Accessory Power Socket Cadillac CTS I

Scheme 90

Scheme 91

Power Outlet Connector End Views

Auxiliary Power Outlet Terminal Identification Connector Part Information 12176446 3-Way F Metri-Pack 280 Series Flexlock (BK) Pin Wire Color Circuit No. Function A RD/WH 2040 Battery Positive Voltage B - - Not Used C BK 450 Ground

Cigar Lighter Terminal Identification Connector Part Information 12047699 2-Way F Misc. Series (GY) Pin Wire Color Circuit No. Function A RD/WH 3540 Battery Positive Voltage B BK 450 Ground

Tools Required

J 42059 Cigar Lighter Socket Remover. See Special Tools and Equipment .

Scheme 92

Scheme 93

1. Remove the cigar lighter fuse.
2. Remove the cigar lighter element.
3. Remove the cigar lighter housing by placing one side of the T portion of J 42059 into the tab window and the other side into the opposite tab window. See «Special Tools and Equipment»(/cadillac/cts/i-2002-2007/remont/body-electrical/#accessory-power-socket) . Pull the lighter housing straight out.
4. Remove the tool from the lighter housing.
5. Pull the housing (3) and the retainer (2) out of the ash tray.
6. Disconnect the electrical connector (1) from the housing.
7. Remove the retainer from the housing.

Scheme 94

Scheme 95

Scheme 96

1. Install the cigar lighter retainer (1) to the ash tray, by pressing the retainer into place until fully seated.
2. Connect the electrical connector (2) to the retainer.
3. Align the housing (2) key way, to the key slot in the retainer ring (1).
4. Press the housing into place until the housing is fully seated.
5. Install the cigar lighter fuse.
6. Install the cigar lighter element.

Special Tools

Special Tools Illustration Tool Number/Description J 42059 Cigar Lighter Socket Remover
