - P235/50R17-95S BW R/PE ST TL ALS
R11Vehicle Service Tech Training Center
R1EVehicle General Motors Suppliers Purchase
RYJShade - Cargo Area, Retractable
SGCProcessing Tire and Wheel Spare, Not Desired
T1GVehicle Military Personnel Delivery
T2JOrnamentation - Interior, Export Unique Requirements (AOS Display)
T3ULamp - Front Fog
T4FHeadlamps - High Intensity Discharge
T62Lamp System - Daytime Running - Delete
T65Lamp System - Daytime Running, Export
T79Lamp - Fog, Rear
T90Lamp - Signaling and Marker, Export
T94Headlamps Control - Left Hand Rule of the Road
TB8Headlamps Control - Right Hand Rule of the Road
TFKAlarm - Seat Belt Warning
TR7Headlamps Control - Leveling System, Automatic, Static
TSQLamp Package - Interior, Deluxe
TUMAlarm - Seat Belt Warning, Additional
U03Horn - Noise Regulation
U19Speedometer - Instrument, Kilometers and Miles, Kilometer Odometer
U2JDigital Audio System - S-Band, Not Installed
U2KDigital Audio System - S-Band
U2RInfotainment System - 1
U2SInfotainment System - 2
U2TInfotainment System - 3
U2XInfotainment System - 7
U2YInfotainment System - 8
U30Cluster - Instrument, TACH, Clock
UA2Theft Deterrent System - Export Specific
UA6Theft Deterrent System
UAVInfotainment System - 5.1
UC2Speedometer - Instrument, Kilometers and Miles, Kilometer Odometer, Positive Bias
UD4Alarm - Vehicle Speed, 120 K/H
UD7Sensor Indicator - Rear Parking Assist
UE0Communication System - Vehicle, G.P.S.-Not Installed
UE1Communication System - Vehicle, G.P.S. 1
UG1Opener - Garage Door Universal
UJMTire Pressure Indicator - Manual Learn
UK1Frequencies - Japanese
UL2Frequencies - European
UL8Frequencies - Saudi Arabian
UPFWireless Interface - Short Range, Voice Recorder
UQASpeaker System - Premium Audio Branded with Amplifier
UQSSpeaker System - Premium Audio Branded with Surround Amplifier
UVCCamera - Rear View
V03Cooling System - Extra Capacity
V2STrailer Provisions - Wiring Harness
V3STrailer Provisions - Wiring Harness, 4 Wire
V4CModel Conversion - GMX322, CTS AWD
V4EModel Conversion - GMX322, CTS AWD Uplevel
V4WModel Conversion - GMX320, CTS HFV6
V73Vehicle Statement - USA/Canada
V76Hook - Tow
V78Vehicle Statement - Delete
V83Vehicle Statement - ECE Organization
V86Vehicle Statement - China
V87Vehicle Statement - Gulf States Organization
V8AVehicle Statement - Korea
V8CVehicle Statement - Mexico
V8DVehicle Statement - US
V8EVehicle Statement - Canada
V97Vehicle Preparation - Export
VA7Language Label - French
VAVVEH Personalization All Weather Floor Mats
VB1Label - Shipping, Japan
VBXLanguage Label - Arabic
VC4Label - Price/Fuel Economy, Puerto Rico and Virgin Islands
VC5Label - Shipping, Except US, US Possessions, or Japan
VDQLuggage Carrier - Roof, Double Crossbar
VFMVideo Format - Region 4, NTSC
VG1Protector - Underhood Compound, Corrosion Preventive, Water Based, Clear
VG6Label Information Bumper Impact, 5 MPH, California
VG9Protector - Wax, Exterior Body
VH3Label Information Bumper Impact, 5 MPH, Hawaii
VH5Plate - Vehicle Identification
VH9Envelope - Owner Information Manual
VJ2Label, Export - Headlamp Adjust
VJTPanel Center - Figured Sapele
VK3License Plate Front - Front Mounting Package
VL2Label, Spare - Caution, Compact Spare
VL4License Plate Front - Front Mounting Package, EEC
VL5License Plate - Rear Mounting Package, Export
VL6License Plate Front - Front Mounting Package, Japanese
VLFLicense Plate Front - Front Mounting Package, China
VM3Label Information Consumer, Contains BPR IMP Standard for Front 5 MPH and Rear 5 MPH
VP6Noise Control
VPMModification - Noise Control, Mexico
VQKVEH Personalization Front and Rear Splash Guards
VR5Provisions - Slow Vehicle Warning, Triangle Mounting
VRKVAA/Component REL Roof Trim
VS7Vehicle Non-Saleable
VSGVehicle Personalization - Exterior Appearance
VT7Owners Manual - English Language
VYNVEH Personalization Spoiler, Clear Tail Lamps and CHMSL
VZ3Label - Mercury Disposal Notification
VZLPanel Center - Sapele Midnight
W2ESeat - Front Bucket, Recaro
WXSWiring Provisions - Communications System
XFEFuel Economy Extra Fuel Economy
XL7Frequencies Rating - 315 MHZ, Long Distance
XL8Frequencies Rating - 433 MHZ
XW6Paint Finish Metallic
Y40Sales Package - Cadillac, Luxury Level 001
Y41Sales Package - Cadillac, Luxury Level 002
Y42Sales Package - Cadillac, Performance 001
Y43Sales Package - Cadillac, Performance 002
Y44Sales Package - Cadillac, Seating
YE8Vehicle Test, Engineering
YF5Certification - Emission, California
Z49Country - Canada
Z5XMirror Provisions - Arabic Language
Z5YMirror Provisions - Outside Etched Warning
ZAATire Spare - Compact
ZR6Show Vehicle Zone

Metric Fasteners

This vehicle provides fastener dimensions using the metric system. Most metric fasteners are approximate in diameter to equivalent English fasteners. Make replacements using fasteners of the same nominal diameter, thread pitch, and strength.

A number marking identifies the OE metric fasteners except cross-recess head screws. The number also indicates the strength of the fastener material. A Posidrive® or Type 1A cross-recess identifies a metric cross-recess screw. For best results, use a Type 1A cross-recess screwdriver, or equivalent, in Posidrive® recess head screws.

GM Engineering Standards and North American Industries have adopted a portion of the ISO-defined standard metric fastener sizes. The purpose was to reduce the number of fastener sizes used while retaining the best thread qualities in each thread size. For example, the metric M6.0 X 1 screw, with nearly the same diameter and 25.4 threads per inch replaced the English 1/4-20 and 1/4-28 screws. The thread pitch is midway between the English coarse and fine thread pitches.

Scheme 4

Scheme 4: Metric Fasteners
CalloutComponent Name
1English Bolt, Grade 2 (Strength Class)
2English Bolt, Grade 5 (Strength Class)
3English Bolt, Grade 7 (Strength Class)
4English Bolt, Grade 8 (Strength Class)
5Metric Nut, Strength Class 9
6Metric Bolts, Strength Class Increases as Numbers Increase

The most commonly used metric fastener strength property classes are 9.8 and 10.9. The class identification is embossed on the head of each bolt. The English, inch strength classes range from grade 2 to grade 8. Radial lines are embossed on the head of each bolt in order to identify the strength class. The number of lines on the head of the bolt is 2 lines less than the actual grade. For example, a grade 8 bolt will have 6 radial lines on the bolt head. Some metric nuts are marked with a single digit strength identification number on the nut face.

The correct fasteners are available through GM SPO. Many metric fasteners available in the aftermarket parts channels are designed to metric standards of countries other than the United States, and may exhibit the following

  1. Lower strength
  2. No numbered head marking system
  3. Wrong thread pitch

The metric fasteners on GM products are designed to new, international standards. The following are the common sizes and pitches, except for special applications

  1. M6.0 X 1
  2. M8 X 1.25
  3. M10 X 1.5
  4. M12 X 1.75
  5. M14 X 2.00
  6. M16 X 2.00

Prevailing Torque Fasteners

Prevailing torque fasteners create a thread interface between the fastener and the fastener counterpart in order to prevent the fastener from loosening.

All Metal Prevailing Torque Fasteners

These fasteners accomplish the thread interface by a designed distortion or deformation in the fastener.

Nylon Interface Prevailing Torque Fasteners

These fasteners accomplish the thread interface by the presence of a nylon material on the fastener threads.

Adhesive Coated Fasteners

These fasteners accomplish the thread interface by the presence of a thread-locking compound on the fastener threads. Refer to the appropriate repair procedure in order to determine if the fastener may be reused and the applicable thread-locking compound to apply to the fastener.

Scheme 5

Scheme 5: Adhesive Coated Fasteners
CalloutComponent Name
1Prevailing Torque Nut, Center Lock Type
2Prevailing Torque Nut, Top Lock Type
3Prevailing Torque Nut, Nylon Patch Type
4Prevailing Torque Nut, Nylon Washer Insert Type
5Prevailing Torque Nut, Nylon Insert Type
6Prevailing Torque Bolt, Dry Adhesive Coating Type
7Prevailing Torque Bolt, Thread Profile Deformed Type
8Prevailing Torque Bolt, Nylon Strip Type
9Prevailing Torque Bolt, Out-of-Round Thread Area Type

A prevailing torque fastener may be reused ONLY if

  1. The fastener and the fastener counterpart are clean and not damaged
  2. There is no rust on the fastener
  3. The fastener develops the specified minimum torque against its counterpart prior to the fastener seating
ApplicationSpecification
MetricEnglish
All Metal Prevailing Torque Fasteners
6 mm0.4 N.m4 lb in
8 mm0.8 N.m7 lb in
10 mm1.4 N.m12 lb in
12 mm2.1 N.m19 lb in
14 mm3 N.m27 lb in
16 mm4.2 N.m37 lb in
20 mm7 N.m62 lb in
24 mm10.5 N.m93 lb in
Nylon Interface Prevailing Torque Fasteners
6 mm0.3 N.m3 lb in
8 mm0.6 N.m5 lb in
10 mm1.1 N.m10 lb in
12 mm1.5 N.m13 lb in
14 mm2.3 N.m20 lb in
16 mm3.4 N.m30 lb in
20 mm5.5 N.m49 lb in
24 mm8.5 N.m75 lb in

Metric Prevailing Torque Fastener Minimum Torque Development

ApplicationSpecification
MetricEnglish
All Metal Prevailing Torque Fasteners
1/4 in0.5 N.m4.5 lb in
5/16 in0.8 N.m7.5 lb in
3/8 in1.3 N.m11.5 lb in
7/16 in1.8 N.m16 lb in
1/2 in2.3 N.m20 lb in
9/16 in3.2 N.m28 lb in
5/8 in4 N.m36 lb in
3/4 in7 N.m54 lb in
Nylon Interface Prevailing Torque Fasteners
1/4 in0.3 N.m3 lb in
5/16 in0.6 N.m5 lb in
3/8 in1 N.m9 lb in
7/16 in1.3 N.m12 lb in
1/2 in1.8 N.m16 lb in
9/16 in2.5 N.m22 lb in
5/8 in3.4 N.m30 lb in
3/4 in5 N.m45 lb in

English Prevailing Torque Fastener Minimum Torque Development

Thread Inserts

General Purpose Thread Repair Kits.

These kits are available commercially.

Repair Procedure

  1. Determine the size, the pitch, and the depth of the damaged thread. If necessary, adjust the stop collars on the cutting tool and tap to the required depth.
  2. Drill out the damaged threads. Clean out any chips.
  3. Lubricate the tap with light engine oil. Tap the hole. Clean the threads.
  4. Thread the thread insert onto the mandrel of the installer. Engage the tang of the insert onto the end of the mandrel.
  5. Lubricate the insert with light engine oil, except when installing in aluminum and install the insert.
  6. If the tang of the insert does not break off when backing out the installer, break the tang off with a drift.

Abbreviations and Meanings

AbbreviationMeaning
A
AAmpere(s)
A/CAir Conditioning
A/DAnalog to Digital
A/DFLAir Deflector
A/FAir/Fuel Ratio
A/TAutomatic Transmission/Transaxle
AATAmbient Air Temperature
ABSAntilock Brake System, Absorber
AbvAbove
ACAlternating Current
AccAccess
ACCAutomatic Climate Control, Accumulator
AccelAcceleration
AcclrmAccelerometer
AcclrtmAcceleration
AccumAccumulator
AccyAccessory
ACLAir Cleaner
ACMAir Conditioning Module
AcntAccent
AcsryAccessory
ActActual
ActrActuator
ACTVActivate
ACR4Air Conditioning Refrigerant, Recovery, Recycling, Recharging
ADAutomatic Disconnect, Accommodated Device
AdapAdapter
AdaptAdaptive
AdaptsAdapters
AddtAdditive
ADGAccommodated Device Gateway
AdhesAdhesive
AdjAdjust
AdjrAdjuster
ADLAutomatic Door Lock
ADMINAdministrative
AdsAdsorber
ADSAuxiliary Discriminating Sensor
AdvAdvanced
AFECMAlternative Fuel Engine Control Module
AFMActive Fuel Management, Air Flow Meter
AFOAlternative Fuel Operation
AFRAir Fuel Ratio
AftAfter
AHActive Handling
AHRSAmp-Hours
AIAir Inlet
AIRSecondary Air Injection
AlAluminum
ALCAutomatic Level Control, Automatic Lamp Control
ALDLAssembly Line Diagnostic Link
ALMAutomatic Level Module
ALSAll Seasons - A tire specification
AltAlternative, Altitude
AM/FMAmplitude Modulation/Frequency Modulation
AmbAmbient
AmmAmmeter
AmpAmpere, Amplifier
AmpfAmplifier
AmpsAmperages
AmtArmature
AncAnchor
AntAntenna
APAccelerator Pedal
APCMAccessory Power Control Module
APIAmerican Petroleum Institute
APLQApplique
APMAccelerator Pedal Module, Accessory Power Module
APPAccelerator Pedal Position
APPLApplication
AprApril
APTAdjustable Part Throttle
APUAuxiliary Power Unit
APVAll Purpose Vehicle
ARSAdaptive Receptive System
ASCAnti-Slip Control
AsmAssembly
ASMAccelerator and Servo Control Module, Alarm Siren Module
ASRAcceleration Slip Regulation
ASSTAssist
ATAutomatic Transmission
ATAAutomatic Transmission Actuator
ATCAutomatic Transfer Case, Automatic Temperature Control, Automatic Traction Control, Axle Torque Capacity
ATCHAttach
ATDAllison Transmission Division
ATDCAfter Top Dead Center
ATFAutomatic Transmission Fluid
ATSAir Temperature Sensor
ATVAll Terrain Vehicle
ATSLCAutomatic Transmission Shift Lock Control
AugAugust
AutoAutomatic
AuxAuxiliary
AvgAverage
A4WDAutomatic Four-Wheel Drive
AWDAll-Wheel Drive
AWGAmerican Wire Gauge
B
B/CBellCrank
B/JNTBall Joint
B/UBack Up
B+Battery Positive Voltage
BAIBlower Air Inlet
BALBalance
BALRBalancer
BAROBarometric Pressure
BARRBarrier
BASBelt Alternator System, Brake Apply Sensor
BATTBattery
BBVBrake Booster Vacuum
BCABias Control Assembly
BCMBody Control Module
BDBoard
BECBus Electrical Center
BFCBody Function Controller
BFLBaffle
BHDBulkhead
BGBeige
BHPBrake Horsepower
BIWBody In White
BKBlack
BKGBacking
BKLBuckle
BKLTBooklet
BKTBucket
BLBleed
BLKBlock, Black
BLOBlower
BltsBelts
BLUBlue
BLWBrake Lining Wear
BnBank
BNBrown
BOMBill Of Material
BPBack Pressure
BPCMBattery Pack Control Module
BPMVBrake Pressure Modulator Valve
BPPBrake Pedal Position
BPRBumper
BRBrace
BRDBraid
BRDRBorder
BRGBearing
BRKBrake
BRKRBreaker
BRKTBracket
BRNBrown
BTCMBrake Torque Control Module
BTDCBefore Top Dead Center
BTMBattery Thermal Module
BTSIBrake Transmission Shift Interlock
BTUBritish Thermal Units
BUBlue
C
°CDegrees Celsius
C/BALCounterbalance
C/CASECrankcase
C/LPCourtesy Lamp
C/LTRCigarette Lighter
C/MBRCrossmember
C/OCarryover
C/OVRCrossover
C/PLRCenter Pillar
C/SHFCross Shaft
C/VLVControl Valve
CABTCabinet
CACCharge Air Cooler
CAFECorporate Average Fuel Economy
CalCalibration
CalcCalculated
CALNCalibration
CALRCalibrator
CamCamshaft
CANController (Control) Area Network
CANCCancel
CAPACCapacitor
CARBCarburetor, California Air Resources Board
CARRCarrier
CASECrankshaft Angle Sense Error
CassCassette
CAVCavity
CBLCable
CCCoast Clutch, Climate Control
Cm 3Cubic Centimeters
CCMConvenience Charge Module, Chassis Control Module, Central Control Module
CCOTCycling Clutch Orifice Tube
CCPClimate Control Panel
CCWCounter Clock-Wise
CDCompact Disc
CD/PLYRCompact Disc Player
CDXCompact Disc Changer
CECommutator End
CEABCold Engine Air Bleed
CEMFCounter Electromotive Force
CEXCabin Heat Exchanger
CFMCubic Feet per Minute
CGCenter of Gravity
CHANChannel
CHASChassis
CHEMChemical
CHKCheck
CHMBRChamber
CHRGCharge
CIDCubic Inch Displacement
CIUCharge Interface Unit
CKPCrankshaft Position (Sensor)
CktCircuit
C/LTRCigar Lighter
CLClosed Loop, Clear, Clutch, Clamp
CLAClamp
CLERClearance
CLGCooling
CLKClock
CLNGCleaning
CLNRCleaner
CLPRCaliper
CLRCooler, Color
CLSRClosure
CLSCoolant Level Switch
CLUClutch
CLVClevis
CmCentimeter
CM/SHFCamshaft
CMCCompressor Motor Controller
CmdCommand
CmmdCommanded
CMPCamshaft Position, Component
CMPDCompound
CMPRCompressor
CMPRNCompression
CMPTRComputer
CNCTContact
CNDCTConductor
CNDSRCondenser
CNGCompressed Natural Gas
CNSLConsole
CNSTRCanister
CNTNRContainer
CNTRCounter
COCarbon Monoxide
CO2Carbon Dioxide
COAXCoaxial
COLColumn
COLRCollar
COMBCombination
ComboCombination
COMLCommercial
CommCommunication
COMPCompensator
ComplComplete(d)
COMPTCompartment
CondCondition
ConfigConfiguration
CONNConnector
ConstConstant
CONTControl
CONTAMContamination
CONVConverter
COOLCoolant
CORCornering
CORPCorporation
COTCotter
CPAConnector Position Assurance
CPLGCoupling
CPLYCapillary
CPNCompanion
CPPClutch Pedal Position
CPSChildseat Positioning Sensor, Central Power Supply
CPSLCapsule
CPTCarpet
CPUCentral Processing Unit
CRCross, Cream
CR/SHFCrankshaft
CRKCrank
CRSNCorrosion
CRTCathode Ray Tube
CRTCCathode Ray Tube Controller
CSCharging System
CSFICentral Sequential Fuel Injection
CSTGCasting
CSTRCluster
CTDCoated, Content Theft Deterrent
CTGCoating
CTHCatch
CTHRCatcher
CTLCentral
CTLTCCatalytic
CTNCarton
CTPClosed Throttle Position
CTRCenter
CtrlControl
CTSHFCountershaft
CtsyCourtesy
CTURContour
CURCurrent
CURTCurtain
CUSHCushion
Cu ftCubic Foot/Feet
Cu inCubic Inch/Inches
CVConstant Velocity
CVRCover
CVRSSContinuously Variable Road Sensing Suspension
CVRTDContinuously Variable Real Time Damping
CVTContinuously Variable Transaxle, Continuously Variable Transmission
CWTCounterweight
CYCCycle
CylCylinder(s)
D
DDrive, Dark
D/CVRDust Cover
D/EXHDual Exhaust
D/ODouble Offset
DADash
DABDelayed Accessory Bus
DBDecibels
DBADecibels on A-weighted Scale
DBmDecibel Meter
DCDirect Current, Duty Cycle
DCLRDecelerate
DCMDoor Control Module
DDMDriver Door Module
DDNDeadener
DDSDriver Door (smart) Switch
DEDrive End
DecDecember
DECDigital Electronic Controller
DecelDecelerate
DefDefrost
DEFGDefogger
DefogDefogger
DEFRDefroster
DegDegrees
Deg CDegrees Celsius
DEHYDRDehydrator
DelDelivered
DELDelete
DEPRDepression
DERMDiagnostic Energy Reserve Module
DesDesired
DESData Encryption Standard
DescDescription
DFCODeceleration Fuel Cut-Off
DFLDeflector
DIDistributor Ignition
DiagDiagnostic
DIAGDiagonal
DIAGNDiaphragm
DiaDiameter
DICDriver Information Center
DiffDifferential
DigDigit
DIMDash Integration Module, Dimension
DIMRDimmer
DIRDirect
DisDisable
DISDisplay
DISCHDischarge
DiscrimDiscriminate
DISCRMDiscriminating
DispDisplay
DISPLDisplacement
DISPRDispenser
DISTDistance
DISTRDistributor
DIVDivider
DKDark
DLCData Link Connector, Diamond Like Carbon, Diamond Like Coating
DLC (S/P)Data Link Controller (Serial / Parallel)
DLVYDelivery
DMDome
DMCMDrive Motor Control Module
DMGDamage
DMMDigital Multi-meter
DMSDSDrive Motor Speed and Direction Sensor
DMUDrive Motor Unit
DNDown
DNRDolby Noise Reduction
DNSHFTDownshift
DOCDocument
DOHCDual Overhead Camshafts
DolDolby
DPMDriver Position Module
DPNRDampener
DrDoor
DRLDaytime Running Lights
DRNDrain
DRPDynamic Rear Proportion
DRVNDriven
DrvrDriver
DSCCDistance Sensing Cruise Control
DSCMDrivers Seat Control Module
DSGNDesign
DSLDiesel
DSMDriver Seat Module
DSPDigital Signal Process
DTCDiagnostic Trouble Code
DTNTDetent
DTRNTDeterrent
DVDDigital Versatile Disc
DVTRDiverter
DWGDrawing
DwnDown
E
E&CEntertainment & Comfort
E/GATEEnd Gate
E/MEnglish/Metric
EAEach
EBCElectronic Brake Control
EBCMElectronic Brake Control Module
EBMElectronic Brake Module
EBTCMElectronic Brake and Traction Control Module
ECElectrical Center, Engine Control
ECCElectronic Climate Control
ECIExtended Compressor at Idle
ECLEngine Coolant Level
ECMEngine Control Module, Electronic Control Module
EconEconomy
ECSEmission Control System
ECTEngine Coolant Temperature
ECUElectronic Control Unit
EEPROMElectrically Erasable Programmable Read Only Memory
EEVIREvaporator Equalized Values in Receiver
EFEEarly Fuel Evaporation
EFIElectronic Fuel Injection
EGRExhaust Gas Recirculation
EHAElecto Hydrostatic Actuator
EHCUElectric Hydraulic Control Unit
EGR TVVExhaust Gas Recirculation Thermal Vacuum Valve
EHPSElectrohydraulic Power Steering
EIElectronic Ignition
EJCTREjector
ELElbow
ELAPElapsed
ELASElastic
ELBEmblem
ELCElectronic Level Control
ElecElectric
ELECTElectrode
ELEKElectronic
EMEREmergency
EMFElectromotive Force
EMIElectromagnetic Interference
EMISEmission
ENEvaporative Canister
ENGEngine
ENGMTEngagement
ENGYEnergy
ENGZREnergizer
ENVEnvelope
EOPEngine Oil Pressure
EOSExhaust Oxygen Sensor
EOTEngine Oil Temperature
EPAEnvironmental Protection Agency
EPRExhaust Pressure Regulator
EPROMErasable Programmable Read Only Memory
EPSElectric Power Steering
EQEqualizer
EQLZREqualizer
EQUIPEquipped
ESBExpansion Spring Brake
ESCElectronic Suspension Control
ESCUTEscutcheon
ESDElectrostatic Discharge
ESMElectronic Steering Module
ESNElectronic Serial Number
ESOEngine Shut Off
EstEstimated
ETCElectronic Throttle Control, Electronic Temperature Control, Electronic Timing Control
ETCCElectronic Touch Climate Control
ETRElectronically Tuned Receiver (Radio)
ETSEnhanced Traction System, Enhanced Traction System
EVElectric Vehicle
EvapEvaporator
EVAPEvaporative Emission
EVOElectronic Variable Orifice
EVPREvaporator
EXExhaust
EXCHExchanger
EXHExhaust
EXPDGExpanding
EXPNExpansion
ExtExtended
EXTExternal
EXTNExtension
EXTRExterior
EYLTEyelet
F
°FDegrees Fahrenheit
FFahrenheit
F/AXLFront Axle
F/CMPTFront Compartment
F/DFront of Dash
F/ENDFront End
F/FDRFront Fender
F/FLRFront Floor
F/GAFuel Gauge
F/IDLFuel Idle
F/INJNFuel Injection
F/INJRFuel Injector
F/PMPFuel Pump
F/RSTFoot Rest
F/SEATFront Seat
F/TNKFuel Tank
F/TOPFolding Top
F4WDFull-time Four Wheel Drive
FACFacing
FACTFactor
FCFan Control
FdbkFeedback
FebFebruary
FDCFuel Data Center
FEDFederal All United States except California
FEDSFuel Enable Data Stream
FEICFuel Economy Integrated Counter
FETField Effect Transistor
FEXFront End heat exchanger
FFFlexible Fuel
FFHFuel-Fired Heater
FFVFlexible Fuel Vehicle
FIFuel Injection
FICMFuel Injector Control Module
FILFiller
FILAFilament
FiltFilter
FINFinancial, Finish
FLFront Left
FLDGFolding
FLEXFlexible
FLGFlange
FLMBTYFlammability
FlrFloor
FLSHRFlasher
FLTRFilter
FLYWHLFlywheel
FMFrequency Modulation
FMVSSFederal U.S. Motor Vehicle Safety Standards
FNAFunctional Name Address
FNMFunctional Name Modifier
FORGForging
FPFuel Pump
FRFront Right
FreqFrequency
FRICTFriction
FRMFrame
FRM/UFrame Unit
FrntFront
FRPFuel Rail Pressure
FRTFront
FSCMFuel System Control Module
FtFoot/Feet
FTFuel Trim
FTGFitting
Ft-lbFoot-Pounds
FTPFuel Tank Pressure
FVFront View
FwdForward
F4WDFull Time Four Wheel Drive
4WALFour Wheel Antilock
4WDFour Wheel Drive
FWFlat Wire
FWDFront Wheel Drive, Forward
FWSFront Wheel Spoiler
G
GGrams, Gravitational Acceleration
G/MLDGGarnish Molding
G/NUTGearnut
GAGauge
GALGallery
GalGallon
GARNGarnish
GasGasoline
GCWGross Combination Weight
GDGold
GDEGuide
GenGenerator
GLGear Lubricant
GLZGlaze
GMGeneral Motors
GM SPOGeneral Motors Service Parts Operations
GNGreen
GndGround
GOVGovernor
GOVTGovernment
GPDSGlobal Product Description System
GPMGallons Per Minute
GPSGlobal Positioning System
GRGear
GRLGrille
GRNGreen
GROMGrommet
GRPGroup
GRVGroove
GRVDGrooved
GRYGray
GSGarage Shift, Gold Stripe
GTRGutter
GUSSGusset
GVARGross Vehicle Axle Rating
GVDPGlobal Vehicle Development Process
GVLGravel
GVWGross Vehicle Weight
GVWRGross Vehicle Weight Rating (at ground)
GYGray
H
HHydrogen
H/CHigh Compression
H/PLRHinge Pillar
H/PRFHigh Performance
H/RSTHead Restraint
H/SHLDHeat Shield
H/WHardware
H2OWater
HARNHarness
HCHydrocarbons
HCMHeating Control Module, HVAC Control Module
HCPHybrid Control Processor
HDHeavy Duty, Head
HDCHeavy Duty Cooling
HDLHandle
HDLNGHeadlining
HDLPHeadlamp
HDRHeader
HDVHeavy Duty Vehicle
HDWHardware
HEHinge
HEVHybrid Electric Vehicle
HexHexagon, Hexadecimal
HgMercury
HiHigh
Hi AltHigh Altitude
HIDHigh Intensity Discharge (headlamps)
HistHistory
HLDRHolder
HNGRHanger
HO2SHeated Oxygen Sensor
HOLDNHold Down
HorizHorizontal
HPHorsepower
HPLHigh Pressure Liquid
HPMHybrid Power Module
HPSHigh Performance System
HPVHigh Pressure Vapor
HPVSHeat Pump Ventilation System
HrHour
HrdwHardware
HrsHours
HSGHousing
HTHeat
HTCMHVAC Thermal Control Module
HTDHeated
HtrHeater
HUDHead Up Display
HVHigh Voltage, Hybrid Vehicle
HVACHeater Ventilation Air Conditioning
HVACMHeater Vent Air Conditioning Module
HVILHigh Voltage Interlock Loop
HVMHeater Vent Module
HVYHeavy
HWHeated Windshield
HWYHighway
HYDHydraulic
HzHertz
I
I/MInspection & Maintenance
I/OIn/Out, Input/Output
I/PInstrument Panel
I/PECInstrument Panel Electrical Center
I/SInside
IAIntake Air
IACIdle Air Control
IATIntake Air Temperature
ICIntegrated Circuit, Ignition Control
ICCSIntegrated Chassis Control System
ICDXIntegrated Compact Disc Changer
ICMIgnition Control Module
ICSIntegrated Chassis System
IDIdentification, Inside Diameter, Identifier
IDIIntegrated Direct Ignition
IEAImpact Energy Absorber
IFFInjection Fuel Filter
IGBTInsulated Gate Bipolar Transistor
IgnIgnition
ILCIdle Load Compensator
IllumIllumination
IMDXIntegrated Mini Disc Changer
ImmoImmobilizer
IMPImpact
IMRCIntake Manifold Runner Control
IMTIntake Manifold Tuning
InInch/Inches
InadvInadvertent
IncIncrement
IncandIncandescent
INCLRIntercooler
INDIndictor
InflInflatable
INFLRInflator
InfoInformation
InitInitial
InjInjector
INJNInjection
INJRInjector
INLInlet
INRInner
INSInsert
INSLInsulator
INSPInspection
InstInstantaneous, Instant
INSTInstrument
INSTLInstall
INSTRInstruction
IntInterior
INTIntake
IPInstrument Panel
IPCInstrument Panel Cluster
IPCMInstrument Panel Cluster Module
IPGInstrument Panel Glove box
IPLInstrument Panel, Lower
IPMInstrument Panel Module
IPRInstrument Panel Retainer
IPUInstrument Panel, Upper
IRVMInside Rear View Mirror
IRVSMInside Rear View Sensing Mirror
ISCIdle Speed Control
ISCMIdle Speed Control Motor
ISGIdle Speed Governor
ISMInput Switch Module
IsoIsolation
ISOInternational Standards Organization
ISPIntegrated Spark Plug, Internet Service Provider
ISSInput Speed Shaft, Input Shaft Speed
ITCMIntegrated Transmission Control Module
IVEDIntegrated Vehicle Electrical Design
IVERIntegration Vehicle Engineering Release
K
K/UPKick Up
KAMKeep Alive Memory
KDDKeyboard Display Driver
KgKilogram
Kg/hKilograms per Hour
KHzKilohertz
KmKilometer
Km/hKilometers per Hour
Km/lKilometers per Liter
KNUKnuckle
KPaKilopascals
KSKnock Sensor
KVKilovolts
L
LLiter, Light, Low
L/GATELift Gate
L/PLRLock Pillar
L/SLIPLimited Slip
L4Four Cylinder Engine, In-Line
L6Six-Cylinder Engine, In-Line
LABLaboratory
LAMLaminate
LATLatch
LATLLateral
LbPound
Lb ftPound Feet Torque
Lb inPound Inch Torque
LBLLabel
LBS. FT.Pounds foot
LBS. IN.Pounds inch
LCDLiquid Crystal Display
LCGLacing
LCMLighting Control Module
LDLight Duty
LDCLLeft Door Closed Locking
LDCMLeft Door Control Module
LDGVLedge
LDMLamp Driver Module
LdutyLight Duty
LEDLight Emitting Diode
LEVLow Emissions Vehicle
LFLeft Front
LFTRLifter
LGMLift Gate Module
LGTLight
LGTDNLLongitudinal
LICLicense
LIMSLimit
LIQLiquid
LKLock
LKGLocking
LMDLeft Mid Door
LMTNGLimiting
LNGLining
LNKGLinkage
LNRLiner
LoLow
LOCLocation
LOCRLocator
LPLamp
LPGLiquefied Petroleum Gas (Propane)
LPSLow Pressure Sensor
LPTWLow Tire Pressure Warning
LmLumens
LRLeft Rear
LRDLeft Rear Door
LrnLearn
LtLeft
LTLight Truck, Long Term, Lead Time
LTPILow Tire Pressure Indicator
LTPWLow Tire Pressure Warning
LTPWSLow Tire Pressure Warning System
LTRLetter
LUBLubricant
LUGGLuggage
LUVLouver
LvlLevel
LVLLevel
LVLGLeveling
LVRLever
LWBLong Wheel Base
LWRLower
M
M/CMixture Control
M/CYLMaster Cylinder
M/FUNCMultifunction
M/PORTMultiport
M/TManual Transmission
M/TRNSManual Transmission
MAFMass Air Flow
MAFSMass Air Flow Sensor
MAGMagnetic
MAINTMaintenance
MalfMalfunction
MALLMultifunction Alarm Lighting and Locking
ManManual
MANIFManifold
ManufactManufactures
MAPManifold Absolute Pressure
MAPSManifold Absolute Pressure Sensor
MarMarch
MASMaster
MATManifold Absolute Temperature, Manifold Air Temperature
MATLMaterial
MATLSPECMaterial Specification
MaxMaximum
MBOMManufacturing Bill Of Materials
MCHGMachining
MCUMicroprocessor Control Unit
MDMini Disk
MDLModule
MDPManifold Differential Pressure
MDXMini Disk Changer
MedMedium
MEDLNMedallion
MemMemory
METMetal
MFIMultiport Fuel Injection
MgmtManagement
MiMiles
MICMicrophone
MidMidrange
MILMalfunction Indicator Lamp, Military
MinMinimum
MinMinute
MINMobile Identification Number
MIRMirror
MIXMixture
MKRMarker
MLMilliliter
MmMillimeter
Mm3Cubic millimeter
MmhgMillimeters of Mercury
MMMMemory Mirror Module
ModModule
MODModulator
Mon, MONMonitor
MOTMotor
MPGMiles per Gallon
MPHMiles per Hour
MsMillisecond
MSECMillisecond
MsgMessage
MSMMemory Seat Module
MSTManifold Surface Temperature
MSTREMoisture
MSVAMagnetic Steering Variable Assist, Magnasteer®
MTManual Transmission/Transaxle, Mount
MTGMounting
MtrMotor
MTRMeter
MTRGMetering
MUFFMuffler
MultMultiple
MuxMultiplex(-ing, -or)
MVMegavolt
MVMillivolt
N
NNeutral
N/PLTName Plate
NANatural
NAESNorth American Export Sales
NavNavigation
NbNiobium
NCNormally Closed
NDHNavigation Display Head
NDLNeedle
NEGNegative
NEUNeutral
NiNickel
NINeutral Idle
Ni-CDNickel-Cadmium
Ni-IonNickel-Ion battery
NiMHNickel Metal Hydride
NIPNipple
NLGINational Lubricating Grease Institute
N.mNewton-meter Torque
NONormally Open
No.Number
NOCONTAMNo contamination
NovNovember
NOxOxides of Nitrogen
NOZNozzle
NPTCNational Pipe Thread Coarse
NPTFNational Pipe Thread Fine
NRNoise Reduction
NTCNotice
NOVRAMNon-Volatile Random Access Memory
NVNight Vision
NVRAMNon-Volatile (static) Random Access Memory
O
O/MOwner's Manual
O2Oxygen
O2SOxygen Sensor
OATOutside Air Temperature
OBDOn-Board Diagnostics
OBD IIOn-Board Diagnostics Second Generation
OBPAOff Board Programming Adapter
OCOxidation Catalytic
OCCOccupant
OCSOpportunity Charge Station
OctOctober
ODOutside Diameter
ODMOutput Drive Module
ODOOdometer
OEOriginal Equipment
OEMOriginal Equipment Manufacturer
OGOrange
OHCOverhead Camshaft
OhmsOhm
OLOpen Loop, Out of Limits
OMOwners Manual
ONSOnStar
ORCOxidation Reduction Catalytic
OrigOriginal
ORNOrange
ORVROn-Board Refueling Vapor Recovery
OSCOxygen Storage Capacity
OSRVMOut Side Rear View Mirror
OSSOutput Shaft Speed
OvertempOvertemperature
OzOunce(s)
P
PPark
P/BPower Brake
P/BUTPush-button
P/GRPinion gear
P/NPart Number
P/SPower steering
P/SEATPassenger seat
P/WPower window
PAPublic address
PAGPolyalkylene Glycol
PAIRPulsed Air Injection Reactor
PARKParking
ParmsParameters
PASGPassage
PASS, PSGRPassenger
PASS-Key®Personalized Automotive Security System
PATTPattern
PCPressure Control
PCBPrinted Circuit Board
PCMPowertrain Control Module
PCMCIAPersonal Computer Memory Card International (or Industry) Association
PCSPressure Control Solenoid
PCVPositive Crankcase Ventilation
PDIFPressure Differential
PDMPassenger Door Module
PDSPassenger Door Switch
PEBPower Electronics Bay
PEDPedal
PerfPerformance
PhnPhone
PIDParameter Identification
PILOPillow
PIMPower Inverter Module
PINPersonal Identification Number
PITPitman
PIVPivot
PKPink
PKGPackage
PKTPocket
PLGRPlunger
PLLPhase Locked Loop
PLNMPlenum
PLNTPlanetary
PLRPillar
PLTPlate
PLTFPlatform
PLYRPlayer
PMPermanent Magnet Generator
PMVPressure Modulator Valve
PNPart Number
PNDLMPendulum
PNKPink
PNLPanel
PNPPark/Neutral Position
PNTPointer
POAPilot Operated Absolute Valve
POSPositive, Position
POTPotentiometer Variable Resistor
PPAHParallel Power Assist Hybrid
PPLPurple
PPMParts per Million
PPSPassenger Presence Sensing
PREDLVYPredelivery
PRESPresent
PRESSPressure
PRESS REGPressure Regulator
PretenPretensioner
PrevPrevious
PREVPreventive
PRGMProgram
PRIMPrimary
PRNDLPark, Reverse, Neutral, Drive, Low
PROCProcess
PROCDProcedure
ProgProgram
PROGMRProgrammer
PROMProgrammable Read Only Memory
PROPPropeller
PROPNProportion
PROTNProtection
PROTRProtector
PROTVProtective
PSPower Steering
PSAPower Switch Assembly
PSCPower Steering Controller
PSCMPower Steering Control Module, Passenger Seat Control Module, Power Seat Control Module
PSDPower Sliding Door
PsgrPassenger
PSIPounds per Square Inch
PsiaPounds per Square Inch Absolute
PSIGPounds per Square Inch Gauge
PSIRPassenger Supplemental Inflatable Restraint
PSIVPassive
PSMPassenger Seat Module
PSPPower Steering Pressure
PSTNPiston
PtPint
PTCPositive Temperature Coefficient
PTCMPowertrain Control Module
PTOPower Take-Off
PUPurple
PUBPick Up Box
PUBXPickup box
PULPulley
PULDNPull-down
PWPower Windows
PWMPulse Width Modulated
PWRPower
PWRTPowertrain
PZMPlatform Zone Module
Q
Q/PNLQuarter Panel
Q/WDOQuarter Window
QDMQuad Driver Module
QtQuart(s)
QTRQuarter
R
RReverse
R/AXLRear Axle
R/CMPTRear Compartment
R/CONRemote Control
R/DRear Door
R/ENDRear End
R/FLRRear Floor
R/FDRRear Fender
R/GRRear Gear
R/MLDGReveal Molding
R/QRear Quarter
R/RLRoof Rail
R/SEATRear Seat
R/TOPRemovable Top
R/WDORear Window
R-12Refrigerant-12
R-134aRefrigerant-134a
RACRemote Accessory Control(ler)
RADRadiator
RAMRandom Access Memory, Non-permanent memory device, memory contents are lost when power is removed.
RanRandom
RAPRetained Accessory Power
RAVRemote Activation Verification
RBNDRebound
RCCRear Climate Control
RCPTReceptacle
RCVGReceiving
RCVRReceiver
RCVYRecovery
RCDLRRemote Control Door Lock Receiver
RDRed
RDCMRight Door Control Module
RDCNReduction
RDCRReducer
RDGReading
RDMRear Door Module
RDORadio
RDSRadio Display System
RecReceive
RecepReceptable
RecircRecirculation
ReclRecline
RECLRecliner
RECRGRecirculating
RefReference
REFLReflector
REFLTYReflectivity
RefrigRefrigeration
REFRIGRefrigerant
REGRegulator or Regulated
RegenRegeneration or Regenerate
REINFReinforcement
RELRelease
REMRemote
REMANRemanufacture
REPLReplace
ReqRequisition
REQRequest
REQTRequirement
RESResistor
ResistResistance
RESOResonator
RESVReserve
ResyncResynchronize
RETRetainer
RETRRetractor
RevReverse
REVBRReverberator
REVLDTRevalidation
REXRear Exchanger
RIMRear Integration Module
RFRight Front, Radio Frequency, Roof
RFARemote Function Actuation
RFIRadio Frequency Interference
RFWSRight Front Wheel Speed
RGTRNRegistration
RHRight Hand
RIMRadio Interface Module, Rear Integration Module
RIVRivet
RKERemote Keyless Entry
RKRRocker
RLRail
RLFRelief
RLRRoller
RLYRelay
RMDRight Mid Door
RNDRound
ROMRead Only Memory, Permanent memory device, memory contents are retained when power is removed.
ROSRoll Over Sensor
ROTRotor
RPARear Parking Assist
RPMRevolutions per Minute Engine Speed
RPORegular Production Option
RPRRepair
RPRTReport
RRRight Rear, Rear
RRDRear Right Door
RSARear Seat Audio
RSGRadio Speaker Grill
RSRRiser
RSSRoad Sensing Suspension
RSTRestraint
RSTNRestriction
RSTRRestrictor
RSVRReservoir
RTRight
RTCReal Time Clock
RTDReal Time Damping
RTNReturn
RTTReconfigurable Telltale
RTVRoom Temperature Vulcanizing Sealer
RURust
RVCRegulated Voltage Control (sometimes Controller)
RVHSMRear Vented Heated Seat Module
RVLReveal
RVSRemote Vehicle Start
RWALRear Wheel Antilock
RWDRear Wheel Drive
RWSRear Wheel Steering
S
SSecond(s)
S/ABSShock absorber
S/DSide door
S/GRSteering Gear
S/KNUSteering Knuckle
S/LPStop lamp
S/MBRSide member
S/PNLSide panel
S/RLSide rail
S/SSunshade
S/STRSealing strip
S/WSoftware
SAESociety of Automotive Engineers
SAFSafety
SASSteering Angle Sensor
SBMStandard Body Module
SCSupercharger, Sports Coupe
SCAVScavenging
SCBSupercharger Bypass
SCESource
SCLCMSteering Column Lock Control Module
SCMSeat Control Module
SCRNScreen
SCTRSector
SCVSpeed Controlled Volume
SDLSerial Data Link
SDMSensing and Diagnostic Module
SDRSender
SecSecond(s)
SECDSecondary
SECTSection
SELSelector
SENSensor
SEOSpecial Equipment Option
SepSeptember
SEPSeparator
SeqSequence
SEQSequential
SerSerial
SERVService
SFSpot face
SFISequential Multiport Fuel Injection
SGMShanghai General Motors
SHSheet
SHFShaft
SHFTShift
SHKShock
SHKLShackle
SHLDShield
SHLDRShoulder
SHLFShelf
SHPGShipping
SHRDShroud
SISide, Spark Ignition
SISystem International Modern Version of Metric System
SIABSide Impact Air Bag
SIGSignal
SILSilencer
SIRSupplemental Inflatable Restraint
SISSide Impact Sensor
SKSkirt
SLAShort/Long Arm Suspension
SLDGSliding
SLDRSolder
SLEVSleeve
SMSmall
SMCCStepper Motor Cruise Control
SNBRSnubber
SNDSound
SNFRSnuffer
SO2Sulfur Dioxide
SOCSocket
SOHState Of Health
SOLSolenoid
SOLVSolvent
SPSplice Pack
S/PSeries/Parallel
SPASpare
SPCHGSupercharger
SPCRSpacer
SPDSpeed
SPDLSpindle
SPECSpecification
SPECDSpecified
SPEEDOSpeedometer
SPHSplash
SPHERSpherical
SPISerial Peripheral Interface
SPKRSpeaker
SPKTSprocket
SPLGSpark plug
SPLPSpot Lamp
SPLRSpoiler
SPLTRSplitter
SPLYSupply
SPOService Parts Operations
SPRSpring
SPSService Programming System, Speed Signal
SPWELDSpecified welds
Sq ft, ft 2Square Foot/Feet
Sq in, in 2Square Inch/Inches
SRSilver
SRCService Ride Control
SRIService Reminder Indicator
SRSSupplemental Restraint System
SRVServo
SSShift Solenoid, Speed Signal, Super Sport
SSESuper Sport Edition
SSRSuper Sports Roadster
SSS (S3)Speed Sensitive Steering
SSVShift Solenoid Valve
STScan Tool, Seat
STAStationary
STABStabilizer
STATStator
STCHGStitching
STDStandard
StdbyStandby
STFNRStiffener
STIDStation Identification Station ID
STKRStriker
STLService Transmission Lamp
STNRStrainer
STORStorage
STOWStowage
STPLStaple
STRStrip
STRGSteering
STRGRStringer
STRPStrap
STRPEStripe
STRTRStarter
S4WDSelectable Four-Wheel Drive
SUCSuction
SUPSupplement
SUPPRSuppressor
SUPTSupport
SURFSurface
SUSPSuspension
SUVSport Utility Vehicle
SVSide view
SVSService Vehicle Soon
SwSwitch
SWBShort Wheel Base
SWCSteering Wheel Controls
SwitzSwitzerland
SWIVSwivel
SWPSSteering Wheel Position Sensor
SYNSynchronizer
SyncSynchronize
SYSSystem
T
T&TTilt & telescope
T/BLKTerminal block
T/CVTorque converter
T/GATemperature gauge
T/LPTail lamp
T/PLYRTape player
T/PNLTrim panel
T/SIGTurn signal
T/VThrottle valve
TATraffic Announcement
TACThrottle Actuator Control
TACHTachometer
TACMThrottle Actuator Control Module
TAPTransmission Adaptive Pressure, Throttle Adaptive Pressure, Tapping
TARPTarpaulin
TASTrap Alert System
TAVTransmission Adaptive Volume
TBCTruck Body Controller
TBIThrottle Body Fuel Injection
TCTurbocharger, Transmission Control
TCCTorque Converter Clutch
TCCMTransfer Case Control Module
TCMTraction Control Module, Transmission Control Module
TCSTraction Control System
TCSCMTransfer Case Shift Control Module
TDCTop Dead Center
TELTelephone
TeleTelescope
TEMPTemperature
TEMPLTemplate
TENSTension
TENSRTensioner
TERMTerminal
TFPTransmission Fluid Pressure
TFTTransmission Fluid Temperature
THDThread
THERMThermostat
THMTurbo Hydra-Matic
THNRThinner
THRThrust
THROTThrottle
TIMTire Inflation Monitoring, Tire Inflation Module
TISTechline Information System
TKTank
TLTubeless, Teal
TLATail Lamp
TLSCPTelescope
TMGTiming
TMPRYTemporary
TNTan
TOCTransmission Oil Cooler
TOLTolerance
TORQTorque
TORSTorsion
TPThrottle Position
TPATerminal Positive Assurance
TPIMTraction Power Inverter Module
TPMTire Pressure Monitoring, Tire Pressure Monitor
TQTorque, Turquoise
TRTransmission Range, Trim
TracTraction
TRACTTraction
TRANSTransmission
TranspTransponder
TransxTransaxle
TRFERTransfer
TrkTruck
TRKTrack
TRLRTrailer
TRUNTrunnion
TSDTime speed distance
TSSTurbine Shaft Speed
TSTRTester
TTTell Tail lamp, Tube type
TTMTilt & Telescope Module
TUMBTumbler
TUNTunnel
TURBTurbine
TURBOTurbocharger
TVThrottle Valve
TVRSTelevision and Radio Suppression
TVVThermal Vacuum Valve
TWCThree Way Converter Catalytic
TWRTower
TwtrTweeter
TWC+OCThree Way + Oxidation Converter Catalytic
TXVThermal Expansion Valve
U
U/BUnderbody
U/HOODUnderhood
U/SEATUnderseat
U/VUnder vehicle
UARTUniversal Asynchronous Receiver Transmitter
UBECUnderhood Bussed Electrical Center
U/HUnderhood
U/HECUnderhood Electrical Center
U-jointUniversal Joint
UJTUniversal joint
UNDUnder
UnlkUnlock
UPRUpper
UPSHFTUpshift
UTDUniversal Theft Deterrent
UVUltraviolet
V
VVolt(s), Voltage
V6Six-Cylinder Engine, V-Type
V8Eight-Cylinder Engine, V-Type
VacVacuum
VACVehicle Access Code
VATSVehicle Anti-Theft System
VCIMVehicle Communication Interface Mode
VCMVehicle Control Module
V difVoltage Difference
VDOTVariable Displacement Orifice Tube
VDVVacuum Delay Valve
VelVelocity
VESVariable Effort Steering
VFVacuum Fluorescent
VIOViolet
VINVehicle Identification Number
VLRVoltage Loop Reserve
VMVVacuum Modulator Valve
VRVoltage Regulator
V refVoltage Reference
VSESVehicle Stability Enhancement System
VSSVehicle Speed Sensor
VTViolet
W
W/With
W/BWheel Base
WHWhite
WHLWheel
WHTWhite
W/oWithout
WOTWide Open Throttle
W/PWater Pump
W/SWindshield
WSSWheel Speed Sensor
WU-OCWarm Up Oxidation Converter Catalytic
WU-TWCWarm Up Three-Way Converter Catalytic
X
X-valveExpansion Valve
Y
YdYard(s)
YEYellow
YELYellow

Registered and Non-Registered Trademarks

Listed below are Registered Trademarks (®) or Non-Registered Trademarks (™) which may appear in this service manual.

A
AC®
ACCUTURN®
ACDelco®
Active Fuel Management™
Acuzinc®
Airbank®
Allison®
AMMCO®
AUTOFUSE®
AUTOTRAC®
B
Bendix®
BON-AMI®
Bosch®
Bose®
C
Catapillar®
CAT®
C-Quam®
D
Delco®
Delco Bose®
Delco Electronics®
Delco Freedom®
Delco LOC II®
Delco Moraine®
Delco Remy®
Delco Sound®
Delco Supreme®
Delco Tech®
DELCORE®
Delphi®
DEX-COOL®
DEXOIL®
DEXRON®
DEXSTEER™
DNR®
Dolby®
DR®
Duracell®
Duraguard®
Durastop®
Duramax™
E
Eaton Corporation®
EMD®
ETR®
F
FLO-LITE®
G
General Motors®
GM®
GM Goodwrench Service®
GM Optikleen®
GM Parts™
GM Pass®
GM Ultralite®
GMAC®
Goodwrench®
GTP®
H
Homelink™
HYDRA-MATIC®
I
Illumination®
INSTA-TRAC®
Intune®
L
LOCTITE™
M
MAGNASTEER®
Maxifuse®
Metripack®
Micropack®
Minifuse®
Mr Goodwrench®
N
Northstar®
O
OnStar®
Optikleen®
P
PASS-KEY®
PASS-KEYII®
PASSLOCK™
PK3®
Posidrive®
Pro®
Q
Quad 4®
R
RAINSENSE™
Rapid Fire®
S
ScotchBrite™
Scotchguard™
Signals®
Sikkens™
Soft-Ray®
Solar-Ray®
Stabilitrak®
Sunrayce®
Superlube®
Syclone®
T
Tech 2®
Techline®
Teflon®
Tefzel®
Theft-I®
Theftlock®
Tiltmaster®
TORX®
Transjel®
Transguide®
Twilight Sentinel®
U
Ultralite®
V
Velcro®
W
Weatherpack™

Ignition Lock Cylinder (Automatic Transmission)

The ignition lock cylinder uses only 7 of the 10 cut positions, 2 through 8. The ignition cylinder tumblers (3) are located on alternate sides of the cylinder (1). They are snap-in and self-retaining. It follows the key code with the first tumbler being the first depth of the key code, closest to the head of the key.

  1. Hold the ignition cylinder assembly (1) so the side with the tumbler spring pocket located closest to the head of the cylinder is facing up.
  2. Insert the tumbler spring (2) into each of the 4 spring pockets of the cylinder assembly (1).
  3. The first tumbler (3) to be loaded will be the second key cut position, which is the second number in the key code. Install the first tumbler in the slot over the spring. Install the remaining tumblers following the key code and same process, pressing the tumblers in place until they are secure.
  4. Rotate the cylinder assembly (1). Insert the tumbler spring (2) into each of the spring pockets of the cylinder assembly.
  5. The first tumbler to be loaded will be the third key cut position, the third number in the key code. Install the first tumbler in the slot over the spring. Install the remaining tumblers for cuts 5 and 7 following the key code and same process, pressing the tumblers in place until they are secure.
  6. Inspect for correct loading of the tumblers by inserting the key into the cylinder. All tumblers should drop flush with the lock cylinder body diameter.
  7. Lightly lubricate the outside surface in the tumbler area of the lock body and down the key slot using the provided grease. Insert and extract the key 5 times to lubricate the keyway.
  8. With the key in the cylinder assembly (1), insert the actuator (4) in the actuator pocket and hold. Rotate the cylinder assembly and insert the retainer spring (6) in the retainer slot located in the cylinder assembly. Insert the retainer (7) lining it up in the slot over the spring. Depress the retainer and hold.
  9. Insert the cylinder (1) into the sleeve (5) as shown in the illustration. Make sure the actuator stays located properly in the cylinder.
  10. When the key is removed the sleeve (5) should stay on the cylinder (1).
  11. Insert the key and function the lock 3 times to distribute the grease inside the sleeve.
  12. Verify the key position for inserting the lock into the column.

Scheme 6

Scheme 6: Ignition Lock Cylinder (Manual Transmission)

The ignition lock cylinder uses only 9 of the 10 cut positions, 2-9. The ignition cylinder tumblers (2) are all located on one side of the cylinder (1) and not self-retaining. A retainer (4) secures the tumblers. It follows the key code with the first tumbler being the first depth of the key code.

  1. Hold the ignition cylinder (1) so that the side with the tumbler spring wells is facing up.
  2. The first tumbler (2) to be loaded will be the second key cut position, the second number in the key code. Install the first tumbler in the slot nearest the head of the lock cylinder. Install the remaining tumblers following the key code.
  3. Insert tumbler springs (3) into the wells on top of the tumblers.
  4. Assemble the retainer (4) over springs. Secure by moving cylinder material over edges of the retainer with either a flat head screwdriver or a center punch on each of the four corners over the ends of the retainer.
  5. Inspect for correct loading of the tumblers by inserting the key into the cylinder. The side bar (5) should drop flush with the lock cylinder body diameter.
  6. Lightly lubricate the outside surfaces in the tumbler area of the lock body and down the key slot using the supplied grease. Insert and extract the key 5 times to lubricate the keyway.
  7. Line-up the lock to the run position. Insert lock in steering column making sure the retainer (6) is seated properly. Rotate lock to key out position and remove the key. Insert the key and rotate the lock 3 times to distribute the grease from the lock to column housing inside diameter.

Front Side Door Lock Cylinder

The front side door lock cylinder uses 7 of the 10 key cut positions, 4-10 when counting from the key head. The tumbler orientations alternate in adjacent locations from side to side with 4 on each side.

  1. Hold the uncoded cylinder (1) positioned so the side with 4 tumbler spring holes is facing upward, as shown.
  2. Insert one tumbler spring (2) each into the 4 tumbler spring holes.
  3. The first tumbler to be loaded will be key cut position 4, the fourth number in the key code. Determine the cut depth at this position and install the corresponding tumbler (3) into the tumbler slot nearest the front of the lock cylinder assembly, the end where the key is inserted.
  4. In the same manner, determine the cut depth and corresponding tumbler and install the 3 remaining tumblers (3) into the tumbler slots located at key cut positions 6, 8, and 10.
  5. Check for correct loading by holding the tumblers (3) in position and fully inserting the matching key into the cylinder (1). All tumblers should be flush with the outside diameter of the cylinder.
  6. Rotate the cylinder (1) so that the side with 3 tumbler spring holes is facing downward and then remove the matching key. Remember the tumblers (3) are not self-retaining and must be held in place.
  7. Insert one tumbler spring (2) each into the 3 tumbler spring holes.
  8. The first tumbler to be loaded will be key cut position 5. Determine the cut depth at this position and install the corresponding tumbler (3) into the tumbler slot nearest the front of the cylinder.
  9. In the same manner, determine the cut depth and corresponding tumbler and install the 3 remaining tumblers (3) into the tumbler slots located at key cut positions 7 and 9.
  10. Check for correct loading by holding the tumblers (3) in position and fully inserting the matching key into the cylinder (1). All tumblers should be flush with the outside diameter of the cylinder.
  11. Lightly lubricate tumbler (3) surfaces using the lubrication provided.
  12. Hold the case assembly (4) with the pre-staked detent spring retainer facing downward.
  13. First insert one detent spring (5) and then one detent ball (6) into the detent spring hole located to the rear and inside of the cylinder case assembly (4). The detent spring and detent ball are not self-retaining and must be held in place until the coded cylinder is installed into the case assembly.
  14. With the matching key fully inserted into the coded cylinder, install the coded cylinder into the case assembly (4). Make sure the detent spring (5) and detent ball (6) are held in place until the coded cylinder is fully installed. The detent ball should line up with the V-shaped groove on the rear of the cylinder, which will prevent the detent spring and detent ball from falling out of the case assembly.
  15. Remove the matching key being careful to keep the coded cylinder (1) fully inserted into the case assembly (4).
  16. Insert one shutter spring (7) each into the 2 shutter spring holes located on the front face of the cylinder (1).
  17. Install the shutter assembly (8) into the recessed area on the front face of the cylinder (1). Be sure that the ends of the pin on the shutter assembly are positioned in the pin cavities located in the front face of the cylinder.
  18. Install the lock cylinder cap (9) by aligning the drain hole in the cap with the bottom of the case assembly (4). Snap the cap into place with light hand pressure. Be sure the cap is securely retained on the case assembly. Also, be sure that the shutter springs (7) push the shutter assembly (8) up against the inside surface of the cap.
  19. Install the lever (10) onto the end of the cylinder (1).
  20. Install the retaining ring (11) in the groove at the end of the cylinder (1) to secure the lever (10) to the cylinder.
  21. Snap the rod retainer (12) into the hole in the lever (10).

Instrument Panel Compartment Door Lock Cylinder

The instrument panel (I/P) compartment door lock cylinder uses 4 of the 10 key cut positions, 7-10 when counting from the key head. The tumbler orientations alternate in adjacent locations with all 4 tumblers (3) located on the same side. A stainless steel retaining tumbler is used in the I/P compartment door lock cylinder to retain the lock cylinder in the latch assembly and does not move when the key is inserted. The retaining tumbler is located in the tumbler slot closest to the head of the cylinder assembly (1) and comes pre-installed in the cylinder.

  1. Hold the uncoded cylinder assembly (1) positioned so the side with 4 tumbler spring holes is facing upward.
  2. Insert one tumbler spring (2) each into the 4 tumbler spring holes.
  3. The first tumbler to be loaded will be key cut position 7, the seventh number in the key code. Determine the cut depth at this position and install the corresponding tumbler (3) into the tumbler slot nearest the front of the cylinder assembly (1), the end where the key is inserted.
  4. In the same manner, determine the cut depth and corresponding tumbler and install the 3 remaining tumblers (3) into the tumbler slots located at key cut positions 8, 9 and 10.
  5. Snap the tumblers (3) into place with light hand pressure.
  6. Check for correct tumbler loading by fully inserting the matching key into the cylinder (1). All tumblers (3) should be flush with the outside diameter of the cylinder.

Scheme 7

Scheme 7: Lifting and Jacking the Vehicle
WARNINGTo avoid any vehicle damage, serious personal injury or death when major components are removed from the vehicle and the vehicle is supported by a hoist, support the vehicle with jack stands at the opposite end from which the components are being removed and strap the vehicle to the hoist.
WARNINGTo avoid any vehicle damage, serious personal injury or death, always use the jackstands to support the vehicle when lifting the vehicle with a jack.
CAUTIONPerform the following steps before beginning any vehicle lifting or jacking procedure: Remove or secure all of the vehicle contents in order to avoid any shifting or any movement that may occur during the vehicle lifting or jacking procedure. The lifting equipment or the jacking equipment weight rating must meet or exceed the weight of the vehicle and any vehicle contents. The lifting equipment or the jacking equipment must meet the operational standards of the lifting equipment or jacking equipment manufacturer. Perform the vehicle lifting or jacking procedure on a clean, hard, dry, level surface. Perform the vehicle lifting or jacking procedure only at the identified lift points. DO NOT allow the lifting equipment or jacking equipment to contact any other vehicle components. Failure to perform the previous steps could result in damage to the lifting equipment or the jacking equipment, the vehicle, and/or the vehicle contents.

Front Lift Pads

When lifting the vehicle with a frame-contact lift, place the front lift pads on the front lower brackets, inboard of the rocker pinch weld flange and outboard of the front frame rail, at the torque box location, as shown.

Rear Lift Pads

When lifting the vehicle with a frame-contact lift, place the rear lift pads on the rear frame rail, at the torque box location, as shown.

Vehicle Jacking

CAUTIONWhen you are jacking the vehicle at the front locations, be certain that the jack or the jack lift pad does not contact the front fascia, front fascia air dam, or the front fenders. If such contact occurs, vehicle damage may result. When jacking at selected front locations additional clearance may be required for the jacking points.

Note. When you are lifting a vehicle with a service jack, block the wheels at the opposite end from which you are lifting. Use jack stands to provide additional support.

Front of Vehicle

When using a service jack under the front of the vehicle use one of the following locations

  1. Place the service jack pad in the same location as shown for the front lift pads.
  2. Under the front frame crossmember, as shown.

Rear of Vehicle

Note. Place jackstands ONLY under strong and stable vehicle structures.

When using a service jack under the rear of the vehicle place the jack pad on the rocker panel flange, at the torque box location, as shown.

Under the Engine Front Crossmember Frame

Note. The floor jack pad must not contact the oil pan, splash shield or the steering linkage.

Position the floor jack pad under the center of the engine front crossmember frame, as shown.

Special Tools Ordering Information

The special service tools shown in this service manual that have product numbers beginning with J, SA or BT are available for worldwide distribution from

OE Tool and Equipment Group

Kent-Moore

28635 Mound Road

Warren

MI, U.S.A

48092-3499

Phone: 1-800-345-2233 or 586-574-2332

Monday through Friday

8:00 am-7:00 pm Eastern Standard Time

Fax: 1-800-578-7375 or 586-578-7321

The TECH 2 scan tool and accessories can be purchased through

Dealer Equipment and Services

5775 Enterprise Dr.

Warren

MI, U.S.A

48092-3463

Phone: 1-800-GM-TOOLS or 586-574-2332

Monday through Friday

8:00 am-6:00 pm EST

Fax: 1-586-578-7205
