Ignition Switch
Ignition Switch Connector Part Information 12064978 6-Way F Micro-Pack 100 Series (GY) Pin Wire Color Circuit No. Function 1 RD/WH 540 Battery Positive Voltage 2 BN 4 Accessory Voltage 3 PK 3 Ignition 1 Voltage 4 YE 5 Crank Voltage 5 OG 300 Ignition 3 Voltage 6 RD/WH 1940 Battery Positive Voltage
C101 Engine Harness to Body Harness
C101 Engine Harness to Body Harness Connector Part Information 7283-5545-10 12-Way F 1.5 Series Weather Pack (GY) Connector Part Information 7282-5545-10 12-Way M 1.5 Series Weather Pack (GY) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 TN 884 Left Rear Wheel Speed Sensor Signal 1 TN 884 Left Rear Wheel Speed Sensor Signal 2 OG 885 Left Rear Wheel Speed Sensor Low Reference 2 OG 885 Left Rear Wheel Speed Sensor Low Reference 3 BN 882 Right Rear Wheel Speed Sensor Signal 3 BN 882 Right Rear Wheel Speed Sensor Signal 4 WH 883 Right Rear Wheel Speed Sensor Low Reference 4 WH 883 Right Rear Wheel Speed Sensor Low Reference 5 PK 39 Ignition 1 Voltage 5 PK 39 Ignition 1 Voltage 6 D-GN/WH 465 Fuel Pump Relay Control 6 D-GN/WH 465 Fuel Pump Relay Control 7 TN 452 Low Reference 7 TN 452 Low Reference 8 D-GN 890 Fuel Tank Pressure Sensor Signal 8 D-GN 890 Fuel Tank Pressure Sensor Signal 9 TN 596 5-Volt Reference (LA3/LY9) 9 GY 596 5-Volt Reference GY 596 5-Volt Reference (LY7/LS6) 10 WH 1310 EVAP Canister Vent Solenoid Control 10 WH 1310 EVAP Canister Vent Solenoid Control 11 D-BU 1936 Fuel Level Sensor Signal - Primary 11 D-BU 1936 Fuel Level Sensor Signal - Primary 12 L-BU 1937 Fuel Level Sensor Signal - Secondary 12 L-BU 1937 Fuel Level Sensor Signal - Secondary
Scheme 97
Scheme 98
C102 Engine Harness to Body Harness
C102 Engine Harness to Body Harness Connector Part Information 7283-5946-30 10-Way F 1.5 Series Weather Pack (BK) Connector Part Information 7282-5946-30 10-Way M 1.5 Series Weather Pack (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 OG 5371 BAS Relay Coil Supply Voltage 1 OG 5371 BAS Relay Coil Supply Voltage 2 L-GN/BK 1338 Low Reference (JL4/J56) 2 L-GN/BK 1338 Low Reference (JL4/J56) 3 GY/BK 1337 5-Volt Reference (JL4/J56) 3 GY/BK 1337 5-Volt Reference (JL4/J56) 4 L-BU 715 Lateral Accelerometer Signal (JL4/J56) 4 L-BU 715 Lateral Accelerometer Signal (JL4/J56) 5 D-BU 716 Yaw Rate Sensor Signal (JL4/J56) 5 D-BU 716 Yaw Rate Sensor Signal (JL4/J56) 6 L-GN 5007 Backup Lamp Switch Signal (M35/M12/MN6) 6 L-GN 5007 Backup Lamp Switch Signal (M35/M12/MN6) 7 PU 5128 Auxiliary Cooling Fan Relay Control (Export w/V92) 7 PU 5128 Auxiliary Cooling Fan Relay Control (Export w/V92) 8 BN 818 Vehicle Speed Signal 8 BN 818 Vehicle Speed Signal 9 PK 5126 Afterboil Coolant Pump Supply Voltage (LA3/LY9) 9 PK 5126 Afterboil Coolant Pump Supply Voltage (LA3/LY9/LY7) 10 - - Not Used 10 - - Not Used
Scheme 99
Scheme 100
C103 I/P Harness to Battery Harness
C103 I/P Harness to Battery Harness Connector Part Information 7283-5548-30 2-Way F 1.5 Series Weather Pack (BK) Connector Part Information 7282-5548-30 2-Way M 1.5 Series Weather Pack (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function. 1 BK/WH 51 Ground 1 BK/WH 51 Ground (LA3/LY9/LY7) BK 51 Ground (LS6) 2 BK 100 Blunt Cut 2 - - Not Used
Scheme 101
C104 Engine Harness to I/P Harness (LA3/LY9/LY7)
C104 Engine Harness to I/P Harness (LA3/LY9/LY7) Connector Part Information 15366099 24-Way F GT 150/280 Sealed (BK) Connector Part Information 15336173 24-Way M GT 150/280 Sealed (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A1 L-GN 1763 Steering Wheel Position Signal A (JL4) A1 L-GN 1763 Steering Wheel Position Signal A (JL4) A2 L-BU 1764 Steering Wheel Position Signal B (JL4) A2 L-BU 1764 Steering Wheel Position Signal B (JL4) A3 WH 5359 5-Volt Reference A3 WH 5359 5-Volt Reference A4 BN 5360 Low Reference A4 BN 5360 Low Reference A5 YE 5361 Brake Pedal Position (BPP) Sensor Signal A5 YE 5361 Brake Pedal Position (BPP) Sensor Signal A6 WH 2500 High Speed GMLAN Serial Data Bus + (LY7) A6 WH 2500 High Speed GMLAN Serial Data Bus + (LY7) A7 L-GN 2501 High Speed GMLAN Serial Data Bus - (LY7) A7 L-GN 2501 High Speed GMLAN Serial Data Bus - (LY7) A8 PU 1807 Class 2 Serial Data A8 PU 1807 Class 2 Serial Data B1 PU 1272 Low Reference B1 PU 1272 Low Reference B2 L-BU 1162 APP Sensor 2 Signal B2 L-BU 1162 APP Sensor 2 Signal B3 TN 1274 5-Volt Reference B3 TN 1274 5-Volt Reference B4 BN 1271 Low Reference B4 BN 1271 Low Reference B5 D-BU 1161 APP Sensor 1 Signal B5 D-BU 1161 APP Sensor 1 Signal B6 WH/BK 1164 5-Volt Reference B6 WH/BK 1164 5-Volt Reference B7 PK 839 Ignition 1 Voltage B7 PK 839 Ignition 1 Voltage B8 BN/WH 379 CPP Switch Signal (M35) B8 BN/WH 379 CPP Switch Signal C1 PU 1807 Class 2 Serial Data C1 PU 1807 Class 2 Serial Data C2 WH 121 Engine Speed Signal C2 WH 121 Engine Speed Signal C3 D-BU 1537 ABS Indicator Signal C3 D-BU 1537 ABS Indicator Signal C4 WH/BK 5043 Keyword 2000 Serial Data (LA3/LY9) C4 WH/BK 5043 Keyword 2000 Serial Data C5 GY 1884 Cruise Control Switch Signal (LA3/LY9/LY7) C5 GY 1884 Cruise Control Switch Signal (LA3/LY9/LY7) C6 YE 5 Crank Voltage C6 YE 5 Crank Voltage C7 BN/WH 419 MIL Control C7 BN/WH 419 MIL Control C8 PU/WH 1035 Starter Relay Coil Supply Voltage (M35) C8 PU/WH 1035 Starter Relay Coil Supply Voltage PK 839 Ignition 1 Voltage (M82)
Scheme 102
C105 Engine Harness to I/P Harness (LS6)
C105 Engine Harness to I/P Harness (LS6) Connector Part Information 15326863 16-Way F GT 150 Series Sealed 4.0 (BK) Connector Part Information 15326868 16-Way M GT 150 Series Sealed 4.0 (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A - - Not used A - - Not used B PU/WH 1035 Starter Relay Coil Supply Voltage B PU/WH 1035 Starter Relay Coil Supply Voltage C D-GN/WH 357 Oil Temperature Sensor Signal C D-GN/WH 357 Oil Temperature Sensor Signal D WH 375 Skip Shift Indicator Control (MN6) D WH 375 Skip Shift Indicator Control (MN6) E - - Not Used E - - Not Used F GY 397 Cruise Control On Switch Signal F GY 397 Cruise Control On Switch Signal G D-BU 84 Cruise Control Set/Coast Switch Signal G D-BU 84 Cruise Control Set/Coast Switch Signal H GY/BK 87 Cruise Control Resume/Accel Switch Signal H GY/BK 87 Cruise Control Resume/Accel Switch Signal J BN/WH 379 CPP Switch Signal J BN/WH 379 CPP Switch Signal K-L - - Not Used K-L - - Not Used M BN/WH 419 MIL Control M BN/WH 419 MIL Control N - - Not Used N - - Not Used P WH 121 Engine Speed Signal P WH 121 Engine Speed Signal R D-BU 1537 ABS Indicator Signal R D-BU 1537 ABS Indicator Signal S - - Not Used S - - Not Used
C107 Engine Harness to I/P Harness (LS6)
C107 Engine Harness to I/P Harness (LS6) Connector Part Information 15326084 16-Way F GT 150/280 Series Sealed 4.0 (BK) Connector Part Information 15326085 16-Way M GT 150/280 Series Sealed 4.0 (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A YE 5 Crank Voltage A YE 5 Crank Voltage B-E - - Not Used B-E - - Not Used F L-GN 1763 Steering Wheel Position Signal A F L-GN 1763 Steering Wheel Position Signal A G L-BU 1764 Steering Wheel Position Signal B G L-BU 1764 Steering Wheel Position Signal B H-J - - Not Used H-J - - Not Used K WH 5359 5-Volt Reference K WH 5359 5-Volt Reference L BN 5360 Low Reference L BN 5360 Low Reference M YE 5361 Brake Pedal Position (BPP) Sensor Signal M YE 5361 Brake Pedal Position (BPP) Sensor Signal N PU 1807 Class 2 Serial Data N PU 1807 Class 2 Serial Data P PU 1807 Class 2 Serial Data P PU 1807 Class 2 Serial Data R-S - - Not Used R-S - - Not Used
Scheme 103
C108 Forward Lamp Harness to Left Front Turn Signal/Fog Lamp Harness
C108 Forward Lamp Harness to Left Front Turn Signal/Fog Lamp Harness Connector Part Information 12162144 4-Way F Metri-Pack 150 Series (BK) Connector Part Information 12162102 4-Way M Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A PU 2234 Front Fog Lamp Supply Voltage A WH 2234 Front Fog Lamp Supply Voltage B D-BU 5364 Left DRL/Turn Supply Voltage (Domestic) B WH 5364 Left DRL/Turn Supply Voltage (Domestic) L-BU/WH 1314 Left Turn Signal Indicator Lamp Supply Voltage (Export w/T62/T65) WH 1314 Left Turn Signal Indicator Lamp Supply Voltage (Export w/T62/T65) C BK 250 Ground C WH 250 Ground D BK 250 Ground D WH 250 Ground
C109 Forward Lamp Harness to Right Front Turn Signal/Fog Lamp Harness
C109 Forward Lamp Harness to Right Front Turn Signal/Fog Lamp Harness Connector Part Information 12162144 4-Way F Metri-Pack 150 Series (BK) Connector Part Information 12162102 4-Way M Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A PU 2234 Front Fog Lamp Supply Voltage A WH 2234 Front Fog Lamp Supply Voltage B D-GN 5365 Right DRL/Turn Supply Voltage (Domestic) B WH 5365 Right DRL/Turn Supply Voltage (Domestic) D-BU/WH 1315 Right Turn Signal Indicator Lamp Supply Voltage (Export w/T62/T65) WH 1315 Right Turn Signal Indicator Lamp Supply Voltage (Export w/T62/T65) C BK 250 Ground C WH 250 Ground D BK 250 Ground D WH 250 Ground
C110 Forward Lamp Harness to Left Repeater Lamp Jumper Harness (Export)
C110 Forward Lamp Harness to Left Repeater Lamp Jumper Harness (Export) Connector Part Information 12015792 2-Way F Weather Pack (BK) Connector Part Information 12010973 2-Way M Weather Pack (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A L-BU/WH 1314 Left Turn Signal Indicator Lamp Supply Voltage A L-BU/WH 1314 Left Turn Signal Indicator Lamp Supply Voltage B BK 250 Ground B BK 250 Ground
C111 Forward Lamp Harness to Right Repeater Lamp Jumper Harness (Export) Connector Part Information 12015792 2-Way F Weather Pack (BK) Connector Part Information 12010973 2-Way M Weather Pack (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A D-BU/WH 1315 Right Turn Signal Indicator Lamp Supply Voltage A D-BU/WH 1315 Right Turn Signal Indicator Lamp Supply Voltage B BK 250 Ground B BK 250 Ground
C112 Engine Harness to Fuel Injector Harness (LA3/LY9)
C112 Engine Harness to Fuel Injector Harness (LA3/LY9) Connector Part Information 12059471 7-Way F Metri-Pack 150/480 Series (BK) Connector Part Information 12052200 7-Way M Metri-Pack 150/480 Series (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A TN 1744 Fuel Injector 1 Control A TN/YE 1744 Fuel Injector 1 Control B L-GN/BK 1745 Fuel Injector 2 Control B TN/L-GN 1745 Fuel Injector 2 Control C PK/BK 1746 Fuel Injector 3 Control C TN/D-BU 1746 Fuel Injector 3 Control D L-BU/BK 844 Fuel Injector 4 Control D TN/RD 844 Fuel Injector 4 Control E TN/WH 845 Fuel Injector 5 Control E TN/BK 845 Fuel Injector 5 Control F YE/BK 846 Fuel Injector 6 Control F TN/WH 846 Fuel Injector 6 Control G PK/BK 5291 Ignition 1 Voltage G RD/D-BU 5291 Ignition 1 Voltage
Scheme 104
C113 Forward Lamp Harness to Engine Harness (LS6)
C113 Forward Lamp Harness to Engine Harness (LS6) Connector Part Information 7283-5596-10 2-Way F Yazaki (GY) Connector Part Information 7282-5596-10 2-Way M Yazaki (GY) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 BK 1150 Ground 1 BK 1150 Ground 2 BK 1150 Ground 2 BK 1150 Ground
C120 Engine Harness to POA Harness (LY7)
C120 Engine Harness to POA Harness (LY7) Connector Part Information 12059471 7-Way F Metri-Pack 150/480 Series (BK) Connector Part Information 12052200 7-Way M Metri-Pack 150/480 Series (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A PK/BK 5291 Ignition 1 Voltage A PK/BK 5291 Ignition 1 Voltage B - - Not Used B - - Not Used C D-GN 59 A/C Compressor Clutch Supply Voltage C D-GN 59 A/C Compressor Clutch Supply Voltage D PK/BK 5292 Ignition 1 Voltage D PK/BK 5292 Ignition 1 Voltage E PU 6 Starter Solenoid Crank Voltage E PU 6 Starter Solenoid Crank Voltage F PK/BK 5293 Ignition 1 Voltage F PK/BK 5293 Ignition 1 Voltage G BK/WH 751 Ground (M82) G BK/WH 751 Ground (M82)
C121 Engine Harness to Injector Harness (LY7)
C121 Engine Harness to Injector Harness (LY7) Connector Part Information 1-963214-1 10-Way F Amp (BK) Connector Part Information 6-1355688-1 10-Way M AMP (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 WH 5291 Ignition 1 Voltage 1 WH 5291 Ignition 1 Voltage 2 WH 5292 Ignition 1 Voltage 2 WH 5292 Ignition 1 Voltage 3 TN 1744 Fuel Injector 1 Control 3 TN 1744 Fuel Injector 1 Control 4 PK/BK 1746 Fuel Injector 3 Control 4 PK/BK 1746 Fuel Injector 3 Control 5 TN/WH 845 Fuel Injector 5 Control 5 TN/WH 845 Fuel Injector 5 Control 6 L-GN/BK 1745 Fuel Injector 2 Control 6 L-GN/BK 1745 Fuel Injector 2 Control 7 D-BU/BK 844 Fuel Injector 4 Control 7 L-BU/BK 844 Fuel Injector 4 Control 8 YE/BK 846 Fuel Injector 6 Control 8 YE/BK 846 Fuel Injector 6 Control 9-10 - - Not Used 9-10 - - Not Used
Scheme 105
C131 Engine Harness to Odd Ignition Coils Harness (LS6)
C131 Engine Harness to Odd Ignition Coils Harness (LS6) Connector Part Information 12047938 7-Way F Metri-Pack 150 Series Sealed (GY) Connector Part Information 12047933 7-Way M Metri-Pack 150 Series Sealed (GY) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A BK/WH 1451 Ground A BK 1451 Ground B OG 2127 IC 7 Control B RD 2127 IC 7 Control C D-GN 2125 IC 5 Control C D-GN 2125 IC 5 Control D - - Unavailable D - - Unavailable E BN 2129 Low Reference E BN 2129 Low Reference F L-BU 2123 IC 3 Control F L-BU 2123 IC 3 Control G PU 2121 IC 1 Control G PU 2121 IC 1 Control H PK/BK 5291 Ignition 1 Voltage H PK 5291 Ignition 1 Voltage
Scheme 106
Scheme 107
C132 Engine Harness to Even Ignition Coils Harness (LS6)
C132 Engine Harness to Even Ignition Coils Harness (LS6) Connector Part Information 12047938 7-Way F Metri-Pack 150 Series Sealed (GY) Connector Part Information 12047933 7-Way M Metri-Pack 150 Series Sealed (GY) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A BK/WH 1551 Ground A BK 1551 Ground B RD/WH 2122 IC 2 Control B RD 2122 IC 2 Control C D-GN/WH 2124 IC 4 Control C D-GN 2124 IC 4 Control D - - Unavailable D - - Unavailable E BN/WH 2130 Low Reference E BN 2130 Low Reference F L-BU/WH 2126 IC 6 Control F L-BU 2126 IC 6 Control G PU/WH 2128 IC 8 Control G PU 2128 IC 8 Control H PK/BK 5292 Ignition 1 Voltage H PK 5292 Ignition 1 Voltage
C133 Engine Harness to Knock Sensor Harness (LS6)
C133 Engine Harness to Knock Sensor Harness (LS6) Connector Part Information 12052641 2-Way F Metri-Pack 150 Series Sealed (BK) Connector Part Information 12162000 2-Way M Metri-Pack 150 Series Sealed (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A D-BU 496 Knock Sensor 1 Signal A D-BU 496 Knock Sensor 1 Signal B L-BU 1876 Knock Sensor 2 Signal B L-BU 1876 Knock Sensor 2 Signal
C200 Body Harness to I/P Harness - Left
C200 Body Harness to I/P Harness - Left Connector Part Information 7283-6376-30 26-Way F Hybrid (BK) Connector Part Information 7282-6376-30 26-Way M Hybrid (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 BK 350 Ground 1 BK 350 Ground 2 PU 1807 Class 2 Serial Data 2 PU 1807 Class 2 Serial Data 3 BK/WH 351 Ground 3 BK/WH 351 Ground 4 - - Not Used 4 - - Not Used 5 PK/BK 1597 Courtesy Lamps Switch On Signal 5 PK/BK 1597 Courtesy Lamps Switch On Signal 6 YE 1834 Forward Discriminating Sensor Signal 6 YE 1834 Forward Discriminating Sensor Signal 7 TN/OG 5045 Discriminating Sensor - Low Reference 7 TN/OG 5045 Discriminating Sensor - Low Reference 8 D-BU/WH 1315 Right Turn Signal Indicator Lamp Supply Voltage 8 D-BU/WH 1315 Right Turn Signal Indicator Lamp Supply Voltage D-BU/WH 1315 Right Turn Signal Indicator Lamp Supply Voltage 9 D-BU/WH 149 Courtesy Lamp Supply Voltage 9 D-BU/WH 149 Courtesy Lamp Supply Voltage D-BU/WH 149 Courtesy Lamp Supply Voltage 10 GY 157 Courtesy Lamp Control 10 GY 157 Courtesy Lamp Control GY 157 Courtesy Lamp Control 11 YE 32 Instrument Panel Lamp Fuse Supply Voltage - 1 (w/o T79) 11 YE 32 Instrument Panel Lamp Fuse Supply Voltage - 1 (w/o T79) 12 PU 709 Left Park Lamp Supply Voltage (w/o T79) 12 PU 709 Left Park Lamp Supply Voltage (w/o T79) 13 D-GN 44 Instrument Panel Lamps Dimmer Switch Signal 13 D-GN 44 Instrument Panel Lamps Dimmer Switch Signal 14 YE 5005 Instrument Panel Lamps Dimmer Switch Low Reference 14 YE 5005 Instrument Panel Lamps Dimmer Switch Low Reference 15 OG 300 Ignition 3 Voltage 15 OG 300 Ignition 3 Voltage 16 PK 3 Ignition 1 Voltage 16 PK 3 Ignition 1 Voltage 17 L-BU/WH 1314 Left Turn Signal Indicator Lamp Supply Voltage 17 L-BU/WH 1314 Left Turn Signal Indicator Lamp Supply Voltage 18 L-BU/BK 1688 5-Volt Reference 18 L-BU/BK 1688 5-Volt Reference 19 PU/WH 5025 Ignition Lock Cylinder Control Actuator Supply Voltage (M82) (Maybe Give Away) 19 PU/WH 5025 Ignition Lock Cylinder Control Actuator Supply Voltage (M82) (Maybe Give Away) 20-21 - - Not Used 20-21 - - Not Used 22 BN 41 Ignition 3 Voltage 22 BN 41 Ignition 3 Voltage 23 - - Not Used 23 - - Not Used 24 BN 141 Ignition 3 Voltage 24 BN 141 Ignition 3 Voltage 25 PK/BK 5292 Ignition 1 Voltage (V92) (Maybe Give Away) 25 PK/BK 5292 Ignition 1 Voltage (V92) (Maybe Give Away) 26 - - Not Used 26 - - Not Used
Scheme 108
C201 Body Harness to I/P Harness - Right
C201 Body Harness to I/P Harness - Right Connector Part Information 7283-6376-30 26-Way F Hybrid (BK) Connector Part Information 7282-6376-30 26-Way M Hybrid (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 BK 450 Ground 1 BK 450 Ground 2 - - Not Used 2 - - Not Used 3 GY/BK 1337 5-Volt Reference (JL4/J56) 3 GY/BK 1337 5-Volt Reference (JL4/J56) GY/BK 1337 5-Volt Reference (JL4/J56) 4 L-GN/BK 1338 Low Reference (JL4/J56) 4 L-GN/BK 1338 Low Reference (JL4/J56) L-GN/BK 1338 Low Reference (JL4/J56) 5 PU 1807 Class 2 Serial Data 5 PU 1807 Class 2 Serial Data 6 RD/WH 540 Battery Positive Voltage 6 RD/WH 540 Battery Positive Voltage 7 BN 818 Vehicle Speed Signal 7 BN 818 Vehicle Speed Signal BN 818 Vehicle Speed Signal 8 YE 5358 Auxiliary Cooling Fan Motor Supply Voltage (V92) 8 YE 5358 Auxiliary Cooling Fan Motor Supply Voltage (V92) 9 - - Not Used 9 - - Not Used 10 YE 1491 Backlight Lamps Control 10 YE 1491 Backlight Lamps Control 11 BN/WH 309 Right Park Lamp Supply Voltage (w/o T79) 11 BN/WH 309 Right Park Lamp Supply Voltage (w/o T79) 12-13 - - Not Used 12-13 - - Not Used 14 BK/WH 451 Ground 14 BK/WH 451 Ground 15-16 - - Not Used 15-16 - - Not Used 17 D-BU/WH 149 Courtesy Lamp Supply Voltage 17 D-BU/WH 149 Courtesy Lamp Supply Voltage D-BU/WH 149 Courtesy Lamp Supply Voltage 18 GY 157 Courtesy Lamp Control 18 GY 157 Courtesy Lamp Control GY 157 Courtesy Lamp Control 19-22 - - Not Used 19-22 - - Not Used 23 BN/WH 1571 Traction Control Switch Signal 23 BN/WH 1571 Traction Control Switch Signal 24 - - Not Used 24 - - Not Used 25 GY 5127 After Boil Coolant Pump Relay Control (LA3/LY9) (Maybe Give Away) 25 GY 5127 After Boil Coolant Pump Relay Control (LA3/LY9) 26 TN 5026 Ignition Lock Cylinder Control Switch Signal (M82) (Maybe Give Away) 26 TN 5026 Ignition Lock Cylinder Control Switch Signal (M82)
C202 I/P Harness to Steering Column Harness
C202 I/P Harness to Steering Column Harness Connector Part Information 15359287 40-Way F GT 150 280 (BK) Connector Part Information 15336417 40-Way M GT 150 280 (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A1 BN 1356 Flash To Pass Switch Signal A1 BN 1356 Flash To Pass Switch Signal A2 BK 351 Ground A2 BK 351 Ground A3 TN/WH 1969 Headlamp High Beam Relay Control A3 BK/WH 1969 Headlamp High Beam Relay Control TN/WH 1969 Headlamp High Beam Relay Control A4 PK/WH 1970 Headlamp Low Beam Relay Control A4 L-BU 1970 Headlamp Low Beam Relay Control PK/WH 1970 Headlamp Low Beam Relay Control A5 TN 28 Horn Relay Control A5 L-GN 28 Horn Relay Control TN 28 Horn Relay Control A6 BK/WH 351 Ground A6 BK/WH 351 Ground A7 PU 1807 Class 2 Serial Data A7 PU 1807 Class 2 Serial Data A8 PK 1545 Information Down Switch Signal (LA3/LY9/LY7) A8 PK 1545 Information Down Switch Signal (LA3/LY9/LY7) GY 397 Cruise Control On Switch Signal (LS6) 397 Cruise Control On Switch Signal (LS6) B1 L-BU 187 Rear Fog Lamp Switch Signal (w/ T79) B1 L-BU 187 Rear Fog Lamp Switch Signal B2 OG 192 Front Fog Lamp Switch Signal B2 OG 192 Front Fog Lamp Switch Signal B3 WH 103 Headlamp Switch Headlamps On Signal B3 WH 103 Headlamp Switch Headlamps On Signal B4 BN/WH 301 Park Lamp Switch On Signal B4 BN/WH 301 Park Lamp Switch On Signal B5 PU 1783 Twilight Sentinel Delay Signal B5 PU 1783 Twilight Sentinel Delay Signal B6 - - Not Used B6 - - Not Used B7 D-GN 80 Key In Ignition Switch Signal B7 L-GN 80 Key In Ignition Switch Signal B8 D-BU 477 Windshield Wiper Switch Signal 1 B8 D-BU 477 Windshield Wiper Switch Signal 1 B9 PU 92 Windshield Wiper Motor High Speed B9 PU 92 Windshield Wiper Motor High Speed B10 WH 1538 Windshield Wiper Switch On Signal B10 WH 1538 Windshield Wiper Switch On Signal B11 YE 43 Accessory Voltage B11 YE 43 Accessory Voltage B12 GY 478 Windshield Wiper Switch Signal 2 B12 GY 478 Windshield Wiper Switch Signal 2 C1 PU 1375 Remote Radio Control Supply Voltage (LA3/LY9/LY7) C1 PU 1375 Remote Radio Control Supply Voltage (LA3/LY9/LY7) D-BU 84 Cruise Control Set/Coast Switch Signal (LS6) 84 Cruise Control Set/Coast Switch Signal (LS6) C2 RD/WH 1440 Battery Positive Voltage C2 OG 1440 Battery Positive Voltage C3 YE 343 Accessory Voltage C3 YE 343 Accessory Voltage C4 YE 1491 Backlight Lamps Control C4 YE 1491 Backlight Lamps Control C5 BK 350 Ground C5 BK 350 Ground C6 PU/WH 5025 Ignition Lock Cylinder Control Actuator Supply Voltage (M82) C6 PU/WH 5025 Ignition Lock Cylinder Control Actuator Supply Voltage (M82) C7 L-BU/WH 1414 Left Turn Signal Switch Signal (w/o T62/T65) C7 L-BU/WH 1414 Left Turn Signal Switch Signal (w/o T62/T65) C8 D-BU/WH 1415 Right Turn Signal Switch Signal (w/o T62/T65) C8 D-BU/WH 1415 Right Turn Signal Switch Signal (w/o T62/T65) C9 PK 3 Ignition 1 Voltage C9 PK 3 Ignition 1 Voltage C10 YE 5 Crank Voltage C10 YE 5 Crank Voltage C11 OG 300 Ignition 3 Voltage C11 OG 300 Ignition 3 Voltage C12 D-BU 1796 Steering Wheel Controls Signal (LA3/LY9/LY7) C12 D-BU 1796 Steering Wheel Controls Signal (LA3/LY9/LY7) 901 Steering Wheel Controls Signal (LS6) 5201 Steering Wheel Controls Signal (LS6) D1 OG 1544 Information Up Switch Signal (LA3/LY9/LY7) D1 OG 1544 Information Up Switch Signal (LA3/LY9/LY7) GY/BK 87 Cruise Control Resume/Accel Switch Signal (LS6) 87 Cruise Control Resume/Accel Switch Signal (LS6) D2 GY 1884 Cruise Control Switch Signal (LA3/LY9/LY7/LS6) D2 GY 1884 Cruise Control Switch Signal (LA3/LY9/LY7) GY/BK 1884 Cruise Control Switch Signal (LS6) D3 RD/WH 540 Battery Positive Voltage D3 RD/WH 540 Battery Positive Voltage D4 RD/WH 1940 Battery Positive Voltage D4 RD/WH 1940 Battery Positive Voltage D5 PK 339 Ignition 1 Voltage D5 PK 339 Ignition 1 Voltage D6 BN 4 Accessory Voltage D6 BN 4 Accessory Voltage BN 4 Accessory Voltage D7 YE/BK 1418 Left Rear Turn Signal Switch Signal (T79) D7 YE/BK 1418 Left Rear Turn Signal Switch Signal D8 D-GN/WH 1419 Right Rear Turn Signal Switch Signal (T79) D8 L-GN 1419 Right Rear Turn Signal Switch Signal
Scheme 109
C203 Steering Column Harness to Body Harness
C203 Steering Column Harness to Body Harness Connector Part Information 15336478 4-Way F Metri-Pack 280 Series (YE) Connector Part Information 15336476 4-Way M Metri-Pack 280 Series (YE) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A1 TN 3021 Steering Wheel Module-Stage 1-High Control A1 TN 3021 Steering Wheel Module-Stage 1-High Control A2 BN 3020 Steering Wheel Module-Stage 1-Low Control A2 BN 3020 Steering Wheel Module-Stage 1-Low Control B1 WH 3023 Steering Wheel Module-Stage 2-High Control B1 WH 3023 Steering Wheel Module-Stage 2-High Control B2 PK 3022 Steering Wheel Module-Stage 2-Low Control B2 PK 3022 Steering Wheel Module-Stage 2-Low Control
Scheme 110
C204 Sunload Sensor Jumper Harness to I/P Harness
C204 Sunload Sensor Jumper Harness to I/P Harness Connector Part Information 12064760 4-Way F Metri-Pack 150 Series (BK) Connector Part Information 12064761 4-Way M Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A L-BU/BK 590 Left Sunload Sensor Signal A L-BU/BK 590 Left Sunload Sensor Signal B GY 1548 Right Sunload Sensor Signal B GY 1548 Right Sunload Sensor Signal C YE 61 Low Reference C YE 61 Low Reference D WH 278 Ambient Light Sensor Signal D WH 278 Ambient Light Sensor Signal
C208 Steering Column Harness to Steering Wheel Controls Harness
C208 Steering Column Harness to Steering Wheel Controls Harness Connector Part Information 12064769 10-Way F Metri-Pack 150 Series (WH) Connector Part Information 12064770 10-Way M Metri-Pack 150 Series (WH) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A OG 1544 Information Up Switch Signal A OG 1544 Information Up Switch Signal 87 Cruise Control Resume/Accel Switch Signal (LS6) GY/WH 87 Cruise Control Resume/Accel Switch Signal (LS6) B PK 339 Ignition 1 Voltage B PK 339 Ignition 1 Voltage (LS6) C PK 1545 Information Down Switch Signal C PK 1545 Information Down Switch Signal 397 Cruise Control On Switch Signal (LS6) GY 397 Cruise Control On Switch Signal (LS6) D BK 351 Ground (LS6) D BK 351 Ground (LS6) E PU 1375 Remote Radio Control Supply Voltage (LA3/LY9/LY7) E PU 1375 Remote Radio Control Supply Voltage (LA3/LY9/LY7) 84 Cruise Control Set/Coast Switch Signal (LS6) D-BU 84 Cruise Control Set/Coast Switch Signal (LS6) F YE 1491 Backlight Lamps Control F YE 1491 Backlight Lamps Control YE 1491 Backlight Lamps Control G D-BU 1796 Steering Wheel Controls Signal (LA3/LY9/LY7) G D-BU 1796 Steering Wheel Controls Signal (LA3/LY9/LY7) 1796 Steering Wheel Controls Signal (LA3/LY9/LY7) 5201 Steering Wheel Controls Signal (LS6) 5201 Steering Wheel Controls Signal (LS6) H BK 350 Ground H BK 350 Ground BK 350 Ground J L-GN 28 Horn Relay Control J BK 28 Horn Relay Control TN 28 Horn Relay Control (LS6) K - - Not Used K - - Not Used
C300 Body Harness to Driver Seat Harness
C300 Body Harness to Driver Seat Harness Connector Part Information 7283-5622-40 14-Way F Hybrid (GY) Connector Part Information 7282-5622-40 14-Way M Hybrid (GY) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 RD/WH 3740 Battery Positive Voltage 1 OG 3740 Battery Positive Voltage 2 RD/WH 2440 Battery Positive Voltage (KA1) 2 OG 2440 Battery Positive Voltage (KA1) 3 PK 1501 Driver Heated Seat High/Low Signal (KA1) 3 PK 1501 Driver Heated Seat High/Low Signal (KA1) 4 L-BU/WH 181 Heated Seat Control Module Status Signal (KA1) 4 L-BU/WH 181 Heated Seat Control Module Status Signal (KA1) 5-7 - - Not Used 5-7 - - Not Used 8 RD/WH 2840 Battery Positive Voltage (A45) 8 OG 2840 Battery Positive Voltage (A45) 9 BN 41 Ignition 3 Voltage (KA1) 9 BN 41 Ignition 3 Voltage (KA1) 10 - - Not Used 10 - - Not Used 11 PU 1807 Class 2 Serial Data (A45) 11 PU 1807 Class 2 Serial Data (A45) 12 PK 5017 Seat Belt Switch - Driver - Low Reference 12 BK 5017 Seat Belt Switch - Driver - Low Reference 13 TN/WH 238 Seat Belt Switch - Driver - Signal 13 BK/WH 238 Seat Belt Switch - Driver - Signal 14 BK 550 Ground (AH8/KA1) 14 BK 550 Ground (AH8/KA1)
Scheme 111
C301 Driver Seat Harness to Body Harness
C301 Driver Seat Harness to Body Harness Connector Part Information 15304656 2-Way F GT 250 Series (YE) 15304653 4-Way F GT 250 Series (YE) Connector Part Information 15304649 6-Way M 150 Series (YE) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A BK 2118 Seat Belt Pretensioner - Driver - High Control A TN/WH 2118 Seat Belt Pretensioner - Driver - High Control B - - Not Used B - - Not Used C WH 2105 Side Impact Module - Driver - High Control C D-GN 2105 Side Impact Module - Driver - High Control D GN 2106 Side Impact Module - Driver - Low Control D BN 2106 Side Impact Module - Driver - Low Control E - - Not Used E - - Not Used F WH 2119 Seat Belt Pretensioner - Driver - Low Control F OG/BK 2119 Seat Belt Pretensioner - Driver - Low Control
Scheme 112
Scheme 113
C303 Body Harness to I/P Harness - Center
C303 Body Harness to I/P Harness - Center Connector Part Information 7283-6376-30 26-Way F Hybrid (BK) Connector Part Information 7282-6376-30 26-Way M Hybrid (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 RD/WH 2240 Battery Positive Voltage 1 RD/WH 2240 Battery Positive Voltage 2 L-BU 1960 Front Center Speaker Output (-) (U57) 2 L-BU 1960 Front Center Speaker Output (-) (U57) 3 YE 1860 Front Center Speaker Output (+) (U57) 3 YE 1880 Front Center Speaker Output (+) (U57) 4 TN 511 Left Front Low Level Audio Signal (+) 4 TN 511 Left Front Low Level Audio Signal (+) 5 L-GN 512 Right Front Low Level Audio Signal (+) 5 L-GN 512 Right Front Low Level Audio Signal (+) 6 OG 1486 FM Composite Signal 6 OG 1486 FM Composite Signal 7 BARE 5324 Drain Wire (Blunt Cut) (U2K/U2L) 7 BARE 5324 Drain Wire (U2K/U2L) 8 - - Not Used 8 - - Not Used 9 PK 5149 Cellular Microphone Signal (U2V) 9 PK 5149 Cellular Microphone Signal (U2V) GY 655 Cellular Microphone Signal (U2Y/U2X) GY 655 Cellular Microphone Signal (U2Y/U2X) 10 PK/BK 5152 Cellular Microphone Low Reference (U2V) 10 PK/BK 5152 Cellular Microphone Low Reference (U2V) BARE 1782 Drain Wire (U2Y/U2X) BARE 1782 Drain Wire (U2Y/U2X) 11 D-GN 1947 Left Front Low Level Audio Signal (-) 11 D-GN 1947 Left Front Low Level Audio Signal (-) 12 L-GN 1948 Right Front Low Level Audio Signal (-) 12 L-GN 1948 Right Front Low Level Audio Signal (-) 13 BARE 2011 Drain Wire (Blunt Cut) 13 BARE 2011 Drain Wire 14 BARE 2012 Drain Wire (Blunt Cut) 14 BARE 2012 Drain Wire 15 TN/WH 372 Audio Common (U2K/U2L) 15 TN/WH 372 Audio Common (U2K/U2L) 16 BARE 1792 Drain Wire (UAV) 16 BARE 1792 Drain Wire (Blunt Cut) (UAV) 17 D-GN/WH 368 Right Audio Signal (+) (U2K/U2L) 17 D-GN/WH 368 Right Audio Signal (+) (U2K/U2L) 18 BN/WH 367 Left Audio Signal (+) (U2K/U2L) 18 BN/WH 367 Left Audio Signal (+) (U2K/U2L) 19 WH 5343 Voice Prompt Output (-) (U2V/U2X/U2Y) 19 WH 5343 Voice Prompt Output (-) (U2V/U2X/U2Y) 20 L-BU 5141 Modem Rx (UAV) 20 L-BU 5141 Modem Rx (UAV) 21 D-GN 5142 Modem Tx (UAV) 21 D-GN 5142 Modem Tx (UAV) 22 YE/BK 5143 Modem Ground (UAV) 22 YE/BK 5143 Modem Ground (UAV) 23 BARE 701 Drain Wire (UAV) 23 BARE 701 Drain Wire (Blunt Cut) (UAV) 24 YE 5342 Voice Prompt Output (+) (U2V/U2X/U2Y) 24 YE 5342 Voice Prompt Output (+) (U2V/U2X/U2Y) 25 BARE 5344 Drain Wire (Blunt Cut) (U2V/U2X/U2Y) 25 BARE 5344 Drain Wire (U2V/U2X/U2Y) 26 BK/WH 851 Ground 26 BK/WH 851 Ground
C304 Console Harness to I/P Harness
C304 Console Harness to I/P Harness Connector Part Information 7283-5621-40 10-Way F (GY) Connector Part Information 7282-5621-40 10-Way M (GY) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 RD/WH 2040 Battery Positive Voltage 1 RD/WH 2040 Battery Positive Voltage 2 YE 772 Transmission Range Switch Signal B (M82) 2 YE 772 Transmission Range Switch Signal B (M82) 3 GY 773 Transmission Range Switch Signal C (M82) 3 GY 773 Transmission Range Switch Signal C (M82) 4 - - Not Used 4 - - Not Used 5 PU/WH 1382 LED Dimming Signal (M82) 5 PU/WH 1382 LED Dimming Signal (M82) 6 YE 243 Accessory Voltage (M82) 6 YE 243 Accessory Voltage (M82) 7 WH 776 Transmission Range Switch Signal P (M82) 7 WH 776 Transmission Range Switch Signal P (M82) 8 BK/WH 771 Transmission Range Switch Signal A (M82) 8 TN/WH 771 Transmission Range Switch Signal A (M82) 9 - - Not Used 9 - - Not Used 10 YE 1491 Backlight Lamps Control (M82) 10 YE 1491 Backlight Lamps Control (M82)
Scheme 114
C305 Headliner Harness to Body Harness
C305 Headliner Harness to Body Harness Connector Part Information 7283-5534-60 16-Way F 1.5 Series (GN) Connector Part Information 7282-5534-60 16-Way M 1.5 Series (GN) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 RD/WH 3640 Battery Positive Voltage 1 RD/WH 3640 Battery Positive Voltage 2 D-GN 44 Instrument Panel Lamps Dimmer Switch Signal 2 D-GN 44 Instrument Panel Lamps Dimmer Switch Signal 3 BARE 1489 Drain Wire (U57) 3 BARE 1489 Drain Wire (U57) 4 D-GN 1488 Noise Reduction Microphone Supply Voltage (U57) 4 D-GN 1488 Noise Reduction Microphone Supply Voltage (U57) 5 PK/BK 1597 Courtesy Lamps Switch On Signal 5 PK/BK 1597 Courtesy Lamps Switch On Signal 6 BARE 1782 Drain Wire (UE1) 6 BARE 1782 Drain Wire (UE1) 7 GY 655 Cellular Microphone Signal (UE1) 7 GY 655 Cellular Microphone Signal (UE1) 8-9 - - Not Used 8-9 - - Not Used 10 PU 1807 Class 2 Serial Data 10 PU 1807 Class 2 Serial Data 11 L-BU/BK 1688 5-Volt Reference 11 L-BU/BK 1688 5-Volt Reference 12 YE 5005 Instrument Panel Lamps Dimmer Switch Low Reference 12 YE 5005 Instrument Panel Lamps Dimmer Switch Low Reference 13 YE 1491 Backlight Lamps Control 13 YE 1491 Backlight Lamps Control 14 PU 5059 Intrusion Sensor Alarm On Signal (Export w/UA6/UA2) 14 PU 5059 Intrusion Sensor Alarm On Signal (Export w/UA6/UA2) 15 YE 5058 Intrusion Sensor Armed Signal (Export w/UA6/UA2) 15 YE 5058 Intrusion Sensor Armed Signal (Export w/UA6/UA2) 16 PU 679 Radio Master Request Display Signal (UE1) 16 PU 679 Radio Master Request Display Signal (UE1)
C306 Passenger Seat Harness to Body Harness
C306 Passenger Seat Harness to Body Harness Connector Part Information 15304656 2-Way F GT 250 Series (YE) 15304653 4-Way F GT 250 Series (YE) Connector Part Information 15304649 6-Way M 150 280 GT (YE) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A BK 2116 Seat Belt Pretensioner - Front Passenger - High Control A L-GN 2116 Seat Belt Pretensioner - Front Passenger - High Control B - - Not Used B - - Not Used C WH 2103 Side Impact Module - Front Passenger - High Control C GY 2103 Side Impact Module - Front Passenger - High Control D D-GN 2104 Side Impact Module - Front Passenger - Low Control D D-BU 2104 Side Impact Module - Front Passenger - Low Control E - - Not Used E - - Not Used F WH 2117 Seat Belt Pretensioner - Front Passenger - Low Control F OG 2117 Seat Belt Pretensioner - Front Passenger - Low Control
C307 Body Harness to Passenger Seat Harness
C307 Body Harness to Passenger Seat Harness Connector Part Information 7283-5622-40 14-Way F Hybrid (GY) Connector Part Information 7282-5622-40 14-Way M Hybrid (GY) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 RD/WH 3740 Battery Positive Voltage (AH8) 1 OG 3740 Battery Positive Voltage (AH8) 2 RD/WH 2540 Battery Positive Voltage (KA1) 2 OG 2540 Battery Positive Voltage (KA1) 3 PK/BK 1503 Passenger Heated Seat High/Low Signal (KA1) 3 PK 1503 Passenger Heated Seat High/Low Signal (KA1) 4 D-BU 2181 Passenger Heated Seat Control Module Status Signal (KA1) 4 L-BU/WH 2181 Passenger Heated Seat Control Module Status Signal (KA1) 5-8 - - Not Used 5-8 - - Not Used 9 BN 41 Ignition 3 Voltage (KA1) 9 BN 41 Ignition 3 Voltage (KA1) 10-13 - - Not Used 10-13 - - Not Used 14 BK 550 Ground (AH8/KA1) 14 BK 550 Ground (AH8/KA1)
C308 Headliner Harness to Body Harness
C308 Headliner Harness to Body Harness Connector Part Information 7283-5535-90 16-Way F YESC 1.5 (BU) Connector Part Information 7282-5535-90 16-Way M YESC 1.5 (BU) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 D-BU/WH 149 Courtesy Lamp Supply Voltage 1 D-BU/WH 149 Courtesy Lamp Supply Voltage 2 GY/BK 1798 Ground (UE1) 2 GY/BK 1798 Ground (UE1) 3 PU 1156 Keypad Red LED Signal (UE1) 3 PU 1156 Keypad Red LED Signal (UE1) 4 BN 1941 Ignition 3 Voltage (UE1) 4 BN 1941 Ignition 3 Voltage (UE1) 5 - - Not Used 5 - - Not Used 6 GY 157 Courtesy Lamp Control 6 GY 157 Courtesy Lamp Control 7 BK 850 Ground 7 BK 850 Ground 8 L-GN 24 Backup Lamp Supply Voltage (DD8) 8 L-GN 24 Backup Lamp Supply Voltage (DD8) 9 PK 1339 Ignition 1 Voltage (DD8) 9 PK 1339 Ignition 1 Voltage (DD8) 10-11 - - Not Used 10-11 - - Not Used 12 BK/WH 851 Ground (DD8) 12 BK/WH 851 Ground (DD8) 13 TN 1856 Left Front Tweeter Speaker Output (+) 13 TN 1856 Left Front Tweeter Speaker Output (+) 14 YE 1956 Left Front Tweeter Speaker Output (-) 14 YE 1956 Left Front Tweeter Speaker Output (-) 15 L-GN 1852 Right Front Tweeter Speaker Output (+) 15 L-GN 1852 Right Front Tweeter Speaker Output (+) 16 PU 1952 Right Front Tweeter Speaker Output (-) 16 PU 1952 Right Front Tweeter Speaker Output (-)
Scheme 115
C309 Headliner Harness to Sunroof Harness (CF5)
C309 Headliner Harness to Sunroof Harness (CF5) Connector Part Information 7283-5533-40 10-Way F Header Series (GY) Connector Part Information 7282-5533-40 10-Way M Header Series (GY) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 D-BU 128 Sunroof Switch Low Reference 1 D-BU 128 Sunroof Switch Low Reference 2 L-BU 5027 Sunroof Switch - Data 1 2 L-BU 5027 Sunroof Switch - Data 1 3 BN 5028 Sunroof Switch - Data 2 3 BN 5028 Sunroof Switch - Data 2 4 OG 5029 Sunroof Switch - Data 3 4 OG 5029 Sunroof Switch - Data 3 5 PK 5031 Sunroof Switch - Data 5 5 PK 5031 Sunroof Switch - Data 5 6 PU 5032 Sunroof Switch - Data 6 6 PU 5032 Sunroof Switch - Data 6 7 TN 5030 Sunroof Switch - Data 4 7 TN 5030 Sunroof Switch - Data 4 8-10 - - Not Used 8-10 - - Not Used
Scheme 116
C310 Sunroof Harness to Body Harness (CF5)
C310 Sunroof Harness to Body Harness (CF5) Connector Part Information 12129489 3-Way F Metri-Pack 280 Series (BK) Connector Part Information 12129490 3-Way M Metri-Pack 280 Series (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A BK 1050 Ground (CF5) A BK 1050 Ground (CF5) B BN 834 Vehicle Speed Signal (CF5) B BN 834 Vehicle Speed Signal (CF5) C D-BU 75 RAP Relay Switch Supply Voltage (CF5) C D-BU 75 RAP Relay Switch Supply Voltage (CF5)
Scheme 117
C311 Headliner Harness to Body Harness
C311 Headliner Harness to Body Harness Connector Part Information 12059251 2-Way F Metri-Pack 150 Series (RD) Connector Part Information 12059252 2-Way M Metri-Pack 150 Series (RD) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A - - Not Used A - - Not Used B RD 1486 FM Composite Signal B OG 1486 FM Composite Signal
C312 Console Harness to Body Harness
C312 Console Harness to Body Harness Connector Part Information 7283-5621-40 10-Way F YESC (GY) Connector Part Information 7282-5621-40 10-Way M YESC (GY) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 BK 450 Ground 1 BK 450 Ground 2 BK/WH 451 Ground (M82) 2 BK/WH 451 Ground (M82) 3 L-GN 5053 Winter Mode Switch Signal (M82) 3 L-GN 5053 Winter Mode Switch Signal (M82) 4 PU 2056 Auxiliary Video High Signal (U2Y/U2X) 4 PU 2056 Auxiliary Video High Signal (U2Y/U2X) 5 - - Not Used 5 - - Not Used 6 GY 5054 Sport Mode Switch Signal (M82) 6 GY 5054 Sport Mode Switch Signal (M82) 7 BARE 814 Drain Wire (U2Y/U2X) 7 BARE 814 Drain Wire (U2Y/U2X) 8 WH 2058 Auxiliary Audio Right Signal (U2Y/U2X) 8 WH 2058 Auxiliary Audio Right Signal (U2Y/U2X) 9 YE 2059 Auxiliary Audio Left Signal (U2Y/U2X) 9 YE 2059 Auxiliary Audio Left Signal (U2Y/U2X) 10 BARE 814 Drain Wire (U2Y/U2X) 10 BARE 814 Drain Wire (U2Y/U2X)
C321 I/P Harness to HVAC Harness (LHD)
C321 I/P Harness to HVAC Harness (LHD) Connector Part Information 7283-5534-60 16-Way F 1.5 Series Weather Pack (GN) Connector Part Information 7282-5534-60 16-Way M 1.5 Series Weather Pack (GN) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 D-BU 1646 Passenger Air Temperature Door Position 1 D-BU 1646 Passenger Air Temperature Door Position 2 WH/BK 1236 Passenger Air Temperature Door Control B 2 WH/BK 1236 Passenger Air Temperature Door Control B 3 GY/BK 2778 Passenger Air Temperature Door Control A 3 GY/BK 2778 Passenger Air Temperature Door Control A 4 YE 1318 Mode Door Control B 4 PK 1318 Mode Door Control B 5 YE/BK 1814 Lower Mode Door Position Signal 5 GY 1814 Lower Mode Door Position Signal 6 TN 2273 Mode Door Control A 6 L-BU 2273 Mode Door Control A 7-9 - - Not Used 7-9 - - Not Used 10 GY 705 5-Volt Reference 10 GY 705 5-Volt Reference 11 L-BU 733 Driver Air Temperature Door Position Signal 11 L-BU 733 Driver Air Temperature Door Position Signal 12 YE 1791 Driver Air Temperature Door Control A 12 YE 1791 Driver Air Temperature Door Control A 13 D-BU 1199 Driver Air Temperature Door Control B 13 D-BU 1199 Driver Air Temperature Door Control B 14 YE 61 Low Reference 14 YE 61 Low Reference 15 GY 731 Evaporator Temperature Sensor Signal 15 GY 731 Evaporator Temperature Sensor Signal 16 - - Not Used 16 - - Not Used
C321 I/P Harness to HVAC Harness (RHD)
C321 I/P Harness to HVAC Harness (RHD) Connector Part Information 7182-5534-60 16-Way 1.5 Series Weather Pack (GN) Connector Part Information 7182-5534-60 16-Way 1.5 Series Weather Pack (GN) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 L-BU 733 Driver Air Temperature Door Position Signal 1 L-BU 733 Driver Air Temperature Door Position Signal 2 D-BU 1199 Driver Air Temperature Door Control B 2 D-BU 1199 Driver Air Temperature Door Control B 3 YE 1791 Driver Air Temperature Door Control A 3 YE 1791 Driver Air Temperature Door Control A 4 YE 1318 Mode Door Control B 4 PK 1318 Mode Door Control B 5 YE/BK 1814 Mode Door Position Signal 5 GY 1814 Mode Door Position Signal 6 TN 2273 Mode Door Control A 6 L-BU 2273 Mode Door Control A 7-9 - - Not Used 7-9 - - Not Used 10 GY 705 5-Volt Reference 10 GY 705 5-Volt Reference 11 D-BU 1646 Passenger Air Temperature Door Position Signal 11 D-BU 1646 Passenger Air Temperature Door Position Signal 12 GY/BK 2778 Passenger Air Temperature Door Control A 12 GY/BK 2778 Passenger Air Temperature Door Control A 13 WH/BK 1236 Passenger Air Temperature Door Control B 13 WH/BK 1236 Passenger Air Temperature Door Control B 14 YE 61 Low Reference 14 YE 61 Low Reference 15 GY 731 Evaporator Temperature Sensor Signal 15 GY 731 Evaporator Temperature Sensor Signal 16 - - Not Used 16 - - Not Used
C322 Body Harness to Rear Shelf Harness
C322 Body Harness to Rear Shelf Harness Connector Part Information 7283-5622-40 14-Way F Hybrid (GY) Connector Part Information 7282-5622-40 14-Way M Hybrid (GY) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 L-GN/BK 1794 Left (U66) or Rear (U57) Subwoofer Speaker Output (-) 1 L-GN/BK 1794 Left (U66) or Rear (U57) Subwoofer Speaker Output (-) 2 - - Not Used 2 - - Not Used 3 OG/BK 737 Rear Compartment Lamp Control 3 OG/BK 737 Rear Compartment Lamp Control 4 L-BU/BK 315 Right Subwoofer Speaker Output (-) (U66) 4 L-BU/BK 315 Right Subwoofer Speaker Output (-) (U66) 5 D-BU/WH 149 Courtesy Lamp Supply Voltage 5 D-BU/WH 149 Courtesy Lamp Supply Voltage 6 D-GN 1795 Right Subwoofer Speaker Output (+) (U66) 6 D-GN 1795 Right Subwoofer Speaker Output (+) (U66) 7 D-BU/WH 346 Left (U66) or Rear (U57) Subwoofer Speaker Output (+) 7 D-BU/WH 346 Left (U66) or Rear (U57) Subwoofer Speaker Output (+) 8-14 - - Not Used 8-14 - - Not Used
C323 I/P Harness to HVAC Harness
C323 I/P Harness to HVAC Harness Connector Part Information 7283-1064 6-Way F Yazaki (WH) Connector Part Information 7282-1064 6-Way M Yazaki (WH) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 L-BU 188 Blower Motor Control Processor Supply Voltage 1 L-BU 188 Blower Motor Control Processor Supply Voltage 2 BK 450 Ground 2 BK 450 Ground 3 BN 41 Ignition 3 Voltage 3 TN 41 Ignition 3 Voltage 4 PU 1838 Recirculation Door Control A 4 PU 1838 Recirculation Door Control A 5 D-GN 1614 Recirculation Door Control B 5 D-GN 1614 Recirculation Door Control B 6 GY/BK 754 Blower Motor Speed Control 6 GY/BK 754 Blower Motor Speed Control
Scheme 118
Scheme 119
C410 Body Harness to Left Tail Lamp Harness
C410 Body Harness to Left Tail Lamp Harness Connector Part Information 12047886 8-Way F Metri-Pack 150 Series (BK) Connector Part Information 12045688 8-Way M Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A PU 709 Left Park Lamp Supply Voltage (w/o T79) A D-BU 709 Left Park Lamp Supply Voltage (w/o T79) 1472 Left Park Lamp Supply Voltage (w/T79) PU 1472 Left Park Lamp Supply Voltage (w/T79) B WH 17 Stop Lamp Supply Voltage (w/o T79) B WH 17 Stop Lamp Supply Voltage (w/o T79) - - Not Used (w/T79) - - Not Used (w/T79) C L-BU/WH 1314 Left Turn Signal Indicator Lamp Supply Voltage C L-BU/WH 1314 Left Turn Signal Indicator Lamp Supply Voltage D BK 850 Ground D BK 850 Ground E D-BU/WH 1315 Right Turn Signal Indicator Lamp Supply Voltage E - - Not Used F PU 709 Left Park Lamp Supply Voltage (w/o T79) F PU 709 Left Park Lamp Supply Voltage (w/o T79) - - Not Used (w/T79) - - Not Used (w/T79) G WH 17 Stop Lamp Supply Voltage (w/T79) G WH/BK 17 Stop Lamp Supply Voltage H PU 709 Left Park Lamp Supply Voltage H OG 709 Left Park Lamp Supply Voltage
C411 Body Harness to Right Tail Lamp Harness
C411 Body Harness to Right Tail Lamp Harness Connector Part Information 12047886 8-Way F Metri-Pack 150 Series (BK) Connector Part Information 12045688 8-Way M Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A BN/WH 309 Right Park Lamp Supply Voltage (w/o T79) A D-BU 1473 Right Park Lamp Supply Voltage (w/o T79) BN/WH 1473 Right Park Lamp Supply Voltage (w/T79) BN/WH 1473 Right Park Lamp Supply Voltage (w/T79) B WH 17 Stop Lamp Supply Voltage (w/o T79) B WH 17 Stop Lamp Supply Voltage (w/o T79) - - Not Used (w/T79) - - Not Used (w/T79) C D-BU/WH 1315 Right Turn Signal Indicator Lamp Supply Voltage C L-BU/WH 1315 Right Turn Signal Indicator Lamp Supply Voltage D BK 1050 Ground D BK 1050 Ground E - - Not Used E - - Not Used F BN/WH 309 Right Park Lamp Supply Voltage (w/o T79) F PU 309 Right Park Lamp Supply Voltage (w/o T79) - - Not Used (w/T79) - - Not Used (w/T79) G WH 17 Stop Lamp Supply Voltage (w/T79) G WH/BK 17 Stop Lamp Supply Voltage (w/T79) H BN/WH 309 Right Park Lamp Supply Voltage H OG 1473 Right Park Lamp Supply Voltage
C420 Fuel Tank Harness to Body Harness (LA3/LY9/LY7)
C420 Fuel Tank Harness to Body Harness (LA3/LY9/LY7) Connector Part Information 15326660 10-Way F Delphi Sealed 5.8 (BK) Connector Part Information 7282-5946-30 10-Way M Delphi Sealed 5.8 (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A GY 120 Fuel Pump Supply Voltage A GY 120 Fuel Pump Supply Voltage B D-GN 890 Fuel Tank Pressure Sensor Signal B D-GN 890 Fuel Tank Pressure Sensor Signal C GY 2709 5-Volt Reference C GY 596 5-Volt Reference D WH 1310 EVAP Canister Vent Solenoid Control D WH 1310 EVAP Canister Vent Solenoid Control E TN 2759 Low Reference E TN 452 Low Reference F L-BU 1936 Fuel Level Sensor Signal - Primary F D-BU 1936 Fuel Level Sensor Signal - Primary G D-BU 1937 Fuel Level Sensor Signal - Secondary G L-BU 1937 Fuel Level Sensor Signal - Secondary H - - Not Used H - - Not Used J PK 1540 Battery Positive Voltage J RD/WH 1540 Battery Positive Voltage K BK 1050 Ground K BK 1050 Ground
Scheme 120
C421 Body Harness to License Lamp Assembly Harness (Domestic)
C421 Body Harness to License Lamp Assembly Harness (Domestic) Connector Part Information 12047785 4-Way F Metri-Pack 150 Series (BK) Connector Part Information 12047786 4-Way M Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A YE 32 Instrument Panel Lamp Fuse Supply Voltage - 1 A YE 32 Instrument Panel Lamp Fuse Supply Voltage - 1 B L-GN 24 Backup Lamp Supply Voltage B L-GN 24 Backup Lamp Supply Voltage C WH 17 Stop Lamp Supply Voltage C WH 17 Stop Lamp Supply Voltage D BK 850 Ground D BK 850 Ground
C421 Body Harness to License Lamp Assembly Harness (Export)
C421 Body Harness to License Lamp Assembly Harness (Export) Connector Part Information 12064762 6-Way F Metri-Pack 150 Series (GY) Connector Part Information 12064763 6-Way M Metri-Pack 150 Series (GY) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A YE 32 Instrument Panel Lamp Fuse Supply Voltage - 1 A YE 32 Instrument Panel Lamp Fuse Supply Voltage - 1 B L-GN 24 Backup Lamp Supply Voltage B L-GN 24 Backup Lamp Supply Voltage C WH 17 Stop Lamp Supply Voltage C WH 17 Stop Lamp Supply Voltage D BK 850 Ground D BK 850 Ground E OG 122 Rear Fog Lamp Supply Voltage E OG 122 Rear Fog Lamp Supply Voltage F - - Not Used F - - Not Used
C422 Body Harness to Fuel Tank Harness (LS6)
C422 Body Harness to Fuel Tank Harness (LS6) Connector Part Information 15326660 10-Way F GT 280 Series Sealed 5.8 (BK) Connector Part Information 15326661 10-Way M GT 280 Series Sealed 5.8 (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A GY 120 Fuel Pump Supply Voltage A GY 120 Fuel Pump Supply Voltage B D-GN 890 Fuel Tank Pressure Sensor Signal B D-GN 890 Fuel Tank Pressure Sensor Signal C GY 596 5-Volt Reference C GY 2709 5-Volt Reference D WH 1310 EVAP Canister Vent Solenoid Control D WH 1310 EVAP Canister Vent Solenoid Control E TN 452 Low Reference E TN 2759 Low Reference F D-BU 1936 Fuel Level Sensor Signal - Primary F L-BU 1936 Fuel Level Sensor Signal - Primary G L-BU 1937 Fuel Level Sensor Signal - Secondary G D-BU 1937 Fuel Level Sensor Signal - Secondary H - - Not Used H - - Not Used J RD/WH 1540 Battery Positive Voltage J PK 1540 Battery Positive Voltage K BK 1050 Ground K BK 1050 Ground
C500 Body Harness to Left Front Door Harness
C500 Body Harness to Left Front Door Harness Connector Part Information 7283-5622-40 14-Way F Hybrid Yazaki (GY) Connector Part Information 7282-5622-40 14-Way M Hybrid Yazaki (GY) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 RD/WH 1040 Battery Positive Voltage 1 RD/WH 1040 Battery Positive Voltage 2 RD/WH 640 Battery Positive Voltage 2 RD/WH 640 Battery Positive Voltage 3 PU 1807 Class 2 Serial Data 3 PU 1807 Class 2 Serial Data 4-5 - - Not Used 4-5 - - Not Used 6 BK/WH 351 Ground 6 BK/WH 351 Ground 7 BK 350 Ground 7 BK 350 Ground 8 BK/WH 351 Ground 8 BK/WH 351 Ground 9 L-BU 1957 Left Front Midrange Speaker Output (-) (w/U66) 9 L-BU 1957 Left Front Midrange Speaker Output (-) (w/U66) TN 1856 Left Front Tweeter Speaker Output (+) (w/U57) TN 1856 Left Front Tweeter Speaker Output (+) (w/U57) 10 D-BU 1857 Left Front Midrange Speaker Output (+) (w/U66) 10 D-BU 1857 Left Front Midrange Speaker Output (+) (w/U66) YE 1956 Left Front Tweeter Speaker Output (-) (w/U57) YE 1956 Left Front Tweeter Speaker Output (-) (w/U57) 11 D-BU/WH 149 Courtesy Lamp Supply Voltage 11 D-BU/WH 149 Courtesy Lamp Supply Voltage 12 GY 157 Courtesy Lamp Control 12 GY 157 Courtesy Lamp Control 13-14 - - Not Used 13-14 - - Not Used
C501 Left Front Door Harness to Left Front Door Trim Harness
C501 Left Front Door Harness to Left Front Door Trim Harness Connector Part Information 7283-4848-30 12-Way F Dock and Lock (WH) Connector Part Information 7282-4848-30 12-Way M Dock and Lock (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 YE 1491 Backlight Lamps Control 1 YE 1491 Backlight Lamps Control 2 D-BU/WH 149 Courtesy Lamp Supply Voltage 2 D-BU/WH 149 Courtesy Lamp Supply Voltage 3 GY 157 Courtesy Lamp Control 3 GY 157 Courtesy Lamp Control 4 RD/WH 640 Battery Positive Voltage 4 RD/WH 640 Battery Positive Voltage 5 PU 1807 Class 2 Serial Data 5 PU 1807 Class 2 Serial Data 6 BK/WH 351 Ground 6 BK/WH 351 Ground 7-12 - - Not Used 7-12 - - Not Used
Scheme 121
Scheme 122
C600 Body Harness to Right Front Door Harness
C600 Body Harness to Right Front Door Harness Connector Part Information 7283-5622-40 14-Way F Yazaki Hybrid (GY) Connector Part Information 7282-5622-40 14-Way M Yazaki Hybrid (GY) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 RD/WH 1040 Battery Positive Voltage 1 RD/WH 1040 Battery Positive Voltage 2 RD/WH 740 Battery Positive Voltage 2 RD/WH 740 Battery Positive Voltage 3 PU 1807 Class 2 Serial Data 3 PU 1807 Class 2 Serial Data 4 BK/WH 451 Ground 4 BK/WH 451 Ground 5-7 - - Not Used 5-7 - - Not Used 8 D-GN 1953 Right Front Midrange Speaker Output (-) (w/U66) 8 D-GN 1953 Right Front Midrange Speaker Output (-) (w/U66) PU 1952 Right Front Tweeter Speaker Output (-) (w/U57) PU 1952 Right Front Tweeter Speaker Output (-) (w/U57) 9 OG 1853 Right Front Midrange Speaker Output (+) (w/U66) 9 OG 1853 Right Front Midrange Speaker Output (+) (w/U66) L-GN 1852 Right Front Tweeter Speaker Output (+) (w/U57) L-GN 1852 Right Front Tweeter Speaker Output (+) (w/U57) 10 D-BU/WH 149 Courtesy Lamp Supply Voltage 10 D-BU/WH 149 Courtesy Lamp Supply Voltage 11 GY 157 Courtesy Lamp Control 11 GY 157 Courtesy Lamp Control 12-13 - - Not Used 12-13 - - Not Used 14 BK 450 Ground 14 BK 450 Ground
C601 Right Front Door Harness to Right Front Door Trim Harness
C601 Right Front Door Harness to Right Front Door Trim Harness Connector Part Information 7283-4848-30 12-Way F Dock and Lock (WH) Connector Part Information 7282-4848-30 12-Way M Dock and Lock (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 YE 1491 Backlight Lamps Control 1 YE 1491 Backlight Lamps Control 2 OG 1189 Power Window Switch Front Passenger Down Signal 2 BN 5295 Power Window Switch Front Passenger Down Signal 3 PU 2765 Power Window Switch Front Passenger Express Signal 3 PU 2765 Power Window Switch Front Passenger Express Signal 4 D-GN 1184 Power Window Switch Front Passenger Up Signal 4 D-GN 1184 Power Window Switch Front Passenger Up Signal 5 BK/WH 451 Ground 5 BK/WH 451 Ground 6 L-BU 244 Passenger Door Lock Switch Lock Signal 6 L-BU 244 Passenger Door Lock Switch Lock Signal 7 D-BU 245 Passenger Door Lock Switch Unlock Signal 7 D-BU 245 Passenger Door Lock Switch Unlock Signal 8 D-BU/WH 149 Courtesy Lamp Supply Voltage 8 D-BU/WH 149 Courtesy Lamp Supply Voltage 9 GY 157 Courtesy Lamp Control 9 GY 157 Courtesy Lamp Control 10-12 - - Not Used 10-12 - - Not Used
C700 Body Harness to Left Rear Door Harness
C700 Body Harness to Left Rear Door Harness Connector Part Information 7283-5622-40 14-Way F Yazaki Hybrid (GY) Connector Part Information 7282-5622-40 14-Way M Yazaki Hybrid (GY) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 RD/WH 1040 Battery Positive Voltage 1 RD/WH 1040 Battery Positive Voltage 2 RD/WH 840 Battery Positive Voltage 2 RD/WH 840 Battery Positive Voltage 3 PU 1807 Class 2 Serial Data 3 PU 1807 Class 2 Serial Data 4 BK/WH 351 Ground 4 BK/WH 351 Ground 5 TN 1859 Left Rear Midrange Speaker Output (+) 5 TN 1859 Left Rear Midrange Speaker Output (+) 6 WH 1959 Left Rear Midrange Speaker Output (-) 6 WH 1959 Left Rear Midrange Speaker Output (-) 7 BK 350 Ground 7 BK 350 Ground 8-14 - - Not Used 8-14 - - Not Used
C701 Left Rear Door Harness to Left Rear Door Trim Harness
C701 Left Rear Door Harness to Left Rear Door Trim Harness Connector Part Information 7283-4848-30 12-Way F Dock and Lock (WH) Connector Part Information 7282-4848-30 12-Way M Dock and Lock (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 YE 1491 Backlight Lamps Control 1 YE 1491 Backlight Lamps Control 2 YE 1187 Power Window Switch Left Rear Down Signal 2 YE 1187 Power Window Switch Left Rear Down Signal 3 WH 1185 Power Window Switch Left Rear Up Signal 3 WH 1185 Power Window Switch Left Rear Up Signal 4 BK/WH 351 Ground 4 BK/WH 351 Ground 5 L-GN 5048 Power Window Switch Left Rear Express Signal 5 L-GN 5048 Power Window Switch Left Rear Express Signal 6 TN 1859 Left Rear Midrange Speaker Output (+) 6 TN 1859 Left Rear Midrange Speaker Output (+) 7 WH 1959 Left Rear Midrange Speaker Output (-) 7 WH 1959 Left Rear Midrange Speaker Output (-) 8-12 - - Not Used 8-12 - - Not Used
C800 Body Harness to Right Rear Door Harness
C800 Body Harness to Right Rear Door Harness Connector Part Information 7283-5622-40 14-Way F Yazaki Hybrid (GY) Connector Part Information 7282-5622-40 14-Way M Yazaki Hybrid (GY) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 RD/WH 1040 Battery Positive Voltage 1 RD/WH 1040 Battery Positive Voltage 2 RD/WH 840 Battery Positive Voltage 2 RD/WH 840 Battery Positive Voltage 3 PU 1807 Class 2 Serial Data 3 PU 1807 Class 2 Serial Data 4 BK/WH 451 Ground 4 BK/WH 451 Ground 5 TN 1855 Right Rear Midrange Speaker Output (+) 5 TN 1855 Right Rear Midrange Speaker Output (+) 6 OG 1955 Right Rear Midrange Speaker Output (-) 6 OG 1955 Right Rear Midrange Speaker Output (-) 7 BK 450 Ground 7 BK 450 Ground 8-14 - - Not Used 8-14 - - Not Used
C801 Right Rear Door Harness to Right Rear Door Trim Harness
C801 Right Rear Door Harness to Right Rear Door Trim Harness Connector Part Information 7283-4848-30 12-Way F Dock and Lock (WH) Connector Part Information 7282-4848-30 12-Way M Dock and Lock (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 YE 1491 Backlight Lamps Control 1 YE 1491 Backlight Lamps Control 2 D-GN 1188 Power Window Switch Right Rear Down Signal 2 D-GN 1188 Power Window Switch Right Rear Down Signal 3 GY 1186 Power Window Switch Right Rear Up Signal 3 GY 1186 Power Window Switch Right Rear Up Signal 4 BK/WH 451 Ground 4 BK/WH 451 Ground 5 L-GN 5049 Power Window Switch Right Rear Express Signal 5 L-GN 5049 Power Window Switch Right Rear Express Signal 6 TN 1855 Right Rear Midrange Speaker Output (+) 6 TN 1855 Right Rear Midrange Speaker Output (+) 7 OG 1955 Right Rear Midrange Speaker Output (-) 7 OG 1955 Right Rear Midrange Speaker Output (-) 8-12 - - Not Used 8-12 - - Not Used
Splice Pack SP102 (LA3/LY9/LY7)
Splice Pack SP102 (LA3/LY9/LY7) Connector Part Information 7123-1508 22-Way F JC Type (WH) Pin Wire Color Circuit No. Function 1-3 OG 5371 BAS Relay Coil Supply Voltage 4 OG 5371 BAS Relay Coil Supply Voltage (M82) 5 - - Not Used 6-8 YE 581 TAC Motor Control - 1 (LA3/LY9) 9-11 BN 582 TAC Motor Control - 2 (LA3/LY9) 12 GY 596 5-Volt Reference (LY7) 13-14 GY 596 5-Volt Reference 15 GY 474 5-Volt Reference (LA3/LY9) GY 596 5-Volt Reference (LY7) 16-22 - - Not Used
Splice Pack SP200
Splice Pack SP200 Connector Part Information 7123-1509 33-Way F (WH) Pin Wire Color Circuit No. Function 1 L-BU/WH 1314 Left Turn Signal Indicator Lamp Supply Voltage (Export w/T62/T65) 2-5 L-BU/WH 1314 Left Turn Signal Indicator Lamp Supply Voltage 6 L-BU/WH 1314 Left Turn Signal Indicator Lamp Supply Voltage (w/o T62/T65) 7 - - Not Used 8-11 PK 3 Ignition 1 Voltage 12-16 YE 61 Low Reference 17-18 - - Not Used 19-22 D-BU/WH 1315 Right Turn Signal Indicator Lamp Supply Voltage 23-26 PU 1807 Class 2 Serial Data 27 - - Not Used 28-30 PK 839 Ignition 1 Voltage (M35/M12/MN6) 31 TN/WH 99 Windshield Washer Fluid Level Signal (CE4) 32-33 TN/WH 99 Windshield Washer Fluid Level Signal
Splice Pack SP300
Splice Pack SP300 Connector Part Information 7123-1509 33-Way F (WH) Pin Wire Color Circuit N0. Function 1-2 PU 1807 Class 2 Serial Data 3 PU 1807 Class 2 Serial Data (LHD w/A45) 4-6 PU 1807 Class 2 Serial Data 7 - - Not Used 8-10 YE 1956 Left Front Tweeter Speaker Output (-) (U57) 11 - - Not Used 12-14 PU 1952 Right Front Tweeter Speaker Output (-) (U57) 15-16 - - Not Used 17-19 L-GN 1852 Right Front Tweeter Speaker Output (+) (U57) 20-22 TN 1856 Left Front Tweeter Speaker Output (+) (U57) 23-33 - - Not Used
Splice Pack SP303
Splice Pack SP303 Connector Part Information 7283-1100 10-Way F (WH) (Indexing May Vary) Pin Wire Color Circuit No. Function 1 PU 1807 Class 2 Serial Data 2 PU 1807 Class 2 Serial Data (RHD w/A45) 3 PU 1807 Class 2 Serial Data (UE1) 4-5 PU 1807 Class 2 Serial Data 6 PU 1807 Class 2 Serial Data (Export w/U2Y/U2X) 7 PU 1807 Class 2 Serial Data (U2K/U2L) 8-9 PU 1807 Class 2 Serial Data 10 - - Not Used
